Casio EX-TR60 User's Guide
Digital Camera
User’s Guide
EN
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
Accessories
As you unpack your camera, check to make sure that all accessories shown below
are included. If anything is missing, contact your original retailer.
Rechargeable lithium ion
battery (NP-150)
Micro USB cable Basic Reference
USB-AC adaptor
(AD-C53U)
Power cord
*
* The shape of the power cord plug varies according to the country or geographic
area where the camera is sold.
2
Read this first!
• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost
profits, or claims by third parties arising out of the use of EXILIM Connect.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
3
Contents
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Monitor Screen Contents and How to Change Them . . . . . . . . . . . . . . . . . . . . 9
]\
Quick Start Basics 12
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing the Camera Style to Suit Shooting Conditions . . . . . . . . . . . . . . . . 14
]
Opening and Closing the Frame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
]
Rotating the Monitor Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
]
Camera Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the Touch Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using the Selfie Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
]
Loading the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
]
Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 26
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
]
Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
]
To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
]
To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Turning Power On and Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To Shoot a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
]
Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
]
To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
]\
Recording Images 39
Selecting a Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
]
Shooting with Posing Shot . . . . . . . . . . . . . . . . . . . . . . . . . . . (Posing Shot) . . . 41
]
Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Art Shot) . . . 42
]
Shooting Three Versions of an Image with
Different Skin Tone Settings . . . . . . . . . . . . . . . . . . . . . . . . .(Make-up BKT). . . 44
]
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Make-up). . . 45
Using the Camera as a Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Shooting a Self-portrait . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Using the LED Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (LED) . . 52
4
Contents
]\
Using BEST SHOT 53
Shooting with Triple Shot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Using Motion Shutter to Trigger a Self-timer Operation . . (Motion Shutter) . . 55
Digitally Correcting for Overexposure and Underexposure . . . . . . (HDR) . . 56
Shooting with High Speed Night Scene . . . . . . . . . . . . .(HS Night Scene) . . 56
Shooting with High Speed Night Scene
and Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . . (HS Night Scene Portrait) . . 57
]\
Advanced Recording Settings 58
Using the REC Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
]
Using the Selfie Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Selfie Pad) . . . 59
]
Using Touch Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Touch Shutter). . . 60
]
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . . . 61
]
Using the LED Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (LED) . . . 61
]
Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Image Size) . . . 62
]
Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . .(Movie Quality) . . . 63
]
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . (Brightness). . . 63
]
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance). . . 64
]
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 65
]
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus) . . . 66
]
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review) . . . 67
]\
Viewing Snapshots and Movies 68
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
]
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . . .(Movie Editing). . . 70
Viewing the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . . 72
]\
Other Playback Functions (PLAY) 74
Using the PLAY Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
]
Using the Selfie Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Selfie Pad) . . . 75
]
Creating a Promotion Movie . . . . . . . . . . . . . . . . . . . . . (Promotion Movie). . . 75
]
Performing Paint Operations on an Image . . . . . . . . . . . . . . . . . . . . .(Paint). . . 77
]
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . . . 78
]
Extracting an Image from a Snapshot . . . . . . . . . . . . . . . .(Cut out subject). . . 78
]
Inserting a Subject into another Snapshot or
Adding a Built-in Frame to a Snapshot . . . . . . . . . . . . . . . . (Paste subject) . . . 80
]
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . . (Protect). . . 81
]
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation). . . 82
]
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize) . . . 82
]
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . . . 83
5
Contents
]\
Connecting the Camera with a Smartphone
(Wireless Connection) 84
Controlling Your Camera with a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . 84
Using a Wireless Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Getting Ready to Establish a Connection between a Smartphone and Your
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
]
Installing the EXILIM Connect App on Your Smartphone . . . . . . . . . . . . . . . . . . 88
]
Establishing a Wireless Connection for the First Time . . . . . . . . . . . . . . . . . . . . 89
Using a Smartphone as a Camera Remote Controller (Shoot with phone) . . 91
Sending a Snapshot or Movie File from Camera Memory
to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . (Send Selected Image) . . 91
Viewing Snapshots and Movies in Camera Memory
on a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (View on phone) . . 92
Configuring Wireless Connection Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
]
Entering the Camera’s Airplane Mode . . . . . . . . . . . . . . . . (Airplane Mode). . . 93
]
Sending Images from the Camera to a Smartphone
as They are Recorded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Auto Send) . . . 94
]
Specifying Images to be Sent by Auto Send . . . . (Auto Send File Settings). . . 95
]
Resizing Snapshots before Sending Them
to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize before send). . . 95
]
Changing the Camera Password for
Wireless LAN Connection . . . . . . . . . . . . . . . . . . . . . . . (WLAN password). . . 95
]
Unpairing the Camera from a Smartphone . . . . . . . . . . . . . . . . (Unpairing). . . 96
]\
Printing 97
Printing with a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
]\
Using the Camera with a Computer 98
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . . 98
]
Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
]
Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
]
Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . 102
]
Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
6
Contents
]\
Other Settings (Set Up) 107
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . . (Screen) . 107
Selecting Display Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Info) . 107
Locking the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Screen Lock) . 108
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 108
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . .(Timestamp) . 109
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . 110
]
Setting a Travel Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
]
Selecting the Time Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . .111
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . .111
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 112
Selecting the HDMI Terminal Output Method . . . . . . . . . . . . . . . . .(HDMI) . 112
Displaying a Startup Screen at Power On . . . . . . . . . . . . . . . . . .(Startup) . 113
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . 113
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . 113
Checking the Current Camera Firmware Version . . . . . . . . . . . . (Version) . 114
]\
Appendix 115
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
]
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
]
Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
]
Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
]
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
]
Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 145
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
7
Contents
General Guide
The numbers in parentheses indicate the pages where each item is explained.
2
1 3
9
bo
bk
bo
4
5
8
7
6
bn
bm
bl
Frame (page 14)
1
Shutter button (page 33)
2
[HDMI] cover (page 72)
3
LED light (page 52)
4
Lens
5
Microphone
6
(pages 17, 51)
bp
bq
br
• Above illustration shows the camera’s cover removed (page 19).
To attach the strap (commercially available or
separately available) to the camera
Attach strap here.
[HDMI] HDMI output
7
(micro) (page 72)
[USB] port
8
(pages 21, 24, 99, 103)
[p] (Power) (page 31)
9
Back lamp
bk
(pages 22, 25, 31, 33)
Battery compartment (page 19)
bp
Memory card slot (pages 29, 137)
bq
[OPEN] button (pages 19, 29)
br
Strap hole (page 8)
bl
Monitor screen
bm
(pages 9, 17, 107)
Speaker
bn
Selfie pad
bo
(pages 19, 59, 75)
1
2
8
Monitor Screen Contents and How to Change Them
bm blbnbo
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
. Snapshot Recording
1
2
cl
ck
bt
bs
br
bq
bp
PLAY mode icon (page 31)
1
“ ” (Show Icons) icon
2
White Balance (page 64)
3
Focus mode (page 66)
4
Digital zoom (page 47)
5
Timestamp (page 109)
6
Self-timer mode (page 61)
7
Snapshot image size (page 62)
8
Movie quality (pages 49, 63)
9
Battery level indicator (page 26)
bk
LED light (page 52)
bl
3
4
5
6
7
8
9
bk
cp co cn cm
Operation assigned to selfie pad
bm
(pages 19, 59)
Remaining movie memory capacity
bn
(page 145)
Remaining snapshot memory capacity
bo
(page 145)
“ ” Movie icon (pages 34, 49)
bp
Date/Time (pages 26, 111)
bq
Brightness (page 63)
br
ISO sensitivity (page 65)
bs
Bluetooth Smart communication
bt
status (page 89)
Auto Send (page 94)
ck
Wireless LAN communication status
cl
(page 90)/Airplane mode (page 93)
Menu icon (page 58)
cm
Recording mode icon (page 40)
cn
Wireless mode icon (page 86)
co
Mirror mode icon (page 46)
cp
9
. Movie Recording
1 3
Movie quality (
42
1
Recording time switch icon (page 50)
2
Movie remaining time icon (page 50)
3
Remaining movie memory capacity/
4
Movie recording time (pages 50, 145)
“ ” Movie stop icon (pages 34, 50)
5
pages 49, 63)
5
NOTE
• If you do not perform any operation for about three seconds during snapshot
recording or movie recording, icons will become transparent.
. Snapshot Viewing
4213
bq
bp
bo
bn
bm
bl
bk
9
8
Protect indicator (page 81)
1
“ ” (Show Icons) icon
2
Folder name-file name (page 105)
3
Snapshot image size (page 62)
4
Operation assigned to selfie pad
5
(pages 19, 75)
Battery level indicator (page 26)
6
Date/time (pages 26, 111)
7
5
6
7
ck bt bs br
Image menu icon (p
8
Shutter speed
9
Make-up (page 45)
bk
Brightness (page 63)
bl
ISO sensitivity (page 65)
bm
Bluetooth Smart communication
bn
status (page 89)
Auto Send (page 94)
bo
White Balance (page 64)
bp
Wireless LAN communication status
bq
(page 90)/Airplane mode (page 93)
Menu icon (page 74)
br
Delete icon (page 36)
bs
Wireless mode icon (pages 86, 92)
bt
REC mode icon (page 31)
ck
age 71)
NOTE
• The folder name and file name in the upper right corner of the monitor screen has
the meaning described below (page 105).
Example: 100-0023: 23rd image file in the folder named “100CASIO”.
10
. Movie Playback
Protect indicator (page 81)
5
1
“ ” (Show Icons) icon
2
Folder name-file name (page 105)
3
Movie quality (pages 49, 63)
4
Movie recording time (page 68)
5
Date/time (pages 26, 111)
6
Image menu ico
7
“”
Movie play ico
8
n (page 71)
n (page 68)
4213
8
67
NOTE
• If you do not perform any operation for about three seconds during snapshot
viewing or movie playback, icons will become transparent.
11
Quick Start Basics
What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following main functions.
Shooting better looking portraits
Make-up enables adjustment of human skin tone hues
and texture, and softening of facial shadows caused by
harsh sunlight for better looking portraits.
*See page 45 for more information.
A variety of shooting styles
The frame can be opened and the LCD monitor screen
rotated into positions that make long-term shooting
more comfortable and simplify self-shooting.
*See page 14 for more information.
Simple touch panel operation
The monitor screen is a touch panel that can be used
to perform operations.
*See page 17 for more information.
Simple self-portrait shooting
The monitor screen can be rotated so it faces in the
same direction as the camera’s lens, making selfshooting much easier.
*See page 48 for more information.
Posing Shot
Posing Shot lets you shoot five successive snapshots,
as the camera provides voice guidance.
*See page 41 for more information.
12
Quick Start Basics
Art Shot
A variety of artistic effects help to make even common,
ordinary subjects become more novel and exciting.
*See page 42 for more information.
Paint
Draw figures, write text, or stamp information into a
recorded snapshot.
*See page 77 for more information.
Wireless Connection
Turns your smartphone into a camera remote
controller and allows you to send images recorded with
your camera to your smartphone.
*See page 84 for more information.
13
Quick Start Basics
Changing the Camera Style to Suit Shooting Conditions
You can change the configuration of the camera by opening or closing the frame and
rotating the monitor screen panel to suit shooting conditions.
IMPORTANT!
• Do not apply strong pressure to the surface of the monitor screen. Doing so can
damage it.
• Never touch the lens with your fingers. Finger smudges, dirt, and other foreign
matter on the lens can interfere with proper operation of the camera. Use a blower
or other means to keep the lens and flash window free of dirt and dust, and wipe
gently with a soft, dry cloth.
Opening and Closing the Frame
The camera’s frame can be rotated 90 degrees
towards the lens side and 225 degrees towards
the opposite side.
225 degrees
90 degrees
1. With the lens facing towards you, hold
onto the frame.
2. Push the monitor screen panel.
3. Holding the edges of the monitor
screen panel, swing the frame open.
IMPORTANT!
• Do not try to open or close the frame while the monitor screen panel is rotated.
Doing so can cause the frame to come into contact with the monitor screen panel
and cause malfunction.
14
Quick Start Basics
Rotating the Monitor Screen
Use the steps below to rotate the monitor screen.
NOTE
• While holding the monitor screen panel as shown in the illustration, you can rotate
it 180 degrees clockwise and 90 degrees counterclockwise.
• The monitor screen panel can also be rotated when the frame is closed.
1. Hold the camera as shown in the
illustration.
2. Firmly holding the frame, carefully rotate the monitor screen panel.
180 degrees clockwise
90 degrees counterclockwise
15
Quick Start Basics
Camera Configurations
You can open the frame and rotate the monitor screen for a variety of different styles.
Normal Shooting Movie Recording
Shoot with the monitor screen facing the
opposite direction of the lens.
Tabletop Shooting Self-portrait Shooting
Point the monitor screen and lens in the
same direction and open the frame
about 30 degrees so the camera can
stand up.
Open the frame 90 degrees and hold the
frame. You can also shoot with the
camera upside down, if you like.
Open the frame, point the monitor
screen and lens in the same direction.
16
Quick Start Basics
NOTE
• When shooting hold the camera still. Carefully press the shutter button and take
care to avoid all movement as the shutter releases and for a few moments after it
releases.
• Take care that your fingers and the strap do not cover
any of the areas indicated in the illustration.
LED light
• To protect against accidentally dropping the camera,
attach the wrist strap (commercially available or
separately available) and make sure it is around your
fingers or wrist while you are operating the camera.
• Never swing the camera around by its strap.
IMPORTANT!
Microphone
Lens
• Take care to ensure that your finger is not blocking or
is not too close to the LED light. Fingers can cause
unwanted shadows when shooting.
Using the Touch Panel
The monitor screen of the camera is a touch panel. This means you can perform the
following operations by touching the screen with your fingers.
Touch
Momentarily touching the screen with your finger.
Touch the screen to select an icon or menu item, and
to configure settings.
Touch-and-hold
Holding your finger against the screen.
Touch and hold the screen to perform continual
frame-by-frame playback of a movie.
17
Quick Start Basics
Drag
Holding your finger against the screen as you drag it
up, down, left, or right.
Use drag to move a screen image to a different
location, and to scroll between images.
Spread
Holding your thumb and forefinger against the screen
as you spread them out.
Use spread to enlarge the screen image.
Squeeze
Holding your thumb and forefinger against the screen
as you bring them together.
Use squeeze to reduce the size of the screen image.
IMPORTANT!
• Never use a pointed or hard object to perform screen operations. Doing so can
damage the screen.
• The camera will have a hard time interpreting a screen operation made using your
fingernails. Use the fleshy pad of your finger.
NOTE
• Applying a commercially available LCD protective sheet will reduce the operation
sensitivity of the monitor screen.
18
Quick Start Basics
Using the Selfie Pad
You can use the selfie pad on the outside
edge of the frame to perform various functions
while shooting a self-portrait.
Double-tap
Tap the selfie pad twice in succession.
“μ” will appear on the screen, which
indicates that selfie pad operation is enabled.
Slide
Slide your finger upwards or downwards along
the selfie pad.
NOTE
• Use the menu screen’s “Selfie Pad” item (pages 59, 75) to assign an operation to
the selfie pad.
The selfie pad is the area
between the two bumps on
the side of the frame.
First, charge the battery prior to use.
Note that the battery of a newly purchased camera is not charged. Perform the steps
below to load the battery into the camera and charge it.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-150)
for power. Never try to use any other type of battery.
Loading the Battery
1. Open the frame (page 14).
2. Open the cover.
While depressing the [OPEN] button, slide
the cover in the direction of arrow
nearby illustration.
2
in the
1
3
19
[OPEN] button
2
Quick Start Basics
3. Load the battery.
With the CASIO logo on the battery
upwards, load the battery into the
camera as shown in the illustration.
Battery
NG
OK
CASIO logo
4. Close the cover.
• Positioning the cover about two millimeters from
the lens unit, keep it parallel with the camera as
you slide it in the direction of arrow
arrow
To replace the battery
to secure it in place.
2
and then
1
1. Open the cover and remove the current
battery.
As shown in the illustration, pull up the edge of
the battery to remove it.
2. Load a new battery.
1
2mm
2
20
Quick Start Basics
Charge the Battery
You can use either of the two following methods to charge the battery. Before
charging the battery, use the procedure under “Opening and Closing the Frame”
(page 14) to open the frame.
• USB-AC adaptor
• USB connection to a computer
. To charge with the USB-AC adaptor
The adaptor lets you charge the battery while it is loaded in the camera.
While the camera is turned off, connect in the sequence shown below.
Charging time: Approximately 140 minutes
[USB] port
Micro USB cable
(included with camera)
3
4
u mark of the small (micro
USB) connector facing the side
opposite that of the monitor
screen.
• When disconnecting the USB-AC adaptor from the camera, be sure to disconnect
from the camera first.
1
USB-AC adaptor
(AD-C53U)
2
Power cord
21
Quick Start Basics
IMPORTANT!
• A battery that has not been used for a long time, or ambient temperature extremes
can cause charging to take longer than normal. If charging takes longer than about
five hours, a timer will terminate it automatically, even if the battery is not fully
charged. This is indicated by the back lamp flashing red. If the battery has not been
used for a very long time, charging may be terminated automatically and the back
lamp may start flashing red after only about 60 minutes. In either case, disconnect
the USB cable from the camera and then reconnect it to resume charging.
•Pressing [p] (Power) while the USB-AC adaptor is connected to the camera will
turn on the camera with power being supplied by the battery. Because of this,
charging will stop.
• The USB-AC adaptor will become warm during charging. This is normal and does
not indicate malfunction.
• The shape of the power plug depends on each country or geographic area.
Back Lamp Operation
Lamp Status Description
Back lamp
Lit Red Charging
Abnormal ambient temperature, USB-AC
Flashing Red
adaptor problem, or battery problem (page
135), or charging terminated by the timer
Off Charging complete
22
Quick Start Basics
USB Cable Connection Precautions
• When connecting the USB cable to the camera, make sure that the cable
connector and monitor screen panel are oriented correctly as shown in the
illustration below.
Make sure that the u mark side of the
USB cable connector and the front of the
monitor screen panel (the side opposite that
of the monitor screen) are facing in the same
direction.
Front of monitor screen
The back lamp always initially light after charging starts. Even if the battery is
already fully charged, the lamp will light momentarily.
If the lamp does not light, check the orientation of the USB cable connector.
• Make sure that you insert the cable connector into the USB port until you feel it
click securely into place. Failure to insert the connector fully can result in poor
communication or malfunction.
• Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector as
shown in the illustration.
panel
23
Quick Start Basics
. To charge using a USB connection to a computer
USB connection lets you charge the battery while it is loaded in the camera.
While the camera is turned off, connect in the sequence shown below (
[USB] port
USB port
1, 2
Computer
(power turned on)
USB
).
1
Micro USB cable
(included with camera)
u mark of the small (micro USB) connector facing the side
opposite that of the monitor screen.
• If the camera is on, press [p] (Power) to turn it off before connecting it to your
computer.
Charging time: Approximately 170 minutes
IMPORTANT!
• The first time you connect the camera to your computer with the USB cable, an
error message may appear on your computer. If this happens, disconnect and then
reconnect the USB cable.
• A battery that has not been used for a long time, certain types of computers, and
connection conditions can cause charging to take more than approximately five
hours, which will trigger a timer that terminates charging automatically, even if the
battery is not fully charged. If this happens, disconnect and then reconnect the
USB cable to restart charging. To complete charging faster, use of the included
USB-AC adaptor is recommended.
• If the battery has not been used for a very long time, charging may terminate
automatically and the back lamp may start flashing red or go out after only about
60 minutes. In either case, use of the USB-AC adaptor that comes with the camera
is recommended.
• If you turn on the camera while charging over a USB connection to a computer is in
progress, the camera will establish a USB connection with the computer. Though
charging normally should continue at this time, certain types of computers or
connection environments may stop charging if supply power is low. This will be
indicated by the camera’s back lamp lighting green.
• Charging is not performed while the connected computer is in the hibernate mode.
2
24
Quick Start Basics
Back Lamp Operation
Lamp Status Description
Lit Red,
(Lit/Flashing Amber)
Charging
Back lamp
Abnormal ambient temperature,
Flashing Red
charging taking abnormally long, or
battery problem (page 135)
Off, (Lit Green) Charging complete
• The information in parentheses in the above table shows the lamp status while the
camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s
battery (NP-150) without removing it from the camera. Never use any other type of
charger device. Attempting to use a different charger can result in unexpected
accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards.
Use of an inferior device or a device that is not up to standard can cause
malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you.
Even in the case of a commercially available computer, certain USB port
specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give
the battery time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the USB-AC adaptor into an outlet that is further away from
the TV or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging.
Use of any other type of devices may result in improper charging.
25
Quick Start Basics
Checking the Current Battery Level
As battery power is consumed, a battery indicator on the monitor screen indicates its
current level as shown below.
Remaining Power High Low
Battery Indicator ***
Indicator Color White * White * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• Leaving the camera for about 20 days with no power supplied while the battery is
dead will cause its date and time settings to be cleared. A message telling you to
configure time and date settings will appear the next time you turn on the camera
after restoring power. When this happens, configure date and time settings (page
111).
• See page 149 for information about battery life and number of shots.
Configuring Basic Settings the First Time You Turn On the Camera
The first time you turn on the camera, a screen appears for configuring the display
language, date, and time settings. Failure to set the date and time correctly will cause
the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if
you purchased a camera intended for the Japanese market. To change the display
language from Japanese in this case, use the procedure under “Specifying the
Display Language (Language)” (page 112). Note that a version of this manual in
the language you select may not be included with a camera intended for the
Japanese market.
• Camera models sold in certain geographic areas may not support display language
selection.
26
Quick Start Basics
1. Press [p] (Power) to turn on the camera.
2. Drag (page 18) upwards and downwards until
you find the language you want, and then touch
to select it.
3. Touch the date display format you want.
Example: July 10, 2016
YY/MM/DD
DD/MM/YY
MM/DD/YY
* 16/7/10
* 10/7/16
* 7/10/16
[p] (Power)
4. Touch the value you want to change (year, month,
day, hour, minute).
5. Touch “ ”, “ ” to change the currently selected
value.
• Touching and holding “ ”, “ ” will change the setting
at high speed.
• To switch between 12-hour and 24-hour format, touch
the 12/24 hour switch icon.
6. When the date and time settings are the way you
want, touch “OK”.
12/24 hour switch
7. Touch “Auto” or “Premium Auto Pro” to select the default auto
recording mode you want.
8. Touch “Apply”.
• You will be able to change this setting later, if you want. See page 32 for
details.
icon
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: Page 112
– Date and time: Page 111
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
27
Quick Start Basics
Preparing a Memory Card
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 145.
Supported Memory Cards
– microSD Memory Card
– microSDHC Memory Card
– microSDXC Memory Card
• The above are supported memory card types as of January
2015.
• This camera supports use of microSD memory cards of the following types and
capacities: microSD memory cards up to 2GB, microSDHC memory cards from
2GB up to 32GB, microSDXC memory cards from 32GB up to 2TB. Note that the
ability to use any particular card with this camera, even if it satisfies the above
capacity and type requirements, is not guaranteed.
Warning!
*
0 Memory cards are small and present a risk of accidentally being swallowed
by infants and young children. Keep memory cards out of the reach of
infants and young children. If a memory card is ever swallowed accidentally,
contact a physician immediately.
+
. Memory Card Handling Precautions
Certain types of memory cards can slow down processing speeds. In particular, highquality movies may not be able to be stored correctly. A slow memory card can take
too much time to record data and result in breaks in the image and/or audio during
playback. When this happens the movie icon will turn yellow on the monitor screen.
28
Quick Start Basics
To load a memory card
1. Press [p] (Power) to turn off the
camera and then open the frame
(page 14).
2. While holding down [OPEN], slide
the cover in the direction of arrow
in the nearby illustration to
2
remove it.
3. Load a memory card.
Positioning the memory card as shown in
the nearby illustration insert it into the
camera’s memory card slot and press
until you hear it click into place.
1
[OPEN] button
Front
3
2
Front Back
4. Close the cover.
• Positioning the cover about two millimeters from
the lens unit, keep it parallel with the camera as
you slide it in the direction of arrow
arrow
IMPORTANT!
• Never insert anything besides a supported memory card (page 28) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, and contact your retailer or nearest CASIO authorized service center.
to secure it in place.
2
and then
1
29
1
2mm
2
Quick Start Basics
. To replace the memory card
Press the memory card and then release it. This will
cause it to pop out of the memory card slot slightly.
Pull the card out the rest of the way and then insert
another one.
• Never remove a card from the camera while the
back lamp is flashing green. Doing so can cause the
image save operation to fail and even damage the
memory card.
To format (initialize) a new memory card
Format a memory card on the camera before using it for the first time.
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete
its contents. Normally you do not need to format a memory card again. However, if
storing to a card has slowed down or if you notice any other abnormality, re-format
the card.
• Be sure to use the camera to format a memory card. Formatting a card on a
computer will result in a non-SD standard format, which can greatly slow down
processing time and cause compatibility, performance, and other problems.
1. Load a memory card (page 29).
2. Turn on the camera and then touch “ ” (Show Icons).
3. Touch “MENU”.
4. Drag upwards and downwards until you find “Setup”, and then touch it.
5. Touch “Format”.
6. Touch “Format” and then touch “Yes”.
This starts the memory card format operation.
30
Quick Start Basics
Loading...
