User’s Manual

WLAN 11b USB Module 12*71

WL-1205

Version1.2

2004/05/27

Table of Contents

Information to User……………………………….. 3

1 Introduction………………………………………... 5

2

Wireless LAN basics……………………………… 6

Windows Installation……………………………… 7

3

Install Driver/Utility………………………………..

3.1

Configuration Utility………………………………………….

3.2

3.2.1 Configured at “Windows XP configuration”……..

3.2.2 Configured at “Advanced configuration”…….

Technical Specifications of WLAN 11b USB Module

4

12*71

Troubleshooting…………………………………… 17

Glossary…………………………………………… 18

…

8

10

10

11

15

Product names mentioned herein may be trademarks and/or registered trademarks of their respective companies.

2

INFORMATION TO USER

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate this equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

3

This device is intended only for OEM integrators under the following

conditions:

The transmitter module may not be co-located with any other transmitter or antenna.

As long as conduction above is met, further transmitter

However, the OEM integrator is still responsible for testing their end-product for any

additional compliance requirements required with this module installed (for example,

digital device emissions, PC peripheral requirements, etc.).

test will not be required.

IMPORTANT NOTE: In the event that these conditions can not be met (for example

certain laptop configurations or co-location with another transmitter), then the FCC

authorization is no longer considered valid and the FCC ID can not

final product. In these circumstances, the OEM integrator will be responsible for

re-evaluating the end product (including the transmitter) and obtaining a separate

FCC authorization.

be used on the

End Product Labeling

The final end product must be labeled in a visible area with the following: “Contains

TX FCC ID: PANWL1205”.

Manual Information That Must be Included

The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the users manual of the end
product which integrate this module.

IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements.
The antenna must not be co-located or operating in conjunction with any other antenna

or transmitter.

4

REGULATORY INFORMATION

WLAN 11b USB Module 12*71 must be installed and used in strict accordance with

the instructions. This device complies with the following radio frequency and safety

standards.

USA - Federal Communications Commission (FCC)

This device complies with Part 15 of FCC Rules.

The channel identifiers, channel center frequencies, and regulatory domains of each

22-MHz-wide channel are shown in following Table.

Channel

Center

Frequency

Identifier

(MHZ)

1 2412

2 2417

3 2422

4 2427

5 2432

6 2437

7 2442

8 2447

9 2452

10 2457

11 2462

12 2467

Regulatory Domains

North

Japan ETSI

America

ˇ ˇ ˇ

ˇ ˇ ˇ

ˇ ˇ ˇ ˇ

ˇ ˇ ˇ ˇ

ˇ ˇ ˇ ˇ

ˇ ˇ ˇ ˇ

ˇ ˇ ˇ ˇ

ˇ ˇ ˇ ˇ

ˇ ˇ ˇ ˇ

ˇ ˇ ˇ

ˇ ˇ ˇ

ˇ ˇ

Israel France Mexico

ˇ ˇ

ˇ ˇ

ˇ

13 2472

14 2484

ˇ ˇ

ˇ

5

ˇ

1. Introduction

Thank you for purchasing Wireless Local Area Net (WLAN) 11b USB
Module 12*71. You are about to install a networking system that is not only
fast and powerful, but also easy to set up and simple to maintain. In a short
time you and those in your network will be able to share a local printer and
files, access the Internet, and roam about the office wire-free.

Using radio frequency (RF) technology, WLANs transmit and receive data
over the air, minimizing the need for wired connections. Thus, WLANs
combine data connectivity with user mobility, and, through simplified
configuration, enable movable LANs.

This wireless networking solution has been designed for both large and
small businesses, and it is scalable so that you can easily add more users
and new network features as your business grows.

This manual will assist you in the installing WLAN 11b USB Module 12*71.

6

2. Wireless LAN basics

Wireless LAN network defined by IEEE 802.11b standard committee could be
configured as:

• Ad Hoc wireless LAN, or

• Infrastructure wireless LAN.

Ad Hoc network is a group of notebooks with wireless LAN PC card called a
BSS (Basic Service Set). These notebooks use their wireless LAN PC cards to
communicate with each other, and notebooks cannot connect to the Internet.

STA 1

STA 2

STA 3

Figure 2-1 Ad Hoc wireless network

The most obvious differentiation between Infrastructure wireless network and
Ad Hoc wireless network is that the notebooks in Infrastructure wireless
network can make use of the resource in the Internet through Access Point.

Access Point

STA 1

STA 2

STA 3

Figure 2-2 Infrastructure wireless network

Internet

To set up your notebook’s network as the type of “Ad Hoc” or “Infrastructure”
wireless network depends completely on your requirement. Generally, if your
network environment has an Access Point, we recommend that you set it as
“Infrastructure” to connect to the Internet.

7
