Cassida 5520 User Manual
Moving money forward
UV MG
COUNT
UV MG
COUNT
®
Cassida 5520 Digital Currency Counter
3
This manual contains important information on safety
measures and operational features, please read it
carefully before operating your currency counter and
keep it for future reference.
Moving money forward
®
4
Table of contents:
1. Introduction
1.1 About the Cassida 5520 __________________________________________________ 5
1.2 Box contents _____________________________________________________________ 5
1.3 Front and rear views ______________________________________________________ 6
1.4 Control panel ____________________________________________________________ 8
1.5 Specications ____________________________________________________________ 9
1.6 Important safety notes ___________________________________________________ 9
2. Getting started
2.1 Powering up ____________________________________________________________10
2.2 Loading the hopper _____________________________________________________ 10
2.3 Carrying the unit ________________________________________________________11
3.1 Counting mode _________________________________________________________ 11
3. Operating Modes
3.2 Batching mode _________________________________________________________12
3.3 Adding Mode ___________________________________________________________ 12
3.4 Add + Batch mode ______________________________________________________13
3.5 Value counting mode ___________________________________________________13
3.6 Value counting and add mode __________________________________________ 13
4. Detection Features
4.1 UV Counterfeit detection ________________________________________________14
4.2 MG Counterfeit detection (Cassida UV/MG model only) __________________14
4.3 Double note detection __________________________________________________15
4.4 Half note detection _____________________________________________________15
4.5 Chain note detection ___________________________________________________16
5. Maintenance and Troubleshooting
5.1 Maintenance ___________________________________________________________16
5.2 Troubleshooting _________________________________________________________17
5.2 Warranty _______________________________________________________________18
5.3 Contact Information ____________________________________________________19
Cassida 5520 Digital Currency Counter
5
1.1 About the Cassida 5520
Thank you for choosing the Cassida 5520 series currency counter. We hope you
enjoy using it.
Cassida’s 5520 series currency counters are sophisticated yet simple to operate
money processing machines. They will save you time and reduce errors of
counting by swiftly and precisely counting stacks of bills at a speed of 1200
notes per minute. The Cassida 5520 series will also enable you to add up totals
and batch necessary amounts into separate stacks. All these features come
together with built-in counterfeit detection system which uses ultraviolet
“UV” (and magnetic “MG” 5520 UV/MG model) ink detection and alerts you
immediately for any suspicious bill.
Cassida 5520 series currency counter makes an invaluable aid in banks, retail
stores, groceries, car washes, gas stations, bars, nightclubs, restaurants, movie
theaters and any other cash intensive environment.
1.2 Box contents
• Cassida 5520 Digital Currency Counter
• Power cord
• Spare parts kit:
- rubber belt
• Maintenance kit (optional)
- cleaning brush
- cleaning cloth
• User manual
INTRODUCTION
1.
Moving money forward
®
UV
MG
COUNT
UV
MG
COUNT
6
1.3 Front and rear views
Front view
1. Control panel
2. Stacking rollers - transports counted bills into the stacker
3. Stacker - holds counted bills
4. Stacker sensors - signals presence of bills in the stacker
5. Hopper sensor - signals presence of bills in the hopper
6. Hopper - holds bills that need to be counted
7. Retractable handle - used to carry the counter
