Cecilware CH100-N Operators Manual

Chinese Hot Tea Urns
CH75N, CH100N Series
Operator Manual
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA Phone: 502.425.4776 Toll Free: 800.695.4500 Fax: 502.425.4664 Web: gmcw.com Email: info@gmcw.com
Rough-In Drawings .................3
Installation...............................4
Electrical Specifications...........4
Priming ....................................5
Adjustments ............................6
Cleaning...................................6
Maintenance ...........................8
Parts Diagram........................11
Parts List.................................14
Wiring Diagram.....................15
Thank you for purchasing this quality urn. For your safety and the safety of others, read all warnings and the operator manual before installing or using the product. Properly instruct all operators. Keep training records. For future reference, record serial number here:
Table of Contents
©2016 Grindmaster-Cecilware
Printed in USA
0516 Form #CW-327-01
Part # 390-00071
Grindmaster-Cecilware provides the industry’s BEST warranty. Visit gmcw.com for warranty terms and conditions.
Model CH100N
GB Series Cecilware
®
2
For safe and proper operation, the appliance must be placed in a stable, vertical position.
To reduce risk of serious burns or scalding, do not place hand or other body parts under dispenser or container while product is brewing.
Always unplug unit from power supply before servicing.
Hot liquid in brew basket could cause burns. Remove with care.
Surfaces are hot and can cause burns.
CAUTION
To reduce risk of electrical shock, do not remove or open cover. No user-serviceable parts inside. Repair should be done by authorized service personnel only.
The appliance is not intended for outdoor use.
Do not clean with pressurized water or use in an area where pressurized water may be used.
Cleaning and maintenance shall be made only by properly trained persons with supervision.
This appliance is not intended for use by persons with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not alter or deform the power cord or plug in any way! Altering or deforming the plug may cause electrical shock, damage unit, and will void warranty.
To reduce risk of explosion or fire, do not use near combustibles.
WARNING
Safety Information
2 Cecilware
®
Chinese Hot Tea Urns
Important Safety Information
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
For your safety and the safety of others, read all warnings and the operator manual before installing or using the product.
DANGER: This term warns the user of imminent hazard that will result in serious injury or death. WARNING: This term refers to a potential hazard or unsafe practice, which could result in serious injury or death. CAUTION: This term refers to a potential hazard or unsafe practice, which could result in minor or moderate
injury. NOTICE: This term refers to information that needs special attention or must be fully understood.
Use only on a circuit that is properly protected and capable of the rated load.
Electronically ground the chassis.
Follow national and local electrical codes.
Do not use extension cord.
This equipment must be installed in compliance with applicable Federal, State, and/or Local plumbing codes having jurisdiction. This product requires an approved back flow prevention water device, such as a double check valve, to be installed between the machine and the water supply.
NOTICE
Chinese Hot Tea Urns Cecilware
®
3
Rough-In Drawings
CH75N Single 3 Gallon Urn, Adjustable By-pass, and Electro-Mechanical Timer
CL100N Twin 3 Gallon Urn, Adjustable By-pass, and Electro-Mechanical Timer
10
9
F
8
29.1
19.3
F O
7
6
5
1
4
2
3
3.5
NN10A
10.1
4.0
29.1
19.3
10
9
F
8
F
O
7
6
5
1
4
2
3
2.5
14.016.0 5.4
4.0
28.0
5.4
3.5
NN10A
10.1
2.5
14.0
4 Cecilware
®
Chinese Hot Tea Urns
Electrical Specifications
Information below provided for US models only. Check rating marking on urn nameplate. Consult factory for export model information.
Installation
Unpacking Instructions
Carefully unpack the machine and inspect immediately for shipping damage. The packaging may contain unattached parts. Your machine was shipped in a carton designed to give it maximum protection in normal handling. It was thoroughly inspected before leaving the factory. In case of damage, contact the shipper, not Grindmaster-Cecilware.
NOTICE: The person installing this appliance is
responsible for ensuring that electric and water connections meet the requirements of the national electric code, national plumbing code, and any local ordinances.
See Rough-in Drawings for approximate dimensions and locations of electric and water input.
Mechanical Installation
NOTICE: Do not turn thermostat on until all
installation instructions have been followed.
1. Inspect unit to see if any damage occurred in shipment.
2. Remove the urn from the packing material. The four legs, faucets, and vent cap drain are packed separately with urn.
3. Install legs by tilting urn on its side and screwing legs into urn leg supports until hand tight.
4. Carefully right unit and install in its permanent location, being sure to leave at least 6" on right side of urn for access to controls. Position urn so that the faucets drip into a drip trough or drain receptacle of some type.
5. Level urn by adjusting legs. Then attach faucets and install vent cap drain.
6. Cover(s) are shipped with knob(s) on inside to prevent damage. Simply unscrew and reverse.
WARNING: ELECTRIC SHOCK HAZARD!
Installation of this appliance should be performed by qualified service personnel only. Improper installation could result in electrocution.
CAUTION
These urns are heavy pieces of equipment. It is recommended that moving or lifting the unit be done by two people to avoid injury.
Neutral and Ground Wires # 14 AWG min. Note: Field wiring must be suitable for 75° C. Use copper wire only for power supply connections. GROUNDING: ON ALL URNS, CONNECT A GROUND WIRE TO GROUNDING LUG TO COMPLY WITH LOCAL ELECTRICAL CODES (14 AWG MIN. 75° C)
Recommended Wire Size For Field-Wiring Urns US models only. Consult factory for export model information..
MODEL VOLTS KILOWATTS AMPS
1 PHASE 3 PHASE 1 PHASE 3 PHASE
3 WIRE 4 WIRE
CH75N
120/240
7
6
29
15
120/208 5.3 4.5 26 12
CH100N 120/240 7 8 29 20
120/208 5.3 6 26 17
MODEL WIRE SIZE
1 PHASE 3 PHASE
CH75N, CH100N (2) 10 AWG + GND
(3) 10 AWG + GND
Chinese Hot Tea Urns Cecilware
®
5
Water Hook-up
NOTICE:
This equipment must be installed in compliance with applicable Federal, State and/or Local plumbing codes having jurisdiction. This product requires an approved back flow prevention water device, such as a double check valve, to be installed between the machine and the water supply. Incoming pressure should be greater than 30 psi and not more than 70 psi.
Urn should be connected to cold water supply
1. The automatic urn is equipped with a ¼" Flare
water inlet fitting which is located on the back of the unit.
2. Provide shut-off valve and union in supply line near
urn.
3. Minimum inlet pressure at urn should be 30 PSI.
4. Maximum inlet pressure recommended at 70 PSI.
5. Copper flex tubing should be used for valve
connections.
6. To ensure pressure at the urn of at least 30 PSI, use
3/8" OD tubing for short runs, 1/2" OD tubing for longer runs, and larger size tubing for unusually long runs. Be sure other appliances will not reduce water pressure excessively.
7. Turn on the water supply line and check for leaks.
NOTE: For the best tasting tea, add a filtering system to the water supply line to eliminate any taste and/or odor from the water. NOTE: In areas with extremely hard water, a water softener must be installed in order to prevent mineral deposits that could result in malfunctioning of the equipment and in order not to void the warranty.
Electrical Hook-up
NOTICE: This equipment must be installed in compliance
with applicable Federal, State and/or Local electrical codes having jurisdiction. Do not use extension cords. Make sure that the outlet the urn plugs into is grounded.
1. Check rating marking on urn nameplate to be sure
electric lines match voltage, phase, and amperage requirements of urn. Select the proper cord and cord grip for electrical rating of the urn.
2. Urn body MUST be grounded. A grounding
terminal is provided for this purpose.
3. Use only copper wire to connect this urn.
NOTE: THERMOSTAT MUST BE IN THE "OFF" POSITION.
1. Open water supply line valve to urn.
2. Turn on or plug in the power supply to the urn. Water compartment will begin to fill automatically. Do not power up the urn when the water line is off.
3. Wait until water is visible in center gauge glass (left­hand gauge glass on 3-gallon single urns). Then turn thermostat knob to 10; thermostat pilot light shows heater is on. Urn jacket will continue to fill automatically until water reaches the proper level.
4. When indicator on dial thermometer approaches the "W" in BREW zone, 200° - 205°F (93° - 96°C), urn is ready to brew tea.
5. In high altitude locations (over 5000 ft. above sea level), thermostat may have to be lowered to prevent boiling.
6. Brew and discard at least one batch of water into each liner. Check that the fill level is correct. See the
Adjustments section if changes are needed.
WARNING: ELECTRIC SHOCK HAZARD!
Installation of this appliance should be performed by qualified service personnel only. Improper installation could result in electrocution.
Installation (continued) Priming
WARNING: ELECTROCUTION HAZARD!
Never use the ground conductor as a neutral. This could cause electrocution.
CAUTION: BURN HAZARD
Water used for brewing tea is very hot. Use caution when brewing, pouring, or transporting tea. Accidental spills may result in severe burns. Use caution when disposing tea leaves.
6 Cecilware
®
Chinese Hot Tea Urns
Cleaning
NOTICE: All sanitizing agents in the food zone must
comply with 21 CFR 178.1010. Sanitize all food dispensing units periodically. All parts to be sanitized must be cleaned first. Cleaning and sanitizing frequency must follow state and local health department regulations.
NOTICE: Do not use cleansers, bleach liquids,
powders, or any other substance containing chlorine. These products promote corrosion and will pit the stainless steel. USE OF THESE PRODUCTS WILL VOID THE WARRANTY.
After Each Brew:
1. Dispose of tea leaves and rinse brew basket.
Every Day:
1. Drain the urn; then run a brew cycle of hot water. After spraying hot water into the liner, thoroughly brush the liner with a long handled brush.
2. Drain the water and repeat step one. Run another brew cycle. Brush the liner and drain.
3. Wash the wire brew baskets with urn cleaner and rinse thoroughly.
Weekly or Bi-Weekly, Depending on Use:
1. Fill the urn liners with several gallons of hot water.
2. Pour into the liner the recommended concentration of urn cleaning compound. Set the thermostat to high (NO. 10) and then run a brew cycle of hot water.
3. Allow solution to remain in the liner for approximately 30 minutes.
4. Scrub the inside of both the liner and the cover with a long handled brush.
5. Drain the cleaning solution from the liner. Rinse by running several brew cycles with the sprayhead centered over the liner. Be sure to drain the rinse water between cycles.
6. Thoroughly clean the faucets.
7. Use a long, thin gauge glass brush to clean the tea gauge glass. Use the same brush to clean the fitting at the bottom of the liner and the pipe connected to the faucet.
8. Reassemble faucets. Fill the liners with hot water and drain until the liner and all parts are completely
rinsed.
Adjustments
Thermostat Adjustment
The Thermostat is factory set for proper dispense temperature of 200°F ± 3°F with the control knob set to the maximum clockwise position. If field adjustments are needed proceed as follows:
• To DECREASE temperature, turn the control knob slightly in the COUNTERCLOCKWISE direction.
• To INCREASE the water temperature -
1. With the Thermostat Knob to its maximum clockwise position, remove the knob and locate the slotted adjustment screw inside the hollow thermostat shaft.
2. Using a narrow-bladed screwdriver, engage slotted adjustment screw and turn it 1/4 turn slowly counter-clockwise.
(continued next page)
WARNING: SHOCK AND BURN HAZARD
To prevent electric shock and burn hazard all tasks described in this section are to be performed by a trained and qualified service technician.
Thermostat Adjustment
CAUTION: BURN HAZARD
The urn surfaces and water inside jacket are very hot. Use caution when cleaning this urn to prevent burns.
CAUTION: BURN HAZARD
Never remove the faucet when the liner has water or tea in it. Switch OFF the power to the unit at the circuit breaker. Turn off the water line running to the urn.
Faucet Body
Seat Cup
X014A
Bonnet
Faucet Handle
Faucet Assembly (D017A)
Chinese Hot Tea Urns Cecilware
®
7
Thermostat Adjustment (continued)
3. Allow a few minutes for the temperature to reach set level. The Heater Light will go ON, indicating the heating element is activated, wait for it to go OFF, indicating that the water has reached new set temperature.
4. Take a temperature reading and repeat if necessary.
Mechanical Timer Adjustment
The factory pre-set mechanical timer can be adjusted for more or less water by following these instructions:
1. Remove timer knob and loosen lock nut holding stop pin.
2. To increase volume of water, rotate stop pin clockwise.
3. To decrease, rotate counterclockwise. Tighten lock nut and replace knob.
WARNING: SHOCK HAZARD
Disconnect power before attempting any electrical repairs.
Thermostat Bulb
Coupling
Nut
CCW - Decrease
Temperature
WARNING: SHOCK AND BURN HAZARD
To prevent electric shock and burn hazard all tasks described in this section are to be performed by a trained and qualified service technician.
Adjustments (continued)
Manual Timer
(L154A)
Thermostat Assy
(L780A)
8 Cecilware
®
Chinese Hot Tea Urns
Maintenance
The rest of this manual contains information to aid the service technician who is maintaining this equipment. This section has information on performing common service tasks. If you still need help after reading this section, call Grindmaster-Cecilware Technical Service Department, (502) 425-4776 or (800) 695-4500 (USA & Canada only) (Monday through Friday 8 AM - 6 PM EST). Please have the model and serial number ready so that accurate information can be given.
Prior authorization must be obtained from Grindmaster-Cecilware for all warranty claims.
Grindmaster-Cecilware provides the industry’s BEST warranty. Visit our website at gmcw.com for warranty terms and conditions.
To Move the Urn
The urn must be completely drained (jacket and liners) and allowed to cool prior to moving this urn.
Spray Arm Assembly
The new improved spray head system was designed to facilitate easier cleaning and maintenance. The swivel valve has a larger flow opening and the spray head cap is equipped with a stainless steel disc, used to control the flow of water. When ordering replacement parts, be sure to order the correct disc and spray cap for each urn, as shown in Parts Diagram Illustration.
• To prevent lime buildup, especially in hard water areas, remove and clean spray head cap and spray head disc frequently.
• To clean swivel valve loosen nut and remove spray arm assembly from urn.
• Remove sediment by inserting a pipe cleaner through small hole in valve.
• If maximum setting of timer fails to deliver enough
water, check water pump.
If Water Fails To Heat
1. Check line fuse or circuit breaker. Replace or reset if necessary.
2. Make sure thermostat is in ON position. If thermostat pilot light does not come on, replace thermostat. (Refer to instructions below.) If pilot light is on, measure continuity between terminals l and 2 of thermostat, and between terminals 3 and
4. If a resistance is measured, replace thermostat.
3. If thermostat is okay, check wiring and repair if necessary: if wiring is okay, check heater resistance; if high or infinite, replace as follows:
Replacing Heater
1. Shut off power and disconnect water supply at elbow. Drain urn.
2. Remove one tea gauge glass, faucet, shank, and liner.
3. Tilt urn and disconnect wires to heater.
4. Remove socket head screw and heater flange and lift heater out.
5. Install new heater and reassemble urn.
6. Repeat Priming instructions on page 5. NOTE: DO
NOT TURN ON THERMOSTAT UNTIL URN IS PRIMED.
Replacing Thermostat
Thermostat is located in side box of urn. Lift off side box door to gain access to thermostat; then follow instructions below.
1. Shut off power, disconnect water supply, and drain urn by opening hot water faucet. When faucet stops running you are ready to remove the thermostat bulb.
2. Remove thermostat knob and two screws holding thermostat in place.
3. Disconnect wires from thermostat.
4. Pull out thermostat bulb.
5. Install new thermostat, push in the new thermostat bulb. Tighten compression nut on thermostat fitting to prevent leaking.
6. Repeat Priming instructions on page 5. NOTE: DO
NOT TURN ON THERMOSTAT UNTIL URN IS PRIMED.
If Water from Cold Water Supply Line Does Not Enter Urn
1. Check water supply to external shut-off valve.
2. Check fuse on rear of side box and replace if necessary.
3. If water supply and fuse are okay, remove fuse and lift off side box door exposing terminal block and electrical wiring.
4. Check dual probe liquid level controller. (See
Component Tests)
WARNING: SHOCK AND BURN HAZARD
To prevent electric shock and burn hazard, all tasks described in this section are to be performed by a trained and qualified service technician.
WARNING: SHOCK HAZARD
Disconnect power before attempting any electrical repairs.
WARNING: SHOCK AND BURN HAZARD
To prevent electric shock and burn hazard, all tasks described in this section are to be performed by a trained and qualified service technician.
WARNING: SHOCK HAZARD
Disconnect power before attempting any electrical repairs.
Chinese Hot Tea Urns Cecilware
®
9
If Water Runs Out At Overflow Drain
1. Make sure urn is level and overflow tube is vertical.
2. Remove fuse from rear of side box.
3. If water continues to flow, solenoid valve is dirty or not seating properly. Replace solenoid as described below.
Replacing Solenoid
1. Shut off water supply, remove fuse, and lift off side box door.
2. Disconnect wires from solenoid: then remove flare nut and unscrew solenoid valve from bracket.
3. Install new solenoid and reinstall fuse and side box door.
4. If necessary, follow Priming instructions on page 5.
No Water from Spray Head
1. Check fuse first.
2. For CH urns: Turn brew timer knob clockwise. Replace timer if it does not go on. If timer goes on but pump doesn't, replace pump.
Replacing Water Pump
1. Shut off water supply and remove fuse. Drain urn to level of water faucet.
2. Lift off side box door and disconnect the two pump wires.
3. Loosen union fittings on pump and remove pump from urn.
NOTICE: If your urn has older style pump with copper connections, it is imperative that you use a counter wrench when removing and installing pump to avoid damaging copper tubing. DO NOT OVERTIGHTEN.
4. Replace pump and follow Priming instructions on page 5.
Component Tests
Water Inlet Valve Test
1. Turn power OFF. If the water level rises inside a partially filled tank, the Water Inlet Valve is leaking.
2. Disconnect wires from the Water Inlet Valve coil and connect a 2 wire line cord to the terminals. Plug it into a 115V outlet. If water flows in and stops when you pull it out, the Valve is working fine. Repeat this test a few times. The problem may be in the Probe or Water Level Control Board.
3. If the water does not flow in when the cord is plugged into an electrical outlet, the Solenoid coil may be damaged, opened or the valve may have an obstruction preventing the water from flowing in.
4. Clean or replace it.
WARNING: SHOCK AND BURN HAZARD
To prevent electric shock and burn hazard, all tasks described in this section are to be performed by a trained and qualified service technician.
WARNING: SHOCK HAZARD
Disconnect power before attempting any electrical repairs.
Maintenance (continued)
Hose Nut Assembly
Component Tests (continued)
Dual Probe Test
If lack of water persists, check the probe as follows:
1. Turn on the power and water supply. Check inside the tank to make sure the water is below the Probe. Pull the BLUE wire and terminal OFF the Probe rod.
2. If water still does not flow after the wire is disconnected from the Probe, the problem may be in the Solid State Dual Level Control Board.
3. If water starts flowing into the tank, the Probe may be grounded, due to excessive liming. Check with Ohm meter.
4. Clean or replace probe.
Dual Probe Liquid Level Controller Test
Check the Controller as follows:
1. Make sure there is power input to the Controller at the terminals AC1 & AC2. Your voltmeter should read 115 Volts. It should read the same at terminals AC1 & FILL when the water level is low. This is the output power to actuate the coil of the Solenoid Valve to open it.
2. The lack of voltage at terminals AC1 & L-LEVEL or H-LEVEL indicates that the Controller is not working properly.
3. Make sure all wire connections are tight, including ground.
4. If after this, the Controller is still failing to open the Water Inlet Valve, replace it.
10 Cecilware
®
Chinese Hot Tea Urns
Maintenance (continued)
Blue
WARNING: SHOCK AND BURN HAZARD
To prevent electric shock and burn hazard, all tasks described in this section are to be performed by a trained and qualified service technician.
WARNING: SHOCK HAZARD
Disconnect power before attempting any electrical repairs.
Chinese Hot Tea Urns Cecilware
®
11
Parts Diagram
17
12 Cecilware
®
Chinese Hot Tea Urns
Parts Diagram (continued)
F
E
2
0
0
N ,
C
L
2
0
0
N
y
TEA
CH
If maximum setting
Remove sediment by inserting a pipe cleaner through small hole in valve.
head cap and spray head disc frequently. To clean swivel valve, loosen nut and
remove spray arm assembly from urn.
To prevent lime buildup, especially in hard water areas, remove and clean spra
of timer fails to deliver enough water, check water pump.
SPRAY ARM ASSEMBLY
AUTOMATIC COFFEE URNS
FE300-N
FAUCET, COFFEE
FAUCET, HOT WATER
Chinese Hot Tea Urns Cecilware
®
13
Parts Diagram (continued)
14 Cecilware
®
Chinese Hot Tea Urns
Parts List
ITEM PART DESCRIPTION
# CL75N CL100N
1 B157A TERMINAL BLOCK 4 WIRE 1 1 2 C036AL CONTACTOR, 3 POLE, 50 AMP - (240V) - -
CG12AL CONTACTOR, 3 POLE, 50 AMP - 120V 1 1
3 C395AL FUSE 6A SC-6 1 1 4 C396AL FUSEHOLDER, SC-6 11 6 CD417 WATER INLET VALVE (120V ONLY), .35 GPM 1 1
CD418 WATER INLET VALVE (240V), .35 GPM - -
7 CH387 WIRING HARNESS (MECH. TIMER) 1 1 8 355-00035 SIGHT GLASS ASSEMBLY 1 2
9 D017Q FAUCET, SHANK ASSEMBLY (TEA) 1 2 10 D022Q FAUCET, SHANK, VALVE ASSEMBLY (WATER) 1 1 11 355-00032 SIGHT GLASS ASSEMBLY (WATER) 1 1 12 E000A WATER PUMP (120V ONLY) (Prior to 3/2014) 1 1
E070A WATER PUMP (240V) (Prior to 3/2014) - -
A533-033 WATER PUMP (120V ONLY) (After 3/2014) 1 1 A533-034 WATER PUMP (240V) (After 3/2014) - -
13 359-00074 OVERFLOW FITTING W/ NUT 1 1 14 235-00007 COMPLETE SPRAY ARM ASSY NO BYPASS 1 1 17 320-00020 HEATER ELEMENT 7KW 240V 1PH 1 1 18 H429Q TUBE, OVERFLOW 1 1 19 HOSE NUT ASSEMBLY 11 20 H416A WATER INLET TUBE 1 1 21 K808A RETAINER MOUNTING BLOCK 2 3 22 K810Q LEVEL SENSOR, DUAL PROBE 1 1 23 L007A THERMOMETER, BREW DIAL 1 1 24 L154A TIMER, MECHANICAL (0 - 15 MINUTES) 1 1 26 L155A ROCKER SWITCH, POWER ON-OFF 1 1 28 L780A THERMOSTAT 25A, URNS 1 1 30 L775A DUAL LEVEL CONTROL HI-LO (120V) 1 1
L776A DUAL LEVEL CONTROL HI-LO (220V ONLY) - -
31 M005S LEGS (4" ADJ) (4 PER BAG) 1 1 32 M008A KNOB THERMOSTAT 11 33 M016A THERMOSTAT BEZEL 1 1 34 M027A KNOB, URN COVER 12 35 M326A WATER INLET HOSE 3/8 x 5/8 x 8" 1 1 36 M461A SILICONE GROMMET 12mm 3 3 37 M462A SILICONE GROMMET 15mm - - 40 MA15A COPPER GASKET, TEFLON FILLED 6 7 41 Q027Q LINER ASSY & COVER (CH75/ CH100) 1 2 42 UB17A SIGHT GLASS RETAINER 23 43 V002A BREW BASKET, CH75 / CH100 1 1 44 32004L INDICATOR LIGHT W/ RED LENS - -
45 ABB3WP FILTER PAPER (FE75N/FE100N) 1 2
Chinese Hot Tea Urns Cecilware
®
15
Wiring Diagram
Coffee Urn Only
SWITCH
CONFIGURATION
NC
C
NO
NO
C
NC
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA Phone: 502.425.4776 Toll Free: 800.695.4500 Fax: 502.425.4664 Web: gmcw.com Email: info@gmcw.com
©2016 Grindmaster-Cecilware
Printed in USA
0516 Form #CW-327-01
Part # 390-00071
Loading...
