CDA HVC65 User Manual

HVC65 / 75 Ceramic Hobs

Manual for Installation, Use and Maintenance

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu

Important

The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this

product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect

installation or misuse of the appliance or use in a commercial environment.

This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental

capacity, or who lack experience or knowledge about it, unless they have had supervision or instructions on how to use

the appliance by someone who is responsible for their safety.

Under no circumstances should any external covers be removed for servicing or maintenance except by suitably qualified

personnel.

Appliance information:

Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a

fault with your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity:

This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including

Electrical safety (LVD) 72/23/EEC and Electromagnetic interference compatibility (EMC) 289/336/EEC. Parts intended

to come into contact with food conform to 89/109/EC. This appliance also conforms to requirements of directive

93/68/EEC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC

DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer

providing appliance recycling services.

Disposing of a household appliance separately avoids possible negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both energy and resources. As a reminder of the need to dispose of

household appliances separately, the product is marked with a crossed-out wheeled dustbin.

1

Please note:

Before operating this hob, please read the instructions carefully

After unpacking the appliance, make sure it is not damaged. In case of doubt, do not use the appliance and contact your

supplier.

Remove all packaging and do not leave the packing materials in easy reach of children as they may cause serious injury. The

packaging materials are recyclable.

Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance.

Ceramic hobs become hot and remain hot during and immediately after use. Do not touch the hob until it has been allowed

to cool.

After use, please ensure that all the zones have been switched off.

Keep children away from the appliance when in use.

Pan handles should never stand out beyond the edge of the worktop. This will ensure children cannot reach them.

Do not use pans with rough bases (e.g. cast iron) as these may scratch the hob surface.

Ensure the base of the saucepan is clean and dry before placing it on the zone.

Do not switch on the zones without cookware in place.

Do not lean over the hob when it is in use.

Do not drop heavy or sharp objects on to the hob top.

Do not scratch the hob top with sharp objects.

Follow the cleaning instructions carefully.

Never put cooking foil or plastic materials on the hob top when it is hot. These materials could melt and cause damage to

the hob.

Do not leave inflammable materials on the hob top.

Never use the hob top for storage or as a worktop.

Do not leave wet or damp pan lids on the hob.

Important

Do not use the hob if the glass surface is cracked or damaged to prevent risk of electric shock, Disconnect it from the power

supply.

Do not use the hob if the electrical cord is damaged.

When correctly installed, this hob meets all the safety requirements laid down for this type of product. However, special

care should be taken around the underneath of the appliance as this area is not designed or intended to be touched and may

contain sharp or rough edges, that may cause injury.

This hob (Class 3) has been designed for use only as a cooking appliance. Any other use (e.g. heating rooms) should be

considered incorrect and therefore dangerous.

This appliance is not intended to be operated by any means of an external timer or separate remote control system.

Make sure that electrical cords connecting other appliance do not come into contact with the hob top.

Before disposing of an unwanted appliance, it is recommended that it is made inoperative and that all potentially hazardous

parts are removed.

2

Using your hob

HVC65
Zones:

1. Front left 1.8 kW 180 mm

2. Rear left 1.2 kW 140 mm

3. Rear right 0.75/2.2 kW 120/210 mm dual

4. Front right 1.2 kW 140 mm

5. Touch control panel

2

1

3

4

HVC75
Zones:

1. Front left 0.75/2.2 kW 120/210 mm dual

2. Rear left 1.2 kW 140 mm

3. Rear right 0.8/2.2 kW – 180x260 mm

4. Front right 1.2 kW 140 mm

5. Touch control panel

The Touch Control

1 Timer key
2 Timer display
3 Timer zone indicator
4 Dual zone indicator (where available)
5 Dual zone key
6 Zone display
7 Minus key for all zones
8 Plus key (zone specific)
9 Zone indicator
10 Power key

Fig.1

2

1

Fig.2

5

3

4

5

1

2 3 4

Fig.3

5 6 7 8 9 10

3

How to use the hob

The ceramic surface of the hob allows fast transmission of heat

vertically from the heating elements under the glass to the pans

on the hob top.

The heat does not spread horizontally, so the hob top remains

relatively cool only a few centimetres from the zone in use.

Please note:

The heating elements are equipped with a temperature limiter

that will switch the element off to prevent damage to the hob.

The temperature limiter may also operate when incorrect pans

are used or pans are poorly positioned. This will affect cooking

performance.

The temperature limiter can be seen in the zone as the straight

line out from the centre of the element. This is not a fault with

the hob.

To switch the hob on

Touch and hold

Please note:

If a zone is not selected or the timer set within 20 seconds, the hob will automatically switch off.

until the zone displays show 0.

Hi-light cooking zone

Ø 140mm

Hi-light cooking zone

Ø 180mm

Second element

Hi-light double zone

Hi-light oval
double zone

fig. 4

fig. 5

To switch on a zone

Once the hob is switched on, touch

EITHER Touch and hold

on the zone display.

OR Touch and hold

The zone will remain active for approximately ten seconds to allow for adjustment.

To adjust the power level once set

for the zone required. The zone indicator will switch on to confirm the zone is active.

Touch

Touch and hold

To use the dual zone

The dual zones are formed of two separate coils of resistant material.

The dual zone will switch on automatically when the zone is selected. Touch

The dual zone indicator will switch on when the dual zone is on.

To switch off a zone

for the zone required.

Touch

EITHER Touch

OR Touch and hold

The zone display will alternate between 0 and H to indicate the residual heat.

To switch the hob off

Touch and hold

.

to select the power level from 1 (minimum) to 9 (maximum). The power level selected will show

to select the power level from 9 to 1.

or until the required power level shows on the zone display.

and at the same time.

until the zone display shows 0.

at any time.

for the zone required. The zone indicator will switch on to confirm the zone is active.

at any time to switch the dual zone on or off.

4
