Page 1
The FRY-SAVER®-
Oil Filtration System
Countertop Fryers
Gas and Electric
Stainless Steel
Construction
Stainless Steel
Fry Tank
Keeps Oil at
Peak Quality
®
Since 1911
®
Since 1911
Page 2
Heavy Duty Floor Model Electric Fryers - 40 lb. and 65 lb.
The Cecilware Electric & Gas Floor Model Fryers wer
foodservice operator in mind. We have built an economical, efficient and hard working fryer
Features
9
Economical To Operate - Maximum efficiency with a balanced electrical
load.
9
Mechanical Temperature Controls
9
Trouble Free, Low Watt Density, Fixed Elements
9
High Energy Incoloy Elements - provide fast recovery.
9
Robertshaw High Limit and Automatic Temperature Controls insure accurate, safe fryer operation. Conserve energy and save money.
9
Melt Cycle Controls - standard on all models.
9
Oversized, Full-flow 1.25'' Drain Valve - makes draining effortless.
9
Tough Unibody Construction
9
All Controls Are Easy To Service and Accessible From the Front of
the Fryer.
9
Options: Locking & regular casters, single fry baskets, banking strips
Model # Tank
EFP-40* Mild Steel 208V,50A
EFS-40* Stainless Steel
EFP-65** Mild Steel
EFS-65** Stainless Steel
Working Height: 35'' Overall Height: 44½'' Minimum Fat Capacity: * 55 lbs. ** 102 lbs. Specify voltage and phase
40 lb. Fryer Basket Size: 121/8'' x 6½'' x 5½''; Use Basket # V184A 65 lb. Fryer Basket size: 16¾''x 8¾'' x 6''; Use Basket # V180A
40 lb. Fryer Foam Area: 13½'' x 22'' 65 lb. Fryer Foam Area: 18¼'' x 28''
40 lb. Fryer: 18 KW 65 lb. Fryer: 21 KW
Door: Stainless Steel; Body: Stainless Steel except: FMP-40BSS - Enamel
Fat Overall
Capacity Depth Weight 1 Phase 3 Phase
40 lbs. 31'' 15½'' 140 lbs. 208V,86.5A 220V,48A / 380V,28A
65 lbs. 35'' 20'' 200 lbs. 208V,100A 220V,55A / 380V,32A
Width
Ship Electrical
240V,75A 240V,44A / 415V,25A
208V,58A
240V,87.5A 240V,51A / 415V,29A
Electric & Gas Fryer
Model A B
40 lb. 31'' 15½''
65 lb. 35½'' 20''
Floor Model Fry Baskets
Part # Fryer Type Depth
V174P 40 lb. gas / electric 13¼''
V180P 65 lb. gas / electric 16¾''
''P'' Plasticized handles Front hook placement
Page 3
Heavy Duty Floor Model Gas Fryers - 40 lb. and 65 lb.
When you need performance, you can depend on Cecilware
Heavy Duty Gas Fryers to do the job.
Features
9
Heavy Duty Stainless Steel Unibody Construction - for long life.
9
Heavy Duty Stainless Steel Heat Exchangers - for maximum heat transfer.
9
Heavy Duty Cast Iron Burners
9
Oversized, Full-flow 1.25'' Drain Valve - makes draining effortless.
9
Automatic Temperature Controls - standard.
9
Large Foam Area
9
Super Fast Heat-up & Recovery
9
Includes Two Fry Baskets and Crumb Screen
9
Options: Locking and regular casters, single fry basket, banking strips
C D
Model # Tank
FMP403-HP* Mild Steel
FMS403-HP* Stainless Steel 40 lbs. 31'' 15½''
FMP-40** Mild Steel
FMP-40BSS** Mild Steel
FMS-40** Stainless Steel
FMP-65*** Mild Steel
FMS-65*** Stainless Steel
Minimum Fat Capacity: * 49 lbs., **41 lbs., ***79 lbs. Specify Natural or LP Gas; Working Height: 35'' Overall Height: 44½''
40 lb. Fryer Basket Size: 13¼'' x 6½'' x 6''; Use Basket # V174A 40 lb. Fryer Foam Area: 13½'' x 22''
65 lb. Fryer Basket Size: 16¾'' x 8¾'' x 6''; Use Basket # V180A 65 lb. Fryer Foam Area: 18¼'' x 28''
Door: Stainless Steel; Body: Stainless Steel except: FMP-40BSS, FMS403HPBSS - Enamel sides
Fat Overall
Capacity Depth Hr. Tubes Weight
40 lbs. 31'' 15½'' 115,000 4 200 lbs.
65 lbs. 35¼'' 20'' 140,000 5 265 lbs.
Width
BTU/ Burner Ship
110,000 Nat
100,000 LP
3 190 lbs.
Width Height Weight
6½'' 6'' 3 lbs.
8¾'' 6'' 7 lbs.
Page 4
* Specify voltage. 1 phase only. El-120/170 and EL-250/270 line cord included
Use Fry Baskets: V091A and V092A except for EL310 use V077A and V078A
9
Heavy duty 100% stainless steel construction for long life.
9
The EL120 can plug in anywhere.
9
Heavy duty, high speed elements.
9
Automatic temperature controls.
9
Includes two fry baskets.
9
Heavy duty 100% stainless steel construction for long life.
9
18 gauge Stainless Steel fry tank.
9
Automatic temperature controls.
9
Includes two fry baskets, crumb screen, and pressure regulator.
9
Ball type slanted drain valve for fast draining.
9
Basso Safety Pilot with high-limit control.
9
GF-10 has a flat bottom, GF-16 and GF-28 are tube fired.
9
4'' legs optional.
Counter Top Gas Fryers
Counter Top Fry Baskets
Removable Stainless Steel Tank
Automatic Temperature Controls
Features
Features
Counter Top Electric Fryers
Model # Fat Capacity Width Depth Height Electrical Ship Weight
EL-120
15 lbs. 12'' 19½'' 8¼'' 120V, 18KW, 15A 29 lbs.
EL-170 Same as EL-120 with 4'' legs
EL-250 15 lbs. 12'' 19½'' 8¼''
240V, 5.5KW, 22.9A
208V, 4.2KW, 20.2A
29 lbs.
EL-270 Same as EL-250 with 4'' legs
EL-310* 45 lbs. 18'' 21'' 11½''
240V, 5.5KW, 22.9A
208V, 5.5KW, 26.4A
45 lbs.
ELT-500 60 lbs. 25½'' 20½'' 18½''
240V, 11KW, 46A
208V, 8.4KW, 40A
60 lbs.
Model #
Fat
Depth
BTU/Hr Ship Use Fry
Capacity Nat.; LP Weight Baskets
GF-10 13 lbs. 20½'' 26,000; 26,000 53 lbs. V091A/V092A
GF-16 18 lbs. 21¾'' 22,500; 18,000 60 lbs. V091A/V092A
GF-28 28 lbs. 22'' 45,000; 38,000 91 lbs. V094A/V095A
Specify Natural or LP Gas Width: 12¼'' GF28: 18¼'' Height: 17¼'' GF10: 14½''
Part # Fryer Type
Hook
Placement
Depth Width Height
V006A 10 lb. gas Front 8¾'' 3½'' 4½''
V091A
13, 18 lb. gas,
15 lb. electric
Right
10¾'' 3
3
/8'' 3¾''
V092A Left
V077A
20 lb.
electric
Right
10
7
/8'' 3½''
4
9
/16''
V078A Left
V094A
28 lb. gas
Right
10
3
/16'' 53/8'' 4¾''
V095A Left
Page 5
Automatic
Reversible Pump
The Only Filtration System That Doubles the Life of Cooking Oil!
Compact Design
Why Leading Chain Store Restaurants
Prefer the FRY-SAVER
9
Keeps Oil At Peak Quality - Improves the taste of fried foods by
removing contaminants > 3 microns.
9
Reduces Oil Cost To Keep Profits High - Doubles the life of oil.
9
Super Fast Filtration Process - Processes 3 ½ gallons of oil in 1
minute.
9
Safe, Automatic, Reversible Pump - No pouring, spilling or
spattering. Oil is pumped into the completely enclosed unit,
thoroughly filtered, and at the flip of a switch pumped back, absolutely
clean.
®
Page 6
Reasons FRY-SAVER®Works Better Than Other Filtration Systems
Reasons FRY-SAVER®Works Better Than Other Filtration Systems
9
Pleated filter design provides 15 times more filtering area than other filters. Long life
FRY-SAVER®pleated cartridge filters are replaced only when pleats become full.
9
Does not require Diatomaceous Earth or other harsh chemicals that can leave residue in oil.
9
The only filter system that removes microscopic oil-killing contaminants.
9
Filter Cartridge and Pre-Filter Paper - filters and cleans up to 1,500 lbs. of oil or fat.
Savings
Oil Savings Calculations - Filtering Once Per Day
Not
Filtering
A Lbs. of Oil Used Per Day 40 40 40
B Life of Oil 2 (Doubles) 1.5
C Days Per Year 365 365 365
Total lbs. of Oil Used
D
Per Year (AxC) ÷ B
14,600 7,300 9,733
E Price of oil per lb. $ 0.46 $0.46 $ 0.46
F Annual Oil Expense (DxE)
$ 6,716 $ 3,358 $4,477
G Diatomecious Earth - (not needed) $406
H Filter Paper - $274 $314
I Filter Cartridges - $375 -
Adjusted Annual Oil
J
Expense (F+G+H+I)
$ 6,716 $ 3,632 $ 5,197
Savings vs. Not Filtering $ 3,084
Savings vs. Leading
Competitor
Cecilware
FRY-SAVER
$ 1,565
Leading
®
Competitor
MODEL
F-150
Insert Your Figures
MODEL
F-100
(AxC) ÷ B
(DxE)
(F+G+H+I)
Accessories
FILTER
CARTRIDGE
Part # Description
20000 (F-101)
20003 Filter Cartridges (3 / pack)
20215 (F-201) Stainless Steel Pre-Filter Assembly
20220 (F-202) Pre-Filter Paper For F-201 (150 / carton)
20230 Large Casters (4 / Set)
20240
Filter Cartridges (1 dozen / carton)
Stabilizing “Wings” For Large Casters
(Model F-150 only)
PRE-FILTER ASSEMBLY
PRE-FILTER PAPER
MODEL
F-60
Model # Capacity Height Pump Capacity Ship Weight
F-60 60 lbs. (8 gals.) 17''
F-100 120 lbs. (16 gals.) 33'' 95 lbs.
F-150 150 lbs. (20 gals.) 40'' 105 lbs.
Electrical: 120 volts,60 cycles,5.5 amps Motor: 1/4 hp; Diameter: 17''
When 220 volts, 50 cycle motor is furnished; the above model numbers will carry the designation
“NUL”
3.5 gal. / Min.
Specifications subject to change without prior notice
85 lbs.
Since 1911
®
Cecilware Corporation • 43-05 20th Avenue • Long Island City, NY 11105
Tel: 800.935.2211 • 718.932.1414 • Fax 718.932.7860 • www.cecilware.com
