CDA WC370 User Manual

WC370 Integrated Dishwasher

Manual for Installation, Use and Maintenance

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu

Important

The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this
product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect
installation or misuse of the appliance.

This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental
capacity, or who lack experience or knowledge about it, unless they have had supervision or instructions on how to use
the appliance by someone who is responsible for their safety.

Under no circumstances should any external covers be removed for servicing or maintenance except by suitably
qualified personnel.

Appliance information:

Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a
fault with your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

This appliance has been designed for domestic use only. Commercial use will invalidate the warranty

CE Declarations of Conformity:

This appliance has been designed, constructed and marketed in compliance with safety requirements of EEC Directives
89/336/EC, 2006/95/EC, IEC436/DIN44990, EN 50242

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer
providing appliance recycling services.

Disposing of a household appliance separately avoids possible negative consequences for the environment and health
deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings
in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked
with a crossed-out wheeled dustbin.

Important

• Read the instructions prior to installation and use of the appliance.

• Do not lean or climb on the open dishwasher door to prevent damage.

• Close the dishwasher door after use to prevent accidents.

• Use only detergents, salt and rinse aid specifically designed for dishwashers.

• Do not put solvents in the dishwasher detergent compartment to prevent risk of explosion

• Only put dishwasher safe items into the dishwasher. If in doubt, check with the manufacturer of the items.

• Take care when loading the dishwasher to observe the recommendations for best loading practice, and also to ensure

that sharp objects such as knives are placed blade down to prevent accidents.

• Do not open the dishwasher door when a programme is running. If it is necessary to do so, then open it

only slightly to allow the dishwasher to pause the programme and prevent any water spilling out. Remember that the
water in the dishwasher can be very hot when the programme is running.

• When the dishwasher is not in use, we reccomend that you turn off the water supply at the supply tap and disconnect

the main supply.

• If you are leaving the dishwasher for an extended period you should leave the door slightly open to prevent the

formation of unpleasant smells.

Disposing of a household appliance separately avoids possible negative consequences for the environment
and health. It also enables the constituent materials to be recovered, saving both energy and resources. As a
reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out
wheeled dustbin.

.

1

• The plastic housing on the water inlet pipe contains an electrically operated valve. The wires that connect to this valve

are inside the inlet hose. Do not cut through the inlet hose, and do not put the plastic housing in water.

• Children could get locked inside the appliance. Therefore when disposing of an old appliance, cut off the plug and set

aside, and damage the door lock so that the door can no longer be closed.

Recommendations

• To reduce energy and water consumption, remove all dirt residues from the dishes prior to loading the dishwasher.

• Only run the dishwasher when fully loaded.

• Place hollow items (bowls, glasses and pans) face down in the basket.

• Do not put dishes or cutlery with tobacco ash, wax, lubricating grease or paint residues in the dishwasher.

Before First Use

• Set the water softener level as required by the water hardness in the area.

• Add 2kg of salt into the salt compartment and then fill with water to the top of the salt compartment.

• Remove all the packaging materials from the interior of the dishwasher.

• Fill the rinse aid compartment.

• Run a hot programme without any dishes in the dishwasher.

2

Control Panel

1 2 3 4 5 6 7 8

Power button (1)

• To switch the dishwasher on or off, press the power button (1). When you switch on the dishwasher, the end of

programme light will illuminate, and two dashes will appear on the display.

Programme display (2)

The programme display shows the selected programme and the remaining time to run. If there is a fault on the
dishwasher, the fault code will show on the display.

Programme selection button (3)

• To select a programme, press the programme selection button (3). The dishwasher will store in its memory the last

programme used.

Delay timer button (4)

The dishwasher is equipped with a variable timer of up to 19 hours’ duration at hourly intervals.

• To set the delay timer, press the delay timer button (4). This will switch the timer on for one hour.

• To change the delay duration, press the delay timer button again until the required delay duration is shown on the

display, alternating with the selected programme and the programme duration.

• To cancel the delay timer, press the delay timer button again until 0h shows on the display.

3 in 1 function button (5)

The dishwasher is equipped with a tablet function that automatically adjusts the amount of rinse aid and dishwasher
salt used during a programme.

• To use this function, press the button after selecting the programme, before you close the door.

Prewash button (6)

The dishwasher is equipped with a prewash function that automatically adds a prewash to the selected programme.

The prewash function improves the wash performance of the programme, but also can change the temperature and
duration of the programme.

• To use this function, press the button after selecting the programme, before you close the door.

The prewash is also an independent programme (8) which can be used to rinse the contents of the dishwasher, for
example if the dishwasher is not yet full and a complete programme is not yet required.

• To do so, select the programme as described below.

Half-load button (7) and indicator lights

The dishwasher is equipped with a half-load function that allows for either the upper or lower basket to be washed
independently, or for both baskets to be washed if they contain only a small number of dishes.

• To use this function, press the half-load button (7) until the indicator light shows next to the required section of the

dishwasher, either upper, lower or both lights if both baskets are to be washed together.

Salt and rinse aid warning lights (8)

When the dishwasher salt or rinse aid begins to run out, the warning light will illuminate
to advise that it needs refilling.

End of programme light (8)

When the programme is complete, the dishwasher will emit five beeps and the end of
programme indicator light will illuminate.

3

Please note: You should ensure that there are no dishes in the upper basket when running a lower basket
half-load programme, and none in the lower basket when running an upper basket half-load programme.

If you have selected any extra function (3 in 1, prewash, half-load) for a programme, this function will
automatically be selected the next time the dishwasher is used. To cancel the selection of any extra function,
press the specific extra function button (5, 6 or 7) until the indicator light for that function goes out.

Starting a programme

• Press the Power button (the end of programme light will be switched on)

• Press the Programme Selection button until the required programme is shown on the display.

• If required, set the delay timer by pressing the Delay Timer button

• Once a programme is selected, the end of programme light will switch off.

• When you close the dishwasher door, the programme will start automatically.

Please note: The dishwasher stores the most recently used programme in its memory. To change the
programme, simply press the Programme Selection button.

At the end of a programme

If possible, do not open the dishwasher door once the programme has started.
At the end of a programme, the dishwasher will beep five times, and the end of Programme Indicator light will switch on.

Changing a programme

It is possible to change the programme if necessary once the programme has started.

• First open the door slightly to reduce the risk of water spillage.

• Press the programme selection button until the required programme is shown on the display.

• Then close the door. The dishwasher will begin the new programme from the point at which the old programme stopped.

Cancelling a programme

It is possible to cancel the programme once is has started.

• First open the door slightly to reduce the risk of water spillage.

• Press and hold in the Programme Selection button for three seconds until the end of programme indicator flashes and

a “1” shows on the display.

• Then close the door. The dishwasher will run a drain cycle which will take approximately 30 seconds. Once this is

complete, the dishwasher will beep five times and the end of programme light will switch on.

Switching the dishwasher off

• Once the dishwasher beeps five times and the end of programme light switches on, the dishwasher can be switched off

by pressing the Power button.

• Then turn off the water tap and remove the plug from the power socket.

Please note: the dishwasher will automatically continue on the programme it has started if the door is
opened or in the event of a power cut.

4

Detergent

fig 1

To fill the detergent compartment

1. Push the latch to open the compartment.

2. Add the required amount of detergent. The main detergent compartment
“b” (figure 1) has lines to allow for specific amounts of detergent. These
are marked at either 15 cm
the dishes are.
If your dishes are in need of an intensive wash, then add 5 cm
detergent into the prewash section of the compartment “a” (figure 1).

3. Then close the detergent compartment lid until the latch locks.

3

or 25 cm3, to be used depending on how dirty

3

of

Please note: You should only use detergents designed specifically for
use in dishwashers.

If using dishwasher tablets, always use the detergent compartment, do not
put them in the main body of the dishwasher or in the cutlery basket. The
solubility of dishwasher tablets can vary depending on the temperature and
duration of the programme. As a result, it is recommended that powder
detergents should be used in the shorter programmes to allow better
performance.

CDA recommends the use of separate detergent, rinse aid and dishwasher
salt rather than combination tablets as separates achieve better wash
performance.

If you do use combination detergents, add salt and rinse aid to the dishwasher
and then adjust the water hardness setting and rinse aid setting to the
minimum. When you then use separate detergents again, you should fill the
salt and rinse aid compartments, adjust the water hardness setting to the
maximum and run an empty wash, then adjust the water hardness setting and
the rinse aid setting to the appropriate level.

fig. 1

5

Salt

fig 2

fig 1

To ensure the best efficiency, the dishwasher needs soft water. Hard water
means that lime residues remain on the dishes and the interior of the
dishwasher, affecting performance. The softener system is designed to
remove the ions that make the water hard to provide the best quality wash
performance. This is achieved by using dishwasher salt.

To add dishwasher salt, follow the steps below:

1. Remove the lower dishwasher basket and then unscrew the salt
compartment cap, as shown in figure 2.

2. Fill the compartment with dishwasher salt (do not use table salt),
carefully to prevent unnecessary spillage (figure 3). Before first use, you
should fill the compartment with 2kg of dishwasher salt and then fill up
the salt compartment with water (up to the brim of the compartment) as
shown in figure 3.

3. Replace the cap and the lower basket.

When the salt warning light on the control panel illuminates, you should
refill the salt compartment with salt only – do not add water to the salt
compartment after the first use.

fig. 2

Important:

You should run a prewash programme immediately after adding dishwasher
salt, to prevent any damage to the dishwasher systems.

fig. 3

6

Softener Adjustment

Softener adjustment

The efficiency of your dishwasher depends on the softness of the tap water. To ensure best efficiency, the dishwasher
is equipped with a system that reduces the hardness in the mains water supply. The efficiency will increase when the
system is correctly set. To find out the water hardness level of your water supply you can use the test strip supplied or
alternatively contact your local water board.

ENGLISH

Open the
testing
strip.

Run
water
through
your tap
for 1
min.

Keep the
testing
strip in
water for 1
sec.

Shake the
testing strip
after taking it
out of water.

Wait for
1 min.

Make your machine’s water hardness
setting according to the result
obtained through the testing strip.

No Lime

Very low lime content
Low lime content

Medium lime content
Lime content
High Lime content

The efficiency of your dishwasher depends on the softness of the tap water.
To ensure best efficiency, the dishwasher is equipped with a system that
reduces the hardness in the mains water supply. The efficiency will increase
when the system is correctly set. To find out the water hardness level of your
water supply you can use the test strip supplied or alternatively contact your
local water board.

fig. 4

1. Open the testing strip (figure 4).

2. Run water through the tap for one minute.

3. Hold the testing strip in water for one second.

4. Remove from the water and shake the test strip to remove excess water.

5. Wait for one minute.

6. Check the number of marks on the strip to see the level of water
hardness.

If the hardness of the water you use is above 63 dE or if you are using well
water; you are recommended to contact your local water board to confirm
the water hardness level and to use filter and water refinement devices.

Please note: The level of water hardness is preset to level 3.

1. Press and hold down the programme selection button

2. Press the Power button to switch on the dishwasher

3. Keep the programme selection button pressed until “SL” shows on the
display and then disappears

4. To adjust the level, press the programme selection button until the
required level is shown on the display, as listed in the Table of Water
Hardness below.

5. To store the selected water hardness level, press the power button.

Water hardness level British hardness dE Display shows

7

1 0-6 L1

2 7-14 L2

3 15-21 L3

4 22-28 L4

5 29-39 L5

6 40-63 L6

Rinse Aid

fig 4

fig 4

fig 5

To fill the rinse aid compartment

1. Open the rinse aid compartment by turning and removing the cap as

shown in figure 5.

2. Fill the rinse aid compartment until the rinse aid indicator goes dark, as

shown in figure 6 (where a indicates the compartment is empty, and “b”

indicates the compartment is full).

3. Replace the cap, ensuring the markers on the cap line up with the

compartment prior to screwing the cap back in place.

Rinse Aid Adjustment

The level of rinse aid use is preset to 3. You can adjust the level of rinse aid

use by adjusting as shown in figure 7.

If water stains form on the dishes after a wash, the level should be increased.

If blue stains which can be wiped away are left on the dishes after a wash, the

level should be decreased.

Please note: Rinse aid ensures better quality wash results and

increased drying performance.

Always refill the rinse aid when the rinse aid indicator light on the

control panel is illuminated.

fig. 5

fig. 6

fig. 7

8

Dishwasher Baskets

Dishwasher Baskets

To adjust the height of the upper basket:

1. Open the basket retaining clips, as shown in gure 7, but turning them to

the side.

2. Remove the upper basket, and relocate the alternate set of wheels on the

runner, as shown in figure 8, pushing the basket back into place.

3. Close the basket retaining clips.

The images below are designed as guidance as to best practice for loading

the dishwasher.

g 7

fig 8

Upper basket

Lower basket

Bad loads

Basket height adjustment mechanism on the top basket of
your machine is designed to let you adjust the height of your
top basket upwards or downwards, without removing it from
your machine when it is full, and create large spaces at the top
or bottom area of your machine as needed. Basket of your
machine is set to upper position in factory settings.
In order to raise your basket, hold it from both sides and pull it
upwards. In order to lower it, hold it from both sides again, and

Basket height adjustment me chanism on the top basket of
your machine is designed to let you adjust the height of your
top basket upwards or downwards , without removing it from
your machine when it is fu ll, and create large spaces at the top
or bottom area of your machi ne as needed. Basket of your
machine is set to upper posi tion in factory settings.
In order to raise your bask et, hold it from both sides and pull it
upwards. In order to lower it, hold it from both sides again, and
leave it.

The upper basket has two different heights available, to allow for larger

products in either the upper or lower basket. To raise or lower the upper

basket:

1. Take hold of the basket handles, as shown in fig. 8.

2. Raise the basket up as high as possible, then lower it down until it stops.

The images below are designed as guidance as to best practice for loading the

dishwasher.

Lower basket

Upper basket Lower basket

fig. 8

9

Standard Loading and Test Data

3

, in accordance with EN50242-DIN 44990 IEC 436

Capacity

• Upper and lower baskets: 12 place settings.

• The upper basket should be adjusted to high position.

• Cups should be placed on to the dish rack pins.

Detergent / Rinse aid

• 5 + 25 cm3, in accordance with EN50242-DIN 44990 IEC 436

(international norms) / Rinse aid dosage adjustment: 4.

Programme test

• Economy 50°C, in accordance with EN 50242 (international norms.).

10

Programme Listing

Programme name

and temperature

Level of soil

Detergent

required

Programme

duration (mins.)

Auto

Intensive

60-70

Auto-

normal

O

50-60

Auto-

delicate

O

30-50

Intensive

O

Express

O

60

Economy

O

60

50

Quick

O

Prewash

O

40

-

High High Low High Medium Medium Low - High

A+B A+B A A+B A+B A+B A - A+B

The dishwasher is equipped with a sensor that

automatically adjusts the washing time, temperature

and amount of water required.

Prewash

O

60

Prewash Prewash Prewash Prewash

wash

60O wash

Cold rinse

50O wash 40O wash

Cold rinse Cold rinseCold rinse

Hot rinseHot rinseHot rinseHot rinse

DryDryDry Dry

111-183 100-127 64-92 123 55 170 30 15 161

Intensive+

O

70

Prewash

50O Prewash

70O wash

Cold rinse

Warm rinse

Hot rinse

Dry

EndEndEndEndEnd End

Electricity

consumption

(kW hours)

Water consump-

tion (liters)

1.25-1.78 1.03-1.28 0.6-0.8 1.55 0.93 1.05 0.71 0.02 1.75

13.3-24.6 10.9-18.5 10.6-17.7 15 11 13.5 11 4.2 22.7

The values and times provided above have been obtained under laboratory conditions according to relevant standards.

Actual results obtained can vary depending on the conditions of the dishwasher’s use and environment. (mains supply

voltage, water pressure, water input temperature and environment temperature).

Laboratory measured value in accordance with European standard EN50242

11

Care and Maintenance

Before beginning any care or maintenance, you should always disconnect the

appliance from the electricity supply, and also turn off the water supply.

Door seals

Wipe the dishwasher door seals regularly with a damp cloth to remove

any residues.

Filters

You should clean the filters at least once a month.

1. Remove the lower basket.

2. Turn the microfilter anticlockwise and then lift it out as in figure 9.

3. Remove the coarse lter from the microlter (gure 10).

4. Remove the base filter from the dishwasher compartment (figure 11).

You should clean and rinse the filters thoroughly before replacing all the

sections in reverse order to that above. The microfilter should lock into

place once it is secure as shown in figure 12.

Please note: Never run a programme without the filters in place.

Incorrect fitting of the filters may reduce wash performance and

potentially damage your appliance.

Spray arms

You should clean the spray arms at least once a month.

1. Remove the lower basket

2. Pull the lower spray arm upwards to remove it.

3. To remove the upper spray arm, first remove the nut on the upper spray

arm by turning it as in figure 9.

You should clean and rinse the spray arms thoroughly before replacing

them. Ensure that the upper spray arm nut is securely tightened when

refitting the upper spray arm.

Dishwasher interior

To deal with an accumulation of dirt, oil or limescale in the dishwasher, run

an intensive programme with detergent when the dishwasher is empty.

Alternatively, there are specialist dishwasher cleaners available that can be used.

fig 9

g 10

fig 11

MAINTENANCE AND CLEANING

Cleaning the machine in regular intervals prolongs the machine's service life.

Oil and lime may accumulate in the machine's washing section. In case of such
accumulation;

Cleaning the seals in the machine door,

Cleaning the machine,

Filters

-Fill the detergent compartment without loading any dishes into the machine, select a
programme that runs at high temperature, and start the machine. In case of insufficiency, use
special cleansing material available in the market. (Cleansing material produced special to
machines by detergent producers.)

-To clean any accumulated residues in the door seals, wipe the seals regularly by using a
dampened cloth.

Clean the filters and spray arms at least once a week.
Unplug your machine and turn off its tap before starting the cleaning.
Do not use hard materials when cleaning your machine. Wipe with a fine cleaning material
and a dampened cloth.

Check if any food wastes have remained on the coarse and fine
filters.
If any food wastes are left, remove the filters and clean them
thoroughly under the water tap.

a. Micro Filter
b. Coarse Filter
c. Metal/Plastic Filter

To remove and clean the filter combination, turn it counter
clockwise and take it out by lifting upwards.1

fig 12

arm by turning it.

12

Failure Codes and Troubleshooting

The programme indicators also serve as a diagnostic display to help in the event of a problem with the appliance.

Error Code Error description Advice

F1 Alarm is active against water overflow.

F2

F3 Continual fill error. Close the tap and contact CDA service

F4 Inadequate water supply.

F5 Faulty heater sensor. Contact CDA service.

F6

F7 Heater error. Contact CDA service.

F8 Spray diverter position error. Contact CDA service.

The waste water in the machine can not be

discharged.

Overheating error (temperature in the

machine is too high).

Turn off the dishwasher and disconnect the water supply.

Contact CDA service.

Drain hose is blocked.

The filters of your machine might be blocked.

Restart the dishwasher and cancel the programme.

If the error continues, contact CDA service.

Make sure the water inlet tap is fully open.

Close the water tap, separate the water inlet hose from the tap and

clean the filter.

Restart your machine, contact CDA service if the error resumes.

Contact CDA service.

F9 Faulty electronic card. Contact CDA service.

13

Failure Codes and Troubleshooting

Problem Possible cause

The programme will not start

Water remains inside the dishwasher at the end of a programme

The dishwasher stops in the middle of a programme

Wash performance is of a low standard

White stains on the dishes

The dishes are not completely dry at the end of a programme

There are rust stains on the dishes

The door is not opening or closing properly Door tension not correctly adjusted for the decor door.

Check the plug, fuse and circuit breakers of the mains supply.

The water tap is turned off.

The dishwasher door is not fully closed.

The water inlet filter or the machine filters are blocked.

The water drain hose is blocked or kinked.

The filters are blocked.

Power failure.

Water inlet failure.

Programme is on standby.

Poor loading of dishes hinders wash performance.

Insufficient detergent added.

Inappropriate wash programme selected.

Spray arm is blocked.

Filters clogged or incorrectly fitted.

Water drain pump is blocked.

Insufficient detergent added.

Rinse aid setting is too low.

Insufficient dishwasher salt added.

Water softener setting is too low.

Salt compartment cap may not be completely closed.

A programme without a drying stage was selected.

Rinse aid setting is too low.

Dishes unloaded too soon (allow time for drying).

Different sets of cutlery should be kept separate.

Too much salt (water softener setting is too high).

Salt compartment cap not completely closed.

Poor appliance earth (check mains electrical supply).

14

Electrical information

Warning! This appliance must be earthed.

The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug,

follow the steps below:

1. Remove the fuse cover and fuse.

2. Fit replacement 13A fuse, ASTA approved to BS 1362 type, into the fuse cover.

3. Replace fuse cover.

Important: Do not use the appliance without the fuse cover in position.

How to connect an alternative plug

If the tted plug is not suitable for your socket outlet, then it should be cut off and disposed of safely to avoid the risk of

electric shock. A suitable alternative plug of at least 13 Amp rating to BS 1363 should be used.

As the colours of the wires in the mains lead of this appliance may not correspond with the

coloured markings identifying the terminals in your plug, proceed as follows:-

• The wire which is coloured GREEN and YELLOW must be connected to the terminal which is marked with letter (E) or

by the Earth symbol or coloured GREEN and YELLOW.

• The wire which is coloured BLUE must be connected to the terminal which is marked with the letter (N), or

coloured BLACK or BLUE.

• The wire which is coloured BROWN must be connected to the terminal which is marked with the letter (L) or

coloured RED or BROWN.

If in doubt regarding the electrical connection of this appliance, consult a qualied electrician. Do not shorten the

supply cable, the appliance may require removing for servicing.

N.B. Ensure that the plug socket is situated in an easily accessible place.

15

Installation

• Do not install this appliance if it is damaged in any way. Installing a

damaged appliance may invalidate the warranty.

• The water supply tap should be located in an adjacent cupboard so that it

can be accessed after installation.

• Ensure the appliance is level by adjusting the feet as necessary.

• Only use the water inlet supplied with the appliance.

• If the water pressure is above 10 bar, a pressure relief valve should be used.

• After connecting the water supply, check to ensure there are no leaks.

• The water outlet can either be connected to a water drain or to a sink outlet

spigot. This connection should be at a minimum of 50 cm and a maximum

of 110 cm from the oor. The drain hose should be no longer than 4m in

length to ensure good performance from the dishwasher.

fig 14

fig 15

fig 16

fig. 13

Installation

• Do not install this appliance if it is damaged in any way. Installing a

damaged appliance may invalidate the warranty.

• The water supply tap should be located in an adjacent cupboard so that it

can be accessed after installation.

• Ensure the appliance is level by adjusting the feet as necessary. The

dishwasher is equipped with an adjustable rear foot that can be raised or
lowered by means of an adjustment screw, located in the centre of the kick plate.

• Only use the water inlet supplied with the appliance.

• If the water pressure is above 10 bar, a pressure relief valve should be used.

• After connecting the water supply, check to ensure there are no leaks.

• The water outlet can either be connected to a water drain or to a sink outlet

spigot. This connection should be at a minimum of 50 cm and a maximum of
110 cm from the floor. The drain hose should be no longer than 4m in length
to ensure good performance from the dishwasher.

• To prevent siphoning, ensure that the water outlet is not pushed too far into

the waste standpipe. The lowest part of the water outlet should be level with
the bottom basket of the dishwasher.

• When connecting to the sink, ensure that the waste pipe runs higher than the

level of the sink bowl to prevent siphoning.

100cm

4cm

40cm

10cm

recommended

fig. 13

fig. 14

fig. 15

16

Fitting the integrated appliance door

Where non-standard integrated appliance doors are supplied, additional fitting
instructions are required to ensure compatibility with this product.

The machine is supplied with a fitting template and these instructions should be
followed as normal.

However, the fitting template needs to be located lower down the fascia door;
this is shown below.

The amount of offset, Y, depends on the height of the fascia door and can be
calculated as X = 723mm.

For example, if you have a 731mm tall fascia door and are fitting a door to your
dishwasher, then Y = 731-723 = 8mm.

Y offset

Fitting template

X Door height

Ensure that the hinge tensioners are adjusted to balance the weight of the door.

17

Notes

18

To contact our Customer Care Department, or for Service,

please contact us on the details below.

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu
