Accessories
As you unpack your camera, check to make sure that all accessories shown below
are included. If anything is missing, contact your original retailer.
Camera
(EX-FR10)
Lens hoodTripod nutNeck strap
Carabiner strap
Micro USB cableBasic Reference
Controller
(EX-FR10CT)
USB-AC adaptor
(AD-C53U)
Hinge Unit
• The hinge unit comes
pre-attached to the
camera.
Power cord*
* The shape of the power cord plug varies according to the country or geographic
area where the camera is sold.
2
Read this first!
• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages, lost
profits, or claims by third parties arising out of the use of EXILIM Link.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Take test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
The numbers in parentheses indicate the pages where each item is explained.
CameraController
1 2
5678
Camera
Operation lamp
1
(pages 19, 22)
[p] (Power) (page 25)
2
Memory card slot
3
(page 30)
[RESET] button
4
(page 109)
[CARD] cover (page 30)
5
Speaker
6
Microphone
7
(pages 16, 43)
Lens (page 16)
8
Shutter button (page 32)
9
[0] (Movie) (page 42)
bk
9bk
43
bl
bm
bn
bo
[FREE] lever (page 13)
bl
[USB] port
bm
(pages 18, 21, 74, 78)
[USB] cover
bn
(pages 18, 21)
Strap holes (page 15)
bo
Controller
[USB] cover
bp
(pages 18, 21)
[RELEASE] button
bq
(page 12)
[RESET] button
br
(page 109)
[USB] port
bs
(pages 18, 21)
bt
bp
bq
br
bs
cl cm cn co cpck
Carabiner strap
bt
attachment bar
(page 16)
Strap holes (page 15)
ck
[0] (Movie) (page 42)
cl
Shutter button
cm
(page 32)
Operation lamp
cn
(pages 19, 22)
[p] (Power) (page 25)
co
Hinge unit slot
cp
(page 12)
7
Monitor Screen Contents and How to Change Them
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
. Snapshot Recording
Zoom icon (page 41)
12 3
br
bq
bp
bo
bn
bm
9bkbl
. Movie Recording
1
1
Snapshot capacity (number of shots)
2
4
(page 115)
Snapshot image size (page 46)
3
5
Information icon (page 9)
4
6
Movie quality (page 42)
5
Movie capacity (recording time) (page 115)
6
7
Bluetooth communication status (page 26)
7
8
PLAY mode icon (pages 27, 51)
8
Date/Time (pages 27, 68)
9
Camera battery level indicator (page 24)
bk
Controller battery level indicator (page 24)
bl
Home icon (page 35)
bm
Recording mode (page 39)
bn
White balance (page 48)
bo
Exposure compensation (page 47)
bp
Digital zoom (page 41)
bq
Focus frame
br
Close-range indicator (page42)
1
Movie Recording time (page 42)
2
Time set with “Max Recording Time”
3
(page 42)
2
3
8
. Snapshot Viewing
12
bm
bl
bk
9
. Movie Playback
1
Image menu icon (p
1
Information icon (page 9)
2
Snapshot image size (page 46)
3
3
Folder name/file name (page 80)
4
REC mode icon (page 27)
5
4
Date/Time (pages 27, 68)
6
Camera battery level indicator (page 24)
7
Controller battery level indicator (page 24)
8
5
Home icon (page 50)
9
68 7
Exposure compensation (page 47)
bk
White balance (page 48)
bl
Highlight Score (page 58)
bm
Movie recording time (page 52)
1
“6”
Movie play ico
2
age 54)
n (page 52)
2
. Selecting Display Information (DISP)
Each touch of “DISP” will cycle through settings that display or hide on-screen
information. You can configure separate settings for the REC mode and PLAY mode.
• Display information cannot be changed during movie recording.
OffNo information displayed.
Information OnShows information about image settings, etc.
Status OnShows more detailed information about settings.
9
Quick Start Basics
What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following main functions.
. Shooting
A variety of shooting styles
The camera connects to the controller using Bluetooth®
wireless technology (Bluetooth).
You can hang it from your neck, mount it on a tripod, and select
the shooting style that suits current conditions. The camera can
also be rotated 90 degrees, which means you can change the
orientation of a snapshot with little repositioning the camera.
*See page 12 for more information.
Interval Snapshot
Shoot snapshots and/or movies at fixed intervals. It’s a
great way to chronicle a day’s activities or changes
over time.
*See page 36 for more information.
ART SHOT
A variety of artistic effects help to make even common,
ordinary subjects become more novel and exciting.
*See page 39 for more information.
10
Quick Start Basics
. Viewing
. Sharing
Highlight Photo
You can configure camera settings to automatically
select snapshot highlights and generate a collage of
them each day.
*See page 55 for more information.
Highlight Movie
You can configure camera settings to automatically
select snapshot and movie highlights, and create a
movie of them each day.
*See page 56 for more information.
Wireless LAN Connection
Turns your smartphone into a camera remote
controller and allows you to select one or more
snapshot and/or movie file in camera memory and
send a copy to a smartphone.
*See page 60 for more information.
11
Quick Start Basics
Using the Attachment
You can configure the camera to suit your specific needs by attaching the hinge unit,
which enables attachment of the controller, and other included and optionally
available attachments. This way you can configure the camera to suit your specific
needs.
IMPORTANT!
• Do not apply strong pressure to the surface of the monitor screen. Doing so can
damage it.
• Never touch the lens with your fingers. Finger smudges, dirt, and other foreign
matter on the lens can interfere with proper operation of the camera. Use a blower
or other means to keep the lens and flash window free of dirt and dust, and wipe
gently with a soft, dry cloth.
Controller
You can attach the controller to the camera and use the camera as a normal camera.
. To attach the controller
1. With the camera lens pointed in the
same direction as the controller’s
monitor screen, slide the hinge unit into
the controller’s hinge unit slot.
2. Push the hinge unit in until you hear it
click into place.
. To detach the controller
1. While holding down the controller’s
[RELEASE] button, pull it out of the
camera.
12
Hinge unit slot
Align the 2 mark on the end of
the hinge unit with the 8 mark
next to the hinge unit slot.
[RELEASE] button
Quick Start Basics
Hinge Unit
. To use the hinge unit as a stand
. To change the shooting direction by 90 degrees
1. While pulling down on the camera’s [FREE]
lever, rotate the camera clockwise 90 degrees
until you hear a click.
• Align the camera’s operation lamp with the C
mark on the hinge unit.
• The gray lines on the lens ring indicate the
orientation of the long dimension of the image
being shot.
. To remove the hinge unit from the camera
1. While pulling down on the camera’s [FREE]
lever, rotate the camera counterclockwise
about 15 degrees until its operation lamp is
aligned with the A mark on the hinge unit.
[FREE] lever
AB C
Gray lines
Lens ring
A
[FREE] lever
13
Quick Start Basics
2. Remove the hinge unit from the camera.
. To attach the hinge unit to the camera
1. Align the camera’s operation lamp with
the A mark on the hinge unit.
2. Rotate the camera clockwise about
15 degrees until its operation lamp is aligned
with the B mark on the hinge unit.
Lens hood
A
B
If unwanted light is shining on the lens, rotate the lens
ring counterclockwise to detach it, and then attach a
lens hood.
When attaching the lens hood or lens ring, align the
8 mark on the camera with the 2 mark on the lens
hood or lens ring.
14
Attach
Detach
Lens ring
Quick Start Basics
Tripod nut
1. Use the tripod nut to secure a tripod
(commercially available) to the hinge unit.
Strap
. Neck Strap
The neck strap can be attached to the camera or the controller.
1. Remove the buckles from the
strap and attach the strap to the
two strap holes on the camera
or controller.
2. Replace the buckles.
Tripod nut
Tripod (commercially
available)
3. Use the adjusters to adjust the strap length and then fix the adjusters
on place.
Shorter
15
Longer
Quick Start Basics
4. Pass the ends of the strap through the bands.
. Carabiner Strap
1. Pass the carabiner strap belt around
the controller’s carabiner strap
attachment bar.
2. Pass the belt through the buckle to
secure it.
IMPORTANT!
• The carabiner strap is not intended for mountain climbing use. It is designed only to
support the camera.
NOTE
• When shooting hold the camera still. Carefully press the shutter button and take
care to avoid all movement as the shutter releases and for a few moments after it
releases.
• Take care that your fingers and the strap do not cover
any of the areas indicated in the illustration.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this
camera only. Never use it for any other purpose.
Microphone
Lens
16
Quick Start Basics
Using the Touch Panel
The monitor screen of the camera is a touch panel. This means you can perform the
following operations by touching the screen with your fingers.
Touch
Momentarily touching the screen with your finger.
Touch the screen to select an icon or menu item, and
to configure settings.
Flick
Holding your finger against the screen as you flick it
up, down, left, or right.
Use flick to scroll forward through images.
Spread
Holding your thumb and forefinger against the screen
as you spread them out.
Use spread to enlarge the screen image.
Squeeze
Holding your thumb and forefinger against the screen
as you bring them together.
Use squeeze to reduce the size of the screen image,
and to display multiple images.
IMPORTANT!
• Never use a pointed or hard object to perform screen operations. Doing so can
damage the screen.
NOTE
• Applying a commercially available LCD protective sheet will reduce the operation
sensitivity of the monitor screen.
• The camera will have a hard time interpreting a screen operation made using your
fingernails. Use the fleshy pad of your finger.
17
Quick Start Basics
First, charge the battery prior to use.
The camera and the controller each have a built-in rechargeable lithium ion battery.
The batteries are not charged when you purchase the camera, so you will need to
charge both the camera and controller before using them.
You can use either of the two following methods to charge the batteries.
• USB-AC adaptor
• USB connection to a computer
. To charge with the USB-AC adaptor
While the camera and controller are turned off, connect in the sequence shown
below.
Charging time: Approximately 135 minutes
[USB] port
Micro USB cable
(included with camera)
4
[USB] cover
When plugging in the connectors, orient this marking as described below.
Camera : Towards the lens side
Controller: Towards the monitor screen side
• When disconnecting the USB-AC adaptor from the camera, be sure to disconnect
from the camera first.
NOTE
• If you turn on the camera or controller while charging (with the USB-AC adaptor or
USB charger), you will be able to perform normal recording operations. In this
case, however, charging of the camera will be stopped while it is turned on.
4
18
1
USB-AC adaptor
(AD-C53U)
3
2
Power cord
Quick Start Basics
. Operation Lamp Indications
While power is off
Operation Lamp StatusMeaning
Lit redCharging
Charging stopped due to abnormal ambient
Flashing red
temperature, USB-AC adaptor problem, battery
problem (page 102), timer operation.
UnlitCharging complete
While power is on
•Camera
Operation Lamp
Status
Lit green
Slow red-amber
flashing
Meaning
Camera turned
on
Charging stopped
Charging
Charging stopped due to abnormal
High speed red-green
flashing
In sleep state
ambient temperature, USB-AC adaptor
problem, battery problem (page 102),
timer operation.
Slow green flashingCharging complete
•Controller
Operation Lamp StatusMeaning
Lit redCharging
Slow red-amber flashingCharging (sleep state)
High-speed green-amber
flashing
Charging stopped due to abnormal ambient
temperature, USB-AC adaptor problem, battery
problem (page 102), timer operation.
High-speed red-green flashingSame as above (sleep state)
Lit greenCharging complete
Slow green flashingCharging complete (sleep state)
19
Quick Start Basics
IMPORTANT!
• A battery that has not been used for a long time, or ambient temperature extremes
can cause charging to take longer than normal. If charging takes longer than about
five hours, a timer will terminate it automatically, even if the battery is not fully
charged. This is indicated by the operation lamp flashing red.
• The USB-AC adaptor will become warm during charging. This is normal and does
not indicate malfunction.
• The shape of the power plug depends on each country or geographic area.
If the operation lamp is not lit or flashing during charging, check the orientation of the
USB cable connectors.
• Make sure that you insert the cable connector into the USB port until you feel it
click securely into place. Failure to insert the connector fully can result in poor
communication or malfunction.
• Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector
Camera
as shown in the illustration.
Controller
20
Quick Start Basics
. To charge using a USB connection to a computer
While the camera and controller are turned off, connect in the sequence shown below
).
(
1, 2
[USB] port
USB port
Computer
(power turned on)
USB
11
[USB] cover
When plugging in the connectors, orient this marking as described below.
Camera : Towards the lens side
Controller: Towards the monitor screen side
• If the camera or controller is on, hold down [p] (Power) to turn it off before
connecting it to your computer.
Charging time: Approximately 150 minutes
NOTE
• If you turn on the camera while charging over a USB connection to a computer is in
progress, the camera will establish a USB connection with the computer. Charging
will continue. Charging will also continue if you turn on the controller. Note that
certain types of computers or connection environments may stop charging if supply
power is low.
Micro USB cable
(included with camera)
2
21
Quick Start Basics
. Operation Lamp Indications
While power is off
Operation Lamp StatusMeaning
Lit redCharging
Charging stopped due to abnormal ambient
Flashing red
temperature, USB-AC adaptor problem, battery
problem (page 102), timer operation.
UnlitCharging complete
While power is on
•Camera
Operation Lamp StatusMeaning
Lit amberCharging
Charging stopped due to abnormal ambient
High speed red-green flashing
temperature, USB-AC adaptor problem, battery
problem (page 102), timer operation.
Lit greenCharging complete
•Controller
Operation Lamp StatusMeaning
Lit amberCharging
Slow red-amber flashingCharging (sleep state)
High-speed green-amber
flashing
Charging stopped due to abnormal ambient
temperature, USB-AC adaptor problem, battery
problem (page 102), timer operation.
High-speed red-green flashingSame as above (sleep state)
Lit greenCharging complete
Slow green flashingCharging complete (sleep state)
22
Quick Start Basics
IMPORTANT!
• The first time you connect the camera or controller to your computer with the USB
cable, an error message may appear on your computer. If this happens, disconnect
and then reconnect the USB cable.
• A battery that has not been used for a long time, certain types of computers, and
connection conditions can cause charging to take more than approximately five
hours, which will trigger a timer that terminates charging automatically, even if the
battery is not fully charged. If this happens, disconnect and then reconnect the
USB cable to restart charging. To complete charging faster, use of the included
USB-AC adaptor is recommended.
• Charging is not performed while the connected computer is in the hibernate mode.
Other Charging Precautions
• With the two charging methods described above, you can charge the batteries.
Never use any other type of charger device. Attempting to use a different charger
can result in unexpected accident.
• This model can be charged only via from USB 2.0 specification USB port only.
• USB charging devices and power supply devices are subject to fixed standards.
Use of an inferior device or a device that is not up to standard can cause
malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you.
Even in the case of a commercially available computer, certain USB port
specifications may make it impossible to charge via the USB cable.
• A battery that is still warm immediately after normal use may not charge fully. Give
the battery time to cool before charging it.
• A battery discharges slightly while it is loaded in the camera or controller. Because
of this, it is recommended that you charge the battery immediately before you need
to use it.
• Charging the battery may cause interference with TV and radio reception. If this
happens, plug the USB-AC adaptor into an outlet that is further away from the TV
or radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging.
Use of any other type of devices may result in improper charging.
23
Quick Start Basics
Checking the Current Battery Level
As battery power is consumed, a battery indicator on the monitor screen indicates its
current level as shown below.
LevelHighLow
Battery
Indicator
Camera***
Controller***
Indicator ColorWhite* White* Red* Red
indicates battery power is low. Charge the battery as soon as possible.
indicates that the battery is about to go dead. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• Leaving the camera for about 5 days with no power supplied while the battery is
dead will cause its date and time settings to be cleared. A message telling you to
configure time and date settings will appear the next time you turn on the camera
after restoring power. When this happens, configure date and time settings (page
68).
• See page 118 for information about battery life and number of shots.
The camera and controller communicate over a
Bluetooth wireless technology connection. Once
you perform the “pairing” operation required for
Bluetooth wireless technology connection, the
camera and controller will automatically connect to each other whenever you turn
them on. Note that the connection will be lost of the distance between the camera and
controller becomes too great or if a wireless LAN connection is established between
the camera and a smartphone. The controller will turn off after a preset amount of
time after the Bluetooth wireless technology connection is lost. The camera will
remain on, so you can shoot images by pressing its shutter button.
IMPORTANT!
• Your camera has Bluetooth wireless technology communication functionality built
in. Avoid operating the camera (including camera standalone operations) inside of
aircraft or anywhere else where wireless data communication is restricted.
NOTE
• The Bluetooth connection settings of this camera cannot be changed.
• The camera and controller’s Bluetooth wireless technology will not connect to any
other type of device.
. To turn on power
Both the camera and controller need to be turned on in order to use them.
Camera
Press [p] (Power).
[p] (Power)
Operation lamp
• Turning on the camera causes the camera and controller operation lamps to light
green, and automatically starts an operation to establish a Bluetooth wireless
technology connection between the camera and controller. An image appears on
the controller and shooting is enabled.
• The connection between the camera and controller is affected by their orientation
and by the distance between them.
Controller
Press [p] (Power).
Operation lamp
25
[p] (Power)
Quick Start Basics
• The maximum range for shooting with the controller’s shutter button is around
10 meters (32.8'). The maximum range for viewing the image on the controller’s
monitor screen is around five meters (16.4').
• If the connection is poor, the controller operation lamp will flash green and
“ ” (Bluetooth communication status) will appear on the monitor screen. Camera
response may be slow if you perform an operation on the controller while
communication conditions are bad. If this happens, try adjusting the orientation and
the distance between the camera and controller.
• Note the precautions below to ensure stable
communication between the camera and controller.
– Position the controller so it is upright, with its screen
in a landscape (horizontal) orientation.
– Make sure nothing is blocking the back of the
controller, which is imprinted with logos and text.
– Point the back of the controller at the camera.
– Make sure nothing is blocking the area around the
camera’s lens ring.
– Make sure there are no obstacles in the path
between the camera and controller.
Sleep Mode
If you press [p] (Power) on the controller or if you do not perform any controller
operation for 25 seconds while there is a Bluetooth wireless technology connection
between the camera and controller, the controller image will go blank. Then, if no
operation is performed for five seconds, the camera and controller will enter a sleep
mode. The operation lamp slowly flashes green while the camera is in the sleep
mode. To restore the controller display, press any controller button. The Bluetooth
wireless technology connection between the camera and controller is maintained
even while they are in the sleep mode, so they can quickly recover when you press a
button.
• If the distance between the camera and controller becomes to great or if
communication conditions become bad while the camera is in the sleep mode, the
connection may be dropped between them.
26
Quick Start Basics
Toggling Between the REC Mode and PLAY Mode
Touch the icon in the lower right corner of the screen or flick the screen upwards or
downwards to toggle between the REC mode and PLAY mode.
REC modePLAY mode
“” (PLAY)
“”(REC)
NOTE
• If “” (PLAY) and/or “” (REC) is not displayed, touch “” or “DISP”.
. To turn off power
On the camera or the controller, hold down [p] (Power).
• Turning off the camera will cause the controller to turn off automatically after about
5 minutes.
Configuring Basic Settings the First Time You Turn On the
Camera
The first time you turn on the camera, a screen appears for configuring the display
language, date, and time settings. Failure to set the date and time correctly will cause
the wrong date and time data to be recorded with images.
IMPORTANT!
• Camera models sold in certain geographic areas may not support display language
selection.
1. Turn on the camera and controller (page 25).
• If this is the first time you are turning on power, a language selection screen will
appear. If the screen does not appear, check to make sure that the camera is
turned on.
2. Flick (page 17) the controller screen upwards and downwards or touch
“”, “” until you find the language you want, and then touch to
select it.
3. Touch the date display format you want.
Example: July 10, 2016
YY/MM/DD
DD/MM/YY
MM/DD/YY
* 16/7/10
* 10/7/16
* 7/10/16
27
Quick Start Basics
4. Set the date and the time.
• Touch the value you want to change (year,
month, day, hour, minute) and then touch “”,
“” to change it.
• To switch between 12-hour and 24-hour format,
select “am (pm)”/“24h” and then touch “”, “”
to change the setting.
12/24 hour switch icon
5. When the date and time settings are the way
you want, touch “Apply”.
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: Page 69
– Date and time: Page 68
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
28
Quick Start Basics
Preparing a Memory Card
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• Snapshots and movies stored in built-in memory cannot be copied to a memory
card.
• For information about memory card capacities, see page 115.
• The above are supported memory card types as of July 2014.
• This camera supports use of microSD memory cards of the
following types and capacities: microSD memory cards up to 2GB, microSDHC
memory cards from 2GB up to 32GB, microSDXC memory cards from 32GB up to
2TB. Note that the ability to use any particular card with this camera, even if it
satisfies the above capacity and type requirements, is not guaranteed.
Warning!
*
0 Memory cards are small and present a risk of accidentally being swallowed
by infants and young children. Keep memory cards out of the reach of
infants and young children. If a memory card is ever swallowed accidentally,
contact a physician immediately.
+
29
Quick Start Basics
To load a memory card
1. Holding down camera’s [p]
(Power) to turn off the camera and
then open the [CARD] cover.
2. Load a memory card.
Positioning the memory card so its back
is facing upwards (towards the lens side
of the camera), slide it into the card slot
all the way in until you hear it click
securely into place.
3. Close the [CARD] cover.
Back
FrontBack
IMPORTANT!
• Never insert anything besides a supported memory card (page 29) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, and contact your retailer or nearest CASIO authorized service center.
30
Quick Start Basics
Loading...
+ 92 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
