CDA FWC621, FWC151, FWC301, FWC601 User Manual
FWC151 / FWC301 / FWC601 /
FWC621 Wine Coolers
Manual for Installation, Use and Maintenance
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu
Important
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please
note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse
of the appliance or use in a commercial environment.
This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had supervision or instructions on how to use the appliance by
someone who is responsible for their safety.
Under no circumstances should any external covers be removed for servicing or maintenance except by suitably qualified
personnel.
Do not use the appliance if the plug, the mains cord or the appliance itself is damaged. If the mains cord is damaged, you must
have it replaced by the manufacturer, or an authorised service centre or similarly qualified persons in order to avoid a hazard.
Children should be supervised to ensure that they do not play with the appliance. Keep the mains cord out of the reach of
children. Do not let the mains cord hang over the edge of the table or worktop on which the appliance stands.
Appliance information:
Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity:
This appliance has been designed, constructed and marketed in compliance with safety requirements of EEC Directive 2006/95/
EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE
2002/96/EC.
Please render the appliance unusable before disposal. This includes removing the plug and breaking the door fixings to prevent
children being trapped inside the appliance during play, or any other risk of injury.
At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority
differentiated waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and
resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out
wheeled dustbin.
1
Before first use
You must allow the appliance to settle for at least twenty four hours prior to switching the power on.
It is recommended that you remove all internal and external packaging and clean the interior of the appliance prior to first use,
using a solution of bicarbonate of soda and warm water and then thoroughly dry the interior.
The appliance may have an odour to it at first use. This will disappear as the appliance cools.
Please note:
• The appliance will work continuously until it gets to the correct temperature.
• If the appliance is switched off, you should allow five minutes before switching it on again to prevent the risk of
unnecessary damage to the compressor.
• The LED display may not show the selected temperature whilst the appliance first gets to the correct temperature. This is
normal, and the display will be corrected automatically once the appliance has run for a few hours.
Use
• Only store wine in sealed containers
• Do not overload the cabinet
• Only open the door when necessary
• Do not cover the shelves with aluminium foil or anything else that will prevent air from circulating around the cabinet.
• To prevent damage to the door seal, ensure the door is fully open before removing the shelves.
• This is a self-defrosting appliance. The compressor will not run during the thirty minute defrost cycle.
• Do not pull the shelves beyond the anti-stop position (approximately one third out) when fully loaded.
• This appliance is intended to be used exclusively for the storage of wine.
• In the event of a power failure, leave the door closed as much as possible to maintain the internal working
temperature. Should the power failure continue for a prolonged period, you should take steps to protect the contents
of the wine cooler against a rise in temperature.
This appliance is suitable for use in an extended temperature climate (N for FWC151, N/ST for FWC301/FWC601/
FWC621) and has a normal operating ambient temperature of 16-38C. Use of the appliance below 10C may cause
performance issues that are not indicative of a fault. Normal operation will resume once the appliance is within the
specified range.
FWC151, FWC301 & FWC621 will not be able to reach the required temperature if the ambient temperature is lower than
that required.
2
Use and Controls
FWC151
1 2
FWC301
1 2
To switch the power on/off
Press and hold the power button for five seconds.
To change the temperature
• Press the up or down buttons until the required temperature is shown on the display.
• The preset temperature is 12˚C / 54˚ F.
• To change the temperature display from Fahrenheit to Celsius, or Celsius to Fahrenheit, press and hold the light button
for five seconds.
• To view the set temperature, touch the up or down button at any time and the set temperature will flash in the LED
display for five seconds.
3
4
Key:
1 – Power button
2 – Light button
3 – Up button
4 – Down button
3 4
Key:
1 – Power button
2 – Light button
3 – Up button
4 – Down button
fig. 1
fig. 2
Optimal temperature selection
Whilst wine is best stored at temperatures between 13 and 15˚ C, your wine can also be stored at drinking temperature. For
red wine this is between 15 and 17˚ C, and for white wine between 12 and 13˚ C.
To use the internal light
• Press the light button to switch the light on or off.
3
Use and Controls
FWC601
3
To switch the power on/off
Press and hold the light and temperature set buttons simultaneously for five seconds.
To change the temperature
• Press the temperature set button once to select the upper zone.
• The LED display for the upper zone will flash.
• Press the up or down buttons until the required temperature is shown on the display.
• Press the temperature set button again to select the lower zone.
• The LED display for the lower zone will flash.
• The preset temperature for the upper zone is 10˚C / 50˚ F and for the lower zone is 16˚C / 60˚ F.
• To change the temperature display from Fahrenheit to Celsius, or Celsius to Fahrenheit, press and hold the
for five seconds.
• To view the set temperature in either zone, touch the up or down button at any time and the set temperature will flash
in the LED display for five seconds.
41 2
Key:
1 – Light button
2 – Temperature set button
3 – Up button
4 – Down button
button
fig. 3
Optimal temperature selection
Whilst wine is best stored at temperatures between 13 and 15˚ C, your wine can also be stored at drinking temperature, for
red wine this is between 15 and 17˚ C, and for white wine between 12 and 13˚ C.
To use the internal light
• Press the light button to switch the light on or off.
Please note:
The temperature in the lower zone must be set either the same or higher than the temperature in the upper zone. For
optimal performance, the temperatures in the two zones should differ by at least 4˚ C
4
