Cecilware CMS24M, CMS24Q User Manual
CMS24Q
CMS24M
ELECTRIC COUNTER TOP
CHEESEMELTER
OPERATION MANUAL
CMS24Q Shown
CECILWARE CORPORATION
43-05 20th AVENUE, LONG ISLAND CITY, NEW YORK 11105-1295 ■
718-932-1414 FAX 718-932-7860 www.cecilware.com
NN54A 5/05
TABLE OF CONTENTS
Introduction ....................................................... page 2
Packaging .......................................................... page 2
Installation ......................................................... page 2
Operation ........................................................... page 2
Cooking By Time ............................................... page 3
Continuous Cooking ......................................... page 3
Cleaning, Care and Maintenance ..................... page 3
Safety ................................................................. page 4
Trouble Shooting .............................................. page 4-5
Compliance ........................................................ page 5
Electrical Diagram ............................................. page 6
Explosion View .................................................. page 7-8
Spare Part List ................................................... page 9
Specifications .................................................... page 10
1
Introduction
Congratulations on the purchase of your Cecilware Cheesemelter. Please take time to carefully read
through this manual to ensure the machine is operated and maintained prop erly. This will enable the best
possible performance from this product for many years.
Cecilware will not accept liability for the following if:
*The instructions in this manual have not been followed correctly.
*Non-authorized personnel have tampered with the machine.
*Non-original spare parts are used.
*The machine has not been handled and cleaned correctly.
Packaging
Cecilware prides itself on quality and service, ensuring that at the time of packing all products are
supplied fully functioning and free of damage.
Provided in this package are the following:
* Cheesemelter
* Crumb Tr ays
* Grilling Rack
* Manual
Should you find any damage that has occurred in transit, please contact your Cecilware dealer
immediately.
Installation
Remove the Cecilware Cheesemelter from the packaging. Be certain that all protective plastics and
residues are thoroughly cleaned from its surface.
Place the Cecilware Cheesemelter on a firm level surface.
Local standards and regulations should be consulted in order to abide by standards set in relation to
positioning, spacing, and ventilation.
Caution:
Do not position and operate near combustible materials/flammable objects. Once the Cheesemelter has
been placed in position, ensure the upper and lower stainless steel trays are positioned correctly.
Supply the appropriate power and connect to source. The Cheesemelter is now ready to turn on and
operate. (For power supply, please see technical specification sheet, page 10).
Operation
The Cecilware Cheesemelter has upper and lower ele ment s which can be used t ogether or alt ernatively;
the top element can be used on its own. This can provide flexibility when toasting and grilling.
The toaster is also fitted with a timer and a thermostat which allows cooking continuously or by time.
Please see next page for further details.
2
Cooking By Time
Select the style of toasting/grilling by selecting both elements or alternatively select the upper element by
pressing the element control switch. Adj ust the timer dial to the desired time of cookin g. When the time is
selected, the elements will automatically be activated at full power; when the time has lapsed, the
elements will automatically switch off. For this cooking method ensure the thermostat is turned off.
*Note: If the elements are not required to turn off completely, adjust the thermostat dial to low; this will
keep the elements on after the time has lapsed. This will help to keep the product warm and will also
allow for faster reheat when required.
Continuous Cooking
Select the style of toasting/grilling by selecting both elements or alternatively select the upper element by
pressing the element control switch.
When cooking continuously, be sure the timer dial is turned off. Using the thermostat dial, select the
desired temperature. When selected, the elements will automatically switch on; when finished, turn the
thermostat dial off. The timer will over ri de the energy regulator if it is not turned off.
*Summary: Time Control - provides full power to elements for the selected period of time.
The thermostat control provides the desired heat control setting for continuous operation when the timer
is off.
*Note: When in operation, the Cheesemelter will be hot; part of unit is the grilling rack which is handled
regularly. This rack is made from steel and will hold heat; therefore, protective gloves must be worn for
protection when handling.
Cleaning, Care and Maintenance
Switch off the power and disconnect from the power source.
The Cheesemelter should be cleaned after each day’s operation; however, the unit may require more
frequent cleaning, depending on the volume of production.
Allow the Cheesemelter to cool before cleaning. Remove upper and lower trays and wash them in
warm soapy water; be sure to dry before returning them to the unit.
The remainder of the Cheesemelter can be cleaned with a damp cloth using hot, soapy wat er.
Do not immerse completely in water or use hose to clean.
Warm soapy water is re commended for clea ning; prolonged use of cleaning agent s may cause dama ge
to stainless steel.
3
