Casio EX-H10 User Manual
Digital Camera
User’s Guide
E
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
To go to “Getting the Most Out of Dynamic Photo” click here!
1
Unpacking
As you unpack your camera, check to make sure that all items shown below are
included. If anything is missing, contact your original retailer.
Digital camera
* The shape of the power cord plug
varies according to country or
geographic area.
Rechargeable lithium ion
battery (NP-90)
To attach the strap to the camera
Charger unit (BC-90L)
Attach strap
here.
Power cord Strap
USB cable AV cable CD-ROM Basic Reference
2
Read this first!
• The contents of this manual and the bundled Basic Reference are subject to
change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost
profits, or claims by third parties arising out of the use of Photo Transport, Dynamic
Photo Manager, or YouTube Uploader for CASIO.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take a few test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
C
3
Contents
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Monitor Screen Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
❚❙
Quick Start Basics 12
What is a digital camera? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . 13
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
❚
To charge the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
❚
To load the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . 17
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
❚
Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
❚
To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
❚
To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
❚
To turn power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
❚
To turn off the camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
To shoot a snapshot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Holding the Camera Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Deleting Images. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
❚
To delete a single file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
❚
To delete all files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
❚
Auto Focus Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
❚❙
Snapshot Tutorial 28
Using the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
❚
Specifying Control Panel Items. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Size) . . 29
Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Flash) . . 32
Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . (AF Area) . . 34
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . . 35
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (ISO) . . 36
Using Continuous Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(CS) . . 37
❚
Specifying the Method for Saving Continuous Shutter Images. . . . . . . . . . . . . . 38
Using Face Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . (Face Detection) . . 39
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . .(EV Shift) . . 41
Changing the Control Panel Date/Time Style . . . . . . . . . . . . . . . . . . . . . . . . 42
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
❚
Optical Zoom and Digital Zoom Switch Point . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Shooting with the Make-up Mode . . . . . . . . . . . . . . . . . . . . . . . (Make-up) . . 44
Shooting Beautiful Scenery Images . . . . . . . . . . . . . . . . . . . (Landscape) . . 45
4
Contents
❚❙
Recording Movie Images and Audio 47
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Shooting a Snapshot while Shooting a Movie . . . . . . . . . . . . . . . . . . . . . . . . 49
Recording Audio Only . . . . . . . . . . . . . . . . . . . . . . . . . . (Voice Recording) . . 49
❚
To play back an audio recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
❚❙
Using BEST SHOT 51
What is BEST SHOT? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
❚
Some Sample Scenes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
To shoot an image with BEST SHOT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
❚
Creating Your Own BEST SHOT Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Shooting with AUTO BEST SHOT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Shooting ID Photographs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Shooting Images of Business Cards and Documents . . . . . . . . . . . . . . . . . . 57
Recording a Self-portrait . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Isolating Moving Subjects . . . . . . . . . . . . . . . . . . . . . (Multi-motion Image) . . 59
❚❙
Advanced Settings 60
Using On-screen Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
REC Mode Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (REC) . . 62
❚
Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus) . . . 62
❚
Using Continuous Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (CS). . . 64
❚
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer). . . 65
❚
Using Auto Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Auto Shutter). . . 66
❚
Shooting with Face Detection . . . . . . . . . . . . . . . . . . . . . .(Face Detection). . . 69
❚
Shooting with Continuous Auto Focus . . . . . . . . . . . . . . . .(Continuous AF). . . 70
❚
Reducing the Effects of Camera and Subject Movement . . . . (Anti Shake). . . 70
❚
Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . . . (AF Area). . . 71
❚
Using the Auto Focus Assist Light . . . . . . . . . . . . . . . . . . .(AF Assist Light). . . 71
❚
Changing the Focus Frame Shape . . . . . . . . . . . . . . . . . . . (Focus Frame). . . 72
❚
Turning Digital Zoom On or Off . . . . . . . . . . . . . . . . . . . . . . .(Digital Zoom). . . 72
❚
Assigning Functions to the [4] and [6] Keys . . . . . . . . . . . . . . . (L/R Key). . . 73
❚
Shooting with Quick Shutter . . . . . . . . . . . . . . . . . . . . . . . . .(Quick Shutter) . . . 73
❚
Displaying the On-screen Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Grid). . . 74
❚
Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review). . . 74
❚
Using Icon Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Icon Help). . . 74
❚
Configuring Power On Default Settings . . . . . . . . . . . . . . . . . . . . (Memory). . . 75
Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Quality) . . 76
❚
Specifying Snapshot Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Size) . . . 76
❚
Specifying Snapshot Image Quality . . . . . . . . . . . . . . . (Quality (Snapshot)). . . 76
❚
Specifying Movie Image Quality . . . . . . . . . . . . . . . . . . . . .(Quality (Movie)). . . 77
❚
Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift). . . 77
❚
Controlling White Balance . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . . 78
❚
Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 79
❚
Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .(Metering) . . . 79
❚
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting). . . 79
❚
Using Built-in Color Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Color Filter). . . 80
5
Contents
❚
Controlling Image Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . . (Sharpness) . . . 80
❚
Controlling Color Saturation . . . . . . . . . . . . . . . . . . . . . . . . . . . (Saturation). . . 80
❚
Adjusting Image Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Contrast). . . 80
❚
Specifying Flash Intensity . . . . . . . . . . . . . . . . . . . . . . . . . (Flash Intensity) . . . 80
❚❙
Viewing Snapshots and Movies 81
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Viewing Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
❚
Deleting Continuous Shutter Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
❚
Dividing Up a CS Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Displaying the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Displaying Images in the Calendar Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Viewing Snapshots and Movies on a TV Screen. . . . . . . . . . . . . . . . . . . . . . 87
❚❙
Other Playback Functions (PLAY) 89
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . . 89
❚
Saving Music from Your Computer to Camera Memory . . . . . . . . . . . . . . . . . . . 90
Laying Out Snapshots with Layout Print . . . . . . . . . . . . . . . (Layout Print) . . 92
Creating a Snapshot of Movie Frames . . . . . . . . . . . . . (MOTION PRINT) . . 93
Editing a Movie on the Camera . . . . . . . . . . . . . . . . . . . . (Movie Editing) . . 94
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . . 96
Using Red Eye Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Red Eye) . . 96
Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance) . . 97
Adjusting the Brightness of an Existing Snapshot . . . . . . . . .(Brightness) . . 98
Keystone Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Keystone) . . 98
Using Color Correction to Correct the Color of
an Old Photograph . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Color Correction) . . 99
Selecting Images for Printing . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . 100
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . (Protect) . 100
Editing the Date and Time of an Image . . . . . . . . . . . . . . . . .(Date/Time) . 101
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation) . 101
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Resize) . 102
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . 102
Adding Audio to a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . (Dubbing) . 103
❚
To play snapshot audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Copy) . 104
❚❙
Dynamic Photo 105
To create a subject image to be inserted . . . . . . . . . . . . (Dynamic Photo) . 105
Inserting a Subject into a Background Image . . . . . . . . . (Dynamic Photo) . 107
❚
To view a Dynamic Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Converting a Dynamic Photo to a Movie . . . . . . . . . . . (Movie Converter) . 108
6
Contents
❚❙
Printing 109
Printing Snapshots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Connecting Directly to a PictBridge Compatible Printer . . . . . . . . . . . . . . . 110
Using DPOF to Specify Images to be Printed and the Number of Copies. . 112
❚❙
Using the Camera with a Computer 115
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . 116
❚
Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . 117
❚
Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
❚
Uploading Movie Files to YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
❚
Transferring Images from Your Computer to Camera Memory. . . . . . . . . . . . . 123
❚
Play back Dynamic Photo images on your EXILIM, a computer,
or on a mobile phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
❚
Viewing User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . (PDF Files) . . 125
❚
User Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
❚
Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . 126
❚
Transferring Images Automatically and Managing Them
on Your Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
❚
Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
❚
Viewing User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . .(PDF Files) . . 130
❚
User Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Using an Eye-Fi Wireless SD Memory Card to Transfer Images . (Eye-Fi) . 130
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
❚❙
Other Settings (Set Up) 135
Enabling Power Saving . . . . . . . . . . . . . . . . . . . . . . . . . . . (Power Saving) . 135
Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . (Screen) . 135
Turning off Eye-Fi Card Communication . . . . . . . . . . . . . . . . . . . . (Eye-Fi) . 135
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . 136
Configuring a Startup Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Startup) . 136
Specifying the File Name Serial Number Generation Rule . . . . . (File No.) . 137
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . 137
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . (Timestamp) . 138
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 139
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 139
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 140
Configuring Sleep State Settings . . . . . . . . . . . . . . . . . . . . . . . . . (Sleep) . 140
Configuring Auto Power Settings . . . . . . . . . . . . . . . . . . (Auto Power Off) . 141
Configuring [r] and [p] Settings . . . . . . . . . . . . . . . . . . . (REC/PLAY) . 141
Configuring USB Protocol Settings . . . . . . . . . . . . . . . . . . . . . . . . . (USB) . 142
Selecting the Screen Aspect Ratio and
Video Output System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Video Out) . 142
7
Contents
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . (Format) . 143
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . (Reset) . 143
❚❙
Configuring Monitor Screen Settings 144
Using the On-screen Histogram to Check Exposure . . . . . . . . . . . . . . . . . . 144
❚
How to Use the Histogram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
❚❙
Appendix 146
Precautions during Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
❚
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
❚
To replace the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
❚
Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
❚
Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
❚
To replace the memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Computer System Requirements for
Bundled Software . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Bundled CD-ROM) . 158
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
❚
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
❚
Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Number of Snapshots/Movie Recording Time/Voice Recording Time . . . . . 170
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
8
Contents
General Guide
The numbers in parentheses indicate the pages where each item is explained.
. Camera
Front
4213
5
67
Zoom controller
1
(pages 21, 42, 85, 86)
Shutter button (page 21)
2
[ON/OFF] (Power)
3
(page 20)
Microphone
4
(pages 48, 103)
Front lamp
5
(pages 24, 65, 71)
Lens
6
Flash (page 32)
7
Ô (Landscape)
8
(page 45)
Back
bl
89 bk
ckcl
½ (Make-up) (page 44)
9
[r] (REC) button
bk
(pages 20, 21)
Back lamp
bl
(pages 20, 22, 32)
[0] (movie) button
bm
(page 47)
Connector cover
bn
USB/AV port (pages
bo
87, 110, 118, 127)
Strap hole (page 2)
bp
[SET] button (page 28)
bq
bm
bqbrbsbt
bn
bo
[ ]
bp
[ ]
[ ]
[BS] button (page 51)
br
[MENU] button
bs
(page 60)
Control button
bt
([8][2][4][6])
(pages 26, 28, 32, 60,
144)
[p] (PLAY) button
ck
(pages 20, 25)
Monitor screen
cl
(pages 10, 144)
[
SET
[ ]
]
Bottom
.
Charger Unit
1
2
3
Battery/memory card slots (pages 15, 18, 154, 156)
cm
Tripod hole
cn
Use this hole when attaching to a tripod.
Speaker
co
cmcnco
+- Contacts
1
[CHARGE] Lamp
2
AC jack
3
9
Monitor Screen Contents
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
. Snapshot Recording
Metering mode (page 79)
9bk
bl
bm
bn
bo
bp
cr
cq
cp
co
4351768
2
bq
br
cn
cm
Remaining snapshot memory
1
capacity (page 170)
Movie image quality (page 77)
2
Self-timer (page 65)
3
Recording mode (page 21)
4
White balance setting (page 78)
5
Remaining movie memory capacity
6
(page 47)
Image deterioration indicator
7
(page 43)
NOTE
• If the current aperture, shutter speed, ISO sensitivity, or Auto Exposure is not
correct, the setting will turn orange when you half-press the shutter button.
bsbt
ck
clbo
8
Snapshot image size (page 29)
9
Snapshot image quality (page 76)
bk
Flash (page 32)
bl
AF Area (page 34)
bm
Lighting (page 35)
bn
ISO sensitivity (page 36)
bo
Continuous shutter (page 37)
bp
Face Detection/Make-up/Landscape
bq
(pages 39, 44, 45)
Exposure compensation (page 41)
br
Date/time (page 42)
bs
Timestamp indicator (page 138)
bt
Shutter speed
ck
Aperture value
cl
Focus frame (pages 21, 34)
cm
Battery level indicator (page 16)
cn
Histogram (page 144)
co
Anti Shake (page 70)
cp
Auto shutter (page 66)
cq
Focus mode (page 62)
cr
10
. Movie Recording
123
8
7 6
. Snapshot Viewing
2
bq
bp
bo blbkbmbn
. Movie Playback
1
23
7
Flash (page 32)
1
Recording mode (page 47)
2
4
5
31
White balance setting (page 78)
3
Remaining movie memory capacity (page 47)
4
Movie recording time (page 47)
5
Exposure compensation (page 41)
6
Battery level indicator (page 16)
7
Histogram (page 144)
8
File type
1
Protect indicator (page 100)
2
4
Folder name/file name (page 132)
3
Snapshot image quality (page 76)
5
4
Snapshot image size (page 29)
5
6
ISO sensitivity (page 36)
6
7
Aperture value
7
8
Shutter speed
8
9
Date/time (page 42)
9
Metering mode (page 79)
bk
White balance setting (page 97)
bl
Flash (page 32)
bm
Recording mode
bn
Battery level indicator (page 16)
bo
Histogram (page 144)
bp
Exposure compensation (page 41)
bq
File type
1
Protect indicator (page 100)
2
Folder name/file name (page 132)
3
4
Movie recording time (page 81)
4
5
Movie image quality (page 77)
5
Date/time (page 42)
6
Battery level indicator (page 16)
7
6
11
Quick Start Basics
What is a digital camera?
A digital camera stores images on a memory card, so you can record and
delete images a countless number of times.
Record
Delete
You can use the images you record in a variety of different ways.
Store images on your
computer.
Print images. Attach images to e-mail.
12
Play
Quick Start Basics
What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following three main functions.
Dynamic Photo
Extract a moving subject out of a series of Continuous Shutter images you
have shot and insert them into another image to create a Dynamic Photo
image that features the moving subject.
See page
105 for more information.
Make-up Mode/Landscape Mode
Pressing the ½ button sets the camera up to smooth the
skin texture of the subject and softens facial shadows
caused by harsh sunlight for better looking portraits.
Pressing the Ô button makes colors more vivid and
performs other processes to enhance the beauty of natural
scenery.
BEST SHOT
See pages
Simply select the sample scene you want and the
camera sets up automatically. Then all you need do is
press the shutter button for perfect images.
An AUTO BEST SHOT mode automatically selects the
appropriate BEST SHOT sample scene based on
current shooting conditions.
44 , 45 for more information.
See page
51 for more information.
D
13
Quick Start Basics
First, charge the battery prior to use.
Note that the battery of a newly purchased camera is not charged. Perform the steps
under “To charge the battery” to bring the battery to a full charge.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-90) for
power. Never try to use any other type of battery.
To charge the battery
1. Positioning the positive
+
and
negative - terminals of the
battery with those of the charger
unit, load the battery into the
charger unit.
2. Plug the charger unit into a
household power outlet.
About 180 minutes are required to
reach full charge. The [CHARGE] lamp
will go out when charging is complete.
Unplug the power cord from the power
outlet and then remove the battery
from the charger.
Lamp Status Description
Lit Red Charging
Flashing Red
Off Charging complete
Abnormal ambient temperature, charger problem, or
battery problem (page 154)
[CHARGE] lamp
E
14
Quick Start Basics
Other Charging Precautions
• Use the special charger (BC-90L) to charge the special lithium ion battery (NP-90).
Never use any other type of charger device. Attempting to use a different charger
can result in unexpected accident.
• A battery that is still warm due to normal use may not charge fully. Give the battery
time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the charger into an outlet that is further away from the TV or
radio.
• Actual charging time depends on current battery capacity and charging conditions.
To load the battery
1. Open the battery cover.
Slide the battery cover slider towards OPEN
and then open it as indicated by the arrows in
the illustration.
2. Load the battery.
With the EXILIM logo on the
battery facing downwards (in
the direction of the lens), hold
the stopper next to the battery
in the direction indicated by
the arrow as you slide the
battery into the camera. Press
the battery in until the stopper
secures it in place.
Stopper
3. Close the battery cover.
Close the battery cover and then shift the slider
towards LOCK.
• For information about how to replace the
battery, see page 154.
Battery contacts
EXILIM logo
1
2
Front
Back
2
1
15
Quick Start Basics
Checking Remaining Battery Power
As battery power is consumed, a battery indicator on the monitor screen indicates
remaining power as shown below.
Remaining Power High Low
Battery Indicator ***
Indicator Color Cyan * Amber * Red * Red
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• Leaving the camera for about two days with no power supplied while the battery is
dead will cause its date and time settings to be cleared. A message telling you to
configure time and date settings will appear the next time you turn on the camera
after restoring power. When this happens, configure date and time settings (page
139).
• See page 174 for information about battery life and memory capacity.
Battery Power Conservation Tips
• When you do not need to use the flash, select ? (Flash off) for the flash setting
(page 32).
• Enable the Auto Power Off and the Sleep features to protect against wasting
battery power when you forget to turn off the camera (pages 140, 141).
• Select “Off” for “Continuous AF” (page 70).
16
Quick Start Basics
Configuring Basic Settings the First Time You Turn On the Camera
The first time you load a battery into the camera, a screen appears for configuring the
display language, date, and time settings. Failure to set the date and time correctly
will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if
you purchased a camera intended for the Japanese market. To change the display
language from Japanese in this case, use the procedure under “Specifying the
Display Language (Language)” (page 140). Note that a version of this manual in
the language you select may not be included with a camera intended for the
Japanese market.
[ON/OFF]
1. Press [ON/OFF] to turn on the camera.
2. Use [8], [2], [4], and [6] to select the
language you want and then press
[SET].
[BS]
3. Use [8] and [2] to select a date style and then press [SET].
Example: 19. 12. 09
YY/MM/DD
DD/MM/YY
MM/DD/YY
* 09/12/19
* 19/12/09
* 12/19/09
4. Set the date and the time.
Use [4] and [6] to select the setting you want to
change and then use [8] and [2] to change it.
To switch between 12-hour and 24-hour format, press
[BS].
5. After setting the date and time, use [4] and [6]
to select “Apply” and then press [SET].
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: Page 140
– Date and time: Page 139
SET
17
Quick Start Basics
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
• Removing the battery from the camera too soon after configuring time and date
settings for the first time can cause the settings to be reset to their factory defaults.
Do not remove the battery for at least 24 hours after configuring settings.
Preparing a Memory Card
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 170.
Supported Memory Cards
– SD Memory Card
– SDHC Memory Card
Use one of the above types of memory card.
To load a memory card
1. Press [ON/OFF] to turn off the camera
and then open the battery cover.
Slide the battery cover slider towards OPEN
and then open it as indicated by the arrows in
the illustration.
2. Load a memory card.
Positioning the memory card so its front is
facing upwards (towards the monitor
screen side of the camera), slide it into
the card slot all the way in until you hear it
click securely into place.
18
1
2
Front
Front Back
Quick Start Basics
3. Close the battery cover.
Close the battery cover and then shift the slider
towards LOCK.
• For information about how to replace the
memory card, see page 156.
IMPORTANT!
• Never insert anything besides a supported memory card (page 18) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, remove the battery, and contact your retailer or nearest CASIO
authorized service center.
1
2
To format (initialize) a new memory card
You need to format a new memory card before using it for the first time.
1. Turn on the camera and press [MENU].
2. Select the “Set Up” tab, select “Format” and then press [6].
3. Use [8] and [2] to select “Format” and then press [SET].
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete
its contents. Normally you do not need to format a memory card again. However, if
storing to a card has slowed down or if you notice any other abnormality, re-format
the card.
• Be sure to use the camera to format a memory card. Formatting a memory card on
a computer and then using it in the camera can slow down data processing by the
camera. In the case of an SD or SDHC memory card, formatting on a computer can
result in non-conformity with the SD format, causing problems with compatibility,
operation, etc.
• Before formatting a new Eye-Fi card to use it for the first time, copy the Eye-Fi
Manager install files to your computer. Do this before formatting the card.
19
Quick Start Basics
Turning the Camera On and Off
To turn power on
To enter the REC Mode, press [ON/OFF] (Power) or
[r] (REC). To enter the PLAY mode, press [p]
(PLAY).
The back lamp will light (green) momentarily and the
camera will turn on. If you are entering the REC mode,
the lens will extend from the camera at this time.
• Take care to ensure that nothing is restricting or
coming into contact with the lens as it extends. Holding
the lens with your hand so it cannot extend creates the
risk of malfunction.
•Pressing [p] (PLAY) while in the REC mode switches
to the PLAY mode. The lens retracts about 10 seconds
after switching modes.
• The Sleep function or Auto Power Off (pages 140,
141) will turn off power automatically if you do not
perform any operation for a preset amount of time.
[ON/OFF] (Power)
Back lamp
[p]
(PLAY)
[r]
(REC)
To turn off the camera
Press [ON/OFF] (Power).
• You can configure the camera so power does not turn on when you press [r]
(REC) or [p] (PLAY). You also can configure the camera to turn off when you
press [r] (REC) or [p] (PLAY) (page 141).
20
Quick Start Basics
To shoot a snapshot
1. Press [r] (REC) to turn on the camera.
Make sure R is on the display. If it isn’t, see page 51.
Snapshot mode icon
Remaining Snapshot Memory
Capacity (page 170)
2. Point the camera
at the subject.
You can zoom the
image, if you want.
Zoom controller
Monitor screen
Shutter button
[r] (REC)
w Wide Angle z Telephoto
21
Quick Start Basics
3. Half-press the shutter button to
focus the image.
When focus is complete, the camera
will beep, the back lamp will light green,
and the focus frame will turn green.
Back lamp
Focus frame
Half-press
Press lightly
until the
button stops.
Beep, beep (Image is in focus.)
When you half-press the shutter button, the
camera automatically adjusts exposure and
focuses on the subject it is currently pointed
at. Mastering how much pressure is required
for a half-press and a full-press of the shutter
button is an important technique for goodlooking images.
• The focus frame in the screen shots
included in this manual is shown at ß.
Note that you can change the form of the
focus frame, if you want (page 72).
4. Continuing to keep the camera still, press the shutter button the rest of
the way down.
This records the snapshot.
Full-press
Snap (Image is recorded.)
Shooting a Movie
Press [0] (Movie) to start
movie recording. Press
[0] (Movie) again to stop
movie recording. See
page 47 for details.
[0] (Movie)
22
Quick Start Basics
. Using Quick Shutter
Fully pressing the shutting button without waiting for Auto Focus to operate will record
using Quick Shutter (page 73).
• With Quick Shutter, the camera focuses faster than normal Auto Focus, which
means you can capture quick moving action more easily. Note, however, that some
images may be out of focus when Quick Shutter is used.
• Whenever possible, take a little extra time to half-press the shutter button in order
to ensure proper focus.
. If the image does not focus...
If the focus frame stays red and the back lamp is flashing green, it means that the
image is not in focus (because the subject is too close, etc.) Re-point the camera at
the subject and try to focus again.
. If the subject is not in the center of the frame...
“Focus lock” (page 64) is the name of a technique you can use when you want to
shoot an image in which the subject to be focused on is not within the focus frame in
the center of the screen.
. To track the movement of a moving subject
Use [4] and [6] to follow and focus automatically on a moving subject, without halfpressing the shutter button. See “Ë Tracking” (page 34) for more information.
23
Quick Start Basics
Holding the Camera Correctly
Your images will not come out clearly if you move the camera when you press the
shutter button. When pressing the shutter button, be sure to hold the camera as
shown in the illustration below, and keep it still by pressing your arms firmly against
your sides as you shoot.
Holding the camera still, carefully press the shutter button and take care to avoid all
movement as the shutter releases and for a few moments after it releases. This is
especially important when available lighting is low, which slows down the shutter
speed.
Horizontal Vertical
Hold the camera so the flash is
above the lens.
NOTE
• Hold the camera securely in your left hand, with
your fingers around the grip on the right front of the
camera.
• Take care that your fingers and the strap do not
cover any of the areas indicated in the illustration.
• To protect against accidentally dropping the
camera, attach the wrist strap and make sure it is
around your fingers or wrist while you are operating
the camera.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this
camera only. Never use it for any other purpose.
Flash
Microphone
Front lamp
Lens
IMPORTANT!
• Take care to ensure that your fingers are not blocking or
are not too close to the flash. Fingers can cause unwanted
shadows when using the flash.
24
Quick Start Basics
Viewing Snapshots
Use the following procedure to view snapshots on the camera’s monitor screen.
• For information about how to play back movies, see page 81.
1. Press [p] (PLAY) to enter the
PLAY mode.
• This will display one of the snapshots
currently stored in memory.
• Information about the displayed
snapshot also is included (page 170).
• You also can clear the information to
view only the snapshot (page 144).
• You can zoom in on the image by
sliding the zoom controller towards z (page 85). If you are recording a
snapshot that is very important to you, it is recommended that you zoom the
image and check its details after recording it.
[p] (PLAY)
2. Use [4] and [6] to scroll between images.
• Holding down either button scrolls at high speed.
[6]
[6]
[4]
NOTE
• Half-pressing the shutter button while in the PLAY mode or while a menu screen is
displayed will switch directly to the REC mode.
25
[4]
Quick Start Basics
Deleting Images
If memory becomes full, you can delete images you no longer need to free up storage
and record more images.
IMPORTANT!
• Remember that a file (image) delete operation cannot be undone.
• Deleting an audio snapshot (page 103) deletes both the snapshot and the audio
file.
To delete a single file
1. Press [p] (PLAY) to enter the PLAY mode and then
press [2] ( ).
2. Use [4] and [6] to scroll through the files until the one you want to
delete is displayed.
3. Use [8] and [2] to select “Delete” and then press [SET].
• To delete other files, repeat steps 2 and 3.
• To exit the delete operation, press [MENU].
To delete all files
1. Press [p] (PLAY) to enter the PLAY mode and then press [2] ( ).
2. Use [8] and [2] to select “Delete All Files” and then press [SET].
3. Use [8] and [2] to select “Yes” and then press [SET] to delete all files.
This will cause the message “There are no files” to appear.
26
Quick Start Basics
Snapshot Shooting Precautions
Operation
• Never open the battery cover while the back lamp is flashing green. Doing so can
result in the image you just shot being saved incorrectly, damage to other images
stored in memory, malfunction of the camera, etc.
• If unwanted light is shining directly onto the lens, shade the lens with your hand
when shooting an image.
Monitor Screen when Shooting Snapshots
• Subject brightness conditions can cause monitor screen response to slow and can
cause digital noise in the monitor screen image.
• The image that appears on the monitor screen is for image composition. The actual
image will be recorded at the quality set for the image quality setting (page 76).
Shooting Indoors under Fluorescent Lighting
• Minute flickering of fluorescent lighting can affect the brightness or color of an
image.
Auto Focus Restrictions
• Any of the following can make proper focus impossible.
– Solid color wall or other very low contrast subject
– Strongly back lit subject
– Very shiny subject
– Blinds or other subject with a repeating horizontal pattern
– Multiple subjects at varying distances from the camera
– Subject in a dark location
– Subject that is too far away for light from the AF assist lamp to reach
– Camera movement while shooting
– Fast-moving subject
– Subjects outside the focus range of the camera
• If you cannot focus properly, try using focus lock (page 64) or Manual Focus (page
62).
27
Quick Start Basics
Snapshot Tutorial
Using the Control Panel
The Control Panel can be used to configure camera settings.
1. In the REC mode, press [SET].
This will select one of the Control Panel icons and display its settings.
[8] [2] [4] [6]
[SET]
Available settings
2. Use [8] and [2] to select the setting you want to change.
Image size/Quality* (pages 29, 76)
1
Flash (page 32)
2
AF Area (page 34)
3
Lighting (page 35)
4
ISO sensitivity (page 36)
5
Continuous shutter (page 37)
6
* Snapshot image quality cannot be changed using the Control Panel.
3. Use [4] and [6] to change the setting.
Control Panel
1
2
3
4
5
6
7
8
9
Face Detection/Make-up/Landscape
7
(pages 39, 44, 45)
EV shift (page 41)
8
Date/Time (page 42)
9
4. If you want to configure another setting, repeat steps 2 and 3.
5. After all of the settings are the way you want, press [SET].
This will apply the settings and return to the REC mode.
NOTE
• You also can configure settings other than those listed above (page 60).
• The Control Panel cannot be displayed while a Dynamic Photo, For YouTube, or
Voice Recording Operation is in progress.
28
Snapshot Tutorial
Specifying Control Panel Items
You can use the following procedure to specify the eight items you want on the
Control Panel.
1. While the Control Panel is displayed, press
[MENU].
• This will display a menu of Control Panel items, with
the items currently selected for display shown in
green.
2. Use [8], [2], [4], and [6] to select an item you
want on the Control Panel and then press [SET].
This will cause the lamp next to the item to light.
3. Repeat the above step to select eight items for the Control Panel.
After you select the eighth item, the camera switches to the REC mode and
displays the Control Panel.
• To exit the item select operation, press [MENU].
NOTE
• The “Date/Time” item at the bottom of the Control Panel is fixed and cannot be
changed.
• The screen shots in this manual show the initial default Control Panel items.
• To return the Control Panel items to their initial defaults, reset the camera (page
143).
Changing the Image Size (Size)
. Pixels
A digital camera image is a collection of small
dots called “pixels”. The more pixels there are
in an image, the more detail there will be.
However, you generally can do with fewer
pixels when printing an image (L size) through
a print service, attaching an image to e-mail,
when viewing the image on a computer, etc.
Pixel
29
Snapshot Tutorial
. About image sizes
The size of an image indicates how many pixels it contains, and is expressed as
horizontal pixels
8M (3264
Approximately 8 million pixels
x
vertical pixels.
x
2448) size image =
3264*
2448*
VGA (640x480) size image =
Approximately 300,000 pixels
640*
480*
* Unit: pixels
Image Size Selection Tips
Note that larger images have more pixels, so they take up more memory space.
Large Number
of Pixels
Small Number
of Pixels
More detail, but takes up more memory. Best
when you plan to print large-size prints (such
as A3 size).
Less detail, but takes up less memory. Best
when you want to send images by e-mail,
etc.
• For information about image size, image quality, and number of images that can be
stored, see page 170.
• For information about movie image size, see page 77.
• For information about resizing existing snapshots, see page 102.
30
Snapshot Tutorial
Loading...
