Casio EX-FR100 User's Guide

Download

Digital Camera

User’s Guide

Thank you for purchasing this CASIO product.

• Before using it, be sure to read the precautions contained in this User’s Guide.

• Keep the User’s Guide in a safe place for future reference.

• For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.com/

Accessories

As you unpack your camera, check to make sure that all accessories shown below are included. If anything is missing, contact your original retailer.

Camera

(EX-FR100)

Tripod nut Carabiner strap

Power cord* Micro USB cable Basic Reference

Controller

(EX-FR100CT)

Hinge Unit

• The hinge unit comes pre-attached to the camera.

USB-AC adaptor

(AD-C53U)

* The shape of the power cord plug varies according to the country or geographic

area where the camera is sold.

Read this first!

• The contents of this manual are subject to change without notice.

• The contents of this manual have been checked at each step of the production process. Feel free to contact us if you notice anything that is questionable, erroneous, etc.

• Any copying of the contents of this User’s Guide, either in part or its entirety, is forbidden. Except for your own personal use, any other use of the contents of this manual without the permission of CASIO COMPUTER CO., LTD. is forbidden under copyright laws.

• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.

• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost profits, or claims by third parties arising out of the use of the EXILIM Connect application software.

• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits caused by loss of memory contents due to malfunction, repair, or any other reason.

• Note that the example screens and product illustrations shown in this User’s Guide may differ somewhat from the screens and configuration of the actual camera.

LCD Panel

The liquid crystal panel of the monitor screen uses high-precision technology that provides a pixel yield in excess of 99.99%. This means that some very small number of pixels may not light or may remain lit at all times. This is due to the characteristics of the liquid crystal panel, and does not indicate malfunction.

Take test shots

Before shooting your final image, shoot a test shot to ensure that the camera is recording correctly.

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Monitor Screen Contents and How to Change Them . . . . . . . . . . . . . . . . . . . . 9



Quick Start Basics 12

What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Using the Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14



Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14



Hinge Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15



Tripod nut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16



Carabiner Strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Using the Touch Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Turning Power On and Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 28

Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30



Supported Memory Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30



To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31



To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

To Shoot a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33



Selecting an Auto Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33



To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38



Recording Images 39

To configure REC mode settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Selecting a Recording Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40



Shooting a Burst of Images . . . . . . . . . . . . . . . . . . . . . . . (High Speed CS). . . 41



Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Art Shot) . . . 42

Shooting Scenes of an Activity at a Fixed Interval . . . . (Interval Shooting) . . 43

Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Contents



Advanced Recording Settings 51

Using the REC Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51



Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Make-up). . . 52



Shooting by Touching the Monitor Screen . . . . . . . . . . . . (Touch Shooting). . . 52



Reducing Blur Due to Camera Movement

During Movie Recording . . . . . . . . . . . . . . . . . . . . . . . .(Movie Anti Shake). . . 53



Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Image Size) . . . 54



Movie Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . .(Movie Quality) . . . 55



Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . (Brightness). . . 55



Adjusting White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance). . . 56



Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 57



Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus) . . . 58



Self-shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Mirror). . . 59



Reducing Wind Noise during Movie Recording . . . . . . . . (Wind Noise Cut) . . . 59



Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review) . . . 60



Displaying a Grid on the Monitor Screen . . . . . . . . . . . . . . . . . . . . . . (Grid). . . 60



Viewing Snapshots and Movies 61

Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Viewing the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Creating a Movie of a Day’s Images . . . . . . . . . . . . . . . . (Highlight Movie) . . 63

Creating a Collage of a Day’s Snapshots . . . . . . . . . . . . (Highlight Photo) . . 65

Changing the Highlight Score of an Image . . . . . . . . . . . (Highlight Score) . . 66

Creating a Time Lapse Movie . . . . . . . . . . . . . . . . . . . . . . . . (Time Lapse) . . 67



Other Playback Functions (PLAY) 69

Using the PLAY Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69



Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Rotation). . . 70

Contents



Connecting the Camera with a Smartphone (Wireless Connection) 71

Controlling Your Camera with a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . 71

Using a Wireless Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Getting Ready to Establish a Connection between

a Smartphone and Your Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74



Installing the EXILIM Connect App on Your Smartphone . . . . . . . . . . . . . . . . . . 74



Establishing a Wireless Connection for the First Time . . . . . . . . . . . . . . . . . . . . 75

Using a Smartphone as a Camera Remote Controller (Shoot with phone) . . 77 Sending a Snapshot or Movie File from Camera Memory

to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . (Send Selected Image) . . 78

Viewing Snapshots and Movies in Camera Memory

on a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (View on phone) . . 79

Configuring Wireless Connection Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 80



Having Images Shot with the Camera Sent

to a Smartphone Automatically . . . . . . . . . . . . . . . . . . . . . . . . (Auto Send) . . . 80



Specifying Images to be Sent by Auto Send . . . . (Auto Send File Settings). . . 81



Resizing Snapshots before Sending Them

to a Smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize When Sending). . . 82



Changing the Camera Password for

Wireless LAN Connection . . . . . . . . . . . . . . . . . . . . . . . (WLAN password). . . 82



Unpairing the Camera from a Smartphone . . . . . . . . . . . . . . . . (Unpairing). . . 83



Printing 84

Printing with a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84



Using the Camera with a Computer 85

Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . . 85



Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 86



Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89



Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . . 89



Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Contents



Other Settings (Set Up) 95

Adjusting Monitor Screen Brightness . . . . . . . . . . . . . . . . . . . . . . (Screen) . . 95

Selecting Display Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Info) . . 95

Locking the Camera or Controller Screen Orientation . . . (Rotation Lock) . . 96

Configuring Camera Sound Settings . . . . . . . . . . . . . . . (Camera Sound) . . 96

Using the Vibration Function . . . . . . . . . . . . . . . . . . . . . . . . . . . (Vibration) . . 97

Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . . 97

Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . . 97

Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . . 98

Specifying the Controller Sleep State Trigger Time . . . . . . . . . . . . (Sleep) . . 98

Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . . (Format) . . 99

Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . . (Reset) . . 99

Checking the Current Camera Firmware Version . . . . . . . . . . . . (Version) . . 99



Appendix 100

Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Shock resistant, Splashproof, Dustproof . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111

Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124



Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124



Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125



Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Disposing of the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132



Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132



Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Number of Snapshots/Movie Recording Time . . . . . . . . . . . . . . . . . . . . . . . . 137

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Contents

General Guide

6789

21 3

bk bl

bo bp

Camera



Wireless LAN connection lamp (page 76)



Operation lamp (pages 20, 23)



[p] (Power) (page 26)



Memory card slot (page 31)



[RESET] button (page 132)



[CARD] cover (page 31)



Speaker



Lens (page 17)



Microphone (pages 17, 50)



Shutter button (page 34)



[0] (Movie) (page 48)



[FREE] lever (page 15)



[USB] port (pages 19, 22)



[USB] cover (pages 19, 22)



Strap holes

Controller



[USB] cover (pages 19, 22)



[RELEASE] button (page 14)



[RESET] button (page 132)



[USB] port (pages 19, 22)



Carabiner strap attachment bar (page 17)



Strap holes



[0] (Movie) (page 48)



Shutter button (page 34)



Operation lamp (pages 20, 23)



[p] (Power) (page 26)



Hinge unit slot (page 14)

Camera Controller

The numbers in parentheses indicate the pages where each item is explained.

cmcnco cp

bq br

bs bt

Monitor Screen Contents and How to Change Them

2 4 65 7 8



White Balance (page 56)



Focus mode (page 58)



Digital zoom (page 47)



Auto Send (page 80)



Remaining movie memory capacity (page 137)



Remaining snapshot memory capacity (page 137)



Snapshot image size (page 54)



Movie quality (pages 48, 55)



Touch Shooting function (page 52)



Movie Anti Shake (page 53)



ISO sensitivity (page 57)



Brightness (page 55)



Date/Time (pages 28, 97)



Camera battery level indicator (page 25)



Controller battery level indicator (page 25)



Communication status between camera and controller (page 26)



PLAY mode icon (page 28)



“ ” (Show Icons) icon



Interval Shooting icon (page 43)



Wireless mode icon (page 73)



Recording mode icon (page 40)



Menu icon (page 51)

The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status.

• The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes. They do not represent screens that actually appear on the camera.

. Snapshot Recording

. Movie Recording

NOTE

21 3

bs ck bt

543 6

bqbr bp bo

bk bl bm bn



Current image number/total number of grouped images (pages 41, 43)



Group images (High Speed CS (page 41), Interval Shooting (page 43))



Auto Send (page 80)



Protect indicator



Folder name-file name (page 92)



Snapshot image size (page 54)



Highlight Score (page 66)



Make-up (page 52)



White Balance (page 56)



ISO sensitivity (page 57)



Brightness (page 55)



Shutter speed



Image menu icon (p

age 62)



Camera battery level indicator (page 25)



Controller battery level indicator (page 25)



Date/time (pages 28, 97)



Communication status between camera and controller (page 26)



“ ” (Show Icons) icon



REC mode icon (page 28)



Delete icon (page 37)



Wireless mode icon (pages 73, 79)



Edit icon (pages 63, 65, 66, 67)



Menu icon (page 69)

Close-range indicator (page



Movie quality (



Movie recording time (page 49)



• If you do not perform any operation for about three seconds during snapshot recording or movie recording, icons will become transparent.

. Snapshot Viewing

pages 48, 55)

48)

NOTE

• The folder name and file name in the upper right corner of the monitor screen has

NOTE

1 2

the meaning described below (page 92). Example: 100-0023: 23rd image file in the folder named “100CASIO”.

. Movie Playback

Movie recording time (page 61)



Movie quality (pages 48, 55)



Highlight Score (page 66)



Image menu ico



Date/time (pages 28, 97)



“”

Movie play ico



“ ” (Show Icons) icon



• If you do not perform any operation for about three seconds during snapshot viewing or movie playback, icons will become transparent.

n (page 62)

n (page 61)

Quick Start Basics

*See page 14 for more information.

*See page 43 for more information.

*See page 42 for more information.

What you can do with your CASIO camera

Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following main functions.

. Shooting

A variety of shooting styles

The camera connects to the controller using Bluetooth® wireless technology (Bluetooth). You can hang it from your neck, mount it on a tripod, and select the shooting style that suits current conditions. The camera can also be rotated 90 degrees, which means you can change the orientation of a snapshot with little physical repositioning of the camera.

Interval Shooting

Shoot snapshots and/or movies at fixed intervals. It’s a great way to chronicle an activities or changes over time.

Art Shot

A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting.

Quick Start Basics

. Viewing

*See page 65 for more information.

*See page 63 for more information.

*See page 67 for more information.

*See page 71 for more information.

. Sharing

Highlight Photo

You can configure camera settings to automatically select snapshot highlights and generate a collage of them.

Highlight Movie

You can configure camera settings to automatically select snapshot and movie highlights, and create a movie of them.

Time Lapse

Creates a movie of snapshots you shot.

Wireless Connection

Turns your smartphone into a camera remote controller and allows you to select one or more snapshot and/or movie file in camera memory and send a copy to a smartphone.

Quick Start Basics

IMPORTANT!

Using the Attachment

Hinge unit slot

Align the 2 mark on the end of the hinge unit with the 8 mark next to the hinge unit slot.

[RELEASE] button

You can configure the camera to suit your specific needs by attaching the hinge unit, which enables attachment of the controller, and other included and optionally available attachments. This way you can configure the camera to suit your specific needs.

• Do not apply strong pressure to the surface of the monitor screen. Doing so can damage it.

• Never touch the lens with your fingers. Finger smudges, dirt, and other foreign matter on the lens can interfere with proper operation of the camera. Use a blower or other means to keep the lens and flash window free of dirt and dust, and wipe gently with a soft, dry cloth.

Controller

You can attach the controller to the camera and use the camera as a normal camera.

. To attach the controller

1. With the camera lens pointed in the

same direction as the controller’s monitor screen, slide the hinge unit into the controller’s hinge unit slot.

2. Push the hinge unit in until you hear it

click into place.

. To detach the controller

1. While holding down the controller’s

[RELEASE] button, pull it out of the camera.

Quick Start Basics

Hinge Unit

Lens ring

[FREE] lever

Indentations

AB C

[FREE] lever

. To use the hinge unit as a stand

. To change the shooting direction by 90 degrees

1. While pulling down on the camera’s [FREE]

lever, rotate the camera clockwise 90 degrees until you hear a click.

• Align the camera’s operation lamp with the C mark on the hinge unit.

• The indentations in the lens ring indicate the orientation of the long dimension of the image being shot.

. To remove the hinge unit from the camera

1. While pulling down on the camera’s [FREE]

lever, rotate the camera counterclockwise about 15 degrees until its operation lamp is aligned with the A mark on the hinge unit.

Quick Start Basics

2. Remove the hinge unit from the camera.

Tripod (commercially available)

Tripod nut

. To attach the hinge unit to the camera

1. Align the camera’s operation lamp with

the A mark on the hinge unit.

2. Rotate the camera clockwise about

15 degrees until its operation lamp is aligned with the B mark on the hinge unit.

Tripod nut

1. Use the tripod nut to secure a tripod

(commercially available) to the hinge unit.

Quick Start Basics

IMPORTANT!

NOTE

Carabiner Strap

flap

Microphone

Lens

1. Pass the carabiner strap belt around

the controller’s carabiner strap attachment bar.

2. Pass the belt through the buckle to

secure it.

Pull on the belt until the belt flap is passed all the way through the buckle.

3. Hook the flap on the buckle.

4. Pull on the carabiner and controller to confirm that

the flap is hooked on the buckle and is secure.

• The carabiner strap is not intended for mountain climbing use. It is designed only to support the camera.

• When shooting hold the camera still. Carefully press the shutter button and take care to avoid all movement as the shutter releases and for a few moments after it releases.

• Take care that your fingers and the strap do not cover any of the areas indicated in the illustration.

• Never swing the camera around by its strap.

• The supplied strap is intended for use with this camera only. Never use it for any other purpose.

Quick Start Basics

Using the Touch Panel

Monitor Screen

The monitor screen of the camera is a touch panel. This means you can perform the following operations by touching the screen with your fingers.

Touch

Momentarily touching the screen with your finger. Touch the screen to select an icon or menu item, and to configure settings.

Flick

Holding your finger against the screen as you flick it up, down, left, or right. Use flick to scroll forward through images.

Spread

Holding your thumb and forefinger against the screen as you spread them out. Use spread to enlarge the screen image.

Squeeze

Holding your thumb and forefinger against the screen as you bring them together. Use squeeze to reduce the size of the screen image, and to display multiple images.

IMPORTANT!

• Never use a pointed or hard object to perform screen operations. Doing so can damage the screen.

• The camera will have a hard time interpreting a screen operation made using your fingernails. Use the fleshy pad of your finger.

Quick Start Basics

NOTE

• Applying a commercially available LCD protective sheet will reduce the operation

NOTE

USB-AC adaptor

(AD-C53U)

When plugging in the connectors, orient this marking as described below. Camera : Towards the lens side Controller: Towards the monitor screen side

[USB] port

Micro USB cable (included with camera)

Power cord

[USB] cover

sensitivity of the monitor screen.

First, charge the battery prior to use.

The camera and the controller each have a built-in rechargeable lithium ion battery. The batteries are not charged when you purchase the camera, so you will need to charge both the camera and controller before using them. You can use either of the two following methods to charge the batteries.

• USB-AC adaptor

• USB connection to a computer (Using the included micro USB cable.)

. To charge with the USB-AC adaptor

While the camera and controller are turned off, connect in the sequence shown below. Charging time: Approximately 2 hours 55 minutes

• When disconnecting the USB-AC adaptor from the camera or controller, be sure to disconnect from them first.

• If you turn on the camera or controller while charging with the USB-AC adaptor, you will be able to perform normal recording operations. In this case, however, charging of the camera will be stopped while it is turned on.

Quick Start Basics

. Operation Lamp Indications

While power is off

Operation Lamp Status Meaning

Lit red Charging

Charging stopped due to abnormal internal

Flashing red

temperature, USB-AC adaptor problem, battery problem (page 124), timer operation.

Unlit Charging complete

While power is on

•Camera

Operation Lamp Status

Lit green

Slow red-amber flashing

Meaning

Camera turned on

Charging stopped

Charging

Charging stopped due to abnormal High speed red-green flashing

In sleep state

internal temperature, USB-AC adaptor

problem, battery problem (page 124),

timer operation.

Slow green flashing Charging complete

•Controller

Operation Lamp Status Meaning

Lit red Charging

Slow red-amber flashing Charging (sleep state)

High-speed green-amber flashing

Charging stopped due to abnormal internal temperature, USB-AC adaptor problem, battery problem (page 124), timer operation.

High-speed red-green flashing Same as above (sleep state)

Lit green Charging complete

Slow green flashing Charging complete (sleep state)

Quick Start Basics

IMPORTANT!

Camera

Controller

• A battery that has not been used for a long time and/or ambient temperature can cause charging to take longer than normal. These conditions may also cause the operation lamp to flash red. If this happens, refer to page 124.

• The USB-AC adaptor will become warm during charging. This is normal and does not indicate malfunction.

• The shape of the power plug depends on each country or geographic area.

If the operation lamp is not lit or flashing during charging, check the orientation of the USB cable connectors.

• Make sure that you insert the cable connector into the USB port until you feel it click securely into place. Failure to insert the connector fully can result in poor communication or malfunction.

• Note that even while the connector is fully inserted, you still will be able to see the metal part of the connector as shown in the illustration.

Quick Start Basics

. To charge using a USB connection to a computer

NOTE

USB

Micro USB cable

(included with camera)

[USB] port

USB port

Computer

(power turned on)

When plugging in the connectors, orient this marking as described below. Camera : Towards the lens side Controller: Towards the monitor screen side

[USB] cover

While the camera and controller are turned off, connect in the sequence shown below

(

, 

• If the camera or controller is on, hold down [p] (Power) to turn it off before connecting it to your computer. Charging time: Approximately 2 hours 55 minutes

• If you turn on the camera while charging over a USB connection to a computer is in progress, the camera will establish a USB connection with the computer. Charging will continue. Charging will also continue if you turn on the controller. Note that certain types of computers or connection environments may stop charging if supply power is low.

Quick Start Basics

. Operation Lamp Indications

While power is off

Operation Lamp Status Meaning

Lit red Charging

Charging stopped due to abnormal internal

Flashing red

temperature, USB-AC adaptor problem, battery problem (page 124), timer operation.

Unlit Charging complete

While power is on

•Camera

Operation Lamp Status Meaning

Lit amber Charging

Charging stopped due to abnormal internal

High speed red-green flashing

temperature, USB-AC adaptor problem, battery problem (page 124), timer operation.

Lit green Charging complete

•Controller

Operation Lamp Status Meaning

Lit amber Charging

Slow red-amber flashing Charging (sleep state)

High-speed green-amber flashing

Charging stopped due to abnormal internal temperature, USB-AC adaptor problem, battery problem (page 124), timer operation.

High-speed red-green flashing Same as above (sleep state)

Lit green Charging complete

Slow green flashing Charging complete (sleep state)

Quick Start Basics

IMPORTANT!

• The first time you connect the camera or controller to your computer with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.

• A battery that has not been used for a long time, certain types of computers, and connection conditions can cause charging to take longer than normal. These conditions may also cause the operation lamp to flash red. If this happens, refer to page 132.

• For faster charging, use of the supplied USB-AC adaptor is recommended.

• Charging is not performed while the connected computer is in the hibernate mode.

Other Charging Precautions

• With the two charging methods described above, you can charge the batteries. Never use any other type of charger device. Attempting to use a different charger can result in unexpected accident.

• This model can be charged only via from USB 2.0 specification USB port.

• USB charging devices and power supply devices are subject to fixed standards. Use of an inferior device or a device that is not up to standard can cause malfunction and/or failure of your camera.

• Operation is not guaranteed in the case of a computer built or modified by you. Even in the case of a commercially available computer, certain USB port specifications may make it impossible to charge via the USB cable.

• A battery that is still warm immediately after normal use may not charge fully. Give the battery time to cool before charging it.

• A battery discharges slightly while it is loaded in the camera or controller. Because of this, it is recommended that you charge the battery immediately before you need to use it.

• Charging the battery may cause interference with TV and radio reception. If this happens, plug the USB-AC adaptor into an outlet that is further away from the TV or radio.

• Actual charging time depends on current battery capacity and charging conditions.

• Do not use the USB-AC adaptor with any other device.

• Never use the power cord with another device.

• Use only the USB-AC adaptor and USB cable specified in this manual for charging. Use of any other type of devices may result in improper charging.

Quick Start Basics

Checking the Current Battery Level

As battery power is consumed, a battery indicator on the monitor screen indicates its current level as shown below.

Level High Low

Battery Indicator

Camera

Controller

***

Indicator Color White * White * Red * Red

indicates battery power is low. Charge the battery as soon as possible. indicates that the battery is about to go dead. Charge the battery immediately.

• The level shown by the battery indicator may change when you switch between the REC mode and PLAY mode.

• Leaving the camera for about 8 days with no power supplied while the battery is dead will cause its date and time settings to be cleared. A message telling you to configure time and date settings will appear the next time you turn on the camera after restoring power. When this happens, configure date and time settings (page

97).

• See page 141 for information about battery life and number of shots.

Quick Start Basics

IMPORTANT!

Turning Power On and Off

[p] (Power)

Operation lamp

[p] (Power)

Operation lamp

. Camera-Controller Wireless Connection (Bluetooth)

The camera and controller communicate over a Bluetooth wireless technology connection. Once you perform the “pairing” operation required for Bluetooth wireless technology connection, the camera and controller will automatically connect to each other whenever you turn them on. Note that the connection will be lost when the distance between the camera and controller becomes too great. The controller will turn off after a preset amount of time after the Bluetooth wireless technology connection is lost. The camera will remain on, so you can shoot images by pressing its shutter button.

• Your camera has Bluetooth wireless technology communication functionality built in. Avoid operating the camera (including camera standalone operations) inside of aircraft or anywhere else where wireless data communication is restricted.

. To turn on power

Both the camera and controller need to be turned on in order to use them.

Camera

Press [p] (Power).

• Turning on the camera causes the camera and controller operation lamps to light green, and automatically starts an operation to establish a Bluetooth wireless technology connection between the camera and controller. An image appears on the controller and shooting is enabled.

• The connection between the camera and controller is affected by their orientation and by the distance between them.

• The maximum range for shooting with the controller’s shutter button is around 10 meters (32.8'). The maximum range for viewing the image on the controller’s monitor screen is around five meters (16.4').

• If the connection is poor, the controller operation lamp will flash green and “ ” (Communication status between camera and controller) will appear on the monitor screen. Camera response may be slow if you perform an operation on the controller while communication conditions are bad. If this happens, try adjusting the orientation and the distance between the camera and controller.

Controller

Press [p] (Power).

Quick Start Basics

• Note the precautions below to ensure stable communication between the camera and controller. – Make sure nothing is blocking the gray areas

as shown in the illustrations.

– Point the back of the controller at the

camera.

– Make sure there are no obstacles in the path

between the camera and controller.

Sleep Mode

If you press [p] (Power) on the controller or if you do not perform any controller operation for the time specified by the “Sleep” setting on the Setup menu (page 98) while there is a Bluetooth wireless technology connection between the camera and controller, the camera and controller will enter a sleep state. The operation lamp slowly flashes green while the camera is in the sleep mode. To restore the controller display, press any controller button. A low-power Bluetooth wireless technology connection between the camera and controller is maintained even while they are in the sleep mode, so operation is quickly enabled when you are ready to use the camera and controller.

• If the distance between the camera and controller becomes to great or if communication conditions become bad while the camera is in the sleep mode, the connection may be dropped between them.

Quick Start Basics

Toggling Between the REC Mode and PLAY Mode

“”

(Show Icons)

Screen after “ ”

(Show Icons) is touched

“ ” (PLAY) / “ ” (REC)

In the REC mode, touch “ ” (PLAY).

• If “ ” (PLAY) is not displayed on

To enter the PLAY mode

To enter the REC mode

the screen, you can touching the Review image (page 60), or switch to the PLAY mode by touching “ ” (Show Icons) and then touching “ ” (PLAY).

In the PLAY mode, touch “ ” (Show Icons). On the screen image that appears, touch “ ” (REC).

. To turn off power

On the camera or the controller, hold down [p] (Power).

• Turning off the camera will cause the controller to turn off automatically.

• The camera will emit a sound when the camera is turned off. The camera turns off when the power down process is complete.

Configuring Basic Settings the First Time You Turn On the Camera

The first time you turn on the camera, a screen appears for configuring the display language, date, and time settings. Failure to set the date and time correctly will cause the wrong date and time data to be recorded with images.

IMPORTANT!

• Camera models sold in certain geographic areas may not support display language selection.

1. Turn on the camera and controller (page 26).

• If this is the first time you are turning on power, a language selection screen will appear. If the screen does not appear, check to make sure that the camera is turned on.

2. Flick (page 18) the controller screen upwards and downwards or touch

“ ”, “ ” until you find the language you want, and then touch to select it.

Quick Start Basics

3. Touch the date display format you want.

NOTE

12/24 hour switch icon

Example: July 10, 2016 YY/MM/DD DD/MM/YY MM/DD/YY

* 16/7/10 * 10/7/16 * 7/10/16

4. Set the date and the time.

• Touch the value you want to change (year, month, day, hour, minute) and then touch “ ”, “ ” to change it.

• To switch between 12-hour and 24-hour format, select “am (pm)”/“24h” and then touch “ ”, “ ” to change the setting.

5. When the date and time settings are the way

you want, touch “OK”.

If you make a mistake configuring display language, date, or time settings with the above procedure, refer to the following pages for information about how to correct the settings.

– Display language: Page 98 – Date and time: Page 97

• Each country controls its local time offset and the use of summer time, and so they are subject to change.

Quick Start Basics

Preparing a Memory Card

Though the camera has built-in memory that can be used to store images and movies, you probably will want to purchase a commercially available memory card for greater capacity. The camera does not come with a memory card. Images recorded while a memory card is loaded are saved to the memory card. When no memory card is loaded, images are saved to built-in memory.

• Snapshots and movies stored in built-in memory cannot be copied to a memory card.

• For information about memory capacities, see page 137.

Supported Memory Cards

– microSD Memory Card – microSDHC Memory Card – microSDXC Memory Card

• The above are supported memory card types as of September

2015.

• This camera supports use of microSD memory cards of the following types and capacities: microSD memory cards up to 2GB; microSDHC memory cards greater than 2GB, up to 32GB; microSDXC memory cards greater than 32GB, up to 2TB. Note that the ability to use any particular card with this camera, even if it satisfies the above capacity and type requirements, is not guaranteed.

Warning!

0 Memory cards are small and present a risk of accidentally being swallowed

by infants and young children. Keep memory cards out of the reach of infants and young children. If a memory card is ever swallowed accidentally, contact a physician immediately.

. Memory Card Handling Precautions

Certain types of memory cards can slow down processing speeds. In particular, highquality movies may not be able to be stored correctly. A slow memory card can take too much time to record data and result in breaks in the image and/or audio during playback.

Quick Start Basics

To load a memory card

Back

Front Back

1. Holding down camera’s [p]

(Power) to turn off the camera and then open the [CARD] cover.

2. Load a memory card.

Positioning the memory card so its back is facing upwards (towards the lens side of the camera), slide it into the card slot all the way in until you hear it click securely into place.

3. Close the [CARD] cover.

IMPORTANT!

• Never insert anything besides a supported memory card (page 30) into the memory card slot.

• Should water or any foreign object ever get into the card slot, immediately turn off the camera, and contact your retailer or nearest CASIO authorized service center.

Quick Start Basics

. To replace the memory card

IMPORTANT!

Press the memory card and then release it. This will cause it to pop out of the memory card slot slightly. Pull the card out the rest of the way and then insert another one.

• Turn off the camera before replacing the memory card. Replacing the card while the camera is on can result in recorded images not being saved and even damage the memory card.

To format (initialize) a new memory card

Format a memory card on the camera before using it for the first time.

• Formatting a memory card that already has snapshots or other files on it, will delete its contents. Normally you do not need to format a memory card again. However, if storing to a card has slowed down or if you notice any other abnormality, re-format the card.

• Be sure to use the camera to format a memory card. Formatting a card on a computer will result in a non-SD standard format, which can greatly slow down processing time and cause compatibility, performance, and other problems.

1. Load a memory card (page 31).

2. Turn on the camera and controller, and then touch “ ” (Show

Icons).

3. Touch “MENU”.

4. Touch the “¥ Setup” tab.

5. Flick upwards and downwards until you find “Format”, and then touch

it.

6. Touch “Format” and then touch “Yes”.

This starts the memory card format operation.

Quick Start Basics

To Shoot a Snapshot

Recording mode icon

Your camera has a variety of different recording modes to suit various shooting conditions and objectives (page 40). This section explains general shooting procedures using the auto recording mode.

Selecting an Auto Recording Mode

You can select one of two auto recording modes (Auto or Premium Auto Pro) according to your digital imaging needs.

Setting

Auto This is the standard Auto recording mode.

Premium

Auto Pro

REC Screen Icon Display

Description

With Premium Auto Pro recording, the camera automatically determines whether you are shooting a subject or scenery, and other conditions. Premium Auto Pro recording delivers higher image quality than standard Auto recording.

• Some of the settings configured automatically by Premium Auto Pro cannot be changed by you.

• It also requires more power (and runs down the battery quicker) than Auto.

• This recording mode is recommended when you plan to create a Highlight Photo or Highlight Movie.

1. Turn on the camera and controller (page 26).

This causes the camera and controller to start up on the REC mode.

2. Touch “ ” (Show Icons).

3. Touch the second icon from the top (second

icon from the right in the case of portrait display orientation) (Recording mode).

4. Touch “Auto” or “Premium Auto Pro” to select

the auto recording mode you want.

Quick Start Basics

NOTE

To shoot a snapshot

Type of shot

(Telephoto) – (Wide Angle)

Shutter button

Camera

Controller

[0] (Movie)

Shutter button

Operation lamp

1. Point the camera at the subject.

If you are using Premium Auto Pro, an icon will appear on the monitor screen describing the type of shot the camera has detected.

• You can change display the zoom screen by holding two fingers against the screen and spreading them apart (page 47).

2. Press the camera or controller shutter button.

The camera will automatically adjust exposure and focus, and then shoot the snapshot.

• Normally, shooting a snapshot will cause the operation lamp to flash red once. Note, however, that the operation lamp will not flash while “Macro” is selected as the focus mode.

Shooting a Movie

Press [0] (Movie) on the camera or controller to start movie recording. To stop movie recording, press [0] (Movie) again. See page 48 for details.

• You also touch a location on the screen to focus on it, and then shoot the image (page 52).

• You can specify the image size for snapshots. See page 54 for more information.

• The operation lamp flashes red while movie recording is in progress.

. Shooting with the Camera Alone

You can use the camera in a stand-alone configuration without turning on the controller or otherwise establishing a connection between it and the camera.

• If an Interval Shooting (page 43) operation or movie recording (page 48) is in progress, it will continue to shoot images even when controller power is turned off.

Quick Start Basics

. Shooting with Premium Auto Pro

• Some menu items are not available while Premium Auto Pro is in use (page 51).

• In addition to shutter speed and ISO sensitivity, the camera automatically executes the following operation as required when shooting with Premium Auto Pro. – Auto Focus is normally performed until you touch the monitor screen. – The camera automatically determines the focus point on the screen and focuses

there.

• When shooting with Premium Auto Pro, the message “Processing Premium Auto. Please wait...” may appear on the monitor screen. If you feel the camera is taking too long to process data, try shooting with standard Auto instead.

• In some cases, Premium Auto Pro may not be able to interpret the shooting environment correctly. If this happens, shoot with standard Auto.

• If “HS” is displayed, the camera will shoot a series of CS images and merge them into a final image. Take care to avoid any camera and subject movement until shooting of all of the CS images is complete.

Quick Start Basics

NOTE

Viewing Snapshots

“” (PLAY)

Use the following procedure to view snapshots on the camera’s monitor screen.

• For information about how to play back movies, see page 61.

1. Touch “ ” (PLAY) to enter the PLAY mode.

This will display one of the snapshots currently stored in memory.

• You can also enter the PLAY mode by touching the review image screen (page 60).

• Information about the displayed snapshot also is included (page 10).

• You also can clear the information to view only the snapshot (page 95).

• You can zoom the screen image by touching the monitor screen (page 62). If you are recording a snapshot that is very important to you, it is recommended that you zoom the image and check its details after recording it.

2. Flick left or right across the screen image to scroll through the

snapshots.

• Pressing the controller shutter button while in the PLAY mode or while a menu screen is displayed will switch directly to the REC mode.

• A question mark (?) will be displayed for images that cannot be displayed for some reason.

Quick Start Basics

Deleting Snapshots and Movies

If memory becomes full, you can delete snapshots and movies you no longer need in order to free up storage and record more images.

IMPORTANT!

• Remember that a file (image) delete operation cannot be undone.

. To delete a single file

1. Enter the PLAY mode.

2. Touch “ ” (Show Icons).

3. Touch “ ”.

4. Touch “Delete 1 File”.

5. Flick the screen the left or right to scroll through

images until the one you want to delete is displayed.

6. Touch “ ” (Delete).

This will delete the selected image.

. To delete all files

1. Enter the PLAY mode.

2. Touch “ ” (Show Icons).

3. Touch “ ”.

4. Touch “Delete All Files”.

5. Touch “Delete”.

This will cause the message “There are no files.” to appear.

Quick Start Basics

Snapshot Shooting Precautions

Operation

• If unwanted light is shining onto the lens, shade the lens with your hand when shooting an image.

Monitor Screen when Shooting Snapshots

• Subject brightness conditions can cause monitor screen response to slow and can cause digital noise in the monitor screen image.

• The image that appears on the monitor screen is for image composition. The actual image will be recorded in accordance with the currently selected recording mode (page 40).

Shooting Indoors under Fluorescent Lighting

• Minute flickering of fluorescent lighting can affect the brightness or color of an image.

Other Precautions

• A noise reduction process is performed when ISO sensitivity is set to a high value. This can cause the camera to take relatively longer to be ready to shoot again after you press the shutter button. Do not perform any operation while the image recording operation is in progress.

• Due to the characteristics of the imaging element used by the camera, very fast moving objects in an image may appear distorted.

. Auto Focus Restrictions

• Any of the following can make proper focus impossible. – Solid color wall or other very low contrast subject – Strongly back lit subject – Very shiny subject – Blinds or other subject with a repeating horizontal pattern – Multiple subjects at varying distances from the camera – Subject in a dark location – Camera movement while shooting – Fast-moving subject – Subjects outside the focus range of the camera

• Focus lock can be used in some recording modes. If you cannot focus properly, try using focus lock (page 53).

Quick Start Basics

Recording Images

[p] (Power)

Touching the monitor screen in the REC mode will display a screen for configuring REC mode settings.

To configure REC mode settings

1. Press [p] (Power) to turn on the camera and enter the REC mode.

• If the camera is in the PLAY mode, touch “ ” (REC) to enter the REC mode.

2. Touch “ ” (Show Icons).

3. Touch the item whose setting you want to change.

Menu (page 51)*



Recording mode (page 40)



Wireless mode (page 73)



Interval Shooting mode (page 43)



PLAY mode (page 28)



1 2 3 4 5

* Depending on the recording mode, some of the items on the menu that

appears may not be usable.

Recording Images

Selecting a Recording Mode

Recording mode icon

The camera has a variety of different recording modes.

1. In the REC mode, touch the “ ” (Show

Icons).

2. Touch the recording mode icon.

3. Touch the icon of the recording mode you want

to use.

This enters the selected recording mode.

Auto

Premium Auto

Pro

Õ High Speed CS

Art Shot

Standard Auto recording mode. This is the mode normally used for shooting (page 33).

High Speed CS lets you shoot a burst of 30 images (page

41).

A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting (page

42).

Recording Images

Shooting a Burst of Images (High Speed CS)

Use the procedure below to shoot a burst of images.

1. In the REC mode, touch “ ” (Show Icons).

2. Touch the recording mode icon.

3. Touch “Õ” (High Speed CS).

4. Touch the scene that matches what you want to shoot.

Scene Description

High Speed CS 30 fps High-speed shooting of 30 images in one second.

High Speed CS Prerecord

• Touching “ ” on the screen and then touching a High Speed CS scene displays detailed information about the scene.

• If you selected “High Speed CS 30 fps”, go to step 6.

• If you selected “High Speed CS Prerecord”, go to step 5.

Pressing the shutter button will store 15 pre-recorded images along with 15 CS images that are shot after the shutter button is pressed.

5. Touch “Pre REC”.

This will start pre-recording of a group of images that will be continually updated until you press the shutter button.

• To stop the pre-record operation of images, touch “ ”.

6. Press the shutter button.

This will shoot 30 CS images.

Recording Images

NOTE

Shooting with Artistic Effects (Art Shot)

A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting.

Scene Description

Toy Camera

Soft Focus Overall blurring for a soft and romantic effect.

Light Tone Weakened contrast for a feeling of airy refinement.

Sepia Sepia tones create a decidedly retro look.

Monochrome

Dark edges and altered hues make images look like they were shot by a toy camera.

All of the strong contrast and graininess of a black and white print.

1. In the REC mode, touch the “ ” (Show Icons).

2. Touch the recording mode icon.

3. Touch “C” (Art Shot).

4. Touch the Art Shot scene you want to use.

• Touch “ ”, “ ” to display another scene.

• Touching “ ” on the monitor screen and then touching an Art Shot scene will display detailed information about the scene.

5. Press the shutter button to shoot.

• If you record a movie while an Art Shot scene is selected, the Art Shot effects will not be applied to the movie image.

• Sample images shown on Art Shot scene screens were not shot with this camera.

• An image shot with an Art Shot scene cannot be converted to a normal image without the Art Shot effect.

Recording Images

Shooting Scenes of an Activity at a Fixed Interval

Interval Shooting mode icon

(Interval Shooting)

You can use Interval Shooting to shoot snapshots and movies automatically at a specified interval.

Scene

Standard Shoots at a fixed interval.

Intelligent Shoots after determining the optimum setup.

Hiking Shoots using a setup optimized for hiking.

Cycling Shoots using a setup optimized for cycling.

Snow & Water

Leisure

REC Screen Icon Display

Description

Shoots using a setup optimized for snow and water sports.

Shoots using a setup optimized for leisure and trips.

Scenes marked with “ ” mark (non-Standard scenes)

• With these scenes, the “Interval” setting is a rough guide only, and the actual interval depends on decisions made by the camera about shooting conditions. Because of this, the actual shooting interval may be different from the setting.

• A five-second interval cannot be set for these scenes.

. To start an Interval Shooting operation

1. In the REC mode, touch the “ ” (Show Icons).

2. Touch the Interval Shooting mode icon.

3. Touch the Interval Shooting scene you want to

use.

• Touching “ ” will display a detailed explanation about each scene. Flick upwards or downwards on the monitor screen to scroll through scenes. When the one you want is displayed, touch its icon.

4. Touch “ ”

Recording Images

5. Touch an item and then change its setting.

Interval

Shooting Style

Allows selection of one of the shooting intervals below. 5 sec, 15 sec, 30 sec, 1 min, 2 min

t³:

Shoots five snapshots followed by a five-second movie.

³ Only:

Shoots a five-second movie. Audio is also recorded with this setting.

t Only: Shoots a snapshot.

• When “5 sec” is selected for the “Interval” setting, the movie recording time is two seconds.

6. Touch “ ” (Back).

7. Touch “Start”.

This starts the operation.

• Starting Interval Shooting operation causes the camera and controller to enter a sleep state and standby for recording of the images. This will be indicated by the camera’s operation lamp flashing green. Note that the camera will not enter the sleep state if “5 sec” is selected for the “Interval” setting.

• To recover from the sleep state, press any controller button. Next, touching “ ” on the monitor screen will display the number of recorded images. The maximum number of shots is 9,999.

Recording Images

NOTE

• Anti-shake is applied in accordance with the current camera settings. However, image anti-shake is not applied.

• The current shooting setup, including zoom, cannot be changed while shooting with this function.

• The Review image is displayed only when “Type 1” is selected as the Review image type (page 60).

• If the camera battery goes dead during an Interval Shooting operation, the operation will terminate. The controller battery going dead does not affect an ongoing operation. To stop the Interval Shooting operation in this case, hold down [p] (Power) on the camera.

• If you are performing manual camera operations or if the camera is out of the sleep state when the Interval Shooting operation reaches a shooting interval, Interval Shooting recording for that interval will be skipped.

• Pressing the controller’s [p] (Power) button while the camera is out of the sleep state will return to the sleep state and restart the Interval Snapshot operation.

• Initial default settings depend on the selected scene.

• If you change any settings, they are retained when you turn the camera off. To restore initial default settings, perform a reset operation (page 99) to reset the camera.

• Certain environments may cause the shooting interval to be longer than normal.

Recording Images

. To stop an Interval Shooting operation

NOTE

1. On the controller, press any button to recover from the sleep state.

2. Touch “ ” icon.

3. Touch “Yes”.

This stops the Interval Shooting operation.

. To shoot images manually during an Interval Shooting operation

You can shoot snapshots and movies manually even while an Interval Shooting operation is in progress.

1. On the controller, press any button to recover from the sleep state.

2. Perform the required controller or camera operation to shoot the image

you want.

• You can also press the camera’s shutter button or [0] (Movie) button to shoot while the camera is in the sleep state.

• After an Interval Shooting operation is complete, the recording mode will return to Premium Auto Pro.

Recording Images

NOTE

Shooting with Zoom

Telephoto Wide Angle

Your camera is equipped with digital zoom, that lets you zoom an image up to 4X. Note that a digital process is used to enlarge the center of the image, so there is deterioration of image quality.

1. Perform the required screen operation to change the zoom factor as

desired.

Zoom in: Touch “+”, or spread Zoom out: Touch “–”, or squeeze

Telephoto : Enlarges the subject and narrows the range. Wide Angle : Reduces the size of the subject and broadens the range.

2. Press the shutter button to shoot the image.

• Telephoto images are prone to blurring caused by camera movement when you press the shutter button. Because of this, stabilizing the camera by placing it on a level surface, etc. is recommended.

• Zoom operations are disabled while shooting with Interval Shooting.

• Zoom operations are disabled during movie recording. Perform the zoom operation before you start recording.

•“Ù” is displayed on the monitor screen while digital zoom is being used.

Recording Images

To record a movie

The following procedure explains how to record a movie.

1. In the REC mode, touch “ ” (Show Icons).

2. Touch “MENU”.

3. Touch “ ”, “ ” until you find “Movie Quality”, and then touch to

select it.

4. Touch the item whose setting you want to change.

Movie Quality

Full HD 30fps 1920

STD 30fps 640

HS240 240fps 512

REC Screen Icon Display

Frame Rate

Image Size (Pixels)

1080

480

384

Description

Select this setting to record full high-definition (Full HD) movies. The aspect ratio of movies recorded with this setting is 16:9.

Use this setting for standard movie recording. Shooting is performed using an aspect ratio of 4:3.

Select this setting to record high speed movies at a speed of 240 fps.

• Audio is not recorded.

5. To close the menu screen, touch “ ” or press the shutter button.

Recording Images

6. Press [0] (Movie).

Recording time

This will start recording.

• Monaural audio is also recorded during movie recording while “Full HD” or “STD” is selected for the movie quality setting.

• When “Full HD” or “STD” is selected for the movie quality setting, you can touch a point on the controller screen while movie recording is in progress to focus on that point. Note, however, that touching the screen will not perform a focus operation if the Touch Shooting setting (page 52) is “Off”.

7. Press [0] (Movie) to stop recording.

• Each movie can be up to 29 minutes or 4 GB long. Movie recording also will stop automatically if memory becomes full before you stop movie recording.

Recording Movies with Premium Auto Pro

When Premium Auto Pro is enabled (page 33), the camera automatically make judgments about the subject, shooting conditions, and other parameters. The result is higher quality images than those produced by Auto recording.

• Premium Auto Pro is enabled for Full HD movies and STD movies only.

• Using Premium Auto Pro uses up the battery charge more quickly than using Auto recording.

Minimizing the Effects of Camera Movement during Movie Recording

While the image quality setting is “Full HD” or “STD”, you can reduce blur due to camera movement during movie recording by selecting the “Standard” or “Strong” setting for “Movie Anti Shake” (page 53). Note, however, that image stabilization does not prevent image blur due to subject movement during movie recording. Also, image stabilization results in a narrower angle of view during movie recording. Though selecting “Strong” for the Movie Anti Shake setting will increase the anti shake effect, it can also increase the chance horizontal banding in the image due to light source flicker (caused by fluorescent lighting).

High Speed Movie Recording Precautions

• When shooting a high speed movie, shoot in a well-lit environment.

• When recording a high speed movie, light source flicker can cause horizontal bands to appear in the image. This does not indicate malfunction of the camera.

Recording Images

Movie Recording Focus Position

NOTE

Microphone

When the focus mode setting is “AF” or “PF”, recording is performed using pan focus, which provides a deep depth of field and suppresses image blurring. When the focus mode setting is “Macro”, the image is automatically focused and fixed before recording starts. Also, you can touch a location on the monitor screen during movie recording to focus at that location. Note, however, that touching the screen will not perform a focus operation in the following cases.

• “Off” selected for the Touch Shooting setting

• “PF” selected for the focus setting

• “HS240” is selected for the movie quality setting

IMPORTANT!

• Spending a long time using movie recording will cause the camera to become slightly warm to the touch. This is normal and does not indicate malfunction.

• The camera also records audio along with Full HD and STD movies. Note the following points when shooting a movie. – Take care that the microphone is not blocked by your

fingers, etc.

– Good audio recording results are not possible when the

camera is too far away from what you are trying to record.

• Shooting movies for long periods in areas where temperature is relatively high can cause digital noise (dots of light) to appear in the movie image. A rise in the camera’s internal temperature also may force movie recording to stop automatically. If this happens, stop recording and allow the camera to cool down, which should cause normal operation to resume.

• Use of the camera’s built-in memory or certain types of memory cards can slow down processing speeds. In particular, high-quality movies may not be able to be stored correctly. A slow memory card can take too much time to record data and result in breaks in the image and/or audio during playback.

• Zoom operations are disabled during movie recording. To use zoom, perform the zoom operation before you press [0] (Movie) to start recording.

• You can focus at a particular point before starting movie recording. On the controller screen, touch the location where you want to focus, and then start recording.

• The Make-up function cannot be used during movie recording.

Recording Images

Advanced Recording Settings

NOTE

Tabs

Items

Procedure

Enter the REC Mode * MENU * “rREC MENU” Tab * Touch Shooting

The following are menu operations you can use to configure various camera settings.

Using the REC Menu

. Example Menu Screen Operation

1. In the REC mode, touch “ ” (Show

Icons).

2. Touch “MENU”.

This will display the menu screen.

• Menu contents are different in the REC mode and PLAY mode.

3. Touch the tab where the menu item you want

to configure is located.

4. Flick upwards and downwards until you find the item whose setting

you want to change.

• To cancel and exit the menu, touch “ ” or press the controller’s shutter button.

5. Touch the item.

6. Configure the setting of the item in accordance with the screen

contents.

• To navigate back to the previous menu level, touch “ ”.

• Depending on the recording mode, some of the items on the menu that appears may not be usable. Nothing will happen if you touch an unusable item.

. Menu Operations in This Manual

Menu operations are represented in this manual as shown below. Touch the indicated icons and items, and perform operations as they are indicated, from left to right.

Advanced Recording Settings

Procedure

NOTE

Procedure

NOTE

Recording Beautiful Portraits (Make-up)

Enter the REC mode * MENU * “rREC MENU” Tab * Make-up

Make-up enables adjustment of human skin tone hues and texture, and softening of facial shadows caused by harsh sunlight for better looking portraits.

Skin Tone “Tan +6” to “0 (Off)” to “Light +6”

Smooth Skin “0 (Off)” to “+12 (Max.)”

• Make-up is disabled while shooting with the following feature. High Speed CS, Art Shot

Shooting by Touching the Monitor Screen (Touch Shooting)

Enter the REC mode * MENU * “rREC MENU” Tab * Touch Shooting

When you touch a location on the screen, the camera focuses on that location and shoots.

AF + Shoot

AF Only

Off Touch Shooting disabled.

• When using Touch Shooting to focus, select “AF” or “Macro” as the focus mode (page 58).

• If the focus frame remains red and the camera’s operation lamp flashes green while the “AF Only” setting is selected, it means that the image is not in focus (because the subject is too close, etc.) If this happens, point the camera at the subject and try focusing again.

• Touch Shooting cannot be used while the camera is configured with either of the settings below. – Recording Mode: High Speed CS Prerecord

The camera performs Auto Focus at the spot you touch and then shoots.

The camera performs Auto Focus at the spot you touch and locks focus (Focus Lock).

Advanced Recording Settings

Using Focus Lock

NOTE

Procedure

NOTE

Focus frame

Subject to be focused on

Use “focus lock” when you want to focus on a particular person or object. To use focus lock, configure the camera settings below. Touch Shooting: AF Only Focus Mode: AF or Macro

1. Touch the subject you want to focus on.

2. When you are ready to shoot the image,

press the shutter button.

• Focus lock also locks exposure (AE) and white balance.

• Focus lock is cancelled if you touch the screen, or about five minutes after focus lock is activated.

Reducing Blur Due to Camera Movement During Movie Recording (Movie Anti Shake)

Enter the REC mode * MENU * “rREC MENU” Tab * Movie Anti Shake

You can reduce blur due to camera movement during movie recording by selecting the (Standard) or (Strong) setting. However, image anti-shake is not used. Also, Anti Shake results in a narrower angle of view during movie recording.

• Movie Anti Shake is not supported during High Speed Movie recording.

Advanced Recording Settings

Procedure

Changing the Image Size (Image Size)

Pixel

Enter the REC Mode * MENU * “rREC MENU” Tab * Image Size

This setting can be used to configure snapshot image size.

Image Size (Pixels)

12M

(4000

3000)

(2560

1920)

REC Screen Icon Display

Suggested Print Size and

Description

Application

Good detail for better clarity even

Poster Print

for images cropped from the original on a computer, etc.

A4 Print Good detail

• The initial factory default image size setting is 12M (12 million pixels).

• You should regard the print paper sizes suggested here as guidelines only (200 dpi print resolution).

. Pixels and image size

A digital camera image is a collection of small dots called “pixels”. The more pixels there are in an image, the more detail there will be. However, you generally can do with fewer pixels when printing an image (L size) through a print service, attaching an image to e-mail, when viewing the image on a computer, etc. The size of an image indicates how many pixels it contains, and is expressed as horizontal pixels

• Note that larger images have more pixels, so they take up more memory space.

• For information about image size and number of images that can be stored, see page 137.

• For information about movie image size, see page 137.

vertical pixels.

Advanced Recording Settings

Procedure

NOTE

Movie Image Quality Settings (Movie Quality)

Decreases the EV value. A lower EV value is best for dark-color subjects and for shooting outdoors on a clear day.

Increases the EV value. A higher EV value is best for light-colored subjects and backlit subjects.

Enter the REC Mode * MENU * “rREC MENU” Tab * Movie Quality

This setting can be used to configure movie image quality settings and to select either normal movie recording or High Speed Movie recording. For information about movie image quality settings, see page 48.

Correcting Image Brightness (Brightness)

Enter the REC Mode * MENU * “rREC MENU” Tab * Brightness

You can manually adjust an image’s exposure value (EV value) before shooting it. The exposure compensation value you set remains in effect until you change it or turn off the camera (which causes it to revert to “0.0”).

– Exposure Compensation Range: –2.0 EV to +2.0 EV – Unit: 1/3 EV

• To cancel exposure compensation, change the EV value to 0.0.

• When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even after performing exposure compensation.

Advanced Recording Settings

Procedure

Adjusting White Balance (White Balance)

Blank white paper

Enter the REC Mode * MENU * “rREC MENU” Tab * White Balance

You can adjust white balance to match the source of light available where you are shooting and avoid the blue cast that results when shooting outdoors when it is cloudy, and the green cast that results when shooting under fluorescent lighting.

1. Touch the type of white balance you want to select.

You can see the affect of the white balance setting you select on the monitor screen.

Setting Description

Configures the camera to adjust white balance automatically

For shooting outdoors on an overcast rainy day, in the shade, etc.

For shooting on a clear day in the shade of trees or buildings

For shooting under white or day white fluorescent lighting

For configuring the camera manually to suit a particular light source.

Touch “· Manual WB”.



In the location where you plan to



shoot, point the camera at a blank white piece of paper so it fills the entire monitor screen. Touch an area of the screen



where no icon is located. The white balance setting is retained even if you turn off the camera.

• When “‡Auto WB” is selected for the white balance setting, the camera automatically determines the white point of the subject. Certain subject colors and light source conditions can cause problems when the camera tries to determine the white point, which makes proper white balance adjustment impossible. If this happens, select the white balance setting that matches your shooting conditions (Daylight, Overcast, etc.).

• When shooting with Premium Auto Pro, the white balance setting is fixed at “‡Auto WB”.

Auto WB

Daylight For shooting outdoors on a clear day

Overcast

Shade

Day White Fl.

Daylight Fluor For shooting under daylight fluorescent lighting

Tungsten For shooting under light bulb lighting

Manual WB

Advanced Recording Settings

Procedure

Specifying ISO Sensitivity (ISO)

Enter the REC Mode * MENU * “rREC MENU” Tab * ISO

ISO sensitivity is a measure of sensitivity to light.

Setting Description

Auto Adjusts sensitivity automatically according to conditions

ISO64

Lower

sensitivity

ISO100

ISO200

ISO400

ISO800

ISO1600

ISO3200

Higher

sensitivity

• Since higher ISO sensitivity values tend to result in digital noise in images, the camera performs a noise filtering process. Because of this, it may take relatively longer for the camera to finish recording an image after it is shot. You will not be able to perform any operation while image recording is in progress.

• When shooting with Premium Auto Pro, the ISO setting is fixed at “Auto”.

Slow shutter speed

Fast shutter speed (Set

for shooting in dimly lit

areas.)

Less noise

Some coarseness

(increased digital noise)

Advanced Recording Settings

Procedure

NOTE

Selecting a Focus Mode (Focus)

Enter the REC Mode * MENU * “rREC MENU” Tab * Focus

Changing to a different focus mode can help to achieve better focus.

Settings

AF (Auto Focus)

Macro

REC Screen Icon Display

None

Type of Shot

General recording

Close ups Automatic

Shooting

PF (Pan Focus)

with a relatively wide focus range

*1 The focus range is the distance from the lens surface. *2 Focus remains fixed at the position where it was when movie recording started. *3 Some time may be required to focus.

• The focus mode is fixed as “AF” (Auto Focus) while shooting with Premium Auto Pro.

Focus Mode Approximate Focus Range

Snapshot Movies Snapshot Movies

Automatic

Fixed

focal point

Fixed

focal point

Fixed

focal point

10 cm to

(infinity)

(3.9"

3 cm to 10 cm (1.2" to 3.9")

55 cm to

(infinity)

(21.7"

)

46 cm to

(infinity)

(18.1"

3 cm to 10 cm (1.2" to 3.9")

2, 3

46 cm to

(infinity)

)

(18.1"

)

Advanced Recording Settings

Procedure

NOTE

Procedure

Self-shooting (Mirror)

Normal image Mirrored image

Enter the REC Mode * MENU * “rREC MENU” Tab * Mirror Image

Turning on this function displays the controller monitor image as a mirror image. This comes in handy when using the controller to compose self-shot images. The image is recorded in normal orientation (not mirror imaged).

• You can change an image displayed on the screen to a mirror image by flicking the image.

Reducing Wind Noise during Movie Recording (Wind Noise Cut)

Enter the REC Mode * MENU * “rREC MENU” Tab * Wind Noise Cut

Select “On” to reduce wind noise during movie recording. Note, however, that this will also cause the sound quality to change.

Advanced Recording Settings

Procedure

NOTE

Procedure

Turning on Image Review (Review)

Enter the REC Mode * MENU * “rREC MENU” Tab * Review

While Review is turned on, the camera will display an image immediately after it is recorded.

Type 1 Displays a full-screen view of the image for about one second.

Displays a Review image in the lower left corner (in the case of a

Type 2

Off Turns off review image display

• A Type 2 review image is displayed when “High Speed CS” is selected as the recording mode, even if “Type 1” is selected for the Review setting.

landscape orientation image) or the upper left corner (in the case of a portrait orientation image) of the monitor screen. Touching the Review image will enter the PLAY mode and display a full-screen view of the image.

Displaying a Grid on the Monitor Screen (Grid)

Enter the REC Mode * MENU * “rREC MENU” Tab * Grid

Selecting “On” displays grid lines on the monitor screen. The grid lines provide references that help you keep the camera vertically and horizontally straight.

Advanced Recording Settings

Viewing Snapshots and Movies

NOTE

Movie icon:

Movie recording time

Image quality

Playback in progress Playback paused

Touch “ ”.

Progress bar

Viewing Snapshots

See page 36 for the procedure for viewing snapshots.

Viewing a Movie

1. Touch “ ” (PLAY) to enter the PLAY mode.

2. Flick left or right across the screen image to

scroll through the movies until the one you want is displayed.

3. Touch “ ” (Movie) to start playback.

• To switch to full-screen view, touch the monitor screen.

• Playback may not be possible for movies not recorded with this camera.

• When a movie is played back on the camera, the audio output from the camera speaker will be out of sync with the video image. This does not indicate any problem with the movie file. Also, playback on the camera uses a low frame rate. Send the movie to a smartphone for better movie playback results.

Viewing Snapshots and Movies

Viewing the Image Menu

The image menu shows multiple images on a single screen.

1. In the PLAY mode, touch “ ” or squeeze your

fingers on the screen.

This displays the image menu.

• Touch “ ”, “ ”, or flick upwards or downwards to scroll to the next page of images.

• To view the normal (single image) display mode, touch the image your want to view.

• In the case of a movie, the first image in the movie is displayed.

• CS images and images shot with Interval Shooting are displayed as grouped images.

• A question mark (?) will be displayed for images that cannot be displayed for some reason.

Zooming an On-screen Image

Snapshots can be zoomed on the monitor screen up to 2X.

1. In the PLAY mode, flick left or right to display the image you want to

view.

2. Touch the center of the screen or spread your thumb and forefinger

(page 18) on the displayed image to enlarge it.

• Dragging an enlarged screen image will change the part of the image that is displayed.

• Touching “ “ or squeezing your thumb and forefinger (page 18) on the displayed image will reduce it in size.

Viewing Snapshots and Movies

Creating a Movie of a Day’s Images (Highlight Movie)

You can configure camera settings to automatically select snapshot and movie highlights, and create a movie of them. Images included in a Highlight Movie are selected based on their highlight scores and shooting condition information recorded along with the images.

• You can use the Highlight Score function (page 66) to change the highlight score of a snapshot.

• The playback time and effects applied to the Highlight Movie are automatically determined based on the shooting condition information recorded along with the images included in the movie and their highlight score (+1 or 0).

1. In the PLAY mode, touch “ ” (Show Icons).

2. Touch the “ ” (Edit) icon.

3. Touch “ ” (Highlight Movie) icon.

• Touching “ ” will display a detailed explanation about image editing functions. Flick upwards or downwards on the monitor screen until “Highlight Movie” is displayed, and then touch its icon.

4. Select how images should be chosen for conversion to a Highlight

Movie.

Date

Interval Group

Images are selected from among those shot on a specific date.

Images are selected from among those in a group of Interval Shooting images (page 43).

5. Touch “¥”.

6. Touch an item and then change its setting.

Max Play Time Specify the playback time of the Highlight Movie.

Music Select the background music you want to use.

7. After settings are the way you want, touch “ ” (Back) to return to the

screen in step 5.

8. Touch “ ” or “ ” to select the date or Interval Shooting for which

you want to create a Highlight Movie, and then touch it.

Viewing Snapshots and Movies

9. Touch “Yes”.

NOTE

This creates and save the Highlight Movie, and displays it on the monitor screen.

• Touching “Cancel” while creation of a Highlight Movie is in progress will stop Highlight Movie creation. No movie is saved if you stop Highlight Movie creation.

• An image whose highlight score is “0” is never included in a Highlight Movie.

• A Highlight Movie is Full HD movie quality, with an aspect ratio of 16:9. If an image with an aspect ratio that is not 16:9 is incorporated into a Highlight Move, the top and bottom of the image will be cropped as required.

• If a portrait orientation image is incorporated in to a Highlight Movie, there will be black bands on the left and right of the image.

• When there is a total of more than 9,999 snapshot and movie files shot on the same date, Highlight Movie will select photos and movies from the files numbered 1 to 9999.

• Depending on the number of files and other factors when a Highlight Movie is being created, the creation operation may take some time.

• Only Full HD quality movies that have been recorded with this camera or with a CASIO EX-FR10 camera can be used in a Highlight Movie. Even if a movie was recorded with this camera, it cannot be used in a Highlight Movie if it is HS240 or STD quality.

Viewing Snapshots and Movies

Creating a Collage of a Day’s Snapshots (Highlight Photo)

You can configure camera settings to automatically select snapshot highlights and generate a collage of them. The snapshots included in a Highlight Photo are selected automatically based on their high light scores and shooting condition information recorded along with the snapshots.

• You can use the Highlight Score function (page 66) to change the highlight score of a snapshot.

1. In the PLAY mode, touch “ ” (Show Icons).

2. Touch the “ ” (Edit) icon.

3. Touch “ ”.

• Touching “ ” will display a detailed explanation about image editing functions. Flick upwards or downwards on the monitor screen until “Highlight Photo” is displayed, and then touch its icon.

4. Select how images should be chosen for conversion to a Highlight

Photo.

Date

Interval Group

Images are selected from among those shot on a specific date.

Images are selected from among those in a group of Interval Shooting images (page 43).

5. Touch “ ”, “ ” to select the date or Interval Shooting for which you

want to create a Highlight Photo.

6. Touch “ ”, “ ” to display the layout you want to use, and then

touch it.

7. Touch “Apply”.

This displays the Highlight Photo and saves it in camera memory.

• Touching “Cancel” while creation of a Highlight Photo is in progress will stop Highlight Photo creation.

• The screen that appears after the image is saved includes a “ ” (Shuffle) icon. Touching the shuffle icon creates a Highlight Photo using different snapshots. This also deleted the previously created Highlight Photo.

8. Touch “ ” to exit Highlight Photo.

Viewing Snapshots and Movies

NOTE

• An image whose highlight score is “0” is never included in a Highlight Photo.

NOTE

• When there are more than 9,999 snapshots shot on the same date stored on the memory card, Highlight Photo will select photos from those numbered 1 to 9999.

• The Highlight Photo operation may not be possible while battery power is low.

Changing the Highlight Score of an Image (Highlight Score)

You can use the procedure below to change the highlight score of a snapshot or movie.

Highlight

Score

No score assigned (default) An image with this score may be selected for a Highlight Snapshot or Highlight Movie.

An image with this score is given priority for Highlight Snapshot or Highlight Movie selection.

An image with this score is never selected for a Highlight Snapshot or Highlight Movie.

Description

1. In the PLAY mode, touch “ ” (Show Icons).

2. Touch the “ ” (Edit) icon.

3. Touch the “ ” (Highlight Score) icon.

4. Flick the screen upwards or downwards to

scroll through highlight scores until the one you want to delete is displayed, and then touch to select it.

5. Touch the score you want to assign to the selected image.

• You can flick the screen left or right to scroll to another image and change its score as well.

6. After changing the highlight score of the image, touch “ ” to return

to the main screen.

• The highlight score function can be used only with snapshots and movies recorded with this camera.

• The highlight score of a protected image cannot be changed.

Viewing Snapshots and Movies

Creating a Time Lapse Movie (Time Lapse)

This function creates a Time Lapse Movie up to 10 minutes long by combining snapshots shot with the camera on a particular date, in the order they were shot.

1. In the PLAY mode, touch “ ” (Show Icons).

2. Touch the “ ” (Edit) icon.

3. Touch the “ ” (Time Lapse) icon.

• Touching “ ” will display a detailed explanation about image editing functions. Flick upwards or downwards on the monitor screen until “Time Lapse” is displayed, and then touch its icon.

4. Select how images should be chosen for conversion to a Time Lapse

Movie.

Date Create a Time Lapse Movie for a specific date.

Interval Group

Create a Time Lapse Movie for group of Interval Shooting images (page 43).

5. Touch “¥”.

6. Touch an item and then change its setting.

Playback Speed

Music Select the background music you want to use.

Specify the playback time of each image. Selecting “Slow” specifies a longer playback time for each image, while “Fast” specifies a shorter playback time.

7. After settings are the way you want, touch “ ” (Back) to return to the

screen in step 5.

8. Use (touch) the up and down arrows (“ ”, “ ”) to display the

recording date or Interval Shooting of the images you want to use to create a Time Lapse Movie.

9. Touch “Yes”.

This creates and displays the Time Lapse Movie.

• Touching “Cancel” while creation of a Time Lapse Movie is in progress will cancel the creation process.

Viewing Snapshots and Movies

NOTE

• A Time Lapse Movie is Full HD movie quality, with an aspect ratio of 16:9. If an image with an aspect ratio that is not 16:9 is incorporated into a Time Lapse Movie, the top and bottom of the image will be cropped as required.

• If a portrait orientation image is incorporated in to a Time Lapse Movie, there will be black bands on the left and right of the image.

• When there is a large number of images, this function will stop processing when the Time Lapse Movie reaches a length of 10 minutes. Subsequent images will not be converted to a Time Lapse Movie.

• Highlight Photos are not included in Time Lapse Movies.

• Depending on the number of files and other factors when a Time Lapse Movie is being created, the creation operation may take some time.

Viewing Snapshots and Movies

Other Playback Functions (PLAY)

Tabs

Items

Procedure

Enter the PLAY Mode * MENU * Rotation

The following are menu operations you can use to configure various camera settings.

Using the PLAY Menu

. Example Menu Screen Operation

1. In the PLAY mode, touch “ ” (Show

Icons).

2. Touch “MENU”.

This will display the menu screen.

• Menu contents are different in the REC mode and PLAY mode.

3. Touch the tab where the menu item you want

to configure is located.

4. Touch the item whose setting you want to change.

5. Configure the setting of the item in accordance with the screen

contents.

• To navigate back to the previous menu level, touch “ ”.

. Menu Operations in This Manual

Menu operations are represented in this manual as shown below. Touch the indicated icons and items, and perform operations as they are indicated, from left to right.

Other Playback Functions (PLAY)

Procedure

NOTE

Rotating an Image (Rotation)

Enter the PLAY Mode * MENU * Rotation

1. Flick left or right to display the image you want to rotate.

2. Touch “ ”.

This will rotate the image 90 degrees to the left.

3. When the image is in the orientation you want, touch “ ”.

• Note that this procedure does not actually change the image data. It simply alters how the image is displayed on the camera’s monitor screen.

Other Playback Functions (PLAY)

Connecting the Camera with a Smartphone (Wireless Connection)

Controlling Your Camera with a Smartphone

Your camera has both Bluetooth wireless technology and wireless LAN capabilities built in. After establishing a wireless connection with a smartphone, you can perform the operations described in the table below. Requires installation of the EXILIM Connect app on your smartphone.

• Your camera is a Bluetooth device.

• Your camera can connect using Bluetooth wireless technology with a smartphone that supports Bluetooth Smart. Note that the Bluetooth wireless technology that connects your camera with a smartphone is different from the Bluetooth wireless technology that connects the camera with the controller.

With this function: You can do this:

Auto Send

Shoot with phone

Smart

Images can be automatically sent as they are shot to a smartphone that has been Bluetooth paired with the camera.

Send to phone

Remotely control and shoot with the camera using a smartphone (page 77).

Send snapshots and movies recorded with your camera to your smartphone. image to a smartphone, you can then upload it from the smartphone to a social networking service (page 78).

Connecting the Camera with a Smartphone

After sending an

(Wireless Connection)

IMPORTANT!

NOTE

With this function: You can do this:

View on phone

View snapshots stored in camera memory on a smartphone, and copy snapshots and movies to a smartphone for viewing. You can also view snapshots and movies in camera memory on a computer, and copy them to a computer (page

79).

• Inside an aircraft or anywhere else where use of wireless communication is restricted or prohibited, do not use this camera.

• Some smartphone models may not be able to play back movie files from your camera.

• Depending on your smartphone model, its operating system version, and/or its remaining storage capacity can cause failure of a movie or snapshot save operation. Receiving a camera file, perform the required operation on your smartphone to check if the file was stored properly.

• A movie received on an Android terminal: – Movies are not displayed by Gallery app. Movies are stored in a folder named

“EXILIM Connect”.

– A separate movie player is required to playback movies (whose files have the file

name extension MOV).

– Depending on your movie player, you may not be able to playback movies and/

or audio.

• Images recorded on another manufacturer’s camera cannot be sent using this function.

• Note that using wireless functions requires more battery power usage than normal. Make sure that the camera battery is sufficiently charged before starting a wireless LAN operation.

• The operating range depends on the local communication environment and on the type of smartphone you are connected to.

Connecting the Camera with a Smartphone

(Wireless Connection)

. About EXILIM Connect

“ ” (Wireless)

For detailed information about EXILIM Connect, refer to the EXILIM Connect User’s Guide (which you can download at the website below).

http://www.exilim.com/manual/

• Note that to view the EXILIM Connect User’s Guide, you will have to install Adobe Reader. Consult CASIO authorized service center if you are unable to open to display the PDF format User’s Guide.

• Note that EXILIM Connect User’s Guides may not be available in all languages. If you cannot find a EXILIM Connect User’s Guide in your native language, please use a version in another language.

Using a Wireless Mode

Your camera has a variety of different wireless modes. Select the wireless mode that suits your specific requirements.

1. Touch “ ” (Show Icons).

2. Touch the “ ” (Wireless) icon.

This will display the wireless mode screen.

3. Touch the wireless mode you want.

• To exit the wireless mode, touch “ ”.

Send to phone

Select to view images you shoot with the camera on a smartphone (pages 78,

79).

Pairing

Select this mode to establish a Bluetooth wireless technology connection between the camera and a smartphone (page 75).

Shoot with phone

Select this mode for remote control of image recording from a smartphone (page 77).

Wireless settings

Select this mode to configure wireless settings (page 80).

Connecting the Camera with a Smartphone

(Wireless Connection)

Getting Ready to Establish a Connection between a Smartphone and Your Camera

Installing the EXILIM Connect Smartphone app on your smartphone makes it possible to remotely control the camera from your smartphone and to send images recorded with the camera to your smartphone. Search the EXILIM Connect app on Google Play or App Store and install it on your smartphone.

. App operation guarantees

No guarantees are made concerning the ability to operate the EXILIM Connect app on any particular smartphone or tablet.

IMPORTANT!

• For information about operating system version supported by the app, check the information on Google Play or the App Store.

• App functions and the required operating environment are subject to change without notice.

Installing the EXILIM Connect App on Your Smartphone

. Android terminal

1. Open “Google Play”.

2. In the search field, type “EXILIM Connect”.

3. Install EXILIM Connect.

. iPhone (iOS)

1. Open “App Store”.

2. In the search field, type “EXILIM Connect”.

3. Install EXILIM Connect.

Connecting the Camera with a Smartphone

(Wireless Connection)

Establishing a Wireless Connection for the First Time

The first time you establish a wireless connection between the camera and a smartphone, you need to use the procedure below to configure wireless connection settings. This operation is required for the first connection only.

. Smartphone that supports Bluetooth Smart

Connecting the camera to a smartphone using Bluetooth wireless technology (pairing) makes it simple to configure wireless connection settings.

IMPORTANT!

• Performing this operation automatically configures your smartphone’s wireless LAN connection settings (page 76).

• Some smartphone models may not be compatible with this camera.

• If you want to re-pair the camera with the smartphone it is already paired with, first unpair them and then pair again. Re-pairing the camera and smartphone will result in all pending unsent images to remain unsent.

Camera (Controller) Operation

1. Touch the “ ” (Wireless) icon.

This will display the wireless mode screen.

2. Touch “Pairing”.

3. Touch “Start”.

• You can start pairing by performing an operation on the camera, without using the controller.

Turn off the camera.



On the camera, hold down [p] (Power) for about six seconds.



The camera’s operation lamp will flash amber.

Smartphone Operation

4. Start up the EXILIM Connect app.

5. Tap “Pairing”.

6. Perform the required connection operation as instructed by the app

and your smartphone.

This establishes a Bluetooth wireless technology connection between the camera and smartphone.

• For information about how to configure wireless connection settings, refer to the EXILIM Connect manual (page 73).

Connecting the Camera with a Smartphone

(Wireless Connection)

NOTE

• “Auto Send” (page 80) will be turned on after you configure wireless connection

NOTE

SSID

Password

settings on the camera and smartphone.

• After the camera is paired, Bluetooth wireless technology operation will consume battery power even when the camera it turned off. Because of this, it is recommended that you charge the camera’s battery before you plan to use it.

. Smartphone that does not support Bluetooth Smart

Configure smartphone wireless LAN connection settings (input the camera SSID and password).

1. Touch the “ ” (Wireless) icon.

2. Touch “Shoot with phone”.

3. Touch “Start”.

This will enable connection with a smartphone and the camera will display a screen for input of an SSID and password, and camera’s wireless LAN connection lamp will flash blue.

4. For the smartphone Wi-Fi setting, input the camera “SSID” and

“Password”.

When the smartphone establishes a wireless LAN connection with the camera, the camera’s wireless LAN connection lamp lights blue and the message “Start up the phone app.” appears on the controller’s monitor screen. Next, start up the app on the phone.

• What you need to do to establish a wireless LAN connection depends on the type of smartphone you are using. For details about how to establish a wireless LAN connection see the user documentation that comes with your smartphone.

• The camera SSID (which cannot be changed) and password (initial default) are shown below. SSID: FR100-XXXXXX (6-character alphanumeric ID) Password: 00000000

• You can also use the procedure below to establish a wireless LAN connection between the camera and smartphone.

Turn off the camera.



On the camera, while holding down [0] (Movie), hold down [p] (Power) for



about one second. The camera’s wireless LAN connection lamp will flash blue. On the smartphone, select the camera’s SSID.



Connecting the Camera with a Smartphone

(Wireless Connection)

. What to do if you are unable to establish a wireless LAN connection

between the camera and a smartphone.

This problem may be caused when the smartphone is already wirelessly connected to one of the networks or devices below. Go to your smartphone’s Wi-Fi settings and select this camera’s SSID.

– Household wireless LAN – Public wireless LAN – Portable wireless LAN device

Using a Smartphone as a Camera Remote Controller (Shoot with phone)

This function lets you remotely shoot a snapshot or movie with the camera using a smartphone. You also can perform remote zoom and other operations as well.

. Bluetooth Wireless Technology Connection

1. Perform one of the operations below.

– Enter the sleep mode.

Turn on the camera and controller.



On the controller, press [p] (Power).



This will enter the sleep mode, which is indicated by the camera’s operation lamp slowly flashing green.

– Display the wireless mode screen.

Touch “ ” (Show Icons).



Touch the “ ” (Wireless) icon.



2. On the smartphone, start up the EXILIM Connect app.

3. On the smartphone, tap “Remote Capture”.

4. Compose the image on the smartphone’s screen as you shoot.

For information about how to use “Shoot with phone”, refer to the EXILIM Connect manual (page 73).

. Cannot Connect with Bluetooth Wireless Technology

1. Touch the “ ” (Wireless) icon.

2. Touch “Shoot with phone”.

3. Touch “Start”.

• If there is a wireless LAN connection between the smartphone and camera, advance to step 5 of this procedure.

Connecting the Camera with a Smartphone

(Wireless Connection)

4. For the smartphone’s Wi-Fi settings, select the SSID displayed on the

camera and establish a wireless LAN connection between the camera and smartphone.

5. On the smartphone, start up the EXILIM Connect app.

6. Compose the image on the smartphone’s screen as you shoot.

For information about how to use “Shoot with phone”, refer to the EXILIM Connect manual (page 73).

Sending a Snapshot or Movie File from Camera Memory to a Smartphone (Send Selected Image)

You can select one more snapshot and/or movie file in camera memory and send it to a smartphone. You can select up to 50 files, totaling no more than 500MB for a single send. After sending an image to a smartphone, you can then upload it to a social networking service.

1. Touch the “ ” (Wireless) icon.

2. Touch “Send to phone”.

3. Touch “Send Selected Image”.

4. Touch the image you want to send to the smartphone.

Selecting the image of a file causes its check box to become selected.

• To exit the send image to smartphone operation, touch “Cancel”.

5. After selecting the images of all of the files you want to send to the

smartphone, touch “OK”.

For information about how to use “Send Selected Image”, refer to the EXILIM Connect manual (page 73).

Connecting the Camera with a Smartphone

(Wireless Connection)

NOTE

Viewing Snapshots and Movies in Camera Memory on a

URL

Smartphone (View on phone)

You can connect the camera to a smartphone over wireless LAN to view and download snapshots and movies in camera memory on up to eight connected smartphones. You can also view snapshots and movies in camera memory on a computer, and copy them to a computer. A smartphone does not need to have the EXILIM Connect app installed in order to access camera images using this function.

1. Touch the “ ” (Wireless) icon.

2. Touch “Send to phone”.

3. Touch “View on phone”.

This establishes a connection between the smartphone and camera, and displays a URL.

• If the message “Connect your phone to the access point below.” remains on the camera’s monitor screen, change the smartphone’s Wi-Fi settings so your camera is selected for connection (page 75).

4. On the smartphone, start up its browser app.

• Accessing the URL displayed by the camera will display an image stored in camera memory.

• To exit the wireless LAN function, touch “Exit” on the camera’s monitor screen.

IMPORTANT!

• Some smartphone models may not be able to play back movie files.

• You can also view image in camera memory on a computer’s browser by establishing a wireless LAN connection with the computer.

• For information about how to start up EXILIM Connect and view images, refer to the EXILIM Connect manual (page 73). Note that the operation you need to perform depends on whether or not there is a Bluetooth wireless technology connection with the smartphone.

Connecting the Camera with a Smartphone

(Wireless Connection)

Procedure

IMPORTANT!

Configuring Wireless Connection Settings

This section explains wireless mode operations and setting items.

1. Touch the “ ” (Wireless) icon.

This will display the wireless mode screen.

• Pressing the shutter button will return to the screen that was displayed before the wireless mode screen.

2. Touch “Wireless settings”.

This will display the wireless setting screen.

3. Touch the item you want to configure.

4. Change the setting of the selected item.

• Changing a setting returns to the wireless mode screen.

Having Images Shot with the Camera Sent to a Smartphone Automatically (Auto Send)

“ ” (Wireless) * Wireless settings * Auto Send

While “On” is selected for this setting, images are sent to the paired smartphone automatically. Images are sent to the smartphone while the camera is in the sleep mode. If there is no wireless connection between the camera and smartphone, the images will be sent as soon as a connection is established.

• The camera’s wireless LAN connection lamp will be flashing or lit while an image send operation is in progress. The lamp will go out after the image send operation is complete.

• Auto Send cannot be enabled unless the camera is paired with a smartphone (page 75).

• Images recorded with Interval Shooting cannot be automatically sent to a smartphone using Auto Send.

Connecting the Camera with a Smartphone

(Wireless Connection)

NOTE

• Auto Send can be used only with a smartphone that supports Bluetooth Smart.

Procedure

IMPORTANT!

Both a Bluetooth and wireless LAN connection are required between the camera and smartphone to auto send camera images.

• You can specify the size of the image sent to the smartphone using “Resize When Sending” (page 82).

• You can use the smartphone apps below to view snapshots after sending them. – iPhone: Camera Roll – Android terminal: Gallery, Photo, or another photo browser app

• Images shot while the Auto Send setting is “On” will be sent to the smartphone, even if the Auto Send setting is changed to “Off” before they are sent.

• If the connection between the camera and smartphone is terminated while there are still unsent images, Auto Send will be cancelled. The next time the camera and smartphone are turned on and the camera enters the Sleep Mode, the Auto Send operation will restart.

• If you delete an image that has not yet been sent to the smartphone, it will not be included in the next Auto Send.

Specifying Images to be Sent by Auto Send (Auto Send File Settings)

“ ” (Wireless) * Wireless settings * Auto Send File Settings

Specifies the files to be sent to a smartphone by Auto Send.

T » Snapshots and movies are sent.

T Only Only snapshots are sent.

• The maximum size movie file that can be sent by Auto Send is 100 MB.

• Auto Send File Settings cannot be configured unless the camera is paired with a smartphone (page 75).

Connecting the Camera with a Smartphone

(Wireless Connection)

Procedure

NOTE

Resizing Snapshots before Sending Them to a Smartphone (Resize When Sending)

“ ” (Wireless) * Wireless settings * Resize When Sending

This feature can be use to resize snapshots before they are sent to a smartphone using “Shoot with phone” or “Send to phone”.

Off Images are sent in the size they were originally recorded.

Images are converted to 3M size before being sent.

• If an original image is 3M size or smaller, it is sent without resizing.

Changing the Camera Password for Wireless LAN Connection (WLAN password)

“ ” (Wireless) * Wireless settings * WLAN password

Use procedure to change the password you used when establishing a wireless LAN connection between the camera and a smartphone.

IMPORTANT!

• Before changing the wireless LAN password, unpair the camera from its paired smartphone (page 83).

1. Touch the password digit you want to change.

2. Touch “ ” or “ ” to change the currently selected digit.

3. When the password is the way you want, touch “OK”.

• Changing the wireless LAN password will terminate the connection with the smartphone. To reconnect with the smartphone, configure wireless connection settings (page 75). If your smartphone does not support Bluetooth Smart, perform the operations below to change your smartphone’s Wi-Fi settings. – iPhone:

Tap the right arrow of the field where the SSID of the camera is displayed in the Wi-Fi settings to delete network settings. After deleting, select the camera SSID again and input the new password.

– Android terminal:

Tap the field where the SSID of the camera is displayed in the Wi-Fi settings and select Forget. Select the camera SSID again and input the new password.

Connecting the Camera with a Smartphone

(Wireless Connection)

Procedure

NOTE

Unpairing the Camera from a Smartphone (Unpairing)

“ ” (Wireless) * Wireless settings * Unpairing

Unpairs the camera from a smartphone. To use the camera with a different smartphone, first unpair it from the current smartphone.

• When unpairing, be sure also to perform the unpairing operation on the smartphone as well. For details, refer to the EXILIM Connect User’s Guide (page

73).

• Unpairing the camera from a smartphone will result in all pending unsent images to remain unsent.

Connecting the Camera with a Smartphone

(Wireless Connection)

Printing

Professional Print Service

You can take a memory card that contains the images you want to print to a professional print service and have them printed.

Printing on a Home Printer

You can use a printer equipped with a memory card slot to print images directly from a memory card. For details, see the user documentation that comes with your printer.

Printing with a Computer

After transferring the images to your computer, use commercially available software to print.

Printing with a Computer

There are a variety of different ways to print images stored on a computer. This section shows one standard printing example.

. Printing on a Windows Computer

1. Use the procedure under “Viewing and Storing Images on a Computer”

(page 86) to store the image you want to print, and then display the image on your computer screen.

2. Click “Print” and then “Print”.

3. Configure the desired print settings and then click “Print”.

. Printing on a Macintosh

1. Use the procedure under “Connecting the Camera to Your Computer

and Saving Files” (page 89) to store the image you want to print, and then display the image on your Macintosh screen.

2. Click “File” and then “Print”.

3. Configure print settings and then click “Print”.

This will print the selected image.

Printing

Using the Camera with a Computer

Things you can do using a computer...

You can perform the operations described below while the camera is connected to a computer.

Save images to a computer and view them there

Play back and edit movies

The procedures you need to perform are different for Windows and the Macintosh.

• Windows users should refer to “Using the Camera with a Windows Computer” on page 85.

• Macintosh users should refer to “Using the Camera with a Macintosh” on page

89.

• Save images and view them manually (USB connection) (pages 86, 89).

• You can play back movies (pages 88, 91).

• To edit movies, use commercially available software as required.

Using the Camera with a Windows Computer

When you want to do this:

Save images to a computer and view them there manually

Play movies

Operating System Version

Windows 10, Windows 8.1, Windows 8, Windows 7, Windows Vista

Required Software

Installation not required.

QuickTime 7 or higher

• You need to download QuickTime 7 on the Web if you want to use it.

See page:

Using the Camera with a Computer

NOTE

Viewing and Storing Images on a Computer

USB

Micro USB cable

(included with camera)

[USB] port

You can connect the camera to your computer in order to view and store images (snapshot and movie files).

Never use your computer to modify, delete, move, or rename any image files that are in the camera’s built-in memory or on its memory card.

Doing so can cause problems with the camera’s image management data, which will make it impossible to play back images on the camera and can drastically alter remaining memory capacity. Whenever you want to modify, delete, move, or rename an image, do so only on images that are stored on your computer.

IMPORTANT!

• Never unplug the USB cable, or operate the camera while viewing or storing images. Doing so can cause data to become corrupted.

• You also can use your computer’s card slot (if it has one) or a commercially available card reader to access image files directly from the camera’s memory card. For details, see the user documentation that comes with your computer.

. To connect the camera to your computer and save files

1. Turn off the camera and then

use the micro USB cable that comes with the camera to connect it to your computer.

• For details about connecting to the camera and precautions when connecting, see page 23.

2. Press [p] (Power) to turn on the camera.

When you turn on the camera, check to make sure that the color of its operation lamp changes from red to green or amber (page 23). Note that in this case the monitor screen will remain blank.

• The first time you connect the camera to your computer with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.

3. Windows 10 users: Click “Start” and then “Explorer”. Next, in the

sidebar, click “PC”. Windows 8.1, Windows 8 users: Click “Desktop” and then “Explorer”. Windows 7, Windows Vista users: Click “Start” and then “Computer”.

Using the Camera with a Computer

4. Double-click “Removable Disk”.

• Your computer recognizes the memory card loaded in the camera (or built-in memory if there is no card) as a removable disk.

5. Right-click the “DCIM” folder.

6. On the shortcut menu that appears, click “Copy”.

7. Windows 10, Windows 8.1, Windows 8 users: Click “Documents”.

Windows 7, Windows Vista users: Click “Start” and then “Documents”.

• If you already have a “DCIM” folder in “Documents”, the next step will overwrite it. If you want to keep the existing “DCIM” folder, you need to change its name or move it to a different location before performing the next step.

8. Windows 10, Windows 8.1, Windows 8 users: On the “Documents”

menus, click “Home” and then “Paste”. Windows 7, Windows Vista users: On the “Documents” menu, click “Organize” or “Edit”, and then “Paste”.

This will paste the “DCIM” folder (and all the image files it contains) into your “Documents” folder. You now have a copy of the files that are in camera memory on your computer.

• After copying images, it is recommended that you right-click the DCIM folder and change its name to something else.

9. After you finish copying images, disconnect the camera from the

computer.

After the copy or read progress dialog on the computer’s screen indicates that the process is complete, close the displayed image and then disconnect the USB cable.

. To view images you copied to your computer

1. Double-click the copied “DCIM” folder to open it.

2. Double-click the folder that contains the images you want to view.

3. Double-click the image file you want to view.

• For information about file names, see “Memory Folder Structure” on page 93.

• An image that was rotated on the camera will be displayed on your computer screen in its original (unrotated) orientation.

• Viewing CS and interval shot images on a computer will individually display the component images in the group. CS and interval shooting images cannot be viewed as a group on a computer.

Using the Camera with a Computer

Playing Movies

To play back a movie, first copy it to your computer and then double-click the movie file. Some operating systems may not be able to play back movies. If this happens, you need to install separately available software.

• With Windows 10, Windows 8.1, Windows 8 and Windows 7, playback is supported by Windows Media Player 12.

• If you are unable to play back movies, go to the URL below to download QuickTime 7 or higher and install it on your computer. https://www.apple.com/quicktime/

. Minimum Computer System Requirements for Movie Playback

The minimum system requirements described below are necessary to play back movies recorded with this camera on a computer.

Operating System : Windows 10, Windows 8.1, Windows 8, Windows 7, Windows

CPU : Image Quality “Full HD”: Core 2 Duo 3.0GHz or higher

Required Software: QuickTime 7 or higher (Not required with Windows 10,

• The above are recommended system environments. Configuring one of these environments does not guarantee proper operation.

• Certain settings and other installed software may interfere with proper playback of movies.

Vista

Image Quality “STD”, “HS240”: Pentium 4 3.2GHz or higher

Windows 8.1, Windows 8 and Windows 7.)

. Movie Playback Precautions

• Be sure to move the movie data to the hard disk of your computer before trying to play it. Proper movie playback may not be possible for data accessed over a network, from a memory card, etc.

• Proper movie playback may not be possible on some computers. If you experience problems, try the following. – Quit any other applications you have running, and stop resident applications.

Using the Camera with a Computer

IMPORTANT!

NOTE

Using the Camera with a Macintosh

When you want to do this:

Save images to your Macintosh and view them there manually

Save images to your Macintosh automatically/ Manage images

Play movies

Operating System Version

OS X Installation not required. 89

OS X

OS X 10.5 or higher

Required Software

Photos or iPhoto, which comes bundled with some Macintosh products.

QuickTime Player (installed on computer)

See page:

–

Connecting the Camera to Your Computer and Saving Files

Never use your computer to modify, delete, move, or rename any image files that are in the camera’s built-in memory or on its memory card.

• Never unplug the USB cable, or operate the camera while viewing or storing images. Doing so can cause data to become corrupted.

• The camera does not support operation with Mac OS X 10.0 to 10.4. Operation is supported with Mac OS 10.5 to 10.11 (using the OS standard USB driver) only.

Using the Camera with a Computer

. To connect the camera to your computer and save files

Micro USB cable

(included with camera)

[USB] port

1. Turn off the camera and then

use the micro USB cable that comes with the camera to connect it to your Macintosh.

• For details about connecting to the camera and precautions when connecting, see page 23.

USB

2. Press [p] (Power) to turn on the camera.

When you turn on the camera, check to make sure that the color of its operation lamp changes from red to green or amber (page 23). Note that in this case the monitor screen will remain blank. In this mode, your Macintosh recognizes the memory card loaded in the camera (or the camera’s built-in memory if it does not have a memory card loaded) as a drive. The appearance of the drive icon depends on the Mac OS version you are using.

• The first time you connect the camera to your Macintosh with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable.

3. Double-click the camera’s drive icon.

4. Drag the “DCIM” folder to the folder to which you want to copy it.

5. After the copy operation is complete, drag the drive icon to Trash.

6. Disconnect the camera from the computer.

After the copy or read progress dialog on the computer’s screen indicates that the process is complete, close the displayed image and then disconnect the USB cable.

Using the Camera with a Computer

. To view copied images

1. Double-click the camera’s drive icon.

2. Double-click the “DCIM” folder to open it.

3. Double-click the folder that contains the images you want to view.

4. Double-click the image file you want to view.

• For information about file names, see “Memory Folder Structure” on page 93.

• An image that was rotated on the camera will be displayed on your Macintosh screen in its original (unrotated) orientation.

Playing a Movie

To play back a movie, first copy it to your Macintosh and then double-click the movie file.

. Minimum Computer System Requirements for Movie Playback

The minimum system requirements described below are necessary to play back movies recorded with this camera on a computer.

Operating System : Mac OS X 10.5 or higher Required Software: QuickTime Player (installed on computer)

• The above are recommended system environments. Configuring one of these environments does not guarantee proper operation.

• Certain settings and other installed software may interfere with proper playback of movies.

. Movie Playback Precautions

Proper movie playback may not be possible on some Macintosh models. If you experience problems, try the following.

– Shut down other applications that are running.

IMPORTANT!

• Be sure to move the movie data to the hard disk of your Macintosh before trying to play it. Proper movie playback may not be possible for data accessed over a network, from a memory card, etc.

Using the Camera with a Computer

Files and Folders


Extension

Serial number (4 digits)

Serial number (3 digits)

The camera creates a file each time you shoot a snapshot, record a movie, or perform any other operation that stores data. Files are grouped by storing them in folders. Each file and folder has its own unique name.

• For details about how folders are organized in memory, see “Memory Folder Structure” (page 93).

Name and Maximum Number Allowed Example

File

Each folder can contain up to 9999 files named CIMG0001 through CIMG9999. The extension on the file name depends on the file type.

Folders

Folders are named from 100CASIO to 999CASIO. There can be up to 900 folders in memory.

• You can view folder and file names on your computer. For details about how file names are displayed on the camera’s monitor screen, see page 10.

• The total number of folders and files allowed depends on the image size and quality, and capacity of the memory card being used for storage.

26th file name:

100th folder name:

100CASIO

Using the Camera with a Computer

Memory Card Data

DCIM

EXILIM

100CASIO

HL_DATA *

CIMG0001.JPG CIMG0002.MOV

101CASIO 102CASIO

MD2016 MD01010E.CMI MD01010T.CMI

MD2017

The camera stores images you shoot in accordance with the Design Rule for Camera File System (DCF).

. About DCF

The following operations are supported for DCF-compliant images. Note, however, that CASIO makes no performance guarantees concerning these operations.

• Transferring this camera’s DCF-compliant images to another manufacturer’s camera and view them.

• Printing this camera’s DCF-compliant images on another manufacturer’s printer.

• Transferring another camera’s DCF-compliant images to this camera and view them.

. Memory Folder Structure

DCIM Folder Recording Folder Image File Movie File

Recording Folder Recording Folder

Recording information

* Used when creating a Highlight Photo or Highlight Movie.

. Supported Image Files

• Image files shot with this camera

• DCF-compliant image files

This camera may not be able to display an image, even if it is DCF-compliant. When displaying an image recorded on another camera, it may take a long time for the image to appear on this camera’s monitor screen.

Using the Camera with a Computer

. Built-in Memory and Memory Card Data Handling Precautions

• Whenever copying memory contents to your computer, you should copy the DCIM folder and all of its contents. A good way to keep track of multiple DCIM folders is to change their names to dates or something similar after you copy them to your computer. If you later decided to return a DCIM folder to the camera, however, be sure to change its name back to DCIM. The camera is designed to recognize only a root file with the name DCIM. Note the camera also will not be able to recognize the folders inside the DCIM folder unless they have the names they originally had when you copied them from the camera to your computer.

• Folders and files must be stored in accordance with the “Memory Folder Structure” shown on page 93 in order for the camera to be able to recognize them correctly.

Using the Camera with a Computer

Other Settings (Set Up)

Procedure

This section explains menu items that you can use to configure settings and perform other operations in both the REC mode and PLAY mode.

For information about menu operations, see page 51.

Adjusting Monitor Screen Brightness (Screen)

MENU * “¥ Setup” Tab * Screen

You can use the following procedure to change the brightness of the monitor screen.

+1 Bright setting for outdoor use, etc. Brightness that is greater than 0.

0 Normal monitor screen brightness for indoor use, etc.

–1

Brightness that is greater than +1, which makes the screen easier to view. This setting consumes more power.

Screen brightness for viewing in a dark environment without disturbing others around you.

Selecting Display Information (Info)

MENU * “¥ Setup” Tab * Info

Selecting “On” displays setup status and other information.

Other Settings (Set Up)

Procedure

NOTE

Procedure

Locking the Camera or Controller Screen Orientation (Rotation Lock)

MENU * “¥ Setup” Tab * Rotation Lock

You can use this setting to fix the orientation of the camera or controller screen image, or allow the orientation to be detected and automatically rotated as required.

The camera detects its orientation when you are

Off

Camera

Off

Controller

• Certain playback environment may cause images to be displayed using the wrong orientation.

shooting, and stores orientation information along with the image data. During playback of an image, it is displayed in accordance with the orientation information.

The camera does not detect its orientation, and images are always stored in landscape orientation.

Display image is rotated according to the controller orientation.

Display image orientation is fixed at where it was when “On” is selected for the controller’s Rotation Lock setting.

Configuring Camera Sound Settings (Camera Sound)

MENU * “¥ Setup” Tab * Camera Sound

You can adjust the volume of the sound emitted when the camera is turned on, when an image is shot, when an error occurs, etc.

High volume

Low volume

• Regardless of this setting, no recording sound is emitted during an Interval Shooting operation.

Other Settings (Set Up)

Procedure

Using the Vibration Function (Vibration)

12/24 hour switch icon

MENU * “¥ Setup” Tab * Vibration

While “On” is selected for this function, the controller will vibrate whenever any one of the events described below occurs.

• When a preview of an image that what just shot appears on the controller screen

• When communication between the camera and controller is lost

• When an error occurs

• While focus is locked

Setting the Camera’s Clock (Adjust)

MENU * “¥ Setup” Tab * Adjust

1. Touch the value you want to change (year,

month, day, hour, minute).

2. Touch “ ” or “ ” to change the currently

selected value.

• You can specify a date from 2001 to 2049.

• To switch between 12-hour and 24-hour format, touch the 12/24 hour switch icon.

• Touching and holding “ ” or “ ” scrolls at high speed.

3. Touch “OK”.

Specifying the Date Style (Date Style)

MENU * “¥ Setup” Tab * Date Style

You can select from among three different styles for the date.

Example: July 10, 2016

YY/MM/DD 16/7/10

DD/MM/YY 10/7/16

MM/DD/YY 7/10/16

Other Settings (Set Up)

Procedure

Specifying the Display Language (Language)

MENU * “¥ Setup” Tab * Language

. Specify the display language you want.

1. On the menu screen, touch “Setup”.

2. Touch “Language”.

3. Flick upwards and downwards until you find the

language you want, and then touch to select it.

• Camera models sold in certain geographic areas may not support display language selection.

Specifying the Controller Sleep State Trigger Time (Sleep)

MENU * “¥ Setup” Tab * Sleep

Use this function to specify how much time should be allowed to laps until the controller display goes blank and the controller enters the sleep state. You can specify either 30 seconds (30 sec) or 5 minutes (5 min).

Other Settings (Set Up)

Procedure

NOTE

Procedure

Formatting Built-in Memory or a Memory Card (Format)

MENU * “¥ Setup” Tab * Format

If a memory card is loaded in the camera, this operation will format the memory card. It will format built-in memory if no memory card is loaded.

• The format operation will delete all contents on the memory card or in built-in memory. It cannot be undone. Make sure you do not need any data currently on the card or in built-in memory before you format it.

• Formatting built-in memory or a memory card will delete all protected images stored there.

• Check the battery level before starting a format operation and make sure it is not too low. Formatting may not be performed correctly and the camera may stop operating normally if the camera powers down while formatting is in progress.

Resetting the Camera to Factory Defaults (Reset)

MENU * “¥ Setup” Tab * Reset

See page 130 for details about the camera’s factory default settings. The settings below are not reset. Clock settings, date style, screen language, WLAN password

• Resetting the camera does not unpair it from a smartphone (page 75).

Checking the Current Camera Firmware Version (Version)

MENU * “¥ Setup” Tab * Version

Selecting this menu item displays the camera model name, the version of firmware installed on the camera.

• Check this screen after updating the camera’s firmware to confirm that updating was actually performed.

Other Settings (Set Up)

Appendix

Safety Precautions

DANGER

This symbol indicates information that, if ignored or applied incorrectly, creates the danger of death or serious personal injury.

WARNING

This indication stipulates matters that have the risk of causing death or serious injury if the product is operated incorrectly while ignoring this indication.

CAUTION

This indication stipulates matters that have the risk of causing injury as well as matters for which there is the likelihood of occurrence of physical damage only if the product is operated incorrectly while ignoring this indication.

Symbol Examples

This circle with a line through it (-) means that the indicated action must not be performed. Indications within or nearby this symbol are specifically

prohibited. (The example at left indicates that disassembly is prohibited.)

The black dot (0) means that the indicated action must be performed. Indications within this symbol are actions that are specifically instructed to be

performed. (The example at left indicates that the power plug must be unplugged from the electrical socket.)

DANGER

. Built-in Rechargeable Battery

• To charge the battery, use only the method specifically described in this manual. Attempting to charge the battery by an unauthorized means creates the risk of battery overheating, fire, and explosion.

• Do not expose or immerse the battery in fresh water or salt water. Doing so can damage the battery, and cause deterioration of its performance and loss of service life.

• The battery is intended for use with a CASIO Digital Camera only. Use with any other device creates the risk of the battery damage, or deterioration of battery performance and service life.

100

Appendix

Casio EX-FR100 User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Accessories

Read this first!

Contents

General Guide

Monitor Screen Contents and How to Change Them

Quick Start Basics

What you can do with your CASIO camera

Using the Attachment

Controller

Hinge Unit

Tripod nut

Carabiner Strap

Using the Touch Panel

First, charge the battery prior to use.

Turning Power On and Off

Configuring Basic Settings the First Time You Turn On the Camera

Preparing a Memory Card

Supported Memory Cards

To load a memory card
