SW115P - SW118P
Passive Subwoofer
USER MANUAL
FCC COMPLIANCE NOTICE
This device complies with part 15 of the FCC rules. Operaon is subject to the following two condions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operaon.
CAUTION: Changes or modi ca ons not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful interference in a residenal installaon. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instrucon manual, may cause harmful interference to radio communicaons. However, there is no guarantee that interference will not occur in a parcular installaon. If this equipment does cause harmful interference to radio or television recepon, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government oce, for details of where and how they can
purchase contract. This product should not be mixed with other commercial wastes for disposal.
take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and condions of the
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sucient magnitude to constute a risk of electric shock to persons.
The exclamaon point within an equilateral triangle is intended to alert the user to the presence of important operang and maintenance (servicing) instrucons in the literature accompanying the appliance.
The informaon contained in this publicaon has been carefully prepared and checked. However no responsibility will be taken for any errors. All rights are reserved and this document cannot be copied, photocopied or reproduced in part or completely without written consent being obtained in advance from CELECTRON. CELECTRON reserves the right to make any aesthetic, functional or design modification to any of its products without any prior notice. CELECTRON assumes no responsibility for the use or application of the products or circuits described herein.
INDEX
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . 4
FREQUENCY RESPONSE . . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
INPUT PANEL (FIG.1) . . . . . . . . . . . . . . . . . . . . . . . 6
CONNECTIONS (FIG.2) . . . . . . . . . . . . . . . . . . . . . . 6
CONFIGURATIONS (FIG.3) . . . . . . . . . . . . . . . . . . . 6
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . . 8
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . .8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . 8
CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PACKAGING, SHIPPING AND COMPLAINT . . . . . . .9
WARRANTY AND PRODUCTS RETURN . . . . . . . . . .9
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . .9
POWER SUPPLY AND MAINTENANCE . . . . . . . . . .9
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . 10
INSTRUCTIONS (FIG. 1 / 2 / 3) . . . . . . . . . . . . . . . 10
4
MODEL
SW115P
BPS enclosure subwoofer
15” woofer with 3"VC
40 Hz - 160 Hz
8 ohm
500 W
1000 W
103 dB @ 1W/1m
160 Hz 12 dB/oct. LP 6 dB/oct. HP
-
-
-
-
-
2 x NEUTRIK NL4 SPEAKON (IN / OUT)
15 / 18mm plywood
Black an -scratch paint
4 x 75mm wheels
1 x top
2 x sides
27.7 Kg (61 lb)
System type
Loudspeaker
Frequency Response
Nominal Impedance
Power Handling (cont.)
Power Handling (peak)
Sensi vity
Crossover Frequency
Max SPL at 1mt (peak)
Total peak power
Ampli er Cont.Power
Ampli er Type
Power Supply type
Input Impedance
Input Sensi vity
Controls
Connectors
Power Supply
Max Consump on
Rated Consump on*
Construc on
Cabinet Colour
Transport System
Pole Adapter
Handles
Weight
Dimensions (W x H x D)
430 x 550 x 600 mm
* Rated consump on is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.
TECHNICAL SPECIFICATIONS
FREQUENCY RESPONSE
SW115P (fi ltered)
SW118P (Without Filter)
2k1k500200100502020 2kHz
dB
100
90
80
70
-
-
-
-
-
-
SW118P
Vented enclosure subwoofer
18” woofer with 3"VC
36 Hz - 1KHz (w/o filter)Hz
8 ohm
650 W
1300 W
104 dB @ 1W/1m
80-125Hz 24dB/oct.
-
-
-
-
-
2 x NEUTRIK NL4 SPEAKON (IN / OUT)
15 / 18mm plywood
Black an -scratch paint
4 x 75mm wheels
1 x top
2 x sides
34 Kg (75 lb)
520 x 660 x 740 mm
-
-
-
-
-
-
5002001005020 2k1k Hz
dB
100
90
80
70
UNFILTERED
DIMENSION
SW118A
26.0"
66 cm
55 cm
21.7"
43 cm
16.9"
Pole adapter
74 cm
29.1"
60 cm
23.6"
20.5"
52 cm
SW115A
POLE ADAPTER
5
70 cm
27.6"
6
INPUT PANEL (FIG.1)
CONNECTIONS (FIG.2)
SW115P CONFIGURATION (FIG.3)
SPEAKER POWER OUTPUTS Neutrik NL4 Speakon Cable Connector
2-
1+
2+
1-
20mm
0.8"
8mm
0.3"
RED
BLACK
n.c.
1+
positive / red
1-
negative / black
n.c.
LEFT
SW115P
(8 ohm)
LEFT
LT12P (8 ohm sat)+
SW115P (8 ohm sub)
RIGHT
LT12P (8 ohm sat)+
SW115P (8 ohm sub)
RIGHT
SW115P
(8 ohm)
SUB system
2x SW115P
SUB+SAT system
2x SW115P
+
2x LT12P
R
L
R
L
SUB+SAT system
SW118P CONFIGURATION (FIG.3)
SW118P (8 ohm)
SW118P (8 ohm)
sub ARRAY
1
2
full range speaker
to other 2x SW118P
LEFT
RIGHT
full range speak
er
HIGH
L
R
LEFT
SW118P subwoofer speaker
PROTECT
PROTECT
BRIDGE
LIMIT
LIMIT
ON
SIGNAL
SIGNAL
SW118P subwoofer speaker
RIGHT
LOW
L
R
7
8
SAFETY AND PRECAUTIONS
CAUTION: before using this product read carefully the following safety instrucons. Take a look of this manual enrely and preserve it for future reference.
When using any electric product, basic precauons should always be taken, including the following: – To reduce the risk, close supervision is necessary when the product is used near children. – Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places. – This product should be site away from heat sources such as radiators, lamps and any other device that generate heat. – This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon. – Care should be taken so that objects and liquids do not go inside the product. – The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the product. Connect the apparatus to a power supply using only power cord included making always sure it is in good condions. – WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. – Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon. – Make sure that power supply mains line has a proper earth connecon. – Power supply cord should be unplugged from the outlet during strong thunderstorm or when le unused for a long period of me. – Do not place objects on the product’s power cord or place it in a posion where anyone could trip over, walk on or roll anything over it. Do not allow the product to rest on or to be installed over power cords of any type. Improper installaons of this type create the possibility of re hazard and/or personal injury. – This product may be capable of producing sound levels that could cause permanent hearing loss. Exposure to extremely high noise levels may cause permanent hearing loss. Individuals vary considerably in suscepbility to noise­induced hearing loss, but nearly everyone will lose some hearing if exposed to sufficiently intense noise for a period of time. The U.S. Government’s Occupational Safety and Health Administration (OSHA) has specified the permissible noise level exposures shown in the following chart. According to OSHA, any exposure in excess of these permissible limits could result in some hearing loss. To ensure against potenally dangerous exposure to high sound pressure levels, it is recommended that all persons exposed to equipment capable of producing high sound pressure levels use hearing protectors while the equipment is in operaon. Ear plugs or protectors in the ear canals or over the ears must be worn when operang the equipment in order to prevent permanent hearing loss if exposure is in excess of the limits set forth here. Keep your's aenon that children and pets are more suscepble to excessive noise levels.
IN CASE OF FAULT
• In case of fault or maintenance this product should be inspected only by qualied service personnel when: – There is a aw either in the connecons or in the supplied connecng cables. – Liquids have spilled inside the product. – The product has fallen and been damaged. – The product does not appear to operate normally or exhibits a marked change in performance. – The product has been lost liquids or gases or the enclosure is damaged.
• Do not operate on the product, it has no user-serviceable parts inside, refer servicing to an authorized maintenance centre.
TROUBLESHOOTING
No Power • The loudspeaker's "POWER" switch is o.
• Make sure the mains AC outlet is live (check with a tester or a lamp).
• Make sure the mains plug is securely plugged into mains AC outlet.
No Sound • Is the input LEVEL control for the channel turned up?
• Is the SIGNAL LED illuminated? If not check if your signal level is too low or check the signal cable, mixer and other equipment seng and cabling.
• Are you sure your signal cables works properly? check it using a cable tester or replacing with a new one.
• Is the SPEAKON cable connector correctly inserted? turn it clockwise unl it clicks.
• Are you sure your power cable works properly? check it using a cable tester or replacing with a new one.
Distorted Sound • Input signal level is too high. Turn down your level controls.
NOTE: The loudspeakers should never be operated at a level which causes the amplier Clip LEDs to illuminate constantly.
Di erent channel level
• Check if are using a balanced cable for one channel and an unbalanced one for the other, as this would cause a considerable dierence in channel levels.
• Be sure that your loudspeaker system is fully connected and both loudspeakers have the same impedance.
Noise / Hum • Enable GND LIFT buon on rear panel, if the problem persist press all GND LIFT buons for all system's ampliers.
• Whenever possible, preferably use only balanced cables. Unbalanced lines may also be used but may result in noise over long cable runs.
• Somemes it helps to plug all audio equipment into the same AC circuit so they share a common ground.
Duraon Per Day In Hours
Sound Level dBA Slow Response
Typical Example
8 90 Duo in smal l club
6 92
4 95 Subway Train
3 97
2 100 Very loud class ical music
1.5 102
1 105 Trac noise
0.5 110
0.25 or les s 115 Loudest part s at a rock concert
9
CE CONFORMITY
CELECTRON products comply with directive EMC 2014/30/CE, as stated in EN 55103-1 and EN 55103-2 standards and with directive LVD 2014/35/CE, as stated in EN 60065 standard.
• Under the EM disturbance, the ratio of signal-noise will be changed above 10dB.
PACKAGING, SHIPPING AND COMPLAINT
• This unit package has been submitted to ISTA 1A integrity tests. We suggest you control the unit conditions immediately after unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspection.
CELECTRON is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately notified to forwarder. Each complaint for package tampered with should be done within eight days from product receipt.
WARRANTY AND PRODUCTS RETURN
CELECTRON products have operating warranty and comply their specifications, as stated by manufacturer.
CELECTRON warrants all materials, workmanship and proper operation of this product for a period of two years from the original date of purchase. If any defects are found in the materials or workmanship or if the product fails to function properly during the applicable warranty period, the owner should inform about
these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed description. This warranty does not extend to damage resulting from improper installation, misuse, neglect or abuse. CELECTRON Electronic will verify damage on returned units, and when the unit has been properly used and warranty is still valid, then the unit will be replaced or repaired. CELECTRON Electronic is not responsible for any "direct damage" or "indirect damage" caused by product defectiveness.
INSTALLATION AND DISCLAIMER
CELECTRON products have been expressly designed for audio application, with signals in audio range (20Hz to 20kHz). CELECTRON has no liability for damages caused in case of lack of maintenance, modifications, improper use or improper installation non-applying safety instructions.
• The installation of these speakers is provided for indoors, in case of use outdoors be sure that the speakers are installed correctly in a safe location protected from wind, rain and humidity. To avoid performance deterioration of mechanical, acoustics and electrical parts is not advisable to leave these speakers exposed outdoors for a long period of time, so we suggest a temporary installation for the limited sound events.
• The installation of these speakers is provided for floor or by means of specific stands able to support their weight. Therefore avoid installation on unstable elements such as: furniture, chairs and vibrant surfaces as stages or other speakers without appropriate fix point specifically designed to avoid speaker movement. Then avoid the use of inadequate supports, we suggest to use CELECTRON stands and accessories only.
• In case of the speakers are provided of rigging points: DO NOT SUSPEND THE SPEAKERS FROM THE HANDLES, use exclusively these rigging points. Consult professional rigger or structural engineers prior to suspending loudspeakers from a structure not intended for that use. Always know the working load limit of the structure supporting the loudspeakers. Always make sure that the rigging hardware minimum rating is at least five times the actual load, speakers and rigging hardware.
• In case of suspended installations of active loudspeakers where is not possible to turn on and off the speakers from their appropriate switches, we recommend to install switches on the mains lines, for this purpose consult an expert electrician for the exact dimension of wiring.
• Locate the speakers as far away as possible from radio or television receivers or other sensitive equipment. These speakers have a strong magnetic field which can induce hum and noise into unshielded devices that are located nearby with consequent deterioration of reception of image and sound.
CELECTRON Electronic reserves the right to change these specifications at any time without notice.
CELECTRON Electronic declines any liability for damages to objects or persons caused by lacks of maintenance, improper use, installation not performed with safety precautions and at the state of the art.
POWER SUPPLY AND MAINTENANCE
• Clean only with dry cloth.
• Check periodically that the slots for its proper ventilation and heating dissipation are not obstructed by dust, remove the dust using a dry brush or a compressed air gun.
• The amplified loudspeakers of CELECTRON have been designed with CLASS I construction and must be connected always to a mains socket outlet with a protective earth connection (the third grounding prong).
• Before connecting the product to the mains outlet make certain that the mains line voltage matches that shown on the rear of the product, a tolerance of up to ±10% is acceptable.
• Inside the amplified
loudspeakers are present special safety devices such as:
ü Transformer and amplifier over-heating protection. ü Protection against excessive power applied at each speaker.
THE REPLACEMENT OF FUSES INSIDE THE APPARATUS MUST BE MADE ONLY BY QUALIFIED PERSONNEL.
CHECK THE CONDITION OF THE PROTECTION FUSE, ACCESSIBLE OUTWARD, ONLY WITH THE APPARATUS SWITCHED OFF AND
DISCONNECTED FROM THE MAINS LINE OUTLET.
REPLACE THE PROTECTION FUSE ONLY WITH SAME TYPE AS SHOWN ON THE PRODUCT.
IF AFTER THE SUBSTITUTION, THE FUSE INTERRUPTS AGAIN THE APPARATUS WORKING, DO NOT TRY AGAIN THEN CONTACT THE
CELECTRON SERVICE CENTRE.
10
GENERAL INFORMATION
Thank you for having chosen a CELECTRON product. The SW Series is a range of sub-woofers designed to complement CELECTRON full-range passive or acve speakers. The variety of size, power and SPL oered by the ve SW models provides the perfect low extension soluon for any speaker model available in the CELECTRON range. All the SW models feature large VC woofers and band-pass or vented design, which provide very ‘punchy’, dynamic lows together with an extended low frequency response. The CLASS D ampli er modules can generate a massive amount of con nuous power in a compact and reliable package. All the modules include a STEREO pre-amp sec on, 24dB/oct. crossover lters with selectable frequency and PHASE reverse switch. The cabinets are built with 15/18mm plywood and feature 2 or 3 metal handles and sturdy 75mm wheels for an easy transport.
INSTRUCTIONS
1. INPUT (SPEAKON)
External amplifi er power input: this is the connector where you plug in the power cable coming from your power amplifi er or powered mixer. The powered signal is fi ltered by an internal passive crossover with a low-pass fi lter for the internal subwoofer speaker, and with a high-pass fi lter for an external satellite speaker. The frequency transi on is about at 160 Hz connec ng an 8 ohm satellite speaker. The INPUT speakon has this pin connec on:
PIN1+: posi ve power signal (usually red wire) PIN1-: nega ve power signal (usually black wire)
2. HI-PASS OUTPUT (SPEAKON)
Output of the power signal to be sent to a satellite loudspeaker. This output is ltered by a so -slope high-pass,
to
obtain an op mal coupling with any kind of satellite. The connector has the same pin out as above.
3. LINK (SPEAKON)
Output of the power signal to be sent to another loudspeaker. The connector has the same pin out as specified above.
CHOOSE THE AMPLIFIER POWER
We give you two power-handling numbers: AES or CONTINUOUS, and PEAK. These data suggest you can use any ampli er with a power capability equal or less the power-handling, but this rule is valid only if the ampli er never clips. Preven ng loudspeaker damage caused by clipping, that is likely the number one cause of damage, and assuming you want to use the full capability of the loudspeaker, we recommend the use of an ampli er with a built-in limiter to prevent clipping: in this case the rated power capability must be the same as the con nuous power ra ng of the loudspeaker into the same speci ed impedance ( pically 4 or 8 ohms):
IMPORTANT: Clipping occurs when the signal at the output of any device in the system (not just the amplif er) reaches its maximum level. Proper opera. on of a sound system includes being aware of the types of audio signals being reproduced, controlling the output levels accordingly, and opera ng all the devices in the system so that no clipping occurs within the signal chain.
Celectron Electronic Group
BBFY Industrial USA Inc
City of Industry - California
www.celectronaudio.com
