Casio EXILIM EX-TR10, EXILIM EX-TR300 User Guide

Digital Camera
User’s Guide
E
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.com/

Accessories

As you unpack your camera, check to make sure that all accessories shown below are included. If anything is missing, contact your original retailer.
Rechargeable lithium ion
battery (NP-150)
USB-AC adaptor
To attach the strap to the camera
Power cord
1
*
(AD-C54UC/AD-C54UG/AD-C53U)
Attach strap here.
2
*
Micro USB cable
1
Strap
*1 The type of USB-AC adaptor included varies according to the country or
geographic area where the camera is sold.
*2 A power cord is included with the AD-C53U USB-AC adapter. The shape of the
power cord plug varies according to the country or geographic area where the camera is sold.
2

Read this first!

• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production process. Feel free to contact us if you notice anything that is questionable, erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is forbidden. Except for your own personal use, any other use of the contents of this manual without the permission of CASIO COMPUTER CO., LTD. is forbidden under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits caused by loss of memory contents due to malfunction, repair, or any other reason.
• Note that the example screens and product illustrations shown in this User’s Guide may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that provides a pixel yield in excess of 99.99%. This means that some very small number of pixels may not light or may remain lit at all times. This is due to the characteristics of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is recording correctly.

Contents

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Monitor Screen Contents and How to Change Them . . . . . . . . . . . . . . . . . . . . 8
]\
Quick Start Basics 11
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Changing the Camera Style to Suit Shooting Conditions . . . . . . . . . . . . . . . . 13
]
Opening and Closing the Frame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
]
Rotating the Monitor Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
]
Camera Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Using the Touch Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
]
Loading the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
]
Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 24
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
]
Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
]
To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
]
To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Turning Power On and Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
To Shoot a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
]
Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
]
To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
]\
Recording Images 37
Selecting a Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
]
Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . . .(ART SHOT). . . 39
]
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Make-up). . . 41
]
Using Motion Shutter to Trigger a Self-timer Operation . . . (Motion Shutter). . . 42
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Shooting a Self-portrait . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
]\
Using BEST SHOT 49
Shooting Clearer Snapshots . . . . . . . . . . . . . . . . . . . . . . (Multi SR Zoom) . . 50
Digitally Correcting for Overexposure and Underexposure . . . . . . (HDR) . . 51
Shooting with High Speed Night Scene . . . . . . . . . . . . .(HS Night Scene) . . 52
Shooting with High Speed Anti Shake . . . . . . . . . . . . . . . (HS Anti Shake) . . 53
Shooting with Priority on Subject Faces . . . . . . . . . . . (HS Best Selection) . . 53
Shooting a Panorama Image . . . . . . . . . . . . . . . . . . . . .(Slide Panorama) . . 54
Contents
]\
Advanced Recording Settings 57
Using the REC Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
]
Using Touch Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Touch Shutter). . . 58
]
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . . . 58
]
Using the LED Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (LED) . . . 59
]
Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Image Size) . . . 60
]
Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . .(Movie Quality) . . . 61
]
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift). . . 62
]
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance). . . 63
]
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 64
]
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus) . . . 65
]
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review) . . . 66
]
Checking a Snapshot before Saving It . . . . . . . . . . . . . (Self-portrait check). . . 67
]\
Viewing Snapshots and Movies 68
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
]
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . . .(Movie Editing). . . 70
Viewing a Panorama Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . . 71
Viewing the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . . 73
]\
Other Playback Functions (PLAY) 75
Using the PLAY Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
]
Performing Paint Operations on an Image . . . . . . . . . . . . . . . . . . . . .(Paint). . . 76
]
Extracting an Image from a Snapshot . . . . . . . . . . . . . . . .(Cut out subject). . . 77
]
Inserting a Subject into another Snapshot or Adding a
Built-in Frame to a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . (Paste subject). . . 79
]
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . . (Protect). . . 80
]
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation). . . 81
]
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize) . . . 81
]
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . . . 82
]\
Printing 83
Printing with a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
]\
Using the Camera with a Computer 85
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . . 85
]
Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
]
Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
]
Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . . 89
]
Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Contents
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
]\
Other Settings (Set Up) 94
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . . (Screen) . . 94
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . . 94
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . . 95
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . .(Timestamp) . . 95
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . . 96
]
Setting a Travel Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
]
Selecting the Time Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . . 97
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . . 97
Selecting the HDMI Terminal Output Method . . . . . . . . . . . . . . . . .(HDMI) . . 98
Displaying a Startup Screen at Power On . . . . . . . . . . . . . . . . . .(Startup) . . 98
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . . 99
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . . 99
]\
Appendix 100
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
]
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
]
Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
]
Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
]
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
]
Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 120
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Contents

General Guide

The numbers in parentheses indicate the pages where each item is explained.
1
Frame (page 13)
1
Speaker
2
Shutter button*
3
(Self-portrait shutter button) (pages 31, 67) Lens
4
Microphone
5
(pages 16, 48) LED light (page 59)
6
* Your camera has two shutter buttons.
456
br
2
3
Memory card slot
7
(pages 27, 28) [HDMI] HDMI output
8
(micro) (page 73) [CARD HDMI] cover
9
(pages 27, 73) Back lamp
bk
(pages 20, 23, 29, 31) [p] (Power) (page 29)
bl
Battery slot (page 18)
br
7
8
bo
9
bkblbmbn bpbq
Shutter button*
bm
(page 31) Monitor screen
bn
(pages 8, 9, 94) [USB] port
bo
(pages 19, 22, 86, 90) Strap hole (page 2)
bp
[BATT.OPEN] button
bq
(pages 18, 18)

Monitor Screen Contents and How to Change Them

The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes. They do not represent screens that actually appear on the camera.
. Snapshot Recording
Tab (page 29)
356
7241
br bq bp bo bn
bkblbm
NOTE
•bl Movie capacity and bm Snapshot capacity do not appear in the following cases, even if “Information On” is selected for the information display setting (page 10). – Portrait orientation display – When the monitor screen and lens are facing in the same direction
1
Focus mode (page 65)
2
Self-timer mode (page 58)
3
8
Digital zoom (page 43)
4
Snapshot image size (page 60)
5
Movie quality (pages 46, 61)
6
LED light (page 59)
7
Zoom icons (pages 31, 43)
9
8
b” Movie icon (pages 32, 46)
9
Battery level indicator (page 24)
bk
Movie capacity (recording time) (page 31)
bl
Snapshot capacity (number of shots)
bm
(page 31) PLAY mode icon (page 29)
bn
Information icon (page 10)
bo
Auto rotate icon (page 10)
bp
Recording mode icon (page 38)
bq
Menu icon (page 57)
br
. Movie Recording
1 3
. Snapshot Viewing
42
13
bn bm bl bk 9
. Movie Playback
32 41
9bk 8
Movie quality (
1
Recording time switch icon (page 47)
2
Movie remaining time icon (page 47)
3
5
Remaining movie memory capacity/
4
Movie recording time (pages 47, 120) Zoom icons (pages 31, 43)
5
c” Movie stop icon (pages 32, 47)
6
6
Tab (page 29)
42
78
1
Protect indicator (page 80)
2
Folder name/file name (page 92)
3
5
Snapshot image size (page 60)
4
Image menu icon (p
5
Image scroll icons (pages 34, 68)
6
Battery level indicator (page 24)
7
Date/time (pages 24, 95)
8
6
REC mode icon (page 29)
9
Information icon (page 10)
bk
Slideshow icon (page 71)
bl
Delete icon (page 34)
bm
Menu icon (page 75)
bn
Tab (page 29)
1
Protect indicator (page 80)
2
Folder name/file name (page 92)
5
3
Movie quality (pages 46, 61)
4
6
Image menu ico
5
Movie recording time (page 68)
6
Image scroll icons (pa
7
Battery level indicator (page 24)
8
7
Date/time (pages 24, 95)
9
6
Movie play ico
bk
pages 46, 61)
age 72)
n (page 72)
ges 34, 68)
n (page 68)
. Configuring Auto Screen Alignment (Auto rotate)
You can use the Auto Rotate setting to enable or disable automatic rotation of screen contents in accordance with the physical orientation of the monitor screen.
1. Turn on the camera and then touch “«” (Auto rotate).
• If you do not see “«” on the screen, touch the tab to display it (page 29).
2. Select the Auto Rotate setting you want.
On
Off Fixes orientation of monitor screen contents.
. Selecting Display Information (DISP)
Each touch of “DISP” will cycle through settings that display or hide on-screen information. You can configure separate settings for the REC mode and PLAY mode.
• If “DISP” is not displayed on the screen, touch the tab to display it.
• Display information cannot be changed during movie recording.
Off No information displayed.
Information On Shows information about image settings, etc.
Status On
When Status On is selected for display information in the PLAY mode, the exposure, shutter speed, and ISO sensitivity setting values of the currently displayed image are displayed in orange when the current image’s Auto Exposure (AE) is not correct.
Automatically orients monitor screen contents to match camera orientation.
Shows more detailed information about settings.
• When Status On is selected, you will not be able to view the subject on the monitor screen.
10

Quick Start Basics

What you can do with your CASIO camera

Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following main functions.
A variety of shooting styles
The frame can be opened and the LCD monitor screen rotated into positions that make long-term shooting more comfortable and simplify self-shooting.
*See page 13 for more information.
Simple touch panel operation
The monitor screen is a touch panel that can be used to perform operations.
*See page 16 for more information.
Simple self-portrait shooting
The monitor screen can be rotated so it faces in the same direction as the camera’s lens, making self­shooting much easier.
*See page 45 for more information.
Make-Up
Make-up smoothes the skin texture of the subject and softens facial shadows caused by harsh sunlight for better looking portraits.
*See page 41 for more information.
11
Quick Start Basics
ART SHOT
A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting. “ART SHOT” provides the following effects: HDR Art, Sparkling Shot, Toy Camera, Soft Focus, Light Tone, Pop, Sepia, Monochrome, Miniature, Fisheye.
*See page 39 for more information.
Extract a subject from one photo and insert it into another
You can extract a person or object out of one snapshot and insert into another snapshot, or you can add a built-in frame to a snapshot.
*See pages 77, 79 for more information.
Paint
Draw figures, write text, or stamp information into a recorded snapshot.
*See page 76 for more information.
B
12
Quick Start Basics

Changing the Camera Style to Suit Shooting Conditions

You can change the configuration of the camera by opening or closing the frame and rotating the monitor screen panel to suit shooting conditions.
IMPORTANT!
• Do not apply strong pressure to the surface of the monitor screen. Doing so can damage it.
• Never touch the lens with your fingers. Finger smudges, dirt, and other foreign matter on the lens can interfere with proper operation of the camera. Use a blower or other means to keep the lens and flash window free of dirt and dust, and wipe gently with a soft, dry cloth.

Opening and Closing the Frame

The frame of the camera can be rotated 360 degrees.
1. With the monitor screen facing towards
you, hold onto the frame.
2. Push the monitor screen panel from
behind.
3. Holding the edges of the monitor
screen panel, swing the frame open.
IMPORTANT!
• Do not try to open or close the frame while the monitor screen panel is rotated. Doing so can cause the frame to come into contact with the monitor screen panel and cause malfunction.
13
Quick Start Basics

Rotating the Monitor Screen

Use the steps below to rotate the monitor screen.
NOTE
• While holding the monitor screen panel as shown in the illustration, you can rotate it 180 degrees clockwise and 90 degrees counterclockwise.
• The monitor screen panel can also be rotated when the frame is closed.
1. Hold the camera as shown in the
illustration.
2. Firmly holding the frame, carefully rotate the monitor screen panel.
180 degrees clockwise
90 degrees counterclockwise
14
Quick Start Basics

Camera Configurations

You can open the frame and rotate the monitor screen for a variety of different styles.
Normal Shooting Movie Recording
Shoot with the monitor screen facing the opposite direction of the lens.
Tabletop Shooting Self-portrait Shooting
Point the monitor screen and lens in the same direction and open the frame about 30 degrees so the camera can stand up.
Open the frame 90 degrees and hold the frame. You can also shoot with the camera upside down, if you like.
Open the frame, point the monitor screen and lens in the same direction, and press the shutter button on the frame to shoot.
15
Quick Start Basics
NOTE
• When shooting hold the camera still. Carefully press the shutter button and take care to avoid all movement as the shutter releases and for a few moments after it releases.
• Take care that your fingers and the strap do not cover any of the areas indicated in the illustration.
LED light
• To protect against accidentally dropping the camera, attach the wrist strap and make sure it is around your fingers or wrist while you are operating the camera.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this camera only. Never use it for any other purpose.
Microphone
Lens
IMPORTANT!
• Take care to ensure that your finger is not blocking or is not too close to the LED light. Fingers can cause unwanted shadows when shooting.

Using the Touch Panel

The monitor screen of the camera is a touch panel. This means you can perform the following operations by touching the screen with your fingers.
Touch
Momentarily touching the screen with your finger. Touch the screen to select an icon or menu item, and to configure settings.
Touch-and-hold
Holding your finger against the screen. Touch and hold the screen to scroll images at high speed, or to perform continual frame-by-frame playback of a movie.
16
Quick Start Basics
Drag
Holding your finger against the screen as you drag it up, down, left, or right. Use drag to move a screen image to a different location, and to scroll between images.
Spread
Holding your thumb and forefinger against the screen as you spread them out. Use spread to enlarge the screen image.
Squeeze
Holding your thumb and forefinger against the screen as you bring them together. Use squeeze to reduce the size of the screen image.
IMPORTANT!
• Never use a pointed or hard object to perform screen operations. Doing so can damage the screen.
NOTE
• Applying a commercially available LCD protective sheet will reduce the operation sensitivity of the monitor screen.
17
Quick Start Basics

First, charge the battery prior to use.

Note that the battery of a newly purchased camera is not charged. Perform the steps below to load the battery into the camera and charge it.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-150) for power. Never try to use any other type of battery.

Loading the Battery

1. Open the cover.
While depressing the [BATT.OPEN] button, slide the cover in the direction indicated by the arrow in the illustration.
1
3
2. Load the battery.
With the CASIO logo on the battery upwards, load the battery into the camera as shown in the illustration.
3. Close the cover.
While holding down the [BATT.OPEN] button, align the tabs of the cover with the notches on the camera and then slide the cover in the direction of the arrow.
[BATT.OPEN]
button
Battery
NG
1
[BATT.OPEN]
button
2
OK
CASIO logo
2
3
18
Quick Start Basics
To replace the battery
1. Open the battery cover and remove the
current battery.
As shown in the illustration, pull up the edge of the battery to remove it.
2. Load a new battery.

Charge the Battery

You can use either of the two following methods to charge the battery. Before charging the battery, use the procedure under “Opening and Closing the Frame” (page 13) to open the frame.
• USB-AC adaptor
• USB connection to a computer
. To charge with the USB-AC adaptor
The adaptor lets you charge the battery while it is loaded in the camera. While the camera is turned off, connect in the sequence shown below. Charging time: Approximately 140 minutes
[USB] port
USB-AC adaptor
(AD-C54UG)
2
1
USB-AC adaptor
u mark of the small
3
(micro USB) connector facing the side opposite that of the monitor screen.
• When disconnecting the USB-AC adaptor from the camera, be sure to disconnect from the camera first.
B
4
Micro USB cable (included with camera)
(AD-C54UC)
1
USB-AC adaptor
19
2
3
2
Power cord
(AD-C53U)
Quick Start Basics
IMPORTANT!
• A battery that has not been used for a long time, or ambient temperature extremes can cause charging to take longer than normal. If charging takes longer than about five hours, a timer will terminate it automatically, even if the battery is not fully charged. This is indicated by the back lamp flashing red. If the battery has not been used for a very long time, charging may be terminated automatically and the back lamp may start flashing red after only about 60 minutes. In either case, disconnect the USB cable from the camera and then reconnect it to resume charging.
•Pressing [p] (Power) while the USB-AC adaptor is connected to the camera will turn on the camera with power being supplied by the battery. Because of this, charging will stop.
• The USB-AC adaptor will become warm during charging. This is normal and does not indicate malfunction.
• The shape of the power plug depends on each country or geographic area.
Back Lamp Operation
Lamp Status Description
Back lamp
Lit Red Charging
Abnormal ambient temperature, USB-AC
Flashing Red
adaptor problem, or battery problem (page
110), or charging terminated by the timer
Off Charging complete
20
Quick Start Basics
USB Cable Connection Precautions
• When connecting the USB cable to the camera, make sure that the cable connector and monitor screen panel are oriented correctly as shown in the illustration below.
Make sure that the u mark side of the USB cable connector and the front of the monitor screen panel (the side opposite that of the monitor screen) are facing in the same direction.
Front of monitor screen
The back lamp always initially light after charging starts. Even if the battery is already fully charged, the lamp will light momentarily. If the lamp does not light, check the orientation of the USB cable connector.
• Make sure that you insert the cable connector into the USB port until you feel it click securely into place. Failure to insert the connector fully can result in poor communication or malfunction.
• Note that even while the connector is fully inserted, you still will be able to see the metal part of the connector as shown in the illustration.
panel
21
Quick Start Basics
. To charge using a USB connection to a computer
USB connection lets you charge the battery while it is loaded in the camera. While the camera is turned off, connect in the sequence shown below (
[USB] port
USB port
1, 2
Computer
(power turned on)
USB
).
1
Micro USB cable
(included with camera)
u mark of the small (micro USB) connector facing the side opposite that of the monitor screen.
• If the camera is on, press [p] (Power) to turn it off before connecting it to your computer. Charging time: Approximately 170 minutes
IMPORTANT!
• The first time you connect the camera to your computer with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.
• A battery that has not been used for a long time, certain types of computers, and connection conditions can cause charging to take more than approximately five hours, which will trigger a timer that terminates charging automatically, even if the battery is not fully charged. If this happens, disconnect and then reconnect the USB cable to restart charging. To complete charging faster, use of the included USB-AC adaptor is recommended.
• If the battery has not been used for a very long time, charging may terminate automatically and the back lamp may start flashing red or go out after only about 60 minutes. In either case, use of the USB-AC adaptor that comes with the camera is recommended.
• If you turn on the camera while charging over a USB connection to a computer is in progress, the camera will establish a USB connection with the computer. Though charging normally should continue at this time, certain types of computers or connection environments may stop charging if supply power is low. This will be indicated by the camera’s back lamp lighting green.
• Charging is not performed while the connected computer is in the hibernate mode.
2
22
Quick Start Basics
Back Lamp Operation
Lamp Status Description
Lit Red, (Lit/Flashing Amber)
Charging
Back lamp
Abnormal ambient temperature,
Flashing Red
charging taking abnormally long, or battery problem (page 110)
Off, (Lit Green) Charging complete
• The information in parentheses in the above table shows the lamp status while the camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s battery (NP-150) without removing it from the camera. Never use any other type of charger device. Attempting to use a different charger can result in unexpected accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards. Use of an inferior device or a device that is not up to standard can cause malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you. Even in the case of a commercially available computer, certain USB port specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give the battery time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of this, it is recommended that you charge the battery immediately before you need to use it.
• Charging the camera’s battery may cause interference with TV and radio reception. If this happens, plug the USB-AC adaptor into an outlet that is further away from the TV or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging. Use of any other type of devices may result in improper charging.
23
Quick Start Basics
Checking the Current Battery Level
As battery power is consumed, a battery indicator on the monitor screen indicates its current level as shown below.
Level High Low
Battery Indicator ***
Indicator Color Cyan * Yellow * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the REC mode and PLAY mode.
• Leaving the camera for about 30 days with no power supplied while the battery is dead will cause its date and time settings to be cleared. A message telling you to configure time and date settings will appear the next time you turn on the camera after restoring power. When this happens, configure date and time settings (page
95).
• See page 123 for information about battery life and number of shots.

Configuring Basic Settings the First Time You Turn On the Camera

The first time you turn on the camera, a screen appears for configuring the display language, date, and time settings. Failure to set the date and time correctly will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if you purchased a camera intended for the Japanese market. To change the display language from Japanese in this case, use the procedure under “Specifying the Display Language (Language)” (page 97). Note that a version of this manual in the language you select may not be included with a camera intended for the Japanese market.
• Camera models sold in certain geographic areas may not support display language selection.
24
Quick Start Basics
1. Press [p] (Power) to turn on the camera.
2. Drag (page 17) upwards and downwards until
you find the language you want, and then touch to select it.
3. Touch the date display format you want.
Example: July 10, 2015 YY/MM/DD DD/MM/YY MM/DD/YY
* 15/7/10 * 10/7/15 * 7/10/15
[p] (Power)
4. Touch the value you want to change (year,
month, day, hour, minute).
5. Touch “8” or “2” to change the currently
selected value.
• Touching and holding “8” or “2” will change the
setting at high speed.
• To switch between 12-hour and 24-hour format, touch the 12/24 hour switch icon.
12/24 hour switch icon
6. When the date and time settings are the way you want, touch “OK”.
7. Touch “Auto” or “Premium Auto Pro” to select the default auto
recording mode you want.
8. Touch “Apply”.
• You will be able to change this setting later, if you want. See page 30 for details.
If you make a mistake configuring display language, date, or time settings with the above procedure, refer to the following pages for information about how to correct the settings.
– Display language: Page 97 – Date and time: Page 95
NOTE
• Each country controls its local time offset and the use of summer time, and so they are subject to change.
25
Quick Start Basics

Preparing a Memory Card

Though the camera has built-in memory that can be used to store images and movies, you probably will want to purchase a commercially available memory card for greater capacity. The camera does not come with a memory card. Images recorded while a memory card is loaded are saved to the memory card. When no memory card is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 120.

Supported Memory Cards

– microSD Memory Card – microSDHC Memory Card – microSDXC Memory Card
• The above are supported memory card types as of June 2013.
• This camera supports use of microSD memory cards of the following types and capacities: microSD memory cards up to 2GB, microSDHC memory cards from 2GB up to 32GB, microSDXC memory cards from 32GB up to 2TB. Note that the ability to use any particular card with this camera, even if it satisfies the above capacity and type requirements, is not guaranteed.
Warning!
*
0 Memory cards are small and present a risk of accidentally being swallowed
by infants and young children. Keep memory cards out of the reach of infants and young children. If a memory card is ever swallowed accidentally, contact a physician immediately.
+
26
Quick Start Basics

To load a memory card

1. Press [p] (Power) to turn off the
camera and then open the frame (page 13).
2. Hook your nail into the groove of
the [CARD HDMI] cover and pull the cover in the direction indicated by the arrow to open it.
3. Load a memory card.
Positioning the memory card so its back is facing upwards (towards the monitor screen side of the camera), slide it into the card slot all the way in until you hear it click securely into place.
4. Close the [CARD HDMI] cover and
then return the frame to its original position.
[CARD HDMI] cover
Back
Front Back
IMPORTANT!
• Never insert anything besides a supported memory card (page 26) into the memory card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off the camera, and contact your retailer or nearest CASIO authorized service center.
27
Quick Start Basics
. To replace the memory card
Press the memory card and then release it. This will cause it to pop out of the memory card slot slightly. Pull the card out the rest of the way and then insert another one.
• Never remove a card from the camera while the back lamp is flashing green. Doing so can cause the image save operation to fail and even damage the memory card.

To format (initialize) a new memory card

Format a memory card on the camera before using it for the first time.
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete its contents. Normally you do not need to format a memory card again. However, if storing to a card has slowed down or if you notice any other abnormality, re-format the card.
• Be sure to use the camera to format a memory card. Formatting a card on a computer will result in a non-SD standard format, which can greatly slow down processing time and cause compatibility, performance, and other problems.
1. Load a memory card (page 27).
2. Turn on the camera and then touch “MENU”.
• If “MENU” is not displayed on the screen, touch the tab to display it (page 37).
3. Drag upwards and downwards until you find “Setup”, and then touch it.
4. Touch “Format”.
5. Touch “Format” and then touch “Yes”.
This starts the memory card format operation.
28
Quick Start Basics

Turning Power On and Off

. To turn on the camera
Back lamp
Press [p] (Power). This will turn on the camera, which is indicated when the back lamp lights green, and enter the REC mode.
Entering the REC Mode and PLAY Mode
In the REC mode, touch “p” (PLAY).
• If Auto, BEST SHOT, or ART SHOT
To enter the PLAY mode
is selected as the recording mode, you can also switch to the PLAY
[p] (Power)
mode by touching the tab and then
To enter the REC mode
touching “p” (PLAY).
In the PLAY mode, touch the tab. On the screen image that appears, touch
r” (REC).
Screen after tab is
touched
. To turn off the camera
Press [p] (Power).
Tab
p” (PLAY) / “r” (REC)
NOTE
• To conserve battery power, an Auto Power Off function will turn off power automatically if you do not perform any operation for about five minutes.
29
Quick Start Basics

To Shoot a Snapshot

Your camera has a variety of different recording modes to suit various shooting conditions and objectives (page 38). This section explains general shooting procedures using the auto recording mode.

Selecting an Auto Recording Mode

You can select one of two auto recording modes (Auto or Premium Auto Pro) according to your digital imaging needs.
Setting
Auto This is the standard Auto recording mode.
Premium
Auto Pro
REC Screen Icon Display
Description
With Premium Auto Pro recording, the camera automatically determines whether you are shooting a subject or scenery, and other conditions. Premium Auto Pro recording delivers higher image quality than standard Auto recording.
• Some of the settings configured automatically by Premium Auto Pro cannot be changed by you.
• It also requires more power (and runs down the battery quicker) than Auto.
1. Press [p] (Power) to turn on the camera.
2. Touch the second icon from the top
(second icon from the right in the case of landscape display orientation) (Recording mode).
If the icon is not displayed on the screen, touch the tab to display it.
Recording mode icon
3. Touch “Auto” or “Premium Auto Pro” to
select the auto recording mode you want.
B
30
Quick Start Basics
Loading...
+ 96 hidden pages
