CDA EVP61, EVP91, EVP101, EVP121 Installation, Use And Maintenance Manual

1

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu

www.cda.eu

EVP61/91/101/121
Extractors

Installation, Use and Maintenance

2

Important

The manufacturer cannot be held responsible for injuries
or losses caused by incorrect use or installation of this
product. Please note that the manufacturer reserves the
right to invalidate the guarantee supplied with this product
following incorrect installation or misuse of the appliance
or use in a commercial environment.

This appliance is not designed to be used by people
(including children) with reduced physical, sensorial or
mental capacity, or who lack experience or knowledge
about it, unless they have had supervision or instructions
on how to use the appliance by someone who is
responsible for their safety.

Under no circumstances should any external covers be
removed for servicing or maintenance except by suitably
qualified personnel.

Appliance information:

Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault
with your appliance and to register your appliance for guarantee
purposes.

Appliance Model

Serial Number

3

CE Declarations of Conformity:

This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Gas safety, Electrical
safety (LVD) and Electromagnetic interference compatibility (EMC).

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services. Disposing of a household appliance
separately avoids possible negative consequences for the
environment and health. It also enables the constituent materials to
be recovered, saving both energy and resources. As a reminder of the
need to dispose of household appliances separately, the product is
marked with a crossed-out wheeled dustbin.

Please note:

• Under no circumstances should the extractor be

connected to any gas ventilation system, flue system or hot
air ducting system.

• Do not vent the extractor into an attic or loft space.

• Only house the extractor in rooms with adequate

ventilation. Remember that the extractor is powerful and
whatever air is extracted needs to be replaced.

• Do not tile the extractor in. It should be removable for

service or maintenance.

• Do not use silicone sealant to secure the hood to the wall.

• You must be able to isolate the extractor from the mains

electrical supply after installation.

4

• Steam cleaners must not be used when cleaning this

appliance.

• The performance of your extractor will vary depending

on a number of factors. These include: type of extraction,
length of ducting, room volume, ventilation available and
cleanliness of the filters.

Using your Extractor

For best performance, you should switch on the extractor 15 minutes
before starting to cook and leave it to run for approximately 15
minutes after the end of cooking.

Control Panel

A - Light key
B - Decrease speed key
C - Display
D - Increase speed key
E - Timer key

To switch the extractor light on and o

• Touch key “A”.

Fig. 1

A

B

C

D

E

5

To switch on the extractor

• Touch either key “B” or “D”. The appliance will switch on at the first

speed.

• To increase the speed touch key “D”.

• To switch the extractor o, touch and hold key “B” for two seconds

when the extractor is working at higher speeds, or touch key “B” at
speed one.

The intensive function

• The extractor is equipped with an intensive function which runs for

ten minutes before returning to the previous selected speed. To
activate the intensive function, touch key “D” at speed three. The
display will blink whilst the intensive function is on.

The timer

• The extractor is equipped with a timer that allows the extractor to

run for 15 minutes before switching o automatically.

• To activate the timer, touch key “E”. The display will flash a decimal

point when the timer is on. Please note: The timer cannot be
activated when the intensive function is on.

The clean air function

• The extractor is equipped with a clean air function that switches on

the motor for ten minutes every hour at speed one.

• To activate the clean air function, touch key “E” for two seconds

when the appliance is o. To return to normal function, touch
either key “B” or “D”. To switch o the clean air function, touch
key “E”. The display “C” will light up in sections whilst the motor is
running, and will show the letter “C” during the fifty minutes when
the motor is not running.
