Casio EXILIM EX-S6 User Guide
Digital Camera
User’s Guide
E
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
1
Unpacking
As you unpack your camera, check to make sure that all items shown below are
included. If anything is missing, contact your original retailer.
Digital camera
Power cord Strap
USB cable AV cable CD-ROM Basic Reference
Rechargeable lithium ion
battery (NP-80)
To attach the strap to the camera
Charger unit (BC-80L)
Attach strap here.
2
Read this first!
• The contents of this manual and the bundled Basic Reference are subject to
change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost
profits, or claims by third parties arising out of the use of Photo Transport or
YouTube Uploader for CASIO.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take a few test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
3
Contents
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Monitor Screen Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
❚❙
Quick Start Basics 13
What is a digital camera? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . 14
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
❚
To charge the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
❚
To load the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . 19
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
❚
Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
❚
To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
❚
To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
❚
To turn power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
❚
To turn off the camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
To shoot a snapshot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Holding the Camera Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Deleting Images. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
❚
To delete a single file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
❚
To delete all files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
❚
Auto Focus Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
❚❙
Snapshot Tutorial 31
Using the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Size) . . 32
Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Flash) . . 35
Using Face Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . (Face Detection) . . 37
Reducing the Effects of Camera and Subject Movement . . . (Anti Shake) . . 39
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . . 40
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . 40
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . .(EV Shift) . . 42
Using the easy Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Changing the Control Panel Date/Time Style . . . . . . . . . . . . . . . . . . . . . . . . 45
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
❚
Optical Zoom and Digital Zoom Switch Point . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4
Contents
❚❙
Recording Movie Images and Audio 48
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Shooting a Snapshot while Shooting a Movie . . . . . . . . . . . . . . . . . . . . . . . . 50
Recording Audio Only . . . . . . . . . . . . . . . . . . . . . . . . . . (Voice Recording) . . 50
❚
To play back an audio recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
❚❙
Using BEST SHOT 52
What is BEST SHOT? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
❚
Some Sample Scenes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
To shoot an image with BEST SHOT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
❚❙
Advanced Settings 55
Using On-screen Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
REC Mode Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (REC) . . 57
❚
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus) . . . 57
❚
Changing the Focus Frame Shape . . . . . . . . . . . . . . . . . . . (Focus Frame). . . 60
❚
Using Continuous Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (CS). . . 61
❚
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer). . . 62
❚
Shooting with Face Detection . . . . . . . . . . . . . . . . . . . . . .(Face Detection). . . 63
❚
Reducing the Effects of Camera and Subject Movement . . . . (Anti Shake). . . 63
❚
Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . . . (AF Area). . . 63
❚
Using the easy Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (easy Mode). . . 64
❚
Assigning Functions to the [4] and [6] Keys . . . . . . . . . . . . . . . (L/R Key). . . 64
❚
Displaying the On-screen Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Grid). . . 64
❚
Turning Digital Zoom On or Off . . . . . . . . . . . . . . . . . . . . . . .(Digital Zoom). . . 65
❚
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review). . . 65
❚
Using Icon Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Icon Help). . . 65
❚
Configuring Power On Default Settings . . . . . . . . . . . . . . . . . . . . (Memory). . . 66
Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Quality) . . 67
❚
Specifying Snapshot Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Size) . . . 67
❚
Specifying Snapshot Image Quality . . . . . . . . . . . . . . . (Quality (Snapshot)). . . 67
❚
Specifying Movie Image Quality . . . . . . . . . . . . . . . . . . . . .(Quality (Movie)). . . 68
❚
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift). . . 68
❚
Controlling White Balance . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . . 68
❚
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 69
❚
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .(Metering) . . . 69
❚
Using Built-in Color Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Color Filter). . . 69
❚
Controlling Image Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . . (Sharpness) . . . 70
❚
Controlling Color Saturation . . . . . . . . . . . . . . . . . . . . . . . . . . . (Saturation). . . 70
❚
Adjusting Image Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Contrast). . . 70
❚
Specifying Flash Intensity . . . . . . . . . . . . . . . . . . . . . . . . . (Flash Intensity) . . . 70
❚❙
Viewing Snapshots and Movies 71
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Displaying 12 Images on the Same Screen. . . . . . . . . . . . . . . . . . . . . . . . . . 72
5
Contents
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . 73
❚❙
Other Playback Functions (PLAY) 75
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . . 75
Selecting Images for Printing . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . . 76
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . (Protect) . . 76
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation) . . 77
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Resize) . . 77
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . . 78
Adding Audio to a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . (Dubbing) . . 78
❚
To play snapshot audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Copy) . . 80
❚❙
Printing 81
Printing Snapshots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Connecting Directly to a PictBridge Compatible Printer . . . . . . . . . . . . . . . . 82
Using DPOF to Specify Images to be Printed
and the Number of Copies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
❚❙
Using the Camera with a Computer 87
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . 88
❚
Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
❚
Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
❚
Uploading Movie Files to YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
❚
Transferring Images from Your Computer to Camera Memory. . . . . . . . . . . . . . 95
❚
Viewing User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . (PDF Files) . . . 97
❚
User Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
❚
Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . . 98
❚
Transferring Images Automatically and Managing Them on Your Macintosh. . 101
❚
Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
❚
Viewing User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . .(PDF Files) . . 102
❚
User Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Using an Eye-Fi Wireless SD Memory Card to Transfer Images . (Eye-Fi) . 103
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
❚❙
Other Settings (Set Up) 107
Selecting a REC Mode Screen Layout . . . . . . . . . . . . . . . . . . (R Panel) . 107
Selecting a PLAY Mode Screen Layout . . . . . . . . . . . . . . . . (P Display) . 108
Changing the Menu Screen Color . . . . . . . . . . . . . . . . . . . . (Menu Color) . 108
Turning off Eye-Fi Card Communication . . . . . . . . . . . . . . . . . . . . (Eye-Fi) . 109
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 109
Configuring a Startup Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Startup) . 110
6
Contents
Specifying the File Name Serial Number Generation Rule . . . . . (File No.) . 110
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . .111
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . (Timestamp) . 112
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 112
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 113
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 113
Configuring Sleep State Settings . . . . . . . . . . . . . . . . . . . . . . . . . (Sleep) . 114
Configuring Auto Power Settings . . . . . . . . . . . . . . . . . . (Auto Power Off) . 114
Configuring [r] and [p] Settings . . . . . . . . . . . . . . . . . . . (REC/PLAY) . 115
Configuring USB Protocol Settings . . . . . . . . . . . . . . . . . . . . . . . . . (USB) . 115
Selecting the Screen Aspect Ratio and Video Output System (Video Out) . 116
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . (Format) . 117
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . (Reset) . 117
❚❙
Configuring Monitor Screen Settings 118
Using the On-screen Histogram to Check Exposure . . . . . . (+Histogram) . 118
❚
How to Use the Histogram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
❚❙
Appendix 120
Precautions during Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
❚
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
❚
To replace the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
❚
Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
❚
Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
❚
To replace the memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Computer System Requirements for Bundled Software . . . . . . . . . . . . . . . 132
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
❚
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
❚
Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Number of Snapshots/Movie Recording Time/Voice Recording Time . . . . . 142
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
7
Contents
General Guide
The numbers in parentheses indicate the pages where each item is explained.
. Camera
Front Back
5
4
321
bk9
8
7
Zoom controller
1
(pages 24, 45, 72)
Shutter button (page 24)
2
[ON/OFF] (Power)
3
(page 23)
Flash (page 35)
4
Front lamp
5
(pages 27, 62)
Lens
6
Microphone
7
(pages 49, 79)
Strap hole (page 2)
8
Bottom
6
bl
bm
bn
[ ]
[ ]
bpbqbrbsbt bo
Back lamp
9
(pages 23, 25, 35)
[0] (movie) button
bk
(page 48)
[r] (REC) button
bl
(pages 23, 24)
USB/AV port
bm
(pages 73, 82, 89, 98)
Connector cover
bn
[SET] button (page 31)
bo
[BS] button (page 52)
bp
[MENU] button
bq
(page 55)
Battery/memory card slots (pages 17, 21, 128, 130)
ck
Tripod hole
cl
Use this hole when attaching to a tripod.
Speaker
cm
br
bs
bt
[ ]
Control button
([8][2][4][6])
(pages 29, 31, 35, 118)
[p] (PLAY) button
(pages 23, 28)
Monitor screen
(pages 10, 118)
[
SET
[ ]
]
8
. Charger Unit
1
2
3
+- Contacts
1
[CHARGE] Lamp
2
AC jack
3
9
Monitor Screen Contents
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
. Snapshot Recording
Panel : On
19
6784523
bk
bn
cm
bl
bm
bn
bo
bp
bq
cl
Panel : Off
1bk 2
bo
bp
ck
3456 7
bsbt
8
br
9
bm
cm
ck
cl
bp
bn
bt
bs
br
Focus mode (page 57)
1
Continuous shutter (page 61)
2
Self-timer (page 62)
3
Recording mode (page 24)
4
Image deterioration indicator (page 46)
5
Metering mode (page 69)
6
Remaining snapshot memory capacity
7
(page 142)
Snapshot image size (page 32)
8
Snapshot image quality (page 67)
9
Flash (page 35)
bk
Face detection (page 37)
bl
Anti Shake (page 39)
bm
ISO sensitivity (page 40)
bn
White balance setting (page 40)
bo
Exposure compensation (page 42)
bp
easy Mode (page 43)
bq
Date/time (page 45)
br
Shutter speed
bs
Aperture value
bt
Focus frame (pages 25, 63)
ck
Battery level indicator (page 18)
cl
Histogram (page 118)
cm
NOTE
• If the current aperture, shutter speed, ISO sensitivity, or Auto Exposure is not
correct, the setting will turn orange when you half-press the shutter button.
10
easy Mode
ck
cl
. Movie Recording
Panel : On
2
4
31
9
8
Panel : Off
16 23
5
7
8
bk
3
br
6
7
5
4
Focus mode (page 57)
1
Self-timer (page 62)
2
Recording mode (page 48)
3
Movie recording time (page 48)
4
Remaining movie memory capacity
5
(page 48)
White balance setting (page 40)
6
Exposure compensation (page 42)
7
Battery level indicator (page 18)
8
Histogram (page 118)
9
9
8
7
11
. Snapshot Viewing
bq
bp
bo blbkbmbn
. Movie Playback
1
23
7
File type
4
5
6
7
8
9
4
5
1
Protect indicator (page 76)
2
Folder name/file name (page 104)
3
Snapshot image quality (page 67)
4
Snapshot image size (page 32)
5
ISO sensitivity (page 40)
6
Aperture value
7
Shutter speed
8
Date/time (page 45)
9
Metering mode (page 69)
bk
White balance setting (page 40)
bl
Flash (page 35)
bm
Recording mode
bn
Battery level indicator (page 18)
bo
Histogram (page 118)
bp
Exposure compensation (page 42)
bq
File type
1
Protect indicator (page 76)
2
Folder name/file name (page 104)
3
Movie recording time (page 71)
4
Movie image quality (page 67)
5
Date/time (page 45)
6
Battery level indicator (page 18)
7
321
6
12
Quick Start Basics
What is a digital camera?
A digital camera stores images on a memory card, so you can record and
delete images a countless number of times.
Record
Delete
You can use the images you record in a variety of different ways.
Store images on your
computer.
Print images. Attach images to e-mail.
13
Play
Quick Start Basics
What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following three main functions.
Face Detection
Point the camera at a person and it automatically
detects the person’s face for beautiful portraits
every time.
See page
37 for more information.
Anti Shake
The camera corrects automatically to minimize
image blur due to camera movement and highspeed subject movement.
See page
39 for more information.
BEST SHOT
Simply select the sample scene you want and the
camera sets up automatically. Then all you need
do is press the shutter button for perfect images.
See page
52 for more information.
14
Quick Start Basics
First, charge the battery prior to use.
Note that the battery of a newly purchased camera is not charged. Perform the steps
under “To charge the battery” to bring the battery to a full charge.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-80) for
power. Never try to use any other type of battery.
To charge the battery
1. Positioning the positive
+
and
negative - terminals of the battery
with those of the charger unit, load
the battery into the charger unit.
2. Plug the charger unit into a
household power outlet.
About 100 minutes are required to
reach full charge. The [CHARGE]
lamp will go out when charging is
complete. Unplug the power cord
from the power outlet and then
remove the battery from the charger.
Lamp Status Description
Lit Red Charging
Flashing Red
Off Charging complete
Abnormal ambient temperature, charger problem, or
battery problem (page 128)
[CHARGE] lamp
15
Quick Start Basics
Other Charging Precautions
• Use the special charger (BC-80L) to charge the special lithium ion battery (NP-80).
Never use any other type of charger device. Attempting to use a different charger
can result in unexpected accident.
• A battery that is still warm due to normal use may not charge fully. Give the battery
time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the charger into an outlet that is further away from the TV or
radio.
• Actual charging time depends on current battery capacity and charging conditions.
16
Quick Start Basics
To load the battery
1. Open the battery cover.
Pressing the battery cover, slide it in the direction
indicated by the arrow.
1
2
2. Load the battery.
With the EXILIM logo on the
battery facing upwards (in the
direction of the monitor
screen), hold the stopper next
to the battery in the direction
indicated by the arrow as you
slide the battery into the
camera. Press the battery in
until the stopper secures it in
place.
Battery contacts
3. Close the battery cover.
Pressing the battery cover against the camera, slide
it closed.
• For information about how to replace the battery,
see page 128.
EXILIM logo
Stopper
Front
Back
2
1
17
Quick Start Basics
Checking Remaining Battery Power
As battery power is consumed, a battery indicator on the monitor screen indicates
remaining power as shown below.
Remaining Power High Low
Battery Indicator ***
Indicator Color Cyan * Amber * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• The camera date and time display will not be correct if the camera is left for about
two days with no power supplied while the battery is dead. If this happens, load
new battery and then set the correct time and date (page 112).
• See page 146 for information about battery life and memory capacity.
Battery Power Conservation Tips
• When you do not need to use the flash, select ? (Flash Off) for the flash setting
(page 35).
• Enable the Auto Power Off and the Sleep features to protect against wasting
battery power when you forget to turn off the camera (pages 114, 114).
B
18
Quick Start Basics
Configuring Basic Settings the First Time You Turn On the Camera
The first time you load a battery into the camera, a
screen appears for configuring the display
language, date, and time settings. Failure to set
the date and time correctly will cause the wrong
date and time data to be recorded with images.
1. Press [ON/OFF] to turn on the camera.
[BS]
[ON/OFF]
[
SET
2. Use [8], [2], [4], and [6] to select the language you want and then
press [SET].
3. Use [8] and [2] to select a date style and then press [SET].
Example: 19. 12. 10
YY/MM/DD
DD/MM/YY
MM/DD/YY
* 10/12/19
* 19/12/10
* 12/19/10
4. Set the date and the time.
Use [4] and [6] to select the setting you want to
change and then use [8] and [2] to change it.
To switch between 12-hour and 24-hour format,
press [BS].
5. After setting the date and time, use [4] and
[6] to select “Apply” and then press [SET].
]
19
Quick Start Basics
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: Page 113
– Date and time: Page 112
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
• Removing the battery too soon after you set the time and date can cause the date
and time display to become incorrect. Do not remove the battery for at least
24 hours after configuring settings.
B
20
Quick Start Basics
Preparing a Memory Card
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 142.
Supported Memory Cards
– SD Memory Card
– SDHC Memory Card
Use one of the above types of memory card.
To load a memory card
1. Press [ON/OFF] to turn off the camera and
then open the battery cover.
Pressing the battery cover, slide it in the direction
indicated by the arrow.
1
2
2. Load a memory card.
Positioning the memory card so its
back is facing upwards (in the
direction of the monitor screen), slide
it into the card slot all the way in until
you hear it click securely into place.
Back
Front Back
21
Quick Start Basics
3. Close the battery cover.
Pressing the battery cover against the camera, slide
it closed.
• For information about how to replace the memory
card, see page 130.
IMPORTANT!
• Never insert anything besides a supported memory card (page 21) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, remove the battery, and contact your retailer or nearest CASIO
authorized service center.
To format (initialize) a new memory card
You need to format a new memory card before using it for the first time.
2
1. Turn on the camera and press [MENU].
2. Select the “Set Up” tab, select “Format” and then press [6].
3. Use [8] and [2] to select “Format” and then press [SET].
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete
its contents. Normally you do not need to format a memory card again. However, if
storing to a card has slowed down or if you notice any other abnormality, re-format
the card.
• Be sure to use the camera to format a memory card. Formatting a memory card on
a computer and then using it in the camera can slow down data processing by the
camera. In the case of an SD or SDHC memory card, formatting on a computer can
result in non-conformity with the SD format, causing problems with compatibility,
operation, etc.
• Before formatting a new Eye-Fi card to use it for the first time, copy the Eye-Fi
Manager install files to your computer. Do this before formatting the card.
1
22
Quick Start Basics
Turning the Camera On and Off
To turn power on
To enter the REC mode, press [ON/OFF] (Power) or [r]
(REC). To enter the PLAY mode, press [p] (PLAY).
The back lamp will light (green) momentarily and the
camera will turn on. If you are entering the REC mode,
the lens will extend from the camera at this time.
[ON/OFF] (Power)
• Take care to ensure that nothing is restricting or
coming into contact with the lens as it extends. Holding
the lens with your hand so it cannot extend creates the
Back lamp
risk of malfunction.
•Pressing [p] (PLAY) while in the REC mode switches
to the PLAY mode. The lens retracts about 10 seconds
after switching modes.
• The Sleep function or Auto Power Off (pages 114, 114)
will turn off power automatically if you do not perform
any operation for a preset amount of time.
[p]
(PLAY)
[r]
(REC)
To turn off the camera
Press [ON/OFF] (Power).
• You can configure the camera so power does not turn on when you press [r]
(REC) or [p] (PLAY). You also can configure the camera to turn off when you
press [r] (REC) or [p] (PLAY) (page 115).
23
Quick Start Basics
To shoot a snapshot
1. Press [r] (REC) to turn on the camera.
Make sure R is on the display. If it isn’t, see page 52.
Snapshot mode icon
Remaining Snapshot Memory
Capacity (page 142)
2. Point the camera at
the subject.
You can zoom the
image, if you want.
Zoom controller
Monitor screen
Shutter button
[r] (REC)
w Wide Angle z Telephoto
24
Quick Start Basics
3. Half-press the shutter button to
focus the image.
When focus is complete, the camera
will beep, the back lamp will light
green, and the focus frame will turn
green.
Focus frameBack lamp
Half-press
Press lightly
until the
button stops.
Beep, beep (Image is in focus.)
When you half-press the shutter button, the
camera automatically adjusts exposure and
focuses on the subject it is currently pointed
at. Mastering how much pressure is required
for a half-press and a full-press of the shutter
button is an important technique for goodlooking images.
• The focus frame in the screen shots
included in this manual is shown at ß.
Note that you can change the form of the
focus frame, if you want (page 60).
4. Continuing to keep the camera still, press the shutter button the rest of
the way down.
This records the snapshot.
Full-press
Snap (Image is recorded.)
Shooting a Movie
Press [0] (Movie) to start
movie recording. Press
[0] (Movie) again to stop
movie recording. See
page 48 for details.
[0] (Movie)
25
Quick Start Basics
. If the image does not focus...
If the focus frame stays red and the back lamp is flashing green, it means that the
image is not in focus (because the subject is too close, etc.) Re-point the camera at
the subject and try to focus again.
. If the subject is not in the center of the frame...
“Focus lock” (page 59) is the name of a technique you can use when you want to
shoot an image in which the subject to be focused on is not within the focus frame in
the center of the screen.
26
Quick Start Basics
Holding the Camera Correctly
Your images will not come out clearly if you move the camera when you press the
shutter button. When pressing the shutter button, be sure to hold the camera as
shown in the illustration below, and keep it still by pressing your arms firmly against
your sides as you shoot.
Holding the camera still, carefully press the shutter button and take care to avoid all
movement as the shutter releases and for a few moments after it releases. This is
especially important when available lighting is low, which slows down the shutter
speed.
Horizontal Vertical
Hold the camera so the flash is
above the lens.
NOTE
• Take care that your fingers and
the strap do not cover any of the
areas indicated in the illustration.
• To protect against accidentally
dropping the camera, attach the
wrist strap and make sure it is
around your fingers or wrist while
you are operating the camera.
• Never swing the camera around
by its strap.
• The supplied strap is intended
for use with this camera only.
Never use it for any other
purpose.
Flash
Front lamp
Lens
Microphone
Strap
27
Quick Start Basics
Viewing Snapshots
Use the following procedure to view snapshots on the camera’s monitor screen.
• For information about how to play back movies, see page 71.
1. Press [p] (PLAY) to enter
[p] (PLAY)
the PLAY mode.
• This will display one of the
snapshots currently stored in
memory.
• Information about the
displayed snapshot also is
included (page 12).
• You also can clear the
information to view only the snapshot (page 118).
• You can zoom in on the image by sliding the zoom controller towards z (page
72). If you are recording a snapshot that is very important to you, it is
recommended that you zoom the image and check its details after recording it.
2. Use [4] and [6] to scroll between images.
• Holding down either button scrolls at high speed.
[6]
[6]
[4]
28
[4]
Quick Start Basics
Deleting Images
If memory becomes full, you can delete images you no longer need to free up storage
and record more images.
IMPORTANT!
• Remember that a file (image) delete operation cannot be undone.
• Deleting an audio snapshot (page 78) deletes both the snapshot and the audio file.
To delete a single file
1. Press [p] (PLAY) to enter the PLAY mode and then
press [2] ( ).
2. Use [4] and [6] to scroll through the files until the one you want to
delete is displayed.
3. Use [8] and [2] to select “Delete” and then press [SET].
• To delete other files, repeat steps 2 and 3.
• To exit the delete operation, press [MENU].
To delete all files
1. Press [p] (PLAY) to enter the PLAY mode and then press [2] ( ).
2. Use [8] and [2] to select “Delete All Files” and then press [SET].
3. Use [8] and [2] to select “Yes” and then press [SET] to delete all files.
This will cause the message “There are no files” to appear.
29
Quick Start Basics
Snapshot Shooting Precautions
Operation
• Never open the battery cover while the back lamp is flashing green. Doing so can
result in the image you just shot being saved incorrectly, damage to other images
stored in memory, malfunction of the camera, etc.
• If unwanted light is shining directly onto the lens, shade the lens with your hand
when shooting an image.
Monitor Screen when Shooting Snapshots
• Subject brightness conditions can cause monitor screen response to slow and can
cause digital noise in the monitor screen image.
• The image that appears on the monitor screen is for image composition. The actual
image will be recorded at the quality set for the image quality setting (page 67).
Shooting Indoors under Fluorescent Lighting
• Minute flickering of fluorescent lighting can affect the brightness or color of an
image.
Auto Focus Restrictions
• Any of the following can make proper focus impossible.
– Solid color wall or other very low contrast subject
– Strongly back lit subject
– Very shiny subject
– Blinds or other subject with a repeating horizontal pattern
– Multiple subjects at varying distances from the camera
– Subject in a dark location
– Camera movement while shooting
– Fast-moving subject
– Subjects outside the focus range of the camera
• If you cannot focus properly, try using focus lock (page 59) or Manual Focus (page
57).
30
Quick Start Basics
Loading...
