Casio EXILIM EX-10 User Guide
Digital Camera
User’s Guide
EN
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
Accessories
As you unpack your camera, check to make sure that all accessories shown below
are included. If anything is missing, contact your original retailer.
Rechargeable lithium ion
battery (NP-130A)
Power cord
2
*
USB-AC adaptor*
(AD-C54UG/AD-C53U)
Micro USB cable Basic Reference
1
Neck strap Lens cap
*1 The type of USB-AC adaptor included varies according to the country or
geographic area where the camera is sold.
*2 A power cord is included with the AD-C53U USB-AC adapter. The shape of the
power cord plug varies according to the country or geographic area where the
camera is sold.
2
Attaching and Removing the Lens Cap
The lens cap opens and closes
automatically in accordance with the
lens position, so you can leave it in
place, if you want. Make sure the lens
cap is attached to the lens so the dot
mark on the cap is upwards, with the
large blades of the cap on the left and
right. If the cap is in the wrong position,
its blades can cause partial darkening
of images when shooting with flash.
Attach the lens cap with the large blades
on the left and right.
Attaching the Neck Strap to the Camera
• Attach either end of the strap to the two strap
rings on the sides of the camera as shown in the
illustration.
• After you are finished pull on the strap to test it
and to make sure it does not come loose.
. Adjusting the Length of the Strap
You can adjust the length of the strap so it can
be used as a neck strap or a shoulder strap.
Mark
Removal
Attachment
1. Pull the strap out at the center
of the buckle in the direction
indicated by
1
.
2. Pull the strap in one of the
directions indicated by the
illustration to adjust the length.
To lengthen
To shorten
1
3
Read this first!
• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
4
