Casio EX-TR15 User Manual

Digital Camera
User’s Guide
E
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.com/

Accessories

As you unpack your camera, check to make sure that all accessories shown below are included. If anything is missing, contact your original retailer.
Rechargeable lithium ion
battery (NP-150)
Power cord
2
*
To attach the strap to the camera
USB-AC adaptor*
(AD-C54UG/AD-C53U)
Micro USB cable Basic Reference
Attach strap here.
1
1
Strap
*1 The type of USB-AC adaptor included varies according to the country or
geographic area where the camera is sold.
*2 A power cord is included with the AD-C53U USB-AC adapter. The shape of the
power cord plug varies according to the country or geographic area where the camera is sold.
2

Read this first!

• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production process. Feel free to contact us if you notice anything that is questionable, erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is forbidden. Except for your own personal use, any other use of the contents of this manual without the permission of CASIO COMPUTER CO., LTD. is forbidden under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost profits, or claims by third parties arising out of the use of EXILIM Remote.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits caused by loss of memory contents due to malfunction, repair, or any other reason.
• Note that the example screens and product illustrations shown in this User’s Guide may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that provides a pixel yield in excess of 99.99%. This means that some very small number of pixels may not light or may remain lit at all times. This is due to the characteristics of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is recording correctly.

Contents

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Monitor Screen Contents and How to Change Them . . . . . . . . . . . . . . . . . . . . 9
]\
Quick Start Basics 12
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing the Camera Style to Suit Shooting Conditions . . . . . . . . . . . . . . . . 14
]
Opening and Closing the Frame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
]
Rotating the Monitor Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
]
Camera Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the Touch Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
]
Loading the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
]
Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 25
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
]
Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
]
To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
]
To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Turning Power On and Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
To Shoot a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
]
Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
]
To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
]\
Recording Images 38
Selecting a Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
]
Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . . .(ART SHOT). . . 40
]
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Make-up). . . 42
]
Using Motion Shutter to Trigger a Self-timer Operation . . . (Motion Shutter). . . 43
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Shooting a Self-portrait . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Contents
]\
Using BEST SHOT 50
Shooting Clearer Snapshots . . . . . . . . . . . . . . . . . . . . . . (Multi SR Zoom) . . 51
Digitally Correcting for Overexposure and Underexposure . . . . . . (HDR) . . 52
Shooting with High Speed Night Scene . . . . . . . . . . . . .(HS Night Scene) . . 53
Shooting with High Speed Anti Shake . . . . . . . . . . . . . . . (HS Anti Shake) . . 54
Shooting with Priority on Subject Faces . . . . . . . . . . . (HS Best Selection) . . 54
Shooting a Panorama Image . . . . . . . . . . . . . . . . . . . . .(Slide Panorama) . . 55
]\
Advanced Recording Settings 58
Using the REC Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
]
Using Touch Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Touch Shutter). . . 59
]
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . . . 59
]
Using the LED Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (LED) . . . 60
]
Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Image Size) . . . 61
]
Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . .(Movie Quality) . . . 62
]
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift). . . 63
]
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance). . . 64
]
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 65
]
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus) . . . 66
]
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review) . . . 67
]
Checking a Snapshot before Saving It . . . . . . . . . . . . . (Self-portrait check). . . 68
]\
Viewing Snapshots and Movies 69
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
]
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . . .(Movie Editing). . . 71
Viewing a Panorama Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Viewing the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . . 74
]\
Other Playback Functions (PLAY) 76
Using the PLAY Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
]
Performing Paint Operations on an Image . . . . . . . . . . . . . . . . . . . . .(Paint). . . 77
]
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . . . 78
]
Extracting an Image from a Snapshot . . . . . . . . . . . . . . . .(Cut out subject). . . 78
]
Inserting a Subject into another Snapshot . . . . . . . . . . . . . . (Paste subject). . . 80
]
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . . (Protect). . . 81
]
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation). . . 82
]
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize) . . . 82
]
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . . . 83
Contents
]\
Establishing a Wireless LAN Connection 84
Wireless LAN Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Establishing a Connection between a Smartphone and Your Camera . . . . . . 85
]
Installing the EXILIM Remote App on Your Smartphone . . . . . . . . . . . . . . . . . . 85
]
Configuring Wireless LAN Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Using a Smartphone as a Camera Remote Controller . (Remote Capture) . . 86
Sending a Just-recorded Snapshot to a Smartphone . . . . . . (Quick Send) . . 88
Sending a Snapshot or Movie File from
Camera Memory to a Smartphone . . . . . . . . . . . . . . . . . .(Send to phone) . . 89
Resizing Snapshots before Sending Them to
a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize before send) . . 90
Viewing Snapshots and Movies in
Camera Memory on a Smartphone . . . . . . . . . . . . . . . . (View on phone) . . 91
]\
Printing 92
Printing with a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
]\
Using the Camera with a Computer 94
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . . 94
]
Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
]
Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
]
Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . . 98
]
Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
]\
Other Settings (Set Up) 103
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . . (Screen) . 103
Automatically Orienting the Monitor Screen Contents to
Match Camera Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . .(Auto rotate) . 103
Resizing Snapshots before Sending Them to
a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize before send) . 103
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 104
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . .(Timestamp) . 104
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . 105
]
Setting a Travel Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
]
Selecting the Time Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 106
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 106
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 107
Selecting the HDMI Terminal Output Method . . . . . . . . . . . . . . . . .(HDMI) . 107
Contents
Changing the Camera Password for
Wireless LAN Connection . . . . . . . . . . . . . . . . . . . . . . . (WLAN password) . 108
Displaying a Startup Screen at Power On . . . . . . . . . . . . . . . . . .(Startup) . 108
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . 109
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . 109
]\
Appendix 110
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
]
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
]
Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
]
Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
]
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
]
Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 131
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Contents

General Guide

The numbers in parentheses indicate the pages where each item is explained.
1
Frame (page 14)
1
Speaker
2
Shutter button*
3
(Self-portrait shutter button) (pages 32, 68) Lens
4
Microphone
5
(pages 17, 49) LED light (page 60)
6
* Your camera has two shutter buttons.
456
br
2
3
Memory card slot
7
(pages 28, 29) [HDMI] HDMI output
8
(micro) (page 74) [CARD HDMI] cover
9
(pages 28, 74) Back lamp
bk
(pages 21, 24, 30, 32) [p] (Power) (page 30)
bl
Battery slot (page 19)
br
7
8
bo
9
bkblbmbn bpbq
Shutter button*
bm
(page 32) Monitor screen
bn
(pages 9, 10, 103) [USB] port
bo
(pages 20, 23, 95, 99) Strap hole (page 2)
bp
[BATT.OPEN] button
bq
(pages 19, 19)

Monitor Screen Contents and How to Change Them

The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes. They do not represent screens that actually appear on the camera.
. Snapshot Recording
Tab (page 30)
356
7241
bs br bq
bo bp bo
blbmbn
NOTE
•bm Movie capacity and bn Snapshot capacity do not appear in the following cases,
even if “Information On” is selected for the information display setting (page 11). – Portrait orientation display – When the monitor screen and lens are facing in the same direction
1
Focus mode (page 66)
2
Self-timer mode (page 59)
3
8
Digital zoom (page 44)
4
Snapshot image size (page 61)
5
9
Movie quality (pages 47, 62)
6
LED light (page 60)
7
Zoom icons (pages 32, 44)
bk
8
Quick send icon (page 88)
9
b” Movie icon (pages 33, 47)
bk
Battery level indicator (page 25)
bl
Movie capacity (recording time) (page 32)
bm
Snapshot capacity (number of shots)
bn
(page 32) PLAY mode icon (page 30)
bo
Information icon (page 11)
bp
Remote capture icon (page 86)
bq
Recording mode icon (page 39)
br
Menu icon (page 58)
bs
. Movie Recording
1 3
. Snapshot Viewing
42
13
bn bm bl bk 9
. Movie Playback
32 41
9bk 8
Movie quality (
1
Recording time switch icon (page 48)
2
Movie remaining time icon (page 48)
3
5
Remaining movie memory capacity/
4
Movie recording time (pages 48, 132) Zoom icons (pages 32, 44)
5
c” Movie stop icon (pages 33, 48)
6
6
Tab (page 30)
42
78
1
Protect indicator (page 81)
2
Folder name/file name (page 101)
3
5
Snapshot image size (page 61)
4
Image menu icon (p
5
Image scroll icons (pages 35, 69)
6
Battery level indicator (page 25)
7
Date/time (pages 25, 106)
8
6
REC mode icon (page 30)
9
Information icon (page 11)
bk
Image send icon (pages 89, 91)
bl
Delete icon (page 35)
bm
Menu icon (page 76)
bn
Tab (page 30)
1
Protect indicator (page 81)
2
Folder name/file name (page 101)
5
3
Movie quality (pages 47, 62)
4
6
Image menu ico
5
Movie recording time (page 69)
6
Image scroll icons (pa
7
Battery level indicator (page 25)
8
7
Date/time (pages 25, 106)
9
6
Movie play ico
bk
pages 47, 62)
age 73)
n (page 73)
ges 35, 69)
n (page 69)
10
. Selecting Display Information (DISP)
Each touch of “DISP” will cycle through settings that display or hide on-screen information. You can configure separate settings for the REC mode and PLAY mode.
• If “DISP” is not displayed on the screen, touch the tab to display it.
• Display information cannot be changed during movie recording.
Off No information displayed.
Information On Shows information about image settings, etc.
Status On
When Status On is selected for display information in the PLAY mode, the exposure, shutter speed, and ISO sensitivity setting values of the currently displayed image are displayed in orange when the current image’s Auto Exposure (AE) is not correct.
Shows more detailed information about settings.
• When Status On is selected, you will not be able to view the subject on the monitor screen.
11

Quick Start Basics

What you can do with your CASIO camera

Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following main functions.
A variety of shooting styles
The frame can be opened and the LCD monitor screen rotated into positions that make long-term shooting more comfortable and simplify self-shooting.
*See page 14 for more information.
Simple touch panel operation
The monitor screen is a touch panel that can be used to perform operations.
*See page 17 for more information.
Simple self-portrait shooting
The monitor screen can be rotated so it faces in the same direction as the camera’s lens, making self­shooting much easier.
*See page 46 for more information.
Make-Up
Make-up smoothes the skin texture of the subject and softens facial shadows caused by harsh sunlight for better looking portraits.
*See page 42 for more information.
12
Quick Start Basics
ART SHOT
A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting. “ART SHOT” provides the following effects: HDR Art, Sparkling Shot, Toy Camera, Soft Focus, Light Tone, Pop, Sepia, Monochrome, Miniature, Fisheye.
*See page 40 for more information.
Extract a subject from one photo and insert it into another
A simple operation lets you extract a person or object out of one snapshot and insert into another snapshot.
*See pages 78, 80 for more information.
Paint
Draw figures, write text, or stamp information into a recorded snapshot.
*See page 77 for more information.
Wireless LAN Connection
Turns your smartphone into a camera remote controller and allows you to send images recorded with your camera to your smartphone.
*See page 84 for more information.
13
Quick Start Basics

Changing the Camera Style to Suit Shooting Conditions

You can change the configuration of the camera by opening or closing the frame and rotating the monitor screen panel to suit shooting conditions.
IMPORTANT!
• Do not apply strong pressure to the surface of the monitor screen. Doing so can damage it.
• Never touch the lens with your fingers. Finger smudges, dirt, and other foreign matter on the lens can interfere with proper operation of the camera. Use a blower or other means to keep the lens and flash window free of dirt and dust, and wipe gently with a soft, dry cloth.

Opening and Closing the Frame

The frame of the camera can be rotated 360 degrees.
1. With the monitor screen facing towards
you, hold onto the frame.
2. Push the monitor screen panel from
behind.
3. Holding the edges of the monitor
screen panel, swing the frame open.
IMPORTANT!
• Do not try to open or close the frame while the monitor screen panel is rotated. Doing so can cause the frame to come into contact with the monitor screen panel and cause malfunction.
14
Quick Start Basics

Rotating the Monitor Screen

Use the steps below to rotate the monitor screen.
NOTE
• While holding the monitor screen panel as shown in the illustration, you can rotate it 180 degrees clockwise and 90 degrees counterclockwise.
• The monitor screen panel can also be rotated when the frame is closed.
1. Hold the camera as shown in the
illustration.
2. Firmly holding the frame, carefully rotate the monitor screen panel.
180 degrees clockwise
90 degrees counterclockwise
15
Quick Start Basics

Camera Configurations

You can open the frame and rotate the monitor screen for a variety of different styles.
Normal Shooting Movie Recording
Shoot with the monitor screen facing the opposite direction of the lens.
Tabletop Shooting Self-portrait Shooting
Point the monitor screen and lens in the same direction and open the frame about 30 degrees so the camera can stand up.
Open the frame 90 degrees and hold the frame. You can also shoot with the camera upside down, if you like.
Open the frame, point the monitor screen and lens in the same direction, and press the shutter button on the frame to shoot.
16
Quick Start Basics
NOTE
• When shooting hold the camera still. Carefully press the shutter button and take care to avoid all movement as the shutter releases and for a few moments after it releases.
• Take care that your fingers and the strap do not cover any of the areas indicated in the illustration.
LED light
• To protect against accidentally dropping the camera, attach the wrist strap and make sure it is around your fingers or wrist while you are operating the camera.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this camera only. Never use it for any other purpose.
Microphone
Lens
IMPORTANT!
• Take care to ensure that your finger is not blocking or is not too close to the LED light. Fingers can cause unwanted shadows when shooting.

Using the Touch Panel

The monitor screen of the camera is a touch panel. This means you can perform the following operations by touching the screen with your fingers.
Touch
Momentarily touching the screen with your finger. Touch the screen to select an icon or menu item, and to configure settings.
Touch-and-hold
Holding your finger against the screen. Touch and hold the screen to scroll images at high speed, or to perform continual frame-by-frame playback of a movie.
17
Quick Start Basics
Drag
Holding your finger against the screen as you drag it up, down, left, or right. Use drag to move a screen image to a different location, and to scroll between images.
Spread
Holding your thumb and forefinger against the screen as you spread them out. Use spread to enlarge the screen image.
Squeeze
Holding your thumb and forefinger against the screen as you bring them together. Use squeeze to reduce the size of the screen image.
IMPORTANT!
• Never use a pointed or hard object to perform screen operations. Doing so can damage the screen.
NOTE
• Applying a commercially available LCD protective sheet will reduce the operation sensitivity of the monitor screen.
18
Quick Start Basics

First, charge the battery prior to use.

Note that the battery of a newly purchased camera is not charged. Perform the steps below to load the battery into the camera and charge it.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-150) for power. Never try to use any other type of battery.

Loading the Battery

1. Open the cover.
While depressing the [BATT.OPEN] button, slide the cover in the direction indicated by the arrow in the illustration.
1
3
2. Load the battery.
With the EXILIM logo on the battery upwards, load the battery into the camera as shown in the illustration.
3. Close the cover.
While holding down the [BATT.OPEN] button, align the tabs of the cover with the notches on the camera and then slide the cover in the direction of the arrow.
[BATT.OPEN]
button
Battery
NG
1
[BATT.OPEN]
button
2
OK
EXILIM logo
2
3
19
Quick Start Basics
To replace the battery
1. Open the battery cover and remove the
current battery.
As shown in the illustration, pull up the edge of the battery to remove it.
2. Load a new battery.

Charge the Battery

You can use either of the two following methods to charge the battery. Before charging the battery, use the procedure under “Opening and Closing the Frame” (page 14) to open the frame.
• USB-AC adaptor
• USB connection to a computer
. To charge with the USB-AC adaptor
The adaptor lets you charge the battery while it is loaded in the camera. While the camera is turned off, connect in the sequence shown below. Charging time: Approximately 140 minutes
[USB] port
USB-AC adaptor
(AD-C54UG)
3
2
u mark of the small (micro USB) connector facing the side opposite that of the monitor screen.
1
2
USB-AC adaptor
20
Micro USB cable (included with camera)
4
3
Power cord
(AD-C53U)
Quick Start Basics
IMPORTANT!
• A battery that has not been used for a long time, or ambient temperature extremes can cause charging to take longer than normal. If charging takes longer than about five hours, a timer will terminate it automatically, even if the battery is not fully charged. This is indicated by the back lamp flashing red. If the battery has not been used for a very long time, charging may be terminated automatically and the back lamp may start flashing red after only about 60 minutes. In either case, disconnect the USB cable from the camera and then reconnect it to resume charging.
•Pressing [p] (Power) while the USB-AC adaptor is connected to the camera will turn on the camera with power being supplied by the battery. Because of this, charging will stop.
• The USB-AC adaptor will become warm during charging. This is normal and does not indicate malfunction.
• The shape of the power plug depends on each country or geographic area.
Back Lamp Operation
Lamp Status Description
Back lamp
Lit Red Charging
Abnormal ambient temperature, USB-AC
Flashing Red
adaptor problem, or battery problem (page
121), or charging terminated by the timer
Off Charging complete
21
Quick Start Basics
USB Cable Connection Precautions
• When connecting the USB cable to the camera, make sure that the cable connector and monitor screen panel are oriented correctly as shown in the illustration below.
Make sure that the u mark side of the USB cable connector and the front of the monitor screen panel (the side opposite that of the monitor screen) are facing in the same direction.
Front of monitor screen
The back lamp always initially light after charging starts. Even if the battery is already fully charged, the lamp will light momentarily. If the lamp does not light, check the orientation of the USB cable connector.
• Make sure that you insert the cable connector into the USB port until you feel it click securely into place. Failure to insert the connector fully can result in poor communication or malfunction.
• Note that even while the connector is fully inserted, you still will be able to see the metal part of the connector as shown in the illustration.
panel
22
Quick Start Basics
. To charge using a USB connection to a computer
USB connection lets you charge the battery while it is loaded in the camera. While the camera is turned off, connect in the sequence shown below (
[USB] port
USB port
1, 2
Computer
(power turned on)
USB
).
1
Micro USB cable
(included with camera)
u mark of the small (micro USB) connector facing the side opposite that of the monitor screen.
• If the camera is on, press [p] (Power) to turn it off before connecting it to your computer. Charging time: Approximately 170 minutes
IMPORTANT!
• The first time you connect the camera to your computer with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.
• A battery that has not been used for a long time, certain types of computers, and connection conditions can cause charging to take more than approximately five hours, which will trigger a timer that terminates charging automatically, even if the battery is not fully charged. If this happens, disconnect and then reconnect the USB cable to restart charging. To complete charging faster, use of the included USB-AC adaptor is recommended.
• If the battery has not been used for a very long time, charging may terminate automatically and the back lamp may start flashing red or go out after only about 60 minutes. In either case, use of the USB-AC adaptor that comes with the camera is recommended.
• If you turn on the camera while charging over a USB connection to a computer is in progress, the camera will establish a USB connection with the computer. Though charging normally should continue at this time, certain types of computers or connection environments may stop charging if supply power is low. This will be indicated by the camera’s back lamp lighting green.
• Charging is not performed while the connected computer is in the hibernate mode.
2
23
Quick Start Basics
Back Lamp Operation
Lamp Status Description
Lit Red, (Lit/Flashing Amber)
Charging
Back lamp
Abnormal ambient temperature,
Flashing Red
charging taking abnormally long, or battery problem (page 121)
Off, (Lit Green) Charging complete
• The information in parentheses in the above table shows the lamp status while the camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s battery (NP-150) without removing it from the camera. Never use any other type of charger device. Attempting to use a different charger can result in unexpected accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards. Use of an inferior device or a device that is not up to standard can cause malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you. Even in the case of a commercially available computer, certain USB port specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give the battery time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of this, it is recommended that you charge the battery immediately before you need to use it.
• Charging the camera’s battery may cause interference with TV and radio reception. If this happens, plug the USB-AC adaptor into an outlet that is further away from the TV or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging. Use of any other type of devices may result in improper charging.
24
Quick Start Basics
Checking the Current Battery Level
As battery power is consumed, a battery indicator on the monitor screen indicates its current level as shown below.
Level High Low
Battery Indicator ***
Indicator Color Cyan * Yellow * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the REC mode and PLAY mode.
• Leaving the camera for about 30 days with no power supplied while the battery is dead will cause its date and time settings to be cleared. A message telling you to configure time and date settings will appear the next time you turn on the camera after restoring power. When this happens, configure date and time settings (page
106).
• See page 135 for information about battery life and number of shots.

Configuring Basic Settings the First Time You Turn On the Camera

The first time you turn on the camera, a screen appears for configuring the display language, date, and time settings. Failure to set the date and time correctly will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if you purchased a camera intended for the Japanese market. To change the display language from Japanese in this case, use the procedure under “Specifying the Display Language (Language)” (page 107). Note that a version of this manual in the language you select may not be included with a camera intended for the Japanese market.
• Camera models sold in certain geographic areas may not support display language selection.
25
Quick Start Basics
1. Press [p] (Power) to turn on the camera.
2. Drag (page 18) upwards and downwards until
you find the language you want, and then touch to select it.
3. Touch the date display format you want.
Example: July 10, 2015 YY/MM/DD DD/MM/YY MM/DD/YY
* 15/7/10 * 10/7/15 * 7/10/15
[p] (Power)
4. Touch the value you want to change (year,
month, day, hour, minute).
5. Touch “8” or “2” to change the currently
selected value.
• Touching and holding “8” or “2” will change the
setting at high speed.
• To switch between 12-hour and 24-hour format, touch the 12/24 hour switch icon.
12/24 hour switch icon
6. When the date and time settings are the way you want, touch “OK”.
7. Touch “Auto” or “Premium Auto Pro” to select the default auto
recording mode you want.
8. Touch “Apply”.
• You will be able to change this setting later, if you want. See page 31 for details.
If you make a mistake configuring display language, date, or time settings with the above procedure, refer to the following pages for information about how to correct the settings.
– Display language: Page 107 – Date and time: Page 106
NOTE
• Each country controls its local time offset and the use of summer time, and so they are subject to change.
26
Quick Start Basics

Preparing a Memory Card

Though the camera has built-in memory that can be used to store images and movies, you probably will want to purchase a commercially available memory card for greater capacity. The camera does not come with a memory card. Images recorded while a memory card is loaded are saved to the memory card. When no memory card is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 131.

Supported Memory Cards

– microSD Memory Card – microSDHC Memory Card – microSDXC Memory Card
• The above are supported memory card types as of April 2013.
• This camera supports use of microSD memory cards of the following types and capacities: microSD memory cards up to 2GB, microSDHC memory cards from 2GB up to 32GB, microSDXC memory cards from 32GB up to 2TB. Note that the ability to use any particular card with this camera, even if it satisfies the above capacity and type requirements, is not guaranteed.
Warning!
*
0 Memory cards are small and present a risk of accidentally being swallowed
by infants and young children. Keep memory cards out of the reach of infants and young children. If a memory card is ever swallowed accidentally, contact a physician immediately.
+
27
Quick Start Basics

To load a memory card

1. Press [p] (Power) to turn off the
camera and then open the frame (page 14).
2. Hook your nail into the groove of
the [CARD HDMI] cover and pull the cover in the direction indicated by the arrow to open it.
3. Load a memory card.
Positioning the memory card so its back is facing upwards (towards the monitor screen side of the camera), slide it into the card slot all the way in until you hear it click securely into place.
4. Close the [CARD HDMI] cover and
then return the frame to its original position.
[CARD HDMI] cover
Back
Front Back
IMPORTANT!
• Never insert anything besides a supported memory card (page 27) into the memory card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off the camera, and contact your retailer or nearest CASIO authorized service center.
28
Quick Start Basics
. To replace the memory card
Press the memory card and then release it. This will cause it to pop out of the memory card slot slightly. Pull the card out the rest of the way and then insert another one.
• Never remove a card from the camera while the back lamp is flashing green. Doing so can cause the image save operation to fail and even damage the memory card.

To format (initialize) a new memory card

Format a memory card on the camera before using it for the first time.
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete its contents. Normally you do not need to format a memory card again. However, if storing to a card has slowed down or if you notice any other abnormality, re-format the card.
• Be sure to use the camera to format a memory card. Formatting a card on a computer will result in a non-SD standard format, which can greatly slow down processing time and cause compatibility, performance, and other problems.
1. Load a memory card (page 28).
2. Turn on the camera and then touch “MENU”.
• If “MENU” is not displayed on the screen, touch the tab to display it (page 38).
3. Drag upwards and downwards until you find “Setup”, and then touch it.
4. Touch “Format”.
5. Touch “Format” and then touch “Yes”.
This starts the memory card format operation.
29
Quick Start Basics

Turning Power On and Off

. To turn on the camera
Back lamp
Press [p] (Power). This will turn on the camera, which is indicated when the back lamp lights green, and enter the REC mode.
Entering the REC Mode and PLAY Mode
In the REC mode, touch “p” (PLAY).
• If Auto, BEST SHOT, or ART SHOT
To enter the PLAY mode
is selected as the recording mode, you can also switch to the PLAY
[p] (Power)
mode by touching the tab and then
To enter the REC mode
touching “p” (PLAY).
In the PLAY mode, touch the tab. On the screen image that appears, touch
r” (REC).
Screen after tab is
touched
. To turn off the camera
Press [p] (Power).
Tab
p” (PLAY) / “r” (REC)
NOTE
• To conserve battery power, an Auto Power Off function will turn off power automatically if you do not perform any operation for about five minutes.
30
Quick Start Basics

To Shoot a Snapshot

Your camera has a variety of different recording modes to suit various shooting conditions and objectives (page 39). This section explains general shooting procedures using the auto recording mode.

Selecting an Auto Recording Mode

You can select one of two auto recording modes (Auto or Premium Auto Pro) according to your digital imaging needs.
Setting
Auto This is the standard Auto recording mode.
Premium
Auto Pro
REC Screen Icon Display
Description
With Premium Auto Pro recording, the camera automatically determines whether you are shooting a subject or scenery, and other conditions. Premium Auto Pro recording delivers higher image quality than standard Auto recording.
• It also requires more power (and runs down the battery quicker) than Auto.
1. Press [p] (Power) to turn on the camera.
2. Touch the second icon from the top
(second icon from the right in the case of landscape display orientation) (Recording mode).
If the icon is not displayed on the screen, touch the tab to display it.
Recording mode icon
3. Touch “Auto” or “Premium Auto Pro” to
select the auto recording mode you want.
31
Quick Start Basics

To shoot a snapshot

1. Point the camera at the subject.
If you are using Premium Auto Pro, text will appear in the lower right corner of the monitor screen describing the type of shot the camera has detected.
• Touch the zoom icons to change the zoom factor (page 44).
(Telephoto) (Wide Angle)
+
2. Half-press the shutter button to focus
the image.
When focus is complete, the camera will beep, the back lamp will light green, and the focus frame will turn green.
Half-press
Press lightly until the button stops.
Beep, beep (Image is in focus.)
When you half-press the shutter button, the camera automatically adjusts exposure and focuses on the subject it is currently pointed at. Mastering how much pressure is required for a half-press and a full-press of the shutter button is an important technique for good-looking images.
Movie capacity (recording time)
Snapshot capacity
(number of shots)
Type of shot
Zoom icons
Shutter buttons
Back lamp
Focus frame
32
Quick Start Basics
3. Continuing to keep the camera still,
press the shutter button the rest of
Full-press
the way down.
This records the snapshot.
Snap (Image is recorded.)
Recording a Movie
Touch “b” (Movie) to start movie recording. Touch
c” (Movie Stop) to stop recording.
“ See page 47 for details.
b” (Movie)/
c” (Movie Stop)
NOTE
• You also can shoot a snapshot by touching a point on the monitor screen (page
59).
• You can specify the image size for snapshots. See page 61 for more information.
. If the image does not focus...
If the focus frame stays red and the back lamp is flashing green, it means that the image is not in focus (because the subject is too close, etc.). Re-point the camera at the subject and try to focus again.
. Shooting with Auto
“Focus lock” (page 67) is the name of a technique you can use when you want to shoot an image in which the subject to be focused on is not within the focus frame in the center of the screen.
33
Quick Start Basics
. Shooting with Premium Auto Pro
• In addition to shutter speed and ISO sensitivity, the camera automatically executes the following operation as required when shooting with Premium Auto Pro. – Auto Focus is normally performed until you half-press the shutter button. – The camera automatically determines the focus point on the screen and focuses
there.
– When shooting people, the face detection feature detects the faces of up to ten
individuals and adjusts focus and brightness accordingly.
• When shooting with Premium Auto Pro, the message “Processing Premium Auto.” may appear on the monitor screen. If you feel the camera is taking too long to process data, try shooting with standard Auto instead.
• In some cases, Premium Auto Pro may not be able to interpret the shooting environment correctly. If this happens, shoot with standard Auto.
• If “Š” is displayed, the camera will shoot a series of CS images and merge them into a final image. Take care to avoid any camera and subject movement until shooting of all of the CS images is complete.

Viewing Snapshots

Use the following procedure to view snapshots on the camera’s monitor screen.
• For information about how to play back movies, see page 69.
1. Touch “p” (PLAY) to enter the PLAY mode.
This will display one of the snapshots currently stored in memory.
• If “Premium Auto Pro” is selected as the recording mode, touch the Review image (page
67) in the lower left corner of the monitor screen.
• Information about the displayed snapshot also is included (page 10).
• You also can clear the information to view only the snapshot (page 11).
• You can zoom the screen image by touching the monitor screen (page 73). If you are recording a snapshot that is very important to you, it is recommended that you zoom the image and check its details after recording it.
p” (PLAY)
34
Quick Start Basics
2. Touch “ú” or “õ”, or drag left or right across the screen image to
scroll through the snapshots.
• To scroll at high speed, touch and hold “ú” or “õ”.
õ
õ
ú
NOTE
• Pressing the shutter button while in the PLAY mode or while a menu screen is displayed will switch directly to the REC mode.
• A question mark (?) will be displayed for images that cannot be displayed for some reason.
ú

Deleting Snapshots and Movies

If memory becomes full, you can delete snapshots and movies you no longer need in order to free up storage and record more images.
IMPORTANT!
• Remember that a file (image) delete operation cannot be undone.
. To delete a single file
1. In the PLAY mode, touch “ú” or “õ” to display the file you want to
delete.
2. Touch “t”.
•If “t” is not displayed on the screen, touch the tab
to display it.
3. Touch “1 File”.
This will delete the selected image.
35
Quick Start Basics
. To delete specific files
1. Enter the PLAY mode.
2. Touch “t”.
•If “t” is not displayed on the screen, touch the tab to display it.
3. Touch “Select”.
This displays a file selection screen.
4. Touch a file you want to delete.
This will select the check box of the selected file’s image.
5. After you are finished selecting files, touch “Delete”.
6. Touch “Delete”.
This deletes the files you selected.
• To cancel the delete operation, touch “Cancel” in step 6.
. To delete all files
1. Enter the PLAY mode.
2. Touch “t”.
•If “t” is not displayed on the screen, touch the tab to display it.
3. Touch “All Files”.
4. Touch “Delete”.
This will cause the message “There are no files.” to appear.

Snapshot Shooting Precautions

Operation
• If unwanted light is shining onto the lens, shade the lens with your hand when shooting an image.
Monitor Screen when Shooting Snapshots
• Subject brightness conditions can cause monitor screen response to slow and can cause digital noise in the monitor screen image.
• The image that appears on the monitor screen is for image composition. The actual image will be recorded in accordance with the currently selected recording mode (page 39).
36
Quick Start Basics
Shooting Indoors under Fluorescent Lighting
• Minute flickering of fluorescent lighting can affect the brightness or color of an image.
Other Precautions
• The slower the shutter speed, the greater the possibility that noticeable noise will be generated in an image. Because of this, the camera automatically performs a noise reduction at slow shutter speeds. The noise reduction process causes it to take longer to record images at lower shutter speeds. The shutter speeds for which noise reduction is performed depend on the camera setup and shooting conditions.
• A noise reduction process is performed when ISO sensitivity is set to a high value. This can cause the camera to take relatively longer to be ready to shoot again after you press the shutter button. Do not perform any operation while the image recording operation is in progress.
• Due to the characteristics of the imaging element used by the camera, very fast moving objects in an image may appear distorted.
. Auto Focus Restrictions
• Any of the following can make proper focus impossible. – Solid color wall or other very low contrast subject – Strongly back lit subject – Very shiny subject – Blinds or other subject with a repeating horizontal pattern – Multiple subjects at varying distances from the camera – Subject in a dark location – Camera movement while shooting – Fast-moving subject – Subjects outside the focus range of the camera
• If you cannot focus properly, try using focus lock (page 67).
37
Quick Start Basics

Recording Images

Touching the monitor screen in the REC mode will display a screen for configuring REC mode settings.
. To configure REC mode settings
1. Press [p] (Power) to turn on the
camera and enter the REC mode.
• If the camera is in the PLAY mode, touch
r” (REC) to enter the REC mode.
[p] (Power)
r” (REC)
2. Touch the item whose setting you want to change.
• If there are no icons along the left side of the screen, touch the tab to display them.
Tab (page 30)
1
Menu (page 58)*
2
Recording mode (page 39)
3
Remote capture (page 86)
4
Information (page 11)
5
PLAY mode/Make-up Level
6
(pages 30, 42) Zoom (page 44)
7
Quick send (page 88)
8
Movie (page 47)
9
* Depending on the recording mode, some of the items on the menu that
appears may not be usable.
1
2 3 4 5 6
7
8
9
38
Recording Images

Selecting a Recording Mode

The camera has a variety of different recording modes.
1. In the REC mode, touch the recording
mode icon (page 31).
• If the icon is not displayed on the screen, touch the tab to display it.
2. Touch the icon of the recording mode you
want to use.
This enters the selected recording mode.
Auto
Premium Auto
Pro
BEST SHOT
ART SHOT
Make-up
Motion Shutter
Standard Auto recording mode. This is the mode normally used for shooting (page 31).
With Premium Auto Pro recording, the camera automatically determines whether you are shooting a subject or scenery, and other conditions. Premium Auto Pro recording delivers higher image quality than standard Auto recording mode (page 31).
With BEST SHOT, simply select the sample scene that resembles the type of shot you want, and the camera automatically configures ideal settings for the subject and shooting conditions (page 50).
A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting (page
40).
Make-up smoothes the skin texture of the subject and softens facial shadows caused by harsh sunlight for better looking portraits (page 42).
In this mode, the camera starts a self-timer countdown when it detects subject movement (page 43).
Recording mode icon
39
Recording Images

Shooting with Artistic Effects (ART SHOT)

A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting.
Scene Description
HDR Art
Sparkling Shot
Toy Camera
Soft Focus Blurs overall focus for a mysteriously soft effect.
Light Tone Weakens contrast to create an elegantly subdued effect.
Pop Strengthens saturation for richer colors.
Sepia Sepia colors are used to create a retro effect.
Monochrome Enhances contrast to create a grainy print effect.
Miniature
Fisheye
Applies HDR (High Dynamic Range, page 52) photography to transform snapshots into works of art that provide a greater degree of expression than conventional imaging.
Softens the overall image and adds points of light for a sparkle effect.
Darkens the periphery and changes hues for a toy camera effect.
Blurs some of the focus to make the image look like a miniature.
Humorous effect that looks like it was shot with a fisheye lens.
1. In the REC mode, touch the recording mode icon (page 38).
2. Touch “C” (ART SHOT).
3. Touch the ART SHOT scene you want to use.
Select from among : HDR Art, Sparkling Shot, Toy Camera, Soft Focus, Light
Tone, Pop, Sepia, Monochrome, Miniature, Fisheye.
• Touch the arrow on the right side of the monitor screen to display another scene.
• Touching “ ” in the upper right corner of the screen and then touching a ART SHOT scene will display detailed information about the scene.
40
Recording Images
4. Touch the “ART” icon.
The intensity of the selected effect can be adjusted as described below. Note, however, that the “Miniature” effect cannot be adjusted.
Scene Adjustment
HDR Art Effect level
Sparkling Shot Effect type
Toy Camera Hue
Soft Focus Effect level
Light Tone Hue
Pop Effect level
Sepia Effect level
Monochrome Effect level
Fisheye Effect level
5. Touch the level you want to select.
6. Touch “OK”.
7. Press the shutter button to shoot.
NOTE
• This function works best when the camera is made stationary by placing it on a level surface, etc.
• With the HDR Art scene, the settings below are configured automatically. – LED light: Off
• Shooting with this REC mode makes the shooting range narrower than normal.
• The desired effect may not be attained if the camera or subject moves during shooting.
• Depending on shooting conditions and image composition, this REC mode may not be able to produce the desired result.
41
Recording Images

Recording Beautiful Portraits (Make-up)

Make-up smoothes the skin texture of the subject and softens facial shadows caused by harsh sunlight for better looking portraits.
1. In the REC mode, touch the recording mode icon (page 31).
2. Touch “½” (Make-up).
3. Touch the tab.
4. Touch “ ” (Make-up Level).
5. Touch the mode and level you want to select.
Brightening
Natural
Make-up Level
Lightens the skin tone of the subject.
Produces a beautifully natural looking skin tone.
You can select a make-up level effect intensity within the range of 0 (Off) to +12 (Strongest).
6. Touch “OK”.
7. Press the shutter button to shoot.
NOTE
• Note that Make-up can be used even when the recording mode is Premium Auto Pro or Motion Shutter. In either of these recording modes, perform steps 3 through 7 of the above procedure to select the Make-up mode and level you want.
42
Recording Images

Using Motion Shutter to Trigger a Self-timer Operation (Motion Shutter)

With Motion Shutter the camera automatically triggers a self-timer countdown whenever it detects subject movement within an icon you specify on the monitor screen. This means you can control operation of the self-timer from a distance by waving your hand, so you can include yourself in the image being shot.
1. In the REC mode, touch the recording mode
icon (page 39).
2. Touch “l” (Motion Shutter).
3. Drag the start self-timer icon “ ” and preview icon “ ” to the
location in the image where you want movement to be detected.
• Keep the two icons separate from each other. Whenever you move an icon to a location where it overlaps the other icon, the other icon will move out of the way automatically.
4. When everything is ready, press the shutter button all the way down.
The start self-timer icon will change to “ ” to indicate that the camera is in standby for shooting.
5. Facing the camera, move your hand or perform some other movement
in the area of the start self-timer icon you positioned in step 3.
When the camera detects subject movement within the icon, it will automatically start a self-timer countdown. The camera will shoot an image when the countdown reaches zero, and then go back into Motion Shutter standby to wait for the next trigger movement.
NOTE
• The trigger time of the Motion Shutter self-timer is fixed at two seconds.
• The preview icon “ ” will appear on the monitor screen when a snapshot is shot. When the camera detects movement within the preview icon, it will display the image that was shot for three seconds.
• Motion Shutter exits standby automatically after it shoots six images.
• To cancel Motion Shutter standby at any time, press the shutter button or touch the monitor screen.
• Motion Shutter may not operate properly when there is little difference in the color of the subject and the color of the background enclosed by the boundary, or when the subject is located far away from the camera, making it too small.
43
Recording Images

Shooting with Zoom

Your camera is equipped with various types of zoom: HD Zoom, SR Zoom, and digital zoom. The maximum zoom factor depends on the image size setting.
HD Zoom
SR Zoom
Digital zoom
Allows greater zoom capabilities by cutting out a portion of the original image and enlarging it, without deterioration of image quality.
Applies super resolution technology to suppress image deterioration.
A digital process is used to enlarge the center of the image, so there is deterioration of image quality.
1. In the REC mode, touch the zoom icons to
Zoom icons
zoom.
+ (Telephoto) – (Wide Angle)
+ (Telephoto) : Enlarges the subject and narrows the range. – (Wide Angle) : Reduces the size of the subject and broadens the range.
2. Press the shutter button to shoot the image.
NOTE
• Telephoto images are prone to blurring caused by camera movement when you press the shutter button. Because of this, stabilizing the camera by placing it on a level surface, etc. is recommended.
• Zoom operations are disabled during high speed movie recording. Perform the zoom operation before you touch “
• Zoom operations are not supporting during Slide Panorama shooting. The zoom setting is fixed at full wide angle.
•“Ù” is displayed on the monitor screen while digital zoom is being used.
b” (Movie) to start recording.
44
Recording Images
. Zoom Factor
• The image deterioration point depends on the image size (page 61) and recording mode (page 39). The smaller the image size, the higher the zoom factor you can use before reaching the image deterioration point.
Auto, Premium Auto Pro, Motion Shutter
Image Size
12M
3:2
Undeteriorated
Zoom Limit
1.5X 4.0X
Maximum
Zoom Factor
5M 2.3X 6.2X
VGA 9.4X 15.9X
BEST SHOT (Multi SR Zoom)
Image Size
12M
3:2
Undeteriorated
Zoom Limit
2.0X 4.0X
Maximum
Zoom Factor
5M 3.1X 6.2X
VGA 12.5X 15.9X
ART SHOT, BEST SHOT (excluding “Multi SR Zoom”)
Image Size
12M
3:2
Undeteriorated
Zoom Limit
1.0X 4.0X
Maximum
Zoom Factor
5M 1.6X 6.2X
VGA 6.2X 15.9X
45
Recording Images

Shooting a Self-portrait

You can configure the camera so the monitor screen and lens are facing in the same direction. This means you can shoot with the self-timer as you compose the self-portrait on the monitor screen.
• When using the self-timer to shoot a self-portrait, select one of the following recording modes. –Auto – Premium Auto Pro – Make-up
1. Rotate the monitor screen panel so the screen is
facing in the same direction as the lens (page 14).
2. Select “Auto”, “Premium Auto Pro” or “Make-up” for the recording
mode (pages 31, 42).
3. Drag “r” (Self-timer) downwards to specify the
self-timer countdown duration.
The camera will shoot an image when the countdown reaches zero.
• You can set a self-timer countdown duration within the range of two to ten seconds. The further you drag, the longer the duration.
• To cancel an ongoing countdown, touch anywhere on the screen except where the self-timer icon is displayed.
• Pressing the shutter button during an ongoing countdown will cancel the countdown and shoot an image.
r” (Self-timer)
46
Recording Images

To record a movie

The following procedure explains how to record a movie.
• You can record a movie while one of the following recording modes is selected. –Auto – Premium Auto Pro – BEST SHOT (HS Night Scene) – Make-up
“MENU”
1. In the REC mode, touch “MENU”.
• If “MENU” is not displayed on the screen, touch the tab to display it.
2. Drag upwards and downwards until you find “Movie Quality”, and then
touch to select it.
3. Touch the item whose setting you want to change.
Movie Quality
Full HD 30fps 1920
HD 30fps 1280
HS240 240fps 512
REC Screen Icon Display
Frame Rate
Image Size (Pixels)
x
1080
x
720
x
384
Description
Select this setting to record full high-definition (Full HD) movies. The aspect ratio of movies recorded with this setting is 16:9.
Select this setting to record high-definition (HD) movies. The aspect ratio of movies recorded with this setting is 16:9.
Select this setting to record high speed movies at a speed of 240 fps.
• Audio is not recorded.
4. To close the menu screen, touch “MENU” or press the shutter button.
47
Recording Images
5. Touch “b” (Movie).
This will start recording.
• Monaural audio is also recorded during movie recording while “Full HD” or “HD” is selected for the movie quality setting.
• Touching “o” while recording is in progress will cause the remaining recording time and “R” to appear. Touch “o” again to switch back to the elapsed recording time.
• When “Full HD” or “HD” is selected as the movie quality, you can perform a zoom operation while recording is in progress by touching the zoom icons.
• When “Macro” is selected as the movie focus mode (page 66), you can half­press the shutter button before starting recording to focus.
Remaining recording time
Recording time/
b” (Movie)/
c” (Movie Stop)
6. Touch “c” (Movie Stop) to stop recording.
• Each movie can be up to 29 minutes long. Movie recording stops automatically after 29 minutes of recording. Movie recording also will stop automatically if memory becomes full before you stop movie recording.
Minimizing the Effects of Camera Movement during Movie Recording
You can configure the camera to minimize the effects of camera movement during Full HD and HD movie recording. Note, however, that this does not prevent image blur due to subject movement.
High Speed Movie Recording Precautions
• When shooting a high speed movie, shoot in a well-lit environment.
• When recording a high speed movie, light source flicker can cause horizontal bands to appear in the image. This does not indicate malfunction of the camera.
48
Recording Images
IMPORTANT!
• Spending a long time using movie recording will cause the camera to become slightly warm to the touch. This is normal and does not indicate malfunction. The camera may automatically adjust its monitor screen brightness in order to reduce heat generation.
• The camera also records audio along with Full HD and HD movies. Note the following points when shooting a movie. – Take care that the microphone is not blocked by your
fingers, etc.
– Good audio recording results are not possible when the
camera is too far away from what you are trying to record.
Microphone
• Shooting movies for long periods in areas where temperature is relatively high can cause digital noise (dots of light) to appear in the movie image. A rise in the camera’s internal temperature also may force movie recording to stop automatically. If this happens, stop recording and allow the camera to cool down, which should cause normal operation to resume.
• Using the camera’s built-in memory or certain types of memory cards can slow down processing speed. Whenever possible use an Ultra High-Speed Type memory card. Note, however, that not all operations can be guaranteed even if an Ultra High-Speed Type memory card is used. Certain movie quality settings can result in too much time being required to record data, which can result in breaks in the image and/or audio during playback. If this happens, the movie icon will turn yellow on the monitor screen.
NOTE
• Except for High Speed Movie, zoom operations are supported during movie recording (page 44). Zoom is disabled during high speed movie recording. If you
b
want to use zoom, perform the zoom operation before you touch “
” (Movie) to
start recording.
• SR Zoom (page 44) is disabled during movie recording.
• The effects of camera movement in an image become more pronounced when you shoot close up or with a large zoom factor. Because of this, stabilizing the camera by placing it on a level surface, etc. is recommended.
• During High Speed Movie recording, focus is fixed at the position where it was when recording started. To focus an image, half-press the shutter button for Auto
b
Focus before you touch “
” (Movie) to start recording.
49
Recording Images

Using BEST SHOT

BEST SHOT provides you with a collection of sample “scenes” that show a variety of different types of shooting conditions. When you need to change the setup of the camera, simply find the scene that matches what you are trying to achieve, and the camera sets up for it automatically. This helps to minimize the chance of ruined images due to poor exposure and shutter speed settings.
. To shoot an image with BEST SHOT
1. In the REC mode, touch the recording mode
icon (page 31).
• If the icon is not displayed on the screen, touch the tab to display it.
2. Touch “b” (BEST SHOT).
This will display a menu of BEST SHOT scenes.
3. Touch the scene you want to select.
• Touching “ ” in the upper right corner of the screen and then touching a BEST SHOT scene will display detailed information about the scene.
4. Press the shutter button (if you are shooting a snapshot) or touch
b” (Movie) (if you are shooting a movie).
. BEST SHOT Precautions
• BEST SHOT scene images were not shot using this camera.
• Images shot using a BEST SHOT scene may not produce the results you expected due to shooting conditions and other factors.
• You can modify the camera settings that are configured after you select a BEST SHOT scene. Note, however, that the BEST SHOT settings revert to their defaults when you select another BEST SHOT scene or turn off the camera.
• Movie recording is supported only while “HS Night Scene” is selected. Selecting “HS240” for the movie quality setting while the “HS Night Scene” BEST SHOT scene is selected will cause the camera to record movies using the auto recording mode.
50
Using BEST SHOT

Shooting Clearer Snapshots (Multi SR Zoom)

Multi SR Zoom uses super-resolution technology and multiple Continuous Shutter (CS) images for higher quality and clarity across the entire image. For information about the zoom factor, see page 45.
• When shooting with Multi SR Zoom, the camera may require more time for image data processing between shots.
1. In the REC mode, touch “b” (BEST SHOT).
2. Touch “Multi SR Zoom” scene.
3. Press the shutter button to shoot.
NOTE
• Multi SR Zoom is effective when you want to capture delicate textures.
• With this BEST SHOT scene, the LED light setting automatically becomes off.
• Shooting with this BEST SHOT scene makes the shooting range narrower than normal.
• The desired Multi SR Zoom effect may not be attained if the camera or subject moves during shooting.
• Depending on shooting conditions and image composition, this BEST SHOT scene may not be able to produce the desired result.
51
Using BEST SHOT

Digitally Correcting for Overexposure and Underexposure (HDR)

With HDR (High Dynamic Range), the camera shoots a series of CS images using different exposure settings and combines them into a final image to correct for overexposure or underexposure of subjects of different brightness levels.
1. In the REC mode, touch “b” (BEST SHOT).
2. Touch “HDR” scene.
3. Press the shutter button to shoot.
NOTE
• This function works best when the camera is made stationary by placing it on a level surface, etc.
• With this BEST SHOT scene, the LED light setting automatically becomes off.
• Shooting with this BEST SHOT scene makes the shooting range narrower than normal.
• The desired HDR effect may not be attained if the camera or subject moves during shooting.
• Depending on shooting conditions and image composition, this BEST SHOT scene may not be able to produce the desired result.
52
Using BEST SHOT

Shooting with High Speed Night Scene (HS Night Scene)

With High Speed Night Scene, the camera automatically detects shooting conditions. When you press the shutter button, the camera will record a burst of images and merge them in a way that minimizes image blur due to low light conditions.
1. In the REC mode, touch “b” (BEST SHOT).
2. Touch “HS Night Scene” scene.
3. When you are ready to shoot, press the shutter button.
NOTE
• With this BEST SHOT scene, the LED light setting automatically becomes off.
• When holding the camera by hand while shooting with this BEST SHOT scene, make sure that the subjects remain as still as possible as the camera shoots the series of images.
• Shooting with this BEST SHOT scene makes the shooting range narrower than normal.
• Movement of the camera while it is placed on a surface may cause erroneous judgment that it is hand held.
• If surroundings are extremely dark when shooting with “HS Night Scene”, the camera may not be able to shoot at proper brightness due to insufficient exposure.
• When shooting with this BEST SHOT scene, the ISO sensitivity setting is fixed at “AUTO”.
53
Using BEST SHOT

Shooting with High Speed Anti Shake (HS Anti Shake)

A single press of the shutter button causes the camera to record multiple images and automatically combine them, which reduces image blur due to camera movement.
1. In the REC mode, touch “b” (BEST SHOT).
2. Touch “HS Anti Shake” scene.
3. When you are ready to shoot, press the shutter button.
NOTE
• With this BEST SHOT scene, the LED light setting automatically becomes off.
• Shooting with this BEST SHOT scene makes the shooting range narrower than normal.
• High Speed Anti Shake may not operate properly resulting in blurred images if the camera is moved more than the allowable range or if the subject moves during shooting.
• When shooting with this BEST SHOT scene, the ISO sensitivity setting is fixed at “AUTO”.

Shooting with Priority on Subject Faces (HS Best Selection)

With High Speed Best Selection, the camera automatically shoots a series of images, and selects the best one based on facial image blur, and facial expression (whether the subject is smiling or blinking).
1. In the REC mode, touch “b” (BEST SHOT).
2. Touch “HS Best Selection” scene.
3. Press the shutter button to shoot.
• This will cause the message “Busy... Please wait...” to appear. Do not move the camera while this message is displayed. The recording process takes some time to complete after the message appears.
54
Using BEST SHOT
NOTE
• With this BEST SHOT scene, the LED light setting automatically becomes off.
• Shooting with this BEST SHOT scene makes the shooting range narrower than normal.
• If one or more of the faces are blurred in all of the images that are shot, they will be blurred in the final image as well.
• The following conditions may make it impossible for the camera to determine if the subject is blinking or smiling. This may result in a final image in which the subject is blinking or not smiling. – Faces that are partially or completely darkened by shadows, etc. – Hair that is hiding or near the eyes – Eye glasses – Small faces – Faces that are not looking directly at the camera
• Shooting a large group of people will cause processing of the image after shooting to take longer.

Shooting a Panorama Image (Slide Panorama)

With Slide Panorama, you move the camera to compose and record multiple images, which are then combined to a panorama. This feature lets you shoot a panorama which is dramatically greater than the physical capabilities of the lens.
• The final panorama image can be one of the two sizes shown below.
x
Slide Direction is Right or Left: Maximum 11520 Slide Direction is Up or Down: Maximum 1920
1080 pixels
x
7296 pixels
• Zoom operations are not supporting during Slide Panorama shooting. The zoom setting is fixed at full wide angle.
• You can shoot a panorama image for approximately 360 degrees horizontally, or approximately 180 degrees vertically.
55
Using BEST SHOT
1. In the REC mode, touch “b” (BEST SHOT).
2. Touch “s” (Slide Panorama) scene.
3. Touch the icon for the slide direction (the
direction the camera will move while shooting).
You can select one of four different slide directions: “ ” (right), “ ” (left), “ ” (up), “ ” (down).
4. Point the camera at the start of the panorama
and half-press the shutter button to allow the camera to focus automatically.
5. Press the shutter button the rest of the way
down and a slide cursor will appear on the monitor screen. Slowly move the camera in the direction indicated by the arrow on the screen until the slide cursor reaches the other end of its movement range (i.e. all the way to the right when moving the camera to the right).
• The camera will start composing the panorama image internally when the slide cursor reached the other end of the movement range.
• Image composing also will start automatically if you stop moving the camera during panorama shooting. After you stop moving the camera, the message “Busy... Please wait...” appears as the camera processes the image. Wait until this message disappears before using the camera. Image shooting is disabled while the message is displayed.
Slide cursor
56
Using BEST SHOT
NOTE
• The following conditions are not compatible with Slide Panorama shooting. – Subject whose brightness is very different from that of its surroundings due to
artificial light, sunlight, etc. – Rivers, waves, waterfalls, or other subject with constantly changing patterns – Sky, beach, or other subject with continuous patterns – Camera too close to the main subject – Moving subject – Dark surroundings
• Slide Panorama may stop part way through in the following cases. – Subject or camera movement – Camera movement that is too fast or too slow
• Shooting a Slide Panorama image after half-pressing the shutter button to perform Auto Focus may not produce the desired results if there are considerable differences in the brightness, color, and/or focus of the individual images. If this happens, try changing the focus position by focusing on a different subject, etc.
• Since a Slide Panorama image is created by joining multiple images together, there may be some roughness at the point where two images are joined.
• Shooting under a flickering light source (such as fluorescent lighting) may result in uneven brightness and/or coloring in the final Slide Panorama image.
• The exposure and white balance when shooting Slide Panorama images are fixed at the levels measured when you half-press the shutter button at the beginning of the operation.
• With this BEST SHOT scene, the LED light setting automatically becomes off.
57
Using BEST SHOT

Advanced Recording Settings

The following are menu operations you can use to configure various camera settings.

Using the REC Menu

. Example Menu Screen Operation
1. In the REC mode, touch “MENU”.
This will display the menu screen.
• If “MENU” is not displayed on the screen, touch the tab to display it.
• Menu contents are different in the REC mode and PLAY mode.
2. Drag upwards and downwards until you find the item whose setting
you want to change.
3. Touch the item.
4. Configure the setting of the item in accordance with the screen
contents.
• To cancel and exit the menu, touch “MENU” or press the shutter button.
NOTE
• Some menu items may not be available, depending on the recording mode being use.
. Menu Operations in This Manual
Menu operations are represented in this manual as shown below. Touch the indicated icons and items, and perform operations as they are indicated, from left to right.
Procedure
Enter the “REC Mode” * MENU * Touch Shutter
58
Advanced Recording Settings

Using Touch Shutter (Touch Shutter)

Procedure
Enter the “REC Mode” * MENU * Touch Shutter
You can use the procedure below to shoot a snapshot.
1. Touch “On”.
2. Point the camera at the subject.
3. When you want to shoot, touch the monitor screen.
The camera automatically comes into focus and then shoots.
• You can still use the shutter button to shoot even when “On” is selected for Touch Shutter.
NOTE
• When “Auto” is selected as the recording mode, the camera will automatically focus on the point you touch.
• When “Premium Auto Pro” is selected as the recording mode, the camera will automatically determine the optimum focus point(s) and focus automatically.

Using the Self-timer (Self-timer)

Procedure
Enter the “REC Mode” * MENU * Self-timer
With the Self-timer, pressing the shutter button starts a timer. The shutter is released and the image is shot after a fixed amount of time.
Setting
REC Screen Icon Display
Description
10 sec 10-second Self-timer
2-second Self-timer
2 sec
Off None Self-timer is disabled.
• You can interrupt an ongoing Self-timer countdown by pressing the shutter button.
• When shooting under conditions that slow down the shutter speed, you can use this setting to prevent image blur due to camera movement.
59
Advanced Recording Settings
NOTE
• The Self-timer configured with the above menu cannot be used under the following conditions. – Slide Panorama (page 55) – Motion Shutter (page 43) – When the monitor screen and lens are facing in the same direction

Using the LED Light (LED)

Procedure
Enter the “REC Mode” * MENU * LED
Use the LED light when shooting where lighting is dim. The effectiveness of the LED light is reduced the further you are from the subject.
Setting
Auto
On LED always lights when shooting.
Off None LED never lights.
IMPORTANT!
• Do not turn on the LED light near a person’s eyes and do not allow anyone to look directly into the light.
• You should compose the image so the main subject is in the center of the image when using the LED light.
• Since the camera is equipped with a wide-angle lens, the center tends to be brighter while the periphery tends to be darker.
REC Screen Icon Display
Description
The LED lights automatically under dark shooting conditions when the shutter button is half-pressed to focus or full-pressed to shoot.
60
Advanced Recording Settings

Changing the Image Size (Image Size)

Procedure
Enter the “REC Mode” * MENU * Image Size
This setting can be used to configure snapshot image size.
Image Size (Pixels)
12M
x
(4000
3000)
3:2
x
2656)
(4000
REC Screen Icon Display
Suggested Print Size and Application
Poster Print
Poster Print
Description
Good detail for better clarity even for images cropped from the original on a computer, etc.
5M (2560
x
1920)
A4 Print Good detail
Image files are smaller, which is VGA (640
x
480)
E-Mail
better when attaching images to e-
mail. However, images are
relatively coarser.
• The initial factory default image size setting is 12M (12 million pixels).
• Selecting “3:2” records images with an aspect ratio of 3:2, which matches the standard aspect ratio of print paper.
• You should regard the print paper sizes suggested here as guidelines only (200 dpi print resolution).
61
Advanced Recording Settings
. Pixels and image size
A digital camera image is a collection of small dots called “pixels”. The more pixels there are in an image, the more detail there will be. However, you generally can do with fewer pixels when printing an image (L size) through a print service, attaching an image to e-mail, when viewing the image on a computer, etc. The size of an image indicates how many pixels it contains, and is expressed as horizontal pixels
Pixel
x
vertical pixels.
Example:
Image size pixels
x
12M 4000
5M 2560
3000 (Approximately 12 million pixels)
x
1920 (Approximately 5 million pixels)
• Note that larger images have more pixels, so they take up more memory space.
• For information about image size and number of images that can be stored, see page 131.
• For information about movie image size, see page 47.
• For information about resizing existing snapshots, see page 82.

Movie Image Quality Settings (Movie Quality)

Procedure
Enter the “REC Mode” * MENU * Movie Quality
This setting can be used to configure movie image quality settings and to select either normal movie recording or High Speed Movie recording. For information about movie image quality settings, see page 47.
62
Advanced Recording Settings

Correcting Image Brightness (EV Shift)

Procedure
Enter the “REC Mode” * MENU * EV Shift
You can manually adjust an image’s exposure value (EV value) before shooting it.
• Exposure Compensation Range: –2.0 EV to +2.0 EV
• Unit: 1/3 EV
1. Touch a level you want to set.
• To cancel exposure compensation, change the EV value to 0.0.
–2.0 +2.0
Decreases the EV value. A lower EV value is best for dark-color subjects and for shooting outdoors on a clear day.
Increases the EV value. A higher EV value is best for light-colored subjects and backlit subjects.
2. Touch “OK”.
This applies the exposure compensation value. The exposure compensation value you set remains in effect until you change it or turn off the camera (which causes it to revert to “0.0”).
NOTE
• When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even after performing exposure compensation.
63
Advanced Recording Settings

Adjusting White Balance (White Balance)

Procedure
Enter the “REC Mode” * MENU * White Balance
You can adjust white balance to match the source of light available where you are shooting and avoid the blue cast that results when shooting outdoors when it is cloudy, and the green cast that results when shooting under fluorescent lighting.
1. Touch the type of white balance you want to select.
You can see the affect of the white balance setting you select on the monitor screen.
Setting Description
Auto WB
Daylight For shooting outdoors on a clear day
Overcast
Shade
Day White Fluor
Daylight Fluor For shooting under daylight fluorescent lighting
Tungsten For shooting under light bulb lighting
Manual WB
• When “ Auto WB” is selected for the white balance setting, the camera
automatically determines the white point of the subject. Certain subject colors and light source conditions can cause problems when the camera tries to determine the white point, which makes proper white balance adjustment impossible. If this happens, select the white balance setting that matches your shooting conditions (Daylight, Overcast, etc.).
Configures the camera to adjust white balance automatically
For shooting outdoors on an overcast rainy day, in the shade, etc.
For shooting on a clear day in the shade of trees or buildings
For shooting under white or day white fluorescent lighting
For configuring the camera manually to suit a particular light source.
Touch “· Manual WB”.
1
In the location where you plan to
2
shoot, point the camera at a blank white piece of paper so it fills the entire monitor screen. Touch an area of the screen
3
where no icon is located. The white balance setting is retained even if you turn off the camera.
Blank white paper
2. Touch “OK”.
64
Advanced Recording Settings

Specifying ISO Sensitivity (ISO)

Procedure
Enter the “REC Mode” * MENU * ISO
ISO sensitivity is a measure of sensitivity to light.
Setting Description
AUTO Adjusts sensitivity automatically according to conditions
ISO 100
Lower
sensitivity
ISO 200
ISO 400
ISO 800
ISO 1600
ISO 3200
Higher
sensitivity
• Since higher ISO sensitivity values tend to result in digital noise in images, the camera performs a noise filtering process. Because of this, it may take relatively longer for the camera to finish recording an image after it is shot. You will not be able to perform any operation while image recording is in progress.
Slow shutter speed
Fast shutter speed (Set
for shooting in dimly lit
areas.)
Less noise
Some coarseness
(increased digital noise)
65
Advanced Recording Settings

Selecting a Focus Mode (Focus)

Procedure
Enter the “REC Mode” * MENU * Focus
Changing to a different focus mode can help to achieve better focus.
Settings
AF (Auto Focus)
Macro
REC Screen Icon Display
None
Type of Shot
General recording
Close ups
Shooting
PF (Pan Focus)
with a relatively wide focus range
Infinity Focus
Scenery and other distant subjects
*1 The focus range is the distance from the lens surface. *2 The distance depends on shooting conditions.
Focus Mode Approximate Focus Range
Snapshot Movies Snapshot Movies
8 cm to
9
(infinity)
to
9
Automatic
(3.1"
)
8 cm to 50 cm (3.1" to 19.7")
Fixed
focal point
Fixed
focal point
Fixed focal
2
*
point
Fixed Infinity (Wide Angle)
*
46 cm to
9
(infinity)
to
9
(18.1"
)
17 cm to 27 cm (6.7" to 10.6")
46 cm to
9
(infinity)
to
9
(18.1"
)
1
66
Advanced Recording Settings
Using Focus Lock
“Focus lock” is a technique you can use when you want to compose an image in which the subject you want to focus on is not within the focus frame in the center of the screen.
Subject to be focused on
1. Align the monitor screen’s focus frame with
the subject you want to focus on and then half-press the shutter button.
Focus frame
2. Keeping the shutter button half-pressed
(which maintains the focus setting), move the camera to compose the image.
3. When you are ready to shoot the image,
press the shutter button the rest of the way down.
NOTE
• Focus lock also locks exposure (AE).
• The focus frame does not appear on the display when the Touch Shutter is enabled (On).

Turning on Image Review (Review)

Procedure
Enter the “REC Mode” * MENU * Review
While Review is turned on, the camera will display an image immediately after it is recorded.
Type 1 Displays a full-screen view of the image for about one second.
Type 2
Off Turns off review image display
Displays a Review image in the lower left corner of the monitor screen. Touching the Review image will enter the PLAY mode and display a full-screen view of the image.
• When “Type 1” is selected, the aperture, shutter speed, and ISO sensitivity, will be orange if the Auto Exposure is not correct.
67
Advanced Recording Settings

Checking a Snapshot before Saving It (Self-portrait check)

Procedure
Enter the “REC Mode” * MENU * Self-portrait check
Pressing the shutter button on the frame to shoot a self-portrait while this function is enabled (“On”), will display an image for review before it is saved. When this function is disabled (“Off”), self-portrait images are stored directly into memory as soon as you shoot them. The self-portrait check function can be used under the conditions described below.
Recording mode : Auto, Premium Auto Pro, Make-up Monitor screen : Pointed in the same direction as the lens.
Shutter button
1. Touch “On”.
2. Press the shutter button on the frame to shoot the image.
3. Review the recorded image.
• When this function is enabled, you can perform the following image review and store operations after shooting a self-portrait.
Setting Description
Zooms the review image.
• Two-finger squeeze and spread screen operations can also be used to zoom the review image.
• An enlarged image can be scrolled by dragging on the screen.
Returns a zoomed image to its original size.
Returns to image recording standby without saving the currently displayed review image.
Saves the currently displayed review image and returns to image recording standby.
• Touching “ ” while a zoomed review image is displayed still saves the image in normal (not zoomed) size.
68
Advanced Recording Settings

Viewing Snapshots and Movies

Viewing Snapshots

See page 34 for the procedure for viewing snapshots.

Viewing a Movie

1. Touch “p” (PLAY) to enter the PLAY mode.
2. Touch “ú” or “õ”, or drag left or right
across the screen image to scroll through the movies until the one you want is displayed.
• To scroll at high speed, touch and hold “ú” or “õ”.
3. Touch “6” (Movie) to start playback.
Playback in progress Playback paused
Touch “|”.
Touch “6”.
Progress bar
Image quality
Movie icon: 6
Movie recording time
69
Viewing Snapshots and Movies
Movie Playback Controls
Pause/Play Touch “|” (pause) or “6” (play).
{” (fast reverse) or “}” (fast
6”.
Fast forward/ Fast reverse
During playback, touch “ forward).
• Each touch of either button increases the speed of the fast forward or fast reverse operation.
• To return to normal playback speed, touch “
Stop playback During playback, touch “.”.
Volume adjustment
During playback, touch “ to the desired level.
• Volume can be adjusted only while movie playback is in
n” and then drag the volume bar
progress.
1 frame forward/ back
Information display on/off
Movie editing
While playback is paused, touch “
• Touching and holding this icon advances frames continuously.
Touch the screen.
Pause movie play at the location where you want to cut, and then touch “
~” (page 71).
z” or “y”.
• Playback may not be possible for movies not recorded with this camera.
70
Viewing Snapshots and Movies

Editing a Movie on the Camera (Movie Editing)

The Movie Editing feature lets you cut out a specific part of a movie.
1. Enter the PLAY mode and then start playback of the movie you want to
edit.
2. When playback reaches the location where you want to cut, touch “|
to pause.
3. Touch “~”.
4. Touch the option that specifies what you want to cut.
Previous Cut
Next Cut
Cuts everything from the beginning of the movie up to the current location.
Cuts everything from the current location to the end of the movie.
5. Touch “Cut”.
The selected cut operation will take considerable time to complete. Don’t try to perform any camera operation until the “Busy... Please wait...” message disappears from the monitor screen. Note that a cut operation can take a long time if the movie being edited is long.
IMPORTANT!
• When you edit a movie, only the result is saved. The original movie is not retained. An editing operation cannot be undone.
NOTE
• A movie that is shorter than five seconds cannot be edited.
• Editing of movies recorded with a different type of camera is not supported.
• You will not be able to edit a movie if the amount of remaining memory capacity is less than the size of the movie file you want to edit. If there is not enough memory available, delete files you no longer need to free up more.
• Splitting of a movie into two movies and splicing of two different movies into a single movie are not supported.
71
Viewing Snapshots and Movies

Viewing a Panorama Image

1. Touch “p” (PLAY) to enter the PLAY mode.
2. Touch “ú” or “õ” or drag upwards or
downwards to display the panorama image you want to view.
• To scroll at high speed, touch and hold “ú” or “õ”.
3. Touch “6” to play the panorama.
Panorama playback causes the image to scroll left, right, up, or down.
Playback Controls
Pause/Play Touch “|” (pause) or “6” (play).
Stop playback During playback, touch “.”.
Scroll the panorama image While playback is paused, drag the screen.
Information display on/off Touch the screen.
NOTE
• The following functions cannot be performed on a panorama image. Movie Editing, Rotation
72
Viewing Snapshots and Movies

Viewing the Image Menu

The image menu shows multiple images on a single screen.
1. In the PLAY mode, touch “]”.
This displays the image menu.
• Touch “û” or “ü” or drag upwards or
downwards to scroll to the next page of images.
• To view the normal (single image) display mode, touch the image your want to view or touch “
• In the case of a movie, the first image in the movie is displayed.
• A question mark (?) will be displayed for images that cannot be displayed for some reason.
ë”.

Zooming an On-screen Image

Snapshots can be zoomed on the monitor screen up to 8X.
• The actual available zoom factors depend on the size of the original image.
1. In the PLAY mode, touch “ú” or “õ” or drag left or right to display the
image you want to view.
2. Spread your thumb and forefinger (page 18)
on the displayed image to enlarge it.
• Dragging an enlarged screen image will change the part of the image that is displayed.
• Squeezing your thumb and forefinger (page 18) on the displayed image will reduce it in size. – When monitor screen contents are turned on, a
graphic in the lower right corner of the screen shows what part of the zoomed image is currently displayed.
• Touching “ú” or “õ” while an enlarged image is displayed will scroll to the next sequential image while maintaining the current zoom factor.
• To return to normal (single image) display, touch “ë”.
73
Zoom factor
Image area
Current display area
Viewing Snapshots and Movies

Viewing Snapshots and Movies on a TV Screen

Use a commercially available HDMI cable to connect the camera to the TV.
• Use a commercially available HDMI cable that is marked with the logo shown to the right.
1. Open the frame (page 14).
[CARD HDMI] cover
2. Hook your nail into the groove of the
[CARD HDMI] cover and pull the cover in the direction indicated by the arrow to open it.
3. Turn off the camera and use a commercially available HDMI cable to
connect the camera to a TV.
HDMI connector
HDMI input
HDMI output (micro)
HDMI cable
HDMI micro connector
• Make sure that the camera is turned off before plugging in or unplugging the cable. Check the user documentation that comes with the TV for information about requirements before plugging into or unplugging from the TV.
(commercially available)
4. Turn on the TV and select its video input mode.
If the TV has more than one video input, select the one where the camera is connected.
74
Viewing Snapshots and Movies
5. Turn on the camera.
The camera monitor screen will shows a remote controller image. The TV screen will show a recorded image.
• The contents of the remote controller image will depend on the type of image that is displayed on the TV screen.
6. Touch the camera monitor screen to perform
operations.
NOTE
• Use a HDMI cable with a plug that is compatible with the camera’s HDMI micro connector on one end, and a plug that is compatible with your TV’s HDMI connector on the other end.
• Proper image and/or audio output and other operations may not be possible with some devices.
• Connecting the camera to the HDMI connector of another device can damage both the camera and the other device. Never connect two HDMI output connectors to each other.
• Disconnect the HDMI cable when you are not using HDMI output. The camera’s monitor screen may not operate normally while the HDMI cable is connected.
• Audio is monaural.
• Audio is initially output by the camera at maximum volume. When you first start displaying images, set the TV volume control at a relatively low level and then adjust it as required.
• To select the digital signal format, see page 107.
75
Viewing Snapshots and Movies

Other Playback Functions (PLAY)

The following are menu operations you can use to configure various camera settings.

Using the PLAY Menu

. Example Menu Screen Operation
1. In the PLAY mode, touch “MENU”.
This will display the menu screen.
• If “MENU” is not displayed on the screen, touch the tab to display it.
• Menu contents are different in the REC mode and PLAY mode.
2. Touch the item whose setting you want to change.
3. Configure the setting of the item in accordance with the screen
contents.
• To cancel and exit the menu, touch “MENU” or press the shutter button.
. Menu Operations in This Manual
Menu operations are represented in this manual as shown below. Touch the indicated icons and items, and perform operations as they are indicated, from left to right.
Procedure
Enter the PLAY Mode * MENU * Protect
76
Other Playback Functions (PLAY)

Performing Paint Operations on an Image (Paint)

Procedure
Enter the PLAY Mode * Display snapshot * MENU * Paint
You can use this function to draw on, write on, or stamp information into a recorded snapshot. If the original image size is 3M or larger, the post-paint image is saved as a 3M size image.
1. On the right side of the monitor screen,
touch “ ” or “ ”.
2. Touch the pen type or the stamp you want to
use.
3. Use the pen to write text or draw figures, or
use the stamp to stamp information.
4. Touch “OK”.
5. Touch “Yes”.
This will save the image as a new image.
. Paint Functions
Exits paint without saving an image.
For selecting the pen color and thickness for drawing or writing. Also can be used to select the eraser and its thickness.
For selecting the stamp type.
Goes back to the previous screen.
Saves the image.
NOTE
• After selecting “ ”, you can change either the color (or eraser) or thickness setting only. To change the other setting, select “ ” again.
77
Other Playback Functions (PLAY)

Playing a Slideshow on the Camera (Slideshow)

Procedure
Enter the PLAY Mode * MENU * Slideshow
You can use the slideshow mode to automatically scroll through all of the images in camera memory.
NOTE
• All operations are disabled while the slideshow is transitioning from one image to another.
• The time required for transition from one image to another may be longer in the case of an image that was not recorded with this camera.
• To return to normal (single image) display, touch the screen.

Extracting an Image from a Snapshot (Cut out subject)

Procedure
Enter the PLAY Mode * Display snapshot * MENU * Cut out subject
You can draw an outline around a subject (person or object) and extract it from the snapshot. You can then insert the extracted subject into another snapshot.
Extracted Subject Another Snapshot Final Combined Image
1. Touch the drawing tool you want and then draw a boundary around the
subject that you want to extract.
Drawing Tool Line Type Description
• The boundary line should be continuous, which means it starts and ends at the same point.
Thin
Thick
Erases a drawn line.
Draws a line for cutting out a subject.
78
Other Playback Functions (PLAY)
2. Touch “OK”.
This will cause the background of the subject you outlined to become gray.
3. Touch “” to select the area to be extracted and then touch “OK”.
This will display the cut out subject.
• To scroll back one screen, touch the “u” icon in the upper right corner of the display.
Extracted subject screen
Original image with subject
extracted
4. After confirming that the part of the image to be extracted is the way
you want, touch “OK”.
This saves the extracted image.
NOTE
• You cannot extract from an extracted subject. Attempting to do so will cause an error.
79
Other Playback Functions (PLAY)

Inserting a Subject into another Snapshot (Paste subject)

Procedure
Enter the PLAY Mode * MENU * Paste subject
You can insert the camera’s built-in subject or subjects you create with “Cut out subject” (page 78) into snapshots.
• Only an image that satisfies the following conditions can be used as a background image. – It must be a snapshot recorded with this camera or a snapshot transferred to this
camera’s memory.
– It must be an image with an aspect ratio of 4:3.
1. Touch “ú” or “õ” or drag left or right to scroll through images. Select
image you want to use as the background and then touch “OK”.
2. Touch “ú” or “õ” or drag left or right to scroll though subjects. Select
the subject you want to insert and then touch “OK”.
3. Touch “+” (zoom in) and “–” (zoom out) to
adjust the size of the subject. You also can drag the subject around the screen to reposition it.
4. After the subject’s size and position are the
way you want, touch “OK”.
This inserts the subject into the background image.
NOTE
• Performing a delete or format operation will not delete the built-in subjects.
80
Other Playback Functions (PLAY)

Protecting a File Against Deletion (Protect)

Procedure
Enter the PLAY Mode * MENU * Protect
You can protect images to prevent them from being deleted.
• A protected image will be indicated by “›”.
All Files On Protects all files.
All Files Off Unprotects all files.
Protects and unprotects specific files.
Touch “û” or “ü” or drag upwards or downwards to display
1
the image you want to protect. Touch an image to be protected,
2
and “›” will appears on the
Select
IMPORTANT!
• Note that even if a file is protected, it will be deleted if you perform the format operation (page 109).
image. You can repeat steps as many times as necessary to select multiple images. Touch “OK”.
3
To unprotect an image, touch it in step procedure to remove “›”.
and 2
1
of the above
2
81
Other Playback Functions (PLAY)

Rotating an Image (Rotation)

Procedure
Enter the PLAY Mode * MENU * Rotation
1. Touch “ú” or “õ” or drag upwards or downwards to display the image
you want to rotate.
2. Touch “Rotate”.
This will rotate the image 90 degrees to the left.
3. When the image is in the orientation you want, touch “ ”.
NOTE
• Rotation of a panorama image is not supported.
• Note that this procedure does not actually change the image data. It simply alters how the image is displayed on the camera’s monitor screen.
• An image that has been protected or zoomed cannot be rotated.

Resizing a Snapshot (Resize)

Procedure
Enter the PLAY Mode * MENU * Resize
You can reduce the size of a snapshot and save the result as a separate snapshot. The original snapshot is also retained. You can select resize an image to one of three image sizes: 5M, 3M, VGA.
1. Touch “ú” or “õ” or drag left or right to display the image you want to
resize.
2. Touch a size.
This resizes the image to the selected size and saves the result as a new photograph.
NOTE
• Resizing a 3:2 size snapshot will create an image with an aspect ratio of 4:3, with both sides cut off.
• The recording date of the resized version of the snapshot will be the same as the recording date of the original snapshot.
82
Other Playback Functions (PLAY)

Cropping a Snapshot (Trimming)

Procedure
Enter the PLAY Mode * MENU * Trimming
You can crop a snapshot to trim parts you do not need, and save the result in a separate file. The original snapshot is also retained.
1. Touch “ú” or “õ” or drag left or right to display the image you want to
crop.
2. Touch “OK”.
3. Drag the image until the part you want to
keep is displayed.
• To enlarge the image, touch “+”, or touch the screen with your thumb and forefinger and then spread them apart. To reduce the size of the image, touch “–”, or touch the screen with your thumb and forefinger and then squeeze them together.
Zoom factor
Represents
snapshot area
4. Touch “OK”.
This will crop the image, leaving only the displayed part.
NOTE
• The image produced by cropping a 3:2 image will have an aspect ratio of 4:3.
• The recording date of the cropped image will be the same as the recording date of the original snapshot.
Part of snapshot that is
currently displayed
83
Other Playback Functions (PLAY)

Establishing a Wireless LAN Connection

Wireless LAN Functions

Establishing a wireless LAN connection between the camera and a smartphone enables the functions described below.
With this function: You can do this:
Remote Capture*
Remotely control and shoot with the camera using a smartphone.
Quick Send
Send to phone
View on phone
*
Send a snapshot that was just recorded with the camera to a smartphone.
*
Send snapshots and movies recorded with your camera to your smartphone.
Use a smartphone or computer to view and download snapshots and movies stored in camera memory.
See page:
86
88
89
91
* Requires installation of the EXILIM Remote app on your smartphone.
IMPORTANT!
• Never use wireless LAN functions inside an aircraft or anywhere else where such operation is restricted.
84
Establishing a Wireless LAN Connection
NOTE
• Note that using wireless LAN functions requires more battery power usage than normal. Make sure that the camera battery is sufficiently charged before starting a wireless LAN operation.
• The operating range depends on the local communication environment and on the type of smartphone you are connected to.

Establishing a Connection between a Smartphone and Your Camera

Installing the EXILIM Remote Smartphone app on your smartphone makes it possible to remotely control the camera from your smartphone and to send images recorded with the camera to your smartphone. For information about how to install and operate EXILIM Remote, see the User’s Guide or visit the official Exilim remote Website (http://www.exilim.com/app/). Note that an Exilim Remote Website may not be available for a particular language. If you cannot find an Exilim remote Website in a language you want, please use a version in another language.
. App operation guarantees
No guarantees are made concerning the ability to operate the EXILIM Remote app on any particular smartphone or tablet.

Installing the EXILIM Remote App on Your Smartphone

. Android terminal (Supported Versions: Android 2.3.3 to 4.2)
1. Open “Google Play”.
2. In the search field, type “EXILIM Remote”.
3. Install EXILIM Remote.
. iPhone (Supported Versions: iOS 5.1 to 6.1)
1. Open “App Store”.
2. In the search field, type “EXILIM Remote”.
3. Install EXILIM Remote.
85
Establishing a Wireless LAN Connection

Configuring Wireless LAN Settings

Use the procedure below to establish a wireless LAN connection between the camera and a smartphone for the first time. This operation is required for the first connection only.
1. On your camera, enter the REC mode and
then touch the “ ” (Remote Capture) icon.
• If the “ ” (Remote Capture) icon is not displayed on the screen, touch the tab to display it.
This will enable connection with a smartphone and the camera will display a screen for input of an SSID and password.
password
SSID
2. For the smartphone Wi-Fi setting, input the
camera SSID and password.
When the message “Start up the phone app.” appears on the camera’s monitor screen, it means that the smartphone has established a wireless connection with the camera.
• To break the wireless connection, touch “Cancel”.
• What you need to do to establish a wireless LAN connection depends on the type of smartphone you are using. For details about how to establish a wireless LAN connection see the user documentation that comes with your smartphone.

Using a Smartphone as a Camera Remote Controller (Remote Capture)

This function lets you remotely shoot a snapshot or movie with the camera using a smartphone. You also can perform remote zoom, self-timer, and other operations as well.
1. On your camera, enter the REC mode and then touch the “ ” (Remote
Capture) icon.
• If the “ ” (Remote Capture) icon is not displayed on the screen, touch the tab to display it.
2. On your smartphone, start up the EXILIM Remote app.
This will establish a connection between the smartphone and your camera.
• About 60 seconds after your camera establishes a connection with the smartphone, the camera’s monitor screen will go blank and its back lamp will light green.
• If the message “Connect your phone to the access point below.” remains on the camera’s monitor screen, change the smartphone’s Wi-Fi settings so your camera is selected for connection (page 86).
86
Establishing a Wireless LAN Connection
3. Compose the image on your smartphone’s screen as you shoot.
• After you are finished using Remote Capture, touch “Exit” on the camera or exit the app on your smartphone.
IMPORTANT!
• For snapshots, Premium Auto Pro is automatically selected as the recording mode while shooting with Remote Capture. You cannot shoot with BEST SHOT or other recording modes.
• The Movie Quality is always STD (640
. Controlling Your Camera with a Smartphone
EXILIM Remote supports the Remote Capture operations listed below. This manual explains EXILIM Remote operations based on screens that appear using the iPhone version. Some operations may differ depending on your smartphone type.
1
1
bk
2 3
4
2
3 4
9 8 7
5 6
5 6 7 8
9 bk
Location Information
You can use 8 to add location information to snapshots shot with Remote Capture when they are sent to a smartphone. On an Android terminal, select the Remote Capture screen. On an iPhone, perform the following operation: “Settings” * “Privacy” * “Location Services”.
x
480) when shooting with Remote Capture.
Exits Remote Capture. Select to configure self-timer and LED light settings for snapshot shooting. The Remote Capture self-timer countdown time is 10 seconds (fixed). Displays current LED light settings. Displays what is being picked up by the camera’s lens. Performs a zoom operation. Toggles between snapshot and movie shooting. Shoot a snapshot or start movie recording. Sends the snapshot that was just recorded to the smartphone. Displays location information settings. Displays current self-timer settings.
“Options” on
2
IMPORTANT!
• Enabling location-based services causes the recording date, location information, and other personally identifiable information to be included in the snapshot data. Take care when sharing or publishing such images on web services, etc.
87
Establishing a Wireless LAN Connection

Sending a Just-recorded Snapshot to a Smartphone (Quick Send)

You can use Quick Send to send a snapshot you just recorded with the camera to a smartphone.
• Note that you will not be able to use Quick Send to send a snapshot to a smartphone if you performed any one of the operations below after recording the snapshot. – Exiting the REC mode to the PLAY mode or turning off the camera – Resetting the camera (page 109) or formatting camera memory (page 109) – Selecting Remote Capture – Performing a movie recording operation
1. On the camera, enter the REC mode and shoot the snapshot.
2. Touch the “ ” (Quick Send) icon.
3. Touch “Send”.
4. On your smartphone, start up the EXILIM Remote app.
This will establish a connection between your camera and the smartphone, and send the snapshot you just recorded to the smartphone.
• If the message “Connect your phone to the access point below.” remains on the camera’s monitor screen, change the smartphone’s Wi-Fi settings so your camera is selected for connection (page 86).
5. After image send is complete, tap “OK” on your smartphone.
The connection between your camera and the smartphone will be terminated automatically after the send operation is complete.
NOTE
• You can specify the size of the image sent to the smartphone using “Resize before send” (page 90).
• You can use the smartphone apps below to view snapshots after sending them. – iPhone: Camera Roll – Android terminal: Gallery or another photo browser app
88
Establishing a Wireless LAN Connection

Sending a Snapshot or Movie File from Camera Memory to a Smartphone (Send to phone)

You can select one more snapshot and/or movie file in camera memory and send it to a smartphone. You can select up to 100 files, totaling no more than 500MB for a single send.
1. On the camera, touch “p” (PLAY) to enter the PLAY mode.
2. Touch the “ ” (Image Send) icon.
• If the “ ” (Image Send) icon is not displayed on the screen, touch the tab to display it.
3. Touch “ ” (Send to phone).
4. Touch the images of the files you want to send to the smartphone.
Touching the image of a file causes its check box to become selected.
5. After selecting the images of all of the files you want to send to the
smartphone, touch “OK”.
6. On your smartphone, start up the EXILIM Remote app.
This will establish a connection between your camera and the smartphone, and send the files to the smartphone.
• If the message “Connect your phone to the access point below.” remains on the camera’s monitor screen, change the smartphone’s Wi-Fi settings so your camera is selected for connection (page 86).
7. After image send is complete, tap “OK” on your smartphone.
The connection between your camera and the smartphone will be terminated automatically after the send operation is complete.
IMPORTANT!
• Some smartphone models may not be able to play back movie files.
• Depending on your smartphone model, its operating system version, and/or its remaining storage capacity can cause failure of a movie or snapshot save operation. After send operation, perform the required operation on your smartphone to ensure that the movie or snapshot was saved properly.
• Viewing a movie received on an Android terminal: Note that movies are not displayed by Gallery. Movies are stored in a folder named “EXILIM Remote”. A separate movie player is required to playback movies (whose files have the file name extension MOV). Depending on your movie player, you may not be able to playback movies and/or audio.
89
Establishing a Wireless LAN Connection
NOTE
• You can specify the size of the snapshots sent to the smartphone using “Resize before send” (page 90).
• You can use the smartphone apps below to view snapshots after sending them. – iPhone: Camera Roll – Android terminal: Gallery or another photo browser app

Resizing Snapshots before Sending Them to a Smartphone (Resize before send)

Procedure
MENU * Setup * Resize before send
This feature can be use to resize snapshots before they are sent to a smartphone using “Quick Send”, “Remote Capture”, or “Send to phone”.
Original Images are sent in the size they were originally recorded.
3M
Images are converted to 3M size before being sent.
• If an original image is 3M size or smaller, it is sent without resizing.
90
Establishing a Wireless LAN Connection

Viewing Snapshots and Movies in Camera Memory on a Smartphone (View on phone)

You can use this function to enable up to eight smartphones and/or computers to access snapshots and movies in camera memory for viewing and download. A smartphone does not need to have the EXILIM Remote app installed in order to access camera images using this function.
1. On the camera, touch “p” (PLAY) to enter the PLAY mode.
2. Touch the “ ” (Image Send) icon.
• If the “ ” (Image Send) icon is not displayed on the screen, touch the tab to display it.
3. Touch “ ” (View on phone).
This establishes a connection between the smartphone and camera, and displays a URL.
• If the message “Connect your phone to the access point below.” remains on the camera’s monitor screen, change the smartphone’s Wi-Fi settings so your camera is selected for connection (page 86).
• After about 60 seconds, the camera’s monitor screen will go blank. Touching the monitor screen will cause its image to reappear.
4. On the smartphone, start up its browser app.
• The browser will automatically access the URL displayed by the camera in step 3 of this procedure, and then display an image stored in camera memory.
• If no camera image appears automatically, manually input the URL into the browser.
• To exit the wireless LAN function, touch “Exit” on the camera’s monitor screen.
URL
IMPORTANT!
• Some smartphone models may not be able to play back movie files.
NOTE
• You can also view image in camera memory on a computer’s browser by establishing a wireless LAN connection with the computer.
91
Establishing a Wireless LAN Connection

Printing

Professional Print Service
You can take a memory card that contains the images you want to print to a professional print service and have them printed.
Printing on a Home Printer
You can use a printer equipped with a memory card slot to print images directly from a memory card. For details, see the user documentation that comes with your printer.

Printing with a Computer

After transferring the images to your computer, use commercially available software to print.
Printing with a Computer
There are a variety of different ways to print images stored on a computer. This section shows one standard printing example.
. Printing on a Windows Computer
1. Use the procedure under “Viewing and Storing Images on a Computer”
(page 95) to store the image you want to print, and then display the image on your computer screen.
2. Windows XP users: Click “File” and then “Print”.
Windows 8, Windows 7, Windows Vista users: Click “Print” and then “Print”.
3. Configure the desired print settings and then print.
Windows XP users: Follow the instructions on the print wizard that appears configure settings and then print. Windows 8, Windows 7, Windows Vista users: Configure print settings and then click “Print”.
92
Printing
. Printing on a Macintosh
1. Use the procedure under “Connecting the Camera to Your Computer
and Saving Files” (page 98) to store the image you want to print, and then display the image on your Macintosh screen.
2. Click “File” and then “Print”.
3. Configure print settings and then click “Print”.
This will print the selected image.
93
Printing

Using the Camera with a Computer

Things you can do using a computer...

You can perform the operations described below while the camera is connected to a computer.
Save images to a computer and view them there
Play back and edit movies
The procedures you need to perform are different for Windows and the Macintosh.
• Windows users should refer to “Using the Camera with a Windows Computer” on page 94.
• Macintosh users should refer to “Using the Camera with a Macintosh” on page
98.
• Save images and view them manually (USB connection) (pages 95, 98).
• You can play back movies (pages 97,
100).
• To edit movies, use commercially available software as required.

Using the Camera with a Windows Computer

When you want to do this:
Save images to a computer and view them there manually
Play movies
Operating System Version
Windows 8, Windows 7, Windows Vista, Windows XP (SP3)
Windows 8, Windows 7, Windows Vista, Windows XP (SP3)
Install this software:
Installation not required.
Movies can be played back using QuickTime 7.
• You need to download QuickTime 7 on the Web if you want to use it.
See page:
95
97
94
Using the Camera with a Computer

Viewing and Storing Images on a Computer

You can connect the camera to your computer in order to view and store images (snapshot and movie files).
Never use your computer to modify, delete, move, or rename any image files that are in the camera’s built-in memory or on its memory card.
Doing so can cause problems with the camera’s image management data, which will make it impossible to play back images on the camera and can drastically alter remaining memory capacity. Whenever you want to modify, delete, move, or rename an image, do so only on images that are stored on your computer.
IMPORTANT!
• Never unplug the USB cable, or operate the camera while viewing or storing images. Doing so can cause data to become corrupted.
NOTE
• You also can use your computer’s card slot (if it has one) or a commercially available card reader to access image files directly from the camera’s memory card. For details, see the user documentation that comes with your computer.
. To connect the camera to your computer and save files
1. Turn off the camera and then
use the micro USB cable that comes with the camera to
[USB] port
USB
connect it to your computer.
• For details about connecting to the camera and precautions when connecting, see page 23.
Micro USB cable
(included with camera)
2. Turn on the camera.
• The first time you connect the camera to your computer with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.
3. Windows 8 users: Click “Desktop” and then “Explorer”.
Windows 7, Windows Vista users: Click “Start” and then “Computer”. Windows XP users: Click “Start” and then “My Computer”.
4. Double-click “Removable Disk”.
• Your computer recognizes the memory card loaded in the camera (or built-in memory if there is no card) as a removable disk.
95
Using the Camera with a Computer
5. Right-click the “DCIM” folder.
6. On the shortcut menu that appears, click “Copy”.
7. Windows 8 users: Click “Documents”.
Windows 7, Windows Vista users: Click “Start” and then “Documents”. Windows XP users: Click “Start” and then “My Documents”.
• If you already have a “DCIM” folder in “Documents” (Windows 8, Windows 7, Windows Vista) or “My Documents” (Windows XP), the next step will overwrite it. If you want to keep the existing “DCIM” folder, you need to change its name or move it to a different location before performing the next step.
8. Windows 8 users: On the “Documents” menus, click “Home” and then
“Paste”. Windows 7 users: On the “Documents” “Organize” menu, select “Paste”. Windows Vista users: On the “Documents” “Edit” menu, select “Paste”. Windows XP users: On the “My Documents” “Edit” menu, select “Paste”.
This will paste the “DCIM” folder (and all the image files it contains) into your “Documents” (Windows 8, Windows 7, Windows Vista) or “My Documents” (Windows XP) folder. You now have a copy of the files that are in camera memory on your computer.
9. After you finish copying images, disconnect the camera from the
computer.
On the camera, press [p] (Power) to turn off the camera. After checking to make sure that the back lamp is unlit or lit red, disconnect the USB cable.
. To view images you copied to your computer
1. Double-click the copied “DCIM” folder to open it.
2. Double-click the folder that contains the images you want to view.
3. Double-click the image file you want to view.
• For information about file names, see “Memory Folder Structure” on page 102.
96
Using the Camera with a Computer

Playing Movies

To play back a movie, first copy it to your computer and then double-click the movie file. Some operating systems may not be able to play back movies. If this happens, you need to install separately available software.
• If you are unable to play back movies, go to the URL below to download QuickTime 7 and install it on your computer. http://www.apple.com/quicktime/
. Minimum Computer System Requirements for Movie Playback
The minimum system requirements described below are necessary to play back movies recorded with this camera on a computer.
Operating System : Windows 8, Windows 7, Windows Vista, Windows XP (SP3) CPU : Image Quality “Full HD”, “HD”:
Required Software: QuickTime 7
• The above are recommended system environments. Configuring one of these environments does not guarantee proper operation.
• Certain settings and other installed software may interfere with proper playback of movies.
Core 2 Duo 3.0GHz or higher
Image Quality “HS240”:
Pentium 4 2.0GHz or higher
. Movie Playback Precautions
• Be sure to move the movie data to the hard disk of your computer before trying to play it. Proper movie playback may not be possible for data accessed over a network, from a memory card, etc.
• Proper movie playback may not be possible on some computers. If you experience problems, try the following. – Quit any other applications you have running, and stop resident applications.
97
Using the Camera with a Computer

Using the Camera with a Macintosh

When you want to do this:
Save images to your Macintosh and view them there manually
Save images to your Macintosh automatically/Manage images
Play movies OS X
Operating System Version
OS X Installation not required. 98
OS X
Install this software:
Use iPhoto, which comes bundled with some Macintosh products.
You can playback with QuickTime, which comes bundled with your operating system.
See page:
100

Connecting the Camera to Your Computer and Saving Files

Never use your computer to modify, delete, move, or rename any image files that are in the camera’s built-in memory or on its memory card.
Doing so can cause problems with the camera’s image management data, which will make it impossible to play back images on the camera and can drastically alter remaining memory capacity. Whenever you want to modify, delete, move, or rename an image, do so only on images that are stored on your computer.
IMPORTANT!
• Never unplug the USB cable, or operate the camera while viewing or storing images. Doing so can cause data to become corrupted.
• The camera does not support operation with Mac OS X 10.0. Operation is supported with Mac OS 10.1, 10.2, 10.3, 10.4, 10.5, 10.6, 10.7, and 10.8 (using the OS standard USB driver) only.
NOTE
• You also can use your computer’s card slot (if it has one) or a commercially available card reader to access image files directly from the camera’s memory card. For details, see the user documentation that comes with your computer.
98
Using the Camera with a Computer
. To connect the camera to your computer and save files
1. Turn off the camera and then
use the micro USB cable that comes with the camera to
[USB] port
USB
connect it to your Macintosh.
• For details about connecting to the camera and precautions when connecting, see page 23.
Micro USB cable
(included with camera)
2. Turn on the camera.
• The camera’s back lamp will light green or amber at this time. In this mode, your Macintosh recognizes the memory card loaded in the camera (or the camera’s built-in memory if it does not have a memory card loaded) as a drive. The appearance of the drive icon depends on the Mac OS version you are using.
• The first time you connect the camera to your Macintosh with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.
3. Double-click the camera’s drive icon.
The camera’s back lamp will light green at this time. In this mode, your Macintosh recognizes the memory card loaded in the camera (or the camera’s built-in memory if it does not have a memory card loaded) as a drive. The appearance of the drive icon depends on the Mac OS version you are using.
4. Drag the “DCIM” folder to the folder to which you want to copy it.
5. After the copy operation is complete, drag the drive icon to Trash.
6. Disconnect the camera from the computer.
On the camera, press [p] (Power) to turn off the camera. After checking to make sure that the back lamp is unlit or lit red, disconnect the USB cable.
99
Using the Camera with a Computer
. To view copied images
1. Double-click the camera’s drive icon.
2. Double-click the “DCIM” folder to open it.
3. Double-click the folder that contains the images you want to view.
4. Double-click the image file you want to view.
• For information about file names, see “Memory Folder Structure” on page 102.
• An image that was rotated on the camera will be displayed on your Macintosh screen in its original (unrotated) orientation.

Playing a Movie

You can use QuickTime, which comes bundled with your operating system, to play back movies on a Macintosh. To play back a movie, first copy it to your Macintosh and then double-click the movie file.
. Minimum Computer System Requirements for Movie Playback
The minimum system requirements described below are necessary to play back movies recorded with this camera on a computer.
Operating System : Image Quality “Full HD”: Mac OS X 10.4.11 or higher
Required Software: QuickTime 7 or higher
• The above are recommended system environments. Configuring one of these environments does not guarantee proper operation.
• Certain settings and other installed software may interfere with proper playback of movies.
Image Quality “HD”, “HS240”: Mac OS X 10.3.9 or higher
. Movie Playback Precautions
Proper movie playback may not be possible on some Macintosh models. If you experience problems, try the following.
– Upgrade to the latest version of QuickTime. – Shut down other applications that are running.
IMPORTANT!
• Be sure to move the movie data to the hard disk of your Macintosh before trying to play it. Proper movie playback may not be possible for data accessed over a network, from a memory card, etc.
100
Using the Camera with a Computer
