Page 1
go cart DESK
hardware
Thank you for purchasing the Go Cart Desk. This
page
lists all the contents included in the box. Please
take the time
individual components
and prepare for assembly, place the contents on a
carpeted or padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
to identify the hardware as well as the
to this product. As you unpack
components
14 - bolts 4 - spring
washers
2 - locking
wheels
Missing hardware?
Please call 800.606.6387 for replacements.
tool required
wheel hex wrench (included)
hex wrench (included)
allen wrench (included)
14 - hex
nuts
2 - wheels
1 - front
left
support
Made in Taiwan - r06
1 - front
right
support
nut
shelf
1 - desktop
2 - short
crossbars
1 - long
crossbar
2 - back
supports
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
bolt
front right
support
Attach desktop to front left/right supports and
back supports as shown with 8 bolts and 8 hex
nuts. While holding each hex nut stationary with
the hex wrench, tighten each bolt using the allen
1
wrench.
support
front left
support
desktop
back
support
Page 1 of 2
Page 2
go cart DESK
A
long
crossbar
front
NOTE:
Make sure
locking wheels
are in front
spring
washers
B
short
crossbar
A. Attach long crossbar to assembled unit with 2
bolts and 2 hex nuts. Secure bolts with an allen
wrench. Secure nuts with a hex wrench.
B. Attach 2 short crossbars to assembled unit
with 2 bolts and 2 hex nuts per crossbar.
2
CLEANING AND CARE
Clean surfaces with a dry or damp soft cloth. Do not use
abrasive cleaners.
A
A. Attach 2 spring washers and 2 locking wheels
to front of assembly as shown. Secure wheels by
fully tightening each with the wheel hex wrench.
B. Attach 2 spring washers and 2 wheels to back
of assembly with the wheel hex wrench as shown.
3
Assembly is now complete.
B
Made in Taiwan - r06
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
Page 2 of 2
