Cecomp F20B, F20BBL, F20BN, F20BNBL, F22B Instruction Manual

...

Download

Page 1

Cecomp® Battery Powered Digital Pressure Gauges w. Memory Options & Selectable Units F20B, F22B

Ranges and Resolution

See table below for standard ranges and units Resolution is fixed for each engineering unit

Accuracy

Accuracy includes linearity, hysteresis, repeatability Standard accuracy: ±0.25% of full scale ±1 least significant digit HA accuracy option: ±0.1% FS ±1 LSD, see ranges for availability Sensor hysteresis: ±0.015% FS, included in accuracy Sensor repeatability: ±0.01% FS, included in accuracy

Display

3 readings per second nominal display update rate 4 digit LCD, 0.5" H and 5 character 0.25" H alphanumeric BL models: red LED backlight

Batteries, Battery Life

B: 2 AA alkaline, approx. 2000 hours BL: 2 AA alkaline, approx. 150 to 1500 hours depending on backlight usage

Controls and Functions

Three button keypad: Zero/clear, on/off, memory BL models: Backlight active for 1 minute (user configurable)

F20B Memory

-M4: 4 peak reading memory, settable to MEM 1 ~ MEM 4 or 4 wheel designations: LF, RF, LR, RR

-M8: 8 peak reading memory, MEM 1 ~ MEM 8

F22B Min/Max Memory

Minimum and/or maximum readings stored in memory, readings cleared or stored at shutoff. User configurable.

Auto Shutoff

User selectable 1 minute to 8 hours or front button on/off Factory default 5 minutes, unless other time is specified

Sensor Ranges and Engineering Units ‡ -HA option not available Consult factory for special units

3 psig ‡

3PSIG 6INHGG 85INH2OG 50ZING 210GCMG 150MMHGG 150TORRG 200MBARG 200CMH2OG 2000MMH2OG 7FTH2O 20KPAG

5 psig ‡

5PSIG 10INHGG 140INH2OG 80ZING 350GCMG 260MMHGG 260TORRG 350MBARG 350CMH2OG 3500MMH2OG 12FTH2O 35KPAG

15 psia Res

15PSIA 30INHGA 400INH2OA 240ZINA 1000GCMA 760MMHGA 760TORRA 1000MBARA 1000CMH2OA 100KPAA

0.1MPAA 1BARA 1KGCMA 1ATMA

15 psig vac ‡

15PSIVAC 30INHGVAC 400INH2OVAC 240ZINVAC 1000GCMVAC 760MMHGVAC 760TORRVAC 1000MBARVAC 1000CMH2OVAC

Res

15 psig vac ‡

100KPAVAC

.001

0.1MPAVAC

.001

1BARVAC

1KGCMVAC

.01

1ATMVAC

.1 .1 .1 .1 .1 1 .001 .01

Res

.001 .01 .1 .1 .1 .1 .1 .1

15 psig Res

15PSIG 30INHGG 400INH2OG 240ZING 1000GCMG 760MMHGG 760TORRG 1000MBARG 1000CMH2OG 35FTH2O 100KPAG

0.1MPAG 1BARG 1KGCMG 1ATMG

.1 ±15 psig ‡

±15PSIG

–30INHG/15PSIG

.01

±30INHGG

.01

±400INH2OG ±240ZING

.01

±1000GCMG

.01

±760MMHGG

±760TORRG

±1000MBARG

±1000CMH2OG

±100KPAG

±0.1MPAG

±1BARG

±1KGCMG

±1ATMG

.0001 .001 .001 .001

Res

.01 .01 .1 .1 1 .1 .1 1 1

30 psia Res

30PSIA 60INHGA 850INH2OA 480ZINA 2100GCMA 1600MMHGA 1600TORRA 2000MBARA 2100CMH2OA 200KPAA

0.2MPAA 2BARA

Res 30 psia Res

2KGCMA

2ATMA

.0001 .001

30PSIG

.001

60INHGG

.001

850INH2OG 480ZING

.01

2100GCMG

.01

1600MMHGG

1600TORRG

2000MBARG

2100CMH2OG

70FTH2O

200KPAG

0.2MPAG

2BARG

.01

2KGCMG

2ATMG

.0001 .001

60PSIG

.001

120INHGG

.001

1660INH2OG

Res

960ZING

.01

4200GCMG

.01

3100MMHGG

.01

3100TORRG

4100MBARG

4200CMH2OG

140FTH2O

400KPAG

0.4MPAG

4BARG

4KGCMG

4ATMG

.0001 .001

100PSIA

.001

200INHGA

.001

2770INH2OA 1600ZINA

.01

7000GCMA

.01

5200MMHGA

5200TORRA

7000MBARA

7000CMH2OA

700KPAA

0.7MPAA

7BARA

7KGCMA

7ATMA

.0001 .001

Calibration

Zero button for gauge reference ranges Pass code protected calibration via keypad Non-interactive zero, span, and linearity, ±10% of range

Weight

Gauge: 9 ounces (approximately) Shipping: 1 pound (approximately)

Materials

Standard: Extruded aluminum case, epoxy powder coated, ABS/ polycarbonate bezel, front and rear gaskets, polycarbonate label. Optional -MC aluminum bezel. NEMA 4X: ABS/polycarbonate case, rear gasket, polycarb. label

Connection and Material

1/4" NPT male fitting All wetted parts are 316L stainless steel

Overpressure, Burst, Vacuum Service

3000 psig sensor: 5000 psig overpressure 5000 psig sensor: 7500 psig overpressure All others: 2 X pressure range overpressure

Burst pressure: 4 X sensor pressure rating, or 10,000 psi, whichever is less

Vacuum service: 15 psia, 15 psig, ±15 psig, 30 psia, 100 psia, 100 psig, 200 psig

Environmental Temperatures

Storage temperature: –40 to 203°F (–40 to 95°C) Operating: –4 to 185°F (–20 to 85°C) Compensated range: 32 to 158°F (0 to 70°C)

Dimensions

See next page

.001 .001

30 psig Res

.01 .01 1 .1 1 1 1 1 1 .01 .1 .0001 .001 .001 .001

60 psig Res

.01 .1 1 1 1 1 1 1 1 .1 –15V200 psig ‡ .1 .0001 .001 .001 .001

100 psia Res

.1 .1 1 1 1 1 1 1 1 .1 .0001 .001 .001 .001

–15V100psig ‡

–15V100PSIG –30INHG/100PSIG –30V200INHGG –400V2770INH2OG –240V1600ZING –760V5200MMHGG –760V5200TORRG –100V700KPAG –0.1V0.7MPAG –1V7BARG –1V7KGCMG –1V7ATMG

100 psig Res

100PSIG 200INHGG 2770INH2OG 1600ZING 7000GCMG 5200MMHGG 5200TORRG 7000MBARG 7000CMH2OG 230FTH2O 700KPAG

0.7MPAG 7BARG 7KGCMG 7ATMG

–15V200PSIG –30INHG/200PSIG –30V400INHGG –400V5500INH2OG –240V3200ZING –100V1400KPAG –0.1V1.4MPAG –1V14BARG –1V14KGCMG –1V 14ATMG

200 psig Res

200PSIG 400INHGG 5500INH2OG 3200ZING 480FTH2O 1400KPAG

1.4MPAG 14BARG 14KGCMG 14ATMG

Res 300 psig Res

300PSIG

610INHGG

4800ZING

700FTH2O

2000KPAG

2MPAG

20BARG

20KGCMG

20ATMG

.001 .01

500PSIG

.01

1020INHGG

.01

1150FTH2O 3500KPAG

3.5MPAG

35BARG

35KGCMG

35ATMG

1 1

1000PSIG

2040INHGG

2300FTH2O

7000KPAG

7MPAG

70BARG

.0001

70KGCMG

.001

70ATMG

.001 .001

2000PSIG

Res

4070INHGG

4600FTH2O

14MPAG

140BARG

140KGCMG

140ATMG

1 .001

3000PSIG

.01

6100INHGG

.01

6900FTH2O

.01

20MPAG 200BARG

200KGCMG

200ATMG

1 1

5000PSIG

35MPAG

350BARG

.001

350KGCMG

.01

340ATMG

.01 .01

.1 .1 1 .1 1 .001 .01 .01 .01

500 psig Res

.1 1 1 1 .001 .01 .01 .01

1000 psig Res

1 1 1 1 .0001 .01 .01 .01

2000 psig Res

1 1 1 .01 .1 .1 .1

3000 psig Res

1 1 1 .01 .1 .1 .1

5000 psig Res

1 .01 .1 .1 .1

O ±0.25% Test Gauge Accuracy, ±0.1% Optional O 316L Stainless Steel Wetted Parts O Keypad Selectable Units and Auto Shutoff Times O Store Readings in Memory

HHHHHH HHHHH HHHHHH HHHHH HHHHHH HHHHH HHHHHH HHHHH HHHHHH

Made in USA

F20BN, F22BN

NEMA 4X

Quick Link: cecomp.com/bat

How to Specify Housing Backlit Memory

F20B range - M4 - options F20BBL range - M4 - options Yes F20BN range - M4 - options F20BNBL range - M4 - options Yes F20B range - M8 - options F20BBL range - M8 - options Yes F20BN range - M8 - options F20BNBL range - M8 - options Yes F22B range - options F22BBL range - options Yes F22BN range - options F22BNBL range - options Yes

Standard

NEMA 4X

Standard

NEMA 4X

Standard

NEMA 4X

Range—See table at left. Select a range code for default units. Please specify if vacuum gauge requires a minus sign.

psi = PSI inHg = INHG oz/in2 = ZIN inH2O = INH2O ftH2O = FTH2O mmHg = MMHG

G gauge reference pressure

torr = TORR mmH2O = MMH2O kg/cm2 = KGCM g/cm2 = GCM kPa = KPA MPa = MPA

A absolute reference

VAC gauge reference vacuum

Options—add to end of model number. See price list for details.

High accuracy, ±0.1% FS ±1 LSD. See range table.

Panel mount, 4.1" x 4.1", n/a NEMA 4X Sealed housing, CC for high-humidity food processing

applications. NEMA models in absolute reference only.

Metal front cover instead of plastic, n/a NEMA 4X

Case bottom stiffener plate, n/a NEMA 4X

Moisture resistant circuit board conformal coating

Top port, gauge port on top of case, n/a NEMA 4X

Surface mount plate, n/a NEMA 4X

Calibration data; 5 test points and date

NIST traceability documentation, 5 points and date

Top gauge port. Primarily used with tire pressure applications. Not available with NEMA 4X models.

Accessories—order separately

High visibility orange rubber boot protects gauge for portable applications. Not available with NEMA 4X models.

SCR14SS

Filter screen fitting keeps debris out of gauge sensor. For food vacuum packaging applications. 303SS body, 100 micron 304SS screen.

CON14SS

Quick connector to install or remove gauge without tools. 304 stainless steel, urethane seal.

mbar = MBAR bar = BAR cmH2O = CMH2O atm = ATM

F20B, F22B

4 max

reading

8 max

reading

Min/max

CECOMP Div. of

ABSOLUTE PROCESS INSTRUMENTS

1220 American Way Libertyville, IL 60048

800-942-0315

cecomp.com

Page 2

Installation Precautions, Ranges and Engineering Units F20B, F22B

Ranges and Selectable Units

Range Codes

The gauge model range code indicates the default range. Alternate

default engineering units may be ordered.

Sensor Range

and Units

–14.7 to 15.0 psig

–29.9 inHg to

15.0 psig –29.9 inHg to

100.0 psig –29.9 inHg to

200.0 psig 0 to 3.000 psig 3.000 20.68 206.8 .2068 .2041 .2109 210.9 2109 210.9 48.00 6.921 83.0 155.1 155.1 6.108 0 to 5.000 psig 5.000 34.47 344.7 .3447 .3402 .3515 351.5 3515 351.5 80.0 11.54 138.4 258.6 258.6 10.18

15.00 to 0 psi abs 15.00 abs 103.4 abs .1034 abs 1034 abs 1.034 abs 1.021 abs 1.055 abs 1055 abs 1055 abs 240.0 abs 34.61 abs 415.1 abs 775.7 abs 775.7 abs 30.54 abs 0 to 14.70 psig vac 14.70 vac 101.3 vac .1013 vac 1013 vac 1.013 vac 1.000 vac 1.033 vac 1033 vac 1033 vac 235.1 vac 33.90 vac 406.8 vac 760 vac 760 vac 29.92 vac 0 to 15.00 psig 15.00 103.4 .1034 1034 1.034 1.021 1.055 1055 1055 240.0 34.61 415.1 775.7 775.7 30.54

30.00 to 0 psi abs 30.00 abs 206.8 abs .2068 abs 2068 abs 2.068 abs 2.041 abs 2.109 abs 2109 abs 2109 abs 480.0 abs 69.21 abs 830 abs 1551 abs 1551 abs 61.08 abs 0 to 30.00 psig 30.00 206.8 .2068 2068 2.068 2.041 2.109 2109 2109 480.0 69.21 830 1551 1551 61.08 0 to 60.00 psig 60.00 413.7 .4137 4137 4.137 4.083 4.218 4218 4218 960 138.4 1660 3103 3103 122.2

100.0 to 0 psi abs 100.0 abs 689.5 abs .6895 abs 6895 abs 6.895 abs 6.805 abs 7.031 abs 7031 abs 7031 abs 1600 abs 230.7 abs 2767 abs 5171 abs 5171 abs 203.6 abs 0 to 100.0 psig 100.0 689.5 .6895 6895 6.895 6.805 7.031 7031 7031 1600 230.7 2767 5171 5171 203.6 0 to 200.0 psig 200.0 1379 1.379 13.79 13.61 14.06 3200 461.4 5534 407.2 0 to 300.0 psig 300.0 2068 2.068 20.68 20.41 21.09 4800 692.1 610.8 0 to 500.0 psig 500.0 3447 3.447 34.47 34.02 35.15 1154 1018 0 to 1000 psig 1000 6895 6.895 68.95 68.05 70.31 2307 2036 0 to 3000 psig 3000 20.68 206.8 204.1 210.9 6921 6108 0 to 5000 psig 5000 34.47 344.7 340.2 351.5

Alphanumeric display

Zero display (gauge reference only)

Clear min/max, Up arrow for setup

Power button

Turn on backlight (BL versions)

Display min/max readings

Down arrow for setup

psi kPa MPa mbar bar atm kg/cm2g/cm2mmH2O cmH2O oz/in2ftH2O inH2O mmHg torr inHg

–14.7 to

15.0 –14.7 to

100.0 –14.7 to

200.0

Low battery symbol

4 digit display

–101.3 to

103.4 –101.3 to

103.4 –101 to

690 –101 to

1379

–.1013 to .1034

–.101 to .690

–.101 to

1.379

–1013 to 1034

XXXXX

Zero/Clear Memory

¼" NPT

3.38"

Standard

3.5" NEMA 4X

Installation Precautions

4 Read these instructions before using the gauge. Configuration may

be easier before installation. Contact the factory for assistance.

4 These products do not contain user-serviceable parts, except

batteries. Contact us for repairs, service, or refurbishment.

4 Gauges must be operated within specified ambient temperature ranges. 4 Outdoor or wash down applications require a NEMA 4X gauge or

installation in a NEMA 4X housing.

4 Use a pressure or vacuum range appropriate for the application. 4 Use fittings appropriate for the pressure range of the gauge. 4 Due to the hardness of 316 stainless steel, it is recommended that

a thread sealant be used to ensure leak-free operation.

4 For contaminated media use an appropriate screen or filter to

keep debris out of gauge port.

4 Remove system pressures before removing or installing gauge. 4 Install or remove gauge using a wrench on the hex fitting only. Do

not attempt to turn gauge by forcing the housing.

4 Good design practice dictates that positive displacement liquid

pumps include protection devices to prevent sensor damage from pressure spikes, acceleration head, and vacuum extremes.

p Avoid permanent sensor damage! Do not apply vacuum to non-

vacuum gauges or hydraulic vacuum to any gauges.

p Avoid permanent sensor damage! NEVER insert objects into

gauge port or blow out with compressed air.

 Gauges are not for oxygen service. Accidental rupture of sensor

diaphragm may cause silicone oil inside sensor to react with oxygen.

Cecomp maintains a constant effort to upgrade and improve its products. Specifications are subject to change without notice. See cecomp.com for latest product information. Consult factory for your specific requirements.

WARNING: This product can expose you to chemicals including lead, nickel and chromium, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Selectable Ranges

Engineering units may be changed to any of those listed in the same row as shown in the table below.

–1.013 to

1.034 –1.013 to

1.034 –1.01 to

6.90 –1.01 to

13.79

–1.000 to

1.021 –1.000 to

1.021 –1.00 to

6.81 –1.00 to

13.61

2.88"

–1.033 to

1.055 –1.033 to

1.055 –1.03 to

7.03 –1.03 to

14.06

Standard

–1033 to 1055

3.0"

0.75"

Power-Up and Normal Operation

Your gauge is ready to use. It was factory calibrated just prior to shipment with batteries installed.

Press and hold the center power button for approximately 1 second. The display is tested.

The full-scale range in the factory default units is indicated. If the units were changed by the user, then the full scale range in the selected engineering units is displayed.

The display test is briefly shown again.

The actual pressure and units are displayed. The gauge is ready for use and readings are updated approximately 3 times per second

For gauge reference models occasional flashing of the minus sign is normal and indicates the gauge is at zero pressure. Absolute gauges only display zero at full vacuum.

Display Backlighting (BL Models Only)

Display backlighting can be turned on by momentarily pressing the power button whenever the gauge is on. This also restarts the auto shutoff timer.

F20B: The backlighting will turn on for 1 minute and then automatically shut off.

F22B: The factory default on-time is 1 minute, but the setup procedure allows setting it to 1 to 255 minutes, or to 0 to disable display backlighting.

The red LED display backlighting will not be apparent under bright lighting conditions.

1.65"

–1033 to 1055

NEMA 4X

2.0"

XXXXX

Zero/Clear Memory

200.0

psig

full

scale

XXXXX

0.0

psig

Conversion

Engineering unit conversions are calculated from the factory default unit to the newly selected units.

–235.1 to

240.0 –235.1 to

240.0 –235 to

1600 –235 to

3200

–33.90 to

34.61 –33.90 to

34.61 –33.9 to

230.7 –33.9 to

461.4

–407 to 415

–407 to 2767

–407 to 5534

–760 to 7767

–760 to 776

–760 to 5171

–760 to 776

–760 to 5171

–29.92 to

30.54 –29.92 to

30.54 –29.9 to

203.6 –29.9 to

407.2

Error or Out-of-Range Indications

Attempting to zero the gauge with pressure greater than approximately 3% of full-scale pressure or vacuum will result in an error condition. The display will alternately indicate Err 0 and the actual pressure. The gauge must be powered down to reset the error condition.

If excessive vacuum is applied to a pressure-only gauge, the display will indicate

-Err until the vacuum is released. Applying vacuum to a pressure-only gauge can damage the pressure sensor.

If 112.5% over range pressure is applied , an out-of-range indication of 1 – – – or 1.–.–.– will be displayed depending on model.

- or -

Zero the Display

This applies to gauge reference models only. Absolute reference gauges do not use the zero feature since they read atmospheric pressure under normal conditions.

Be sure the gauge is in the normal operating mode. The gauge port must be exposed to normal atmospheric pressure with no pressure or vacuum applied.

Press and hold the Zero/Clear button.

Continue to press the Zero/Clear button until oooo is displayed then release the button.

The gauge in now zeroed.

Occasional flashing of the minus sign with zero pressure/vacuum is normal.

The stored zero correction is erased when the gauge is shut off.

0. I

psig

Zero/Clear Memory

hold

Zero/Clear Memory

0.0

psig

Shutoff

The auto shutoff timer starts at power up and resets whenever any button is pressed. The default time is 5 minutes, but can be set for a variety of times. If on/off operation is selected, the gauge will stay on until manually shut off or the batteries are depleted. Turn gauge off when not in use to conserve battery life.

When an auto shutoff time is used, the display indicates OFF five seconds prior to shutoff. Press the power button to keep the gauge on.

To shut the gauge off manually, press and hold (about 5 seconds) the center power button until OFF is displayed.

Zero/Clear Memory

hold

rrE

0rrE

oooo

FFO

CECOMP Div. of

ABSOLUTE PROCESS INSTRUMENTS

1220 American Way Libertyville, IL 60048

800-942-0315

cecomp.com

Page 3

Instructions F20B, F22B

F20B Memory

With the gauge powered up and in the normal operating mode, press and release the Memory button to sequence through the memory locations.

When the Memory button is pressed the gauge is in the peak hold mode. A new higher reading will replace an existing reading, but a pressure reading lower then the one displayed will not be saved.

When desired memory location is displayed, take the pressure reading. The peak reading will be captured.

Remove the gauge from the pressure source and press the memory button for the next location.

Repeat until all readings are taken. The readings will be saved even if the

gauge is shut off.

Press and release the Power button to exit the memory mode and return to live pressure readings.

F22B Min/Max Memory

The Min/Max setup procedure in the Gauge Configuration > F22B Min/Max Setup section may be used to configure the gauge to

capture both maximum and minimum values, the maximum value only, or the minimum value only. Only the configured values will be displayed when the memory button is pressed. The gauge also may be configured to erase or save the readings when the gauge powers down.

The Min/Max readings are captured at the rate of 3 times per second. Note that if a brief pressure deviation occurs, it may not be captured. The readings are captured any time the gauge is on and not in the configuration or calibration mode.

Press and release the Memory button to view the maximum stored value.

The center power button may be pressed at any time to return to the normal display mode.

The gauge may be left in the maximum display mode if desired. The maximum reading will be continuously displayed, stored and updated.

Press and release the Memory button to view the minimum stored value.

For many applications it may be best to bring the system up to normal pressure and then clear the minimum value.

The gauge may be left in the minimum display mode if desired. The minimum reading will be continuously displayed, stored and updated.

Press and release the center power button to return to the normal display mode.

Clear a Memory Location

Press and release the Memory button until the value to be cleared is displayed.

Press and hold the Zero/Clear button.

Release the button when clr is displayed. The reading for the indicated memory location will be cleared.

With a gauge reference models if no pressure is applied, the value will return to zero.

If pressure is applied the new pressure reading will be stored in memory.

Absolute reference models will store the current atmospheric pressure reading if the gauge port is open to atmosphere.

Press and release the Power button to exit the memory mode and return to live pressure readings.

Zero/Clear Memory

200.0

Zero/Clear Memory

205.0

Zero/Clear Memory

i92.0

Zero/Clear Memory

200.0

Zero/Clear Memory

PSIG

MEM I

0.0

psig

MAX

MIN

psig

MEM MIN MAX

MEM I

0002

or or

rlc

Gauge Configuration

The gauge is designed to use a 4 digit pass code to enter the configuration modes. This is to prevent unauthorized changing of settings.

With the gauge off, press and hold the s

button. Then press the Power button.

Release all buttons when the display indicates CFG. The gauge firmware version is also displayed.

The gauge then goes through the normal power up sequence.

The display prompts for entry of the configuration pass code (CFGPC), with the first underscore blinking.

Note: The gauge will automatically revert to normal operation if no buttons are pressed for approximately 15 seconds. To cancel and return to normal operation, press and release the Power button without entering any pass code characters.

Enter Configuration Pass Code

Enter the pass code. 3510 is the factory default, but it is user-modifiable.

Use the s or t buttons to set the left-most digit to 3.

Press and release the Power button to index to the next position.

The 3 will remain, and the second position will be blinking.

Use the s or t buttons to select 5. Press and release the Power button to index

to the next position. 3 5 will remain, and the third position will be blinking.

Use the s or t buttons to select 1. Press and release the Power button to index

to the next position. 3 5 1 will remain, and the fourth position will be blinking.

Use the s or t buttons to select 0. Press and release the Power button to pro-

ceed with configuration procedures. Note: If an incorrect pass code is entered,

the gauge will return to the start of the pass code entry sequence.

Gauge Configuration—User or Factory

Upon successful pass code entry, the upper display will be blank, and the lower section will display USER. If User is not displayed press and release the t button to change the lower display to USER. With User selected, the gauge configuration can be modified as described in the following sections.

Press and release the Power button to continue with configuration.

F20B: Go to Engineering Unit Selection to

continue user configuration.

F22B: Go to the F22B Min/Max Setup sec-

tion to continue user configuration.

If Factory (FCTRY) is selected, the user configuration will be replaced by the configuration as it left the factory. To select Factory, press and release the s button. The lower display will indicate FCTRY.

Press and release the Power button to restore the factory configuration and restart the gauge.

Zero/Clear Memory

hold

firmware version

power up sequence

CFGPC

Zero/Clear Memory

- or -

CFGPC

Zero/Clear Memory

CFGPC

Zero/Clear Memory

USER

Zero/Clear Memory

USER

Zero/Clear Memory

- or -

FCTRY

Zero/Clear Memory

then

GFC

F22B Min/Max Setup

After the center power button is pressed when in user configuration mode, the display indicates MX/MN.

Use the s or t buttons to select the desired configuration.

MX/MN to capture both maximum and minimum readings.

--/MN to capture minimum readings only. MX/-- to capture maximum readings only.

Press and release the power button to save the user configuration and move to the next

____

setup parameter.

After the center power button is pressed when in user MX/MN configuration mode, the upper display indicates clr.

___3

Use the s button to select AUTO and the or t button to select MAN.

When the lower display indicates AUTO, the maximum and/or minimum readings will

___3

be automatically cleared when the gauge is powered off.

When the lower display indicates MAN, the

maximum and/or minimum readings will be retained in memory after the gauge is powered off. The readings can be cleared manually.

__53

Press and release the power button to save the user configuration and move to the next setup parameter.

Engineering Unit Selection

_I53

With the gauge in the user configuration mode, the upper display will be blank with the engineering units in the lower display.

Use the s and t buttons to navigate

0I53

through the list of engineering units. Available engineering units depend on the sensor range.

For compound gauges the choice of CMPND

0I53

(inHg/psig) or -/+EU (±Engineering Units) will apear. The gauge must be changed to -/+EU first before alternate engineering

units may be selected. When the desired units are displayed, press

and release the Power button to save your selection and move to the next parameter.

Auto Shutoff Time Selection

The auto shutoff time is displayed on the upper display. The lower display will indicate

AST M if the time displayed is in minutes or AST H if it is in hours.

Use the s and t buttons to select 0 (manual shutoff), 1, 2, 5, 10, 15, 20 or 30 minutes, or 1, 2, 4, or 8 hours.

A setting of zero disables the auto shutoff timer. This requires using the Power button

to shut the gauge off. When the desired time is displayed, press and

release the Power button to save your selection. If the gauge was ordered with a custom

shutoff time it will be unavailable if the time is changed. Reset the gauge to the original factory defaults as described previously to restore the custom time.

F20B: Go to the appropriate F20B Memory section on the next

page to continue user configuration.

F22B: Go to the F22B Backlight Shutoff Time section on the next

page to continue user configuration.

Zero/Clear Memory

MX/MN

--/MN MX/-MX/MN

- or -

MX/--

man

Auto man

- or -

MAN

PSIG

- or -

INHG

AST M

- or -

AST H

rlc

CECOMP Div. of

ABSOLUTE PROCESS INSTRUMENTS

1220 American Way Libertyville, IL 60048

800-942-0315

cecomp.com

Page 4

Instructions F20B, F22B

F22B Backlight Time Selection

The lower display will indicate BL if the display backlight is enabled or NO BL if display backlight is disabled.

Use the s button to enable backlighting and the t button to disable backlighting.

Press the power button to save the setting. If NO BL was selected the user setup is

complete and the gauge will restart and be ready for use with the new configuration.

If BL was selected the current backlight auto shutoff time is displayed in minutes. 1 minute is the factory default.

Use the s and t buttons to select the minutes for backlight shutoff time.

A setting of zero disables the auto shutoff timer and the backlight will be on whenever the gauge is on. The maximum setting is 255 minutes. The gauge auto shutoff time will override the backlight time. When the desired time is displayed, press and release the power button to save your selection and restart the gauge.

F20B Memory—M4 Versions

The M4 version allows recording pressure readings of up to four tires. While in the memory mode the peak reading is captured.

The number 1 is shown on the upper display. The lower display will indicate the label for memory 1.

Use the s and t buttons to select the desired label: MEM I, LR (left rear), RR (right rear), RF (right front), or LF (left front).

Each of the memory locations may be renamed as desired in any sequence. Care should be taken to avoid duplication or omission of a position.

When the desired label for memory 1 is displayed, press the Power button.

Repeat the steps for the other memory locations. When the desired label for memory 4 is displayed, press and release the Power button to save the user configuration and restart the gauge.

F20B Memory—M8 Versions

The M8 version allows recording of up to eight pressure readings. While in the memory mode the peak reading is captured.

The eight MEM 1 through MEM 8 labels are factory set.

F20B Memory—Custom Versions

If a special memory configuration was ordered, the custom memory labels may be shown.

In some cases, it may be possible to rename the MEM locations to the custom labels. If this is the case, use the following example below.

After auto shutoff time selection, the number 1 is on the upper display. The lower display will indicate the label for memory 1.

Use the s and t buttons to select MEM 1, or the programmed memory label.

When the desired label for memory 1 is displayed, press and release the Power button.

Repeat the steps for the other memory locations. When the desired label for the last memory location is displayed, press and release the Power button to save the user configuration and restart the gauge.

Battery Replacement

A low battery indication will be shown in the upper lefthand corner of the display when the battery voltage falls sufficiently. The batteries should be replaced soon after the indicator comes on or unreliable readings may result.

1. Remove the 6 Phillips screws on the back of the unit.

2. Lift up the battery holder.

3. Remove batteries by lifting up the positive end of the battery (opposite the spring) taking care not to bend the battery holder spring.

4. Discard old batteries properly, do not discard into fire, sources of extreme heat, or in any hazardous manner.

5. Always replace both batteries at the same time with high quality alkaline batteries.

6. Install batteries with correct orientation. Incorrect polarity will damage the gauge. The negative (flat) end of each battery should be inserted first facing the battery holder spring.

7. Replace battery holder and back cover, including the rubber gasket and reinstall the six screws.

CECOMP Div. of

No BL

Zero/Clear Memory

- or -

BLTMR

Zero/Clear Memory

- or -

Mem I

Zero/Clear Memory

- or -

Zero/Clear Memory

Mem I

Zero/Clear Memory

- or -

NLG I

Zero/Clear Memory

ABSOLUTE PROCESS INSTRUMENTS

Calibration

Setup and Preparation

Gauges are calibrated at the factory using equipment traceable to NIST. There is no need to calibrate the gauge before putting it into service. Calibration should only be performed by qualified individuals using appropriate calibration standards and procedures. Calibration intervals depend on your quality control program requirements, although many customers calibrate annually.

The calibration system must be able to generate and measure pressure/vacuum over the full range of the gauge and should be at least four times more accurate than the gauge being calibrated.

A vacuum pump able to produce a vacuum of 100 microns (0.1 torr or 100 millitorr) or lower is required for vacuum gauges.

Allow the gauge to acclimate to ambient temperature for 20 minutes. Install fresh batteries.

Entering Calibration Mode

With the gauge off, press and hold the t button. Then press the Power button. Release all buttons when the display indicates CAL.

The display begins by indicating the full-scale positive pressure rating of the gauge in the engineering units as configured by the factory, and then shows all display.

Before the gauge enters the Calibration Mode, the display initially indicates _ _ _ _ with the first underscore blinking, and with

CALPC (calibration pass code) on the lower display.

Enter the 3510 pass code as described in the Configuration Pass Code section.

Calibration Mode

The gauge enters and remains in the Calibration Mode until restarted manually or power is removed. Features not related to calibration are disabled and compound range models are set for the same engineering units for pressure and for vacuum.

The calibration may be performed in any of the available engineering units as well as percent (PCT).

For greatest accuracy, use the s and t buttons to select engineering units for calibration with highest resolution (highest number of display counts).

Press and release the Power button when the appropriate engineering units are displayed. Suggested units are listed below.

Sensor Suggested units for calibration 5 PSI 5.000 PSI 15 PSI 775.7 MMHG or TORR 30 PSI 61.08 INHG 50 PSI 50.00 PSI 60 PSI 60.00 PSI 100 PSI 7.031 KG/CM2 200 PSI 407.2 INHG 300 PSI 610.8 INHG 500 PSI 3447 KPA 1000 PSI 6895 KPA 2000 PSI 4613 FTH2O 3000 PSI 6920 FTH2O 5000 PSI 5000 PSI

The display will then indicate the currently applied pressure in the

engineering units selected for calibration.

s and t Button Operation Each time one of the s or t buttons is pressed and released quickly, a small change is made to the digitized pressure signal. It may take more than one of these small changes to result in a single digit change on the display.

To make larger changes, press and hold the appropriate button. After about one second, the display will begin to change continuously. Release the button to stop. Then make fine adjustments by pressing and quickly releasing the buttons as previously described.

Gauge Reference Pressure Gauges

Apply zero pressure by venting the gauge port to atmosphere. The character display will alternate between ZERO and CAL. Adjust for a display indication of zero using the s and t buttons.

Apply full-scale pressure. The character display will alternate between +SPAN and CAL. Adjust for a display indication of full-scale pressure using the s and t buttons.

Apply 50% full-scale pressure. The character display will alternate between +MID and CAL. Adjust for a display indication equal to 50% of full-scale pressure using the s and t buttons.

Gauge Reference Vacuum Gauges

Apply zero pressure by venting the gauge port to atmosphere. The character display will alternate between ZERO and CAL. Adjust for a display indication of zero using the s and t buttons.

Apply full-scale vacuum. The character display will alternate between +SPAN and CAL. Adjust for a display indication of full-scale vacuum using the s and t buttons.

1220 American Way Libertyville, IL 60048

Calibration—continued

Apply 50% full-scale vacuum. The character display will alternate between +MID and CAL. Adjust for a display indication equal to 50% of full-scale vacuum using the s and t buttons.

Absolute Reference Gauges

Apply full vacuum to the gauge. The character display will alternate between ZERO and CAL. Press the s and t buttons to obtain a display indication of zero.

Apply full-scale pressure. The character display will alternate between +SPAN and CAL. Press the s and t buttons to obtain a display indication equal to full-scale pressure.

Apply 50% of full-scale pressure. The lower display will alternate between +MID and CAL. Press the s and t buttons to obtain an indication equal to 50% of full-scale pressure.

Compound and Bipolar Gauges

In addition to the steps described above for pressure gauges, apply full-scale vacuum. The character display will alternate between

-SPAN and CAL. Adjust for a display indication of actual applied

vacuum using the s and t buttons. For bipolar and –30.00inHg/+15.00psig compound range models

only, apply 50% full-scale vacuum. The character display will alternate between -MID and CAL. Adjust for a display indication equal to 50% of full-scale vacuum using the s and t buttons.

Save Calibration

Press and hold the Power button until the display indicates - - - then release the button to store the calibration parameters in nonvolatile memory and restart the gauge.

Verify the pressure indications at 0%, 25%, 50%, 75% and 100% of full scale.

User-Defined Pass Code Configuration

The factory default pass code 3510 may be changed to a different value for configuration and/or calibration.

Configuration Pass Code

With the unit off, press and hold the s button to view and/or change the user configuration pass code. Then press the Power button. Release all buttons when the display indicates CFG.

Calibration Pass Code

With the unit off, press and hold the t button to view and/or change the user calibration pass code. Then press the Power button. Release all buttons when the display indicates CAL.

Change Pass Code Mode

Before the unit enters the view or change pass code mode, the display initially indicates _ _ _ _ with the first underscore blinking, and with CFGPC or CALPC on the character segments.

Note: The unit will automatically revert to normal operation if no buttons are operated for approximately 15 seconds. To cancel and return to normal operation, press and release the Power button without entering any pass code characters.

Enter access code 1220: Use the s and t buttons to set the left-most digit to 1. Press and release the Power button to index to the next position.

The 1 will remain, and the second position will be blinking. Use the s and t buttons to select 2. Press and release the Power button to index to the next position. 1

2 will remain, and the third position will be blinking. Use the s and t buttons to select 2. Press and release the Power button to index to the next position. 1

2 2 will remain, and the fourth position will be blinking. Use the s and t buttons to select 0. Press and release the Power button to proceed. Note: If an incorrect access code was entered, the gauge will return

to the start of the access code entry sequence.

Change Pass Code

Once the access code has been entered correctly, the display will indicate the existing user-defined pass code with CFGPC or

CALPC on the character segments.

Press the s or t button to select the first character of the new pass code.

When the correct first character is being displayed, press and release the Power button to proceed to the next pass code character.

Repeat above until the entire pass code is complete. To exit the User Defined Pass Code change mode, press and hold

the Power button. Release the button when the display indicates - - - - to restart

the gauge.

800-942-0315

cecomp.com
