wc431 Slimline Integrated
Dishwasher
Manual for Installation, Use and Maintenance
2
Contents
Contents ............................................................................................................. 2
Important ............................................................................................................ 3
Important Notes ............................................................................................... 4
Recommendations
......................................................................................... 5
Before First Use ............................................................................................... 5
Control Panel .................................................................................................... 6
Detergent........................................................................................................... 9
Salt ....................................................................................................................... 11
Softener Adjustment .................................................................................... 12
Rinse Aid ...........................................................................................................14
Dishwasher Baskets ..................................................................................... 15
Standard Loading and Test Data .............................................................. 17
Programme Listing ........................................................................................ 18
Care and Maintenance ................................................................................ 19
Failure Codes and Troubleshooting ....................................................... 21
Electrical Information ................................................................................... 23
Installation ....................................................................................................... 25
Fitting the Integrated Appliance Door ................................................... 26
3
Important
The CDA Group Ltd cannot be held responsible for injuries or
losses caused by incorrect use or installation of this product.
Please note that CDA reserve the right to invalidate the guarantee
supplied with this product following incorrect installation or misuse
of the appliance or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by
someone who is responsible for their safety.
Under no circumstances should any external covers be removed
for servicing or maintenance except by suitably qualified
personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee
purposes.
Appliance Model
Serial Number
This appliance has been designed for domestic use only.
Commercial use will invalidate the warranty
CE Declarations of Conformity:
This appliance has been designed, constructed and marketed in
compliance with safety requirements of EEC Directives
2004/108/EC, 2006/95/EC, IEC436/DIN44990 & EN 50242.
4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF
THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE
2002/96/EC.
At the end of its working life, the product must be taken to a
special local authority waste collection centre or to a dealer
providing appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both
energy and resources. As a reminder of the need to dispose of
household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
Important Notes
• Read the instructions prior to installation and use of the
appliance.
• Do not lean or climb on the open dishwasher door to
prevent damage.
• Close the dishwasher door after use to prevent accidents.
• Use only detergents, salt and rinse aid specifically
designed for dishwashers.
• Do not put solvents in the dishwasher detergent
compartment to prevent risk of explosion
• Only put dishwasher safe items into the dishwasher. If in
doubt, check with the manufacturer of the items.
• Take care when loading the dishwasher to observe the
recommendations for best loading practice, and also to
ensure that sharp objects such as knives are placed blade
down to prevent accidents.
• Do not open the dishwasher door when a programme is
running. If it is necessary to do so, then open it only slightly
to allow the dishwasher to pause the programme and
prevent any water spilling out. Remember that the water in
5
the dishwasher can be very hot when the programme is
running.
• When the dishwasher is not in use, we recommend that
you turn off the water supply at the supply tap and
disconnect the main supply.
• If you are leaving the dishwasher for an extended period
you should leave the door slightly open to prevent the
formation of unpleasant smells.
• The plastic housing on the water inlet pipe contains an
electrically operated valve. The wires that connect to this
valve are inside the inlet hose. Do not cut through the inlet
hose, and do not put the plastic housing in water.
• Children could get locked inside the appliance. Therefore
when disposing of an old appliance, cut off the plug and
set aside, and damage the door lock so that the door can
no longer be closed.
R
ec
ommendations
• To reduce energy and water consumption, remove all dirt
residues from the dishes prior to loading the dishwasher.
• Only run the dishwasher when fully loaded.
• Place hollow items (bowls, glasses and pans) face down in
the basket.
• Do not put dishes or cutlery with tobacco ash, wax,
lubricating grease or paint residues in the dishwasher.
Before First Use
• Set the water softener level as required by the water
hardness in the area.
• Add 1kg of salt into the salt compartment and then fill with
water to the top of the salt compartment.
• Remove all the packaging materials from the interior of the
dishwasher.
• Fill the rinse aid compartment.
6
• Run a hot programme without any dishes in the
dishwasher.
Control Panel
1 2 3 4 5 6 7
2 3 4 5 6 7
Power Button (1)
To switch the dishwasher on or off, press the power button (1).
When you switch on the dishwasher, the end of programme light
will illuminate, and two dashes will appear on the display.
Programme Display (2)
The programme display shows the selected programme and the
remaining time to run. If there is a fault on the dishwasher, the fault
code will show on the display.
Programme Selection Button (3)
To select a programme, press the programme selection button (3).
The dishwasher will store in its memory the last programme used.
7
Half-Load Butt
on
(4) and Indicator L
ight
The dishwasher is equipped with a half-load function that allows
for small numbers of dishes to be washed, spread between both
baskets. This reduces the amount of water and electricity used.
• To use this function, press the half-load button (4), the
indicator light shows to indicate that this function is
selected.
If you have selected the half-load function for a programme,
this function will automatically be selected the next time the
dishwasher is used. To cancel the selection of this function,
press the specific half load button (4) until the indicator light
goes out.
Delay Timer Button (5)
The dishwasher is equipped with a variable timer of 3, 6 or 9
hours to delay the start of a programme.
• To set the delay timer, press the delay timer button (5). This
will switch the timer on for 3 hours.
• Pressing the delay timer button (5) again will increase the
delay to 6 hours, a third press increases the time to 9
hours. The delay time selected will show on the indicator
lights (6).
• To cancel the delay timer, press the delay timer button
again until none of the indicator lights (6) are lit.
Salt, Rinse Aid Warning Lights and End of Programme Light (7)
When the dishwasher salt or rinse aid begins to run out, the
warning light will illuminate to advise that it needs refilling.
When the programme is complete, the dishwasher will emit five
beeps and the end of programme indicator light will illuminate.
8
Starting a Programme
• Press the Power button (the end of programme light will be
switched on)
• Press the Programme Selection button until the required
programme is shown on the display.
• If required, set the delay timer by pressing the Delay Timer
button
• Once a programme is selected, the end of programme light
will switch off.
• When you close the dishwasher door, the programme will
start automatically.
Please note: The dishwasher stores the most recently used
programme in its memory. To change the programme,
simply press the Programme Selection button.
At the End of a Programme
If possible, do not open the dishwasher door once the programme
has started.
At the end of a programme, the dishwasher will beep five times,
and the end of Programme Indicator light will switch on.
Changing a Programme
It is possible to change the programme if necessary once the
programme has started.
• First open the door slightly to reduce the risk of water
spillage.
• Press the programme selection button until the required
programme is shown on the display.
• Then close the door. The dishwasher will begin the new
programme from the point at which the old programme
stopped.
9
Cancelling a Programme
It is possible to cancel the programme once is has started.
• First open the door slightly to reduce the risk of water
spillage.
• Press and hold in the Programme Selection button for
three seconds until the end of programme indicator flashes
and a“1”shows on the display.
• Then close the door. The dishwasher will run a drain cycle
which will take approximately 30 seconds. Once this is
complete, the dishwasher will beep five times and the end
of programme light will switch on.
Switching the Dishwasher Off
Once the dishwasher beeps five times and the end of programme
light switches on, the dishwasher can be switched off by pressing
the Power button.
Then turn off the water tap and remove the plug from the power
socket.
Please note: the dishwasher will automatically continue on the
programme it has started if the door is opened or in the event
of a power cut.
Detergent
To Fill the Detergent Compartment
1. Push the latch to open the
compartment.
2. Add the required amount of
detergent. The main detergent
compartment “b” (figure 2)
has lines to allow for specific
amounts of detergent. These
are marked at either 15 cm3 or
Fig.2
10
25 cm3, to be used depending on how dirty the dishes are.
If your dishes are in need of an intensive wash, then add 5
cm3 of detergent into the prewash section of the
compartment “a” (figure 1).
3. Then close the detergent compartment lid until the latch
locks.
Please note: You should only use detergents designed
specifically for use in dishwashers.
Combination detergents (e.g. 3-in-1 tablets) must not be used in
any quick wash or half load programme.
If using dishwasher tablets, always use the detergent
compartment, do not put them in the main body of the dishwasher
or in the cutlery basket. The solubility of dishwasher tablets can
vary depending on the temperature and duration of the
programme. As a result, it is recommended that powder
detergents should be used in the shorter programmes to allow
better performance.
CDA recommends the use of separate detergent, rinse aid and
dishwasher salt rather than combination tablets as separates
achieve better wash performance.
If you do use combination detergents, add salt and rinse aid to the
dishwasher and then adjust the water hardness setting and rinse
aid setting to the minimum. When you then use separate
detergents again, you should fill the salt and rinse aid
compartments, adjust the water hardness setting to the maximum
and run an empty wash, then adjust the water hardness setting
and the rinse aid setting to the appropriate level.
11
Salt
To ensure the best efficiency, the
dishwasher needs soft water. Hard
water means that lime residues remain
on the dishes and the interior of the
dishwasher, affecting performance. The
softener system is designed to remove
the ions that make the water hard to
provide the best quality wash
performance. This is achieved by using
dishwasher salt.
To Add Dishwasher Salt, Follow the
Steps Below:
1. Remove the lower dishwasher
basket and then unscrew the
salt compartment cap, as shown
in figure 3.
2. Fill the compartment with
dishwasher salt (do not use
table salt), carefully to prevent unnecessary spillage (figure
4). Before first use, you should fill the compartment with 1kg
of dishwasher salt and then fill up the salt compartment
with water (up to the brim of the compartment) as shown in
figure 4.
3. Replace the cap and the lower basket.
When the salt warning light on the control panel illuminates, you
should refill the salt compartment with salt only – do not add water
to the salt compartment after the first use.
Important: You should run a prewash programme immediately
after adding dishwasher salt, to prevent any damage to the
dishwasher systems.
Only fill the salt compartment with water on first use.
Fig.4
Fig.3
12
Softener Adjustment
The efficiency of your dishwasher
depends on the softness of the tap
water.
To ensure best efficiency, the
dishwasher is equipped with a system
that reduces the hardness in the mains
water supply. The efficiency will increase
when the system is correctly set. To find
out the water hardness level of your
water supply you can use the test strip
supplied or alternatively contact your
local water board.
• Open the testing strip (figure 5).
• Run water through the tap for one
minute.
• Hold the testing strip in water for
one second.
• Remove from the water and
shake the test strip to remove
excess water.
• Wait for one minute.
• Check the number of marks on
the strip to see the level of water
hardness.
If the hardness of the water you use is
above 63 dE or if you are using well
water; you are recommended to contact
your local water board to confirm the
water hardness level and to use filter and
water refinement devices.
Please note: The level of water
Fig.5
13
hardness is preset to level 3.
1. Press and hold down the programme selection button
2. Press the Power button to switch on the dishwasher
3. Keep the programme selection button pressed until “8”
shows on the display and then disappears.
4. After the 8 disappears the machine displays the last water
hardness setting entered.
5. To adjust the level, press the programme selection button
(3) until the required level is shown on the display, as listed
in the Table of Water Hardness below.
6. To store the selected water hardness level, press the
power button.
Water Hardness Level
British Hardness dE
Display Shows
1
0 – 6
L1
2
7 – 14
L2
3
15 – 21
L3
4
22 – 28
L4
5
29 – 39
L5
6
40 - 63
L6
14
Rinse Aid
To Fill the Rinse Aid Compartment
1. Open the rinse aid
compartment by turning and
removing the cap as shown
in figure 6.
2. Fill the rinse aid
compartment until the rinse
aid indicator goes dark, as
shown in figure 7 (where “a”
indicates the compartment is
empty, and “b” indicates
the compartment is full).
3. Replace the cap, ensuring
the markers on the cap line
up with the compartment
prior to screwing the cap
back in place.
Rinse Aid Adjustment
The level of rinse aid use is preset
to 3. You can adjust the level of
rinse aid use by adjusting as shown
in figure 8.
If water stains form on the dishes
after a wash, the level should be
increased.
If blue stains which can be wiped
away are left on the dishes after a
wash, the level should be decreased.
Please note: Rinse aid ensures better quality wash results and
increased drying performance.
Fig.8
Fig.6
Fig.7
15
Always refill the rinse aid when the rinse aid indicator light on
the control panel is illuminated.
Dishwasher Baskets
Top Basket Height Adjustment
The top basket of your machine is
supplied in the upper position.
When it is in this position, you can
place big items such as pans, etc.
on lower basket.
When you move the top basket to
lower position, you can place and
wash large plates on the top
basket.
The basket height is adjusted by
using the alternative wheel sets on the tracks:
1. Swing open the basket retainers (fig. 9).
2. Slide the basket forward off the rails.
3. Re-insert the other set of wheels into the rails.
4. Swing the basket retainers closed (fig.9).
Fig.9
16
The images below are designed as guidance as to best practice
for loading the dishwasher.
Fig.10
Upper basket
Lower basket
Fig.11
Bad loads
Fig.14
Fig.15
Fig.12
Fig.13
17
Standard Loading and Test Data
Capacity
• Upper and lower baskets: 10 place settings.
• The upper basket should be adjusted to high position.
• Cups should be placed on to the dish rack pins.
Detergent / Rinse Aid
• 5 + 20 cm
3
, in accordance with EN50242-DIN 44990 IEC
436 (international norms) / Rinse aid dosage adjustment: 4.
Programme Test
• Eco 50°C, in accordance with EN 50242 (international
norms.).
18
Programme Listing
Programme
Name &
Temperature
Intensive +
70°C (P1)
Intensive
65°C (P2)
Express
65°C (P3)
Eco
50°C * (P4)
Quick
40°C (P5)
Prewash
(P6)
Level of Soil
High High Medium Medium Low -
Detergent
Required
A=25cm3/15cm3
B=5cm3
A + B A + B A + B A + B A -
Prewash
Prewash
Prewash Prewash Prewash Prewash
70°C Wash 65°C Wash 65°C Wash 50°C Wash 40°C Wash
End
Cold Rinse
Cold Rinse
Cold Rinse
Cold Rinse
Cold Rinse
Hot Rinse
Hot Rinse
Hot Rinse
Hot Rinse
Hot Rinse
Dry
Dry
Dry Dry Dry
End
End
End End End
Programme
Duration (min.)
124 115 50 186 30 15
Electricity
Consumption
(kW hour)
1.31 1.33 1.08 0.83 0.71 0.02
Water
Consumption
(litre)
15.1 17.6 10.5 13.0 10.0 3.5
The values and times provided above have been obtained under
laboratory conditions according to relevant standards. Actual
results obtained can vary depending on the conditions of the
dishwasher’s use and environment (mains supply voltage, water
pressure, water input temperature and environment temperature).
*Laboratory measured value in accordance with European
standard EN50242
19
Care and Maintenance
Before beginning any care or
maintenance, you should always
disconnect the appliance from the
electricity supply, and also turn off the
water supply.
Fascia
Wipe the fascia clean using just a damp
cloth rinsed in a mild liquid detergent
solution and well wrung out.
Door Seals
Wipe the dishwasher door seals regularly
with a damp cloth to remove any
residues.
Filters
You should clean the filters at least once
a month.
1. Remove the lower basket.
2. Turn the microfilter
anticlockwise and then lift it out
(figure 16).
3. Remove the coarse filter from
the microfilter (figure 17).
4. Remove the base filter from the
dishwasher compartment (fi
gure 18).
You should clean and rinse the
filters thoroughly before
replacing all the sections in
20
reverse order to that above. The microfilter should lock
into place once it is secure (figure 19).
Please note: Never run a programme without the filters in
place. Incorrect fitting of the filters may reduce wash
performance and potentially damage your appliance.
Spray Arms
You should clean the spray arms at least once a month.
1. Remove the lower basket
2. Pull the lower spray arm upwards to remove it.
3. To remove the upper spray arm, first remove the nut on the
upper spray arm by turning it (figure 9).
4. You should clean and rinse the spray arms thoroughly
before replacing them. Ensure that the upper spray arm nut
is securely tightened when refitting the upper spray arm.
To deal with an accumulation of dirt, oil or limescale in the
dishwasher, run an intensive programme with detergent when the
dishwasher is empty.
Alternatively, there are specialist dishwasher cleaners available
that can be used.
21
Failure Codes and Troubleshooting
The programme indicators also serve as a diagnostic display to
help in the event of a problem with the appliance.
Error Code
Error Description
Advice
F1
Alarm is active against
water flow
Turn off dishwasher and disconnect water
supply
Contact CDA Customer Care
F2
Waste water in the
machine cannot be
discharged
Drain hose is blocked
The filters in the machine may be blocked
Restart the dishwasher and cancel the
programme
If the error continues contact CDA Customer
Care
F3
Continual fill error
Contact CDA Customer Care
F5
Inadequate water
supply
Make sure the water tap is fully open
Close the water tap, separate the water inlet
hose from the tap and clean the filter
Restart the dishwasher
If the error continues contact CDA Customer
Care
F6
Faulty heater sensor
Contact CDA Customer Care
F7
Overheating error
(temperature in the
machine is too high
Contact CDA Customer Care
F8
Heater error
Contact CDA Customer Care
F9
Spray diverter position
error
Contact CDA Customer Care
FE
Faulty electronic card
Contact CDA Customer Care
22
Problem
Possible Cause
The programme will not start
Check the plug, fuse and circuit breakers
of the mains supply
The water tap is turned off
The dishwasher door is not fully closed
The water inlet filter or the machine filters
are blocked
Water remains inside the dishwasher at
the end of the programme
The water drain hose is blocked or kinked
The filters are blocked
The dishwasher stops in the middle of a
programme
Power failure
Water inlet failure
Programme is on standby
Wash performance is of a low standard
Poor loading of dishes hinders wash
performance
Insufficient detergent added
Inappropriate wash programme selected
Spray arm is blocked
Filters clogged or incorrectly fitted
Water drain pump is blocked
White stains on the dishes
Insufficient detergent added
Rinse aid setting is too low
Insufficient dishwasher salt added
Water softener setting is too low
Salt compartment cap may not be
completely closed
The dishes are not completely dry at the
end of a programme
A programme without a drying stage was
selected
Rinse aid setting is too low
Dishes unloaded too soon (allow time for
drying)
There are rust stains on the dishes
Different sets of cutlery should be kept
separate
Too much salt (water softener setting is
too high)
Salt compartment cap not completely
closed
Poor appliance earth (check mains
electrical supply)
The door is not opening or closing
properly
Door tension not correctly adjusted on the
décor door
23
Electrical Information
Warning: This appliance must be earthed,
The mains lead of this appliance has been fitted with a BS 1363A
13 Amp fused plug. To change a fuse in this type of plug, follow
the steps below:
1. Remove the fuse cover and fuse.
2. Fit replacement 13A fuse, ASTA approved to BS 1362 type,
into the fuse cover.
3. Replace fuse cover.
Important: Do not use the appliance without the fuse cover in
position.
How to Connect an Alternative Plug
If the fitted plug is not suitable for your socket outlet, then it
should be cut off and disposed of safely to avoid the risk of
electric shock. A suitable alternative plug of at least 13 Amp rating
to BS 1363 should be used.
As the colours of the wires in the mains lead of this appliance may
not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:-
• The wire which is coloured GREEN and YELLOW must be
24
connected to the terminal which is marked with letter (E) or
by the Earth symbol or coloured GREEN and YELLOW.
• The wire which is coloured BLUE must be connected to the
terminal which is marked with the letter (N), or coloured
BLACK or BLUE.
• The wire which is coloured BROWN must be connected to
the terminal which is marked with the letter (L) or coloured
RED or BROWN.
If in doubt regarding the electrical connection of this appliance,
consult a qualified electrician. Do not shorten the supply cable,
the appliance may require removing for servicing.
N.B. Ensure that the plug socket is situated in an easily
accessible place.
25
Installation
• Do not install this appliance if it is
damaged in any way. Installing a
damaged appliance may
invalidate the warranty.
• The water supply tap should be
located in an adjacent cupboard
so that it can be accessed after
installation.
• Ensure the appliance is level by
adjusting the feet as necessary.
The dishwasher is equipped with
an adjustable rear foot that can
be raised or lowered by means
of an adjustment screw, located
in the centre of the kick plate.
• Only use the water inlet supplied
with the appliance.
• If the water pressure is above 10
bar, a pressure relief valve
should be used.
• After connecting the water
supply, check to ensure there
are no leaks.
• The water outlet can either be
connected to a water drain or to
a sink outlet spigot. This
connection should be at a
minimum of 50 cm and a
maximum of 110 cm from the
floor. The drain hose should be
no longer than 4m in length to
ensure good performance from
the dishwasher.
• To prevent syphoning, ensure
26
that the water outlet is not pushed too far into the waste
standpipe. The lowest part of the water outlet should be
level with the bottom basket of the dishwasher.
• When connecting to the sink, ensure that the waste pipe
runs higher than the level of the sink bowl to prevent
syphoning.
Fitting the Integrated Appliance Door
Where non-standard integrated appliance doors are supplied,
additional fitting instructions are required to ensure compatibility
with this product.
The machine is supplied with a fitting template and these
instructions should be followed as normal.
However, the fitting template needs to be located lower down the
fascia door; this is shown below.
The amount of offset, Y, depends on
the height of the fascia door and can
be calculated as X = 723mm.
For example, if you have a 731mm tall
fascia door and are fitting a door to
your dishwasher,
then Y = 731-723 = 8mm.
Ensure that the hinge tensioners are
adjusted to balance the weight of the
door.
27
NOTES:
28
1. brackets.
Loading...
