Casio EX - ZR1500 User Manual

Digital Camera
User’s Guide
EN
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.com/

Accessories

As you unpack your camera, check to make sure that all accessories shown below are included. If anything is missing, contact your original retailer.
Rechargeable lithium ion
battery (NP-130A)
USB cable Neck strap Basic Reference
USB-AC adaptor
(AD-C53U)
Power cord
*
* The shape of the power cord plug varies according to the country or geographic
area where the camera is sold.

Attaching the Neck Strap to the Camera

1. Undo the strap from the buckle
and remove the strap loop
Buckle
A
3. Pass the end of the strap
.
2. Attach the loop on the other end
of the strap on one side of the camera, and the loop you removed other side.
Strap hole
. Adjusting the Length of the Strap
You can adjust the length of the strap so it can be used as a neck strap or a shoulder strap.
to the strap hole
B
to the
A
through the strap loop ring and secure it with the buckle.
Ring
A
1. Pull the strap out at the center
of the buckle in the direction indicated by
1
.
2. Pull the strap in one of the
directions indicated by the illustration to adjust the length.
To lengthen
To shorten
1

Read this first!

• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production process. Feel free to contact us if you notice anything that is questionable, erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is forbidden. Except for your own personal use, any other use of the contents of this manual without the permission of CASIO COMPUTER CO., LTD. is forbidden under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits caused by loss of memory contents due to malfunction, repair, or any other reason.
• Note that the example screens and product illustrations shown in this User’s Guide may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that provides a pixel yield in excess of 99.99%. This means that some very small number of pixels may not light or may remain lit at all times. This is due to the characteristics of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is recording correctly.

Contents

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
] Attaching the Neck Strap to the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
]\
General Guide 11
]\
Monitor Screen Contents and How to Change Them 13
]\
Quick Start Basics 17
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Tilting the Monitor Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
] To load the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
] Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 28
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
] Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
] To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
] To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Holding the Camera Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
To shoot a snapshot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
] Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
] To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
]\
Snapshot Tutorial 43
Selecting the Recording Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
] Configuring Camera Settings with the Function Ring . . . . . . . . . . . . . . . . . . . . . 46
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . . 47
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . 48
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Focus) . . 50
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . . 53
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . (Smooth Skin) . . 54
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift) . . 55
Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Flash) . . 56
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . (Metering) . . 58
Contents
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
] Monitor Screen Information when Zooming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
] Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . . . (Zoom (SR)) . . . 63
] Expanding the Zoom Range to Shoot Clearer Snapshots . (Multi SR Zoom). . . 64
Triggering a Self-timer Operation with Motion . . . . . . . . . . . . (Handsfree) . . 64
] Configuring Handsfree Mode Settings . . . . . . . . . . . . . . . . . . . (Handsfree). . . 66
] Repositioning the Motion Detection Area . . . . . . . . . . . . . (Motion Position). . . 67
Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . (ART SHOT) . . 68
] Saving a Second Normal Image When
Shooting With HDR Art . . . . . . . . . . . . . . . . . . . . . . . . .(Double (HDR Art)). . . 70
Shooting with Triple Shot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
]\
Recording Movies 72
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
] Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Recording a High-definition Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Recording a High Speed Movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Using Prerecord Movie . . . . . . . . . . . . . . . . . . . . . . . . (Prerecord (Movie)) . . 77
Recording a Time Lapse Movie . . . . . . . . . . . . . . . . . . . . . . (Time Lapse) . . 79
Shooting a Snapshot while Shooting a Movie . . . . . (Snapshot In Movie) . . 82
]\
Using BEST SHOT 83
To shoot with BEST SHOT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Creating and Using Your Own Setups . . . . . . . . . . . . . (CUSTOM SHOT) . . 85
Shooting with a Face Brightening Effect . . . . . . . . . . . . . . . . . . (Make-up) . . 86
Shooting with High Speed Anti Shake . . . . . . . . . . . . . . . (HS Anti Shake) . . 87
Shooting Bright Images in the Dark without Flash . . . . . . (HS Night Shot) . . 88
Digitally Correcting for Overexposure and Underexposure . . . . . . (HDR) . . 89
Shooting with a Blurred Background . . . . . . . . . . . (Blurred Background) . . 90
Shooting with Full Focus Macro . . . . . . . . . . . . . . . . (All-In-Focus Macro) . . 91
Using Continuous Shutter with Auto Focus . . . . . . . . . . . . . . . . . (AF-CS) . . 92
Shooting a Burst of Images . . . . . . . . . . . . . . . . . . . . . . (High Speed CS) . . 93
Shooting with Priority on Subject Faces . . . . . . . . . . . (HS Best Selection) . . 96
Shooting a Panorama Image . . . . . . . . . . . . . . . . . . . . .(Slide Panorama) . . 97
Shooting with a Super Wide Angle of View . . . . . . . . . . . . . . (Wide Shot) . . 99
Shooting Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Snapshot) . 102
Shooting RAW Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Raw Image) . 103
Using a TV Screen to Shoot Snapshots . . . . . . . . . . . . (HDMI TV Output) . 103
Contents
]\
Advanced Settings (REC MENU) 105
Configuring Recording Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Configuring Handsfree Settings . . . . . . . . . . . . . . . . . . . . . . . (Handsfree) . 106
Configuring Motion Position Settings . . . . . . . . . . . . . . . (Motion Position) . 106
Assigning Functions to the Control Dial . . . . . . . . . . . . . . . . (Control Dial) . 107
Assigning Functions to the [4] and [6] Keys . . . . . . . . . . . . . . . (L/R Key) . 108
Saving a Second Normal Image When
Shooting With HDR Art . . . . . . . . . . . . . . . . . . . . . . . (Double (HDR ART)) . 108
To select the snapshot image size . . . . . . . . . . . . . . . . . . . . (Image Size) . 109
Specifying Snapshot Image Quality . . . . . . . . . . . . . . . . . (Image Quality) . .111
Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . (Movie Quality) . .111
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . 113
Specifying the ISO Sensitivity Upper Limit . . . . . . . . . . . . (ISO High Limit) . 113
Reducing the Effects of Camera and Subject Movement . . . . (Anti Shake) . 114
Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . .(Zoom (SR)) . 115
Turning Digital Zoom On or Off . . . . . . . . . . . . . . . . . . . . . . (Digital Zoom) . 115
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Focus) . 115
Shooting with Face Detection . . . . . . . . . . . . . . . . . . . . . (Face Detection) . 116
Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . . (AF Area) . 117
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . (Smooth Skin) . 118
Shooting with Continuous Auto Focus . . . . . . . . . . . . . . (Continuous AF) . 118
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . 118
Reducing Wind Noise during Movie Recording . . . . . . . (Wind Noise Cut) . 119
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift) . 119
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . 119
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . 119
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . (Metering) . 119
Specifying Flash Intensity . . . . . . . . . . . . . . . . . . . . . . . . . (Flash Intensity) . 120
Controlling Image Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . (Sharpness) . 120
Controlling Color Saturation . . . . . . . . . . . . . . . . . . . . . . . . . . (Saturation) . 120
Adjusting Image Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Contrast) . 120
Using the Auto Focus Assist Light . . . . . . . . . . . . . . . . . (AF Assist Light) . 121
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Review) . 121
Using Icon Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Icon Help) . 122
Changing the Monitor Screen when Recording . . . . . . . . . (Shooting Info) . 122
Configuring Power On Default Settings . . . . . . . . . . . . . . . . . . . (Memory) . 124
Contents
]\
Viewing Snapshots and Movies 125
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Viewing a Panorama Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Viewing Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
] Deleting Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
] Dividing Up a Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
] Copying a Group Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Scrolling Images at High Speed or by Recording Date . . . . . . . . . . . . . . . . . 131
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Displaying the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . 133
] Viewing High-quality Movies on a Hi-Vision Television. . . . . . . . . . . . . . . . . . . 134
]\
Other Playback Functions (PLAY MENU) 137
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . 137
] Transferring Music from Your Computer to Camera Memory . . . . . . . . . . . . . . 139
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . .(Movie Editing) . 140
To merge two movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Movie Merge) . 142
Creating a Snapshot of Movie Frames . . . . . . . . . . . . . (MOTION PRINT) . 143
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . 143
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . 144
Adjusting the Brightness of an Existing Snapshot . . . . . . . . . (Brightness) . 144
Selecting Images for Printing . . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 145
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . . (Protect) . 145
Editing the Date and Time of an Image . . . . . . . . . . . . . . . . . (Date/Time) . 147
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Rotation) . 147
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize) . 148
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . 148
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Copy) . 149
Combining CS Images into a Single Still Image . . . . . . . . (CS Multi Print) . 149
Dividing Up a Continuous Shutter Group . . . . . . . . . . . . . . (Divide Group) . 150
Editing a Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Edit Group) . 150
]\
Printing 151
Printing Snapshots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Using DPOF to Specify Images to be Printed and
the Number of Copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 151
Contents
]\
Using the Camera with a Computer 156
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . 157
] Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . 157
] Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
] Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . 161
] Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Using an SD Memory Card with Built-in LAN . . . . . . . . . . . . . . . . . . . . . . . . 164
] Transferring Images with an Eye-Fi Card . . . . . . . . . . . . . . . . . . . (Eye-Fi). . 164
] Using a Smartphone to Play Back Images Stored
on a FlashAir Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (FlashAir). . 166
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
]\
Other Settings (SETTING) 171
Enabling Power Saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ECO Mode) . 171
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . . (Screen) . 171
Turning off Eye-Fi Card Communication . . . . . . . . . . . . . . . . . . . . (Eye-Fi) . 172
Configuring FlashAir Card Communication Settings . . . . . . . . . (FlashAir) . 172
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 172
Creating an Image Storage Folder . . . . . . . . . . . . . . . . . . (Create Folder) . 173
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . .(Timestamp) . 173
Auto Image Orientation Detection and Rotation . . . . . . . . . . (Auto Rotate) . 174
Specifying the File Name Serial Number Generation Rule . . . . . (File No.) . 174
Configuring Sleep State Settings . . . . . . . . . . . . . . . . . . . . . . . . . . (Sleep) . 175
Configuring Auto Power Off Settings . . . . . . . . . . . . . . . (Auto Power Off) . 175
Specifying the Operation when the Monitor Screen is Tilted . (Screen Tilt) . 176
Configuring [p] Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (PLAY) . 176
Disabling File Deletion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Delete Key) . 176
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . 177
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 178
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 178
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 179
Selecting the Screen Aspect Ratio and
Video Output System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Video Output) . 179
Selecting the HDMI Terminal Output Method . . . . . . . . . . . (HDMI Output) . 180
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . 180
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . 180
Contents
]\
Appendix 181
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
] Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
] Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
] Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
] Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
] Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 205
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
10
Contents

General Guide

The numbers in parentheses indicate the pages where each item is explained.
Front Back
321 46 75
cm
bk bobmbl bn 7
bp
bq
Mode dial
1
(pages 35, 43, 72) Zoom controller
2
(pages 36, 59, 132) Shutter button
3
(pages 33, 35) Flash (page 56)
4
[ON/OFF] (Power)
5
(pages 29, 33) Front lamp
6
(pages 47, 121) Strap holes (page 3)
7
Function ring
8
(pages 46, 131)
89
Lens
9
Microphones (page 73)
bk
[RING] button
bl
(pages 46, 131) [0] (Movie) button
bm
(page 72) Back lamp
bn
(pages 25, 27, 33, 36,
56) Terminal cover
bo
[USB/AV] port
bp
(pages 24, 26) [HDMI OUT]
bq
HDMI output (Mini) (pages 103, 134)
brck bt bscl
[SET] button
br
(pages 45, 72, 105) [MENU] button
bs
(pages 72, 105) [p] (PLAY) button
bt
(pages 33, 39) Control dial
ck
([8][2][4][6]) (pages 12, 45, 72, 83, 105, 107) Monitor screen
cl
(pages 13, 19, 33, 176) Stand (pages 19, 22)
cm
11
General Guide
Bottom
Battery/memory card slots (pages 22, 31)
cn
Battery cover
co
Tripod hole
cp
Use this hole when attaching to a tripod. Speaker
cq
cp cncq co
. Control Dial
In addition to using the up, down, left, and right buttons, you can also use the control dial to perform operations.
• Depending on the function, certain operations cannot be performed using the control dial.
Control dial
[8] [2] [4] [6] : Press the applicable button (up, down, left, right).
12
General Guide

Monitor Screen Contents and How to Change Them

The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes. They do not represent screens that actually appear on the camera.
. Snapshot Recording (1 Shot)
Remaining snapshot memory capacity
2
13567
4
cn cm cl ck bt bs br
bq
Self-timer mode (page 47)
1
Face Detection (page 116)
2
Recording mode (page 35)
3
Image deterioration indicator/
4
Zoom (SR) indicator (page 62) Remaining movie memory
5
capacity (page 72)
bp
6
(page 205)
8
Snapshot image size/Quality (pages 109, 111)
7
9
Movie quality (FHD/STD movie)
8
bk
(pages 72, 75)/
bl
Recording speed (high speed movie) (page 75)
bm
Focal distance
9
bn
(Converted to 35 mm film format.) (page 61)
bo
Anti Shake (page 114)
bk
Timestamp indicator (page 173)
bl
Histogram (page 122)
bm
AF Area (page 117)
bn
Date/Time (pages 28, 178)
bo
Focus frame (pages 36, 117)
bp
Battery level indicator (page 28)
bq
Metering mode (page 58)
br
Flash (page 56)
bs
Exposure compensation (page 55)
bt
Smooth Skin (page 54)
ck
ISO sensitivity (page 53)
cl
Focus mode (page 50)
cm
White balance (page 48)
cn
NOTE
• Depending on recording settings, the aperture, shutter speed, and ISO sensitivity values may not appear on the monitor screen. These values will be red if the Auto Exposure (AE) is not correct for some reason.
Monitor Screen Contents and How to Change Them
13
. Snapshot Recording (Burst Shooting)
Continuous Shutter (CS) speed (page 93)
5
6 7
1
Recording mode (page 35)
2
Remaining snapshot memory capacity
3
(page 205) Allowable CS time*/number of CS images
4
(page 93)
* It is not displayed while shooting with
Prerecord CS.
Remaining movie memory capacity (page 206)
5
Continuous Shutter mode (page 93)
6
Prerecord CS shots (page 94)
7
Maximum CS shots (page 93)
8
Snapshot recording mode (Snapshot In Movie)
1
(page 82) Audio recording disabled (page 75)
2
Recording mode (page 72)
3
Movie recording time (page 72)
4
Remaining movie memory capacity (page 72)
5
Movie recording in progress (page 72)
6
Movie quality (FHD/STD movie)
7
(pages 72, 75)/ Recording speed (high speed movie) (page 75) Remaining snapshot memory capacity
8
(page 205)
1243
8 7
6
. Movie Recording
42
1
3
8
5
Monitor Screen Contents and How to Change Them
14
. Snapshot Viewing
2413
br bq bp bo bn bm
bk 9bl
File type
1
Protect indicator (page 145)
2
Snapshot image size
3
(page 109)
. CS Image Viewing
12
. Movie Playback
1 2
4
5 6
7
8
3
Folder name/file name (page 168)
4
Snapshot image quality (page 111)
5
Recording mode (page 35)
6
Histogram (page 122)
7
Date/time (page 178)
8
Metering mode (page 119)
9
White balance (page 144)
bk
Battery level indicator (page 28)
bl
Flash (page 56)
bm
Exposure compensation (page 55)
bn
Shutter speed
bo
Aperture value
bp
ISO sensitivity (page 53)
bq
Focal distance
br
(Converted to 35 mm film format.)
Number of images in the group (page 127)
1
Group icon (page 127)
2
No audio data available
1
Movie recording time (page 125)
2
Movie quality (FHD/STD movie)
3
(pages 72, 75)/ Recording speed (high speed movie) (page 75) Interval (page 79)
4
Displayed for movie recorded with Time Lapse.
Monitor Screen Contents and How to Change Them
15
. Configuring Monitor Screen Settings
Each press of [8] (DISP) will cycle through display settings that display or hide on-screen information. You can configure separate settings for the REC mode and PLAY mode.
REC mode
Information on Displays setting information.
Information off Hides setting information.
PLAY mode
Information on
Displays settings when shooting, current date and time, histogram (page 122), and other information.
Information off No information displayed when shooting.
[8] (DISP)
Monitor Screen Contents and How to Change Them
16

Quick Start Basics

What you can do with your CASIO camera

Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following main functions.
180 degrees
90 degrees
Tiltable Monitor Screen
The camera’s monitor screen can be tiled upwards up to 180 degrees. This makes it easy to compose self-portraits and to shoot from low angles.
*See page 19 for more information.
Handsfree Self-portraits
You can control operation of the self-timer from a distance by waving your hand, which makes it easier to shoot self-portraits from a distance.
*See page 64 for more information.
Time Lapse Movie
You can use this function to record movies of natural events that occur over time, to speed up the flow of traffic in a city scene, or to record other similar types of movies.
*See page 79 for more information.
ART SHOT
A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting. “ART SHOT” provides the following effects: HDR Art, Toy Camera, Soft Focus, Light Tone, Pop, Sepia, Monochrome, Miniature, Fisheye, Sparkling Shot, Crystal Ball, ART SHOT Bracketing.
*See page 68 for more information.
Triple Shot
Pressing the shutter button shoots a burst of three images and stores them in memory. This feature is great for making sure you don’t miss those special moments when kids are around.
*See page 71 for more information.
17
Quick Start Basics
Premium Auto Pro
Select Premium Auto Pro recording and the camera automatically determines whether you are shooting a subject or scenery, and other conditions. Premium Auto Pro delivers higher image quality than standard Auto.
*See page 35 for more information.
High Speed Movie
Movies can be recorded at up to 1000 frames per second. This makes it possible to clearly view phenomena that are invisible to the human eye, in slow motion.
*See page 75 for more information.
FHD Movie Recording
You can record movies in high-quality FHD.
x
1080 pixels 30 fps)
(1920
*See page 75 for more information.
18
Quick Start Basics

Tilting the Monitor Screen

The monitor screen can be tilted upwards up to 180 degrees. This means you can position the monitor screen so it faces in the same direction as the lens, for easy composition of self-portraits. You can also tilt the monitor screen upwards 90 degrees, which means you can easily shoot from a low angle without straining your neck to view the monitor screen.
. What you can do with the camera...
Shoot self-portraits
You can position the monitor screen so it faces in the same direction as the lens, for easy composition of self-portraits. You can also use a stand on the back of the camera to keep the camera upright when placed on a tabletop or other surface.
180 degrees
90 degrees
Low-angle shots
The tilt angle of the monitor screen can be adjusted for each composition of images from various low angles.
High-angle shots
By holding the camera upside down, you can angle the monitor screen in a way that allows you to shoot from high angles. In this case, the camera will automatically rotate on-screen information and the displayed image 180 degrees.
19
Quick Start Basics
. Tilting the Monitor Screen
As shown in the figure below, pull upwards on the bottom center of the monitor screen at point momentarily. Keep lifting and it will tilt upwards up to 180 degrees.
• Do not pull downwards from the top of the monitor screen. Be sure to pull upwards from the bottom of the monitor screen as shown in the figure.
. The monitor screen will open up to 90 degrees and stop
A
OK NG
A
IMPORTANT!
• Under factory default settings, the camera will turn on automatically whenever the monitor screen is tilted. See page 176 for information about configuring the camera so it does not turn on when the monitor screen is tilted upwards.
• When returning the monitor screen to the back of the camera, take care so you do not catch your fingers between the top or bottom of the monitor screen and the camera.
• Do not subject the monitor screen to strong impact. Doing so can damage it.
NOTE
• Be sure to return the monitor screen to its normal position to the back of the camera when you are not using it.
• Whenever placing the camera on a tabletop or other surface to shoot, be sure to pull out the stand to keep it from falling over (page 22).
20
Quick Start Basics
. Returning the Monitor Screen to Its Normal Position
1. Holding the monitor screen at
point downwards to the back of the camera.
, rotate the screen
A
A
2. Push the monitor screen
downwards with your finger at point screen down as far as it will go.
to slide the monitor
B
B
21
Quick Start Basics

Using the Stand

Your camera has a built-in stand. You can pull out the stand and keep the camera stable on a tabletop or other surface while the monitor screen is tilted upwards 180 degrees. When using the camera on a tabletop or other surface for landscape (horizontal) orientation shots, you can adjust the vertical angle of the camera somewhat by changing how far you pull out the stand.
IMPORTANT!
• When using the camera on a tabletop or other surface for portrait (vertical) orientation shots, pull the stand out as much as possible so the camera is stable. Pulling the stand out part way in this case can cause the camera to become unstable and fall over.
• Even when using the stand to adjust the vertical angle of the camera while shooting with landscape (horizontal) orientation, take care to extend the stand far enough to avoid camera instability, which can cause it to fall over.
• Whenever using the stand, make sure that the location where you place the camera is stable and relatively level.
Stand

First, charge the battery prior to use.

Note that the battery of a newly purchased camera is not charged. Perform the steps below to load the battery into the camera and charge it.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-130A or NP-130) for power. Never try to use any other type of battery.

To load the battery

1. Open the battery cover.
22
Quick Start Basics
2. Load the battery.
With the CASIO logo on the battery facing downwards (in the direction of the lens), hold the stopper next to the battery in the direction indicated by the arrow as you slide the battery into the camera. Press the battery in until the stopper secures it in place.
3. Close the battery cover.
To replace the battery
1. Open the battery cover and
remove the current battery.
2. Load a new battery.
Battery
OK
Stopper
NG
CASIO logo
Stopper
23
Quick Start Basics

Charge the Battery

You can use either of the two following methods to charge the camera’s battery.
• USB-AC adaptor
• USB connection to a computer (Using the included USB cable.)
. To charge with the USB-AC adaptor
The adaptor lets you charge the battery while it is loaded in the camera. While the camera is turned off, connect in the sequence shown below. Charging time: Approximately 240 minutes
Power cord
[USB/AV] port
1
USB-AC adaptor (AD-C53U)
2
3
4
USB cable (included with camera)
Making sure that the 6 mark on the camera is aligned with the 4 mark of the USB cable connector, connect the cable to the camera.
• When disconnecting the USB-AC adaptor from the camera, be sure to disconnect from the camera first.
24
Quick Start Basics
IMPORTANT!
• A battery that has not been used for a long time, or ambient temperature extremes can cause charging to take longer than normal. If charging takes longer than about five hours, a timer will terminate it automatically, even if the battery is not fully charged. This is indicated by the back lamp flashing red. If the battery has not been used for a very long time, charging may be terminated automatically and the back lamp may start flashing red after only about 60 minutes. In either case, disconnect the USB cable from the camera and then reconnect it to resume charging.
• Make sure that you insert the cable connector into the [USB] port until you feel it click securely into place. Failure to insert the connector fully can result in poor communication or malfunction.
• Note that even while the connector is fully inserted, you still will be able to see the metal part of the connector as shown in the illustration.
• Pressing [ON/OFF] (Power) while the USB-AC adaptor is connected to the camera will turn on the camera with power being supplied by the battery. Because of this, charging will stop.
• The USB-AC adaptor will become warm during charging. This is normal and does not indicate malfunction.
• The shape of the power plug depends on each country or geographic area.
Back Lamp Operation
Lamp Status Description
Back lamp
Lit Red Charging
Abnormal ambient temperature,
Flashing Red
USB-AC adaptor problem, or battery problem (page 193)
Off Charging complete
25
Quick Start Basics
. To charge using a USB connection to a computer
USB connection lets you charge the battery while it is loaded in the camera. While the camera is turned off, connect in the sequence shown below (
Computer
(power turned on)
USB port
[USB/AV] port
1, 2
2
USB
).
1
Making sure that the 6 mark on the camera is aligned with the 4 mark of the USB cable connector, connect the cable to the camera.
USB cable
(included with camera)
• If the camera is on, press [ON/OFF] (Power) to turn it off before connecting it to your computer.
IMPORTANT!
• The first time you connect the camera to your computer with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.
• A battery that has not been used for a long time, certain types of computers, and connection conditions can cause charging to take more than approximately five hours, which will trigger a timer that terminates charging automatically, even if the battery is not fully charged. If this happens, disconnect and then reconnect the USB cable to restart charging. To complete charging faster, use of the included USB-AC adaptor is recommended.
• If the battery has not been used for a very long time, charging may terminate automatically and the back lamp may start flashing red or go out after only about 60 minutes. In either case, use of the USB-AC adaptor that comes with the camera is recommended.
• If you turn on the camera while charging over a USB connection to a computer is in progress, the camera will establish a USB connection with the computer. Though charging normally should continue at this time, certain types of computers or connection environments may stop charging if supply power is low. This will be indicated by the camera’s back lamp lighting green.
• Charging is not performed while the connected computer is in the hibernate mode.
26
Quick Start Basics
Back Lamp Operation
Lamp Status Description
Lit Red, (Lit/Flashing Amber)
Charging
Back lamp
Abnormal ambient temperature,
Flashing Red
charging taking abnormally long, or battery problem (page 193)
Off, (Lit Green) Charging complete
• The information in parentheses in the above table shows the lamp status while the camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s battery (NP-130A or NP-130) without removing it from the camera. You also can charge the battery using an optionally available charger unit (BC-130L). Never use any other type of charger device. Attempting to use a different charger can result in unexpected accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards. Use of an inferior device or a device that is not up to standard can cause malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you. Even in the case of a commercially available computer, certain USB port specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give the battery time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of this, it is recommended that you charge the battery immediately before you need to use it.
• Charging the camera’s battery may cause interference with TV and radio reception. If this happens, plug the USB-AC adaptor into an outlet that is further away from the TV or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging. Use of any other type of devices may result in improper charging.
27
Quick Start Basics
Checking Remaining Battery Power
As battery power is consumed, a battery indicator on the monitor screen indicates remaining power as shown below.
Remaining Power High Low
Battery Indicator ***
Indicator Color White * White * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the REC mode and PLAY mode.
• Leaving the camera for about 30 days with no power supplied while the battery is dead will cause its date and time settings to be cleared. A message telling you to configure time and date settings will appear the next time you turn on the camera after restoring power. When this happens, configure date and time settings (page
178).
• See page 210 for information about battery life and number of shots.
Battery Power Conservation Tips
• Entering the “ECO Mode” enables low-power operation (page 171).
• When you do not need to use the flash, select ? (Flash Off) for the flash setting (page 56).
• Enable the Auto Power Off and the Sleep features to protect against wasting battery power when you forget to turn off the camera (pages 175, 175).
• Select “Off” for “Continuous AF” (page 118).

Configuring Basic Settings the First Time You Turn On the Camera

The first time you load a battery into the camera, a screen appears for configuring the display language, date, and time settings. Failure to set the date and time correctly will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if you purchased a camera intended for the Japanese market. To change the display language from Japanese in this case, use the procedure under “Specifying the Display Language (Language)” (page 179). Note that a version of this manual in the language you select may not be included with a camera intended for the Japanese market.
• Camera models sold in certain geographic areas may not support display language selection.
28
Quick Start Basics
1. Press [ON/OFF] (Power) to turn on the
[ON/OFF] (Power)
camera.
2. Use [8], [2], [4], and [6] to select the
language you want and then press [SET].
3. Use [8] and [2] to select a date style and then press [SET].
Example: July 10, 2015 YY/MM/DD DD/MM/YY MM/DD/YY
* 15/7/10 * 10/7/15 * 7/10/15
4. Set the date and the time.
Use [4] and [6] to select the setting you want to change and then use [8] and [2] to change it. To switch between 12-hour and 24-hour format, select “24h” and then use [8] and [2] to change the setting.
5. After setting the date and time, use [4] and [6]
to select “Apply” and then press [SET].
If you make a mistake configuring display language, date, or time settings with the above procedure, refer to the following pages for information about how to correct the settings.
– Display language: page 179 – Date and time: page 178
NOTE
• Each country controls its local time offset and the use of summer time, and so they are subject to change.
• Removing the battery from the camera too soon after configuring time and date settings for the first time can cause the settings to be reset to their factory defaults. Do not remove the battery for at least 24 hours after configuring settings.
29
Quick Start Basics

Preparing a Memory Card

Though the camera has built-in memory that can be used to store images and movies, you probably will want to purchase a commercially available memory card for greater capacity. The camera does not come with a memory card. Images recorded while a memory card is loaded are saved to the memory card. When no memory card is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 205.

Supported Memory Cards

– SD Memory Card – SDHC Memory Card – SDXC Memory Card
Use one of the above types of memory card.
• The above are supported memory card types as of May 2014.
• This camera supports use of SD memory cards of the following types and capacities: SD memory cards up to 2GB, SDHC memory cards from 2GB up to 32GB, SDXC memory cards from 32GB up to 2TB. Note that the ability to use any particular card with this camera, even if it satisfies the above capacity and type requirements, is not guaranteed.
• This camera supports use of Eye-Fi cards and FlashAir cards.
. Memory Card Handling Precautions
Certain types of cards can slow down processing speeds, and even can make it impossible to store High Quality movies correctly. Also, use of certain types of memory cards slows down data transfer and increases the time it takes to record movie data, which can result in movie frames being dropped. The Y indicator on the monitor screen turns yellow to indicate that frames are being dropped. In order to avoid problems such as these, use of an Ultra High Speed Type SD memory card is recommended. Note, however that CASIO makes no guarantees about the operation of any Ultra High Speed Type SD memory card used with this camera.
30
Quick Start Basics
Loading...
+ 182 hidden pages
