Casio EX-ZR10 EN User Manual
Digital Camera
User’s Guide
E
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
To go to “Getting the Most Out of Dynamic Photo” click here!
Unpacking
As you unpack your camera, check to make sure that all items shown below are
included. If anything is missing, contact your original retailer.
Digital camera
* The shape of the power
cord plug varies
according to country or
geographic area.
Rechargeable lithium ion
battery (NP-110)
To attach the strap to the camera
Charger unit (BC-110L)
Attach strap here.
Power cord Strap
USB cable AV cable CD-ROM Basic Reference
2
Read this first!
• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost
profits, or claims by third parties arising out of the use of Photo Transport, Dynamic
Photo Manager, or YouTube Uploader for CASIO.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
3
Contents
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Monitor Screen Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
❚❙
Quick Start Basics 14
What is a digital camera? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . 15
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
❚
To charge the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
❚
To load the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . 19
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
❚
Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
❚
To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
❚
To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
❚
To turn power on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
❚
To turn off the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Holding the Camera Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
To shoot a snapshot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
❚
Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
❚
To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
❚
To delete a single file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
❚
To delete specific files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
❚
To delete all files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
❚
Auto Focus Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
❚❙
Snapshot Tutorial 33
Using the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Size) . . 34
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . . 37
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . 38
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . .(EV Shift) . . 39
Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Flash) . . 40
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
❚
Interpreting the Zoom Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
❚
Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . . . (Zoom (SR)) . . . 45
Using Continuous Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
❚
Using High Speed CS and Prerecord CS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
❚
High Speed CS Shooting Using the Mechanical Shutter Only . . . . . .(F CS) . . . 51
❚
Continuous Shutter Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
4
Contents
❚❙
Recording Movies 54
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
❚
Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Recording a High-definition Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Recording a High Speed Movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Using Prerecord Movie . . . . . . . . . . . . . . . . . . . . . . . .(Prerecord (Movie)) . . 59
Recording a Movie for YouTube . . . . . . . . . . . . . . . . . . . . . (For YouTube) . . 61
Shooting a Snapshot while Shooting a Movie . . . . . . . . . . . . . . . . . . . . . . . . 62
❚❙
Using BEST SHOT 63
What is BEST SHOT? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
❚
Some Sample Scenes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
To shoot an image with Single Shot mode BEST SHOT . . . . . . . . . . . . . . . . 63
To shoot an image with HS BEST SHOT . . . . . . . . . . . (HS BEST SHOT) . . 64
❚
Creating Your Own BEST SHOT Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Shooting with High Speed Night Scene
. . . . . . . .(High Speed Night Scene/High Speed Night Scene and Portrait) . . 68
Shooting with High Speed Anti Shake . . . . . . . .(High Speed Anti Shake) . . 69
Digitally Correcting for Overexposure and Underexposure . . . . . . (HDR) . . 70
Shooting Snapshots Digitally Processed for Artistic Effect . . . . (HDR Art) . . 71
Expanding the Zoom Range to Shoot Clearer Snapshots (Multi SR Zoom) . . 72
Shooting a Panorama Image . . . . . . . . . . . . . . . . . . . . (Slide Panorama) . . 73
Configuring the Camera to Help You Better Time Your Shots
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lag Correction) . . 75
Shooting with Priority on Subject Faces . . . .(High Speed Best Selection) . . 77
Using the Situation-specific CS Scenes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Using the Situation-specific High Speed Movie Scenes . . . . . . . . . . . . . . . . 80
❚❙
Advanced Settings 81
Using On-screen Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
REC Mode Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (REC) . . 83
❚
Zooming with Super Resolution . . . . . . . . . . . . . . . . . . . . . . . . (Zoom (SR)) . . . 83
❚
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus) . . . 83
❚
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer). . . 86
❚
Reducing the Effects of Camera and Subject Movement . . . . (Anti Shake). . . 87
❚
Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . . . (AF Area). . . 88
❚
Using the Auto Focus Assist Light . . . . . . . . . . . . . . . . . . .(AF Assist Light). . . 89
❚
Shooting with Face Detection . . . . . . . . . . . . . . . . . . . . . .(Face Detection). . . 89
❚
Shooting with Continuous Auto Focus . . . . . . . . . . . . . . . .(Continuous AF) . . . 90
❚
Turning Digital Zoom On or Off . . . . . . . . . . . . . . . . . . . . . . .(Digital Zoom). . . 91
❚
Assigning Functions to the [4] and [6] Keys . . . . . . . . . . . . . . . (L/R Key). . . 91
❚
Displaying the On-screen Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Grid) . . . 92
❚
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review) . . . 92
❚
Using Icon Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Icon Help). . . 92
❚
Configuring Power On Default Settings . . . . . . . . . . . . . . . . . . . . (Memory) . . . 93
5
Contents
Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Quality) . . 94
❚
Specifying Snapshot Image Quality . . . . . . . . . . . .(T Quality (Snapshot)). . . 94
❚
Movie Image Quality Settings . . . . . . . . . . . . . . . . . . .(» Quality (Movie)). . . 94
❚
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .(Metering). . . 95
❚
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting). . . 95
❚
Specifying Flash Intensity . . . . . . . . . . . . . . . . . . . . . . . . . (Flash Intensity). . . 96
❚
Using Built-in Color Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Color Filter) . . . 96
❚
Controlling Image Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . . (Sharpness). . . 96
❚
Controlling Color Saturation . . . . . . . . . . . . . . . . . . . . . . . . . . . (Saturation). . . 96
❚
Adjusting Image Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Contrast). . . 96
❚❙
Viewing Snapshots and Movies 97
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Viewing a Panorama Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Viewing Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
❚
Deleting Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
❚
Dividing Up a CS Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
❚
Copying a CS Group Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Displaying the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . 105
❚
Viewing High-quality Movies on a Hi-Vision Television. . . . . . . . . . . . . . . . . . . 107
❚❙
Other Playback Functions (PLAY) 109
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . 109
❚
Transferring Music from Your Computer to Camera Memory . . . . . . . . . . . . . . .111
Creating a Snapshot of Movie Frames . . . . . . . . . . . . . (MOTION PRINT) . 112
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . (Movie Editing) . 112
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . 114
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . 114
Adjusting the Brightness of an Existing Snapshot . . . . . . . . .(Brightness) . 115
Selecting Images for Printing . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 115
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . (Protect) . 116
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation) . 118
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Resize) . 118
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . 119
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Copy) . 119
Dividing Up a Continuous Shutter Group . . . . . . . . . . . . . .(Divide Group) . 120
Combining CS Images into a Single Still Image . . . . . . . . (CS Multi Print) . 120
Editing a CS Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (CS Frame Edit) . 120
❚❙
Dynamic Photo 121
Inserting a Built-in Subject into a Snapshot or Movie . . .(Dynamic Photo) . 121
❚
To view a Dynamic Photo . . . . . . . . . . . . . . . . . . . . . . (Dynamic Photo File). . 123
6
Contents
Converting a Dynamic Photo Still Image to a Movie . . . (Movie Converter) . 123
❚❙
Printing 124
Printing Snapshots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Connecting Directly to a PictBridge Compatible Printer . . . . . . . . . . . . . . . 124
Using DPOF to Specify Images to be Printed and the Number of Copies. . 127
❚❙
Using the Camera with a Computer 132
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . 133
❚
Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . 134
❚
Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
❚
Uploading Movie Files to YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
❚
Transferring Images from Your Computer to Camera Memory. . . . . . . . . . . . . 140
❚
Play back Dynamic Photo images on your EXILIM, a computer,
or on a mobile phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
❚
Viewing User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . (PDF Files) . . 142
❚
User Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
❚
Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . 143
❚
Transferring Images Automatically and Managing Them on Your Macintosh. . 146
❚
Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
❚
Viewing User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . .(PDF Files) . . 147
❚
User Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
❚❙
Other Settings (Set Up) 151
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . (Screen) . 151
Auto Image Orientation Detection and Rotation . . . . . . . . . .(Auto Rotate) . 151
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 152
Specifying the File Name Serial Number Generation Rule . . . . . (File No.) . 152
Creating an Image Storage Folder . . . . . . . . . . . . . . . . . . (Create Folder) . 153
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . 153
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . (Timestamp) . 154
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 155
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 155
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 156
Configuring Sleep State Settings . . . . . . . . . . . . . . . . . . . . . . . . . (Sleep) . 156
Configuring Auto Power Off Settings . . . . . . . . . . . . . . . (Auto Power Off) . 157
Configuring [r] and [p] Settings . . . . . . . . . . . . . . . . . . . (REC/PLAY) . 157
Configuring USB Protocol Settings . . . . . . . . . . . . . . . . . . . . . . . . . (USB) . 158
Selecting the Screen Aspect Ratio and Video Output System (Video Out) . 158
Selecting the HDMI Terminal Output Method . . . . . . . . . . .(HDMI Output) . 159
Configuring a Startup Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Startup) . 159
7
Contents
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . (Format) . 160
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . (Reset) . 160
❚❙
Configuring Monitor Screen Settings 161
Turning Display Information On and Off . . . . . . . . . . . . . . . . . . . . . . (Info) . 161
Using the On-screen Histogram to Check Exposure . . . . . . (+Histogram) . 161
❚
How to Use the Histogram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
❚❙
Appendix 163
Precautions during Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
❚
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
❚
To replace the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
❚
Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
❚
Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
❚
To replace the memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Computer System Requirements for Bundled Software . . . . . . . . . . . . . . . 174
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
❚
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
❚
Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . 185
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
8
Contents
General Guide
The numbers in parentheses indicate the pages where each item is explained.
. Camera
Front Back
1234675
9
Zoom controller
1
(pages 26, 42, 104)
Shutter button (page 25)
2
Flash (page 40)
3
[ON/OFF] (Power)
4
(page 23)
Microphones (page 55)
5
[AUTO] button (page 25)
6
Strap holes (page 2)
7
Front lamp
8
(pages 86, 89)
Lens
9
8
bl 7
bk
btck bs br
cl bq
Õ (Continuous
bk
Shutter) (page 46)
Back lamp
bl
(pages 23, 26, 40)
[0] (Movie) button
bm
(page 54)
Terminal cover
bn
(pages 105, 107, 125,
135, 144)
[USB/AV] port
bo
(pages 105, 125, 135,
144)
[HDMI OUT] HDMI
bp
output (Mini) (page 107)
bm
bn
Control button
bq
([8][2][4][6])
(pages 29, 33, 40, 81,
161)
[MENU] button
br
(page 81)
[p] (PLAY) button
bs
(pages 23, 28)
[SET] button (page 33)
bt
[r] (REC) button
ck
(pages 23, 25)
Monitor screen
cl
(pages 11, 161)
bo
bp
9
Bottom
cn cmco
. Charger Unit
1
2
3
Battery/memory card slots (pages 17, 21, 170, 172)
cm
Tripod hole
cn
Use this hole when attaching to a tripod.
Speaker
co
+7- Contacts
1
[CHARGE] Lamp
2
AC jack
3
10
Monitor Screen Contents
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
. Snapshot Recording
Remaining snapshot memory capacity
2 4561
3
789
cn
cm
cl
ck
bqbrbs
bp
Focus mode (page 83)
1
Metering mode (page 95)
2
Continuous Shutter mode
3
(page 46)
Self-timer mode (page 86)
4
Image deterioration indicator
5
(page 43)
Recording mode (page 25)
6
bobt
7
(pages 49, 185)
bk
Number of recordable CS images
8
bl
(pages 46, 49)
bm
Snapshot image size/Quality (pages 34, 94)
9
ISO sensitivity (page 37)
bk
White balance setting (page 38)
bl
bn
Exposure compensation (page 39)
bm
Flash (page 40)
bn
BEST SHOT (page 63)
bo
Date/Time (pages 19, 155)
bp
Movie quality (FHD/STD movie)
bq
(pages 54, 57)/Recording speed
(high speed movie) (page 57)
Focus frame (pages 26, 88)
br
Timestamp indicator (page 154)
bs
Battery level indicator (page 18)
bt
Histogram (page 161)
ck
Zoom (SR) indicator (page 44)
cl
Anti Shake (page 87)
cm
Face Detection (page 89)
cn
NOTE
• The semi-transparent gray frame on the monitor screen indicates the area that is
recorded when shooting a movie. The area within the frame is recorded for a
movie.
• If the current aperture, shutter speed, ISO sensitivity, or Auto Exposure is not
correct, the setting will turn orange when you half-press the shutter button.
11
. Movie Recording
2
7
. Snapshot Viewing
2413
br
bq
bp
bmbnbo
bkbl
Recording mode (page 54)
4
5
6
5
6
7
8
9
1
Audio recording disabled (page 57)
2
Remaining movie memory capacity (page 54)
3
Movie recording time (page 54)
4
Movie recording in progress (page 54)
5
Movie quality (FHD/STD movie) (pages 54, 57)/
6
Recording speed (high speed movie) (page 57)
Battery level indicator (page 18)
7
File type
1
Protect indicator (page 116)
2
Snapshot image size (page 34)
3
Folder name/file name (page 148)
4
Snapshot image quality (page 94)
5
ISO sensitivity (page 37)
6
Aperture value
7
Shutter speed
8
Date/time (page 155)
9
Exposure compensation (page 39)
bk
Metering mode (page 95)
bl
White balance setting (page 114)
bm
Flash (page 40)
bn
Battery level indicator (page 18)
bo
Continuous Shutter mode (page 46)
bp
Histogram (page 161)
bq
Recording mode (page 25)
br
31
12
. Movie Playback
2
1 34
9
. CS Image Viewing
12
4
3
5
6
7
8
No audio data available
1
File type
2
Protect indicator (page 116)
3
Folder name/file name (page 148)
4
Movie recording time (page 97)
5
Movie quality/speed (pages
6
YouTube (page 61)
7
Date/time (page 155)
8
Battery level indicator (page 18)
9
Current image number/number of images in the
1
group (page 99)
CS group icon (page 99)
2
Playback guide (page 99)
3
CS speed (page 99)
4
54,
57, 57)
B
13
Quick Start Basics
What is a digital camera?
A digital camera stores images on a memory card, so you can record and
delete them a countless number of times.
Record
Delete
You can use the images you record in a variety of different ways.
Store images on your
computer.
Print images. Attach images to e-mail.
14
Play
Quick Start Basics
What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following three main functions.
High Speed CS/Prerecord CS
Now you can shoot up to 30 continuous highresolution images at the amazing speed of
40 images per second (maximum). Prerecord CS
pre-records images to ensure you are almost never
too late with the shutter button.
See page 46 for more information.
High Speed Movie
Movies can be recorded at up to 480 frames per
second. This makes it possible to clearly view
phenomena that are invisible to the human eye, in
slow motion.
See page 57 for more information.
FHD Movie Recording
You can record movies in high-quality FHD.
x
1080 pixels 30 fps)
(1920
See page 57 for more information.
15
1920x1080 pixels
Quick Start Basics
First, charge the battery prior to use.
Note that the battery of a newly purchased camera is not charged. Perform the steps
under “To charge the battery” to bring the battery to a full charge.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-110)
for power. Never try to use any other type of battery.
To charge the battery
1. Aligning the positive
negative
-
terminals of the battery
+
and
with those of the charger unit, load
the battery into the charger unit.
2. Plug the charger unit into a
household power outlet.
About 180 minutes are required to
reach full charge. The [CHARGE]
lamp will go out when charging is
complete. Unplug the power cord
from the power outlet and then
remove the battery from the charger.
Lamp Status Description
Lit Red Charging
Flashing Red
Off Charging complete
Abnormal ambient temperature, charger problem, or
battery problem (page 170)
[CHARGE] lamp
16
Quick Start Basics
Other Charging Precautions
• Use the special charger (BC-110L) to charge the special lithium ion battery (NP-
110). Never use any other type of charger device. Attempting to use a different
charger can result in unexpected accident.
• A battery that is still warm due to normal use may not charge fully. Give the battery
time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the charger into an outlet that is further away from the TV or
radio.
• Actual charging time depends on current battery capacity and charging conditions.
To load the battery
1. Open the battery cover.
Slide the battery cover slider towards OPEN
and then open it as indicated by the arrows in
the illustration.
2. Load the battery.
With the EXILIM logo on the
battery facing upwards (in the
direction of the monitor screen),
hold the stopper next to the
battery in the direction indicated
by the arrow as you slide the
battery into the camera. Press the
battery in until the stopper
secures it in place.
Stopper
Battery contacts
17
EXILIM logo
Front
Back
Quick Start Basics
3. Close the battery cover.
Close the battery cover and then shift the
slider towards LOCK.
• For information about how to replace the
battery, see page 170.
Checking Remaining Battery Power
As battery power is consumed, a battery indicator on the monitor screen indicates
remaining power as shown below.
Remaining Power High Low
Battery Indicator ***
Indicator Color Cyan * Amber * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• Leaving the camera for about 30 days with no power supplied while the battery is
dead will cause its date and time settings to be cleared. A message telling you to
configure time and date settings will appear the next time you turn on the camera
after restoring power. When this happens, configure date and time settings (page
155).
• See page 190 for information about battery life and number of shots.
Battery Power Conservation Tips
• When you do not need to use the flash, select ? (Flash Off) for the flash setting
(page 40).
• Enable the Auto Power Off and the Sleep features to protect against wasting
battery power when you forget to turn off the camera (pages 156, 157).
• Select “Off” for “Continuous AF” (page 90).
• Avoid unnecessary optical zoom operations.
18
Quick Start Basics
Configuring Basic Settings the First Time You Turn On the Camera
The first time you load a battery into the camera, a screen appears for configuring the
display language, date, and time settings. Failure to set the date and time correctly
will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if
you purchased a camera intended for the Japanese market. To change the display
language from Japanese in this case, use the procedure under “Specifying the
Display Language (Language)” (page 156). Note that a version of this manual in
the language you select may not be included with a camera intended for the
Japanese market.
• Camera models sold in certain geographic areas may not support display language
selection.
1. Press [ON/OFF] (Power) to turn on
the camera.
[ON/OFF] (Power)
[0] (Movie)
2. Use [8], [2], [4], and [6] to select
the language you want and then
press [SET].
3. Use [8] and [2] to select a date style and then press [SET].
Example: July 10, 2012
YY/MM/DD
DD/MM/YY
MM/DD/YY
* 12/7/10
* 10/7/12
* 7/10/12
4. Set the date and the time.
Use [4] and [6] to select the setting you want to
change and then use [8] and [2] to change it.
To switch between 12-hour and 24-hour format, press
[0] (Movie).
5. After setting the date and time, use [4] and [6]
to select “Apply” and then press [SET].
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: Page 156
– Date and time: Page 155
19
Quick Start Basics
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
• Removing the battery from the camera too soon after configuring time and date
settings for the first time can cause the settings to be reset to their factory defaults.
Do not remove the battery for at least 24 hours after configuring settings.
Preparing a Memory Card
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 185.
Supported Memory Cards
– SD Memory Card
– SDHC Memory Card
– SDXC Memory Card
Use one of the above types of memory card.
• Use only SD cards that are compliant with the SD Card Association specification.
• This model does not support use of an Eye-Fi card.
. Memory Card Handling Precautions
Certain types of cards can slow down processing speeds, and even can make it
impossible to store High Quality movies correctly. Also, use of certain types of
memory cards slows down data transfer and increases the time it takes to record
movie data, which can result in movie frames being dropped. The Y indicator on the
monitor screen turns yellow to indicate that frames are being dropped. In order to
avoid problems such as these, use of an Ultra High Speed Type SD memory card is
recommended. Note, however that CASIO makes no guarantees about the operation
of any Ultra High Speed Type SD memory card used with this camera.
20
Quick Start Basics
To load a memory card
1. Press [ON/OFF] (Power) to turn off
the camera and then open the
battery cover.
Slide the battery cover slider towards
OPEN and then open it as indicated by
the arrows in the illustration.
2. Load a memory card.
Positioning the memory card so its front
is facing upwards (towards the monitor
screen side of the camera), slide it into
the card slot all the way in until you hear
it click securely into place.
Front
Front Back
3. Close the battery cover.
Close the battery cover and then shift the
slider towards LOCK.
• For information about how to replace
the memory card, see page 172.
IMPORTANT!
• Never insert anything besides a supported memory card (page 20) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, remove the battery, and contact your retailer or nearest CASIO
authorized service center.
21
Quick Start Basics
To format (initialize) a new memory card
You need to format a new memory card before using it for the first time.
1. Turn on the camera and press [MENU].
2. On the “Set Up” tab, select “Format” and then press [6].
3. Use [8] and [2] to select “Format” and then press [SET].
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete
its contents. Normally you do not need to format a memory card again. However, if
storing to a card has slowed down or if you notice any other abnormality, re-format
the card.
• Be sure to use the camera to format a memory card. Formatting a memory card on
a computer and then using it in the camera can slow down data processing by the
camera. In the case of an SD, SDHC, or SDXC memory card, formatting on a
computer can result in non-conformity with the SD format, causing problems with
compatibility, operation, etc.
22
Quick Start Basics
Turning the Camera On and Off
To turn power on
To turn on
power and enter
the REC mode
To turn on
power and enter
the PLAY mode
Press [ON/OFF] (Power) or
[r] (REC).
• The back lamp will light green
momentarily and the lens will extend
out of the camera (page 25).
Press [p] (PLAY).
• The back lamp will light green
momentarily and an image currently
stored in camera memory will
appear on the monitor screen
(page 28).
[ON/OFF] (Power)
Back lamp
• Take care to ensure that nothing is restricting or
coming into contact with the lens as it extends.
Holding the lens with your hand so it cannot extend
creates the risk of malfunction.
•Pressing [p] (PLAY) while in the REC mode
switches to the PLAY mode. The lens retracts about
[p] (PLAY) [r] (REC)
10 seconds after switching modes.
• The Sleep function or Auto Power Off (pages 156, 157) will turn off power
automatically if you do not perform any operation for a preset amount of time.
To turn off the camera
Press [ON/OFF] (Power).
• You can configure the camera so power does not turn on when you press [r]
(REC) or [p] (PLAY). You also can configure the camera to turn off when you
press [r] (REC) or [p] (PLAY) (page 157).
23
Quick Start Basics
Holding the Camera Correctly
Your images will not come out
clearly if you move the camera
when you press the shutter
button. When pressing the
shutter button, be sure to hold
the camera as shown in the
illustration, and keep it still by
pressing your arms firmly
against your sides as you shoot.
Holding the camera still,
carefully press the shutter button
and take care to avoid all
movement as the shutter
releases and for a few moments after it releases. This is especially important when
available lighting is low, which slows down the shutter speed.
NOTE
• Take care that your fingers and the strap do not
cover any of the areas indicated in the illustration.
• To protect against accidentally dropping the
camera, attach the wrist strap and make sure it is
around your fingers or wrist while you are operating
the camera.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this
camera only. Never use it for any other purpose.
• When the “Auto Rotate” setting is turned on, the
camera will detect whether it is being held vertically
or horizontally when a snapshot image is shot.
When you display an image shot with the camera held vertically, the image is
rotated automatically 90 degrees when displayed on the monitor screen (page
151).
Horizontal Vertical
Hold the camera so the flash is above the lens.
Flash
Front lamp
Lens
IMPORTANT!
• Take care to ensure that your fingers are not blocking or
are not too close to the flash. Fingers can cause unwanted
shadows when using the flash.
24
Quick Start Basics
To shoot a snapshot
R
Selecting an Auto Recording Mode
You can select one of two auto recording modes (Auto or Premium Auto) according to
your digital imaging needs.
Auto
Ÿ
Premium Auto
This is the standard Auto recording mode.
• It provides faster operation than Premium Auto recording.
With Premium Auto recording, the camera automatically
determines whether you are shooting a subject or scenery,
and other conditions. Premium Auto recording delivers higher
image quality than standard Auto recording.
• Premium Auto recording takes longer to process image data
after it is shot than Auto recording.
• It also requires more power (and runs down the battery
quicker) than Auto.
1. Press [r] (REC) to turn on the camera.
The camera will enter the REC mode.
2. Use [AUTO] to select Auto recording mode.
Each press of [AUTO] toggles between Auto (r) and Premium Auto (Ÿ).
Auto recording mode icon
Remaining Snapshot Memory
Capacity (page 185)
• Selecting the “Auto” or “Premium Auto” BEST SHOT scene will change the
current auto recording setting accordingly (page 64).
[
AUTO
]
Monitor screen
Shutter button
[r] (REC)
25
Quick Start Basics
To shoot a snapshot
1. Point the camera at the subject.
If you are using Premium Auto, text will appear in the
lower right corner of the monitor screen describing the
type of shot the camera has detected.
• You can zoom the image, if you want.
w Wide Angle z Telephoto
Zoom controller
Appears when the
camera detects it is
stationary on a tripod.
2. Half-press the shutter button to
focus the image.
When focus is complete, the camera
will beep, the back lamp will light green,
and the focus frame will turn green.
Half-press
Press lightly
until the
button stops.
Beep, beep (Image is in focus.)
When you half-press the shutter button, the
camera automatically adjusts exposure and
focuses on the subject it is currently pointed at.
Mastering how much pressure is required for a
half-press and a full-press of the shutter button
is an important technique for good-looking
images.
3. Continuing to keep the camera still,
press the shutter button the rest of
the way down.
This records the snapshot.
Back lamp
Focus frame
Full-press
Snap (Image is recorded.)
26
Quick Start Basics
Recording a Movie
Press [0] (Movie) to start movie recording. Press [0] (Movie)
again to stop movie recording. See the following pages for
details.
Standard movie (STD movie): page 54
High-definition movie (FHD movie): page 57
High speed movie (HS movie): page 57
[0] (Movie)
. If the image does not focus...
If the focus frame stays red and the back lamp is flashing green, it means that the
image is not in focus (because the subject is too close, etc.). Re-point the camera at
the subject and try to focus again.
. Shooting with Auto
If the subject is not in the center of the frame...
“Focus lock” (page 85) is the name of a technique you can use when you want to
shoot an image in which the subject to be focused on is not within the focus frame in
the center of the screen.
To track the movement of a moving subject
Half-press the shutter button to follow and focus automatically on a moving subject.
See “Ë
Tracking” (page 88) for more information.
. Shooting with Premium Auto
• In addition to shutter speed, aperture, and ISO sensitivity, the camera
automatically executes the following operation as required when shooting with
Premium Auto.
– Auto Focus is normally performed until you half-press the shutter button.
– Intelligent AF (Page 88)
– Face Detection (Page 89)
• Shooting with Premium Auto can cause vibration and noise to occur due to lens
operation. This does not indicate malfunction.
• In some cases, Premium Auto may not be able to interpret the shooting
environment correctly. If this happens, shoot with standard Auto.
27
Quick Start Basics
Viewing Snapshots
Use the following procedure to view snapshots on the camera’s monitor screen.
• For information about how to play back movies, see page 97.
• For information about images recorded using continuous shutter (CS), see page
99.
1. Press [p] (PLAY) to enter the
PLAY mode.
• This will display one of the snapshots
currently stored in memory.
• Information about the displayed
snapshot also is included (page 12).
• You also can clear the information to
view only the snapshot (page 161).
• You can zoom in on the image by
sliding the zoom controller towards z (page 104). If you are recording a
snapshot that is very important to you, it is recommended that you zoom the
image and check its details after recording it.
[p] (PLAY)
2. Use [4] and [6] to scroll between images.
• Holding down either button scrolls at high speed.
[6]
[6]
[4]
NOTE
• Half-pressing the shutter button while in the PLAY mode or while a menu screen is
displayed will switch directly to the REC mode.
28
[4]
Quick Start Basics
Deleting Snapshots and Movies
If memory becomes full, you can delete snapshots and movies you no longer need in
order to free up storage and record more images.
IMPORTANT!
• Remember that a file (image) delete operation cannot be undone.
• For information about images recorded using continuous shutter (CS), see page
100.
To delete a single file
1. Press [p] (PLAY) to enter the PLAY mode and then
press [2] ( ).
2. Use [4] and [6] to scroll through the files until the one
you want to delete is displayed.
3. Use [8] and [2] to select “Delete” and then press [SET].
• To delete other files, repeat steps 2 and 3.
• To exit the delete operation, press [MENU].
• If a CS group (page 99) is displayed when you perform the above procedure,
all of the images in the currently displayed CS group will be deleted.
29
Quick Start Basics
To delete specific files
1. Press [p] (PLAY) to enter the PLAY mode and then press [2] ( ).
2. Use [8] and [2] to select “Delete Files” and then press [SET].
• This displays a file selection screen.
3. Use [8], [2], [4], and [6] to move the selection boundary to the file
you want to delete, and then press [SET].
• This will select the check box of the currently selected file.
4. Repeat step 3 to select other files, if you want. After you are finished
selecting files, press [MENU].
5. Use [8] and [2] to select “Yes” and then press [SET].
• This deletes the files you selected.
• To cancel the delete operation, select “No” in step 5 and then press [SET].
To delete all files
1. Press [p] (PLAY) to enter the PLAY mode and then press [2] ( ).
2. Use [8] and [2] to select “Delete All Files” and then press [SET].
3. Use [8] and [2] to select “Yes” and then press [SET] to delete all files.
This will cause the message “There are no files” to appear.
30
Quick Start Basics
Loading...
