Discover Your Phone

How to...

Left softkey

Navigation keys

Pick up key

Microphone

Screen

Right softkey

Hang up, cancel

and on/off key

Alphanumeric

keypad

Headset/charger

connector

Switch the phone On/Off

Enter your PIN code

Lock the keypad Press

Unlock the keypad Press

Make a call Enter the phone number

Long press ).

Enter your PIN code using the keypad and press to confirm.

, or C

*. The keypad

will be locked automatically when the flip is closed (whether or not the keys on the phone's flip will also be locked shall depend on the settings you have made). When the flip of the phone is opened, the keypad will be unlocked automatically, while the keys on the phone's flip will be locked.

C and then press *

to unlock.

using the keypad and press

End a call Press ).

Answer a call When the phone rings, press

Activate/deactivate handsfree mode

Mute a call When the phone rings, press

In idle mode, enter the phone number using the keypad or select a contact in the phonebook.

, or C Options, then

Press select call handsfree and

press During a call, press

Options to access the

handsfree option. When there is an incoming call, long press

,, or C

Reject a call When the phone rings, press

Set the conversation volume

Press volume side keys to adjust the volume during acall.

Set the ringer volume

Access dialed calls list

Access WAP

browser

Access Contacts Press

Access My Files Press

Access Write SMS Press

Access Main Menu Press

Access MP3 Press

Go to previous menu

Quickly return to idle when browsing menus

When the phone is in idle mode, press volume side keys to adjust the ring volume of an incoming call.

Press

Short press

( in idle mode.

+ in idle mode.

- in idle mode. < in idle mode. > in idle mode. , or C in idle mode. c in idle mode. c.

Softkeys

The left and right soft keys ( C and c ) are located at the top of keypad area. Pressing the soft keys allows you to select the option displayed on the screen directly above them, including options during a call. The functions of the soft keys change according to the current context.

Main menu

You can access the different features of your Philips XRazr phone from the main menu. The following table summarizes the structure of the Main menu, what the icons represent and the page number on which you can obtain more information regarding the menu functions.

Entertainment Browser Music Player

page 22

Camera Messages My Files

page 30

Tools Contacts Profiles

page 50

Connectivity Calls Settings

page 68 page 70 page 73

page 23

page 36 page 45

page 61

page 26

page 66

Press , in idle mode to access the main menu and

+, -, < or > to navigate through the icons and

press lists, or press to access the options and functions directly. When navigating through a list, the scrolling bar onthe right of the screen will indicate your current position in the list. Press corresponding options of the selected item in the list. Press

0 - 9 keys, and * or # keys

C Select or , to access the

c Back to return to the previous menu.

How to use this manual

This user manual strives to provide you with concise and complete information regarding your Philips XRazr phone.

Discover your phone

Chapter 1: Getting started

Chapter 2: Main features

The current section presents an overview of your mobile phone and information on the most commonly used features.

Information on how to set up your mobile phone for the first time: installation of the SIM card, battery, etc.

How to make and answer calls, as well as some frequently used call functions.

Chapter 3: Text entry

Chapter 4 to 15

Other sections

How to enter text using the alphanumeric keypad.

Description of the main features of this phone.

Icons & Symbols, Precautions, Troubleshooting, Philips Authentic Accessories, SAR information (if available at the time of publication, otherwise included as a separate document), and finally the Limited Warranty information.

Table of contents

1. Getting Started ............................................7

Inserting the SIM card ......................................7

Switching on the phone ...................................9

Charging the battery ........................................9

Setting Hotkeys ..............................................10

2. Calling .............................................................11

Switch on the phone ..................................... 11

Switch off the phone ..................................... 11

Make a call ....................................................... 11

Options during a call .....................................11

Mute or unmute a call ...................................12

Adjust speaker/earpiece volume ................ 12

Call recording .................................................12

End a call ..........................................................12

Make an international call ............................12

Make a second call (Network dependent) 13

Switch calls (Network dependent) ............13

Call Handsfree ................................................ 13

Answer a call ...................................................13

Reject a call .....................................................13

Answer a second call (Network

dependent) ......................................................13

Fotocall ............................................................. 14

3. Text and number entry ...................... 15

Input method .................................................. 15

Entering texts and numbers ........................ 15

Entering symbols ............................................ 16

Shift case .......................................................... 16

Delete ............................................................... 16

English input ........................................... 16

Basic text input ............................................... 17

Pinyin Input ...................................................... 18

Zhuyin Input .................................................... 19

Stroke input .................................................... 20

4. Entertainment ........................................... 22

Games .............................................................. 22

Demo mode .................................................... 22

5. Browser ........................................................ 23

WAP settings .................................................. 23

Push Inbox ....................................................... 25

6. Music ............................................................... 26

Tracks ............................................................... 26

Artists ............................................................... 26

Playlists ............................................................. 27

Last played ....................................................... 27

Now playing ....................................................27

Settings .............................................................28

Using the music player control keys

on the flip ......................................................... 28

7. Camera .......................................................... 30

Camera mode .................................................30

Video mode .....................................................32

8. Messages .......................................................36

SMS ....................................................................36

MMS (network dependent) ......................... 37

Inbox .................................................................38

Outbox .............................................................39

My favourites ...................................................40

Draft ..................................................................40

SIM archive ...................................................... 41

Templates ........................................................ 41

Voice mailbox ................................................. 41

Cell broadcast ................................................. 42

Message Setting ..............................................43

9. My Files ..........................................................45

Pictures ............................................................. 45

Videos ............................................................... 46

Audios ...............................................................48

Memory capacity ............................................49

10. Tools ............................................................ 50

Lady’s planner ................................................. 50

Calendar ........................................................... 57

Alarm ................................................................ 58

Calculator ........................................................ 58

Voice recorder ............................................... 58

International clock ......................................... 59

Stop watch ....................................................... 59

Unit converter ................................................ 59

Countdown ..................................................... 60

11. Contacts ....................................................61

Create contacts .............................................. 61

View groups ....................................................63

Special numbers ............................................. 63

Quick call .........................................................64

Advanced .........................................................64

12. Profiles ........................................................ 66

Profile selection .............................................. 66

Personalise settings ....................................... 66

13. Connectivity ............................................ 68

Bluetooth .........................................................68

USB function ................................................... 69

PC software ....................................................69

Memory card .................................................. 69

14. Calls ..............................................................70

Call history ......................................................70

Clear history ...................................................70

Call settings .....................................................70

15. Settings ........................................................73

General ............................................................. 73

Display .............................................................. 75

Sounds .............................................................. 75

Connectivity .................................................... 76

Icons & symbols ............................................. 78

Precautions ....................................................... 79

Troubleshooting ............................................ 83

Philips Authentic Accessories ..............85

Trademark Declaration ............................ 86

SAR Information - International ......... 87

Limited warranty ..........................................88

Declaration of conformity ...................... 91

1. Getting Started

Please read the safety instructions in the "Precautions" section before use.

Before you start using your phone, you must insert a valid SIM card supplied by your GSM operator or retailer. The SIM card contains your subscription information, your mobile telephone number, and a small quantity of memory in which you can store phone numbers and messages (for more information, see “Contacts” page 61). You can also insert a memory card. This provides you with expanded memory capability, which allows you to store additional music, photo, and video files separate from the phone's built-in memory.

Lift up the back cover from its slot.

Remove the battery

Put your finger on the black holder located at the top of the battery and lift the battery up from its slot.

Inserting the SIM card

Remove the back cover

Make sure that the phone is switched off. You need to remove the back cover and the battery of your phone before you can insert the SIM card. Hold the phone with the front facing downwards as illustrated in the diagram and push the back cover in the direction as shown.

You may lose all your personal settings if you remove the battery when the phone is switched on.

7 Getting Started

Insert the SIM card

Make sure that the clipped corner of the SIM card is facing the correct direction (clipped corner at upper left) and the metallic contacts are facing downwards. Slide the SIM card into the card slot until it stops. When you remove your SIM card from its holder, make sure that you smoothen the edges, otherwise you may have difficulty sliding the card into the SIM slot.

Replace the back cover

Align and slide the back cover into its slot as shown until it locks into place.

Replace the battery

With the metallic contacts facing downwards, insert one side of the battery into the slot and press it down to lock it into place.

When inserting the battery, be careful not to damage the metallic connectors of the SIM card slot

Getting Started 8

When the phone is switched on without a SIM card, users can access the main menu by pressing or make SOS emergency number via c or (.

, or C,

Switching on the phone

To switch on the phone, long-press the ) key. Enter the PIN code if required (the 4 to 8 digit secret code of your SIM card). It is preconfigured and provided to you by your network operator or retailer. For more information on PIN code, see “Security” on page 74.

If you enter an incorrect PIN code 3 times in succession, your SIM card will be blocked. To unblock it, you must obtain the PUK code from your network operator.

date and time settings are only memorized for a short while. As such, you need to reset the information after you have installed the battery back again.

Once the battery and battery cover are installed, you can charge the phone. Plug in the connector as shown below. Then plug the other end into an AC power socket.

Charging the battery

Your phone is powered by a rechargeable battery. The new battery is partially charged. A sound alert will be emitted to warn you when the battery level becomes low.

We recommend that you do not remove the battery when the phone is switched on as you may lose all your personal settings as a result. If you do remove it, the

The battery symbol indicates the state of charge. During charging, the charge indicators will scroll; it takes around 2.5 hours to fully charge the battery. When all the scroll bars are steady, the battery is fully charged. You can then disconnect the charger. Depending on the network and condition of use, talk time and stand-by time can go up to 10 hours* and 1000 hours* respectively.

9 Getting Started

*Depending on the network conditions, user settings, method of use, etc the actual results may differ.

Keeping the charger plugged to the mobile phone when the battery is fully charged will not damage the battery. The only way to turn off the charger is to unplug it, so it is advisable to use an easily accessible AC power socket.

If you do not intend to use your phone for several days, we recommend that you remove the battery.

You can use the phone while it is charging (note that the vibra alert goes off when the charger is connected). If the battery is completely flat, the battery icon will only reappear after a few minutes of charging.

Options > Personalise, then select a feature to be

associated with the numeric key from the following list:

• Alarm • Bluetooth

• Calendar • Calculator

•Voice Memo •Firewall

• Inbox • Language

Numeric keys 0, 1, # and * have been preconfigured as the default keys to enter "+", access voice mailbox, activate Meeting profile and change language settings, respectively, and cannot be modified.

Setting Hotkeys

You can configure the numeric keys 2 - 9 to access your favorite features. Once they have been set, you can simply long press on the numeric key to access the corresponding features. Majority of the hotkeys have been preset and configured. To check the hotkey settings, go to

Shortcuts > Hotkey. To change the hotkey setting,

press the numeric key you wish to change and select

Getting Started 10

2. Calling

Although your Philips X Razr mobile phone supports a wide variety of functions, such as taking pictures, recording videos and sound, sending and receiving of SMS/MMS, etc, it is first and foremost a mobile phone. This chapter describes the features and options related to making and receiving calls.

Switch on the phone

Long press ) to switch on the phone. You may set a security code (PIN code) on your phone to protect it from unauthorised use. When you have set a security code, you will be prompted to enter the corresponding security code when you switched on the phone.

Enter the PIN code. For security reasons, the screen will display “*” to represent the numbers you have entered. If you have entered the wrong number, press

Press C OK. The phone will validate the PIN code and commence network registration.

Once a network name is displayed on the screen, you are ready to make or answer a call. If there is no network name on the screen, you need to reregister.

c Clear to clear it.

If you enter a wrong PIN code 3 times in succession, your SIM card will be blocked. To unblock it, you must request the PUK code from your operator. If you enter a wrong PUK code 10 times in succession, your SIM card will be permanently blocked and cannot be used anymore. If this happens, please contact your network operator.

Switch off the phone

At all times, you can long press ) to switch off the phone.

Make a call

You can make a call only when the network name appears on the screen.

Enter the phone number.

Press ( to dial the number.

Options during a call

During a call, you can press C Options to carry out the following operations:

- Activate/cancel handsfree

- Activate bluetooth headset

- Mute/Unmute the call

11 Calling

- Put the call on hold

- Dial a new number

- End the current call

-Access Main Menu

- Record phone conversation (which includes 3 sub-options: Record both, Record the opposite

party and Record own)

-Access Contacts list

Mute or unmute a call

During a call, press C Options and select Mute or

Unmute. If you select Mute, the microphone will be

deactivated. When you switch from one call to another, muting will be cancelled.

Adjust speaker/earpiece volume

During a call, call on hold or call waiting, you can

+/- to increase or decrease the volume (if you

press are not browsing the call options menu). When the volume has been set, the call volume will take effect immediately and the settings will be applied to your subsequent calls.

Call recording

During a call, press C Options and select Record to access the 3 recording options; namely, Record both (default), Record the opposite party and Record own (applicable to two-party calls or multi-party calls). When you start recording, a recording icon will appear on the screen. When you end the call, the recording will stop and saved automatically in AMR format under My Files > Audio.

There is no limit to the length of the recording; the recording will stop only when you press the recording, when there is insufficient memory, or when the call has ended.

c key to stop

End a call

Press c End or ) to end a call.

Make an international call

Long press 0 until "+"appears on the screen.

Enter the country code.

Enter the area code (normally without the 0 in front), followed by the phone number.

Press ( to call directly.

Calling 12

Make a second call (Network dependent)

You can make a second call by putting the current call on hold:

During a call with Party A, you can enter Party's B number using the keypad.

Press ( to dial Party B's number. Party A will be put on hold automatically.

Switch calls (Network dependent)

When you have one active call and one call on hold, you can press between the 2 calls.

C Options, then select Swap to switch

Call Handsfree

During a call, press C Options and select Hands free.

When the headset is plugged into the phone, you cannot activate handsfree mode.

Answer a call

Press ( to answer a cal l.

Reject a call

Press ) to reject a call.

Answer a second call (Network dependent)

If you have activated Call waiting, you will be alerted when there is a second incoming call. You can:

Press ( to answer the second call. The current call will be put on hold automatically.

Press ) to reject the second call and continue with your current call.

When there is one active call and one call on hold, you can press following operations:

• Swap • Conference call • Hands free

• Bluetooth headset • Mute • Holding

• End all calls • End call • Send SMS

• Record • View contacts

If you press the numeric keys * or # under call waiting mode, the notepad editor will be activated.

C Options to carry out the

13 Calling

Fotocall

This feature allows you to link a contact in your phonebook to a photo you have taken using the Camera function, or a picture you have downloaded via WAP or data cable. During a call, if the other party's name card is linked to a picture, the incoming call background will display the corresponding picture. This feature is referred to as "Fotocall".

Fotocall is only available on the phone memory. The photo size should not be larger than 128 x 160 pixels.

Calling 14

3. Text and number entry

Input method

Your mobile phone supports several input methods, which include:

• T9 Pinyin: Enter chinese characters with T9 Pinyin;

• T9 Traditional Chinese Zhuyin: Enter Traditional Chinese characters with T9 Zhuyin;

• T9 Stroke: Enter Chinese characters with T9 wubi and stroke components;

• T9 Traditional Chinese stroke: Enter Traditional Chinese characters with Wubi or stroke components;

• T9 English (T9eng/T9Eng): Enter English text using T9 English;

• Multi-Tap (abc/ABC): Press the keys that are marked with the corresponding letter you wish to enter. Press once to get the first letter on the key, press twice quickly to get the second letter and so on until the letter you want is displayed on the screen.

• 123: Enter numbers

This phone supports T9 Simplified Chinese association input method as well.

*During text editing, you can press input mode; the status bar on the screen will display your current input mode. 『拼』 represents Simplified Chinese Pinyin input mode; 『笔』 represents Simplified Chinese stroke input mode;

『ㄅㄆ』 represents Traditional Chinese BoPoMo

input mode; 『筆』 represents Traditional Chinese stroke input mode; 『en』 represents T9 English input mode; 『abc』 represents English alphabets input mode; 『123』 represents numeric input mode. In addition, you can press # to input punctuations."

The text editor remembers the last input method you have used before you exit the editing screen. When you access the editor again, it will automatically select the last input method you have used.

Entering texts and numbers

You can input text in the editor using: T9 English input, English alphabets, Pinyin, Zhuyin, Simplified Chinese Stroke or Traditional Chinese Stroke. In addition, there are two input methods for you to enter numbers and punctuations. The icon displayed on the screen shows the current input method. You can press

* to switch

15 Text and number entry

* to switch from one mode to another. Long press

is required under Zhuyin mode. Long press enter punctuations or press

In numeric input mode, long press 0 to enter ".".

0 to switch case.

# to

Entering symbols

In any input mode, press # to open/close symbols input screen. Press the corresponding number on the left of the symbol to input it and then return to the original input mode. If the symbols occupy more than one screen, press

+/- to scroll up/down the pages.

Shift case

Press 0 to shift case in the English input editor.

Delete

When there are contents in the input row, press c

Clear to delete the rightmost character or symbol. The

candidate area will be updated accordingly until the input row is cleared. Long press input row. When the input row is empty, press delete the character on the left of the cursor in the text area. If there are no characters on the left of the cursor, the character on the right will be deleted. Long press

c Clear to clear the

c Clear will

c Clear to clear the contents in the text area.

T9® English input

What is it?

T9® predictive Text Input is an intelligent editing mode for messages, which includes a comprehensive dictionary. It allows you to quickly enter text. You need to press only once on the key corresponding to each letter needed to spell a word: keystrokes input are analysed and the word suggested by T9 at the bottom of the screen. If there are several words,

< or > to browse the list and choose from those

press proposed by the T9 below). After you have input the word, press to insert space.

built-in dictionary (see example

is displayed

1 or >

How to use it?

Alphabets and symbols represented by each key are as follows:

0 to 9 To input letters.

< or >

To browse the last or next candidate word.

C OK To confirm the letter or word.

Text and number entry 16

c Clear

Short press to clear a letter, long press to clear all entries.

Shift case.

Select input mode.

Activate/deactivate punctuation mode.

Example: How to enter the word "Home"

Press 4 6 6 3, the screen display the first word on the list: Good.

Press > to browse and select Home.

Press C OK to confirm Home.

Basic text input

If you wish to use basic text input mode, press * to select "ABC" basic text input. This method requires multiple key presses to reach the desired character: the letter "h"is the second letter on the must press requires you to press a key as many times as is equal to the order of the letter. To enter the word «Home» in basic text input mode, you should therefore key

4 twice to enter "h". Using this mode

4, 4 (GHI) 6, 6,

4 key, so you

Letters, numbers and symbols are located on each key as follows:

Key Letters and numbers

Space 1

a b c 2 à ä å æ ç

d e f 3 e e Δ Φ

g h i 4 Γ ì

j k l 5 Λ

m n o 6 ñ ò ö ø

p q r s 7 β Π Θ Σ

t u v 8 ü ù

w x y z 9 Ω Ξ Ψ

Shift case

Switch text input mode

Input symbol

6 (MNO), 6 (MNO), 3, 3 (DEF).

17 Text and number entry

Pinyin Input

Press * and select Pinyin input mode. Each Pinyin letter is represented by one of the numeric keys as shown below: (Note that Pinyin input mode is solely meant for the input of Simplified Chinese characters. You cannot input Traditional Chinese characters).

ABC 3 DEF

4 GHI 5 JKL 6 MNO

7 PQRS 8 TUV 9 WXYZ *

* Mode 0 # Punctuation

The general steps of using Pinyin input method are as follows:

Enter Pinyin letters 2 to 9

Select Pinyin combination < or >

Confirm Pinyin combination

Select from candidate list < or > / + or -

Confirm selection

Select and enter association character, or return to step 1 to enter new words.

Or press c Exit to exit from association character input mode, then press complete the editing.

Enter the pinyin lette rs accordingly. Press once on the key corresponding to the pinyin letter without having to consider its position on the key. Pinyin input method will automatically select and list all possible combinations for you to select.

Clear to clear

(scroll list)

, to

Text and number entry 18

For example, to input the character『王』, with the Pinyin letters『wang』, press

> to select the desired pinyin combination for

use

『wang』 , then press

After that, you may press a number key to enter the intonation of the character (1-1 tone, 2-2 tone, 3-3 tone, 4-4 tone, 5- silent tone) to narrow down the candidate characters selection range. Then press to select the desired character 『王』 and press to confirm the input of this character. As soon as you have selected and entered a character, the candidate list will be updated and a list of association characters will be displayed. Press to select the desired association character and press to confirm entry. This speeds up the input process further. When you have finished editing a name on the phonebook or SMS, press association character input mode and press confirm completion of the editing process.

9 2 6 4 and

, to confirm combination.

< or >

c Exit to exit from

, to

Zhuyin Input

T9 Traditonal Chinese Zhuyin

Input

Press once on the key corresponding to the Zhuyin character without having to consider its position on the key. All the possible Zhuyin combinations will be listed on the input row. Characters located on each key follows:

Key Characters

0 - 9 are as

ㄞㄍㄐ

ㄓㄢㄅㄉ

｜ㄗㄦㄚ

ㄠㄎㄑㄟ

ㄔㄣㄊㄆ

ㄨㄘㄛ

ㄡㄏㄒ

ㄕㄤㄋㄇ

19 Text and number entry

When the zhuyin combination appears on the input row, press zhuyin combination and press selection mode.

Selection

Press press the desired character, press and go into association input mode.

Association

The input area is empty and the candidate area display a list of association characters. Press the navigation keys to select an association character, or press a number key to input a new zhuyin combination.

</> to move the selection box over the

</> to move the selection box left or right, and +/- to scroll list. When the selection box is on

ㄩㄙㄜㄝ

ㄖㄌㄈㄥ

, to enter character

, to confirm the input

Stroke input

Press * to select stroke input mode. The strokes are represented on each key as follows:

Left-falling

Horizontal

5 Vertical

Over-down

* Mode 0

3 DEF

Right-failling

9 Special

Punctuation

Text and number entry 20

The basic steps of Stroke input are as follows:

Enter strokes 2 to 9

(excluding 3 and 7)

c Clear to clear.

Select from candidate list

Confirm selection

Select and enter association character, or return to step 1 to enter new strokes.

Or press c Exit to exit from association character input mode, then press , to complete the editing.

The principle of stroke input is to dissect and separate every stroke of a chinese character according to sequence. When you wish to input the character, press the keys corresponding to the required strokes according to sequence to get the desired character. The stroke input method in this phone classify a chinese character into 5 basic strokes: (horizontal, vertical, left falling stroke, right falling stroke and over-down) as well as a special stroke. When the

< or > / + or -

( scroll list)

stroke you need does not correspond to the 5 basic strokes, replace it with the special stroke. The examples below will give you a clearer understanding of how to use stroke input method:

木 : 2 + 5 + 4 + 6

田 : 5 + 8 + 2 + 5

2 + >

加 : 9 + 4 + 5 + 8 + 2

凉 : 6 + 9 + 6 + 2 + 5

8 + 2 + 9 + 4 +

陈 : 9 + 5 + 2 + 9 + 9

4 + 6 + > + (repeat > 4 times)

Generally, you will be able to find a desired character before you finished entering all the strokes. After you have entered the name of the phonebook or SMS,

c Exit to exit from association character list and

press

, to confirm completion of text editing.

press

The input mode for Traditional chinese stroke and Simplified Chinese stroke are similar, with the exception of the character coding.

21 Text and number entry

4. Entertainment

This section describes the games and additional tools installed on your mobile phone.

Some of the features described here are dependent on the configuration of your mobile phone, the country in which you purchased your mobile phone, and/or your service provider.

Demo mode

This menu displays a video clip that illustrates the multimedia features in your mobile phone. It is available even if you have not inserted a SIM card.

Games

Default games

This phone comes with several pre-installed games for entertainment. Press idle mode and select Entertainment > Games > Default

games.

, to enter the main menu from

Java Games

Your mobile phone features a Java run-time environment which allows you to run the preinstalled Java applications in the handset. You can also download games and other applications via WAP or USB and run them in the Java environment.

Entertainment 22

5. Browser

Your phone comes with a WAP browser. You can obtain news, sports and weather information, as well as services from the Internet via the WAP browser.

This feature is available only if your subscription includes WAP access services. The settings have been pre-configured and you do not need to modify them. For more information, please contact your network operator.

WAP settings

You can send MMS only if your configurations are correct. Normally, the phone would have been preconfigured. If you wish to add or modify the configuration parameters, you need to obtain the necessary information from your network operator before you proceed. Philips is not liable to give prior notification nor shall it bear any consequences for any failures arising from changes of configuration made by you or by the network operator. Please check with your network operator for the most updated information.

Homepage

Select this menu to access the homepage directly. You can also set the homepage address in the settings menu.

Bookmark

You can save the current Web page or the Web pages that you frequently visit to the Bookmark list, manage and organize them. Up to 10 bookmarks can be stored on the phone. When you enter the menu, a list of bookmark entries is displayed. To connect to the Web address of a particular bookmark entry, select an entry using

+ or - and press ,.

If there are no existing entries, you can select the following options to add and manage your bookmarks:

Add bookmark Edit the title and Web address.

Manage bookmark

Delete or edit a bookmark entry.

23 Browser

To add a new bookmark:

Go to Bookmark menu

Select Add Bookmark Press

Add a new bookmark

Press menu from idle mode and select Browser > Bookmark.

Select.

Enter the Address and Title of the new bookmark and press

C Save.

To edit a bookmark:

Go to Bookmark menu

Select Manage

Bookmark

Select a bookmark you wish to edit

Enter Options menu Press

Press menu from idle mode and select Browser > Bookmark.

Press

Select.

Press

, to enter the main

+ or - and press C

, to enter the main

+ or - and press C

+ or - .

C Options.

Select Edit Press

Edit the bookmark Edit the Address and Title of

+ or - and press C

Select.

the bookmark and press

Save.

History

This menu allows you to manage, organize and quickly access the Web pages you have previously visited.

When you enter this menu, the Web pages you have previously visited will be listed.

Press C Options to access the following:

Homepage Save as

Back Send as MMS

Forward Save as homepage

Refresh Exit

Bookmark Setting

Enter address

Enter the Web address and press C or , to connect,

c Back to return to previous Web page.

press

Browser 24

Settings

This menu allows you to configure the Web settings for Web browsing. Your phone may have been preconfigured with the settings of a specific network operator. If you are a subscriber of the network operator, you may start using your WAP browser immediately. Otherwise, you need to re-configure the settings.

Philips is not liable to give prior notification nor shall it bear any consequences for failures arising from changes in configuration made by you or by the network operator, or changes in WAP address or contents made by the Internet content provider. Please check with your network operator and your internet content provider for the most updated information.

The following options are available:

Browser options Allows you to configure the

browser parameters, such as

Display pictures, Activate Refresh,

etc.

Cache Allows you to set the Cache mode

and Clear cache.

Cookies Allows you to Enable cookies or

Clear cookies.

Push Inbox

Allows you to check your Push messages and configure your Push settings, such as select whether or not to accept Push messages, delete push messages, etc.

25 Browser

6. Music

This feature allows you to download music from the network, save the audio files, edit your playlist, and play music. The phone supports audio files in MP3 and AAC format.

Tracks

This feature allows you to play downloaded music in your Phone memory or Memory card. From the listed tracks, use play and then press

Options Description

Open Open the music player to play the

Add to playlist

+/- to select the music file you want to

C Options.

selected track.

Open the playlist, select a playlist and add the selected track to the playlist.

Delete Delete the selected track.

Details View detailed information of the

selected track.

Artists

A list of singer names is displayed on the screen. You can press

+/- to select a certain artist and press

C or , to display all tracks of the selected artist.

From the listed tracks, use you want to play and then press

Options Description

Open Open the music player to play the

Add to playlist

Delete track Delete the selected track.

Delete artist Delete all tracks of the same artist.

Details View detailed information of the

+/- to select t he mus ic file

C Options.

selected track.

Open the playlist, select a playlist and add the selected track to the playlist.

selected track.

Music 26

Playlists

The stored playlists are displayed on the screen. To create a new playlist, select New playlist. Enter the playlist name and press file, press the playlist.

You can create up to 10 playlist and you can store up to 20 track s in ea ch lis t. The avail able o ption s includ e:

,, and then press C to confirm and store

Options Description

Open Open the music player to play the

Edit playlist Edit the playlist.

Rename Modify the playlist name.

Delete Delete the current playlist.

Tracks sequence Modify the play sequence of the

Details View detailed information of the

,. Then use +/- to select a

currently selected file.

current playlist.

selected file.

Last played

List the last 10 tracks you have played, and the last played track is displayed at the top of the list.

Now playing

The screen displays the file currently playing. If there is no file currently playing, a list of tracks last played before exiting the playlist is displayed.

Keys operation

The keypad operations during music playback are as follows:

Key Operation

, key Short press to Start/Pause/resume

music playback. Long press to stop playback.

< or > Short press to select the previous

song/next song. Long press to fast rewind/fast forward.

+ or - Adjust volume. Once you have set

the volume, the settings will be saved until the next time you adjust it again.

27 Music

C Options Open options menu.

c Stop Stop playback.

c Back Return to previous menu.

Press C Options to carry out the following operations:

Play/Pause Play/Pause the selected audio file.

Add to playlist Open the playlist, select a playlist

and add the selected file to the playlist.

Play mode Shuffle: On or Off

Repeat: None, Repeat Single or Repeat playlist.

Equalizer Select Bass boost, Dance, Hip-hop,

Pop, R&B or Rock.

Detail Display detailed informatio n of the

selected audio file.

Flip exit Select On or Off (default). If you

select On, once you close the flip, you will exit from the music player.

Settings

The available options include:

Options Description

Equalizer Select Bass boost, Dance, Hip-hop,

Pop, R&B or Rock.

Play mode Shuffle: On or Off

Repeat: None, Repeat Single or Repeat playlist.

Help Display descriptions on how to use

the music player.

Refresh list All tracks stored in the phone

memory and the memory card will be refreshed.

Using the music player control keys on the flip

Whether or not the music player will stop playing when you close the flip of the phone during music playback depends on your settings in the Flip exit option.

Music 28

When the flip of the phone is closed, whether or not the keys on the flip can be operated depends on your keylock setting as well.

When the flip is closed, the operations of the external keys are as follows:

Key Operation

+ or - Short press: Turn the volume up/

down. Long press: Select previous/next track.

29 Music

7. Camera

Your mobile phone features a digital camera that allows you to take pictures and record short videos, store them in your phone, use them as wallpaper or send them to your friends.

Please ensure that the camera lens is clean before you take pictures, as small dust particles can strongly affect the picture quality.

Camera mode

Consult the table below on how to carry out some common operations with your camera.

How to ...

Launch Camera Press

, to enter the main

menu from idle mode and select DC/DV > DC.

Zoom in/out Press </>.

Maximum zoom factor is 4x for pixels below 480*640 only.

Adjust brightness Press

Take a picture Press

Exit from Camera and return to idle mode

At any point in time, you can press ) key to cancel the current operation and return to idle mode.

+/-.

Brightness level is -3 to +3. Default level is 0.

The picture will be automatically saved and stored in My Files > Pictures.

If a memory card is inserted, the picture will be saved in the memory card by default.

) key.

Press

Camera 30

Camera option menu

When the camera mode is activated and before a picture is taken, you can change a number of settings by pressing

Options Description

Capture Take a new picture.

Switch to DV Exit from Camera mode and

Picture resolution Select image size: 1024x1280,

Picture Quality Select image quality: Super fine,

C Options.

switch to Video mode.

In the viewfinder mode, you can switch from Camera to Video mode by pressing the </> button.

768x1024, 480x640 and 128x160.

Fine and Normal.

The last selected value will remain active until you change you change it again.

View pictures Enter My Files > Pictures to view

the pictures taken.

Camera mode Color effect: Off (default), B & W,

Sepia or Blue.

The selected color efffect will be displayed on the screen in real time.

Night mode: On or Off Multishot: On or Off

Three pictures can be taken at the same time.

Advanced Stored location: Phone memory or

Memory card Default name: modify the default

name of the photo

Electricity frequency: 50HZ or 60HZ

31 Camera

Once you have activated the camera, simply press , to take a picture. The picture is automatically saved and displayed on the screen. You can press to carry out the following operations:

Options Description

Send Send the picture:

Delete Delete the current picture.

Capture R eturn to the viewfinder screen t o

Set as contact picture

Set as wallpaper

Send by Bluetooth, or Send by MMS.

take a new picture.

Link the picture to a contact in your mobile phone so that the picture will be displayed when the contact calls you.

Set the picture as a wallpaper in idle screen.

C Options

When the memory card is full, the pictures will be automatically stored in the phone memory. When there is not enough memory space in both the phone and memory card, you will not be able to save the picture and you will be prompted wtih a warning me ssa ge. Yo u ha ve to d ele te exi sti ng p ictur es b efore you can store new ones.

Video mode

This option allows you to record short videos. You can play the video, store it in your phone or in the memory card. You can also send the video to your friends via MMS or Bluetooth.

How to ...

Launch Video Camera

Zoom in/out Press

, to enter the main

Press menu from idle mode and select DC/DV > DV.

</>.

Maximum zoom factor is 4x for pixels below 480*640 only.

Camera 32

Adjust brightness Press

Brightness level is -3 to +3. Default level is 0.

Record a video Press

Exit from Video mode and return to idle mode

to stop recording.

The video will be automatically saved and stored in My Files > Videos.

If a memory card is inserted, the video will be saved in the memory card by default.

Press

+/-.

, key once. Press twice

) key.

Video option menu

When the video mode is activated and before you start recording, you can change a number of settings by

C Options.

pressing

Options Description

Record now Record a new video.

Switch to DC Exit from Video mode and switch

Video Quality Select video quality: Fine or

View videos Enter My Files > Videos to view the

Video mode Color effect: Off (default), B & W,

to Camera mode.

Normal

The last selected value will remain active until you change it again.

recorded videos.

Sepia or Blue.

The selected color efffect will be displayed on the screen.

Video format: MPEG-4 or 3GP

33 Camera

Advanced Stored location: Phone memory or

Memory card Default name: modify the default

name of the video

Mute audio: On or Off

If you select On, sound will not be recorded.

Video length: MMS (default) or Unlimit.

If you select MMS, the size of the recorded video will be smaller than the currently specified maximum MMS size. Recording will stop when reaching the maximum MMS size and the video will be stored automatically. If you select Unlimit, there will be no restrictions on the size of the recorded video. The maximum size shall be determined by the memory capacity of your mobile phone or the memory card.

Once you have activated the video mode, simply press

, to start recording. Press , twice to stop recording.

The video is automatically saved and the last recorded scene is displayed on the screen. You can press

Options to carry out the following operations:

Options Description

Playback Play the recorded video.

During playback, you can: Pause playback by pressing , or

Pause.

Resume playback by pressing

C Play.

or Adjust volume by pressing Fast rewind by pressing and

< Fast forward by

holding pressing and holding previous menu level by pressing

+/-

> Go to

Return to idle screen by pressing

)

Send Send the recorded video:

Send by Bluetooth and Send by MMS.

Camera 34

Delete Delete the recorded video.

Record new Return to video mode to record

When there is not enough memory space, you will not be able to save the recorded video and you will be prompted wtih a warning message.

anew video clip.

35 Camera

8. Messages

SMS

SMS (Short Message Service) is a service that lets you to send text messages to another party. You can use the SMS menu on the phone to send messages to another mobile phone or a device that is capable of receiving SMS. Your phone can store up to 500 messages. Once you have reached 500 messages, the screen will flash an ic on to ale rt you . You nee d to dele te som e mess ages in order to receive new ones.

In idle mode, press , to enter the main menu.

Select Messages > SMS and press ,.

Create, edit and send SMS

You need to enter the correct message center number before you can send SMS. The number can be obtained from your network operator.

In idle mode, press , to enter the main menu.

Select Messages > Create Message > SMS and

,. The SMS editing screen will appear.

press

Enter the SMS content in the SMS editor and

C Options to carry out the following

press operations:

Continue Enter the phone number of the

Insert Insert animation or sound.

Save Save the SMS.

If your SMS is not sent successfully, you can resend it. If your SMS cannot be sent successfully after several attempts, please check if your SMS center number has been set correctly.

When editing SMS, for certain reasons (such as an incoming call, out of battery), you are forced to exit from the SMS editing screen before you managed to send or save your message successfully, the edited message will be saved automatically. The next time you enter the SMS editor, the message will be displayed on the screen.

recipient. You can also select it from the

Contacts list or Groups. Press

to send the SMS.

Messages 36

MMS (network dependent)

Your phone allows you to send and receive multimedia messag es, known as MMS, which features text, pictures, sound and video clips. MMS can comprise one or several slides. Whether you send it to an e-mail address or to another mobile phone, the MMS will be played as a slide show. Your phone can support 50 MMS (maximum 98KB). When the maximum of 50 MMS is reached, the screen will display a MMS icon to alert you. You will need to delete some old MMS in order to receive new ones.

In idle mode, press , to enter the main menu.

Select Messages > MMS and press ,.

Before you can send MMS, you need to enter the correct MMS center number and ensure that the network profile of your MMS has been correctly configured. You can obtain such information from your network operator.

Create, edit and send MMS

In idle mode, press , to enter the main menu.

Select Messages > Create Message > MMS and

,. The MMS editing screen will appear.

press

Enter the MMS content in the MMS editor and

C Options to carry out the following

press operations:

Continue Enter the phone number of the

Insert object Insert picture, video, melody,

Change object It appears after you have inserted

Delete object Delete inserted objects.

Preview Preview the current MMS.

recipient. You can also select it on Contacts list or Groups. Press the MMS.

page or object.

Only a picture, a melody and a video can be inserted on one page. If 3 of them exist at the same time, only one can be saved.

objects. You can change these inserted objects.

, to send

37 Messages

Pages timing Set play time of the MMS slides.

Save Save the MMS.

When there is more than one page, you can press </> to view the different pages of the MMS. At the same time, the title bar at the top of the screen will display the current page you are viewing and the total number of pages in your MMS.

The default value is 3 seconds.

Inbox

The Inbox stores the messages you have received.

In idle mode, press , to enter the main menu.

Select Messages > Inbox and press ,.

If there are messages in the Inbox, they will be listed on the screen in the order they were received (the most recent message will appear at the top of the list).

Press +/- to select a message. When a message is selected, its contents will be displayed on the screen.

Press , to enter the next screen whereby the message details will be displayed. Press

Options to carry out the following operations:

View View the selected SMS or play

Reply The sender's number will be

Forward When you select Forward, the

Delete Delete the message from the

Delete all Delete all the messages in the

Add to SIM archive

the selected MMS.

used as the destination number automatically and the message editor will be activated. Enter your reply and send the message.

contents of the selected message will appear in the message editor. You may edit the message before sending.

Inbox.

Add the selected message to the SIM card.

Messages 38

Move to Favourites

Details View information of the mes sage

Call back Extract the sender's number

Select multiple You can press

Move the selected message to My

Favourites.

such as date, time and sender.

from the message and dial the number.

, to select/cancel

the operations on multiple messages. Checkboxes will be marked on the le ft of the selected message. You can delete the selected messages.

Outbox

The Outbox allows you to save the messages you have sent successfully and which you have chosen to save before sending.

In idle mode, press , to enter the main menu.

Select Messages > Outbox and press ,.

If there are messages in the Outbox, they will be listed on the screen.

Press +/- to select a message. When a message is selected, its contents will be displayed on the screen.

Press , to enter the next screen whereby the details will be displayed. When you press

Options, you can carry out the following

operations:

View View the selected message.

Send Resend the message to the

recipient.

Forward When you select Forward, the

contents of the selected message will appear on the message editor. You may edit the message before sending.

Delete Delete the message from the

Outbox.

Delete all Delete all the messages in the

Outbox.

Details View information of the message

such as date and time.

39 Messages

Select multiple You can press

the operations on multiple messages. Checkboxes will be marked on the left of the selected message. You can delete the selected messages.

My favourites

This menu contains all the messages received and saved in the phone memory via Move to Favourites option. The available options include:

Options Description

View Open the current message and

view the detailed contents of the message.

Reply Reply the message.

Forward Forward the message to other

recipients.

Delete Delete the message.

Delete all Delete all messages.

Details View details of the message.

, to select/cancel

Call back Call the sender of the message.

Select mutiple You can press

the operations on multiple messages. Checkboxes will be marked on the left of the selected message. You can delete the selected messages.

, to select/cancel

Draft

This menu lists the messages that were created and saved but were not sent, and messages that were automatically saved before you were able to save or send them when you exit from the message editor. Select a message from the Draft menu and press

Options to: View, Send, Edit, Delete, Delete all, Details and Select multiple. If you select View, the subsequent

procedures would be similar to the Inbox operations.

Messages 40

SIM archive

In the menu, you can see the read and unread messages saved in the SIM card. The available options include:

Options Description

View Open the current message and

view the detailed contents of the message.

Reply Reply the message.

Forward Forward the message to other

recipients.

Delete Delete the message.

Delete all Delete all messages.

Details View information of the message,

such as date, time and sender, etc.

Call back Call the sender of the message.

Select mutiple You can press

the operations on multiple messages. Checkboxes will be marked on the left of the selected message. You can delete the selected messages.

Templates

You can preset up to 10 frequently used messages. This menu allows you to send, add, modify and delete your preset messages.

Voice mailbox

This menu allows you to set your voice mailbox number and listen to voice messages your correspondents have left for you.

You can forward your calls to your voice mailbox (the phone number for callers to leave a message) via the Call forwarding feature.

Call voice mail

When you receive a voice mail, the phone will send you an alert. You can then call your voice mailbox number to retrieve your voice mail.

, to select/cancel

41 Messages

In idle mode, long press 1 to call your voice mailbox directly. If the number is empty, you will be prompted to enter the number.

Voice mail number

Generally, you can obtain two sets of numbers from your network provider:

• number for the caller to leave a message (this number can also used for Call Forwarding)

• number for you to retrieve your voice messages

Cell broadcast

This is a network service which allows you to receive text messages of various contents, such as news, traffic, etc. These messages are provided by the network to the subscribers within a certain network area. If this service is available, the network will provide you with the broadcast channel numbers. It gives you access to the options listed below.

Options Description

Reception Select to turn on/off the reception

of new cell broadcast messages.

Channel list Add, change or delete channels.

Reception

You can set the reception of broadcast messsages On or

Off. If you select Off, you will not receive any

broadcast messages, even if you have set the corresponding channel numbers. When you received a broadcast message, the message content will be displayed on the screen until you press

<New channel>: Add a new

channel.

Change: Edit a channel number. Delete: Delete a channel in the

channel list.

c Exit. Broadcast messages will not be saved on your

mobile phone or your SIM card. Once you exit from the message screen, you will not be able to read it again.

To obtain the codes corresponding to the different types, you must contact your operator.

Messages 42

Message Setting

SMS

Message center

This menu allows you to save and edit the SMS service center number of your home network. If the service center number is empty, you will not be able to send any SMS.

Validity period

Allows you to select the duration by which your messages will be stored in the message center. You can select from: 12 hours, 1 day, 1 week and Maximum (default). Press This option is useful when your recipient is not connected to the network and is not able to receive your messages immediately.

This feature is subscription dependent.

Delivery report

You can select set whether or not to notify you the send status of your messages: successfully sent to the recipient, or not sent successfully. This feature is subscription dependent.

</> to select a value.

C On or Off. This option allows you to

Signature

You can select

On, the signature will be added to the end of your

message before it is sent to your recipient.

If the SMS is too long after adding the signature, the signature will be shortened automatically.

Saved location

You can select the preferred storage location of your messages: SIM card (Default) or mobile phone.

C On or Off (Default is Off). If set to

MMS

This menu allows you to set your MMS center and personalize your MMS settings. The options include:

MMS parameters

You can select or edit the parameters.

Sender visibility

You can set this option On or Off. It is used to set if your identity will be visible when MMS is sent.

Priority

This option allows you to set the priority level of your MMS. You can set Low, Normal (default) or High.

Delivery report

You can set this option On or Off. When set to On, a report will be sent to notify you if the MMS has been delivered to the recipient.

43 Messages

Read report

You can set this option On or Off. When set to On, a report will be sent to notify you if the MMS has been read by the recipient.

Expiry time

Allows you to select the duration by which your MMS will be stored in the MMS center. You can choose from 6 hours, 12 hours, 1 day, 1 week or Maximum (default).

Messages 44

9. My Files

This menu allows you to store the files in different folders (Pictures, Videos, Audios, Others) to facilitate more efficient management of files in your phone and the memory card. In addition, you can obtain information regarding your phone and memory card, such as number of files, memory utilised, percentage of memory utilised via the Memory check option.

Pictures

When you enter this menu, the photos which you have taken using the phone's camera as well as pictures you have downloaded via MMS, WAP or USB will be displayed in a list.

Select My files > Pictures and press , to enter the menu.

Press C Options to carry out the following operations to a selected file:

Options Description

View View the picture in full screen.

Send Send the selected file: Send by

Advanced Copy: Copy the selected file to

Use Set as contact ID: If you select this

bluetooth and Send by MMS.

another folder.

Cut: Similar to copy, but the

original file will be deleted.

Rename: Modify the name of the

selected file.

Details: Display detailed

information of the selected photo, such as last modified date, file size, etc.

option, the phonebook list will be displayed. After you have selected a contact from the phonebook,

C OK to associate the

press picture to the selected contact.

Set as wallpaper: If the selected

photo is 176*220 or smaller, it will be displayed as wallpaper in its original size. If larger than 176*220, it will be re-sized accordingly.

45 My Files

Delete Delete the selected picture.

Slide show If you select this option, the

screen will display the full screen view of all the pictures in the form of slideshow every 4 seconds. Press any key to exit from the slide show mode.

Change view You can select to view the pictures

in List view, Grid view or Full

screen.

Sort Sort the pictures and folders by

name or date.

Select multiple Selecting one by one: select the

picture one by one and then Cut,

Copy or Delete them. Selecting all: select all the pictures

and then Cut, Copy or Delete them.

Add frame Add a photo frame to the selected

picture. Available only when the picture size is 176*220.

The folder options include:

View Browse the selected folder.

Advanced Rename: Modify the name of the

Delete Delete the selected folder.

Change view Select List view or Grid view.

Sort Sort the pictures and folders by

selected folder.

Details: View detailed

information of the selected folder.

name or date.

Videos

When you enter this menu, the videos wh ich you have recorded using the phone's camera as well as videos you have downloaded via MMS, WAP or USB will be displayed as a list.

Select My files > Videos and press , to enter the menu.

Press C Options to carry out the following operations to a selected file:

My Files 46

Options Description

Play/Pause Play or pause the selected video.

Send Send the selected file: Send by

bluetooth and Send by MMS.

Advanced Copy: Copy the selected file to

another folder.

Cut: Similar to copy, but the

original file will be deleted.

Rename: Modify the name of the

selected file.

Details: Display detailed

information of the selected video, such as last modified date, file size, etc.

Delete Delete the selected video.

Change view You can select to view the video

files in List view or Grid view

Sort Sort the videos and folders by

name or date.

Select multiple Selecting one by one: select the

The folder options and their operations are the same as those in the Pictures menu. Videos are played in the middle of the screen. A status bar is displayed at the top of the screen. The keypad operations when playing videos are as follows:

Key Operation

video one by one and then Cut,

Copy or Delete them. Selecting all: select all the videos

and then Cut, Copy or Delete them.

, or C Start/pause playback.

+/- Adjust volume level. The

volume level selected will be stored.

Long press to rewind.

Long press to fast forward.

47 My Files

)

Exit/return to an upper menu level.

Return to idle screen.

Audios

When you enter this menu, the audios which you have stored or downloaded via MMS, WAP or USB will be displayed in a list.

Select My files > Audios and press , to enter the menu.

Press C Options to carry out the following operations to a selected file:

Options Descriptions

Play Play the selected audio file.

Send The available options are: Send by

bluetooth and Send by MMS.

Advanced Copy: Copy the selected file to

another folder

Cut: Similar to copy, but the

original file will be deleted

Rename: Modify the name of the

selected file

Details: Display detailed

information of the selected audio file, such as last modified date, file size, etc.

Apply The selected audio file can be: Set

as incoming call ring or Set as content ring.

Delete Delete the selected audio file.

Sort Sort the audio files and folders by

name or date.

Select multiple Selecting one by one: select the

audio files one by one and then

Cut, Copy or Delete them. Selecting all: select all the audio

files and then Cut, Copy or Delete them.

My Files 48

The folder options and their operations are the same as those in the Pictures menu.

Memory capacity

This menu displays the full memory capacity in the phone, the amount used and the percentage between the full memory and used memory in both the phone memory and memory card.

49 My Files

10. Tools

Lady’s planner

The results generated by the various functions under the Lady's planner are for reference only, and may not be accurate as the conditions of each individual may be different. The results shall NOT be relied upon for health, medical, family or pregnancy planning or decision making under whatever circumstances, and the measurements shall NOT be regarded as a replacement for health checks by a medical practitioner. This Philips phone is not a medical instrument or device. Users are advised to seek independent medical advice for health and/or pregnancy related issues. Philips shall not be held liable if users get pregnant or fail to get pregnant by relying on the female calendar.

Female calendar

This function allows you to check your estimated menstrual cycle and your possible high fertility risk periods.

Enter the menu.

The screen displays 3 input boxes. Press +/- to switch between the input boxes.

Average menstrual cycle

Average menstrual days

1st day of last menstrual cycle

Press C Options to carry out the following operations:

Enter the average number of days of your ovulation cycle (e.g. 28 days).

Enter the average number of days of your period (e.g. 5 days).

Enter the first date of your last period (DD/MM/YYYY) .

Tools 50

Options Description

Check Show the dates of your possible

Legend Show the meaning of the colors

high fertility risk periods and estimated menstrual period. Users can view the current, previous and next month’s conditions. Different color or icon will be displayed to indicate different conditions (e.g. Pink represents menstrual period).

Press C Options and select Legend to show the meaning of the colors and icons displayed.

and icons displayed in the female calendar menu.

Shopping list

Shopping list provides a convenient way for you to record the items you wish to buy. You can view, add, modify or delete the shopping list.

Enter the menu.

The screen displays a list of items you have already added to the list. If the list is empty, you

will be prompted to create it. Press to create a shopping list. Press

If a shopping list has been created, press +/- to select a certain list.

The shopping list will be sorted according to its date of creation. The last created list will appear first and indicated with a green icon.

If the date of the shopping list is close to the current system date ( 1 day limit), then the shopping list will be moved to the top of the list and indicated with a red icon. For example, if today is 5 October and the date of the shopping list is 6 October, and the system date of your phone is 5 October, the list will be moved to the top of the list. When a shopping list has expired, it will be indicated with a grey icon.

Press C Options to carry out the following operations:

Options Description

Create Create a new shopping list.

View View details of the selected

Modify Edit the selected shopping list.

shopping list.

C Confirm

c Cancel to exit.

51 Tools

Delete Delete the selected shopping list.

Delete all Delete all the contents of the

Create a shopping list

Select Create to enter create shopping list screen. You can create a maximum of 30 shopping lists.

Press +/- to switch between the various input boxes. You can enter the following information: Item name, shop, date, unit price, quantity, completion status and reminder.

When the cursor in the date, unit price, quantity input boxes, enter the values using the keypad. To enter decimal point for unit price, long press

shopping list.

When the cursor is in the completion and reminder input box, press

No (default).

The maximum length of a store name is 40 characters. The maximum number of digits for unit price is 10.

When you have completed, press C Save or , to save the shopping list.

Please note that all the input boxes in the shopping list are mandatory and cannot be left empty.

</> to select Yes or

Price comparison table

This menu allows you to enter different prices for the same product, so as to identify the store that sells the product at the lowest price.

Enter the menu.

The screen displays a list of items you have already added to the list. If the list is empty, you will be prompted to create it. Press

Confirm to create a list. Press

If a list has been created, press +/- to select aproduct.

Press C Options to carry out the following operations:

Options Description

Create Create a new product

View View details of the selected

Change Edit the selected product

Delete Delete the selected product

information.

product.

information.

c Cancel to exit.

Tools 52

Delete all Delete all the product

Create a product information

Select Create to enter create product information screen. You can create a maximum of 20 product information.

Press +/- to switch between the various input boxes. You can enter the following information: product name, shop, name of up to 5 shopping malls and their respective prices.

When the cursor in the price input boxes, enter the values using the keypad. To enter decimal point for unit price, long press

The maximum length of a store name is 40 characters. The maximum number of digits for unit price is 10.

When you have completed, press C Save or , to save the product information.

Please note that all the input boxes are mandatory and cannot be left empty. If data for more than one store is added, the store with the cheapest price for the specific product will be highlighted.

information in the list.

Discount Manager

This menu allows you to calculate the discounted price of an item. The calculation for discounted price varies according to the language settings. When the current language setting is Chinese, the method of calculation is: Original $*(Discount rate/10) When the current language setting is English, the method of calculation is: Original $*(100-Discount rate)/100 As the method of calculation varies according to language settings, the input boxes also vary. When the current language is Chinese, the screen will prompt you to enter the original price and n discount rate.

Press +/- to switch between the two input boxes.

The maximum length for original price is 10 digits and the maximum length for n is 3 digits (including decimal point and the number after the decimal point). Long press 0 to enter decimal point.

Press C Calculate or , to display the results on the screen.

Press C Clear to clear the results and continue with the next calculation.

53 Tools

The calculation procedure is the same when the language is English, except that the maximum length for n discount rate is 4 digits (up to 2 decimal points).

My card

This menu allows you to manage your cards, such as membership cards, bank cards, credit cards, debit cards, etc. When you forgot to carry your cards, you can use this menu to check your card information or even enjoy accumulation of points, bonuses, etc you are entitled to.

Enter the menu.

The screen displays a list of cards which you have added. If the list is empty, you will be prompted to create it. Press information. Press

If the card information has been created, the screen will display the list of card issuers and the type of card will be indicated on the left of the card list

Press +/- to select a card and press C Options to carry out the following operations:

Options Description

Create Create a new card information.

C Confirm to create a card

c Cancel to exit.

View View details of the selected card.

Change Edit the selected card

information.

Delete Delete the selected card

information.

Delete all Delete all the card information in

the list.

The card information will be listed according to the date of creation. The last created card will appear at the top of the list.

If the effective date of the card relative to the system date of the phone has expired, then the card will be moved to the bottom of the list and will be indicated with an icon.

If the date of the card information is close to the current system date (30-day limit), then the card information will be moved to the top of the list and indicated with an icon. For example, if today is 1 October and the expiry date of the card is 31 October, and the system date of your phone is 1 October, the card will be moved to th e top of the list until it e xpires.

Tools 54

Create new card information

Select Create to enter create new card information screen. You can create a maximum of 10 card information.

Press </> to select a card type; after selection,

+/- to switch between the different input

press boxes: card issuer, card number, validity period, contact phone number and remarks.

The maximum length for name is 40 characters, card number is 30 digits, phone number is 41 digits, remarks is 60 characters.

When you have finished, press C Save or , to save the card information.

Please note that except for remarks and phone number fields, the rest of the input boxes are mandatory and cannot be left empty.

BMI-Body Mass Index

BMI is the recommended method for measurement of overweight in adults. The borderline for overweight and obesity is determined by BMI, which is closely linked to body fat. You can measure your weight index using the BMI function. BMI is calculated by using the weight divided by the height in squares. In the calculation, weight is in

kilogrammes, while height is in metres. The formula is as follows: BMI= [Weight (kg)]/ [(Height) metres x (Height) metres]

Enter the menu.

The cursor will be in the weight input box. Use the keypad to enter your weight. Press to switch the cursor between weight and height input boxes.

The unit of measurement for weight is kilograms (kg) or pounds, and the measurement for height is centimetres (cm). However, in the calculation of BMI, your height in centimetres will be converted to metres.

Weight ranges between 10 to 200 kg. Height ranges between 10 to 300 cm.

After you have entered the height and weight,

C Calculate or , to start calculation.

press The results will be displayed at the bottom of the screen. Besides displaying your BMI, the interpretation of your BMI results will also be displayed in the following manner:

16 or below Cacotrophia

16 - 18.5 Underweight

+/-

55 Tools

18.5 - 24.99 Normal weight

25 - 29.99 Overweight

30 - 39.99 Obesity

40 or higher Morbid Obesity

After you have done the calculation, press L Clear to clear the input boxes and the calculation results, so that you can perform another calculation.

Basal Metabolic Rate (BMR)

Basal Metabolic Rate is the minimal calorie requirement required to sustain life in a resting or sleeping individual that is not subject to the influence of stress, hunger, muscular activities, ambient temperature and health conditions. Basal Metabolic Rate reflects an individual's metabolic condition and has been considered as a reference for weight control and the maintenance of health. The formula for calculating BMR provided by your mobile phone is the Harris-Benedict formula, which is as follows: Female: BMR = 655 + (9.6 x weight in kg) + (1.8 x height in cm) - (4.7 x age in years) Male: BMR = 66 + (13.7 x weight in kg) + (5 x height in cm) - (6.8 x age in years)

In the above method of calculation, the unit for weight is in kilogrammes and the unit for height is in centimetres. Take for example a 68 kg, 168 cm tall, 21-year-old male; his daily Basal Metabolic Rate (BMR) will be: 66 + (13.7 x 68) + (5 x 168) - (6.8 x 21) = 66 + 932 + 840 - 143 = 1695 calories.

Enter the menu.

The cursor will be in the gender selection box.

</> to select gender (Male/Female), press

Press

+/- to switch between age, weight, height input

boxes and enter the values using the keypad. Age is in years, height is in kilogrammes and weight is in centimetres.

Weight ranges between 10 to 200 kg, age ranges between 1 to 200 and height ranges between 10 to 300 cm.

After you have entered the height and weight,

C Calculate or , to start calculation.

press The results will be displayed at the bottom of the screen. After calculation, press the input boxes and the results of the calculation to perform another calculation.

C Clear to clear

Tools 56

Calendar

This menu displays the calendar. You can select Day view, Week view or Month view. You can create new appointment, view appointments list, delete or modify appointments in the calendar. The calendar stores the alarm date and time of every event. If the current date and time correspond with the date and time of the event, the phone will emit an alarm (if needed), and the screen will display a prompt to indicate that a new event has arrived. You can create a maximum of 30 events. The list will display part of the contents. Once you have selected an event, you can press information.

Enter the menu.

The options include: New, Check (this month),

Weekly, View all events, Delete all events, Delete expired events and Capacity.

Add new event

The list of events will be displayed. When you add a new event, you need to enter the corresponding information of the event, such as subject, location, start date, start time, end date, end time, reminder and repetition.

, to view the detailed

If the memory space for events is full, the phone will prompt you that there is no more space.

When editing date and time, the phone will display the default or the selected date and time. You can edit or confirm them directly.

The maximum length of an event is 40 characters.

Alert type

The phone provides the following alert types: No

reminder, At event time, 5 minutes before, 15 minutes before, 1 hour before, 1 day before and other (the

reminder time can be set by you).

Repeat method

The phone provides the following repeat methods:

once, daily, weekly, monthly and annually.

When you change the date and time of your phone, the next alert will be repeated based on the modified date and time of the phone.

When you switch off the phone, the organizer alert will be postponed until the next time you switch on the phone. For repeated events, only the latest one will be alerted.

57 Tools

Alarm

This phone supports 24-hour alarm. The available options are:

Options Description

Sample alarm A sample alarm rings only once.

Set the alarm status to On or Off. When set to On, you need to specify the alarm time.

Reccurent alarm A recurrent alarm rings according

to the day you specify in a week. For example, if you select Sunday and Monday, the alarm clock will ring every Sunday and Monday.

Alarm tone Select an alarm tone.

Snooze mode Select On or Off.

When the set alarm time is reached, the alarm will ring even if your phone is switched off. Press any key to disable the alarm and the mobile phone will be switched off automatically.

Calculator

Your mobile phone has a built in calculator. Enter the numbers with the keypad.

Options Description

* Options To toggle between negative and

LSK Options Add a % symbol.

Addition

Subtraction

Multiplication

Division

Equals

positive figures.

Add a decimal point.

Voice recorder

This menu allows you to record a voice memo. From the main menu, select Tools > Voice recorder.

Tools 58

To start recording, press C or ,. During the process, the recorded time will be displayed in real time. To stop recording, press saved in My files > Audios.

c and the file will be

International clock

The International clock allows you to check the time of the major cities of the world. You can activate or deactivate the clock display in the Clock status submenu.

Local settings

To set the local time zone. The screen displays a world map with the current date and time. A vertical highlight in orange indicates the current zone on the map, and a text bar shows the display with ‘GMT’ and the current cities. Move the highlight with information in real time. You can access the following options:

Select Choose the current time zone as

Set time Open time editor screen.

Summer time Turn daylight saving on or off.

</> key to update other

the local setting.

City list Open an information screen with

a list of cities in the currently highlighted time zone.

Foreign settings

To set the foreign time zone. The operations and options are the same as Local time zone. However,

Set time option is not available in the menu.

Stop watch

Your phone features a stop watch and the minimum unit is 0.1 second. The starting time is 00:00.0, in the format “mm:ss.n”, where mm stands for minutes of the watch, which can be any number from 0 to 59; ss stands for seconds, a number between 0 and 59; n stands for 0.x second, x being any number from 0 to 9. The stopwatch will start the timing when you press pause the timing, press

Continue, to stop the timing, press

C Start or ,. You can

C Pause, to resume press C

c Stop.

Unit converter

This application allows you to convert many types of units such as exchange rate, acreage, energy, weight, power, pressure, temperature and volume.

59 Tools

You need to enter the conversion Type, Amount,

Unit, Convert to and Quantity. Press

between the different input boxes.

+ or - to switch

Countdown

This feature is very simliar to the alarm clock, except that you will be alerted of the remaining time, and the phone will emit an alarm at the end of the countdown. The alarm tone is the same as your alarm clock. The minimum time is 1 minute. The format of the time is hh:mm, and the maximum time input is 23 hours 59 minutes 59 seconds. You can start the countdown by pressing

, key or the

C Start. To stop countdown, press C Stop, to reset,

C Reset and you can exit the menu by pressing

press

c Back.

the When the set time is up, the alert will start to ring and the ring type is the same with the alarm.

The count-down timer will switch on automatically and emit an alarm at the end of the count-down even if your phone is switched off.

Tools 60

11. Contacts

This menu allows you to manage the names, addresses, and telephone numbers of your friends, family, and colleagues. Your Philips X Razr mobile phone has two storage areas for your contacts: the SIM phonebook and the onboard phonebook. Managing contacts in the onboard phonebook allows you to store more information (e-mail address, fax number, company name, etc.) than if you used the SIM phonebook. The space available for these fields on the SIM card may vary according to your operator or SIM card provider. If you want to be able to call your contacts while outside your home country network, enter the international prefix, country and area codes.

Create contacts

To create a new SIM/phone contact:

Enter New

Contact

, to enter main menu from

Press idle mode, and select Contacts >

New contact.

Enter contact details

Store the new contact

Note that to create a contact, you must enter at least anumber. Most of the fields are free-text, which means you can enter alph anumeric da ta using the text entry fu nctions of your mobile phone (for more information on text entry, see “Text and number entry” on page 15).

Enter the following for SIM card contacts.

•Name

•Number

Enter the following for onboard phonebook contacts:

•Name

• Telephone number

•Address

• Postal code and etc

C Save.

Press

Phonebook Options

In the phonebook, you can display the details of a contact by selecting it and pressing view/edit more details:

C Options to

61 Contacts

Options Description

View View the details of the selected

Send message Send a Text Message or

Call Call the contact.

Handsfree dial

Delete Delete the contact.

Go to Go to the website in the record (if

Set as default number

Send namecard

Copy to SIM Copy the phone entry to SIM

contact.

Multimedia Message to the

contact.

Call the contact's number in handsfree mode.

available).

Set Mobile number, Family number or Office number as the default number (if record is in the phone).

Send the selected record: Send by

SMS, Send by MMS or Send by BT.

card.

Copy to phone

Move to SIM Similar to copy, but the source

Move to phone

Set as ID image

Select multiple

Save location?

Copy the SIM entry to phone.

record on the phone will be deleted after copy.

Similar to copy, but the source record on the SIM card will be deleted after copy.

Add a picture ID to the contact. This option is only available for contacts in the onboard phonebook. If picture has been set, this option will show “Change ID image”.

Select one contact at a time or select all contacts.

Select location for the new contact: SIM card or Phone

memory.

Contacts 62

View groups

The View groups feature allows you to organize your contacts so that you can associate images and/or ringtones with a group of contacts and send messages to all the members of the group. You can create up to 10 group lists and each group list can store up to 100 contacts. From the Contacts menu, select View groups and the list of groups is displayed.

View

Select a group and press C Options > View to display the members of the group.

Group Options

Options Description

View Display the group members.

Rename Rename the group.

Add picture Add a picture to the group.

Send SMS Send an SMS to members of

agroup.

Reset Restore group to default settings.

Remove Remove a contact from the group.

Special numbers

This menu allows you to keep a list of useful numbers such as own numbers, service numbers, voicemail and SOS numbers.

Options Description

My numbers You can enter and save your own

Service numbers You can view but not edit the

Voice mail number

Emergency call

phone number.

operators' numbers.

Dial the number for your voice mail service provider.

Display emergency phone number.

63 Contacts

Quick call

This feature allows you to set your 4 preferred or most frequently dialled numbers. You can then quickly call one of them by selecting the corresponding icon or picture on the screen, thereby eliminating the need to enter and browse the contact list. You may edit a list of quick calls.

Enter Quick call menu Press

Go to the desired icon Press the navigation

Add a number to the selected location and then display all the contacts or return to the main menu.

Select a contact from the phonebook.

Confirm the added contact and add picture or Cancel.

, to enter the

main menu from idle mode and select Contacts > Quick call.

keys.

C Add

c Back

+ or -.

Press

C Done or

Press

c Cancel.

Advanced

This menu provides you with advanced features so that you can view and edit your contacts:

Options Description

Choose contacts list

Copy to SIM Copy all the phone entries to SIM

Copy to phone

Move to SIM Move all the phone entries to

Move to phone

Switch between SIM contacts,

Phone contacts or SIM & phone contacts.

card.

Copy all the SIM card entries to phone.

SIM card. This is similar to copy, except the phone entries will be deleted after copy.

Move all the SIM card entries to phone. This is similar to copy, except the SIM card entries will be deleted after copy.

Contacts 64

Send all contacts Send contact: Send by BT.

Delete all contacts

Delete all contacts.

65 Contacts

12. Profiles

Your mobile phone has been preconfigured with the following modes:

•Personal

(default)

• Headset • Home • Meeting

• Outdoors • Silent

You can activate and modify all the modes, except

Flight mode and Silent mode. These 2 modes can only

be activated and viewed.

Profile selection

To select a different profile:

Go to Profiles menu Press

Select the desired profile.

•Car •Flight

, to enter the main

menu from idle mode and select Profiles.

+ or -.

Press

Enter the Options menu

Press C Options. You may select:

• Activate: To activate the profile.

• Personalise: To modify the setting in the profile.

Personalise settings

The available options include:

Options Description

Ringer level Select from 10 volume levels.

Ringtone Select the ringtone for Incoming

Alerting type Select an alert type: Ring only,

Key sound Turn the key sound On or Off.

call, Alarm, Appointments, Messages or Cell info.

Vibrate only, Ring & vibrate, Vibrate then ring or None.

Profiles 66

Low-battery warning

Headset function Turn headset function On or Off.

Turn battery low warning alert

On or Off.

67 Profiles

13. Connectivity

Your phone allows you to connect to a variety of external devices via Bluetooth, USB, CSD, or GPRS. This menu provides you with more features to set up a connection with these external devices.

Bluetooth

Your phone supports Bluetooth wireless technology, allowing connection to a compatible Bluetooth device. The Bluetooth connection can be subjected to interference from obstructions such as walls or other electronic devices. To use Bluetooth connection, the device with which you want to establish a connection with must be support Bluetooth function. Please contact the device's manufacturer or its accompanied documentation.

Establish a Bluetooth connection

To activate, press , to enter the main menu from idle mode and then select Connectivity > Bluetooth. On the Bluetooth screen, select Activate. Next, select Search

device. When the list of devices appears, press

C to

select the device you wish to establish a connection with.

If you do not intend to use the Bluetooth feature for some time, you should deactivate it in order to conserve battery power.

Bluetooth menu

Options Description

Activate Turn Bluetooth feature On or Off

Search device Search for the external Bluetooth

devices that you can connect to.

My devices Display the bluetooth devices that

you can connect to.

Settings Select to display more features:

• My Device name

• Device displaying

• My parameters

When searching for a device, you are presented with a list of any devices discovered within the range of your Bluetooth-enabled phone. As soon as you select a device and a connection is made, you are prompted to enter a passkey in order to pair with the device. This passkey is supplied by the manufacturer of the

Connectivity 68

other Bluetooth device. Refer to its documentation for further information. The passkey feature ensures that only legitimate connections are allowed to connect either to your device or to the selected device.

USB function

Once the USB function is activated, a microSD card inserted into the phone will be recognized as a USB mass storage device on a PC without having to install any drivers

PC software

Memory card

This menu lets you uninstall or format the memory card in the phone.

69 Connectivity

14. Calls

Most options described in this chapter are operator and/or subscription dependent and require either a PIN2 code or a phone code. For more information on PIN codes, see “Security” on page 74.

Call history

This menu provides you with a list of calls you have missed, answered and made. The calls include All calls,

Missed calls, Answered calls and Outgoing calls, which

are displayed in chronological order with the most recent call at the top of the list. Select a call from one of the lists and press

Options Description

Extract number

Save Save the number if the number

Delete Delete the selected number from

C Options to access the following:

Extract the selected phone number.

is not in the Contacts list.

the list.

Call Call the selected number.

Send message

Edit Open the contacts list and edit

Send a message to the selected number. You can send by SMS or MMS.

the number if it is in the contacts list.

Clear history

This menu allows you to clear the call history in:

Outgoing/Answered/Missed/All calls. Press

to confirm deletion and

c Back to cancel deletion.

C Confirm

Call settings

This menu allows you to configure the call settings:

Options Description

Auto answer Turn Auto answer on/off.

Any key answer

Turn Any key answer on/off.

When this option is turned on, you can answer calls by pressing any keys except for the ) and c

Calls 70

Minute reminder Select On or Off. The default

setting is every 45 seconds in China and off for other countries.

Call services The available options include:

Call meters: Display the duration

of your calls and their charges:

Total incoming call, Total outgoing call and Total calls.

Call waiting: Select On or Off, or

check Status.

This feature is network/ subscription dependent.

Hide ID: Select On or Off. If you

select On, then your phone number or identity will not be displayed to the called party.

Call divert Set the following call divert

This feature is network/ subscription dependent.

Caller ID: Select to display the

identity of your caller.

This feature is network/ subscription dependent.

Charge information setting: This

option is available only when the charge information is included in your SIM card. You can view information of the current call and all recent calls. You need to enter the PIN2 code to manage total call credit, maximum total call credit and unit rate.

options: All voice calls, If out of

reach, If no reply, If busy, All data calls. You can also check Status of

your call diverts or Cancel all call diverts.

71 Calls

Call barring This menu allows you to limit the

Auto redial Once this option is activated,

IP dial Select On or Off. If you select On,

use of your phone to specific calls by preventing the reception or making of different types of calls. The types of calls you can bar are as follows:

• All outgoing calls

• All international calls

• Only here & home

• All incoming calls

• Incoming if abroad

You can also check Status of your call barring or Cancel all call barring.

when a call is unsuccessful, the phone will automatically redial the number.

you need to enter the IP number (only for Chinese mainland and Hong Kong).

Calls 72

15. Settings

You can configure your Philips X Razr mobile phone to best suit your usage preference. You can configure the following setttings: General, Sounds, Display, and

Connectivity.

Enter the menu Press

Select a settings menu

Enter the menu options

General

This menu allows you to configure some general settings:

Options Description

Active flip Select On or Off. When you select

On, you can answer an incoming

call simply by opening the flip.

, to enter the main

menu from idle mode and select Settings.

< or >.

Press

+ or -.

Press

Language Set the display language of the

phone.

Time & date Display time: Select On or Off.

When you select On, the time information will be displayed in idle screen.

Time zone: Change the time zone. Set time: Set the time. Set date: Set the date. Time format: Set the time format

as 24 hours or 12 hours.

Date format: Set the date format

as YYY/MM/DD, YYYY.MM.DD,

DD.MM.YYYY, YYYY-MM-DD or DD-MM-YYYY. Power-on time: Set a time for the

phone to be switched on. You can select On or Off. When you select

On, you need to enter the time

you want your phone to be switched on.

Power-off time: same as above.

73 Settings

Security PIN protection: Select On or Off.

When you select On, you need to enter the PIN code when you switch on the phone.

The default PIN code is 0000.

Change PIN: Modify the PIN

code.

Change PIN2: Modify the PIN2

code.

Safe guard: You can protect

important information on your phone by activating safeguard. You can also change the password for safeguard.

The default safeguard password is

0000.

Shortcuts Displays a list of shortcut features.

You can set a new shortcut key by establishing a link between a certain feature and a numeric or navigation key. You can also change or delete an existing shortcut key.

Default storage

Memory status

Default settings Restore your phone settings to the

Only buttons 2 to 9 can be assigned as shortcut keys. "

1", "*" and "#" have

" already been pre-assigned for quick access to the enter the "+" symbol, access voice mailbox, change language settings and activate Meeting profile, respectively.

Set the default storage location:

Phone memory or Memory card.

You can check the memory status of Contacts, Messaging and My

files.

default values.

0",

Settings 74

Display

You may configure your phone with different display settings:

Options Description

Wallpaper Turn wallpaper display On or Off.

Themes Select a theme for your phone.

Backlight level

Backlight duration

Greeting Turn greetings On or Off. When

Select from 4 backlight levels.

Select backlight duration fro m 60

seconds, 30 seconds and 15 seconds.

you select On, you can edit the greetings message that appears when the phone is switched on.

Sounds

You can set your phone to operate with different sound profiles. For details, see “Profiles” on page 66.

Options Description

Alert type You can select Ring only, Vibrate

Ringtones Select the ringtone for Contact

Ring volume Select from 10 volume levels.

Key sound Turn key sound On or Off.

Shutter sound

Lowbattery warning

only, Ring & vibrate, Vibrate then ring or None.

calls, Calendar, Messages, Cell info, Alarm and Other calls.

Select from one of the shutter sounds.

Turn warning On or Off.

75 Settings

Connectivity

Network settings

The network name will be displayed on the idle screen. If the phone is not able to identify the network name, it will display the country code and the network code of the unknown network.

Select network

It will vary according to the search mode you have selected. If you select Automatic the network will be searched automatically. If you select Manual, the search will commence only when you confirm to start searching.

Search mode

You can select Automatic or Manual.

Preferred Network

Preferred network list is stored in the SIM card. It specifies the priority by which your phone will register to the available network during automatic registration.

In idle mode, press , to enter the main menu.

Select Settings > Connectivity > Network settings > Preferred network and press

Press , or C OK to enter the preferred network list. The most preferred network will be at the top of the list.

Press +/- to select a certain network and press

, or C Select.

You will be given options to Delete network, Add

available network, Add existing network and Add network code.

Browser

Various parameters relative to browser can be set under this option, including WAP parameters and Push message.

WAP profiles

You can set up to 5 groups of WAP profiles. You can can activate and use one of the profiles. At the same time, you can edit or directly connect to the address. Select Edit to access the following settings:

• Name: A name to identify the server.

• IP address: The numeric address of the server in nnn.nnn.nnn.nnn format.

• Port: The port number on the server. The number is usually 9201.

• Homepage: The URL of the message server.

Settings 76

• Linger time: The duration your phone stays connected to the WAP.

• Connection: Select GPRS or CSD connection.

• CSD profiles: Select a predefined CSD setting.

• GPRS profiles: Select a predefined GPRS setting.

77 Settings

Icons & symbols

In idle mode, several symbols can be displayed simultaneously on the main screen.

Silent - Your phone will not ring when there is

an incoming call.

Vibra - Your phone will vibrate when there is

an incoming call.

GPRS attach - Your phone is connected to the

GPRS network.

SMS message / MMS message / Voice mail -

You have received a new text message / multimedia message / voice mail.

Battery - The bars indicate the battery level

(3 bars = full battery , 1 bar = low battery).

SIM memory full - The SIM card’s memory is

full. Delete items to store new ones.

Call divert Unconditional to number / Call divert to voice mailbox

incoming voice calls will be diverted to a number / voice mail.

GSM Network: your phone is connected to

aGSM network.

Reception quality:

better the reception is.

- All your

the more bars are shown the

If the network symbol isn’t displayed, the network is currently not available. You may be in a bad reception area; moving to a different location may help.

Alarm clock is activated.

Roaming - Displayed when your phone is

registered to a network other than your own (especially when you are abroad).

SMS full - Memory for messages is full. Delete

old messages to receive new ones.

Phone memory full - The phone’s memory is

full. Delete items to store new ones.

Icons & symbols 78

Precautions

Radio Waves

Your cellular mobile phone is a low power radio transmitter and receiver. When it is

operating, it sends and receives radio waves.

The radio waves carry your voice or data signal to a base station that is connected to the telephone network. The network controls the power at which the phone transmits.

• Your phone transmits/receives radio waves in the

GSM frequency (900 / 1800 MHz).

• The GSM network controls transmission power

(0.01 to 2 watts).

• Your phone complies with all relevant safety

standards.

• The CE mark on your phone shows compliancy

with European electromagnetic compatibility (Ref. 89/336/EEC) and low voltage directives (Ref. 73/

23/EEC). Your cellular mobile phone is your responsibility. To avoid damage to yourself, to others or to the phone itself, read and follow all the safety instructions and make them known to anyone borrowing your phone. Furthermore to prevent unauthorised use of your phone:

Keep your phone in a safe place and keep it out of small children's reach. Avoid writing down your PIN code. Try to

remember it instead. Switch off the phone and remove the battery if you are going to leave it unused for a long time. Change your PIN code after purchasing the phone and to activate call restriction options.

The design of your phone complies with all applicable laws and regulations. However your phone may cause interference

with other electronic devices. Consequently you should follow all local recommendations and regulations when using your cellular phone both at home and when away. Regulations on the use

of cellular phones in vehicles and aircraft are particularly stringent.

Public concern has been focused for some time on the possible health risks for users of cellular phones. The current research on radio wave technology, including the GSM technology, has been reviewed and safety standards have been drawn up to ensure protection from exposure to radio wave energy. Your cellular telephone complies with all applicable safety standards and the Radio Equipment and

Telecommunications Terminal Equipment Directive 1999/5/EC.

Always switch off your phone...

Inadequately protected or sensitive electronic equipment may be affected by radio energy. This

interference can lead to accidents.

Before boarding an aircraft and/or when packing the phone in your luggage: the use

of mobile phones in an aircraft may be dangerous for the operation of the aircraft, disrupt the mobile phones network and may be illegal.

In hospitals, clinics, other health care

centres and anywhere else where you may be

in the close vicinity of medic

In areas with a potentially explosive

atmosphere (e.g. petrol stations and also

areas where the air contains dust particles,

such as metal powders). In a vehicle transporting flammable products (even if the vehicle is parke d) or a vehicle powered by liquefie d petroleum gas (LPG), check first that the vehicle complies with the applicable safety rules.

al equ

ipment.

In areas where you are requested to turn off radio transmitting devices, such as quarries or other areas where blasting operations are in progress.

Check with the vehicle manufacturer that electronic equipment used in your vehicle will not be affected by radio energy.

Pacemakers

If you have a pacemaker:

• Always keep the phone more than 15 cm from your pacemaker when the phone is switched on, in order to avoid potential interference.

• Do not carry the phone in a breastpocket.

• Use the ear opposite to the pacemaker to minimise the potential interference.

• Switch off your phone if you suspect that interference is taking place.

Hearing aids

If you are a user of a hearing aid, consult your physician and hearing aid manufacturer to learn whether your particular device is susceptible to cellular phone interference.

Improved performance

In order to improve the performance of your phone, reduce radio energy emission, reduce battery consumption and ensure safe operation adhere to the following guidelines:

For the optimal and satisfactory operation of the phone you are recommended to use the phone in the normal operating position (when not using in hands-free mode or with a hands-free accessory).

• Do not expose your phone to extreme temperatures.

• Treat the phone with care. Any misuse will void the International Guarantee.

• Do not immerse the phone in any liquid; if your phone is damp, switch it off, remove the battery and let them dry for 24hrs before using them again.

• To clean the phone, wipe it with a soft cloth.

• Placing and receiving calls consumes the same amount of battery energy. However, the mobile consumes less energy in idle screen when kept in the same place. When in idle screen and while you are moving, your phone consumes energy to transmit updated location information to the network. Setting the backlight for a shorter period of time as well as avoiding unnecessary navigating

in the menus will also help to save the battery’s energy for longer phoning and stand-by performances.

Battery information

• Your phone is powered by a rechargeable battery.

• Use specified charger only.

• Do not incinerate.

• Do not deform or open the battery.

• Do not allow metal objects (such as keys in your pocket) to short circuit the battery contacts.

• Avoid exposure to excessive heat (>60° C or 140° F), moisture or caustic environments.

You should only use Philips authentic battery and accessories, as the use of any other accessories may damage your phone and may be dangerous, and will make all guarantees for your Philips phone null and void. The use of an incorrect type of battery

may also cause an explosion. Make sure damaged parts are replaced immediately by a qualified technician and that they are replaced with genuine Philips replacement parts.

Do not use your phone while driving

Speaking on the telephone while driving lowers your concentration, which can be dangerous. Adhere to the following guidelines:

• Give your full attention to driving. Pull off the road and park before using the phone.

• Respect the local regulations in countries where you drive and use your GSM phone.

• If you want to use your phone in a vehicle, install the hands-free car kit which is designed for that purpose.

• Ensure that your phone and car kit do not block any air bags or other security devices fitted in your car.

The use of an alarm system to operate a vehicle's light or horn to indicate incoming phone calls is prohibited on public roads in some countries. Check local regulations.

EN 60950 Norm

In hot weather or after prolonged exposure to the sun (e.g., behind a window or a windscreen), the

temperature of your phone's casing might increase, especially when featuring a metallic finish. Be very careful in this case when picking up your phone and also avoid using it with an ambient temperature over 40° C.

Environmental care

Remember to observe the local regulations regarding the disposal of the packaging materials, exhausted batteries and old phone

and please promote their recycling. Philips has marked the battery and packaging with standard symbols designed to promote the recycling and appropriate disposal of your eventual waste.

The battery should not be disposed of with general household waste.

The labelled packaging material is recyclable.

A financial contribution has been made to the associated national packaging recovery and recycling system. (e.g. EcoEmballage in France).

The plastic material is recyclable (also identifies the type of plastic).

Troubleshooting

The phone does not switch on

Remove/reinstall the battery. Then charge the phone until the battery icon stops scrolling. Unplug from charger and try to switch the mobile on.

Your phone doesn’t return to the idle screen

Long press the hangup key or switch off the phone, check that the SIM card and the battery are installed correctly and switch it on again.

The network symbol is not displayed

The network connection is lost. Either you are in a radio shadow (in a tunnel or between tall buildings) or you are outside the network coverage area. Try from another place, try to reconnect to the network (especially when abroad), check that the antenna is in place if your mobile has an external antenna, or contact your network operator for assistance/ information.

The display doesn’t respond (or the display responds slowly) to key presses

The display responds more slowly at very low temperatures. This is normal and does not affect the operation of the phone. Take the phone to a warmer

place and try again. In other cases please contact your phone supplier.

Your battery seems to over heat

You might be using a charger that was not intended for your phone. Make sure you always use the Philips authentic accessory shipped with your phone.

Your phone doesn’t display the phone numbers of incoming calls

This feature is network and subscription dependent. If the network doesn’t send the caller’s number, the phone will display your operator for detailed information on this subject.

Call 1

or Withheld instead. Contact

You can’t send text messages

Some networks don’t allow message exchanges with other networks. First check that you entered the number of your SMS centre, or contact your operator for detailed information on this subject.

You can’t receive and/or store pictures

A picture may not be accepted by your mobile phone if it is too large, if its name is too long, or if it doesn’t have the correct file format.

You have the feeling that you miss some calls

Check your call divert options.

The display shows INSERT SIM

Check that the SIM card has been inserted in the right position. If the problem remains, your SIM card may be damaged. Contact your operator.

When attempting to use a feature in the menu, the mobile displays NOT ALLOWED

Some features are network dependent. They are only available, therefore, if the network or your subscription supports them. Contact your operator for detailed information on this subject.

Your phone is not charging

If your battery is completely flat, it might take several minutes of pre-charge (up to 5 minutes in some cases) before the charging icon is displayed on the screen.

Philips Authentic

Accessories

Some accessories, such as a standard battery and a charger, are included as standard accessories in your mobile phone package. Additional accessories may also be provided or sold separately. Package contents may therefore vary.

To maximise the performance of your Philips mobile phone and not to void the warranty, always purchase Philips Authentic Accessories that are specially designed for use with your phone. Philips Consumer Electronics cannot be held liable for any damage due to use with non authorised accessories.

Charger

Charges your battery in any AC outlet. Small enough to carry in a briefcase/handbag.

Data connect kit

Provides easy data connection to your Philips mobile phone. The USB cable enables high-speed communication between your phone and your computer. The provided software allows you to download pictures and melodies and to synchronize your contacts and appointments.

Trademark Declaration

JAVA is a trademark of Sun Microsystems, Inc.

is a trademark of Tegic

Communications Inc.

Tegic Euro. Pat.

App. 084246 3

FCC Regulations:

This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

87 FCC Regulations:

RF Exposure Information (SAR)

THIS MODEL PHONE MEETS THE GOVERNMENT'S REQUIREMENTS

This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF)

energy set by the Federal Communications Commission of the U.S. Government.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard

operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested

frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the

phone while operating can be well below the maximum value. This is because the phone is designed to operate at

multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a

wireless base station antenna, the lower the power output.

The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is 0.076 W/kg

and when worn on the body, as described in this user guide, is 0.284 W/kg (Body-worn measurements differ

among phone models, depending upon available enhancements and FCC requirements.)

While there may be differences between the SAR levels of various phones and at various positions, they all meet

the government requirement.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as

in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the

FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC

ID: RXSCT9A9R.

For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use with an

accessory that contains no metal and the positions the handset a minimum of 1.5 cm from the body. Use of other

enhancements may not ensure compliance with FCC RF exposure guidelines. If you do no t use a body-worn

accessory and are not holding the phone at the ear, position the handset a minimum of 1.5 cm from your body

when the phone is switched on.

RF Exposure Information (SAR) 88

FOR EXPOSURE TO RADIO WAVES.

Limited warranty

1. What Does This Limited Warranty Cover?

Philips warrants to the original retail purchaser (“Consumer” or “You”) that this Philips cellular product and all accessories originally provided by Philips in the sales package (“Product”) are free from defects in materials, design and workmanship under normal use in accordance with the operating instructions and pursuant to the following terms and conditions. This limited warranty extends only to the Consumer for Products purchased and used in the original country of purchase. The limited warranty is valid only in Philips’ intended country of sales of the product.

2. How Long is The Limited Warranty Period?

The limited warranty period for the Product extends for ONE (1) YEAR from the date of purchase of the Product, documented by valid proof of purchase. The limited warranty for original Philips rechargeable battery extends for six (6) months from the date of purchase.

3. What Will Philips Do if The Product is Not Free From Material Defects in Materials and

Workmanship During The Limited Warranty Period?

During the limited warranty period, Philips or its authorized service representative will, at its option either repair or replace, without charge for parts or labour, a materially defective Product with new or refurbished parts or Product and return such repaired or replaced Product to the Consumer in working condition. Philips will retain defective parts, modules or equipment.

Repaired or replaced Product will be covered by this limited warranty for the balance of the original limited warranty period or ninety (90) days from the date of repair or replacement whichever is longer. Repair or replacement of Product, at Philips’ option is your exclusive remedy.

4. What is Not Covered By This Limited Warranty?

This limited warranty does not cover::

a) Product that has been subjected to misuse,

accident, shipping or other physical damage, improper installation, abnormal operation handling, neglect, inundation, fire, water or other liquid intrusion; or

b) Product that has been damaged due to

repair, alteration, or modification by anyone not authorized by Philips; or

c) Product that has reception or operation

problems caused by signal conditions, network reliability or cable or antenna systems; or

d) Product defects or problems caused by uses

with non-Philips products or accessories; or

e) Product which warranty/quality stickers,

product serial number or electronic serial number has been removed, altered or rendered illegible; or

f) Product purchased, used, serviced, or

shipped for repair from outside the original country of purchase, or used for commercial or institutional purposes (including but not limited to Products used for rental purposes); or

g) Product returned without valid proof of

purchase or which proof of purchase has been altered or is illegible.

h) Normal wear and tear or Force Majeure.

5. How Do You Get Warranty Service?

a) Return the Product to an authorized service

center of Philips. You may contact the local Philips office for the location of the nearest authorized service center.

b) The SIM card must be removed from the

Product before it is given to Philips. Philips assumes no liability for damaged or loss of the SIM card or the data contained therein.

c) If the Product failure is not covered by this

limited warranty, or this limited warranty is inapplicable, void or invalid due to any terms and conditions stated herein, the Consumer will be charged for the cost of repair or replacement of the Product and all other related cost incurred in repairing or replacing the Product.

d) IMPORTANT - you are required to return

the Product together with a valid proof of purchase which must identify the point of purchase, date of purchase, Product model and Product serial number clearly.

6. Other Limitation: This Warranty is The Entire Agreement.

EXCEPT FOR THE EXPRESS WARRANTIES SET FORTH ABOVE AND THOSE IMPLIED BY LAW AND WHICH CANNOT BE EXCLUDED OR MODIFIED BY AGREEMENT, PHILIPS PROVIDES NO OTHER WARRANTY WHETHER EXPRESS OR IMPLIED (WHETHER BY STATUTE, UNDER THE OPERATION OF LAW OR OTHERWISE) AND SPECIALLY DISCLAIMS

ANY WARRANTY OF SATISFACTORY QUALITY MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. PHILIPS’ TOTAL LIABILITY FOR DAMAGES RELATING TO OR ARISING OUT OF THE PURCHASE OR USE OF THE PRODUCT, REGARDLESS OF THE TYPE OR CAUSE OF SUCH DAMAGE OR THE FORM OR CHARACTERISATION OF THE CLAIM ASSERTED (E.G. CONTRACT OR TOPIT), SHALL NOT EXCEED THE ORIGINAL PURCHASE PRICE PAID FOR THE PRODUCT.

HOWEVER IN NO EVENT SHALL PHILIPS BE LIABLE FOR ANY PUNITIVE, SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED TO THE LOSS OF USE, LOSS OF TIME, INCONVENIENCE, COMMERIAL LOSS, LOST PROFITS, LOST BUSINESS OPPORTUNITIES, COST OF SUBSTITUTION OF GOODS OR SERVICES, INVESTMENTS, DAMAGE TO GOODWILL OR REPUTATION, OR LOSS OF DATA AND CLAIMS BY THIRD PARTIES) RESULTING FROM PURCHASE OR USE OF THE PRODUCT, TO THE FULLEST EXTENT ALLOWED BY LAW, WHETHER OR NOT PHILIPS HAS BEEN

ADVISED OF THE POSSIBILTY OF SUCH DAMAGES. THESE LIMITATIONS SHALL APPLY NOTWITHSTANDING THE FAILURE OF THE ESSENTIAL PURPOSE OF ANY LIMITED REMEDY.

This limited warranty represents the complete and exclusive agreement between the Consumer and Philips with respect to this cellular Product and it supercedes all prior agreements between the parties, oral or written, and all other communications between the parties relating to the subject matter of this limited warranty. No carrier, retailer, agent, dealer, employee, thereof, or employee of Philips is authorized to make modifications to this limited warranty and you should not rely on any such representation.

This limited warranty does not affect the Consumer’s statutory rights under applicable national laws in force.

CEC Wireless R and D CT9A9R Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
