Casio EX-S9 User's Guide
Digital Camera
User’s Guide
E
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
1
Unpacking
As you unpack your camera, check to make sure that all items shown below are
included. If anything is missing, contact your original retailer.
Digital camera
Power cord Strap
USB cable AV cable CD-ROM Quick Start Guide
Rechargeable lithium ion
battery (NP-80)
To attach the strap to the camera
1
2
Charger unit (BC-81L)
Attach strap here.
2
