Cecilware ST220V User Manual
Since 1911
®
II
Espresso Equipment
NR20A (4/08)
Standard Features
• Fully Automatic – Dispense single or double espresso, 1 or 2 cups at a time, or choose manual
continuous flow.
• Dual Pressure Gauge – Readouts for the dispensing water pressure & boiler steam pressure.
• User Friendly – Microprocessor technology, featuring touch pad controls & LED display.
• Heavy Duty Design – Built-in 260W motor & 200-300 qt/hr pump.
• Sight Glass – For instant & easy monitoring of the water tank level.
• Auto Cleaning Function – Flushes the line to the brew head.
• Stainless Steel Dual Boiler.
• Hot Water Dispensing Valve.
Specifications subject to change without notice.
Cecilware Corporation 43-05 20th. Avenue, LIC NY 11105
Tel: 800.935.2211 / 718.932.1414 • Fax: 718.932.7860
Since 1911
®
www.cecilware.com
Venezia II Espresso Equipment
Also Available
Steamer Model ST220V
Standard Features
• Two Steam Wands For Rapid &
Continuous Dispensing.
• 6 Quart Stainless Steel Boiler.
• 3000 Watt Heating Element.
• Endless Hot Water Supply.
• Steam Pressure Gauge With
Color Display.
• 100Watt Motor.
• Note: Unit only available in red,
not stainless steel as shown.
Espresso Machines & Steamer
Specications
Espresso Grinders Model VGT, VGA, & VGHDA
Standard Features
• Micro“Grind Control”Adjustment
An exclusive adjustment system
that gives the operator infinite
control over grind settings. No
more preset “clicks” for grind
settings.
• Cast Aluminum Frame – Insures
perfect grind head alignment.
• Stroke Counter– Comes standard
to indicate how many cups of
espresso have been served.
*
# Of
Model Description
ESP1-110V Auto Espresso Machine 1 Group 6 qts. 240
ESP1-220V Auto Espresso Machine 1 Group 6 qts. 240
ESP2-220V Auto Espresso Machine 2 Group 13 qts. 480
ESP3-220V Auto Espresso Machine 3 Group 19 qts. 720
ST220V* Steamer N/A 6 qts. N/A
Plumbing: 3∕8" Water line required. Accessories: Two & one cup filter holder assemblies and hoses are included with all espresso machines. Steamers
include hoses. Installation Package: Includes in-line water filter,part OPTESP, add $600 to list price. Note: In-line water filter must be installed for
warranty to be in effect. * Model ST220V steamer is not certified by ETL or NSF. Above prices in effect until December 31,2008.
Heads
Boiler
Size
Cups
/Hr.*
Dimensions
W x D x H Electrical
205∕16'' x 219∕16'' x 21½''
205∕16'' x 219∕16'' x 21½''
283∕8'' x 219∕16'' x 21½''
377∕8'' x 219∕16'' x 21½''
193∕8'' x 213∕16'' x 22¾''
120V, 2KW, 18A 106 lbs. $ 4,600
240V, 2.5KW, 10A 106 lbs. 4,800
240V, 4.7KW, 20A 147 lbs. 5,500
240V, 6.5KW, 27A 185 lbs. 6,400
240V, 3.1KW, 13A 88 lbs. 4,000
Ship
Weight
List
Price
Espresso Grinders
Specications
Grinding
Model Description
VGT Grinder WithManual Timer 2½" dia. 1600 rpm .6lbs. 7¾'' x 10½'' x 23½'' 120V,350W, 2.9A 31 lbs. $ 1,320
VGA Grinder With Automatic Timer 2½" dia. 1600 rpm .6lbs. 7¾'' x 10½'' x 23½'' 120V,350W, 2.9A 31 lbs. 1,590
VGHDA
Espresso Bean Container Capacity: VGT & VGS - 2.7 lbs., VGHDA - 4 lbs. Dose Adjustment: 5.5 - 9 g. Above prices in effect until December 31, 2008.
Heavy Duty Grinder With
Automatic Timer
Blades
3¼" dia. 1600 rpm .8 lbs.
Grinding
Speed
Ground Espresso
Container Capacity
Dimensions
W x D x H Electrical
83∕8'' x 11½'' x 25''
120V, 650W, 5.4A 44 lbs. 2,200
Ship
Weight
List
Price
Specifications subject to change without notice.
Cecilware Corporation 43-05 20th. Avenue, LIC NY 11105
Tel: 800.935.2211 / 718.932.1414 • Fax: 718.932.7860
Since 1911
®
www.cecilware.com
