CDA FW222 User Manual

FW222 integrated under
counter larder fridge

Manual for Installation, Use and Maintenance

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

FW222 Fridge Freezer Manual.indd 1 11/02/2011 16:38

T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu

Important

The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this

product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect

installation or misuse of the appliance.

This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental

capacity, or who lack experience or knowledge about it, unless they have had supervision or instructions on how to use

the appliance by someone who is responsible for their safety.

Under no circumstances should any external covers be removed for servicing or maintenance except by suitably

qualified personnel.

Appliance information:

Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a

fault with your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity:

This appliance has been designed, constructed and marketed in compliance with safety requirements of EEC Directive
2006/95/EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC.

This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including

Electrical safety (LVD) and Electromagnetic interference compatibility (EMC). Parts intended to come into contact with

food conform to EEC/89/109.4

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC

DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local

authority differentiated waste collection centre or to a dealer providing this service.

Disposing of a household appliance separately avoids possible negative consequences for the environment and health

deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings

in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked

with a crossed-out wheeled dustbin.

FW222 Fridge Freezer Manual.indd 2 11/02/2011 16:38

Important

Never store inflammable or explosive items and strong corrosive acids or alkalis in the appliance.

This is a household appliance, which is produced in accordance with the national standard. It is intended for food storage

only, not for storage of blood, medicine and biological products.

To prevent risk of fire, keep the appliance away from petrol or any other inflammables.

To prevent risk of electromagnetic interference or other accidents, do not place a microwave oven on top of the

refrigerator or use any electric appliance inside the refrigerator.

Do not allow children to play with or near the appliance.

The internal surface of freezer compartment is very cold when the appliance is running. Do not touch the surface

especially with wet hands.

Do not splash water onto the appliance. Keep it away from places of high humidity that may have adverse effect on the

electric insulation performance.

Please remove the door, door seal and shelves before disposal of the old appliance and put them away in a safe place to

prevent children from being entrapped.

Before first use

You must allow the fridge to settle for at least twenty four hours prior to switching the power on.

It is recommended that you clean the interior of the appliance prior to first use, using a solution of bicarbonate of soda

and warm water and then thoroughly drying the interior.

The fridge may have an odour to it at first use. This will disappear as the appliance cools.

Please note:

The appliance will work continuously until it comes down to the correct temperature.

If the appliance is switched off, you should allow five minutes before switching it on again to prevent unnecessary damage

to the compressor.

Setting the temperature

You must allow the fridge to settle for at least twenty four hours prior to switching the power on.

To adjust the temperature turn the thermostat control knob clockwise (from off) to the required level. The temperature

becomes colder the higher the number on the control.

FW222 Fridge Freezer Manual.indd 3 11/02/2011 16:38

Use

Fridge

• Never put liquids in the refrigerator uncovered.

• Never put hot foods in the refrigerator. Warm food should be allowed to cool to room temperature before being

put into the refrigerator.

• Nothing should rest against the rear wall of the refrigerator, as this will cause frost and possible condensation

problems which will be difficult to remove.

• Make sure food is clean and any extra water is wiped away before putting into the fridge.

• Wrap or cover food before putting into the fridge. This will help prevent the loss of moisture, keep food fresh and

avoid unpleasant odours.

• Sort foods prior to storing. Any foods to be used soon should be stored at the front of the shelf to prevent

deterioration caused by the door being open for prolonged periods.

• Do not overfill the fridge. There should be sufficient space between the foods to allow the cool air to circulate.

• Thawing frozen foods in the fridge compartment will help to keep the temperature low and save energy.

• Only open the door for as long as is necessary. Leaving the door open for long periods will affect the temperature

inside the appliance and waste energy.

• Ensure all compartments are fully closed after use.

FW222 Fridge Freezer Manual.indd 4 11/02/2011 16:38

Care and cleaning

Always disconnect the appliance from the power supply before any cleaning or maintenance.

The fridge sections should be cleaned using a solution of bicarbonate of soda and lukewarm water. Do not use abrasive

products or detergents. After washing, rinse and dry thoroughly.

Clean the shelves and balconies separately by hand with soap and water. Do not put them in the dishwasher.

The water drain hole at the back of the fridge compartment and the evaporating tray should be clened periodically to

prevent the defrosted water from collecting inside the fridge compartment. The drain plug can be used to clean the

drain hole.

Once cleaning is complete, then reconnect the power.

• Keep the door gasket clean. If damaged, the gasket should be replaced.

• If the appliance is not used for prolonged periods of time, unplug and clean the appliance. The door should be left

slightly open to prevent the formation of mildew and smell.

Defrosting the fridge

The fridge is self-defrosting. Any water created will run out of the fridge through the channel at the back of the fridge.

It is important to keep the channel clear at all times. The defrosted water is collected in the evaporating tray at the back of

the appliance.

fig. 1

Changing the light bulb

Disconnect the appliance from the power.

• Carefully remove the light cover by pushing in the lever at the back of the cover, and then pulling the cover down..

• Unscrew the light bulb to remove it and replace with a new bulb (not more than 15W).

• Replace the light cover and reconnect the power after five minutes’ delay as explained on page 3.
