Cedar Summit WESTBURY F25030 Installation And Operating Instructions Manual

W E S T B U RY – F 2 5 0 3 0

27'

30'- 4"

18'-4"

7'-6"

INSTALLATION AND OPERATING INSTRUCTIONS

To reduce the risk of serious injury or death, you must read and

WARNING

Manufacturer contact informaon provided below.

OBSTACLE FREE SAFETY ZONE -30’ 6” x 27” area requires Protecve Surfacing. See page 3.

MAXIMUM VERTICAL FALL HEIGHT - 6’ 9”

CAPACITY - 10 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.

RESIDENTIAL HOME USE ONLY. Not intended for public areas such as mul-unit residences, schools, churches,
nurseries, day cares or parks.

follow these instrucons. Keep and refer to these instrucons
oen and give them to any future owner of this play set.

FORT

10-14 Hrs

Two person

assembly

Cedar Summit
c/o ©Solowave Design LP
Mount Forest, ON Canada
N0G 2L0

wwwcedarsummitplaycom
support@cedarsummitplaycom

Rev 01/06/20169405030

Customer Service
1-877-817-5682 (toll free)
1-519-323-2258

Table of Contents

Warnings and Safe Play Instructions           pg 2

Protective Surfacing Guidelines               pg 3

Instructions for Proper Maintenance          pg 4

About Our Wood – Limited Warranty         pg 5

Keys to Assembly Success                  pg 6-7

Part ID                                    pg 8-13

Step-By-Step Instructions                pg 14-65

Installation of ID/Warning Plaque          pg 66

Registration                             Last Page

Warnings and Safe Play Instructions

CONTINUOUS ADULT SUPERVISION REQUIRED. Most serious injuries and deaths on playground equipment have occurred

while children were unsupervised! Our products are designed to meet mandatory and voluntary safety standards. Complying
with all warnings and recommendations in these instructions will reduce the risk of serious or fatal injury to children using
this play system. Go over the warnings and safe play instructions regularly with your children and make certain that they
understand and follow them. Remember on-site adult supervision is required for children of all ages.

WARNING

SERIOUS HEAD INJURY HAZARD

Installation over concrete, asphalt, dirt, grass, carpet
and other hard surface creates a risk of serious injury
or death from falls to the ground. Install and maintain
shock absorbing material under and around play-set as
recommended on page 3 of these instructions.

COLLISION HAZARD

Place play-set on level ground at least 6 feet from any
obstruction such as a garage or house, fences, poles,
trees, sidewalks, walls, landscape timbers, rocks,
pavement, planters, garden borders, overhanging
branches, laundry lines, and electrical wires. (See
OBSTACLE FREE SAFETY ZONE on cover)

CHOKING HAZARD/SHARP EDGES & POINTS

Adult assembly required. This product contains small
parts and parts with sharp edges and points. Keep parts
away from children until fully assembled.

WARNING LABEL

Owners shall be responsible for maintaining the legibility
of the warning labels.

STRANGULATION HAZARD

• NEVER allow children to play with ropes, clotheslines,

pet leashes, cables, chains or cord-like items when using
this play-set or to attach these items to play-set.

• NEVER allow children to wear loose tting clothing,

ponchos, hoods, scarves, capes, necklaces, items with
draw-strings, cords or ties when using this play-set.

• NEVER allow children to wear bike or sport helmets

when using this play-set.

Failure to prohibit these items, even helmets with chin
straps, increases the risk of serious injury and death to
children from entanglement and strangulation.

TIP OVER HAZARD

Choose a level location for the equipment. This can reduce
the likelihood of the play set tipping over and loose-fill
surfacing materials washing away during heavy rains.

DO NOT allow children to play on the play-set until the
assembly is complete and the unit is properly anchored.

WARNING – Safe Play Instructions

Observe capacity limitations of your play-set. See

front cover.

Dress children with well fitting and full foot enclosing

footwear.

Teach children to sit with their full weight in the center

of the swing seat to prevent erratic swing motion or
falling off.

Check for splintered, broken or cracked wood; missing,

loose, or sharp edged hardware. Replace, tighten and or
sand smooth as required prior to playing.

Verify that suspended climbing ropes, rope ladders, chain

or cable are secured at both ends and cannot be looped
back on itself as to create an entanglement hazard.

On sunny and or hot days, check the slide and other

plastic rides to assure that they are not very hot as to
cause burns. Cool hot slide and rides with water and wipe
dry prior to using.

Do not allow children to wear open toe or heel footwear

like sandals, flip–flops or clogs.

Do not allow children to walk, in front, between, behind

or close to moving rides.

Do not let children twist swing chains or ropes or loop

them over the top support bar. This may reduce the
strength of the chain or rope and cause premature failure.

Do not let children get off rides while they are in motion.

Do not permit climbing on equipment when it is wet.

Do not permit rough play or use of equipment in a

manner for which it was not intended. Standing on or
jumping from the roof, elevated platforms, swings,
climbers, ladders or slide can be dangerous.

Do not allow children to swing empty rides or seats.

Do not allow children to go down slide head first or

run up slide.

2 [e-mail]

Protective Surfacing - Reducing Risk of Serious Head Injury From Falls

One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing
protective surfacing under and around your play equipment. The protective surfacing should be applied to a depth that is suitable
for the equipment height in accordance with ASTM F1292. There are different types of surfacing to choose from; whichever
product you select, follow these guidelines:

Loose-Fill Materials

• Maintain a minimum depth of 9 inches of loose-fill materials such as wood mulch/chips, engineered wood fiber (EWF), or
shredded/recycled rubber mulch for equipment up to 8 feet high; and 9 inches of sand or pea gravel for equipment up to 5 feet
high. NOTE: An initial fill level of 12 inches will compress to about a 9-inch depth of surfacing over time. The surfacing will also

compact, displace, and settle, and should be periodically raked and refilled to maintain at least a 9-inch depth.

• Use a minimum of 6 inches of protective surfacing for play equipment less than 4 feet in height. If maintained properly, this
should be adequate. (At depths less than 6 inches, the protective material is too easily displaced or compacted.)

NOTE: Do not install home playground equipment over concrete, asphalt, or any other hard surface. A fall onto a hard surface

can result in serious injury to the equipment user. Grass and dirt are not considered protective surfacing because wear and
environmental factors can reduce their shock absorbing effectiveness. Carpeting and thin mats are not adequate protective
surfacing. Ground level equipment -- such as a sandbox, activity wall, playhouse or other equipment that has no elevated play
surface -- does not need any protective surfacing.

• Use containment, such as digging out around the perimeter and/or lining the perimeter with landscape edging. Don’t forget to

account for water drainage.

• Periodically rake, check and maintain the depth of the loose-fill surfacing material. Marking the correct depth on the play

equipment support posts will help you to see when the material has settled and needs to be raked and or replenished. Be sure to
rake and evenly redistribute the surfacing in heavily used areas.

• Do not install loose fill surfacing over hard surfaces such as concrete or asphalt.

Poured-In-Place Surfaces or Pre-Manufactured Rubber Tiles

You may be interested in using surfacing other than loose-fill materials - like r ubber tiles or poured-in-place surfaces.

• Installations of these surfaces generally require a professional and are not “do-it yourself ” projects.

• Review surface specifications before purchasing this type of surfacing. Ask the installer/manufacturer for a report showing that

the product has been tested to the following safety standard: ASTM F1292 Standard Specification for Impact Attenuation of Surfacing
Materials within the Use Zone of Playground Equipment. This report should show the specific height for which the surface is intended

to protect against serious head injury. This height should be equal to or greater than the fall height - vertical distance between a

designated play surface (elevated surface for standing, sitting, or climbing) and the protective surfacing below - of your play equipment.

• Check the protective surfacing frequently for wear.

Placement

Proper placement and maintenance of protective surfacing is essential. Refer to diagram on front cover. Be sure to;

• Extend surfacing at least 6 feet from the equipment in all directions.

• For to-fro swings, extend protective surfacing in front of and behind the swing to a distance equal to twice the height of the top

bar from which the swing is suspended.

• For tire swings, extend surfacing in a circle whose radius is equal to the height of the suspending chain or rope, plus 6 feet in all directions.

6 ft. 6 ft.

Denotes Use Zone with Protective Surfacing

6 ft

6 ft.

.

6 ft.

6 ft.

6 ft.

Denotes Use Zone with Protective Surfacing

Use Zone for Multi-Axis SwingsUse Zone for Single-Axis Swings

From the CPSC Outdoor Home Playground Safety Handbook. At http://www.playgroundregs.com/resources/CPSC%20324.pdf

3 [e-mail]

Instructions for Proper Maintenance

Your Cedar Summit Play System is designed and constructed of quality materials with your child’s safety in mind. As

with all outdoor products used by children, it will weather and wear. To maximize the enjoyment, safety and life of your

Play Set, it is important that you, the owner, properly maintain it.

Check the following at the beginning of the play season:

HARDWARE:

Check metal parts for rust. If found,

sand and repaint using a non-lead paint

complying with 16 CFR 1303.
Inspect and tighten all hardware. On
wood assemblies DO NOT OVER­TIGHTEN as to cause crushing and

splintering of wood.
Check for sharp edges or protruding screw threads, add
washers if required.

If Bolt protrudes

beyond T-Nut

Use an extra

flat washer

SHOCK ABSORBING SURFACING:

Check for foreign objects. Rake and check depth of loose

fill protective surfacing materials to prevent compaction and

maintain appropriate depth. Replace as necessary.
(See Protective Surfacing, page 3)

GROUND STAKES (ANCHORS):

Check for looseness, damage or deterioration. Should firmly

anchor unit to ground during use. Re-secure and or replace,

if necessary.

SWING HANGERS:

Check that bolts are secure and tight. Quick clips should be

completely closed and threaded clips screwed tight.

If squeaking occurs lubricate bushings with oil or WD-40®.

SWINGS, ROPES AND RIDES:

Reinstall if removed during cold season. Check all moving

parts including swing seats, ropes, chains and attachments

for wear, rust and other deterioration. Replace as needed.

Check that ropes are tight, secure at both ends and cannot

loop back as to create an entrapment.

WOOD PARTS:

Check all wood members for deterioration, structural

damage and splintering. Sand down splinters and replace
deteriorated wood members. As with all wood, some
checking and small cracks in grain is normal.

Applying a water repellent or stain (water-based) on a yearly

basis is important maintenance to maintain maximum life
and performance of the product.

Check twice a month during play season:

HARDWARE:

Inspect for tightness. Must be firmly against, but not

crushing the wood. DO NOT OVER-TIGHTEN.

This will cause splintering of wood.

Check for sharp edges or protruding screw threads.

Add washers if required.

SHOCK ABSORBING SURFACING:

Rake and check depth of loose fill protective surfacing

materials to prevent compaction and maintain appropriate

depth. Replace as necessary.
(See Protective Surfacing, page 3)

Check once a month during play season:

SWING HANGERS:

Check that they are secure and orientated correctly. Hook

should rotate freely and perpendicular to support beam.

If squeaking occurs lubricate bushings with oil or WD-40®.

SWINGS AND RIDES:

Check swing seats, all ropes, chains and attachments for

fraying, wear, excessive corrosion or damage.

Replace if structurally damaged or deteriorated.

Check at the end of the play season:

SWINGS AND RIDES:

To prolong their life, remove swings and store inside when

outside temperature is below 32°F/0°C. Below freezing,

plastic parts may become more brittle.

If you dispose of your play set: Please disassemble and dispose of your unit so that it does not create any unreasonable

hazards at the time it is discarded. Be sure to follow your local waste ordinances.

SHOCK ABSORBING SURFACING:

Rake and check depth of loose fill protective surfacing

materials to prevent compaction and maintain appropriate

depth. Replace as necessary.

(See Protective Surfacing, page 3)

4 [e-mail]

About Our Wood

Cedar Summit Premium Play Systems uses only premium playset lumber, ensuring the safest product for your children’s

use. Although we take great care in selecting the best quality lumber available, wood is still a product of nature and susceptible to

weathering which can change the appearance of your set.

What causes weathering? Does it affect the strength of my Play System?

One of the main reasons for weathering is the effects of water (moisture); the moisture content of the wood at the surface is

different than the interior of the wood. As the climate changes, moisture moves in or out of the wood, causing tension which can
result in checking and or warping. You can expect the following due to weathering. These changes will not affect the strength of
the product:

1. Checking is surface cracks in the wood along the grain. A post (4” x 4”) will experience more checking than a board (1” x 4”)

because the surface and interior moisture content will var y more widely than in thinner wood.

2. Warping results from any distortion (twisting, cupping) from the original plane of the board and often happens from rapid

wetting and drying of the wood.

3. Fading happens as a natural change in the wood color as it is exposed to sun-light and will turn a grey over time.

How can I reduce the amount of weathering to my Play System?

At the factory we have coated the wood with a water repellent or stain. This coating decreases the amount of water absorption
during rain or snow thus decreasing the tension in the wood. Sunlight will break down the coating, applying a water repellant or

stain on a yearly basis is important maintenance. (see your local stain and paint supplier for a recommended product)

Most weathering is just the normal result of nature and will not affect safe play and enjoyment for your child. However if you are
concerned that a part has experienced a severe weathering problem please call our consumer relations department for further assistance.

Complete and mail registration card to receive important product notications and assure prompt

warranty service.

5 Year Limited Warranty

Solowave Design warrants that this product is free from defect in materials and workmanship for a
period of one year from the original date of purchase. In addition, lumber is warranted for 5 years
against structural failure due to rot and insect damage. All other parts, such as hardware, swings, rides,
accessories, and slides carry a one-year warranty only.
This warranty applies to the original owner and registrant and is non-transferable.
Regular maintenance is required to assure the integrity of your Play System. Failure by the owner
to maintain the product according to the maintenance requirements may void this warranty. This
warranty does not cover any inspection cost.

This Limited Warranty does not cover:

• Labor for replacement of any defective item(s);

• Incidental or consequential damages;

• Cosmetic defects which do not affect performance or integrity;

• Vandalism; improper use or installation; acts of nature;

• Minor twisting, warping, checking, or any other natural occurring properties of wood that do not

affect performance or integrity.

Solowave Design products have been designed for safety and quality. Any modications made to

the original product could damage the structural integrity of the unit leading to failure and possible

injury. Solowave Design Inc. cannot assume any responsibility for modied products. Furthermore,
modication voids any and all warranties.

This product is warranted for RESIDENTIAL USE ONLY. Under no circumstance should a
Solowave Design Play System be used in public settings such as schools, churches, playgrounds,
parks, day cares and the like. Such use may lead to product failure and potential injury. Any and all
public use will void this warranty.
Solowave Design disclaims all other representations and warranties of any kind, express or implied.

This Warranty gives you specic legal rights. You may have other rights as well which vary from state to state or

province to province. This warranty excludes all consequential damages, however, some states do not allow the
limitation or exclusion of consequential damages, and therefore this limitation may not apply to you.

5 [e-mail]

Tools Required

Keys to Assembly Success

• Tape Measure

• Carpenters Level

• Carpenters Square

• Claw Hammer

• Standard or Cordless Drill

Part Identification Key

On each page, you will find the parts
and quantities required to complete the
assembly step illustrated on that page.
Here is a sample.

• #1, #3 Phillips or Robertson

bit or Screwdriver

• Ratchet(1/2”, 7/16” &

9/16” sockets)

• Open End Wrench
(1/2”, 7/16” & 9/16”)

• Adjustable Wrench

• 1/8” & 3/16” Drill Bits

2X 012 Post 2 x 4 x 83”

Quantity Key Number

Part Description,
Part Size

• 3/16” Hex Key

• 8’ Step Ladder

• Safety Glasses

• Adult Helpers

• Pencil

Key Number: The first two digits
represent the step number. The third
digit represents the piece. Note that if
the part is used in multiple steps then
the number only reflects the first step it
is used in.

Symbols

Throughout these instructions symbols are provided as important reminders for proper and safe assembly.

This identifies information that requires special
attention. Improper assembly could lead to an unsafe
or dangerous condition.

Use

Help

Measure
Distance

Use

Help

Check that assembly is square
before tightening bolts.

Use a measuring tape to assure
proper location.

Where this is shown, 2 or 3 people
are required to safely complete the
step. To avoid injury or damage
to the assembly make sure to get
help!

Square

Assembly

Check that set or assembly is properly level
before proceeding.

Pre-drill 1/8” & 3/16” Bit

Pre-drill a pilot hole
before fastening screw
or lag to prevent
splitting of wood.

This indicates time to tighten bolts, but
not too tight! Do not crush the wood.
This may create splinters and cause
structural damage.

Use

Level

Tighten

Bolts

CAUTION – Protrusion Hazard

Once the assembly is tightened, watch for exposed threads.
If a thread protrudes from the T-Nut, remove
the bolt and add washers to eliminate this condition.
Extra washers have been provided for this purpose.

Proper Hardware Assembly

Lag screws require drilling pilot
holes to avoid splitting wood. Only
a flat washer is required. For ease of
installation liquid soap can be used
on all lag-type screws.

For bolts, tap T-Nut into hole with
hammer. Insert the hex bolt through
lock washer first then flat washer then
hole. Because the assemblies need to
be squared do not completely tighten
until instructed. Pay close attention to
diameter of the bolts. 5/16” is slightly
larger than 1/4”.

Note: Wafer head bolts with blue lock
tight or a bolt with a Ny-Lok nut do
NOT require a lock washer.

Lag Screw

Hex Bolt

Lock
Washer

Flat
Washer

No Yes

If Bolt protrudes
beyond T-Nut

Use an extra
flat washer

Lag Assembly

Before mounting Lag
Screw, use factory drilled
holes as guides to drill 1/8”
pilot holes

Flat Washer

Bolt Assembly

T-Nut
(Hammer into place)
Do not crush wood!

6 [e-mail]

Your Key To Quick Assembly

SORTING WOOD PARTS INTO

EACH ASSEMBLY STEP WILL

SAVE TIME!

Step Step Step

SAVE TIME - TIP #1:
Open each box with wood parts and look for the Key Number

stamped on the end of the wood part (see chart below). Sort
each wood part into the different assembly steps.

2X 0124 Post 2 x 4 x 83”

Part Quantity Key Number Part Description Part Size

SAVE TIME - TIP #2:
In addition to the key number stamp, you can also identify
the wood parts by using the Parts Identication pages in the

manual or the Parts Identication weather resistant poster.

HARDWARE:
The majority of each hardware part comes packed in a separate
bag so you do not need to sort the hardware. Each assembly step

indicates which hardware (bolt, screw, washer etc.) you will require
to complete the step.

7 [e-mail]

Part Identification (Next Generation E)

1pc. -2648 -

8pc.

2609

-

1 x 4 x 40-5/8 - Floor Board

- 1 x 5 x 40-5/8" - Floor Board

3632648

3632609

1pc. -2757

LT Post Assembly

1-1/4 x 2-1/2 x 87"

37632757

2pc. -2780 -

3pc. -2781 -

2pc. -2778 -

1pc. -2616 -

2pc. -2777 -

2pc. -2607 -

2pc. -2776 -

1pc. -2608 -

3pc. -2770 -

1 x 6 x 19" RK Board A

3632780

1 x 6 x 19" RK Board B

5/4 x 4 x 14¼"

SW Ground MOD

5/4 x 4 x 46-1/2" SW Support

2 x 2 x 40-1/4" Side Joist MOD

1-1/4 x 3 x 22" Diagonal

1-1/4 x 2-1/2 x 51" Rock Rail

1-1/4 x 3 x 40-3/4" - Floor Joist

1-1/4 x 2-1/2 x 87" End Post Left

3632781

3632778

3632616

3632777

3632607

3632776

3632608

3632770

2pc. -2779 -

1 x 6 x 19" Access Board

3632779

1pc.

2758

-

RT Post Assembly
1-1/4 x 2-1/2 x 87"

37632758

3pc. -2771 -

2pc. -2772 -

5pc. -2769 -

2pc. -2774 -

1pc. -2630 -

2613 -

2pc.

-

1pc. -2615

1-1/4 x 2-1/2 x 87" End Post

1-1/4 x 3 x 42" Panel Floor Support

1-1/4 x 3 x 42" Panel BT Frame

1-1/4 x 3 x 42" Upright

1-1/4 x 5-1/2 x 42" SW Top

2 x 3 x 86-11/16" Heavy SW Post

- 4 x 4 x 50-15/16" SW Upright

3632771

3632774

39632630

3632615

3632772

3632769

3632613

2pc. - 2775 -

2pc. -2768 -

1-1/4 x 3 x 42" Panel Cross Support

1-1/4 x 3 x 42" Panel Floor

3632768

3632775

2614 -

1pc.

-

8 [e-mail]

4 x 6 x 88" Engineered Beam

3632614

Add On "G" Part Identification (Quantities per box) (2 Boxes)

4pc. -2759

4pc. -2760 -

2pc. -2761 -

2pc. -9080

2pc. -8305

1pc. -8069

Roof End 1-1/4 x 3 x 10" -

Roof Support 1¼ x 2¼ x 37½" -

Roof Sleeper C ¾ x 2 x 35" -

MOD Sunburst A 1 x 4 x 11-1/2"

3639080

Starburst Centre 5/4 x 6 x 12" -

Dormer Cleat 2 x 4 x 10" -

3632759

3632761

3632760

3638305

3638069

2pc. -9082

1pc. -8073

2pc. -8070

1pc. -8071

1pc.

-

4pc. -9081

2pc. -8072

MOD Sunburst Bottom 1 x 4 x 30" -

Dormer Bottom 1 x 2 x 22" -

Dormer Side 1 x 3 x 13-5/8" -

Dormer Centre 1 x 3 x 10-3/4" -

8074

Dormer Burst 1 x 4 x 5-1/2" -

MOD Sunburst B 1 x 4 x 7-1/4" -

Dormer Side Burst 1 x 3 x 6-3/4" -

3639082

3638073

3638070

3638071

3638074

3639081

3638072

1pc.

2752 -

-

2pc. -2751 -

S30

14pc.

S20

35pc.

MOD Roof Front 1¼ x 20-7/16 x 44"

37632752

MOD Roof Bottom 1-3/16 x 16-13/16 x 44"

37632751

- Wood Screw

(52043517)

- Wood Screw

#8 x 1-1/16"

#8 x 1-3/8"

- (52043516)

1pc.

1pc. -2753

D4

- 2x2 Robertson Driver Bit

10pc.

- MOD Roof Back 1-1/4 x 20-3/16 x 44"

1pc.

(9200014)

S0

- Truss Screw

4pc.

37632753

8068 - Dormer Roof Set

-

(Right/Left Dormer)

3638068

#8 x 7/8"

(52933505)

LW1

- 1/4" Lock Washer

(51303200)

2x

- Narrow Angle Bracket
Set (2 Pk)

(3200632)

S11

30pc.

8pc.

2pc.

9 [e-mail]

- Wood Screw

S3

- Wood Screw

S4

- Wood Screw

#8 x 2"

(52043520)

#8 x 2-1/2" (52043522)

#8 x 3" (52043530)

TN1

4pc.

(54503200)

- 1/4" T-Nut

H3

4pc.

4pc.

FW1

- Hex Bolt 1/4 x 2-1/2" - (53703222)

- 1/4" Flat Washer

(51103200)

Add on "J" Part Identification

1pc. -2804

1pc.

1pc. -2612 -

Table Support

2pc. -2756

Siding Assembly

1pc. - 2665

Half Wall Insert

- 5/4 x 3 x 39" Wall Top

2611 -

­Table Top

5/4 x 5 x 39-5/8"

3632611

2 x 2 x 39-5/8"

3632612

- 1-1/4 x 19-15/16 x 39-3/16"

37632756

- 1.4 x 20-1/4 x 38.8"

37632665

3632804

1pc. -2715 -

Door Stop

1pc. -2717 - 3/4 x 1-3/4 x 9-3/4"

Clock Block

3pc. - 649A

1.27 x 18.8 x 20-15/16"

Short Half Wall

37632649A

MOD 3 Pane Transom

(2Pk) 3320138

5/4 x 3 x 10"

3632715

3632717

1pc.

1pc. -2602

2pc. -2601

Lower Jamb

2655

2pc.

1.27 x 18.8 x 35.86"

Upper Window Insert

-

37632655

- 1-1/4 x 3 x 35-15/16"

Upper Jamb

- 1-1/4 x 3 x 41-15/16"

3632602

3632601

1pc.

1-1/4 x 15-3/4 x 40-3/4"

Door Window Panel

37602709B

-

2709

2x

- Acro Handle

(9320131)

2x

- Quick Link

(Threaded)(4pk)

(3200020)

1x

- Welded Chain Bag
(3200170)

54" x 4

3pc. -

MOD Arch

(9333603)

1x - Steel Acro Bar

(9200131)

1pc. - Corner Bracket

Set (2 Pk)

(3206571)

1pc.

- Cedar Summit
ID Plaque
(9320357)

1x

- L Beam Brkt.

(3200145) (2pk)

1pc. -

Flower Box

(9320401)

1pc. - Gable Clock Assembly

1x

(3320164)

- Swing Hanger (6 Pk)
(3206106)

3x

- Jamb Mount (2 Pk)
(3206301)

1x

- Rebar Ground
Stake (6 Pk)

(3200318)

2x

- Swing Belt Seat
(9320130)

1x

- Hand Grip

Yellow (9320240)

1pc. -

Cedar Summit Plaque

(9320358)

1x

- Rocks (5pk)
(3320386)

25" x 2

1x

1pc.

- Door Hardware

3201710

10 [e-mail]

- Beam Brkt. Set

(3200143) (2pk)

Add on "J" Hardware (Actual Size)

FW0

5pc.

LW2

38pc. LW1

- 5/16" Lock Washer -

(51303300)

- 1/4" Lock Washer -

(51303200)

LN2

23pc.

5/16" Lock Nut

(54303300)

5pc.

40pc.

60pc.

- 3/16" Flat Washer -

(51103100)

FW1

- 1/4" Flat Washer -

(51103200)

FW2

- 5/16" Flat Washer -

(51103300)

32pc.

10pc.

5pc. BN1

TN1

- 1/4" T - Nut

(54503200)

TN2

- 5/16" T- Nut

(54503300)

- 1/4" Barrel Nut

(54803200)

1pc.

32pc.

8pc.

18pc.

S5

- Pan Screw

S13

S10

- Pan Screw

S7

- Pan Screw

(52433502)

- Pan Screw

(52433510)

#8 x 1/2"

#6 x 5/8"

- (52413908)

#8 x 1"

#12 x 2" - (52433620)

8pc.

12pc.

S0

S18

S30

S20

S11

100pc.

65pc.

78pc.

10pc. S3

- Truss Screw

- Wood Screw

- Wood Screw

- Wood Screw

- Wood Screw

- Wood Screw

#8 x 7/8"

- (52933505)

#6 x 1" - (52013910)

#8 x 1-1/16" - (52043517)

#8 x 1-3/8" - (52043516)

#8 x 2" - (52043520)

#8 x 2-1/2" - (52043522)

4pc. S4

D4

1pc.

2 x 2 Robertson Driver Bit

11 [e-mail]

(9200014)

- Wood Screw

#8 x 3"

- (52043530)

Add on "J" Hardware (Actual Size)

2pc.

WL3

- Wafer Lag

(52613216)

2pc. LS3

2pc.

(53613310)

3pc.

- Lag Screw

WB1

- Wafer Bolt w/ Nylok

WB7

- Wafer Bolt w/ Nylok

1/4 x 1-3/8"

1/4 x 3" - (52213230)

5/16 x 1"

5/16 x 3" (53613330)

16pc. WL5

(52613222)

5pc.

(53433212)

- Wafer Lag

PB2

- Pan Bolt

1/4 x 2-1/2"

1/4 x 1-1/4"

24pc.

4pc.

4pc. G8

3pc.

H9

H11

G4

- Hex Bolt

- Hex Bolt

- Hex Bolt 5

- Hex Bolt 5

1/4 x 1-1/4" (53703211)

1/4 x 2-3/4"

(53703223)

/16 x 2" (53703320)

/16 x 4" (53703340)

7pc. G21

H10

4pc.

- Hex Bolt 5

- Hex Bolt

1/4 x 2-1/4"

/16 x 3-3/4" (53703333)

(53703221)

14pc.

G7

- Hex Bolt 5

12 [e-mail]

/16 x 5-1/2"

(53703352)

Part Identification (48" Slide)

2pc.

- 48" High Rail Slide (Green)
(3310148)

13 [e-mail]

First Step: Inventory Parts - Read This Before Starting Assembly

STOP STOPSTOP STOP

This is the time for you to inventory all your hardware, wood and accessories,

A.

referencing the parts identication sheets. This will assist you with your assembly.

• The wood pieces will have the four digit key number stamped on the ends of the
boards. The wood pieces are referenced throughout the instructions with this number.

• Please refer to Page 6 for proper hardware assembly.

• Each step indicates which bolts and/or screws you will need for assembly, as well as
any at washers, lock washers, t-nuts or lock nuts.

B. If there are any missing or damaged pieces or you need assistance with

assembly please contact the Consumer Relations Department directly. Call us
before going back to the store.

1-877-817-5682

[e-mail]

C. Read the assembly manual completely, paying special attention to ANSI warnings;

notes; and safety/maintenance information on pages 1 - 6.

D. Before you discard your cartons ll out the form below.

• The carton I.D. stamp is located on the end of each carton. The tracking number is
located on the Cedar Summit ID Plaque (9320357).

• Please retain this information for future reference. You will need this information if you
contact the Consumer Relations Department.

MODEL NUMBER: F25030

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 1)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 4)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 2)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 3)

TRACKING NUMBER (from ID Plaque):

14 [e-mail]

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 5)

CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 6)

Step 1: Front Back Wall Prep
Part 1

It is important to assemble the frame on a at, smooth surface.

A: Place (2771) End Post and (2770) End Post Left side by side with the grooves facing up and in. Put (2770)
End Post Left on the right hand side. Place (2775) Panel Cross Support in the top grooves, (2772) Panel Floor
Support in the middle grooves and (2769) Panel BT Frame in the bottom grooves. (g. 1.1)

B: Make sure assembly is square then attach with 4 (S30) #8 x 1-1/16” Wood Screws per board. (g. 1.1)

C: Tap 3 (TN1) 1/4” T-nuts in (2775) Panel Cross Support and (2772) Panel Floor Support and 2 in (2769) Panel

BT Frame. (g. 1.1 and 1.2)

Fig. 1.1

S30

x 4 per
board

2775

S30

x 4

2770

Top

TN1

Fig. 1.2

x 3

TN1

Flush

TN1

x 3

2771

2772

Flush

2769

TN1

Bottom

x 2

Wood Parts

2771

2 x End Post 1-1/4 x 2-1/2 x 87”

2770

2 x End Post Left 1-1/4 x 2-1/2 x 87”
2 x Panel Cross Support 1-1/4 x 3 x 42”

2775

2772

2 x Panel Floor Support 1-1/4 x 3 x 42”
2 x Panel BT Frame 1-1/4 x 3 x 42”

2769

Hardware

S30

24 x #8 x 1-1/16” Wood Screw

TN1

16 x 1/4” T-nut

15 [e-mail]

Step 1: Front Back Wall Prep
Part 2

It is important to assemble the frame on a at, smooth surface.

D: Turn the assembly over, place (2774) Upright in the middle grooves of (2775) Panel Cross Support and
(2772) Panel Floor Support then attach all boards with 8 (H9) 1/4 x 1-1/4” Hex Bolts (with lock washer and at
washer) connecting to the previously installed t-nuts. (g. 1.3 and 1.4)

E: Repeat steps A-D to make 1 more Front Back Wall Assembly.

Fig. 1.3

H9

x 3

2775

2771

H9

x 3

H9

x 2

2770

2774

Fig. 1.4

LW1

2772

Flush

H9

FW1

Wood Parts Hardware

2774

2 x Upright 1-1/4 x 3 x 42”

16 [e-mail]

16 x 1/4 x 1-1/4” Hex Bolt

H9

(1/4” lock washer & 1/4” at washer)

Step 2: Side Wall Prep
Part 1

It is important to assemble the frame on a at, smooth surface.

A: Place (2771) End Post and (2770) End Post Left side by side with the grooves facing up and in. (2770) End
Post Left on the right hand side. Place (2769) Panel BT Frames in the top and bottom grooves and (2768) Panel
Floor in the middle grooves. (g. 2.1)

B: Make sure assembly is square then attach with 4 (S30) #8 x 1-1/16” Wood Screws per board. (g. 2.1)

C: Tap in 2 (TN1) 1/4” T-nuts in (2768) Panel Floor and each (2769) Panel BT Frame. (g. 2.1 and 2.2)

Fig. 2.1

Flush

Top

TN1

2771

x 2

2769

TN1

S30

Flush

x 4

2768

TN1

S30

x 4

Flush

2770

S30

x 4

2769

TN1

Bottom

TN1

Fig. 2.2

TN1

Wood Parts

2768

1 x Panel Floor 1-1/4 x 3 x 42”

2769

2 x Panel BT Frame 1-1/4 x 3 x 42”

2771

1 x End Post 1-1/4 x 2-1/2 x 87”

2770

1 x End Post Left 1-1/4 x 2-1/2 x 87”

17 [e-mail]

Hardware

S30

12 x #8 x 1-1/16” Wood Screw

6 x 1/4” T-nut

TN1

Step 2: Side Wall Prep
Part 2

It is important to assemble the frame on a at, smooth surface.

D: Turn the assembly over then attach all boards with 6 (H9) 1/4 x 1-1/4” Hex Bolts (with lock washer and at
washer) connecting to the previously installed t-nuts. (g. 2.3 and 2.4)

Fig. 2.3

2769

2770

Fig. 2.4

2771

2768

H9

H9

x 2 per board

2769

LW1

Hardware

6 x 1/4 x 1-1/4” Hex Bolt

H9

(1/4” lock washer & 1/4” at washer)

18 [e-mail]

FW1

Step 3: Swing Wall Prep
Part 1

It is important to assemble the frame on a at, smooth surface.

A: Place (2757) LT Post Assembly and (2758) RT Post Assembly on a hard, at surface with the notches facing
down. The top of the post assemblies have the longer notches. (g. 3.1)

B: Tap 1 (TN2) 5/16” T-nut in the top holes and 1 (TN1) 1/4” T-nut in the middle and bottom holes. (g. 3.1)

Fig. 3.1

2757

Top

Notice longer
notches at
the top (both
boards)

TN2

TN1

2758

Bottom

Notice shorter
notches at the
bottom (both
boards)

Wood Parts

2757

1 x LT Post Assembly 1-1/4 x 2-1/2 x 87”

2758

1 x RT Post Assembly 1-1/4 x 2-1/2 x 87”

19 [e-mail]

Hardware

TN2

2 x 5/16” T-nut

TN1

4 x 1/4” T-nut

Step 3: Swing Wall Prep
Part 2

It is important to assemble the frame on a at, smooth surface.

C: Turn the (2757) LT Post Assembly and (2758) RT Post Assembly over and place 2 (2756) Siding Assemblies
on top so one sits ush with the top of the middle groove and the second ts ush with the top of the bottom
groove. (g. 3.2 and 3.3)

D: Place (2630) SW Top in the top grooves, (2768) Panel Floor in the middle grooves and (2769) Panel BT
Frame in the bottom grooves so they sit ush to the outside edges of (2757) LT Post Assembly and (2758) R
Post Assembly. Make sure the assembly is square then attach with 4 (S30) #8 x 1-1/16” Wood Screws per
board. (g. 3.4)

T

Fig. 3.2

2757

Fig. 3.3

2756

2758

2756

Top

Bottom

Flush

Top

Notice Orientation of both
(2756) Siding Assemblies.

S30

Fig. 3.4

2630

Flush

Wood Parts

2756

2 x Siding Assembly 1-1/4 x 19-15/16 x 39-3/16”

2630

1 x SW Top 1-1/4 x 5-1/2 x 42”

2768

1 x Panel Floor 1-1/4 x 3 x 42”
1 x Panel BT Frame 1-1/4 x 3 x 42”

2769

x 4

2757

Hardware

S30

12 x #8 x 1-1/16” Wood Screw

S30

2768

x 4

Flush

2758

S30

x 4

2769

20 [e-mail]

Step 3: Swing Wall Prep
Part 3

It is important to assemble the frame on a at, smooth surface.

E: Attach (2630) SW Top to (2757) LT Post Assembly and (2758) RT Post Assembly with 2 (WB1) 5/16 x 1”
Wafer Bolts (with at washer) connecting to previously installed t-nuts. (g. 3.5 and 3.6)

F: Attach (2768) Panel Floor to (2757) LT Post Assembly and (2758) RT Post Assembly with 2 (H9) 1/4 x 1-1/4”
Hex Bolts (with lock washer and at washer) connecting to previously installed t-nuts. (g. 3.5)

G: Place 1 (2778) SW Ground MOD to each side of (2769) Panel BT Frame, notice the hole locations and attach
with 1 (H10) 1/4 x 2-1/4” Hex Bolt (with lock washer and at washer) per board connecting to previously installed
t-nuts. (g. 3.5 and 3.7)

H: Place 1 (2607) Diagonal under (2778) SW Ground MOD on the right hand side so the top sits against (2758)
RT Post Assembly and loosely attach with 1 (H10) 1/4 x 2-1/4” Hex Bolt (with lock washer, at washer and t-nut).
(g. 3.5 and 3.7)

WB1

Fig. 3.5

x 2

2630

H9

x 2

2758

2607

LW1

H10

x 3

Fig. 3.6

WB1

FW2

Fig. 3.7

2769

2768

FW1

TN1

2778

2769

2757

2778

2778

Note which bolt holes are used

2778

Wood Parts Hardware

2778

2 x SW Ground MOD 5/4 x 4 x 14-1/4”
1 x Diagonal 1-1/4 x 3 x 22”

2607

WB1

2 x 5/16 x 1” Wafer Bolt (5/16” at washer)

H9

2 x 1/4 x 1-1/4” Hex Bolt (1/4” lock washer, 1/4” at washer)

H10

3 x 1/4 x 2-1/4” Hex Bolt (1/4” lock washer, 1/4” at washer and 1/4” t-nut)

21 [e-mail]

Step 3: Swing Wall Prep
Part 4

It is important to assemble the frame on a at, smooth surface.

I: Attach the top board in each (2756) Siding Assembly to (2757) LT Post Assembly and (2758) RT Post
Assembly with 4 (S30) #8 x 1-1/16” Wood Screws per board. (g. 3.8 and 3.9)

J: Attach the remaining boards in each (2756) Siding Assembly to (2757) LT Post Assembly and (2758) RT Post
Assembly with 2 (S0) #8 x 7/8” Truss Screws per board. (g. 3.8 an 3.9)

Fig. 3.8

Fig. 3.9

S30

x 4

S0

x 10

2756

2757

Top Board

2758

2756

S30

x 4

S0

x 10

Remaining Boards

S30

S0

Hardware

S30

8 x #8 x 1-1/16” Wood Screw

S0

20 x #8 x 7/8” Truss Screw

22 [e-mail]

Step 4: Fort Assembly
Part 1

It is important to assemble the Fort Assembly on a at, smooth surface.

A: Place Swing Wall from Step 3 between 2 Front/Back Walls from Step 1, noticing the wall orientations. The
tops and bottoms of the walls should be ush. Make sure the walls are square then using the pilot holes as a
guide pre-drill with a 3/16” drill bit and fasten the left Front/Back Wall to the Swing Wall and Swing Wall to the
right Front/Back W

all with 4 (WL5) 1/4 x 2-1/2” Wafer Lags per side. (g. 4.1, 4.2 and 4.3)

Fig. 4.1

Top View

Front/
Back Wall

Notice left Side
Wall overlaps
Swing Wall

WL5

Flush

Left

Swing Wall

Right

Front/
Back Wall

Notice Swing Wall
overlaps Front/Back

Flush

WL5

Fig. 4.3

WL5

x 4 per
side

Front/Back Wall

Left

Fig. 4.2

Flush

Notice grooves
face inwards

Right

Swing Wall

Notice counter sunk
holes on the outside

23 [e-mail]

Flush

Hardware

WL5

8x 1/4 x 2-1/2” Wafer Lag

Front/Back
Wall

Step 4: Fort Assembly
Part 2

B: Place Side Wall from Step 2 between the Front/Back Walls noticing the wall orientation. The tops and

bottoms of the walls should be ush. Make sure the walls are square then using the pilot holes as a guide pre­drill with a 3/16” drill bit and fasten the right Front/Back Wall to the Side Wall and Side Wall to the left Front/Back
Wall with 4 (WL5) 1/4 x 2-1/2” Wafer Lags per side. (g. 4.4)

Right

Front/Back Wall

Swing Wall

Fig. 4.4

WL5

Notice right Front/Back
Wall overlaps Side Wall

Notice Side Wall
overlaps left Front/
Back Wall

Side Wall

Left

Front/Back Wall

Hardware

WL5

8 x 1/4 x 2-1/2” Wafer Lag

24 [e-mail]

Step 4: Fort Assembly
Part 3

C: Loosely attach 1 (2607) Diagonal to left (2778) SW Ground MOD with 1 (H10) 1/4 x 2-1/4” Hex Bolt (with lock

washer, at washer and t-nut). (g. 4.5)

D: Place each (2607) Diagonal tight and ush to the front of the Swing Wall then pre-drill pilot holes with a 3/16”
drill bit and attach each (2607) Diagonal to the Swing Wall with 1 (LS3) 1/4 x 3” Lag Screw (with at washer) per
board, checking that they remain ush to outside edge. (g. 4.5 and 4.6)

Tighten all bolts that were loosely installed from Step 3 Part 3.

Fig. 4.5

H10

Fig. 4.6

LW1

2607

TN1

LS3

Flush

(hidden)

FW1

FW1

2778

Swing Wall

Flush

FW1

2607

LS3

2607

2607

Swing Wall

Wood Parts

2607

1 x Diagonal 1/1/4 x 3 x 22”

1 x 1/4 x 2-1/4” Hex Bolt (1/4” lock washer, 1/4” at washer, 1/4” t-nut)

2 x 1/4 x 3” Lag Screw (1/4” at washer)

Hardware

H10

LS3

25 [e-mail]

Step 5: Floor Assembly
Part 1

A: From inside of the assembly centre (2608) Floor Joist over the pilot holes in both (2768) Panel Floors in the

Swing and Front Walls, measure 5/8” down from the top of boards then attach (2608) Floor Joist to each board
using the left and centre holes with 2 (S4) #8 x 3” Wood Screws per board. (g.5.1, 5.2, 5.3 and 5.4)

Swing Wall

Fig. 5.1

2608

2768

2768

Fig. 5.2

2608

2768

Wood Parts

2608

1 x Floor Joist 1-1/4 x 3 x 40-3/4”

5/8”

Front Wall

Front Wall

Fig. 5.3

S4

Hardware

S4

4 x #8 x 3” Wood Screw

Fig. 5.4

Swing Wall

Notice holes used

S4

26 [e-mail]

Step 5: Floor Assembly
Part 2

B: On the inside of both the Front/Back Walls place 1 (2777) Side Joist MOD against each (2772) Panel Floor

Support, line up bolt holes then loosely attach with 2 (H11) 1/4 x 2-3/4” Hex Bolts (with lock washer, at washer
and t-nut) per joist. Make sure both (2777) Side Joist MODs are level with (2608) Floor Joist. (g. 5.5)

Front/Back Wall

H11

Fig. 5.5

LW1

FW1

2772

2777

2608

FW1

LW1

2777

TN1

TN1

2772

H11

Front/Back Wall

Wood Parts

2777

2 x Side Joist MOD 2 x 2 x 40-1/4”

4 x 1/4 x 2-3/4” Hex Bolt
(1/4” lock washer, 1/4” at washer, 1/4” t-nut)

Hardware

H11

27 [e-mail]

Step 5: Floor Assembly
Part 3

C: Fasten each (2777) Side Joist MOD to each (2772) Panel Floor Support with 4 (S3) #8 x 2-1/2” Wood Screws

per board as shown in g. 5.6.

D: Tighten all (H11) 1/4 x 2-3/4” Hex Bolts in both (2777) Side Joist MOD.

Fig. 5.6

2777

2772

S3

Hardware

S3

8 x #8 x 2-1/2” Wood Screw

28 [e-mail]

Step 5: Floor Assembly
Part 4

E: Starting at the Swing Wall place (2648) Floor Board followed by 8 (2609) Floor Boards. Make sure all boards

are evenly spaced then attach to (2608) Floor Joist and each (2777) Side Joist MOD with 5 (S20) #8 x 1-3/8”
Wood Screws per board. (g. 5.7 and 5.8)

Fig. 5.7

Fig. 5.8

2768

2609

S20

Swing Wall

2648

x 5 per
board

2777

Wood Parts

2648

1 x Floor Board 1 x 4 x 40-5/8”

2609

8 x Floor Board 1 x 5 x 40-5/8”

29 [e-mail]

Wall removed for
clarity

2608

Hardware

S20

45 x #8 x 1-3/8” Wood Screw

2777

Step 6: Swing Beam Assembly

A: Attach 6 Swing Hangers to the (2614) Engineered Beam using 2 (G7) 5/16 x 5-1/2” Hex Bolts (with 2 at

washers and 1 lock nut) per Swing Hanger as shown in g. 6.1.

B: Flush to the Fort End of (2614) Engineered Beam attach 2 L-Beam Brackets with 2 (G21) 5/16 x 3-3/4” Hex
Bolts (with 2 at washers and 1 lock nut). (g. 6.1 and 6.2)

C: Install 1 (WB7) 5/16 x 3” Wafer Bolt (with at washer and t-nut) in the middle bolt hole in (2614) Engineered
Beam as shown in g. 6.3. IT IS IMPORTANT THAT THIS BOLT IS ATTACHED. IT WILL MINIMIZE

CHECKING OF WOOD.

D: Attach Cedar Summit Plaque to centre of (2614) Engineered Beam (over top of t-nut) using 4 (S18) #6 x 1”

Wood Screws. (g. 6.4)

Fig. 6.1

Fig. 6.2

Fort End

L-Beam
Bracket

Flush

Fort End

LN2

FW2

Swing Hanger x 6

2614

Fig. 6.3

TN2

G7

2614

LN2

Swing End

FW2

Fig. 6.4

S18

x 4

L-Beam
Bracket

FW2

2614

Cedar Summit
Plaque

Other Parts

6 x Swing Hangers

2 x L-Beam Bracket

1 x Cedar Summit Plaque

G21

Wood Parts

2614

1 x Engineered Beam 4 x 6 x 88”

FW2

WB7

Hardware

G7

12 x 5/16 x 5-1/2” Hex Bolt (5/16” at washer x 2, 5/16” lock nut)

G21

2 x 5/16 x 3-3/4” Hex Bolt (5/16” at washer x 2, 5/16” lock nut)

WB7

1 x 5/16 x 3” Wafer Bolt (5/16” at washer & 5/16” t-nut)

S18

4 x #6 x 1” Wood Screw

30 [e-mail]

Step 7: Swing End Assembly

A: Loosely attach 2 (2613) Heavy SW Posts to (2615) SW Upright using 2 (G7) 5/16 x 5-1/2” Hex Bolts (with

lock washer, at washer and t-nut). Notice 2 bolt holes at top of (2615) SW Upright and orientation of angle.
(g. 7.1)

B: Attach (2616) SW Support to both (2613) Heavy SW Posts and (2615) SW Upright using 3 (G4) 5/16 x 4”
Hex Bolts (with lock washer, at washer and t-nut). Tighten all bolts (g. 7.1)

C: Install 2 (WB7) 5/16 x 3” Wafer Bolts (with at washer and t-nut) in the top bolt holes in (2615) SW Upright
as shown in g. 7.1. IT IS IMPORTANT THAT THESE BOLTS ARE ATTACHED. THEY WILL MINIMIZE

CHECKING OF WOOD.

FW2

Fig. 7.1

TN2

TN2

2616

2615

WB7

Notice 2 bolt
holes at top and
orientation of
the angle

2613

FW2

LW2

G4

FW2

TN2

G7

LW2

Wood Parts

2613

2 x Heavy SW Post 2 x 3 x 86-11/16”

1 x SW Upright 4 x 4 x 50-15/16”

2615

1 x SW Support 5/4 x 4 x 46-1/2”

2616

G7

2 x 5/16 x 5-1/2” Hex Bolt (5/16” lock washer, 5/16” at washer, 5/16” t-nut)

G4

3 x 5/16 x 4” Hex Bolt (5/16” lock washer, 5/16” at washer, 5/16” t-nut)

WB7

2 x 5/16 x 3” Wafer Bolt (5/16” at washer & 5/16” t-nut)

Hardware

31 [e-mail]

Step 8: Attach Swing End to Swing Beam

A: Place Swing End Assembly against Swing Beam Assembly then place 1 Beam Bracket on each side of the

assembly (they are specic for left and right side) and attach with 5 (G21) 5/16 x 3-3/4” Hex Bolts (with 2 at
washers and 1 lock nut). (g. 8.1 and 8.2)

Fig. 8.1

Swing Beam
Assembly

Beam
Bracket

Swing End
Assembly

Fig. 8.2

Swing Beam
Assembly

LN2

FW2

G21

Swing End
Assembly

Hardware Other Parts

5 x 5/16 x 3-3/4” Hex Bolt

G21

(5/16” at washer x 2, 5/16” lock nut)

32 [e-mail]

2 x Beam Bracket (Left/Right)

Step 9: Attach Swing Assembly To Fort

A: Place Swing Assembly against top of (2630) SW Top, make sure assembly is level then attach from inside

the fort assembly into each L-Beam Bracket with 4 (G8) 5/16 x 2” Hex Bolts (with 2 at washers and 1 lock
nut). (g. 9.1)

Fig. 9.1

G8

L-Beam
Bracket

2630

Swing
Assembly

FW2

LN2

Hardware

4 x 5/16 x 2” Hex Bolt

G8

(5/16” at washer x 2, 5/16” lock nut)

33 [e-mail]

Step 10: Install Ground Stakes

MOVE FORT TO FINAL LOCATION PRIOR TO STAKING

FINAL LOCATION MUST BE LEVEL GROUND

A: In the 5 places shown in g. 10.1 drive the Rebar Ground Stakes 13” into the ground against outside front
corner of the End Wall, on both (2607) Diagonals and both (2613) Heavy SW Posts. Be careful not to hit the
washer while hammering stakes into the ground as this could cause the washer to break off.

B: Attach ground stakes using 1 (S7) #12 x 2” Pan Screw per ground stake. (g. 10.2 and 10.3)

C: After driving stakes into the ground, check for sharp edges caused by the impact of the hammer. Smooth any

sharp edges from impact area and touch up with outdoor paint.

Warning! To prevent tipping and avoid potential injury, stakes

must be driven 13” (330 mm) into ground. Digging or driving stakes can
be dangerous if you do not check rst for under-ground wiring, cables

Fig. 10.1

or gas lines.

Front

Fig. 10.2

End Wall

End
Wall

S7

2607

2613

2607

SEE FRONT COVER
FOR SAFETY CLEARANCE

13” In Ground

Fig. 10.3

S7

Rebar
Ground
Stake

Rebar
Ground
Stake

13” In Ground

Hardware

S7

5 x #12 x 2” Pan Screw

34 [e-mail]

Other Parts

5 x Rebar Ground Stake

Step 11: Install Upper and Lower Jambs

A: In the upper opening of the Side Wall place 1 (2602) Upper Jamb so it measures 17” to the inside of each post

then attach with 2 Jamb Mounts using 4 (S0) #8 x 7/8” Truss Screws per mount. (g. 11.1, 11.3, 11.4 and 11.5)

B: In the lower opening of the Front/Back Wall place 2 (2601) Lower Jamb so it measures 17” to the inside of each
post then attach with 2 Jamb Mounts using 4 (S0) #8 x 7/8” Truss Screws per mount. (g. 11.2, 11.3, 11.4 and 11.5)

Fig. 11.1

Outside View

17” 17”

Do not cover holes
with Jamb Mount

2602

Side Wall

Fig. 11.3

S0

x 4 per
Jamb
Mount

Fig. 11.4

S0

x 4 per
Jamb
Mount

Jamb
Mount

Centred

Jamb
Mount

Centred

Fig. 11.2

Inside View

Front
Wall

2601

17” 17”

Grooves
to the
inside

Fig. 11.5

Outside View

2602

Side Wall

Wood Parts

2602

1 x Upper Jamb 1-1/4 x 3 x 35-15/16”

2601

2 x Lower Jamb 1-1/4 x 3 x 41-15/16”

2601

Front/
BackWall

Hardware

S0

24 x #8 x 7/8” Truss Screw

Other Parts

6 x Jamb Mount

35 [e-mail]

Step 12: Install Inserts
Part 1 - Front Wall

A: In the lower and upper openings of Front Wall install 2 (649A) Short Half Walls using 4 (S0) #8 x 7/8” Truss

Screws per insert. (g. 12.1, 12.2 and 12.3)

B: In the upper openings of Front Wall install 2 MOD Arches with 3 (S0) #8 x 7/8” Truss Screws per MOD Arch.

(g.12.2 and 12.4)

Fig. 12.1

Fig. 12.3

Inside View

Front Wall

649A

Fig.12.2

649A

2601

MOD Arch

649A

Outside View

Fig. 12.4

S0

S0

Tight

Wood Parts

649A

2 x Short Half Wall 1.27 x 18.8 x 20.91”

36 [e-mail]

14 x #8 x 7/8” Truss Screw

Hardware

S0

Tight

S0

Other Parts

2 x MOD Arch

Step 12: Install Inserts
Part 2 - Side Wall

C: In the lower opening of the Side Wall install 1 (2665) Half Wall Insert and in the upper openings, install 2 MOD

3 Pane Transoms using 4 (S0) #8 x 7/8” Truss Screws per part. (g. 12.5, 12.6, 12.7 and 12.8)

Fig. 12.5

Fig. 12.7

Inside View

Fig. 12.6

Outside View

MOD 3 Pane
Transom

2601

2665

Side Wall

2649

MOD 3 Pane
Transom

Wood Parts

2665

1 x Half Wall Insert 1.4 x 20-1/4 x 38.8”

37 [e-mail]

S0

Tight

Hardware

S0

12 x #8 x 7/8” Truss Screw

Fig. 12.8

Inside View

S0

Tight

Other Parts

2 x MOD 3 Pane
Transom

Step 12: Install Inserts
Part 3 - Back Wall

D: In the upper openings of Back Wall install 2 (2655) Uppder Window Insert using 9 (S0) #8 x 7/8” Truss Screws

per insert. (g.12.9, 12.10, 12.11 and 12.12)

E: In the left hand lower opening install 1 (649A) Short Half Wall using 4 (S0) #8 x 7/8” Truss Screws. (g. 12.9,

12.10 and 12.13)

F: In the lower left opening of Back Wall above (649A) Short Half Wall install 1 MOD Arch with 3 (S0) #8 x 7/8”
Truss Screws. (g. 12.10 and 12.11)

Fig. 12.10

Fig. 12.12

Inside View

Fig. 12.9

Back Wall

Fig. 12.11

Inside View

S0

2655

S0

MOD Arch

2601

649A

S0

Fig. 12.13

Inside View

MOD Arch

Tight

S0

Wood Parts

649A

1x Short Half Wall 1.27 x 18.8 x 20-15/16”

2655

2x Upper Window Insert 1.27 x 18.8 x 35.86”

38 [e-mail]

25 x #8 x 7/8” Truss Screw

Hardware

S0

S0

Tight

Other Parts

1 x MOD Arch

Step 13: Rock Wall Assembly

Fig. 13.1

2780

2779

S20

x 4 per
board

2781

Note: Gaps between boards
2-1/4”, not to exceed 2-3/8”

2781

Note: The holes
in the rock boards

2776

27812780

must orient to the
top of the boards.

7-5/8” Approx

A: Lay 2 (2776) Rock Rails down, side by side with angled edges

facing down. (g. 13.1)

B: Place (2779) Access Board on the bottom of each (2776) Rock Rail
as shown in g. 13.1. Make sure (2779) Access Board is ush to the
outside and bottom edges of each (2776). Attach using 4 (S20) #8 x
1-3/8” Wood Screws.

C: 7-5/8” down from the top of both (2776) Rock Rails place 1 (2781)
Rk Board B, making sure the sides are ush to the outside edges of
each (2776) Rock Rail. Attach using 4 (S20) #8 x 1-3/8” Wood Screws.
(g. 13.1)

D: In between the (2779) Access Board and (2781) Rk Board B stagger
2 (2781) Rk Board Bs and 2 (2780) Rk Board As using 4 (S20) #8 x
1-3/8” Wood Screws per board. Placing them as shown in g. 13.1, this
will prevent rocks from forming a straight line. Make sure the boards
are evenly spaced and do not exceed 2-3/8” between boards.

FW0

LW1

Fig. 13.3

Fig. 13.2

PB2

E: Place 1 rock on each (2780) Rk Board A

and (2781) Rk Board B (g. 13.2) and attach

S10

using 1 (PB2) 1/4 x 1-1/4” Pan Bolt (with lock
washer, at washer and barrel nut) and 1
(S10) #8 x 1” Pan Screw per rock. The Screw

BN1

Rock

must be in the hole directly under the Pan
Bolt, it will stop the rock from spinning. (g.

13.3)

Wood Parts Hardware

S20

2779

1 x Access Board 1 x 6 x 19”

2781

3 x Rk Board B 1 x 6 x 19”

2780

2 x Rk Board A 1 x 6 x 19”

2776

2 x Rock Rail 1-1/4 x 2-1/2 x 51”

39 [e-mail]

24 x #8 x 1-3/8” Wood Screw

S10

5 x #8 x 1” Pan Screw

5 x 1/4 x 1-1/4” Pan Bolt

PB2

(1/4” lock washer, 3/16” at washer & 1/4” barrel nut)

Other Parts

5 x Rocks (3 green/2 yellow)

Step 14: Attach Rock Wall Assembly to Fort
Part 1

A: Place Rock Wall Assembly centred in opening on the right side of the Front Wall and ush as shown below. At-

tach (2776) Rock Rails to the Front Wall using 4 (S11) #8 x 2” Wood Screws. (g. 14.1 and 14.2)

B: Attach 1 (2779) Access Board to top of Rock Wall Assembly, ush to top of (2776) Rock Rails using 4 (S20) #8
x 1-3/8” Wood Screws. (g. 14.3)

Note: Make sure (2776) Rock Rails do not cover the bolt heads, move assembly over so it is tight to the
bolt head. (g. 14.1 and 14.2)

Fig. 14.2

S11

2776

Fig. 14.1

Fig. 14.3

2779

S11

Flush

Panel

Flush

S11

Bolt
Head

2776

S20

2776

S20

2776

HardwareWood Parts

2779

1 x Access Board 1 x 6 x 19”

40 [e-mail]

S20

4 x #8 x 1-3/8” Wood Screw

S11

4 x #8 x 2” Wood Screw

Step 14: Attach Rock Wall Assembly to Fort
Part 2

C: Drive 1 Rebar Ground Stake 13” into the ground against outside (2776) Rock Rail then attach with 1 (S7) #12

x 2” Pan Screw. Be careful not to hit the washer while hammering stake into the ground as this could cause the
washer to break off. (g. 14.4 and 14.5)

D: After driving stake into the ground, check for sharp edges caused by the impact of the hammer. Smooth any
sharp edges from impact area and touch up with outdoor paint.

Warning! To prevent tipping and avoid potential injury, stakes must be

driven 13” (330 mm) into ground. Digging or driving stakes can be dangerous if

Fig. 14.4

you do not check rst for under-ground wiring, cables or gas lines.

2776

13”

In Ground

Fig. 14.5

2776

S7

Rebar
Ground
Stake

Hardware

S7

1 x #12 x 2” Pan Screw

41 [e-mail]

Other Parts

1 x Rebar Ground Stake

Step 15: Attach Hand Grip to Fort

A: Measure 6” from the top of the oor boards on the right hand side of the Rock Board, pre-drill with a 1/8”

drill bit then attach 1 Hand Grip with 2 (WL3) 1/4 x 1-3/8” Wafer Lags to the Front Wall. (g. 15.1, 15.2)

Fig. 15.1

Hardware

WL3

2 x 1/4 x 1-3/8” Wafer Lag

6”

Fig. 15.2

Hand Grip

WL3

Other Parts

1 x Hand Grip

42 [e-mail]

Step 16: Clock Assembly

A: From inside the assembly place (2717) Clock Block centred on the panel of (649A) Short Half Wall then from

outside the assembly attach with 1 (S13) #6 x 5/8” Pan Screw in the bottom siding of (649A) Short Half Wall. (g.

16.1 and 16.2)

B: On the Front Wall place Gable Clock Assembly centred under window of (649A) Short Half Wall then attach to
(2774) Upright and (2770) End Post Left with 2 (S10) #8 x 1” Pan Screws. (g. 16.3 and 16.4)

C: Attach peak of Gable Clock Assembly through insert into (2717) Clock Block with 1 (S10) #8 x 1” Pan Screw
and bottom centre to insert with 1 (S5) #8 x 1/2” Pan Screw. (g. 16.4)

Do not overtighten screws.

Fig. 16.1

Inside View

2717

649A

Centred

Fig. 16.2

649A

Fig. 16.4

S10

2717

Parts removed
for clarity

S13

Line notch
under siding

2655

Gable Clock
Assembly

Fig. 16.3

2774

2770

S10

S10

Front Wall

Wood Parts

2717

1 x Clock Block 3/4 x 1-3/4 x 9-3/4”

3 x #8 x 1” Pan Screw

1 x #6 x 5/8” Pan Screw

1 x #8 x 1/2” Pan Screw

Hardware

S10

S13

S5

43 [e-mail]

S5

Other Parts

1 x Gable Clock Assembly

Step 17: Attach Flower Box

A: On the Front Wall place 1 Flower Box on (649A) Short Half Wall centred above the Clock then attach with

2 (S13) #6 x 5/8” Pan Screws. (g. 17.1 and 17.2)

Fig. 17.1

Fig. 17.2

649A

Hardware

S13

2 x #6 x 5/8” Pan Screw

S13

Flower Box

Other Parts

1 x Flower Box

44 [e-mail]

Step 18: Cafe Table Assembly

A: Place 1 (2612) Table Support ush to the notched out ends of 1 (2611) Table Top and attach with 4 (S7) #12 x

2” Pan Screws as shown in g. 18.1.

B: Place Table Top Assembly tight in the opening of Side Wall with the overhang on the outside of the assembly
as shown in g. 18.3 then attach (2612) Table Support to the Side Wall posts with 2 (S3) #8 x 2-1/2” Wood
Screws. (g. 18.2 and 18.3)

Fig. 18.1

Flush

Fig. 18.2

Swing Wall

2611

S7

Fig. 18.3

Outside View

Tight

2611

2612

Flush

Tight

S3

S3

Side Wall

Wood Parts

2612

1 x Table Support 2 x 2 x 39-5/8”

2611

1 x Table Top 5/4 x 5 x 39-5/8”

45 [e-mail]

Hardware

S7

4 x #12 x 2” Pan Screw

S3

2 x #8 x 2-1/2” Wood Screw

Side Wall

2612

Step 19: Attach Wall Top

A: Attach (2804) Wall Top to the Swing Wall from the inside, using 2 (S11) #8 x 2” Wood Screws. (g. 19.1,

19.2 and 19.3)

B: Attach (2804) Wall Top to (2756) Siding Assembly with 2 Corner Brackets using 3 (S13) #6 x 5/8” Pan
Screws per bracket. Corner Brackets are attached to the inside slats of the (2756) Siding Assembly. (g.

19.1, 19.3 and 19.4)

Fig. 19.2

Inside View

Fig. 19.1

Fig. 19.3

Inside View

Swing Wall

2804

S11

x 2 per
board

Tight

2756

Fig. 19.4

Inside View

S13

2804

2804

S11

2756

HardwareWood Parts

2804

1 x Wall Top 5/4 x 3 x 39”

46 [e-mail]

S11

2 x #8 x 2” Wood Screw

S13

6 x #6 x 5/8” Pan Screw

Corner Bracket

Slat

Other Parts

1 x Corner Bracket Set (pkg of 2)

Step 20: Attach Door Components
Part 1

A: On the inside of (2709) Door Window Panel measure 15” up from the bottom and attach Catch Plate ush to

the edge using 2 (S18) #6 x 1” Wood Screws. (g. 20.1 and 20.2)

B: On the inside of (2709) Door Window Panel measure 22” up from the bottom and attach 1 Door Handle using
2 (S13) #6 x 5/8” Pan Screws. (g. 20.1 and 20.2)

Fig. 20.1

Fig. 20.2

2709

S13

Door Handle

22”

15”

Inside View

Wood Parts

2709

1 x Door Window Panel 1-1/4 x 15-3/4 x 40-3/4”

47 [e-mail]

Hardware Other Parts

S18

2 x #6 x 1” Wood Screw

2 x #6 x 5/8” Pan Screw

S13

Catch
Plate

Flush

S18

1 x Door Handle

1 x Catch Plate

Step 20: Attach Door Components
Part 2

C: On the outside of the (2709) Door Window Panel attach the second Door Handle at approximately the same

place as the one on the inside. Use 2 (S13) #6 x 5/8” Pan Screws. (g. 20.3)

D: On the opposite side of the Door Handle measure 5/8” from the top and bottom of (2709) Door Window Panel
attach 2 Door Hinges on the outside using 3 (S13) # 6 x 5/8” Pan Screws per Hinge. (g. 20.3 and 20.5)

Note: Hinge stops must be tight to (2709) Door Window Panel. (g. 20.4)

2709

Fig. 20.3

Fig. 20.4

Top View

1/2”

Door
Handle

S13

5/8”

Hinge Stop

Fig. 20.5

S13

Door
Hinge

Outside View

Hardware

S13

8 x #6 x 5/8” Pan Screw

48 [e-mail]

Other Parts

1 x Door Handle

2 x Door Hinge

Step 21: Attach Door Assembly to Fort

A: On the Front Wall measure 5/8” up from the top of (2769) Panel BT Frame and a maximum 5/8” from the

inside edge of (2601) Lower Jamb then attach the remaining side of the hinges to (2770) End Post Left using 3
(S13) #6 x 5/8” Pan Screws per hinge. (g. 21.1, 21.2 and 21.3)

Fig. 21.1

Fig. 21.2

Outside View

2770

5/8”

Front Wall

Fig. 21.3

2601

Door
Hinge

S13

2769

5/8”

Hardware

S13

6 x #6 x 5/8” Pan Screw

49 [e-mail]

Step 22: Attach Door Stop

A: In the notched out opening of (2715) Door Stop attach the Magnetic Catch using 2 (S18) #6 x 1” Wood
Screws. (g. 22.1) Important: Use a hand held screw driver and DO NOT over tighten.

B: On the inside of the assembly, attach (2715) Door Stop to (2601) Lower Jamb with 3 (S11) #8 x 2” Wood

Screws, making sure (2715) Door Stop has an overhang of 1-1/4” and is in position to receive the Catch Plate.
(g. 22.2 and 22.3)

Fig. 22.2

Inside View

Fig. 22.1

2715

2601

S18

Magnetic Catch

S11

Fig. 22.3

2715

2715

2601

1-1/4”

Wood Parts

2715

1 x Door Stop 5/4 x 3 x 10”

50 [e-mail]

Hardware

S18

2 x #6 x 1” Wood Screw

S11

3 x #8 x 2” Wood Screw

Other Parts

1 x Magnetic Catch

Step 23: Roof Support Assembly

A: Attach 1 (2760) Roof Support to a second (2760) Roof Support at peak using 1 (S4) #8 x 3” Wood Screw.

Repeat this step so there are 2 Roof Support Assemblies. (g. 23.1 and 23.2)

Fig. 23.1

Roof Support
Assembly

S4

2760

Fig. 23.2

S4

2760

Wood Parts

2760

4 x Roof Support 1-1/4 x 2-1/4 x 37-1/2”

51 [e-mail]

Hardware

S4

2 x #8 x 3” Wood Screw

Step 24: Roof Panel Assembly

A: Place 1 (2751) MOD Roof Bottom tight to the bottom of (2752) MOD Roof Front and (2753) MOD Roof Back.

(g. 24.1)

B: Place a (2761) Roof Sleeper C on the middle strip of each Roof Panel Assembly so the ends are ush and
attach with 4 (S20) #8 x 1-3/8” Wood Screws per panel. (g. 24.2)

2753

and

2752

Fig. 24.1

Make sure

Fig. 24.2

2751

2751

panels are tight
to each other

2753

2752

S20

2751

2761

Flush

x 4 per
board

Wood Parts Hardware

2751

2 x MOD Roof Bottom 1-3/16 x 16-13/16 x 44”

2752

1 x MOD Roof Front 1-1/4 x 20-7/16 x 44”

2753

1 x MOD Roof Back 1-1/4 x 20-3/16 x 44”

2761

2 x Roof Sleeper C 3/4 x 2 x 35”

S20

8 x #8 x 1-3/8” Wood Screw

52 [e-mail]

Step 25: Roof Assembly
Part 1

A: Place Front Roof Panel against Back Roof Panel so the tops form a peak then tight to the inside edge of the

outside slats attach 1 Narrow Angle Bracket per slat with 2 (S0) #8 x 7/8” Truss Screws per bracket. (g. 25.1
and 25.2)

B: Attach the third Narrow Angle Bracket centred on the middle slat with 2 (S0) #8 x 7/8” Truss Screws. (g.

25.1 and 25.3)

Narrow Angle
Bracket

Fig. 25.2

Fig. 25.1

Flush

Fig. 25.3

Narrow Angle
Bracket

Centred

S0

x 2

Flush

S0

x 2 per
bracket

Flush

Back Roof
Panel

Hardware

S0

6 x #8 x 7/8” Truss Screw

53 [e-mail]

Front Roof
Panel

Other Parts

3 x Narrow Angle Bracket

Step 25: Roof Assembly
Part 2

C: Place 1 Roof Support Assembly against one side so the peaks meet and the ends of the roof supports are

ush with the ends of the roof panels. Attach with 8 (S11) #8 x 2” Wood Screws. (g. 25.4)

D: Attach the second Roof Support Assembly on the opposite side, peaks to meet and ends are ush with 8
(S11) #8 x 2” Wood Screws. (g. 25.4)

S11

Fig. 25.4

Roof Support
Assembly

Flush

Back Roof
Panel

Flush

Front Roof
Panel

Flush

S11

Flush

54 [e-mail]

(hidden)

Hardware

S11

16 x #8 x 2” Wood Screw

Roof Support
Assembly

Step 25: Roof Assembly
Part 3

E: On the inside of Roof Assembly on the bottom siding of the (2752) MOD Roof Fronts (6th siding down from

top of Roof Assembly), measure 1” from each side of (2761) Roof Sleeper C and pre-drill 2 holes with a 3/16” drill
bit as shown in g. 25.5 and 25.6. This will now be referred to as the front of Roof Assembly.

F: On the outside of Roof Assembly place 1 (8069) Dormer Cleat over the pre-drilled holes and from inside the
assembly attach with 2 (S20) #8 x 1-3/8” Wood Screws. (g. 25.5, 25.7 and 25.8)

Fig. 25.5 Fig. 25.6

Inside View

6th
Siding

Inside View

1”

1”

Fig. 25.7

Inside View

2752

S20

2761

2752

8069

Pre-drilled
hole

2752

2761

Fig. 25.8

Outside View

2752

Front

Wood Parts

8069

1 x Dormer Cleat 2 x 4 x 10”

55 [e-mail]

Hardware

S20

2 x #8 x 1-3/8” Wood Screw

Step 26: Dormer Assembly
Part 1

A: Lay 2 (8070) Dormer Sides at on the ground so the tops are tight together and form a peak. The side facing

up will be the back. (g. 26.1 and 26.2)

B: Tight to the bottom of both (8070) Dormer Sides place (8073) Dormer Bottom so the outside edges are ush.
(g. 26.1 and 26.2)

C: On the front of the assembly, centred on top of (8073) Dormer Bottom, place (8074) Dormer Burst. (g. 26.1
and 26.2)

D: Place (8071) Dormer Centre on the back side, ush to the bottom of (8073) Dormer Bottom so the tip is
centred at the peak of the (8070) Dormer Sides then attach with 4 (S30) #8 x 1-1/6” Wood Screws. (g. 26.2)

E: Place 1 (8072) Dormer Side Burst tight to each side of (8071) Dormer Centre so they are ush to the bottom
of (8073) Dormer Bottom then attach with 2 (S30) #8 x 1-1/6” Wood Screws per board. (g. 26.2)

Tight

Fig. 26.1

8071

Flush

8070

8073

8072

Front View

8074

Flush

8072

8072

8070

8070

Flush

Flush

8074

Flush

Fig. 26.2

8071

8070

8072

Flush

Flush

8073

Wood Parts

8070

2 x Dormer Side 1 x 3 x 13-5/8”

8073

1 x Dormer Bottom 1 x 2 x 22”

8074

1 x Dormer Burst 1 x 4 x 5-1/2”

8071

1 x Dormer Centre 1 x 3 x 10-3/4”

8072

2 x Dormer Side Burst 1 x 3 x 6-3/4”

Back View

Hardware

S30

8 x #8 x 1-1/16” Wood Screw

Flush

S30

56 [e-mail]

Step 26: Dormer Assembly
Part 2

F: Pre-drill with a 1/8” drill bit then attach Dormer Roof Right to Dormer Roof Left, from (8068) Dormer Roof Set

at the inside peak with 1 Narrow Angle Bracket using 2 (S5) #8 x 7/8” Truss Screws. (g. 26.3)

G: Place the Dormer Burst Assembly from Step 26, Part 1 on the inside edge of Dormer Roof and attach with 6
(S30) #8 x 1-1/6” Wood Screws. (g. 26.3)

H: Place 1 completed Dormer Assembly over (8069) Dormer Cleat and attach with 2 (S3) #8 x 2-1/2” Wood
Screws. (g. 26.4)

Narrow
Angle
Bracket

Fig. 26.3

Dormer
Roof Right

S0

Dormer
Roof Left

Dormer Burst
Assembly

Wood Parts

8068

1 x Dormer Roof Set
Includes:
1 x Dormer Roof Right

1 x Dormer Roof Left

S30

S3

Hardware

S30

6 x #8 x 1-1/6” Wood Screw

S0

2 x #8 x 7/8” Truss Screw

S3

2 x #8 x 2-1/2” Wood Screw

8069

(hidden)

Front

S3

Fig. 26.4

Other Parts

1 x Narrow Angle Bracket

57 [e-mail]

Step 27: Attach Roof Ends
Part 1 - Side Wall

A: On the Side Wall remove the 2 outside (H9) 1/4 x 1-1/4” Hex Bolts attached at the top of the assembly from

Step 2, Part 2. Leave the T-nuts in. The Flat Washers and Lock Washers will be used in Step B. (g. 27.1)

Fig. 27.1

Side Wall

Remove these bolts on Side Wall,
keeping lock washers and at washers
for next step. Do not remove the
t-nuts.

58 [e-mail]

Step 27: Attach Roof Ends
Part 2 - Side Wall

B: Loosely attach 1 (2759) Roof End to each corner of the Side Wall, ush to the top of (2769) Panel BT Frame,

with 1 (H3) 1/4 x 2-1/2” Hex Bolt per board, using the (FW1) Flat Washer and (LW1) Lock Washer from Step
and connecting to the (TN1) T-nut. Notice which bolt holes are to be used. (g. 27.2, 27.3 and 27.4)

Fig. 27.2

Flush

A

2759

Fig. 27.3

Left Side

FW1

Flush

LW1

H3

2769

2769

Side Wall

Fig. 27.4

Flush

H3

2759

Right Side

FW1

H3

LW1

X

2759

H3

Wood Parts

2759

2 x Roof End 1-1/4 x 3 x 10”

59 [e-mail]

Keep bolts loose

Hardware

H3

2 x 1/4 x 2-1/2” Hex Bolt

2769

X

2759

Step 27: Attach Roof Ends
Part 3 - Side Wall

C: Measure overhang so it is 4-7/8” then attach (2759) Roof Ends with 2 (S11) #8 x 2” Wood Screws and 1 (S3)

#8 x 2-1/2” Wood Screw per side. Tighten the bolts. (g. 27.5, 27.6 and 27.7)

Fig. 27.5

Top View

2759

S3

Fig. 27.6

Left Side

S3

S11

x 2 per board

S11

Side Wall

Fig. 27.7

Right Side

Front Wall

S3

2759

2759

Hardware

S3

2 x #8 x 2-1/2” Wood Screw

S11

4 x #8 x 2” Wood Screw

60 [e-mail]

Step 27: Attach Roof Ends
Part 4 - Swing Wall

D: Attach 1 (2759) Roof End to each corner of the Swing Wall, ush to the top of (2630) SW Top and

overhanging 4-7/8” then attach with 2 (S11) #8 x 2” Wood Screws and 1 (S3) #8 x 2-1/2” Wood Screw per (2759)
Roof End. Notice which holes are to be used. (g. 27.8, 27.9, and 27.10)

Fig. 27.8

Left Side

2759

2759

S3

Flush

Swing Wall

Fig. 27.9 Fig. 27.10

Left Side

Right Side

2630

S3

Flush

Right Side

2759

2759

S11

4-7/8”
Overhang

Wood Parts

2759

2 x Roof End 1-1/4 x 3 x 10”

61 [e-mail]

2630

Hardware

S3

2 x #8 x 2-1/2” Wood Screw

S11

4 x #8 x 2” Wood Screw

4-7/8”
Overhang

Step 28: Attach Roof Assemblies to Fort

A: With 2 people on the ground and at least 1 person in fort, liift Roof Assembly up and over the Side Wall side

of the fort. Guide the Roof Assembly onto the fort so all four (2760) Roof Supports sit ush to the front and
outside edges of (2759) Roof Ends. Dormer Assembly faces the Front Wall. (g. 28.1 and 28.2)

B: Attach (2760) Roof Supports to (2759) Roof Ends with 1 (S3) #8 x 2-1/2” Wood Screw per support. (g. 28.1
and 28.2)

Roof
Assembly

Fig. 28.1

Swing
Wall

Dormer
Assembly

Fig. 28.2

Front
Wall

Side
Wall

2760

S3

Flush

2759

Hardware

S3

4 x #8 x 2-1/2” Wood Screw

62 [e-mail]

Step 29: Sunburst Assemblies

A: From inside place 1 (9082) MOD Sunburst Bottom against the (2760) Roof Supports on the Roof Assembly

opening on the Swing Wall. Make sure it sits tight to the Roof Assembly on each side then attach with 2 (S20) #8
x 1-3/8” Wood Screws. (g. 29.1 and 29.2)

B: Centre (8305) Starburst Centre lengthway on the outside of (9082) MOD Sunburst Bottom then measure
1-1/4” up from the bottom of (9082) Sunburst Bottom and attach (8305) Starburst Centre with 2 (S20) #8 x 1-3/8”
Wood Screws. (g. 29.1 and 29.3)

C: On the inside of the assembly place (9080) MOD Sunburst A tight to the top of (9082) MOD Sunburst Bottom
so the tip is centred at the peak of the Roof Assembly then attach to each (2760) Roof Support and (8305)
Starburst Centre with 3 (S20) #8 x 1-3/8” Wood Screws. (g. 29.1 and 29.2)

D: Place 1 (9081) MOD Sunburst B tight to each side of (9080) MOD Sunburst A

and tight to the top of (9082)
MOD Sunburst Bottom then attach to each (2760) Roof Support and (8305) Starburst Centre with 2 (S20) #8 x
1-3/8” Wood Screws per board. (g. 29.1 and 29.2)

Repeat steps

A - D to create 2 Sunburst Assemblies

Swing Wall

Fig. 29.1

Side Wall

Fig. 29.2

Inside View

9081

9080

Fig. 29.3

Outside View

9081

1-1/4”

2760

Wood Parts

9082

2 x MOD Sunburst Bottom 1 x 4 x 30”

8305

2 x Starburst Centre 5/4 x 6 x 12”

9081

4 x MOD Sunburst B 1 x 4 x 7-1/4”

9080

2 x MOD Sunburst A 1 x 4 x 11-1/2”

63 [e-mail]

S20

x 11

9082

2760

Hardware

S20

22 x #8 x 1-3/8” Wood Screw

9082

8305

Step 30: Attach Slides to Fort

A: Place 1 Slide in the centre of each opening of the Side Wall, pre-drill with a 1/8” drill bit then attach each

slide to fort through the (2772) Panel Floor Support using 3 (S7) #12 x 2” Pan Screws per slide. (g. 30.1, 30.2
and 30.3)

Fig. 30.1

Fig. 30.2

2772

S7

Slide

Side Wall

S7

Fig. 30.3

2772

Slide

Hardware Other Parts

S7

6 x #12 x 2” Pan Screw

64 [e-mail]

2 x Slide

Step 31: Attach Belt Swings and Acro Swing

A: Using 1 Threaded Quick Link per chain, join 1 Long Chain to each side of the Swing Belt Seat. Make sure

to close the Threaded Quick Link tightly using an adjustable wrench. (g. 31.1 and 31.2).

B: Using 1 Threaded Quick Link per chain, join the Short Chain to the Acro Bar. Attach another Threaded
Quick Link to each Acro Handle and join with rst Threaded Quick Link. Make sure to close the Threaded
Quick Link tightly using an adjustable wrench. (g. 31.2 and 31.3)

C: Attach the other end of the swing chains to the Swing Hangers. Make sure to close the Threaded Quick
Link tightly using an adjustable wrench. (g. 31.1)

Short

Fig. 31.1

Chain

Caution: Threaded Quick Links
must be installed with the gate
completely down covering
the threads and tighten as
instructed. (g. 31.2)

Long Chain

Swing Belt

Swing

Seat

Belt Seat

Acro Bar

Fig. 31.3

Threaded Quick Links

attach to seat and Acro

bar.

Fig. 31.2

Threaded Clip

Threaded
Clip

Tighten Threaded Quick

Link using adjustable

Threaded

wrench

Clip

Acro Handles

Other Parts

1 x Acro Bar
2 x Acro Handle
2 x Swing Belt Seat
2 x Short Chain
4 x Long Chain
8 x Threaded Quick Link

65 [e-mail]

Final Step: Attach I.D. Plaque

ATTACH THIS WARNING & I.D. PLAQUE
TO THIS LOCATION ON YOUR PLAY
EQUIPMENT!

This provides warnings concerning safety and
important contact information. A Tracking Number
is provided to allow you to get critical information
or order replacement parts for this specific model.

ATTACH THIS WARNING & I.D. PLAQUE
TO THIS LOCATION ON YOUR PLAY
EQUIPMENT!

This provides warnings concerning safety and
important contact information. A Tracking Number
is provided to allow you to get critical information or
order replacement parts for this specic model.

A: Attach I.D. Plaque

- Cedar Summit to a
location on your set that
is easily seen and read
by a supervising adult
using 4 (S13) #6 x 5/8”
Pan Screws as shown
below.

S13

I.D. Plaque ­Cedar Summit

Hardware

S13

4 x #6 x 5/8” Pan Screw

66 [e-mail]

Other Parts

1 x I.D. Plaque - Cedar Summit

NOTES

NOTES

67 [e-mail]

CEDAR SUMMIT

Consumer Registration Card

First Name Initial Last Name

Street Apt. No.

City State/Province ZIP/Postal Code

Country Telephone Number

E-Mail Address

Model Name Model Number (Box Labels)

Serial Number (on ID Plaque)

Date Purchase Purchased From

MM / DD / YY

How would you rate this product for quality?

Excellent

Very Good

Average

How would you rate this product for ease of assembly?

Excellent

Very Good

Average

How would you rate our instructions?

Excellent

Very Good

Average

How would you rate the quality of packaging?

Excellent

Very Good

Average

Would you recommend the purchase of our products to friends and family?

Yes

No

Comments:

Below Average

Below Average

Below Average

Below Average

Poor

Poor

Poor

Poor

MAIL TO:

Solowave Design

TM

375 Sligo Road W.
Mount Forest, Ontario, Canada

N0G 2L0

Attention: Customer Service

REVISION: 11/28/12

Fill out your registration card online at

www.cedarsummitplay.com/registration

Cedar Summit would like to say Thank You for
your time and feedback.

CUT ALONG LINE
