User Manual
MT3
MultiPRO
AC Multi-tool
THANK YOU
Thank you for investing in a CEL product. The MultiPRO has been engineered and made to
demanding high quality standards; ease of operation and safety have taken a major role in
development. Proper care of your product will give you years of trouble-free use.
Normal wear and tear, including accessory wear, is not covered under guarantee.
The product is guaranteed for domestic use against manufacturing faults for a period of 24
months (for additional guarantee period (if any) please refer to the store or agent from which
you purchased the product or contact the nearest authorized dealer).
This product is not guaranteed for HIRE purposes.
If you have any questions, please contact us at:
service@cel-global.com
It is possible to download updated user manuals, view demonstration videos and find
information about new products at: www.cel-global.com
Warning: User must read and understand the user manual before using the product to
reduce the risk of injury. Failure to follow all instructions may result in electric shock, fire
and/or serious personal injury. The product must be used only for its prescribed purpose. Any
use other than those mentioned in this manual will be considered a case of misuse. The
manufacturer shall NOT be liable for any damage or injury resulting from such cases of
misuse, use of force, partially or completely dismantled appliances.
Declaration of Conformity
We declare under our sole responsibility that the product described in “Technical
Specifications” is in conformity with the following standards or standardisation documents:
EN 55014-1: 2006, EN 55014-2: 1997/+A1:2001/+A2:2008, EN 61000-3-2: 2006,
EN 61000-3-3: 2008 according to the provisions of the directive 2004/108/EC.
Technical file can be provided by:
CEL-HK 912 Nan Fung Commercial Centre, 19 Lam Lok Street, Kowloon Bay, Hong Kong
C Enterprise (UK) LTD
Unit 4 Harbour Road Trading Estate
Portishead, BS20 7BL, UK
Chris Elsworthy
Managing Director
08 November, 2011
GETTING
STARTED
1.0 Important Safety Notes
2.0 Unpacking
3.0 Description of Parts
OPERATION
CARE
8.0 Maintenance, Storage and Environment
9.0 Additional Tools
10.0 FAQ
11.0 Technical Specifications
4.0 Safety Notes Before Starting
5.0 Fitting Tools
6.0 Operating
7.0 Tips
Contents
The crossed out bin symbol indicates that this product
cannot be disposed of with regular waste. Please dispose
of at a council approved site or contact your reseller.
Important Notes 1.0
Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is grounded.
c) Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. Keep cord away from heat, oil, sharp edges or
moving parts. Replace damaged cords immediately. Damaged cords increase the risk of electric shock.
e) Extension cords must be rated for intended use. Always fully unwind all cables before operating any equipment. Wound cables can build
heat and be very dangerous. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of cord suitable for
outdoor use reduces the risk of electric shock.
Personal safety
a) Stay alert, watch what you are doing, and use common sense when operating a power tool. Do not use tool while tired or under the
influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as dust mask, non-skid safety shoes, hard hat, and hearing
protection must be used for appropriate conditions and will reduce personal injures.
c) Avoid accidental starting. Ensure the switch is in the off-position before plugging in. Carrying tools with your finger on the switch or plugging
in power tools that have the switch on invites accidents.
d) Remove adjusting key or wrench before turning the tool on. A wrench or a key left attached to a moving part of the tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress appropriately. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of
these devices can reduce dust-related hazards.
Description of symbols
The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use.
General
Hazard
Keep Dry Keep
Bystanders
Away
Flying
Debris
Sharp
Blades
Protect
Eyes, Ears,
Lungs
Read
Instructions
WARNING Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The terms “tool”, “machine” or "power tool" in the warnings refers to mains-operated (corded) power tools and their
accessories.
Wear
Appropriate
Clothing
Important Notes 1.0
Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the
power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
Service
Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power
tool is maintained.
NOTE
~ Always check the tool and all cables and connections are undamaged, clean and dry before plugging in.
~ Always use an RCD or suitable circuit breaker when using power tools.
~ Use the machine only for dry sanding. Penetration of water into the machine increases the risk of an electric shock.
~ Keep hands away from the cutting range. Do not reach under the workpiece. Contact with the accessories can lead to injuries.
~ Use suitable detectors to determine if utility lines are hidden in the work area or call the local utility company for assistance. Contact with
electric lines can lead to fire and electric shock. Damaging a gas line can lead to explosion. Penetrating a water line causes property damage
or may cause an electric shock.
~ When working with the machine, always hold it firmly with both hands and provide for a secure stance. The power tool is guided more
securely with both hands.
~ Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held more securely than by hand.
~ Keep your workplace clean. Blends of materials are particularly dangerous. Dust from light alloys can burn or explode.
~ Wear protective gloves when changing application tools/accessories. Application tools/accessories become hot after prolonged usage.
~ Do not scrape wetted materials (e. g. wall-paper) or on moist surfaces. Penetration of water into the machine increases the risk of an electric
shock.
~ Do not treat the surface to be worked with solvent-containing fluids. Materials being warmed up by the friction can cause toxic vapours to
develop.
~ Exercise extreme caution when handling the scraper. The accessory is very sharp; danger of injury.
~ Never cut in an area you cannot clearly see. Hidden objects can cause harm or be damaged.
Key risks with oscillating tools:
~ Vibration over long periods can lead to RSI (Repetitive Strain Injury) and a condition known as HAVS (Hand-Arm Vibration Syndrome) or
White Finger. To avoid injury take regular breaks and never operate the tool continuously for more than 20 minutes. Do not use this tool if you
have a history of medical problems that relate to this type of injury or if you are unwell or have any discomfort.
~ Heat buildup on accessories. A rotating blade will clear swarf and saw dust from the cut, the oscillating action of this tool DOES
NOT clear the debris. Constant friction on one spot can cause extreme heat and even fire. Do not touch a blade until it has cooled,
reduce heat from friction and build up of debris by moving the accessory constantly to clear debris and dissipate heat.
~ Don’t use excessive pressure, cutting blades work better at their own pace, sawing, sanding and grinding tools will clog if pressed too hard.
The risk of slipping and causing harm is reduced when using a controlled, even pressure. Keep grinding and sanding pads clear of debris
buildup with a wire brush.
Always wear equipment to protect vision, hearing and respiratory system.
Wear suitable clothing and footwear. Long periods of use can be harmful, take regular breaks.
Unpacking
2.0
NOTE
Due to modern mass production techniques, it is unlikely that your power tool is faulty or that a part is
missing. If you find anything wrong, do not operate the tool until the parts have been replaced or the fault
has been rectified. Failure to do so could result in serious personal Injury.
Please note that this product is
sold in several configurations.
The content of your package
may vary from this description
and images within this manual.
A
Optional
Description of Parts 3.0
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
MultiPRO
Locking Washer
Blade Adaptor Washer
Locking Bolt
Hex Key
Universal Saw
Scraper
Sanding Pad
4x Sanding Sheets
Wood blade D-shape
MT3 - Or for a cordless alternative see the +Ion Multi2PRO (MT1)
AC17
5mm Hex
AC11
AC14
AC09
AC10
AC13
Replacement code:
A
Note. The plug should match your local supply.
If not, return to your supplier immediately.
Intended Use.
The machine is intended for sawing and cutting using the specified accessories- wooden materials,
plastic, gypsum, non-ferrous metals and fastening
elements (e.g. nails, staples). It is also suitable for
working soft wall tiles as well as for dry sanding and
scraping of small surfaces.
Optional
Before Starting Work 4.0
Fitting Tools
5.0
If required, remove an already
mounted tool/accessory.
Loosen the screw with the hex key
and remove the tool/accessory. Be
sure to clear any debris.
Mount a suitable tool/accessory in
such a manner on the tool holder that
the offset faces downward.
Turn the tool/accessory to a position
favourable for the respective job, and
allow it to engage into the cams of the
tool holder. 12 different positions are
possible, each offset by 30°. Fasten
the tool/accessory with Locking Bolt
and Washer. Tighten the bolt with Hex
key until the washer and bolt are flush
with the tool/accessory and firmly
fixed.
The sanding plates are fitted
with Velcro backing for quick
and easy fastening of sanding
sheets with Velcro adhesion.
Before attaching the sanding
sheet , free the Velcro backing
of the sanding plate from any
debris by tapping to enable
optimum adhesion.
Position the sanding sheet flush
alongside one edge of the
sanding plate, then lay the
sanding sheet onto the sanding
plate and press firmly.
To remove the sanding sheet,
grasp it at one of the tips and
pull it off from the sanding plate.
Sharp blades, heat buildup and flying debris are a
danger to user and bystanders. Use of suitable
protective clothing, gloves, footwear, eye and ear
protection as well as safe working practices can reduce
these risks.
Dusts from materials such as leadcontaining coatings, some wood types,
minerals and metal can be harmful to
one's health. Touching or breathing-in the
dusts can cause allergic reactions and/or
lead to respiratory infections of the user
or bystanders.
Certain dusts, such as oak or beech dust, are
considered as carcinogenic, especially in connection
with wood-treatment additives (chromate, wood
preservative). Materials containing asbestos may only
be worked by specialists.
- Use dust extraction whenever possible.
- Provide for good ventilation of the working place.
- It is recommended to wear a P2 filter class respirator.
Observe the relevant regulations in your country for the
materials to be worked
Do not cover the venting slots of the machine while
working, as this reduces the working life of the
machine.
This tool vibrates at very high frequency. Regular
breaks must be taken to reduce the chance of injury. At
the first sign of discomfort work should immediately
cease.
NOTE:
The AC17 adaptor washer is not required to fit CEL blades on CEL tools.
Check the tight seating of the
tool/accessory while fitting and
regularly while working there is
a risk they can come loose
during operation and be
damaged or hazardous .
Switching On and Off
To start the machine, push the
On/Off switch forward so that "ON" is
indicated on the switch.
To switch off the machine, push the
On/Off switch toward the rear so that the
"OFF" is indicated on the switch.
Selecting the rate of oscillation
Use the thumbwheel to select the rate of
oscillation.
The required rate of oscillation depends
on the material and the working
conditions and can be determined
through practical testing.
Sawing
~ Use undamaged faultless saw blades
only.
Deformed, blunt saw blades or saw
blades that are otherwise damaged can
break or shatter.
~ Continuously move the blade to clear
debris and dissipate heat. Beware of
hot blades.
~ Plunge cuts may only be applied to
soft materials, such as wood, gypsum
plaster boards, etc.
~ Before sawing with AC12 saw blades
in wood, particle board, building
materials, etc., check these for foreign
objects such as nails, screws, or similar.
If required, remove foreign objects or
use AC11 saw blades.
Separating
Note: When separating wall tiles take into
consideration that the application tools/accessories
wear heavily when used for longer periods of time.
Sanding
The removal rate and the sanding pattern are
primarily determined by the choice of sanding
sheet, the preset oscillation rate and the applied
pressure, the corners of the sheet have the
longest oscillating travel and so will perform the
most vigorously.
Flawless sanding sheets achieve the
best sanding capacity and extend
the service life of the machine.
Try to apply uniform sanding pressure;
this increases the working life of the sanding
sheets. Low/medium speed is recommended.
Additional pressure does not lead to an
increased sanding capacity, only increased
wear of the machine and the sanding sheet.
For precise on-the-spot sanding of edges,
corners and hard to reach areas, it is also
possible to work only with the tip or an edge of
the sanding plate.
When selectively sanding on the spot, the
sanding sheet can heat up considerably. Reduce
the oscillation rate and allow the sanding sheet to
cool down regularly.
A sanding sheet that has been used for metal
should not be used for other materials.
Use only original CEL sanding accessories.
Scraping
For scraping, select a high oscillation rate. Work
on a soft surface (e.g. wood) at a flat angle, and
apply only light pressure. Otherwise the scraper
can cut into the surface. Do not press to hard,
allow the tool to work and reduce the risk of a slip.
Operating 6.0
Sharp blades, heat
buildup and flying
debris are a danger
to user and
bystanders. Use of
suitable protective
clothing, gloves,
footwear, eye and
ear protection as
well as safe
working practices
can reduce these
risks.
Variable
Speed
ON
OFF
Tips 7.0
Constant friction on one spot
can cause extreme heat and
even fire.
Reduce heat from friction and
build up of debris by moving the
accessory constantly to clear
debris and dissipate heat.
Don’t use excessive pressure,
cutting blades will work better at
their own pace. Sawing, sanding
and grinding tools will clog if
pressed too hard.
A rotating blade will clear swarf and saw dust from the cut, the oscillating action of this tool
does not clear the debris. When performing a plunge cut where debris cannot escape, eg a
deep cut to fit a lock. Stop cutting regularly and use a brush or vacuum to clear the debris
from the cut. Allowing debris to build up will hinder the cutting action.
Grip the tool firmly, the oscillations can be absorbed by your arm and wrist reducing
the effective cut. Ensure the workpiece is also securely gripped.
Use the Triangular Carbide Rasp (AC04) to smooth out messy concrete in corners when
fitting stud work.
Try the Carbide Grit Semicircle Saw (AC01) to grind away grout between tiles, you wont find
a faster method. By skewing the blade in the gap between the tiles slightly you can make a
wider groove, so you can clear the gap in one pass. Remember to take a wire brush to
regularly clear the build up of debris from the grit.
Moving the tool as shown in this image will, combined with a light pressure, will give a
cleaner, more controllable cut in less time.
Maintenance, Storage and Environment
WARNING, Switch off and unplug the power supply before carrying out any
maintenance on the tool.
General inspection
Regularly check that all the fixing screws are present and tight. They may vibrate loose
over time.
Dust
Keep the tool's air vents unclogged and clean at all times.
Remove dust and dirt regularly.
Cleaning is best done with compressed air or a rag.
Never use caustic agents to clean plastic parts.
Replacing the fuse
Country specific models may use a fuse suitable for the specific requirements of that region.
The plug shows the type of fuse required, open and replace only after removing from any live
electrical outlet. Replace with the same fuse as fitted or with a lower Amp (A) rating.
CAUTION, Do not use cleaning agents to clean the plastic parts of the tool. A mild
detergent on a damp cloth is recommended. Water must never come into contact with
the tool.
Storage
Store the tool, instruction manual and accessories in a secure, dry place. In this way
you will always have all the information and parts ready to hand.
Environment
When the time comes to dispose of this product please consider the environment and take it
to a recognised recycling facility instead of disposing with general household waste.
Call your local council, civic amenity site, or recycling centre for information on the recycling
and disposal of electrical products.
8.0
Additional Tools (sold separately) 9.0
Sand & Polish
AC03
AC04
AC18
Sanding Pad
Sanding Pack
Sanding Finger
Pad
Sanding Finger
Sheet
Polishing Pad
Holds sanding sheet for detailed sanding in
small areas and corners.
Universal sanding applications. Fits AC10 40,
80, 120, 180G
Holds sanding sheets for detailed sanding in
very small areas and corners. Thinner so it
reaches into small openings.
Universal sanding applications. Fits AC07
40, 80, 120, 180, 220G
Soft felt buffing and polishing pad
Rasp
Carbide Rasp
Finger
Triangular Carbide
Rasp
Abrasive Brick and
Masonry Cutting
Coarse grinding or rasping, aggressive material
removal in small, tight areas.
Coarse grinding or rasping, aggressive material
removal over larger areas.
Cut into bricks and masonry, remove mortar
around a brick or cut under a tile.
Stainless Steel
Scraper
Removing old vinyl, wood or other floor
coverings, paint and coatings, residues and
separating laminated layers, cuts carpet.
Scrape
AC09
AC10
AC06
AC07
AC16
AC14
Additional Tools (sold separately) 9.0
Carbide Grit
Semicircle Saw
Blade 2 1/2"
Diamond-Coated
Semicircle Saw
Blade 2 1/2"
35mm (1 3/8")
End Cut
35mm (1 3/8")
Universal End Cut
10mm End Cut
3 1/8" Segment
Saw Blade
Removing grout, cutting and shaping plaster,
porous concrete and masonry. Flat on one
side so you can cut into corners and flush
against adjoining surfaces.
Removing grout, cutting and shaping plaster,
porous concrete and masonry. Scoring and
cutting for a precise fit. Flat on one side so
you can cut into corners and flush against
adjoining surfaces.
Fast Cut Wood- Plunge cutting up to 1-5/8"
40mm depth. Hardened teeth will also cut
non-ferrous metals such as copper pipes or
aluminium.
Cut Metal and Wood- Plunge cutting up to
1-5/8" 40mm depth. Hardened teeth will cut
ferrous metals such as nails and pipes.
Plunge cutting up to 30mm depth. Hardened
teeth will cut non-ferrous metals.
Linear and Plunge cutting. D-shaped so you
can cut into corners and flush against
adjoining surfaces.
Saw
AC01
AC02
AC12
AC11
AC15
AC13
More tools and uses are available at www.cel-global.com
Please let us know if you have any ideas or new uses for the MultiPRO
FAQ 10.0
Why does my MultiPRO stop sometimes?
Excessive heat or a jammed accessory will
cause the tool to shut down. Wait for it to
cool down before re-starting.
Why cant I cut/sand as well as
demonstrated?
Grip the tool firmly, the oscillations can be
absorbed by your arm and wrist reducing the
effective cut. Ensure the workpiece is also
securely gripped.
Make sure the cutting tool is in good
condition and the variable speed is at a
suitable level.
The MultiPRO wont start, what’s wrong?
a)Clean as described in the maintenance
section. b)Check the power is live and
correctly connected, check the fuse is valid,
also make sure the switch and speed control
are working and being operated correctly.
What kind of fuse does the plug use?
See the maintenance section of this manual.
Where should I keep my MultiPRO?
In a dry place at a stable temperature
between 10ºC and 24ºC (50ºF and 75ºF).
What should I do if my MultiPRO gets
wet?
Safely remove from any electrical source.
Dry fully for at least 14 days in a warm but
not hot place and ensure there is no residual
moisture before trying to use.
How can I get my MultiPRO repaired if it
is damaged?
Contact your retailer.
Where do I find my serial number?
On the left hand side of the body.
Where can I get replacement parts,
advice or help?
Ask at your retailer or visit www.celglobal.com
How long is the warranty and what is
covered?
Please see inside cover
Technical Specifications 11.0
If you experience any problems with the product please contact
email: service@cel-global.com
CEL UK: 08453 88 97 69
www.cel-global.com
© Copyright C Enterprise Limited 2011
3188076
C Enterprise Limited
READ INSTRUCTION MANUAL
BEWARE OF FLYING
OBJECTS AND DEBRIS
GENERAL HAZARD
SAFETY ALERT
KEEP BYSTANDERS AWAY
Oscillating speed
Oscillation angle
Sound Pressure Level (dB(A))
Operating wattage
Operating voltage
Dimensions
Boxed weight
Product Code
- 11000 - 19000rpm
- 3.2°
- 86dB
- 220W
- 240vAC 50Hz
- 353x266x95mm
- approx (14x10x4")
- 1.26Kg (2.8lbs)
- MT3
C Enterprise Limited www.cel-global.com info@cel-global.com
UK • HK • USA • China • Europe • Australia • Japan
Designed and edited in the UK :: Printed in China :: Manual Version: 111108
Designed in UK Made in China
Loading...
