Speaker wall mount bracket - 35mm pole - 250mm
2
Highlights:
Fits all speakers with 35 mm stand adaptor•
Can carry a max load of 40 kg•
250 mm distance to wall•
Speaker blocking•
5-Step adjustable incline angle (0° - 45°)•
Horizontal swivel adjustment at any angle•
Solid steel construction•
Available in Black (/B) & White (/W)•
The WLB25 is a wall mountable speaker installation bracket,
containing a 35 mm pole which allows safe and easy installation
for any loudspeaker fitted with a 35 mm pole adapter. The
incline angle is adjustable in 5 steps from 0° up to 45° while in
horizontal way the speaker can be adjusted in any direction. A
speaker blocking mechanism keeps it in the right direction after
installed. The solid steel construction allows a maximum load of
40 kg. The WLB25 is available in both black (/B) and white (/W)
colour.
WLB25
Product Features:
Dimensions 140 x 250 x 267.5 mm (W x H x D)
Weight 2.120 kg
Max. load 40 kg
Pole mount 35 x 120 mm (Ø x H)
Distance to wall 250 mm
Adjustable angle 0° / 11.25° / 22.5° / 33.75° / 45°
Construction Steel
Colours Black (RAL9004)
White (RAL9010)
Variants:
WLB25/B - Black version•
WLB25/W - White version•
CAYMON - WLB25 - 02/02/2025 15:15 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 1 of
Page 2
Technical drawings:
250
122
140
104 104
250
52
143
45°
299
164
Ø10 (6x)
3
Product description:
Weight: Outer dimensions: Unit height:
(w x h x d)
WLB25
1,96 kg 164 x 299 x 268 N/A
SPEAKER WALL MOUNT BRACKET - 35 MM
POLE - 250 MM
2
CAYMON - WLB25 - 02/02/2025 15:15 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 2 of
