THE ELECTRIC VEHICLE MARKET
IN THE UK IS GROWING

, AND IT'S

GROWING FAST!

Improved battery life and more exible hybrid options are making electric vehicles [EV] more
accessible to drivers, while the launch of electric vehicles from the likes of Audi, Jaguar
Land Rover, Mercedes-Benz and Tesla are making them desirable, not just an ethical choice.

At the end of October 2020, the total number of
zero-emission electric vehicles on UK roads was
173,5001, an increase of more than 73% since
January 2020.

Add to the mix, new registrations for plug-in
hybrid vehicles, and the total number of electric
vehicles on UK roads is more than 390,0001.

Last year saw the biggest annual increase in
number of registrations, with more than 72,0001

electric vehicles registered showing a growth of
22%1 on 2018. This year, despite the coronavirus
impact, the gures show that 2020 will see an
even greater growth rate.

Yet for EV adoption to really take off, there
must be an infrastructure in the UK to support
it. EV charging stations have to be widely
available in order for EV ownership to be a
convenient, as well as an economically viable
and environmentally friendly choice.

ELECTRIC VEHICLES NEED TO KNOW

EV sales set to

grow massively

by 2030

2

Lower

carbon emissions

Cheaper

to run

Reduced or no Vehicle Excise

Duty on low-emission vehicles

Grants available to

purchase electric vehicles

Grants available

to install EV

charging stations

1

Source: zap-mapcom/statistics/

CONTENTS

INTRODUCTION

The EV Opportunity

04

The three different types

06

of EV charging

What CEF offer

07

OLEV, REGS & TRAINING

OLEV Grants

08

IET Code of Practice

10

18th Edition Amendment

11

Training

12

PRODUCTS

ICS

16

ABB

20

Rolec

24

Schneider Electric

28

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

EVBox

30

Matt:e

34

Proteus EV

38

MCG - EV

42

Cable

48

Test Equipment

50

For more information visit
cef.co.uk/plugintoev

LOCALLY

3

THE EV

OPPORTUNITY

Currently, the UK is one of Europe’s largest
markets for ultra-low emission vehicles
and while the number of electric vehicles
on the road is growing at a remarkable
rate, so is the demand for a reliable
charging network up and down the country.

Following the announcement in November 2020
of the UK government’s plan to ban the sale of
new petrol and diesel cars by the year 2030, the
number of EVs is expected to
increase substantially.

But motoring experts1 have warned the electric
car charging network is still some way off being
able to support a full transition away from petrol
and diesel vehicles, and will have to expand by
up to 20 times to cope with the
upcoming demand.

4

While the government has pledged to invest £1.3
billion2 to accelerate the rollout of EV charge
points in homes, streets and on motorways across
England, the success of the transition would
depend on EV drivers being able to recharge as
easily as they refuel.

Why should you upskill?

EV charging point installation presents a huge
new business opportunity for electricians and
the increased demand means the opportunity for
electricians within the EV market is one of the most
lucrative in the electrical industry. With every new
EV registration, the demand for charging stations
increases – each new EV purchased requires easy
access to a charging station, not just at home or at
work but in public spaces – and installation must
always be carried out by a qualied electrician.

What does the future hold?

The UK electric car charging point network will
need a huge expansion ahead of the upcoming
ban. Attention needs to be given to installing
more rapid chargers on road networks, as
well as adding charging capability to car parks
where people stay for longer durations, such
as shopping and leisure centres.

For contractors, the opportunity is not only in
being able to respond to incoming EV charging
station requests, but to be able to advise
existing customers on the possibilities.

For commercial clients [hotels, ofce blocks,
entertainment venues] installing EV charging
stations will soon be a key differentiator
amongst competitors. Drivers will actively
seek out places where EV charging
is available.

1

Source: express.co.uk/life-style/cars/1362463/electric-car-uk-charging-station-infrastructure-petrol-diesel-ban-2030

2

Source: zap-map.com/prime-minister-outlines-his-ten-point-plan-for-a-green-industrial-revolution/

390,5004 Electric Vehicles

20,3834 Charging Stations

2020

10,000,0005 Electric Vehicles

29,0006 Charging Stations

2030

The same is true for new-build housing. As more
and more people look to replace petrol vehicles
with cleaner EV models, having EV charging
stations installed at point of build will become a
crucial selling point in a competitive market.

To truly make the most of the EV opportunity, you
need to be an early adopter, help your customers
understand the opportunity, and reap the rewards
as EV continues to evolve.

36,000,0003 Electric Vehicles

3,000,0007 Charging Stations

2040

36 MILLION ELECTRIC VEHICLES ARE EXPECTED ON UK ROADS BY 2040

6

Source: theccc.org.uk/publication/plugging-gap-assessment-future-demand-britains-electric-vehicle-public-charging-network/

7

Source: theccc.org.uk/publication/plugging-gap-assessment-future-demand-britains-electric-vehicle-public-charging-network/

3

3

Source: carbonbrief.org/rise-uk-electric-vehicles-national-grid-doubles-2040-forecast

5

Source: energy-uk.org.uk/les/docs/The_Future_of_Energy/2019/FutureofEnergy_ReportSection_Chapter4_04.19.pdf

4

Source: zap-map.com/statistics/

5

THREE DIFFERENT

WHAT CEF

OFFER

TYPES OF EV CHARGING

Home

Charging

Charging at home is often the most
convenient and cost effective way
to recharge EV, accounting for 80%
of all charging done by EV drivers.
Government grants are available for
the installation of a home EV charger,
but the installer must be OLEV
registered to claim.

Most electric vehicles can be charged at
home using a standard EV wallbox which
should be tted by a qualied electrician.

A wallbox is safer and quicker than using a
domestic socket, as it communicates directly
with the car and charging times are reduced
by 30 - 60%, depending on the vehicle.
3 kW or 7 kW EV chargers are standard
for the vast majority of installations.

Workplace

Charging

An increasing number of businesses
are installing EV charging units
for employees and visitors with
electric vehicles.

Workplace charging stations help make
electric vehicles viable for business users
with longer commutes and must be
installed in the company’s car park or
off-street parking.

While EV charging stations are similar
to home based units, power ratings tend
to be higher with more 7 kW and 22 kW
units installed.

Business units are often double socket,
allowing them to charge two vehicles
at the same time. When combined with
home charging, workplace charging can
double the daily electric range of a vehicle,
making use for longer distances viable.

Source of information: Zap Map: zap-map.com/charge-points/connectors-speeds/

Public

Charging

In the UK, there are a growing number
of public EV charging stations, with
some offering national coverage and
others only found in specic regions.
The major UK wide networks include
BP Chargemaster [Polar], Pod Point
and Charge Your Car.

When it comes to public charging
for longer journeys, rapid charging
is recommended.

This can provide up to 80% of charge
in as little as 20 minutes, making it the
quickest means of EV charging in the UK.

Public EV charging stations are mostly
installed and found at motorway service
stations or close to major roads.
The most common rapid chargers
used are 50 kW DC.

6

WHAT CEF

OFFER

HELPING YOU GET EV READY

As your electrical experts, we are
dedicated to providing you with the
knowledge, resources and products needed
to take advantage of the growing demand
for electric vehicle charging stations.

We offer a complete end to end solution which
means we can provide the training for you to get
started as well as a complete range of electric
vehicle charging products and accessories
whenever and wherever you need them.

Our comprehensive range covers the entire
installation process, so whether you’re looking
to install commercial charging stations, rapid
charging stations or residential charging stations
we have everything you need both in-store and
online at cef.co.uk to help you get EV ready:

Custom design

Bespoke single and three phase
distribution units designed to your
customers’ exact requirements.

390 STORES

NATIONWIDE

Installation

A complete array of installation products from
leading suppliers including ProteusEV and MCG-EV.

Electrical protection

18th Edition 1st amendment compliant O-PEN
from Matt:e providing protection against the
dangers of an open PEN conductor on a three
phase TN-C-S [PME] supply.

Fault detection

The latest testing and maintenance equipment
for detection of DC fault in your EV installations.

Choose CEF for your EV charging
solutions and benet from:

� Full range of EV charging products

and accessories from leading brands

� Assurance that all suppliers have

passed our due diligence process

� Stock solutions available for next

day delivery on orders placed before 8pm

� Bespoke solutions
� Click & Collect service

� NICEIC Electric Vehicle Charging training
� Guidance on buying an EV charger, accessories

and test equipment

� Access to knowledge articles, installation guides,

industry news and special offers via our dedicated
EV charging website cef.co.uk/plugintoev

� Dedicated email address for EV charging advice

and enquiries [email protected]

� Dedicated technical phone helpline

Working on a large project, in need of a national
agreement or require regional support?

Our National Accounts and Projects teams can help
you with tailor made solutions for your business.

For contractors working on larger projects or
companies who require a national agreement
or regional support, our National Accounts and
Projects teams can provide you with the products,
expertise, technical know-how and pricing
consistency for any project whatever and
wherever it may be.

Ask in-store for more details.

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

7

OLEV

GRANTS

EV CHARGING AT

HOME AND WORK

To boost the uptake of electric vehicles in
the UK, the Ofce for Low Emission Vehicles
[OLEV] is offering both commercial and
domestic customers grants to help with the
costs of installing EV charging stations at
home and in the workplace.

Here’s what you need to know about the eligibility
for each scheme and how you can help your
customers get the nancial support they are
entitled to.

Electric Vehicle Homecharge Scheme [EVHS]

Homeowners can benet from signicant savings
on EV charging stations via the EVHS.

8

The grant provides up to £350 off the cost of
purchasing and installing a
homecharging point.

Most electric and hybrid plug-in cars are eligible, a
full list can be found at:

gov.uk/plug-in-car-van-grants

Customers can claim one charge point per eligible
vehicle, with a maximum of two charging stations
per household. Again, off-street parking must be
available for the installation to take place.

Both the charging point and the installer must be
OLEV approved. To receive the grant, the date of
installation must not be more than four months
ahead of delivery or registration date.

An additional grant of up to £300 is available to
Scottish EV drivers via the Energy Savings Trust
Scotland.

You can nd out more about both grants online
by visiting the OLEV website:

gov.uk/government/collections/government­grants-for-low-emission-vehicles#electric­vehicle-homecharge-scheme

CUSTOMERS CAN CLAIM ONE CHARGING STATION

PER ELIGIBLE VEHICLE, WITH A MAXIMUM OF

TWO CHARGING STATIONS PER HOUSEHOLD

BUSINESSES CAN

Workplace Charging Scheme [WCS]

Businesses can save up to £10,000 on the cost of
installing EV charging stations through the WCS.

The WCS offers a 75% reduction in the cost
of purchasing and installing a new workplace
charging station [single socket]. There is a £350
cap per socket.

A maximum of 40 individual charging stations can
be claimed by a single business.

To qualify, businesses must have sufcient off­street parking available and charging stations
need to be installed by an OLEV
accredited installer.

Becoming an accredited installer
is a two stage process:

1. Gain accreditation via particular manufacturers

to install their products

2. Apply to OLEV to become an approved installer

Recipients of the grant don’t need to have electric
vehicles as part of their eet, but they do need
to be able to show an existing or future need
for EV charging within the business. However,
businesses can’t claim retrospectively, so make
sure your clients know about the opportunity
before work begins.

SAVE

on the cost of installing EV charging stations

75%

reduction in the cost of
purchasing and installing a
new workplace charging station

... but they do need
to be able to show
an existing or future
need for EV charging
within the business

£10K

UP TO

FORTY

individual charging
stations can be claimed
by a single business

£350

Recipients of the
grant don’t need to
have electric vehicles
as part of their eet...

CAP

PER SOCKET

Both the charging station
and the installer must be

OLEV approved

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

9

IET CODE OF

PRACTICE

ARE YOU UP

TO SPEED?

The IET Code of Practice 4th Edition provides
an overview of EV charging equipment
and has been updated in line with recent
changes to BS 7671 [IET Wiring Regulations].
It reects some major developments in
this area including vehicle to grid, smart
integration and inductive charging.
Therefore, before any installation,
make sure you’re up to speed with the new
requirements.

Essential reading for those procuring, installing,
managing or otherwise working on EV charging
stations, the IET Code of Practice considers
pre-installation and the physical and electrical
requirements in accordance with the 18th Edition
of the IET wiring regulations.

The Code of Practice is aimed at installers,
competent electricians, procurers who specify
EV installation work, design engineers [those who
manufacture EV charging equipment and vehicles],
and the electricity supply companies. It is also
used to communicate EV electrical safety to
the public. Therefore, it is vital that you are aware
of the detail within the latest regulations.

Electric vehicles may be the future, but there are
some risks to be aware of:

� Incorrect charging could overload a plug

and cable

� Wrongly installed EV charging equipment

could cause electrical res

� A fault in the electrical supply could make a

car live while on charge

� Death or injury could be caused by misuse of

adapters and extension leads

With these in mind, the Code of Practice has
been fully updated to reect the 18th Edition of
the IET Wiring Regulations, including the new
requirements around the use of PME [Protective
Multiple Earthing]. It also references all relevant
European and international standards.

WITH 80% OF CARS SOLD IN 2030 FORECAST TO HAVE
ELECTRIC OR HYBRID POWER OF SOME SORT, BEING UP

TO DATE HAS NEVER BEEN MORE ESSENTIAL

2622-8533

ONLY

£

60.95

Important changes since the 3rd Edition include:

� Use of open-PEN detection devices
� Issues with TT systems, including recommended

separation distances underground

� Improved risk assessment forms
� Phase unbalance in three-phase systems,

including a table and rule-of-thumb which can
be used to avoid complex calculations

0% VAT

10

cef.co.uk/plugintoev

AMENDMENT TO

BS 7671 IET WIRING
REGULATIONS

The Institution of Engineering and
Technology’s [IET] Wiring Guidelines BS
7671:2018 has been amended to support
the roll-out of electric vehicle charging
infrastructure across the UK.

Effective February 2020, the update follows
advances in technology that were unavailable
when BS 7671:2018 was rst published.

Consisting of a stand-alone update to Section
722 Electric Vehicle [EV] Charging Installations,
the change has been designed to reduce the
cost for both consumers and installers, while
simultaneously making the installation of charging
points quicker and easier – a necessity if the UK
Government is to achieve it’s target of emitting
virtually zero carbon by 2050.

Having the correct guidance to hand for the
installation of practical and safe charging points
will be vital for EV installers in helping the UK
create one of the largest electric vehicle charging
networks in Europe.

You can view Amendment 1
of BS 7671:2018 for free here:

electrical.theiet.org/bs-7671/
updates-to-18th-edition/

2378-9218

ONLY

£

77

.95

0% VAT

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

11

TRAINING

ELECTRIC VEHICLE

CHARGING COURSES

Before an electrician is able to install
EV charging stations, they’ll need to become
an accredited installer with one [or more]
EV charger manufacturers.

At CEF we can arrange electric vehicle charging
training for you, via the NICEIC, City and Guilds
or through our suppliers.

PUT SIMPLY, EV CHARGING
IS NO LONGER A FUTURE
TREND. IT IS HERE TO STAY.

SO DON’T MISS OUT ON
THIS HUGE OPPORTUNITY

AND MAKE IT AN INTEGRAL
PART OF THE SERVICE
YOUR BUSINESS OFFERS

NICEIC TRAINING

The NICEIC’s electric vehicle charging
courses cover the installation of electric
vehicle charging stations in compliance
with BS 7671, the Electrical Safety Quality
and Continuity Regulations and the new IET
Code of Practice.

Course outline

� Introduction to electrical vehicle charging
� History of electric vehicles
� Government legislation and incentives
� BS 7671 - supply requirements,

installation requirements,
protection requirements

� The IET Code of Practice
� Product demonstration
� Exam [followed by Q&A]

Who should attend?

Available as both classroom training
and virtual training, the course lasts one
day and is aimed at contractors looking
to expand their business to include the
installation of EV charging stations.

Entry requirements

There are no formal entry requirements
to attend this course, however candidates
should have a basic knowledge and
understanding of electrical science and the
principles of electrical installation work.

To check dates, availability and
book a course visit your
local CEF store.

12

cef.co.uk/plugintoev

CITY & GUILDS
TRAINING

The City and Guilds training course aims to provide expert guidance
to electricians wishing to gain knowledge and understanding on
electric vehicle charging equipment installation.

Course outline

� Introduction to electric vehicles
� EV characteristics, charging requirements and safety considerations
� Overview of EV charging
� Modes of EV charging, requirements and restrictions
� Requirements for electrical installation
� Electrical supply, earthing, planning permission, explosive

atmospheres, protection, labelling, control and risk assessment

� Domestic and commercial installations
� Practical domestic and commercial installations
� Inspection, test and certication
� Commissioning and DNO paperwork
� Risk assessment, pre and post installation check lists
� System test, fault nding and examination
� C&G 2919-01, 60 mins multi-choice exam and 180 mins practical

assessment [both open book IET CoP to EV charging]

Who should attend?

This course lasts 2 days and is aimed at practicing electricians
interested in understanding how to install the range of equipment
and systems available. It covers the specialised installation
requirements of electric vehicle charging equipment in public,
private and commercial locations and includes exclusive guidance
on electrical requirements.

Entry requirements

There are no formal entry requirements to attend this course,
however it is recommended you are up to date with your 18th Edition
wiring regulations.

For more information on EV charging training
or to book a course, contact your local CEF store.

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

13

EASY

WAYS TO SHOP

THE EASY WAY TO SHOP FOR ELECTRICAL PRODUCTS

390 STORES

NATIONWIDE

Open 6 days a week

Monday – Friday 7:30am – 5:30pm
Saturday – 8:30am – 12:00 pm
[local exceptions may apply]

TRADE APP

DOWNLOAD NOW

Get the products you need

smart phone or tablet with our
free app. It’s as easy as...

1. Scan, 2. Select 3. Checkout

on your

OVER 35,000

ITEMS ONLINE

Choose from over 35,000 products

In stock at cef.co.uk

CLICK
& COLLECT

If a product is in-store, reserve it online and it
will be ready for you to collect when you need it.

Can’t find it in-store? Order in-store or online
[before 8pm] for collection from your chosen
store the next working day

Find your 8 digit order code.

Order in-store, online or over the phone

Save time, next time.

allows you to pre-order by phone, text or
email to your local store, so that you can
collect at a time that suits you

TRADE
CATALOGUE

PREORDER
& COLLECT

Our pre-order & collect

OPEN A TRADE ACCOUNT TODAY [INSTORE OR ONLINE] AND BENEFIT FROM:

� Credit facilities

[subject to credit checks]

� Monthly statements

� VAT approved itemised invoices
� Online account management

� Make payments online
� View previous orders

14

EASY WAYS
TO PAY...

Whether online or
in-store you can pay via

CASH

£

In-store

CARD

In-store and
online

PAYPAL

Online

BANK
TRANSFER

Subject to
account type

cef.co.uk/plugintoev

CHOOSE FROM OVER

DELIVERY MADE
EASY

OVER 35,000 PRODUCTS AND HAVE THEM
DELIVERED WHERE AND WHEN YOU NEED THEM

DELIVERY OPTIONS TO SUIT YOU

SAME DAY DELIVERY

If the product you want is in stock at your local store, we’ll arrange with you how and where you
want it delivered. Simply check the stock online and call your nearest store.

35,000 PRODUCTS IN

STOCK AT CEF.CO.UK

cef.co.uk

way to purchase electrical products. With more than
35,000 products in stock and available for next day
delivery from our 151,000ft2 warehouse, you can be
assured you will nd everything you need to get the
job done with delivery options to suit you.

OUR AWARD WINNING WEBSITE FEATURES:

is the fastest, most convenient

Improved search
Fast and easy navigation
Detailed product information including data

sheets and enriched content
Great deals
Guest checkout
Product pricing and stock availability
Next day delivery for orders placed before 8:00pm
Multiple secure payment options
Customer product reviews
Store locator
Online chat

NEXT DAY LOCAL DELIVERY

We’re ready and waiting to deliver your orders where and when you need them. Simply order
online before 8pm Monday – Friday and we’ll deliver the next working day. All orders over £50 are
delivered free of charge. Timed deliveries are available at an extra cost.

CLICK & COLLECT

If a product is in-store, reserve it online and it will be ready for you to collect when you need it.
Can’t nd it in-store? Our Click & Collect allows delivery of any product on our website to your
chosen store the very next working day. Simply order in-store or online [before 8pm] and collect
at a time that suits you.

PREORDER & COLLECT

Save time, next time. Our pre-order & collect allows you to pre-order by phone, text or email to your
local store, so that you can collect at a time that suits you.

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

15

YOUR KEY TO

EV CHARGING

Convenient EV Charging
for residential situations

iCS

3 YEARS*

WARRANTY

*WHEN INSTALLED UNDER THE OLEV GRANT SCHEME

The iCS product range is tailored to
overcome many of the challenges faced by
EV charge point installers. From negating
the need to install additional earth devices,
to controlling power distribution through
the unique software solution, iCS make
installing EV Charging systems easier.

No need for additional earth devices

The iCS workplace charging range includes
earth fault monitoring circuits that are fully
compliant with the IET Code of Practice
4th Edition, which means installation on to
standard TN-C-S [PME] systems can be
carried out without the need to install
additional earth devices.

Fewer calls to site

Their all-in-one workplace charge points
require no further EV equipment, regardless of
features required or the size of the installation
and come as standard with an automatic fault
recovery system, thereby reducing the number
of calls to site.

No need to upgrade infrastructure

Software is a key component to public
EV installations and the iCS2.0 smart
charging solution is fully compatible with
the OCPP1.6J workplace charge points.
A key feature is the ability to increase
the number of charge points installed
on-site without the need to upgrade
electrical infrastructure, saving end
users substantial costs.

Becoming an approved installer is
straight forward

iCS provide City & Guilds accredited
training courses for contractors wishing
to get involved with EV charge point
installations. For customers who are
already OLEV approved, they offer
product familiarisation modules to get
you up and running quickly.

Ask in-store for more information.

EV Charging suitable
for public locations

Ideal EV business solution
for employees and visitors

Auto On / Off with charge rate controlled
by the car and current level limited by

MODE 2

the supply circuit

Faster charging than Mode 2 with
dedicated controls and advanced

MODE 3

communication with the vehicle

Up to 7 kW AC [single phase only]

Up to 43 kW AC rapid or 22 kW AC
fast charging [single phase or 3 phase
for faster charging]

Monitoring and charging control
via Smart Device

Added convenience; just park
and plug in with tethered lead

Ingress protection against particles
[1st digit] and liquids [2nd digit]

Qualies for grant funding when installed
by a professional accredited installer

Qualies for grant funding
when professionally installed
in workplace locations

THE iCS WORKPLACE
CHARGING RANGE INCLUDES
EARTH FAULT MONITORING
CIRCUITS THAT ARE FULLY

COMPLIANT WITH THE IET CODE
OF PRACTICE 4TH EDITION

16

cef.co.uk/plugintoev

7 kW [32A] HOMECHARGE EV WALL UNIT

7 kW [32A] SMART AC EV WALL UNIT

MODE 3

§ Simple but intuitive EV charging solution for the home

§ LED Charging status indicator

§ Built-in Type B RCCB protection [30 mA AC / 6 mA DC]

§ UV Stabilised, corrosion and impact resistant design

§ Mounted: Wall

§ Dimensions: 326 mm[H] x 199 mm[W] x 132 mm[D]

§ Output: Type 2 socket

§ IEC 61851-1

22 kW [32A] SMART AC EV WALL UNIT

MODE 3 MODE 3

2613-8308

ONLY

£

359

.95

+VAT

MODE 3

§ Ideal solution in workplace parking environments

§ Integrated earth fault sensing device allowing direct

connection to a TN-C-S earthing system

§ Built-in minor fault recovery; reducing calls to site

§ Compatible with iCS2.0 software allowing multiple

units to run efficiently on existing infrastructure

§ Switchable charge rate: 6A, 8A, 10A, 13A, 16A, 20A,

25A and 32A

§ OCPP 1.6 Compliant

§ User authentication via authorised RFID cards

[included]

§ Safe data transfer via VPN using 3G / 4G

modem [sim required] or ethernet connectivity

§ Mounted: Wall or pole [sold separately]

§ Dimensions: 363 mm[H] x 318 mm[W] x 136 mm[D]

§ Output: Type 2 socket

§ IEC 61851-1

22 kW [32A] SMART AC EV PEDESTAL

2613-8305

ONLY

.00

725

£ +VAT

§ Modern metal cased unit with large 7" LCD display –

ideal for public or workplace charging

§ Integrated earth fault sensing device allowing direct

connection to a TN-C-S earthing device

§ Built-in minor fault recovery; reducing calls to site

§ Compatible with iCS2.0 software allowing multiple

units to run efficiently on existing infrastructure

§ No additional equipment required for multiple unit

installations or connection to software

§ User authentication via authorised RFID cards or

configured to plug and charge

§ Safe data transfer via VPN using 3G / 4G modem [SIM

required], ethernet or Wi-Fi connectivity

§ Mounted: Wall or pole [sold separately]

§ Dimensions: 400 mm[H] x 270 mm[W] x 130 mm[D]

§ Output: 2 x Type 2 sockets

§ IEC 61851-1

390 STORES

NATIONWIDE

§ Installer friendly pedestal with large 7" LCD display –

ideal for public or workplace charging

§ Integrated earth fault sensing device allowing direct

connection to a TN-C-S earthing device

§ Built-in minor fault recovery; reducing calls to site

§ Compatible with iCS2.0 software allowing multiple

units to run efficiently on existing infrastructure

§ No additional equipment required for multiple unit

installations or connection to software

§ User authentication via RFID cards or configured to

plug and charge

§ Safe data transfer via VPN using 3G / 4G modem [SIM

2632-8127

ONLY

required], ethernet or Wi-Fi connectivity

§ Mounted: Floor

§ Dimensions: 1,425 mm[H] x 350 mm[W] x 200 mm[D]

§ Output: 2 x Type 2 sockets

§ IEC 61851-1

.95

899

£ +VAT

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

2634-1639

ONLY

2,459£

.95

+VAT

17

CHARGING LEADS

� Current rating: 32A
� IEC 62196-2 and

EN 50620

FROM

INCLUDES:

� Carry case
� 2 x Microfibre cleaning mitts

Code kW Rating Output Length 1+

Single Phase Charging Lead

2613-8311 7 kW Type 2 to Type 2 5 m £124.95

3 Phase Charging Lead

2613-8314 22 kW Type 2 to Type 2 5 m £199.95

£

.95

+VAT124

EV CHARGING SIGNS

� Highlight location of EV charging spaces
� Aluminium printed sign
� Class I reflective

INCLUDES:

� 2 x 76 mm Post clips [2624-4643]

and [2633-5810] only

Code Mounting Channels Height Width 1+

2624-4646 - 200 mm 300 mm £21.95
2624-4643 Horizontal 300 mm 400 mm £42.95
2633-5810 Vertical 300 mm 400 mm £42.95

FROM

.95

£ +VAT21

FLOOR MOUNTED
PROTECTION BARRIER

� Galvanised structural-steel construction
� Dimensions: 750 mm[H] x 750 mm[W]

2627-4286

ONLY

£

99

.95

+VAT

FLOOR MOUNTED POLE

� Suitable for floor mounting

[2613-8305] charging unit

� Galvanised steel construction
� Height: 1.4 m

Code 1+

2623-9696 £139.95

Root Mounting Kit

2625-3025 £39.95

18

FLOOR MOUNTED POLE

� Suitable for floor mounting

[2613-8305] and [2632-8127]

charging units

� S235 steel construction
� Removable rear access plate
� Integrated junction box for

cable termination

� Height: 1.39 m

2625-3025

2623-9696 2624-4598

ONLY

Integrated junction box

ONLY

.95

£

£ +VAT

139

cef.co.uk/plugintoev

279

.95

+VAT

PRICING DETAILS: [EX V.A.T]*

Description 1+

Charge point setup fee [per charge point] £19.99
Charge point subscription 1 year [per charge point] £60.00
User [driver] subscription 1 year [per user] £12.00
User card [optional RFID card] £2.50

*REVENUE GENERATED FROM CHARGE SESSIONS IS
SUBJECT TO A £0.25 TRANSACTION FEE

ICS2.0 EV

CHARGING SOFTWARE

iCS charging software iCS2.0 enables the
intelligent control and management of an EV
network. Charging stations are administered
on an ultra-fast cloud-based web portal with
fully customisable options and access levels,
giving the user total control.

� Industry leading event-based smart

charging, using only the available

electrical capacity on-site

� No costly additional infrastructure
� Scalable with a limitless number

of connected charge points

� Reliable and responsive interface
� Data reporting including

employee reimbursement

� Mapping, roaming and billing functionality
� Remote management
� Charge Assist App [available on iOS and Android]

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

Manage the way revenue is generated
from your EV charging network

With iCS2.0 users can:

� Set charging tariffs for each location and

for any EV driver so that they can use your
charge points

� Processes payments from 3rd party users,

ensuring revenue is guaranteed and
paid monthly

� Grant authorised drivers access to charge

at any participating iCS supplied charge
point, with one central invoice raised,
including a costed breakdown of charging
sessions per driver

� Access charge session records for

authorised drivers [or charge cards]
using your own network, allowing you
to invoice accordingly if required

� Set reimbursement tariffs for charge point

networks that incorporate employee home
chargers for company vehicle drivers, ensuring
employees are compensated accordingly for
the electricity used at home

Pricing

Subscription to iCS2.0 includes smart charging
functionality to provide charging networks
based on the available spare capacity on-site.
Remote management and connectivity to the
Charge Assist app enables receipt of credit
card payments directly from charge points as
standard. You are in full control of the revenue
[if applicable] you wish to receive.

User [Driver] subscriptions can be added to
enable detailed reporting of charge point use per
driver, so accurate billing can be easily actioned.

LOCALLY

19

YOUR KEY TO

EV CHARGING

Convenient EV Charging
for residential situations

EV Charging suitable
for public locations

ABB

3 YEARS

WARRANTY

With a heritage spanning more
than 130 years, ABB – a pioneering
technology leader, provide market­leading e-mobility solutions for
some of the world’s biggest brands
and have a world-leading AC and DC
charging portfolio

With years of experience in creating,
installing and maintaining charging
infrastructure, including several

nationwide charger networks, ABB offer a
complete EV charging solution from compact,
high quality, OLEV approved AC wallboxes,
reliable DC fast charging stations with robust
connectivity, to innovative on-demand electric
bus charging systems. Their ABB Ability™
connected chargers enable fast global service
and pro-active maintenance.

In deploying infrastructure that meets the
needs of the next generation of smarter

Ideal EV business solution
for employees and visitors

Auto On / Off with charge rate controlled
by the car and current level limited by

MODE 2

the supply circuit

Faster charging than Mode 2 with
dedicated controls and advanced

MODE 3

communication with the vehicle

Up to 7 kW AC [single phase only]

Up to 43 kW AC rapid or 22 kW AC
fast charging [single phase or 3 phase
for faster charging]

Monitoring and charging control
via Smart Device

Added convenience; just park
and plug in with tethered lead

Ingress protection against particles
[1st digit] and liquids [2nd digit]

Qualies for grant funding when installed
by a professional accredited installer

Qualies for grant funding
when professionally installed
in workplace locations

THEIR ABB ABILITY™
CONNECTED CHARGERS ENABLE
FAST GLOBAL SERVICE AND
PROACTIVE MAINTENANCE

mobility, ABB lays the foundations for a future
of smarter, reliable, and emission-free mobility,
accessible by everyone, everywhere.

Ask in-store for more information.

20

cef.co.uk/plugintoev

7.4 kW [32A] TERRA AC WALLBOX

MODE 3

� Versatile and future-proof charging solution for any home,

business or public location

� Enabled for remote software updates and energy meter

integration for dynamic load management

� Built-in overload, ground fault, surge protection and

continuity monitoring

� Wi-Fi, Bluetooth® and ethernet connectivity for easy

integration with existing infrastructure

� Dedicated app allows for user authentication, control and

optimal charging status indication

� RFID cards allow vehicle charging authorisation when swiped

against the station – sold separately [2629-2583]

� Mounted: Wall or pedestal [sold separately]
� OCPP 1.6 compliant
� Dimensions: 320 mm[H] x 195 mm[W] x 110 mm [D]
� IEC 61851-1 and IEC 61851-23

ONLY

Code Output Authentication Connectivity 1+

2629-2514 Type 2 Socket Free to use Bluetooth® / Ethernet / Wi-Fi £425.00

22.1 kW [32A] TERRA AC WALLBOX

MODE 3

� Versatile and future-proof charging solution for any home,

business or public location

� Enabled for remote software updates and energy meter

integration for dynamic load management

� Built-in overload, ground fault, surge protection and

continuity monitoring

� Wi-Fi, Bluetooth® and ethernet connectivity for easy

integration with existing infrastructure

� Dedicated app allows for user authentication, control and

optimal charging status indication

� RFID cards allow vehicle charging authorisation when swiped

against the station – sold separately [2629-2583]

� Mounted: Wall or pedestal [sold separately]
� OCPP 1.6 compliant
� Dimensions: 320 mm[H] x 195 mm[W] x 110 mm [D]
� IEC 61851-1 and IEC 61851-23

Code Output Authentication Connectivit y 1+

2629-2517 Type 2 Socket Free to use Bluetooth® / Ethernet / Wi-Fi £619.95
2629-2520 Type 2 Socket Smartphone / RFID Bluetooth® / Ethernet / Wi-Fi £815.00
2629-2523 Type 2 Socket Smartphone / RFID 4G / Bluetooth® / Ethernet / Wi-Fi £895.00

£

425

FROM

£

619

.00

+VAT

.95

+VAT

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

21

TERRA AC PEDESTAL

� For floor mounting up to two

Terra AC Wallbox charging

stations back-to-back

� Dual pedestals must be fitted

with two units to prevent

exposed cable opening

� Height: 1.4 m

TERRA AC PEDESTAL

� For floor mounting up to two

Terra AC Wallbox charging
stations back-to-back

� Removable access panel with

internal DIN rail mounting
for devices

� Must be fitted with two units

to prevent exposed cable
opening

� Height: 1.46 m

FROM

259£

Code Mounting 1+

2639-7277 Single £259.95
2639-7280 Dual £389.95

RFID CARDS

� Swipe the card against the station to authorise vehicle charging
� Compatible with Terra AC Wallbox charging units
� Pack of 5

22

.95

+VAT

+VAT

2629-2580

ONLY

.00

625£

2629-2583

ONLY

+VAT

.95

£

cef.co.uk/plugintoev

+VAT12

FULLY CONNECTED

• User is typically the owner/ EV driver that creates
an account on the app and then adds a charger to
the account.

• One charger can be operated by multiple smart
phones if they all share the same account (with
same username and password). This allows multiple
people to share an access controlled charger.

– Authentication
– Adding a charger (and unbinding a charger)
– Firmware upgrade
– Load balancing - adjust to static power limit
– Energy Plan
– Schedule
– Status monitoring
– Troubleshoot
– Statistics

—
Download now for iOS or Android

TERRA AC: CHARGERSYNC APP

FOR LARGER BUSINESSES
AND CHARGING SITES

Functionality: Functionality:

� Create an account and add numerous chargers and users

to the account

� Portal for configuration and monitoring of cloud based

load management

� Connect to the charger when it's online [via LAN / Wi-Fi /

4G] to do advanced configuration, view charging status,
statistics and errors

� Map various RFID cards in groups and

priority to the accounts

� Top up each card with virtual money

and specify a cost per kWh

� Configure charging site
� Operate charging site
� Add multiple chargers
� Manage user group &

authentication

� Detailed usage and status

monitoring

� Revenue data
� Static load management
� Hybrid load management

[subscription based, first 6
months free]

� Remote control
� OCPP logs
� Logs of charging sessions

FOR HOME
AND SINGLE USE CASES

� Create an account on the app and then add a charger

to the account

� One charger can be operated by multiple smart

phones if they all share the same account [with same
username and password]. This allows multiple people
to share an access controlled charger

� Authentication
� Adding a charger [and unbinding

a charger]

� Firmware upgrade
� Load balancing -

adjust to static power limit

� Energy Plan
� Schedule
� Status monitoring
� Troubleshoot
� Statistics

DOWNLOAD NOW

FOR IOS OR ANDROID

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

23

ROLEC

YOUR KEY TO

EV CHARGING

Convenient EV Charging
for residential situations

EV Charging suitable
for public locations

Ideal EV business solution
for employees and visitors

Auto On / Off with charge rate controlled
by the car and current level limited by

MODE 2

the supply circuit

Faster charging than Mode 2 with
dedicated controls and advanced

MODE 3

communication with the vehicle

Up to 7 kW AC [single phase only]

Up to 43 kW AC rapid or 22 kW AC
fast charging [single phase or 3 phase
for faster charging]

Monitoring and charging control
via Smart Device

Added convenience; just park
and plug in with tethered lead

Ingress protection against particles
[1st digit] and liquids [2nd digit]

3 YEARS

WARRANTY*

*WHEN INSTALLED UNDER THE OLEV, EVHS, OR WCS GRANT SCHEMES. SUBJECT TO ROLEC AND OLEV T&C'S

Rolec EV is the largest independent
EV charge point manufacturer in the UK.

Having specialised for over 10 years in the design,
manufacture and supply of Europe’s largest and
most diverse range of electric vehicle charging
solutions. Rolec EV has manufactured and supplied
over 150,000 EV charging stations to date.

Rolec EV manufactures high quality, cost effective
EV charging units and is an OLEV government

grant funding approved manufacturer.
Rolec EV has a product portfolio which
encompasses the most comprehensive
EV charging range in Europe, with all EV
charging stations compatible with all EVs
and PHEVs.

Become a Rolec EV / OLEV
approved installer

Rolec EV sponsor NICEIC, City & Guilds
and EAL training courses to help provide

24

Qualies for grant funding when installed
by a professional accredited installer

Qualies for grant funding
when professionally installed
in workplace locations

electrical contractors with the
accreditation they need to access grant
funding for both domestic and commercial
EV charging point installations.

Contractors who complete the training will
become OLEV approved. Upon completion,
they can then register with Rolec to
become Rolec approved.

Ask in-store for more information.

cef.co.uk/plugintoev

WALLPOD: EV READY

7.2 kW [32A] EV WALLPOD

MODE 3

� Can be easily upgraded for Type 1 or Type 2, Mode 3

charging – upgrade kits sold separately

� Outdoor socket is also ideal for home maintenance,

charging mobility scooters, electric bikes, etc.

� Built-in overload and fault current protection

[Type A RCBO]

� UV Stabilised, fire retardant, corrosion and impact

resistant design

� Dimensions: 367 mm[H] x 179 mm[W] x 142 mm[D]
� IEC 61851-1

Code kW Rating Current Rating Output 1+
Code kW Rating Current Rating Output 1+

1402-3339 3 kW 13A Domestic Socket £91.50

Tethered Upgrade Kits

1597-9240 3.6 kW 16A Type 1 Socket £319.95
1597-9243 7.2 kW 32A Type 1 Socket £355.00

Socket Upgrade Kits

1597-9252 3.6 kW 16A Type 2 Socket £239.95
1597-9255 7.2 kW 32A Type 2 Socket £239.95

7.2 kW [32A] HOMESMART EV WALLPODS

MODE 3

� Simple interactive EV charging solution for the

home with tethered lead for added convenience

� App controlled charging and smart analytics
� Built-in overload and fault current protection

[Type A RCBO]

� Class 1 MID compliant kWh meter and LED charging

status indicator

� UV Stabilised, fire retardant, corrosion and impact

resistant design

� Dimensions: 415.5 mm[H] x 179 mm[W] x 142 mm[D]
� IEC 61851-1

FROM

£

91

.50

+VAT

MODE 3

� Entry level unit designed for domestic and

commercial locations

� LED charging status indicator
� Built-in overload and fault current protection

[Type A RCBO]

� UV Stabilised, fire retardant, corrosion and impact

resistant design

� Dimensions: 367 mm[H] x 179 mm[W] x 142 mm[D]
� Output: Type 2 socket - Lockable
� IEC 61851-1

7.2 kW [32A] HOMESMART EV WALLPOD

MODE 3

� Simple interactive charging solution for the home

with a neat socket to connect EV charging lead

� App controlled charging and smart analytics
� Built-in overload and fault current protection

[Type A RCBO]

� Built-in Class 1 MID compliant kWh meter and LED

charging status indicator

� UV Stabilised, fire retardant, corrosion

and impact resistant design

� Dimensions: 367 mm[H] x 179 mm[W] x 142 mm[D]
� Output: Type 2 socket
� IEC 61851-1

1402-3417

ONLY

379£

2575-9378

.95

+VAT

Code Output 1+

2575-9366 Type 1 Tethered Lead £525.00
2575-9372 Type 2 Tethered Lead £525.00

390 STORES

NATIONWIDE

ONLY

.00

£

525

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

+VAT

LOCALLY

ONLY

449£

.95

+VAT

25

7.2 kW [32A] SECURICHARGE
EV WALL UNITS

MODE 3 MODE 3

� Heavy-duty, vandal resistant charging unit, designed

specifically for public and exposed locations

� LED halo charging status indicator
� Built-in overload and fault current protection
� UV Stabilised, fire retardant, corrosion and impact

resistant design

� IEC 61851-1

OPENCHARGE FEATURES:

� OCPP 1.6 compliant
� User authentication via authorised RFID tags,

smartphone or configured to plug and charge

� Electrical load management software
� Built-in MID approved meter
� GPRS modem with antenna and ethernet connection
� Choice of data management plans – essential or

premium [fees will apply]

Code Output Height Width Depth 1+

Standard Units

2077-4374 Type 2 Socket 500 mm 200 mm 125 mm £614.95
2077-4386 2 x Type 2 Sockets 500 mm 200 mm 125 mm £895.00

OpenCharge Units*

2625-7612 Type 2 Socket 575 mm 320 mm 155 mm £835.00
2625-7615 2 x Type 2 Sockets 575 mm 320 mm 155 mm £1,215.00

*OpenCharge units, unless

otherwise stated at time of
order, will be programmed
to operate with Rolec's
own back-office
management system

FROM

.95

614£

+VAT

7.2 kW [32A] BASICCHARGE
EV PEDESTALS

� Best selling tried and tested pedestal is

extremely versatile and very affordable

� Photocell controlled integrated LED amenity

lighting and secure hatchlock facility

� Built-in overload and fault current protection
� LED halo charging status indicator
� Mounted: Surface or root
� UV Stabilised, fire retardant, corrosion and

impact resistant design

� Dimensions: 1,130 mm[H] x 205 mm[W] x

205 mm[D]

� IEC 61851-1

CHARGING LEADS

� Current rating: 32A
� IEC 62196

FROM

124£

Code Output Length 1+

1402-3948 Type 2 to Type 1 5 m £124.95
2248-7539 Type 2 to Type 1 10 m £149.95
1402-3930 Type 2 to Type 2 5 m £131.95
2248-7536 Type 2 to Type 2 10 m £164.95

26

.95

+VAT

OPENCHARGE FEATURES:

� OCPP 1.6 compliant
� User authentication via authorised RFID tags,

smartphone or configured to plug and charge

� Electrical load management software
� Built-in MID approved meter
� GPRS modem with antenna and ethernet connection
� Choice of data management plans – essential or

premium [fees will apply]

Code Output 1+

Standard Units

2077-4230 Type 2 Socket £549.95
2077-4242 2 x Type 2 Sockets £795.00

OpenCharge Units*

2625-7618 Type 2 Socket £735.00
2625-7621 2 x Type 2 Sockets £1,150.00

Base for Root Mounting

1402-3186 £23.95

1402-3186

£549.95

cef.co.uk/plugintoev

*OpenCharge units, unless

otherwise stated at time of
order, will be programmed
to operate with Rolec's
own back-office
management system

FROM

.95

£

549

+VAT

7.2 kW [32A] AUTOCHARGE
EV PEDESTAL

MODE 3 MODE 3

7.2 kW [32A] QUANTUM
EV PEDESTAL

� Robust, heavy-duty pedestal designed

specifically for commercial and
public environments

� 2 x Charging sockets with security

hatchlock facility

� Built-in overload and fault current

protection components behind

lockable door

� LED halo charging status indicator
� Mounted: Surface or root
� UV Stabilised, corrosion and impact

resistant design

� Dimensions: 1,275 mm[H] x 332 mm[W]

x 270 mm[D]

� IEC 61851-1

2077-4479

� Versatile, heavy-duty pedestal designed

specifically for commercial and
public environments

� Photocell controlled integrated LED

amenity lighting and secure
hatchlock facility

� Built-in overload and fault

current protection

� LED halo charging status indicator
� Mounted: Surface or root
� UV Stabilised, corrosion and impact

resistant design

� Dimensions: 1,440 mm[H] x 375 mm[W]

x 275 mm[D]

� IEC 61851-1

2453-4625

OPENCHARGE FEATURES:

� OCPP 1.6 compliant
� User authentication via authorised RFID tags,

smartphone or configured to plug and charge

� Electrical load management software
� Built-in MID approved meter
� GPRS modem with antenna and ethernet connection
� Choice of data management plans – essential or

premium [fees will apply]

Code Output 1+

Standard Unit

2077-4317 2 x Type 2 Sockets £1,119.95

OpenCharge Unit*

2625-7627 2 x Type 2 Sockets £1,335.00

Base for Root Mounting

2077-4479 £51.95

390 STORES

NATIONWIDE

*OpenCharge units, unless

otherwise stated at time of
order, will be programmed
to operate with Rolec's
own back-office
management system

FROM

.95

1,119£

+VAT

OPENCHARGE FEATURES:

� OCPP 1.6 compliant
� User authentication via authorised RFID tags,

smartphone or configured to plug and charge

� Electrical load management software
� Built-in MID approved meter
� GPRS modem with antenna and ethernet connection
� Choice of data management plans – essential or

premium [fees will apply]

Code Output 1+

Standard Unit

2453-4619 2 x Type 2 Sockets £1,125.00

OpenCharge Unit*

2625-7624 2 x Type 2 Sockets £1,375.00

Base for Root Mounting

2453-4625 £51.95

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

*OpenCharge units, unless

otherwise stated at time of
order, will be programmed
to operate with Rolec's
own back-office
management system

FROM

£1,125

LOCALLY

.00

+VAT

27

YOUR KEY TO

SCHNEIDER

ELECTRIC

3 YEARS

WARRANTY

EV CHARGING

Convenient EV Charging
for residential situations

EV Charging suitable
for public locations

Ideal EV business solution
for employees and visitors

Auto On / Off with charge rate controlled
by the car and current level limited by

MODE 2

the supply circuit

Faster charging than Mode 2 with
dedicated controls and advanced

MODE 3

communication with the vehicle

Up to 7 kW AC [single phase only]

Up to 43 kW AC rapid or 22 kW AC
fast charging [single phase or 3 phase
for faster charging]

Monitoring and charging control
via Smart Device

Added convenience; just park
and plug in with tethered lead

Ingress protection against particles
[1st digit] and liquids [2nd digit]

Qualies for grant funding when installed
by a professional accredited installer

Qualies for grant funding
when professionally installed
in workplace locations

Schneider Electric, a worldwide expert
in energy management, offer a variety of
solutions for charging electric vehicles with
EVlink and energy management software.

Their solutions for both residential and
commercial charging includes EVlink smart wall
boxes, EVlink parking for fast charging.

28

The EVlink charging stations are suitable
for daily use and are compatible with a wide
range of electric vehicles. EVlink is a solution
which incorporates energy management,
minimises installation costs and provides
exibility, protection, reliability and efciency.

From installation to maintenance, EVlink
charging stations incorporate Schneider
Electric expertise to provide the best solution
possible to you with the added benet of
OLEV approved manufacturer status.

Ask in-store for more information.

cef.co.uk/plugintoev

7.4 kW [32A] EVlink WALLBOX 7.4 kW [32A] EVlink SMART WALLBOX

MODE 3 MODE 3

� Plug and charge convenience with

one-touch Start / Stop

� Environmentally friendly options for

controlling energy consumption with
delayed start allowing for off-peak
only charging

� Key locking to prevent

unauthorised charging

� Dimensions: 480 mm[H] x

330 mm[W] x 170 mm[D]

� IEC 62196-2

� Plug and charge convenience with one-touch

Start / Stop

� Environmentally friendly options for controlling

energy consumption with delayed start allowing

for off-peak only charging

� Easy commissioning with a laptop connected to

the embedded webserver

� Key locking to prevent cable theft and

unauthorised charging

� Dimensions: 480 mm[H] x 330 mm[W]

x 170 mm[D]

� Output: Type 2 socket
� OCPP 1.6 compliant
� IEC 62196-2

2255-0269

Code Output 1+

2255-0254 Type 1 Tethered Lead £515.00
2255-0257 Type 2 Tethered Lead £499.95

7.4 kW [32A] EVlink
SMART WALLBOX

MODE 3 MODE 3

� Plug and charge convenience

with one-touch Start / Stop

� Environmentally friendly

options for controlling energy
consumption with delayed
start allowing for off-peak
only charging

� User authentication via

authorised badges compatible
with the station’s RFID badge

� Easy commissioning with

a laptop connected to the
embedded webserver

� Key locking to prevent cable

theft and unauthorised charging

� Dimensions: 480 mm[H] x

330 mm[W] x 170 mm[D]

� Output: Type 2 socket
� OCPP 1.6 compliant
� IEC 62196-2

INCLUDES:

� 10 x RFID Badges

2255-0272

ONLY

£1,014

.95

+VAT

FROM

£

499

.95

+VAT

7 kW EVLINK PARKING
FLOOR CHARGING STATION

� Ideal solution in all parking

environments: Offices, hotels,
supermarkets and fleets

� Visual charging details with record

function [30 day history]

� Adaptable charging station power

demand to match your
electrical distribution

� Configure your charging station via

EVlink embedded web server

� Charging cable to remain securely

plugged in to the charging station

� Dimensions: 1146 mm[H]

x 413 mm[W] x 220 mm[D]

� Output: 2x Type 2 sockets
� OCPP 1.6 compliant
� IEC 61851-1

2255-0248

FROM

£

2,499

CHARGING LEADS

� Current rating: 32A
� IEC 62196

Code Output Length

.95

2255-0263 Type 2 to Type 1 5 m

+VAT

2255-0266 Type 2 to Type 2 5 m

ONLY

£

799

ONLY

379

£ +VAT

.95

+VAT

.95

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

29

EVBOX

YOUR KEY TO

EV CHARGING

Convenient EV Charging
for residential situations

EV Charging suitable
for public locations

Ideal EV business solution
for employees and visitors

Auto On / Off with charge rate controlled
by the car and current level limited by

MODE 2

the supply circuit

Faster charging than Mode 2 with
dedicated controls and advanced

MODE 3

communication with the vehicle

Up to 7 kW AC [single phase only]

Up to 43 kW AC rapid or 22 kW AC
fast charging [single phase or 3 phase
for faster charging]

Monitoring and charging control
via Smart Device

Added convenience; just park
and plug in with tethered lead

Ingress protection against particles
[1st digit] and liquids [2nd digit]

3 YEARS

WARRANTY*

*ONCE FREE PRODUCT AND INSTALLATION TRAINING HAS BEEN UNDERTAKEN

EVBox is a leading global manufacturer
of electric vehicle charging stations
and charging management software.

With an installed base of over 100,000
charging stations across more than
60 countries worldwide, EVBox drives
sustainable mobility, by bringing durable
electric vehicle charging solutions to the
world. In 2018, EVBox acquired ultra-fast
charging station manufacturer EVTronic,

30

adding 700 previously installed fast
charging stations to its European
network. EVBox offer both residential
and commercial electric vehicle
charging solutions. All products are
OLEV approved and have a minimum
3 year warranty.

Training

EVBox offer free technical and
commercial training at their HQ

Qualies for grant funding when installed
by a professional accredited installer

Qualies for grant funding
when professionally installed
in workplace locations

and on-site, as well as [local] technical
support to all of their installation partners.

Upon successful completion of the
training, companies will be ofcially
certied as an EVBox Installation Partner.
What’s more, their free online training
will enable installers to become an
approved EVBox OLEV installer.

Ask in-store for more information.

cef.co.uk/plugintoev

7.4 kW [32A] EVBox ELVI

32A EVBox BUSINESSLINE

MODE 3

6M

� Ideal residential solution is easy to

use, install, and upgrade with modular
future-proofing features

� Track and invoice charging sessions for

multi-unit dwellings

� UMTS Modem allows for cellular communication
� Autostart with LED charging status indication
� Mounted: Wall or pole [sold separately]
� Dimensions: 328 mm[H] x 186 mm[W] x 161 mm[D]
� OCPP 1.6 Compliant
� IEC 61851-1

Code Description Finish 1+

2629-9582 Wi-Fi, kWh Meter Black £739.95
2629-9585 Wi-Fi, kWh Meter White £739.95
2629-9588 Wi-Fi, kWh Meter & UMTS Black £799.95
2629-9591 Wi-Fi, kWh Meter & UMTS White £799.95

EVBox ELVI

MODE 3

FROM

739£

MODE 3

� Charges 2 cars simultaneously
� Equipped with intelligent software designed to suit workplace needs
� Back-office software facilitates data gathering from a single Hub unit
� Up to 19 Satellite units can be connected to a single Hub unit via data cable
� Autostart with LED charging status indication
� Remote monitoring and invoice charging
� Built-in 6 mA DC RCBO protection
� Mounted: Wall or pole [sold separately]
� Dimensions: 600 mm[H] x 255 mm[W] x 410 mm[D]
� OCPP 1.6 Compliant
� IEC 61851-1

.95

+VAT

� Easy to use, install, and upgrade with modular

future-proofing features

� 4 Adjustable kW ratings dependant on supply

circuit: 3.7, 7.4, 11 and 22 kW

� Track and invoice charging sessions for

multi-unit dwellings

� UMTS Modem allows for cellular communication
� Autostart with LED charging status indication
� Mounted: Wall or pole [sold separately]
� Dimensions: 328 mm[H] x 186 mm[W] x 219 mm[D]
� OCPP 1.6 Compliant
� IEC 61851-1

Code Description Finish 1+

2629-9594 Wi-Fi, kWh Meter Black £739.95
2629-9597 Wi-Fi, kWh Meter White £739.95
2629-9600 Wi-Fi, kWh Meter & UMTS Black £799.95
2629-9603 Wi-Fi, kWh Meter & UMTS White £799.95

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

FROM

739£

.95

+VAT

Code kW Rating Finish 1+

Hub

2630-5114 7.4 kW Grey £1,735.00
2629-9609 7.4 kW White £1,735.00
2630-5120 22 kW Grey £1,975.00
2629-9615 22 kW White £1,975.00

Satellite

2630-5111 7.4 kW Grey £1,695.00
2629-9606 7.4 kW White £1,695.00
2630-5117 22 kW Grey £1,935.00
2629-9612 22 kW White £1,935.00

FROM

1,695£

LOCALLY

.00

+VAT

31

CHARGING LEADS

� Current rating: 32A
� IEC 62196

ELVI FLOOR MOUNTED POLE

� For floor mounting ELVI charging stations
� Height: 1.4 m

Code Output Length

2593-2280 Type 2 to Type 1 4 m
2593-2274 Type 2 to Type 2 4 m

SIGNS

� Highlight location of EV charging spaces
� Clear, recognisable weather durable sign

2593-2286

Code Height Width 1+

2593-2286 600 mm 400 mm £74.95
2593-2289 800 mm 400 mm £109.95

CABLE DOCKING STATION

� Durable polycarbonate material
� Safely holds Type 1 or Type 2 cables
� Dimensions: 190 mm[H] x

120 mm[W] x 90 mm[D]

ONLY

169£

2593-2289

FROM

£

74

2593-2262

.95

+VAT

.95

+VAT

2624-0416

ONLY

.95

£

+VAT319

CHECK OUT OUR
DEDICATED SITE FOR

EVERYTHING EV

cef.co.uk/plugintoev

LATEST EV NEWS

INSTALLER'S HUBBUY PRODUCTS

32

ONLY

£

49

.95

+VAT

ASK OUR EXPERTS

OLEV & REGS

TRAINING

cef.co.uk/plugintoev

BUSINESSLINE FLOOR
MOUNTED POLE

� For floor mounting BusinessLine charging stations
� Height: 1.4 m

BUSINESSLINE WALL
MOUNTED POLE

� For wall mounting BusinessLine charging stations
� Height: 500 mm

BUSINESSLINE ROOT
MOUNTED POLE

� For root mounting BusinessLine charging stations
� Height: 1.9 m

2593-2268

ONLY

139

£

.95

+VAT

2593-2271

ONLY

229

£

.95

+VAT

2593-2265

ONLY

£

139

.95

+VAT

FREE EVBOX APP FOR HOME CHARGING

HEY KEEPS AN EYE

ON YOUR CHARGING SESSIONS

Hey EVBox gives you insights into

charging transactions and charging

behavior, helping you easily manage

the settlement and reimbursement of

charging costs.

HEY GETS YOU ON THE ROAD

Hey EVBox tracks all active charging

sessions and allows you to start and

stop remote charging whenever you

want, making sure everyone hits the

road fully charged.

HEY GIVES YOU FULL CONTROL

OVER YOUR ENERGY USE

Hey EVBox balances the power
consumption and simplies the
management of multiple charging
stations, making sure they can charge
efciently at all times, without affecting
any of your other facilities.

HEY HELPS YOU TO SCALE UP

Hey EVBox allows you to add an unlimited
number of users and charging stations
to your account, thanks to its exceptional
computing power and storage. Your staff,
visitors, and customers will switch onto
electric – Hey EV Box prepares you for
this transition.

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

33

MATT:E

TH

18

EDITION

ST

AMENDMENT COMPLIANT

1

2622-8533

A COMPLIANT
ALTERNATIVE
TO EARTH
ELECTRODES

Why do I need to install earth electrodes?

PME [TN-C-S] is the most common form of
earthing provided at new installations and utilises
a single conductor for the neutral and earthing
functions [PEN] with an earth terminal derived
from the neutral cable.

The danger arises if there is an open PEN
conductor within the network. This can lead
to an electric shock if any metallic parts,
including gas pipework and any bonded appliance
were touched by a person in simultaneous contact
with general mass of earth. Unfortunately,
MCBs and RCDs currently used do not detect
this fault and do not offer any protection.

In accordance with the IET Wiring Regulations
[18th Edition] BS 7671, a PME earthing facility
shall not be used as means of earthing for
the protective conductor contact of a charging
station located outdoors or that might reasonably
be expected to be used to charge a vehicle
located outdoors.

Unless one of the following methods is used

The charge station forms part of a three phase
installation where all of the demand, including
the charge station/s, is balanced over all of the
available phases. The problem of proving that the
three phase supplies have been and will remain
balanced is almost impossible.

The EV charging installation includes an earth
electrode of sufcient resistance to ensure
the rise of earth potential will be limited to a
maximum of 70V during a broken neutral event.
The problem of placing earth electrodes to
obtain the minimum separation distances and to
provide the correct resistance values can be very
difcult to achieve.

Protection against electric shock is provided
by a device which disconnects the charging
station/s from the supply live conductors and the
protective earth within ve seconds in the event
of a broken neutral.

The solution

Matt:e has developed a range of compliant
solutions for both single and three phase
infrastructures which enable the installation
of electric vehicle charging stations without
Earth Electrodes, in line with Regulation

722.411.4.1(iii) and (iv). Utilising the Matt:e
connection centres on your EV installations
saves time and costs during installation but more
importantly offers a safer alternative to
earth electrodes.

Key features

� Standardises installation
� No more scanning for buried services
� Minimises civil works
� Prevents danger posed by driving earth

electrodes into the ground

� Allows charging stations to be mounted

directly onto metalclad structures

� Safer earth connection as connected

directly onto PME supply

� Guarantee that the earth resistances

values are maintained all year round

� Designed and manufactured in Great Britain

34

cef.co.uk/plugintoev

MATT:E

SOLUTIONS

EXISTING MAINS
CONSUMER UNIT

METER

ISOLATOR

ISOLATOR

POWER DISTRIBUTION

BOARD / ENCLOSURE

EV DOMESTIC CONNECTION CENTRE  SINGLE PHASE

� Built-in Matt:e technology
� No earth electrodes required
� Simple wire in, wire out connection
� Designed and built in the UK
� IP2X
� Warranty: 3 Years

NO EARTH

ROD REQUIRED

Fed from the consumer unit with
a suitably sized MCB / RCBO via an isolator.

Connect out of the contactor
to feed the EV charging stations.

2598-3556

Code No. of Ways Current Rating Includes Height Width Depth 1+

2598-3556 1 32 A Wire Out Connection 169 mm 182 mm 111 mm £99.00
2629-8457 1 32 A 30 mA B Type RCD and C Curve MCB [10kA] 169 mm 232 mm 111 mm £259.95

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

FROM

LOCALLY

.00

99£

+VAT

35

Fed from the consumer unit with a suitably sized
MCB / RCBO via an isolator or direct from a
Henley block arrangement
from the mains supply.

Connect out of the RCBO
to feed the EV charging station.

EXISTING MAINS
CONSUMER UNIT

NO EARTH

ROD REQUIRED

CAN BE FED VIA HENLEY

BLOCK

FROM MAINS

HENLEY BLOCK

EV DOMESTIC CONNECTION CENTRE  SINGLE PHASE

� Built-in Matt:e technology
� Isolates charge point from supply if consumption

rises above 60A [2629-8460 only]

� No earth electrodes required
� Designed and built in the UK
� IP2X
� Warranty: 3 Years

2598-3559

Code No. of Ways Current Rating Includes Height Width Depth 1+

2598-3559 1 32 A 30 mA C Curve A Type RCBO [10 kA] 169 mm 182 mm 111 mm £129.95
2629-8460 1 32 A 30 mA C Curve DP A Type RCBO [10 kA] & Current Limiting 169 mm 182 mm 111 mm £149.95

36

FROM

.95

129

£

cef.co.uk/plugintoev

+VAT

POWER DISTRIBUTION

BOARD / ENCLOSURE

ISOLATOR

SUPPLIER FUSES

METER

NO EARTH

ROD REQUIRED

Fed from the distribution board and a suitably sized
MCB. Connect out of the MCB, RCBO, isolator or
terminals to feed the EV charging station

EV CONNECTION CENTRES
SINGLE PHASE OUTPUT  3 PHASE SUPPLY

� Built-in O-PEN technology
� Phase loss protection
� Simple wire in, wire out connection
� No earth electrodes required
� Designed and built in the UK
� IP4X
� Warranty: 3 Years

FROM

2598-3550

449

£

Code No. of Ways Current Rating Includes Height Width Depth 1+

2598-3550 3 32 A C Curve DP MCBs [10kA] 380 mm 300 mm 140 mm £449.95
2598-3547 3 32 A 30 mA C Curve DP A Type RCBO [10 kA] 380 mm 300 mm 140 mm £449.95
2629-8448 3 63 A DP Isolators 380 mm 300 mm 140 mm £495.00
2629-8445 6 32 A 30 mA C Curve DP A Type RCBO [10 kA] 550 mm 360 mm 140 mm £915.00

.95

+VAT

EV CONNECTION CENTRES
3 PHASE OUTPUT  3 PHASE SUPPLY

� Built-in O-PEN technology
� Phase loss protection
� Simple wire in, wire out connection
� No earth electrodes required
� Designed and built in the UK
� IP4X
� Warranty: 3 Years

FROM

2598-3553

£

449

Code No. of Ways Current Rating Includes Height Width Depth 1+

2629-8439 1 32 A 30 mA C Curve 4 Pole A Type RCBO [10 kA] 380 mm 316 mm 140 mm £449.95
2598-3553 1 63 A Wire Out Connection 380 mm 300 mm 140 mm £449.95
2629-8451 1 100 A Wire Out Connection 550 mm 360 mm 120 mm £625.00
2629-8442 3 32 A 30 mA C Curve 4 Pole A Type RCBO [10 kA] 550 mm 360 mm 120 mm £995.00

.95

+VAT

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

37

PROTEUS EV

DISTRIBUTION UNITS

FOR ELECTRIC
VEHICLE CHARGERS

Proteus offer a large range of custom
designed single and three phase
distribution units for EV chargers.

Ensure your customers’ exact
requirements are met with
a completely bespoke solution.

EV charging stations require various
forms of switchgear to distribute power
and to offer short circuit, overcurrent
and earth leakage protection.

DESIGNED TO YOUR
SPECIFICATION

Proteus utilise the latest drawing
software and provide board layout
drawings at both quotation and
construction stages.

38

Proteus can offer EV charging switchgear
solutions for a variety of installations from
charging at home, the workplace, public
access and commercial applications.

Proteus Switchgear offer pre-built solutions
including MCCBs, MCBs, RCDs, RCBOs to suit
various applications. Whether the installation
requires slow, fast or rapid chargers, Proteus can
offer a standard or bespoke solution to supply and
protect your EV charging stations.

BE
INVOLVED

You’re welcome to visit the Proteus
factory to see your board being built
and discuss build requirements.

The Proteus team are happy to
visit your site to establish your
switchgear requirements.

ON-SITE
SURVEY

PROTEUS OFFER A WIDE
RANGE OF STANDARD

AND BESPOKE PRODUCTS

TO PROVIDE POWER AND
PROTECTION FOR A VARIETY
OF EV CHARGERS

TESTING &
COMPLIANCE

All products tested to relevant
British and European Standards.

cef.co.uk/plugintoev

SELECTION CHART

� All boards are 230 / 400V AC tted with a switch

disconnector, RCD or MCB as the

incoming device

� kW ratings - Single phase 230V 3.6 kW - 16A,

7.2 kW - 32A. three phase 400V 11 kW - 16A,

22 kW - 32A

� RCD requirements should be checked with the

charge point manufacturer

� BS 7671 clause 722.531.2.1.1 requires RCDs to

disconnect all live conductors

� RCBOs have Type A ltering and switched

live, unswitched neutral. Check with the charge
point manufacturer that it is tted with an
incoming devices that switches the neutral.

SINGLE PHASE INSTALLATION

No. of SP EV Charger Circuits kW Rating Protection Device RCD Type Code Page

1 7.2 kW MCB / RCD A 2562-2500 27
1 7.2 kW MCB / RCD B 2562-2503 27
3 7.2 kW RCBO A 2595-2152 27
3 7.2 kW MCB / RCD A 2595-2155 27
6 7.2 kW RCBO A 2595-2164 27
6 7.2 kW MCB / RCD A 2595-2167 27

COMBINED SINGLE AND THREE PHASE INSTALLATION

No. of SP EV
Charger Circuits

3 7.2 kW RCBO 1 22 MCB / RCD A 2595-2158 27
3 7.2 kW MCB / RCD 1 22 MCB / RCD A 2595-2161 27
3 7.2 kW RCBO 2 22 MCB / RCD A 2595-2170 28
3 7.2 kW MCB / RCD 2 22 MCB / RCD A 2595-2173 29
6 7.2 kW RCBO 2 22 MCB / RCD A 2595-2176 28
6 7.2 kW MCB / RCD 2 22 MCB / RCD A 2595-2179 29
9 7.2 kW RCBO 3 22 MCB / RCD A 2595-2182 28
9 7.2 kW MCB / RCD 3 22 MCB / RCD A 2595-2185 28

kW Rating Protection Device No. of TP EV Charger Circuits kW Rating Protection Device RCD Type Code Page

THREE PHASE INSTALLATION

No. of TP EV Charger Circuits kW Rating Protection Device RCD Type Code Page

1 11 kW ISO / RCD A 2595-2128 29
1 11 kW ISO / RCD B 2595-2131 29
1 11 kW MCB / RCD A 2595-2134 29
1 11 kW MCB / RCD B 2595-2137 29
1 22 kW ISO / RCD A 2595-2140 29
1 22 kW ISO / RCD B 2595-2143 29
1 22 kW MCB / RCD A 2595-2146 29
1 22 kW MCB / RCD B 2595-2149 29

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

39

SP+N DISTRIBUTION BOARDS 
RCD INCOMER

� Non-combustible metalclad

distribution board

� Multiple knockouts for

cable entry

� IP30

100A TP+N POPULATED DISTRIBUTION
BOARDS  MAINS INCOMER

� Non-combustible metalclad distribution board
� Removable top gland plate
� Devices prewired
� Dimensions: 269 mm[H] x 326 mm[W] x 110 mm[D]
� IP3X
� BS EN 61439-3

INCLUDES:

� 63A 30 mA 2 Pole RCD
� 40A B Curve MCB [6 kA]
� Blanks

Code No. of Ways Height Width Depth 1+

Type A RCD [2 Module]

2562-2500 2 235 mm 115 mm 110 mm £57.95

Type B RCD [4 Module]

2562-2503 4 235 mm 184 mm 110 mm £219.95

FROM

57

£

.95

+VAT

100A TP+N POPULATED DISTRIBUTION
BOARDS  MAINS INCOMER

� Non-combustible metalclad

distribution board

� Removable top gland plate
� Devices prewired
� Dimensions: 528 mm[H] x

326 mm[W] x 110 mm[D]

� IP3X
� BS EN 61439-3

INCLUDES:

� 100A 4 Pole isolator
� 40A 30 mA C Curve SP RCBOs [Type A]
� 40A C Curve SP MCBs [10 kA]
� 40A C Curve TP MCBs [10 kA]
� 40A 30 mA 2 Pole RCDs [Type A]
� 40A 30 mA 4 Pole RCDs [Type A]

Code Single Pole RCBOs Single Pole MCBs 3 Pole MCBs 2 Pole RCDs 4 Pole RCDs 1+

Suitable For 3 x 7.2 kW SP EV Chargers

2595-2155 - 3 x 40A - 3 x 40A - £377.95

Suitable For 3 x 7.2 kW SP and 1 x 22 kW TP EV Chargers

2595-2158 3 x 40A - 1 x 40A - 1 x 40A £461.95

Suitable For 6 x 7.2 kW SP EV Chargers

2595-2167 - 6 x 40A - 6 x 40A - £519.75

Suitable For 3 x 7.2 kW SP and 1 x 22 kW TP EV Chargers

2595-2161 - 3 x 40A 1 x 40A 3 x 40A 1 x 40A £514.50

FROM

377

£

.95

+VAT

INCLUDES:

� 100A 4 Pole isolator
� 40A 30 mA C Curve

SP RCBO [Type A]

Code Single Pole RCBOs 1+

Suitable For 3 x 7.2 kW SP EV Chargers

2595-2152 3 x 40A £230.95

Suitable For 6 x 7.2 kW SP EV Chargers

2595-2164 6 x 40A £ 314.95

FROM

£

230

.95

+VAT

125A TP+N POPULATED
DISTRIBUTION BOARDS 
MAINS INCOMER

� Non-combustible metalclad

distribution board

� Removable top gland plate
� Devices prewired
� Dimensions: 655 mm[H] x

410 mm[W] x 110 mm[D]

� IP3X
� BS EN 61439-3

INCLUDES:

� 125A 4 Pole isolator

� 40A 30 mA C Curve SP RCBOs

[Type A]

� 40A C Curve TP MCBs [10 kA]
� 40A 30 mA 4 Pole RCDs [Type A]

Code Single Pole RCBOs 3 Pole MCBs 4 Pole RCDs 1+

Suitable For 3 x 7.2 kW SP and 2 x 22 kW TP EV Chargers

2595-2170 3 x 40A 2 x 40A 2 x 40A £650.95

Suitable For 6 x 7.2 kW SP and 2 x 22 kW TP EV Chargers

2595-2176 6 x 40A 2 x 40A 2 x 40A £761.25

FROM

£650

.95

+VAT

40

cef.co.uk/plugintoev

200A TP+N POPULATED
DISTRIBUTION BOARD 
MAINS INCOMER

� Non-combustible metalclad

distribution board

� Removable top gland plate
� Devices prewired
� Dimensions: 1,045 mm[H] x

410 mm[W] x 110 mm[D]

� IP3X
� BS EN 61439-3

INCLUDES:

� 200A 4 Pole isolator
� 40A 30 mA C Curve SP RCBOs

[Type A]

� 40A C Curve TP MCBs [10 kA]
� 40A 30 mA 4 Pole RCDs [Type A]

Code Single Pole RCBOs 3 Pole MCBs 4 Pole RCDs 1+

Suitable For 9 x 7.2 kW SP and 3 x 22 kW TP EV Chargers

2595-2182 9 x 40A 3 x 40A 3 x 40A £1,291.50

ONLY

1,291£

.50

+VAT

200A TP+N POPULATED
DISTRIBUTION BOARD 
MAINS INCOMER

� Non-combustible metalclad

distribution board

� Removable top gland plate
� Devices prewired
� Dimensions: 1,380 mm[H] x

410 mm[W] x 110 mm[D]

� IP3X
� BS EN 61439-3

INCLUDES:

� 200A 4 Pole isolator
� 40A C Curve SP MCBs [10 kA]
� 40A C Curve TP MCBs [10 kA]
� 40A 30 mA 2 Pole RCDs [Type A]
� 40A 30 mA 4 Pole RCDs [Type A]

Code Single Pole MCBs 3 Pole MCBs 2 Pole RCDs 4 Pole RCDs 1+

Suitable For 9 x 7.2 kW SP and 3 x 22 kW TP EV Chargers

2595-2185 9 x 40A 3 x 40A 9 x 40A 3 x 40A £1,564.50

ONLY

1,564

£

.50

+VAT

125A TP+N POPULATED
DISTRIBUTION BOARDS 
MAINS INCOMER

� Non-combustible metalclad

distribution board

� Removable top gland plate
� Dimensions: 885 mm[H] x

410 mm[W] x 110 mm[D}

� IP3X
� BS EN 61439-3

INCLUDES:

� 125A 4 Pole isolator
� 40A 30 mA C Curve SP RBCOs

[Type A]

� 40A C Curve TP MCBs [10 kA]
� 40A 30 mA 2 Pole RCDs [Type A]
� 40A 30 mA 4 Pole RCDs [Type A]

Code Single Pole MCBs 3 Pole MCBs 2 Pole RCDs 4 Pole RCDs 1+

Suitable For 3 x 7.2 kW SP and 2 x 22 kW TP EV Chargers

2595-2173 3 x 40A 2 x 40A 3 x 40A 2 x 40A £724.50

Suitable For 6 x 7.2 kW SP and 2 x 22 kW TP EV Chargers

2595-2179 6 x 40A 2 x 40A 6 x 40A 2 x 40A £860.95

FROM

£

724

.50

+VAT

TP+N POPULATED
DISTRIBUTION BOARDS 
MAINS INCOMER

� Non-combustible metalclad

distribution board

� Multiple knockouts for

cable entry

� Devices prewired
� Dimensions: 385 mm[H] x

205 mm[W] x 112 mm[D]

� IP3X
� BS EN 61439-3

INCLUDES:

� 4 Pole isolator
� 30 mA 4 Pole RCD

Code 4 Pole Isolator 4 Pole RCDs RCD Type 1+

Suitable For 11 kW TP EV Charger

2595-2128 25A 25A A £204.75
2595-2131 25A 63A B £346.50

Suitable For 22 kW TP EV Charger

2595-2140 40A 40A A £204.75
2595-2143 40A 63A B £346.50

FROM

£

204

.75

+VAT

390 STORES

NATIONWIDE

TP+N POPULATED
DISTRIBUTION BOARD 
MCB INCOMER

� Non-combustible metalclad

distribution board

� Multiple knockouts for

cable entry

� Devices prewired
� Dimensions: 385 mm[H} x

205 mm[W] x 112 mm[D]

� IP3X
� BS EN 61439-3

INCLUDES:

� C Curve 4 Pole MCB [10 kA]
� 30 mA 4 Pole RCD

Code 4 Pole RCDs RCD Type 4 Pole MCBs 1+

Suitable For 11 kW TP EV Charger

2595-2134 25A A 20A £225.75
2595-2137 63A B 20A £367.50

Suitable For 22 kW TP EV Charger

2595-2146 40A A 40A £225.75
2595-2149 63A B 40A £367.50

FROM

£225

63A 30 mA TYPE B RCDs

� Bi-directional - can be supplied from either end
� Positive contact indication
� Test button
� Short circuit capacity: 10 kA
� Terminal capacity: 35 mm²
� Mounted: DIN Rail
� BS EN 61008

.75

+VAT

Code No. of Modules No. of Poles 1+

2562-6871 4 2 £173.50
2574-4120 4 4 £199.50

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

FROM

173£

.50

+VAT

41

MCGEV

0123kWh

PRODUCTS TO SUPPORT

For more than 30 years, MCG have provided
a wide range of high quality products
designed to satisfy the demands of the
contractor market.

Included in this range are a number of EV charge
point installation accessories ranging from
single phase and three phase distribution boards,
circuit protection to adaptable boxes, metal clad
enclosures, switch fuses, electricity meters and
surface mount isolation.

A TYPICAL INSTALLATION

EARTH BOX

COPPER ROD

In addition, their electrical surge protection
devices feature the latest innovative
technology, and with a two year warranty
on their EV range of installation products
you can be safe in the knowledge that the
products are built to last, to get the job done.

Ask in-store for more information.

MCGEV INSTALLATION
PRODUCTS OFFER QUALITY,

RELIABILITY AND INNOVATION

SO WHY NOT MAKE MCG EV
INSTALLATION PRODUCTS
YOUR FIRST CHOICE,
PRODUCTS YOU CAN TRUST

CONDUIT

ISOLATOR

EXISTING MAINS CONSUMER UNIT

METER

ISOLATOR

POWER DISTRIBUTION

BOARD / ENCLOSURE

42

cef.co.uk/plugintoev

PLASTIC EMPTY ENCLOSURES

� Dimensions: 100 mm[L] x 100 mm[W] x 50 mm[D]
� IP66

PLASTIC EMPTY ENCLOSURE

� Dimensions: 376 mm[L] x 300 mm[W] x 120 mm[D]
� IP66

INCLUDES:

� Screws

Code Colour

2094-6730 Black
1868-7337 Grey

ONLY

£

2

.95

+VAT

PLASTIC DIN RAIL ENCLOSURES

� Manufactured from tough, flame retardant ABS
� Snap closing top hinged tinted front window
� Will fit a range of modular devices
� IP65
� BS EN 60529

FROM

.95

INCLUDES:

� DIN rail

Code No. of Modules Height Width Depth 1+

1868-7415 5 158 mm 118 mm 92 mm £14.95
1868-7418 8 158 mm 200 mm 92 mm £20.95

£

14

+VAT

INCLUDES:

� Screws

Code Description 1+

1868-7364 Enclosure £35.55
1868-7400 Steel Mounting Plate £15.65

METALCLAD DIN RAIL ENCLOSURE

� Non-combustible metalclad enclosure
� Multiple knockouts for cable entry
� Snap closing top hinged lid
� Will fit up to 4 modular devices
� Dimensions: 220 mm[H] x 145 mm[W] x 104 mm[D]
� IP65
� BS EN 61439-3

INCLUDES:

� DIN rail
� Earth and neutral bars

ONLY

35

£

2275-1353

ONLY

24

£

.55

+VAT

.50

+VAT

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

43

METALCLAD DIN RAIL ENCLOSURES

� Non-combustible metalclad enclosure
� Multiple knockouts for cable entry
� Raised keyholes for easy installation
� IP20
� BS EN 61439-3

FROM

INCLUDES:

� DIN rail
� Earth bar

Code No. of Modules Height Width Depth 1+

2191-0537 2 146 mm 82 mm 82 mm £10.95
2191-0534 2 225 mm 82 mm 82 mm £13.25
2606-4979 3 175 mm 113 mm 84 mm £13.25
2606-4976 3 225 mm 115 mm 84 mm £14.75
2191-0543 4 175 mm 113 mm 84 mm £16.25
2191-0540 4 225 mm 115 mm 84 mm £20.50

£

10

.95

+VAT

SP+N MAINS ISOLATOR SWITCH FUSE

� Robust metal body
� Complete with flap lid
� M20 and M25 knockouts top and bottom
� 5 Terminal earth bar
� Current rating: 63 / 80 / 100A
� Dimensions: 225 mm[H] x 115 mm[W] x 65 mm[D]
� IP20
� BS EN 61439-3

INCLUDES:

� 100A 2 Pole isolator
� 63A HRC ME Fuse
� 80A HRC ME Fuse
� 100A HRC ME Fuse

2302-9522

ONLY

£

43

.95

+VAT

METALCLAD CONSUMER UNITS 
MAINS INCOMER

� Non-combustible metalclad consumer units
� Knockouts: M25, M32 and M40
� IP40
� BS EN 61439-3

FROM

INCLUDES:

� 100A 2 Pole isolator

Code No. of Ways Height Width Depth 1+

2073-7342 2 234 mm 125 mm 112 mm £23.50
2073-7348 4 234 mm 160 mm 112 mm £28.50
2073-7366 6 234 mm 197 mm 112 mm £30.50

£23

.50

+VAT

METALCLAD CONSUMER UNITS 
RCD INCOMER

� Non-combustible metalclad consumer units
� Multiple knockouts for cable entry
� Raised keyholes for easy installation
� IP20
� BS EN 61439-3

FROM

INCLUDES:

� 100A 30 mA 2 Pole RCD [Type A]

Code No. of Ways Height Width Depth 1+

2579-4616 2 235 mm 125 mm 110 mm £44.95
2579-4625 8 235 mm 233 mm 110 mm £55.95

£

44

.95

+VAT

44

cef.co.uk/plugintoev

125A TP+N DISTRIBUTION BOARDS  MAINS INCOMER

� Non-combustible metalclad enclosure
� Reversible door and removable gland plates

top and bottom for ease of installation

� Can be converted to single phase using

TPN-1PKIT [1488-7186]

� IP40
� BS EN 61439-3

INCLUDES:

� 125A 4 Pole isolator
� Labelling kit
� Accessory pack

Code No. of Ways Height Width Depth 1+

1993-9285 4 458 mm 405 mm 103 mm £112.25
1993-9288 6 510 mm 405 mm 103 mm £127.50
1993-9291 8 565 mm 405 mm 103 mm £132.50
2072-6833 12 674 mm 405 mm 103 mm £163.25
2234-1229 14 728 mm 405 mm 103 mm £178.50
2234-1232 16 780 mm 405 mm 103 mm £204.95

FROM

112

£

.25

+VAT

METAL BLANKING
PIECES

� Pack of 4

20A ENCLOSED ROTARY
ISOLATORS

� Flame retardant ABS plastic
� Easy access and switch

removal

� Current rating: AC21

[resistive loads]

� Padlockable switch
� Cable entry: 20 mm[Ø]

knockouts

� Mounted: Surface
� Dimensions: 125 mm[H] x

100 mm[W] x 74 mm[D]

� IP65
� BS EN 60947-3

Code No. of Poles 1+

0576-1585 3 £13.75
0576-1588 4 £14.75

2195-5240

ONLY

£

2

FROM

£

13

.95

+VAT

.75

+VAT

100A SINGLE PHASE ELECTRICITY METER

� Designed to accurately measure and display active

energy consumption [kWh] in a compact surface
mounted enclosure

� Large easy to read LCD can be configured to auto

cycle any of the available registers or remain static

� Optical part for configuration or meter reading
� Voltage rating: 230V
� Highly reliable and capable of withstanding high

voltage events and overcurrent without failure

� Resistant to tampering with reverse energy fraud

detection and sealing for life

� MID Certified
� Dimensions: 91 mm[H] x 125 mm[W] x 40 mm[D]
� EN 50470-13

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

2027-1052

ONLY

29

£

.50

+VAT

TRIPLE POLE MCBs

� Fault tripping indicator window
� Mounted: DIN rail
� BS EN 60898-1

Code Current Rating

B Curve 10 kA

2123-6989 32A

Code Current Rating

2123-7025 40A

C Curve 10 kA

2123-6992 32A
2123-7028 40A

LOCALLY

ONLY

12

£

.80

+VAT

45

SINGLE POLE MCBs

� Fault tripping indicator window
� Mounted: DIN rail
� BS EN 60898-1

Code Current Rating 1+

B Curve 6 kA

2123-6968 32A £2.15
2123-7001 40A £2.15

B Curve 10 kA

2123-6965 32A £4.85
2123-6998 40A £4.85

Code Current Rating 1+

C Curve 6 kA

2123-6974 32A £2.15
2123-7007 40A £2.15

C Curve 10 kA

2123-6971 32A £4.85
2123-7004 40A £4.85

FROM

2

£

.15

+VAT

30 mA TYPE A RCDs

� Short circuit capacity: 6 kA
� Test button
� Fault tripping indicator window
� Terminal capacity: 35 mm²
� Mounted: DIN rail
� BS EN 61008

Code No. of Modules No. of Poles Current Rating 1+

2579-4559 2 2 63A £32.95
2579-4574 2 2 80A £32.95
2579-4493 2 2 100A £37.95
2579-4607 4 4 63A £29.95
2579-4613 4 4 80A £33.95
2579-4589 4 4 100A £37.95

FROM

29£

.95

+VAT

SINGLE MODULE COMPACT RCBOs
 TYPE A

� Smaller size allows for easier installation and

more wiring space inside the consumer unit

� Integrates residual and overcurrent protection in

one device

� Sensitivity: 30 mA [10 kA]
� Test 'T' operating test button on the front panel
� Fault tripping indicator window
� Mounted: DIN rail
� Complete with 1 m neutral and earth cables
� BS EN 610009-1

Code Current Rating

B Curve 10 kA – RCD Type A

2579-4601 32A
2579-4604 40A

ONLY

£

28

.75

+VAT

63A 30 mA TYPE B RCDs

� Short circuit capacity: 10 kA
� Test button
� Fault tripping indicator window
� Suitable for smooth DC supply
� Terminal capacity: 35 mm²
� Mounted: DIN rail
� BS EN 61008

Code No. of Modules No. of Poles 1+

2577-8734 4 2 £151.95
2577-8737 4 4 £159.95

FROM

151

£

.95

+VAT

46

cef.co.uk/plugintoev

9.3 kW 3 POLE
CONTACTOR

� Maximum voltage rating: 660V
� Coil fitted as standard
� Coil voltage: 415V AC
� Current rating: 32A [AC-1] / 18A [AC3]
� Auxiliary contact: 1 NO
� Cage type cable terminals
� Mounted: DIN rail or screw panel /

base mounting

� IEC 60947-4-1

0462-8569

ONLY

30

£

.95

+VAT

SINGLE MODULE SURGE
PROTECTION DEVICE

� Suitable for use with most brands of consumer units
� Protects against indirect lightning effects and

transient surges

� Prolongs the life of appliances and sensitive

electronic equipment

� Visual end of life indication
� Recommended backup MCB: 16 - 32A
� Warranty: 10 years
� BS EN 61643-11

ONLY

Code Type Suitable For No. of Poles

2433-7003 2 + 3 TN-S, TN-C-S and TT 2

£

39

.95

+VAT

SURGE PROTECTION
DEVICES

� Suitable for use with most brands of

commercial and industrial boards

� Protects against indirect lightning effects and

transient surges

� Prolongs the life of appliances and sensitive

electronic equipment

� Visual end of life indication and remote

indication on [2433-7000]

� Recommended backup MCB: 32A
� Warranty: 10 Years
� BS EN 61643-11

FROM

.95

£

68

+VAT

Code Type Suitable For No. of Poles No. of Modules 1+

2433-6997 2 + 3 TN-S and TN-C-S 2 2 £68.95
2433-7000 2 + 3 TN-S and TN-C-S 4 4 £89.95

COPPERBOND EARTH ROD 

9.5 MM [3/8"] X 1,200 MM

� Unthreaded
� Molecularly bonded low carbon steel core

with 99.9% pure electrolytic copper up to a

thickness of 0.25 mm

� High tensile strength: At least 600N / mm
� BS 7430 and BS 6651

0007-1707

ONLY

£

2

2

.60

+VAT

EARTH ROD CLAMP  9.5 MM [3/8"]

� Machine brassed earth rod

clamp for use with [0007-1707]

� Standard 'B' type
� BS 7430 and BS 6651

0007-1557

ONLY

.85

£

1

+VAT

EARTH ELECTRODE BOX

� Supplied with a printed warning label on the lid
� Compatible with 20 mm conduit
� BS 4607-5

0432-0079

ONLY

3

£

.75

+VAT

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

47

STEEL WIRE ARMOURED CABLE PVC

� XLPE Insulated steel wire armoured cable with PVC sheath
� Annealed stranded copper conductors
� BS 5467
� Earth cable required for compliant installation [sold seperately] –

please see CEF Online or our CEF Catalogue for further information

CABLE

H6942X 2 CORE

Code Conductor 1+

Cut Length Per Metre

0114-3319 1.5 mm² £0.75
0114-3328 2.5 mm² £1.00
0114-3337 4.0 mm² £1.35
0114-3346 6.0 mm² £1.75
0114-3355 10.0 mm² £2.35
0114-3364 16.0 mm² £3.95
0138-6481 25.0 mm² Visit cef.co.uk for latest prices
0138-6484 35.0 mm² Visit cef.co.uk for latest prices

H6944X 4 CORE

Code Conductor 1+

Cut Length Per Metre

0114-3427 1.5 mm² £1.05
0114-3436 2.5 mm² £1.55
0114-3448 4.0 mm² £2.15
0114-3457 6.0 mm² £3.05
0114-3466 10.0 mm² £4.75
0114-3475 16.0 mm² £6.80
0138-6511 25.0 mm² Visit cef.co.uk for latest prices
0138-6514 35.0 mm² Visit cef.co.uk for latest prices
0138-6517 50.0 mm² Visit cef.co.uk for latest prices
0138-6520 70.0 mm² Visit cef.co.uk for latest prices
0138-6523 95.0 mm² Visit cef.co.uk for latest prices

H6945X 5 CORE

Code Conductor 1+

Cut Length Per Metre

0114-3484 1.5 mm² £1.30
0114-3487 2.5 mm² £1.90
0114-3490 4.0 mm² £2.60
0114-3493 6.0 mm² £3.55
0114-3496 10.0 mm² £5.80
0114-3499 16.0 mm² £8.80

0138-6469 25.0 mm² Visit cef.co.uk for latest prices
0138-6472 35.0 mm² Visit cef.co.uk for latest prices
1252-0654 50.0 mm² Visit cef.co.uk for latest prices
1252-0657 70.0 mm² Visit cef.co.uk for latest prices

H6943X 3 CORE

Code Conductor 1+

Cut Length Per Metre

0114-3373 1.5 mm² £0.85
0114-3382 2.5 mm² £1.15
0114-3391 4.0 mm² £1.75
0114-3400 6.0 mm² £2.25
0114-3409 10.0 mm² £3.45
0114-3418 16.0 mm² £5.40
0138-6493 25.0 mm² Visit cef.co.uk for latest prices
0138-6496 35.0 mm² Visit cef.co.uk for latest prices
0138-6499 50.0 mm² Visit cef.co.uk for latest prices
0138-6502 70.0 mm² Visit cef.co.uk for latest prices

H6947X  H694 / 37X
MULTICORE

Code Conductor No. of Cores 1+

Cut Length Per Metre

0006-2722 1.5 mm² 7 £1.95
0006-2725 2.5 mm² 7 £2.90
0024-6112 4 mm² 7 £4.20
0024-6115 6 mm² 7 £6.90
0106-6486 10 mm² 7 £12.05
0006-2728 1.5 mm² 12 £3.20
0006-2731 2.5 mm² 12 £4.75
0024-6067 1.5 mm² 19 £4.85
0024-6070 2.5 mm² 19 £7.60
0024-6076 1.5 mm² 27 £6.85
0024-6079 2.5 mm² 27 £8.05
0024-6088 1.5 mm² 37 £9.95

48

cef.co.uk/plugintoev

STEEL WIRE ARMOURED CABLE LSOH

� XLPE Insulated steel wire armoured cable with LSOH sheath
� Specified where smoke and fumes from burning PVC creates

a fire safety hazard

� Annealed stranded copper conductors
� BS 6724
� Earth cable required for compliant installation [sold separately] –

please see CEF Online or our CEF Catalogue for further information

H6942X LSOH 2 CORE H6943X LSOH 3 CORE

Code Conductor 1+

Cut Length Per Metre

0114-3502 1.5 mm² £0.95
0114-3505 2.5 mm² £1.25
0114-3508 4.0 mm² £1.60
0114-3511 6.0 mm² £2.10
0114-3514 10.0 mm² £3.05
0114-3517 16.0 mm² £4.65
0138-6550 25.0 mm² Visit cef.co.uk for latest prices
0138-6553 35.0 mm² Visit cef.co.uk for latest prices

Code Conductor 1+

Cut Length Per Metre

0114-3520 1.5 mm² £1.15
0114-3523 2.5 mm² £1.55
0114-3526 4.0 mm² £2.05
0114-3529 6.0 mm² £2.75
0114-3532 10.0 mm² £4.30
0114-3535 16.0 mm² £6.20
0138-6562 25.0 mm² Visit cef.co.uk for latest prices
0138-6565 35.0 mm² Visit cef.co.uk for latest prices
0859-8184 50.0 mm² Visit cef.co.uk for latest prices
0552-4144 70.0 mm² Visit cef.co.uk for latest prices

H6945X LSOH 5 CABLE H6947X LSOH  H694/19X

LSOH MULTICORE

H6944X LSOH 4 CORE

Code Conductor 1+

Cut Length Per Metre

0114-3538 1.5 mm² £1.30
0114-3544 2.5 mm² £1.85
0114-3547 4.0 mm² £2.55
0114-3550 6.0 mm² £3.60
0114-3553 10.0 mm² £5.35
0114-3556 16.0 mm² £7.90
0138-6586 25.0 mm² Visit cef.co.uk for latest prices
0138-6589 35.0 mm² Visit cef.co.uk for latest prices
0138-6592 50.0 mm² Visit cef.co.uk for latest prices
0138-6595 70.0 mm² Visit cef.co.uk for latest prices
0138-6598 95.0 mm² Visit cef.co.uk for latest prices

ARMOURED CABLE 
SPLIT CONCENTRIC

Code Conductor 1+

Cut Length Per Metre

0131-4472 1.5 mm² £1.60
0131-4475 2.5 mm² £2.25
0131-4478 4.0 mm² £3.05
0131-4481 6.0 mm² £4.40
0131-4484 10.0 mm² £6.50
0114-3559 16.0 mm² £9.95
0138-6475 25.0 mm² Visit cef.co.uk for latest prices
0138-6478 35.0 mm² Visit cef.co.uk for latest prices
1252-0660 50.0 mm² Visit cef.co.uk for latest prices
1252-0663 70.0 mm² Visit cef.co.uk for latest prices

390 STORES

NATIONWIDE

Code Conductor No. of Cores 1+

Cut Length Per Metre

0024-6127 1.5 mm² 7 £2.15
0024-6130 2.5 mm² 7 £3.05
0024-6121 1.5 mm² 12 £3.85
0024-6124 2.5 mm² 12 £5.30
0107-3476 1.5 mm² 19 £5.10
0107-3479 2.5 mm² 19 £8.05

Code Conductor 1+

Cut Length Per Metre

0114-3562 4.0 mm² £1.90
0114-3565 6.0 mm² £2.90
0114-3568 10.0 mm² £4.10
0114-3571 16.0 mm² £6.15
0114-3577 25.0 mm² £7.85

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

LOCALLY

49

TEST

EQUIPMENT

The government’s plan to ban the sale of
new petrol and diesel cars by 2030, and
the resulting need for sufcient charging
infrastructure, provides electricians with an
enormous opportunity to generate
new business.

However, the ongoing test and maintenance
of charging stations will be a difcult

EV STATION ADAPTOR EV500UK

� Full range of safety and functional tests achievable

through connection to a multifunction installation tester

� Signal outputs for oscilloscope connection
� Simulates vehicle connection and tests all Mode

3 EV stations

� Supplied with Type 2 connector for testing both

tethered cables and socket outlets

� Check for hazardous touch voltage with PE pre-test
� Proximity pilot simulation selector states: Open circuit,

13A, 20A, 32A and 63A

� Control pilot simulation selector states: A, B, C and D
� Error simulation states: E and PE
� Measuring terminal socket outputs for connection of

installation tester

� Socket output for connection of an external load to

check the correct operation of the power meter

� LED voltage indication
� IP54
� Warranty: 1 Year

INCLUDES:

� Type 2 male plug connector
� Instruction manual
� Soft carry case

challenge for the industry, but those who
get in early, with the right equipment
for testing installations, will achieve
signicant competitive advantage.

The 18th Edition Wiring Regulations specify
that it’s a requirement for protective measures
against DC fault current to be designed into all
EV charge stations.

MULTIFUNCTION TESTER  MFT1741

� Data storage and Bluetooth® communication
� Simple colour coded test selection with large clear display
� Earth electrode testing
� Continuity and resistance test currents: 200 mA and 15 mA
� Insulation test voltages: 100, 250, 500 and 1,000V
� 2 and 3 Wire non-trip loop testing
� PSCC, PFC testing and Max. Zs measurement
� Full range of RCD tests including 3 phase, ramp

and auto tests for Type AC, A, S and B RCDs

� Phase rotation and true RMS measurement
� Warranty: 1 Year [3 Years on registration]

INCLUDES

� 3 Wire lead set with

probes and croc clips

� Switched probe
� Mains plug test lead
� Neck strap

2607-3829

ONLY

£

499

.95

+VAT

� Calibration certificate

*If you require your MFT1741 to be upgraded to the MFT1741+ with the added
function of 6mA DC RCD test this can be arranged with Megger service which
will include a calibration certicate, for further information please contact
your local sales or store representative

When an electric vehicle is being charged, if the
DC fault current is greater than 6 mA, it could
change the characteristics of a Type A RCD due
to its core saturation. This could result in the
Type A failing to trip and lack of detection of
the DC fault leading to increased risk of electric
shock and compromised safety.

� AC Battery charger
� 6 x NiMH

Rechargeable
batteries

� Large soft pouch

with extra storage

2315-1076

ONLY

.00

+VAT

875

£

50

cef.co.uk/plugintoev

EV STATION ADAPTOR  A 1532

� Full range of safety and functional

tests achievable through connection
to a multifunction installation tester
– sold separately [2594-2660]

� Simulates vehicle connection and

tests all Mode 3 EV stations

� Supplied with Type 2 connector for

testing both tethered cables and
socket outlets

� Proximity pilot simulation selector

states: Open circuit, 13A, 20A, 32A
and 63A

� Control pilot simulation selector

states: A, B, C, D and E

� Error simulation states: E
� Measuring terminal socket outputs

for connection of 3 phase

installation tester

� Socket output for connection to

single phase installation tester

� LED voltage indication
� IP40
� Warranty: 1 Year

INCLUDES:

� Type 2 male plug connector
� Instruction manual
� Soft carry case

EV STATION TESTER  CHARGECHECK

� Full range of safety and functional tests achievable

through connection to a multifunction

installation tester

� Simulates vehicle connection and tests all Mode 3

EV stations

� Latching test button
� Supplied with Type 2 connector for testing both

tethered cables and socket outlets

� Fitted with Type 1 socket for testing Type 1

tethered cables

� Socket output for connection to installation tester
� LED Polarity checker
� IP65
� Warranty: 1 Year

2594-2483

ONLY

369

£

.95

+VAT

MULTIFUNCTION TESTER  MI3125BT

� Eurolink application: View test results

on PC, tablet and smartphone

� Test Type B, DC sensitive RCDs – ideal

for EV charger testing

� Insulation resistance, continuity, loop

and line resistance

� Full range of RCD tests with clear

pass / fail through red and green LEDs

on either side of display

� True RMS and frequency [AC / DC]
� On / Off switchable auto start for RCD

and loop test

� Insulation testing at 50 to 1,000V
� Phase sequence indicator
� Earth Resistance
� Warranty: 1 Year

INCLUDES:

� 3 Wire test lead set
� Shucko plug cable
� Croc clips and probes
� USB Cable
� Calibration certificate
� Software
� Instruction manual / CD
� Carry case / strap
� 6 x Batteries: Rechargeable NiMH AA

2594-2660

ONLY

529

£

.95

+VAT

INCLUDES:

� 1 m Type 1 to Type 2 adaptor cable
� Carry bag

390 STORES

NATIONWIDE

EVERYTHING AVAILABLE

YOU NEED TO INSTALL EV IN-STORE & ONLINE

2077-4464

ONLY

375

£

LOCALLY

.00

+VAT

51

YOUR GUIDE TO
EV PRODUCTS
& SOLUTIONS

OLEV
& REGULATIONS

PAGES 811

CHECK OUT OUR
DEDICATED SITE FOR

TRAINING

PAGES 1213

EV CHARGERS

PAGES 1633

SWITCHGEAR &
CIRCUIT PROTECTION

PAGES 3447

CABLE

PAGES 4849

TEST
EQUIPMENT

PAGES 5051

EVERYTHING EV

cef.co.uk/plugintoev

INSTALLER'S HUBBUY PRODUCTS ASK OUR EXPERTSLATEST EV NEWS

OLEV & REGS

TRAINING

Your electric vehicle charging guide

cef.co.uk/plugintoev

All products are subject to availability and are correct at the time of print.

Valid until 5:30pm 30th April 2021
