Cecilware BT-2AWT User Manual

W
Whheenn yyoouu tthhiinnkk
C
Cooffffeeee
B
Brree
w
weerrss .. .. ..
tth
hii
n
nkk
CC
CC
ee
ee
cc
cciiiillll
ww
ww
aa
aa
rr
rr
ee
ee!!!!
We Know What’s Hot!
®
Since 1911
Brew Time
Series
!
High Performance - 3.5 minute brew
cycle with instant recovery.
!
Push Button Control - Brew your
favorite blend of coffee at the touch of a button.
!
Brew Light Indicator - Lets the opera-
tor know the coffee brewer is ready to brew.
!
High Limit Control - Automatically turns
the heater off if the brewer runs dry or overheats.
!
Precision Solid State Timers -
Standard in automatic brewers.
!
Stainless Steel Water Tank
!
Liquid Level Control - Automatically
refills the water tank at the end of each brew cycle.
!
12 Cup Capacity
!
Unique Safe Guard Circuit - Prevents
possible flooding on water tap units.
!
All Stainless Steel Construction
!
Easy To Service - Components are
easily accessible through the top.
Optional: Hot Water Faucet - for tea, hot
chocolate, soup and more.
Model # Warmers Height Ship Weight
Pourover Series
BT-2 2 24 ¾” 27 lbs. BT-3 3 25” 27 lbs.
Automatic Series
BT-2A 2 24 ¾” 29 lbs. BT-3A 3 25” 29 lbs.
Automatic Series with Hot Water Tap
BT-2AWT 2 24 ¾” 29 lbs. BT-3AWT 3 25” 29 lbs.
Electrical: 2 warmer units 120V, 1.6KW, 14A
Plumbing: Automatic units require 1/4” water line Dimensions: Width - 17 1/2” Depth - 9 1/2”
3 warmer units 120V, 1.7KW, 15A Line cord Included
!
High Performance - 3.5 minute brew
cycle with instant recovery.
!
Push Button Control - Brew your
favorite blend of coffee at the touch of a button.
!
Brew Light Indicator - Lets the opera-
tor know that the coffee brewer is ready to brew.
!
High Limit Control - Automatically turns
the heater off if the brewer runs dry or overheats.
!
Precision Solid State Timers -
Standard in automatic brewers.
!
Polysulfone Water Tank - Keeps liming
to a minimum.
!
Liquid Level Control - Automatically
refills water tank at the end of each brew cycle.
!
12 Cup Capacity
!
Unique Safe Guard Circuit - Prevents
possible flooding on water tap units.
!
All Stainless Steel Construction
!
Easy To Service - Components are
easily accessible through the top.
Optional: Hot Water Faucet - for tea, hot
chocolate, soup and more.
Coffee Station
Series
Electrical: 2 warmer units 120V, 1.6KW, 14A
3 warmer units 120V, 1.7KW, 15A Line cord included
Plumbing: Automatic units require 1/4” water line Dimensions: Width - 16” Depth - 9”
CS-2A 2 24 ¼” 28 lbs. CS-3A 3 24” 28 lbs.
CS-2AWT 2 24 ¼” 29 lbs. CS-3AWT 3 25 ½” 29 lbs.
CS-2 2 22 ½” 25 lbs. CS-3 3 23 ¾” 26 lbs.
Model # Warmers Height Ship Weight
Automatic Series
Automatic Series with Hot Water Tap
Pourover Series
Warmers and Decanters
To compliment Cecilware’s coffee brewer series, a complete coffee warmer system is the perfect way to enhance your coffee sales. By placing multiple warmers in various locations, e.g. waitress stations, coffee will be readily accessible. Keep it
fresh, hot and ready to serve!
Model # Description Width Depth Height Ship Wt.
SW2CR SW2CL (left)
SW3 3 Warmers 8” 21” 15” 15 lbs. MW-2 2 Warmers 14” 7” 2” 6 lbs. MR-2 2 Ranges 14” 7” 2” 6 lbs.
MWR-2
Combination elements can be used as either warmers or ranges. Electrical: 120V, 15A plug-in, line cord included
(right)
2 Warmers 8” 17 ¼” 8” 8 lbs.
1 Warmer
1 Combination
14” 7” 2” 6 lbs.
From Convenience Stores to Restaurants to
Office Coffee Services, coffee decanters are a necessary part of the coffee brewing cycle. Although coffee decanters come in a variety of styles, shapes and sizes, it’s important to choose one that conforms to the hand for proper comfort and balance.
Cecilware’s new “NCD” coffee decanters set new standards for commercial decanters. Designed with Cecilware’s exclusive ProSet comfort and ratcheted Leak-proof gasket spout, pouring coffee was never this efficient.
For Your Convenience, Handles Are Available In
The Following Attractive Colors:
NCD Decanters - Black, Brown, Orange, Red, Green,
NCD Decanters
Gold, and Purple
CBL Decanters - Black, Brown, Orange, Purple, Blue,
CBL Decanters
Teal, Red, Green and Yellow
Customize Your Decanter
Add a little spice to your business by having your insignia, logo or company name printed on any Cecilware decanter. Just call our toll free number and speak to our Customer Service Department or contact your local Cecilware Sales representative for more details.
Since 1911
We Know What’s Hot!
Cecilware Corporation 43-05 20th Avenue LIC, NY 11105
®
Tel: 718.932.1414 800.935.2211 Fax: 718.932.7860
Visit us on the web: www.cecilware.com
