CEL NX8564LE, NX8565LE, NX8566LE User Manual
NEC's EA MODULATOR
California Eastern Laboratories
INTEGRATED InGaAsP MQW DFB
LASER DIODE MODULE
FOR 2.5 Gb/s ULTRALONG-REACH
360, 600, 240 km DWDM APPLICATIONS
FEATURES
• INTEGRATED ELECTROABSORPTION MODULATOR
• VERY LOW DISPERSION PENALTY:
Over 360 km (6480 ps/nm), NX8564LE-BC/CC
Over 600 km (10800 ps/nm), NX8565LE-BC/CC
Over 240 km (4320 ps/nm), NX8566LE-BC/CC
• LOW MODULATION VOLTAGE
• AVAILABLE FOR DWDM WAVELENGTH
BASED ON ITU-T RECOMMENDATION
100 GHz grid, refer to ORDERING INFORMATION
NX8564LE
NX8565LE
NX8566LE
SERIES
DESCRIPTION
NEC's NX8564/8565/8566LE Series is an Electro-Absorption
(EA) modulator integrated, 1550 nm Multiple Quantum Well
(MQW) structured Distributed Feed-Back (DFB) laser diode.
The module is capable of 2.5 Gb/s applications of over 360
km, 600 km, 240 km ultralong-reach and available for Dense
Wavelength Division Multiplexing (DWDM) wavelengths
based on ITU-T recommendations, enabling a wide range of
applications.
NX8564/8565/8566LE SERIES
Pin
No.
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Function
Function
PIN CONNECTIONS
GND
GND
NC
GND
Signal Input (MOD),
50 Ω RF Input
GND
GND
Thermistor
Thermistor
LD DC Bias
PD Anode
PD Cathode
Cooler Anode
Cooler Cathode
TOP VIEW
#8 #14
#7 #1
+-
PD
LD
MOD
Cooler
Thermistor
Optical Fiber (SMF)
Length : 900 MIN.
29.97±0.25
8.0
0.75
5.4
8.0
Nose
Fiber
20.83±0.13
26.04±0.13
7
8
1
14
1.25
15.24
2.54
4 – 2.67
φ
22.0 MAX.
12.7±0.15
10 MIN.
8.89±0.13
0.9
6.0 MAX.
PACKAGE DIMENSIONS (Units in mm, unless otherwise specified ±0.2mm)
OPTICAL FIBER CHARACTERISTICS
-CC : SC-UPC connector
-BC : FC-UPC connector
Fiber Length : 900 mm MIN.
35±2 mm
8.99±0.5 mm
PARAMETER SPECIFICATION UNIT
Mode Field Diameter 9.3±0.5 μm
Cladding Diameter 125±1 μm
Tight Buffer Diameter 900±100 μm
Cut-off Wavelength < 1270 nm
Attenuation 1525 to 1575 nm < 0.3 dB/km
Minimum Fiber Bending Radius 30 mm
Fiber Length 900 MIN. mm
Flammability UL1581 VW-1
NX8564/8565/8566LE SERIES
NX8564/8565/8566LE SERIES
NX856 LE -
CC : SC-UPC connector
BC : FC-UPC connector (option)
Without wavelength code : Wavelength is a certain point between
1528 to 1565 nm, 1579 to 1609 nm
With wavelength code : Refer to Table A
4 : 360 km (6480 ps/nm)
5 : 600 km (10800 ps/nm)
6 : 240 km (4320 ps/nm)
*NOTE:
Please refer to the last page of this data sheet, “Compliance with EU Directives” for Pb-Free RoHS Compliance Infomation.
ORDERING INFORMATION
PART NUMBER PACKAGING
NX8564-AZ* Butterfly Package
NX8565-AZ*
NX8566-AZ*
Table A: DWDM wavelength base on ITU-T recommendations (@ TLD = Tset) (1/2)
Wavelength
Code
287 1528.77 196.10 485 1548.51 193.60
295 1529.55 196.00 493 1549.31 193.50
303 1530.33 195.90 501 1550.11 193.40
311 1531.11 195.80 509 1550.91 193.30
318 1531.89 195.70 517 1551.72 193.20
326 1532.68 195.60 525 1552.52 193.10
334 1533.46 195.50 533 1553.32 193.00
342 1534.25 195.40 541 1554.13 192.90
350 1535.03 195.30 549 1554.94 192.80
358 1535.82 195.20 557 1555.74 192.70
366 1536.60 195.10 565 1556.55 192.60
373 1537.39 195.00 573 1557.36 192.50
381 1538.18 194.90 581 1558.17 192.40
389 1538.97 194.80 589 1558.98 192.30
397 1539.76 194.70 597 1559.79 192.20
405 1540.55 194.60 606 1560.60 192.10
413 1541.34 194.50 614 1561.41 192.00
421 1542.14 194.40 622 1562.23 191.90
429 1542.93 194.30 630 1563.04 191.80
437 1543.73 194.20 745 1574.54 190.40
445 1544.52 194.10 753 1575.36 190.30
453 1545.32 194.00 761 1576.19 190.20
461 1546.11 193.90 770 1577.02 190.10
469 1546.91 193.80 778 1577.85 190.00
477 1547.71 193.70 786 1578.68 189.90
*1 The value which omitted and computed the 3rd place below the decimal point
ITU-T Wavelength *1
(nm)
Frequency
(THz)
Wavelength Code ITU-T Wavelength *1
(nm)
Frequency
(THz)
