Casio E200UG User Manual

Pocket PC

User’s Guide

Your Pocket PC 2002 comes with a Hardware Manual in addition to this Pocket PC User’s Guide. Be sure to read the Hardware Manual first.

Before using your Pocket PC for the first time,carefully read the Safety Precautions in the Hardware Manual.

Keep this Pocket PC User’s Guide on hand for reference whenever using your Pocket PC.

To reset the Pocket PC

If your Pocket PC responds slowly, stops responding as expected, or “freezes,” try resetting it. A reset causes the Pocket PC to restart and re-adjust memory allocation. Unsaved data in open windows may be lost.

• Use the stylus to press and hold the Reset button for about two seconds.

• CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss

resulting from the use of this manual.

• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss or claims by third parties that may arise through the use of this product.

• CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss caused by deletion of data as a result of malfunction, repairs, or battery replacement. Be sure to back up all important data on other media to protect against its loss.

• Data can be uploaded from this unit to a personal computer for storage on a hard disk, floppy diskette, or other storage medium. Be sure to make multiple copies of all important data to protect against its accidental loss.

• The contents of this manual are subject to change without notice.

• No part of this manual may be reproduced in any form without the express written

consent of the manufacturer.

• Sample displays shown in this manual may differ somewhat from the displays actually produced by the product.

• Specifications, peripherals, and other items can change suddenly to meet market needs. Such changes can cause the contents of this manual to become inaccurate.

• Microsoft, ActiveSync, Outlook, Pocket Outlook, Windows, Windows NT, and the

Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Microsoft products are licensed to OEMs by Microsoft Licensing, Inc., a wholly owned subsidiary of Microsoft Corporation.

• All other product and company names mentioned herein may be the trademarks of their respective owners.

Chapter 1: Getting Started .....................................................6

Welcome ............................................................................................................ 6

Where to Find Information ................................................................................ 6

Chapter 2: Basic Skills .............................................................7

Hardware Buttons and Stylus ............................................................................ 7

Today Screen ...................................................................................................... 7

Programs ............................................................................................................ 8

Navigation Bar and Command Bar .................................................................. 10

Pop-up Menus .................................................................................................. 11

Notifications ..................................................................................................... 11

Enter Information on Your Pocket PC .............................................................. 11

Typing Using the Input Panel .............................................................. 12

Writing on the Screen .......................................................................... 14

Drawing on the Screen ........................................................................ 16

Recording a Message .......................................................................... 17

Using My Text ................................................................................................. 18

Find and Organize Information ........................................................................ 19

Customize Your Pocket PC .............................................................................. 19

Adjusting Settings ............................................................................... 19

Adding or Removing Programs........................................................... 20

Chapter 3: Microsoft ActiveSync .........................................22

Chapter 4: Microsoft Pocket Outlook ..................................24

Calendar: Scheduling Appointments and Meetings ......................................... 24

Using the Summary Screen ................................................................. 26

Creating Meeting Requests ................................................................. 26

Contacts: Tracking Friends and Colleagues ................................................... 27

Finding a contact ................................................................................. 28

Using the Summary Screen ................................................................. 28

Tasks: Keeping a To Do List ........................................................................... 29

Using the Summary Screen ................................................................. 30

Notes: Capturing Thoughts and Ideas ............................................................. 30

Inbox: Sending and Receiving E-mail Messages............................................ 31

Synchronizing E-mail Messages ......................................................... 31

Connecting Directly to an E-mail Server ............................................ 32

Using the Message List ....................................................................... 32

Composing E-mail Messages .............................................................. 34

Managing E-mail Messages and Folders ............................................ 34

Chapter 5: Companion Programs ....................................... 36

Pocket Word ..................................................................................................... 36

Typing Mode ....................................................................................... 37

Writing Mode ...................................................................................... 38

Drawing Mode ..................................................................................... 39

Recording Mode .................................................................................. 39

Pocket Excel .................................................................................................... 40

Tips for Working in Pocket Excel ....................................................... 41

Windows Media Player for Pocket PC............................................................. 42

Microsoft Reader ............................................................................................. 43

Getting Books on Your Pocket PC ...................................................... 43

Using the Library ................................................................................ 43

Reading a Book ................................................................................... 44

Using Reader Features ........................................................................ 45

Removing a Book ................................................................................ 45

Chapter 6: MSN Messenger .................................................46

Setting Up ........................................................................................................ 46

Working with Contacts .................................................................................... 46

Chatting with Contacts ..................................................................................... 47

Chapter 7: Pocket Internet Explorer ....................................48

The Mobile Favorites Folder ............................................................................ 48

Favorite Links .................................................................................................. 48

Mobile Favorites .............................................................................................. 48

Using AvantGo Channels ................................................................................. 49

Using Pocket Internet Explorer ........................................................................ 50

To browse the Internet: ........................................................................ 51

Chapter 8: Getting Connected ............................................52

Transfer Items Using Infrared .......................................................................... 52

Connect to the Internet ..................................................................................... 53

Connect to Work .............................................................................................. 54

End a Connection ............................................................................................. 56

Connect Directly to an E-mail Server .............................................................. 56

Get Help on Connecting .................................................................................. 57

Appendix: Troubleshooting ..................................................58

Reset the Pocket PC and clear memory ........................................................... 58

Batteries lose power ......................................................................................... 58

If you forget your password ............................................................................. 59

If you run out of Pocket PC memory ............................................................... 59

Storage memory .................................................................................. 59

Program memory ................................................................................. 60

Screen freezes or responds slowly ................................................................... 60

Screen is blank ................................................................................................. 60

Screen is dark ................................................................................................... 60

Screen is hard to read ....................................................................................... 61

Inaccurate response to stylus taps .................................................................... 61

Slow or no response ......................................................................................... 61

Infrared (IR) connection problems .................................................................. 61

Modem connection problems ........................................................................... 61

Network connection problems ......................................................................... 62

Cable and cradle connection problems ............................................................ 63

INDEX ............................................................................................................. 64

Important!

Browsing the Web or synchronizing a large number of mobile favorites can cause your device to run low on storage space. To free storage space, open Pocket Internet Explorer and tap Tools

Options.... Then, on the General tab, tap Delete Files to delete all Web pages stored on your

device, including offline favorites content.

Chapter 1: Getting Started

Welcome

Congratulations on purchasing your Pocket PC. Its compact size and powerful features and functions let you keep your most important business and personal information up-to-date and close at hand. Microsoft synchronize the information on your desktop or laptop computer with your Pocket PC. Picture yourself in the following situations:

• While walking with a colleague, your cell phone rings and the boss asks if you two are free this afternoon for an emergency meeting. While your colleague fumbles through his paper organizer, you press a button on your Pocket PC and instantly see a list of today’s appointments and meetings. You are quickly able to tell the boss your available times. For more information on scheduling appointments and meetings, see Chapter 4.

• You’re meeting your friends tonight for dinner and a movie. You download the latest movie information from the Internet to your desktop computer and then synchronize it with your Pocket PC. At dinner, you pull out your Pocket PC and review your movie options with your friends. For more information on downloading Web pages, see Chapter 7.

• A Calendar reminder alerts you that it is time to catch the bus. You grab your Pocket PC and catch the bus just in time. Because ActiveSync keeps the information on your Pocket PC up-todate, you leisurely review your task list, make notes about the new books and CDs you want to buy, and read and respond to e-mail messages. When you get back to the office, ActiveSync transfers any task changes you made, your notes, and your e-mail message responses to your desktop computer. For more information on ActiveSync, see Chapter 3.

Where to Find Information

This manual provides an overview of the programs on your Pocket PC, and explains how to connect your Pocket PC to a desktop computer, a network, or the Internet. For information on your Pocket PC hardware, see the Hardware Manual. For instructions on setting up your Pocket PC and installing ActiveSync, see the Quick Start Guide. The following table is a guide to additional information to help you use your Pocket PC.

ActiveSync® increases the power of your Pocket PC by allowing you to

For information on:

Programs on your Pocket PC

Additional programs that can be installed on the Pocket PC

Connecting to and synchronizing with a desktop computer

Last-minute updates and detailed technical information

Up-to-date information on Windows®powered Pocket PCs

See this source:

This User’s Guide and Pocket PC Help. To view Help, tap and then Help.

The CASSIOPEIA CD-ROM.

The Quick Start Guide or ActiveSync Help on your desktop computer. To view Help, click Help and then Microsoft ActiveSync

Help.

The Read Me files, located in the Microsoft ActiveSync folder on the desktop computer and on the Pocket PC Companion CD.

http://www.microsoft.com/mobile/pocketpc/

Chapter 2: Basic Skills

Learning to use your Pocket PC is easy. This chapter describes the basic concepts of using and customizing your Pocket PC.

Hardware Buttons and Stylus

Your Pocket PC has hardware buttons that control actions and scroll functions, and a stylus for selecting items and entering information. On the Pocket PC, the stylus replaces the mouse.

• Tap. Touch the screen once with the stylus to open items and select options.

• Drag. Hold the stylus on the screen and drag across the screen to select text and images. Drag

in a list to select multiple items.

• Tap-and-hold. Tap and hold the stylus on an item to see a list of actions available for that item. On the pop-up menu that appears, tap the action you want to perform.

Today Screen

When you turn on your Pocket PC for the first time each day (or after 4 hours of inactivity), you’ll see the Today screen. You can also display it by tapping screen, you can see at a glance important information for the day.

Tap to switch to a program.

Tap to view notification messages.

Tap to change volume or mute all sounds.

Tap to change date and time.

Tap to open an item.

and then Today. On the Today

Tap to create a new item.

Your day at a glance.

Tap to view connection status.

You may see the following status icons on the command bar or on the navigation bar.

Status Icon Meaning

Turns all sounds on and off

Backup battery is low, very low, or is not loaded in the Pocket PC

Main batteries are charging

Main batteries are low

Main batteries are very low

Main batteries are full

Connection is active

Synchronization is beginning or ending

Synchronization is occurring

Notification that one or more instant messages were received

Notification that one or more e-mail messages were received

Dial-up connection is active

Direct connection is active

If more notification icons need to be displayed than there is room to display them, the Notification icon,

, will display. Tap the icon to view all notification icons.

Programs

You can switch from one program to another by selecting it from the menu. (You can customize which programs you see on this menu. For information, see “Adjusting Settings,” later in this chapter.) To access some programs, you’ll need to tap program name. You can also switch to some programs by pressing a program button. Your Pocket PC has one or more program buttons located on its front or side. The icons on the buttons identify the programs they switch to.

The following table contains a partial list of programs that are on your Pocket PC. Look on the Pocket PC Companion CD for additional programs that you can install onto your Pocket PC.

, Programs, and then the

Icon

Program

ActiveSync

Calendar

Contacts

Description

Synchronize information between your device and desktop computer.

Keep track of your appointments and create meeting requests.

Keep track of your friends and colleagues.

Inbox

Pocket Internet

Explorer

Notes

Tasks

Pocket Excel

MSN

Messenger

Pocket Word

Card Backup Tool

Send and receive e-mail messages.

Browse Web and WAP sites, and download new programs and files from the Internet.

Create handwritten or typed notes, drawings, and recordings.

Keep track of your tasks.

Create new workbooks or view and edit Excel workbooks created on your desktop computer.

Send and receive instant messages with your MSN Messenger contacts.

Create new documents or view and edit Word documents created on your desktop computer.

Launch applications and open files.

Back up and restore your device card.

memory data to a memory

Navigation Bar and Command Bar

The navigation bar is located at the top of the screen. It displays the active program and current time, and allows you to switch to programs and close screens. Use the command bar at the bottom of the screen to perform tasks in programs. The command bar includes menu names, buttons, and the input panel button. To create a new item in the current program, tap New. To see the name of a button, tap and hold the stylus on the button. Drag the stylus off the button so that the command is not carried out.

Tap to change volume or mute the device.

Tap to quickly select a program you have recently used.

Tap to select a program.

Tap to see additional programs. Tap to customize the device.

Pop-up Menus

With pop-up menus, you can quickly choose an action for an item. For example, you can use the pop-up menu in the contact list to quickly delete a contact, make a copy of a contact, or send an email message to a contact. The actions in the pop-up menus vary from program to program. To access a pop-up menu, tap and hold the stylus on the item name that you want to perform the action on. When the menu appears, lift the stylus, and tap the action you want to perform. Or tap anywhere outside the menu to close the menu without performing an action.

Tap and hold to display the pop-up menu.

Lift the stylus and tap the action you warit.

Tap outside the menu to close it without performing an action.

Notifications

Your Pocket PC reminds you in a variety of ways when you have something to do. For example, if you’ve set up an appointment in Calendar, a task with a due date in Tasks, or an alarm in Clock, you’ll be notified in any of the following ways:

• A message box appears on the screen.

• A sound, which you can specify, is played.

• A light flashes on your Pocket PC.

To choose reminder types and sounds for your Pocket PC, tap Personal tab, tap Sounds & Notifications. The options you choose here apply throughout the Pocket PC.

and then Settings. In the

Enter Information on Your Pocket PC

You have several options for entering new information:

• Use the input panel to enter typed text, either by using the soft keyboard or Character Recognizer.

• Write directly on the screen.

• Draw pictures on the screen.

• Speak into your Pocket PC microphone to record a message.

• Use Microsoft

to your Pocket PC. For more information on ActiveSync, see ActiveSync Help on your desktop computer.

ActiveSync® to synchronize or copy information from your desktop computer

Typing Using the Input Panel

Use the input panel to enter information in any program on your Pocket PC. You can either type using the onscreen keyboard or write using Letter Recognizer, Block Recognizer, or Tramscriber. In either case, the characters appear as typed text on the screen. To show or hide the input panel, tap the Input Panel button. Tap the arrow next to the Input Panel button to see your choices.

Select an input method.

Tap to see your choices.

Input Panel button.

When you use the input panel, your Pocket PC anticipates the word you are typing or writing and displays it above the input panel. When you tap the displayed word, it is inserted into your text at the insertion point. The more you use your Pocket PC, the more words it learns to anticipate.

Tap here if this is the right word.

To change word suggestion options, such as the number of words suggested at one time,

, Settings, Personal tab, Input, and then the Word Completion tab.

tap

To type with the onscreen keyboard

1. Tap the arrow next to the Input Panel button and then Keyboard.

2. On the keyboard that is displayed, tap the keys with your stylus.

To type with the soft keyboard:

1. Tap the arrow next to the Input Panel button and then Keyboard.

2. On the soft keyboard that is displayed, tap the keys with your stylus.

To use Letter Recognizer:

With Letter Recognizer you can write letters using the stylus just as you would on paper.

1. Tap the arrow next to the Input Panel button and then Letter Recognizer.

2. Write a letter in the box.

When you write a letter, it is converted to typed text that appears on the screen. For specific instructions on using Letter Recognizer, with Letter Recognizer open, tap the question mark next to the writing area.

To use Block Recognizer:

With Block Recognizer you can input character strokes using the stylus that are similar to those used on other devices.

1. Tap the arrow next to the Input Panel button and then Block Recognizer.

2. Write a letter in the box.

When you write a letter, it is converted to typed text that appears on the screen. For specific instructions on using Block Recognizer, with Block Recognizer open, tap the question mark next to the writing area.

To use Transcriber:

With Transcriber you can write anywhere on the screen using the stylus just as you would on paper. Unlike Letter Recognizer and Block Recognizer, you can write a sentence or more of information. Then, pause and let Transcriber change the written characters to typed characters.

1. Tap the arrow next to the Input Panel button and then Transcriber.

2. Write anywhere on the screen.

For specific instructions on using Transcriber, with Transcriber open, tap the question mark in the lower right hand corner of the screen.

To select typed text

If you want to edit or format typed text, you must select it first.

• Drag the stylus across the text you want to select.

You can cut, copy, and paste text by tapping and holding the selected words and then tapping an editing command on the pop-up menu, or by tapping the command on the Edit menu.

Writing on the Screen

In any program that accepts writing, such as the Notes program and the Notes tab in Calendar, Contacts, and Tasks, you can use your stylus to write directly on the screen. Write the way you do on paper. You can edit and format what you’ve written and convert the information to text at a later time.

To write on the screen

Tap the Pen button to switch to writing mode. This action displays lines on the screen to help you write.

Tap the Pen button and use your stylus like a pen.

Some programs that accept writing may not have the Pen button. See the documentation for that program to find out how to switch to writing mode.

To select writing

If you want to edit or format writing, you must select it first.

1. Tap and hold the stylus next to the text you want to select until the insertion point appears.

2. Without lifting, drag the stylus across the text you want to select.

If you accidentally write on the screen, tap Edit and then Undo and try again. You can also select text by tapping the Pen button to deselect it and then dragging the stylus across the screen. You can cut, copy, and paste written text in the same way you work with typed text: tap and hold the selected words and then tap an editing command on the pop-up menu, or tap the command on the Edit menu.

To convert writing to text

Tap Tools and then Recognize. If you want to convert only certain words, select them before tapping Recognize on the Tools menu (or tap and hold the selected words and then tap Recognize on the pop-up menu). If a word is not recognized, it is left as writing.

Select the text you want to convert and tap Recognize on the pop-up menu.

The writing is turned into text.

If the conversion is incorrect, you can select different words from a list of alternates or return to the original writing. To do so, tap and hold the incorrect word (tap one word at a time). On the pop-up menu, tap Alternates. A menu with a list of alternate words appears. Tap the word you want to use, or tap the writing at the top of the menu to return to the original writing.

Tap to return to your original writing.

Or, tap the word you want to use.

Tips for getting good recognition

• Write neatly.

• Write on the lines and draw descenders below the line. Write the cross of the “t” and

apostrophes below the top line so that they are not confused with the word above. Write periods and commas above the line.

• For better recognition, try increasing the zoom level to 300% using the Tools menu.

• Write the letters of a word closely and leave big gaps between words so that the Pocket PC can

easily tell where words begin and end.

• Hyphenated words, foreign words that use special characters such as accents, and some punctuation cannot be converted.

• If you add writing to a word to change it (such as changing a “3” to an “8”) after you attempt to recognize the word, the writing you add will not be included if you attempt to recognize the writing again.

Drawing on the Screen

You can draw on the screen in the same way that you write on the screen. The difference between writing and drawing on the screen is how you select items and how they can be edited. For example, selected drawings can be resized, while writing cannot.

To create a drawing

Cross three ruled lines on your first stroke. A drawing box appears. Subsequent strokes in or touching the drawing box become part of the drawing. Drawings that do not cross three ruled lines will be treated as writing.

The drawing box indicates the boundaries of the drawing.

Pen button.

You may want to change the zoom level so that you can more easily work on or view your drawing. Tap Tools and then select a zoom level.

To select a drawing

If you want to edit or format a drawing, you must select it first.

• Tap and hold the stylus on the drawing until the selection handle appears. To select multiple drawings, deselect the Pen button and then drag to select the drawings you want.

You can cut, copy, and paste selected drawings by tapping and holding the selected drawing and then tapping an editing command on the pop-up menu, or by tapping the command on the Edit menu. To resize a drawing, make sure the Pen button is not selected, and drag a selection handle.

Recording a Message

In any program where you can write or draw on the screen, you can also quickly capture thoughts, reminders, and phone numbers by recording a message. In Calendar, Tasks, and Contacts, you can include a recording in the Notes tab. In the Notes program, you can either create a stand-alone recording or include a recording in a written note. If you want to include the recording in a note, open the note first. In the Inbox program, you can add a recording to an e-mail message.

To create a recording

1. Hold your Pocket PC’s microphone near your mouth or other source of sound.

2. Press and hold the Record hardware button on your Pocket PC until you hear a beep.

3. While holding down the Record button, make your recording.

4. To stop recording, release the Record button. Two beeps will sound. The new recording

appears in the note list or as an embedded icon.

You can also make a recording by tapping the Record button on the Recording toolbar.

To play a recording, tap it in the list or tap its icon in the note.

Indicates an embedded recording.

Tap to show or hide the Recording toolber.

Tap to begin recording.

Using My Text

When using Inbox or MSN Messenger, use My Text to quickly insert preset or frequently used messages into the text entry area. To insert a message, tap My Text and tap a message.

Tap to select a prewritten message.

You can add text after inserting a My Text message before sending it.

To edit a My Text message, in the Tools menu, tap Edit and then tap My Text Messages. Select the message you wish to edit and make desired changes.

Find and Organize Information

The Find feature on your Pocket PC helps you quickly locate information.

• On the to start the search.

You can also use the File Explorer to find files on your Pocket PC and to organize these files into folders. On the

Tap to change folders.

menu, tap Find. Enter the text you want to find, select a data type, and then tap Go

To quickly find information that is taking up storage space on your Pocket PC, select Larger than 64 KB in Type.

menu, tap Programs, and then File Explorer.

Select the sort order for the list.

Tap the folder name to open it.

Tap and hold to create a new folder.

You can move files in File Explorer by tapping and holding the item you want to move and then tapping Cut or Copy and Paste on the pop-up menu.

Customize Your Pocket PC

You can customize your Pocket PC by adjusting Pocket PC settings and installing additional software.

Adjusting Settings

You can adjust Pocket PC settings to suit the way you work. To see available options, tap , Settings, then the Personal or System tab located at the bottom of the screen. You might want to adjust the following:

• Clock, to change the time or to set alarms

• Menus, to customize what appears on the

New button

• Owner Information, to enter your contact information

• Password, to limit access to your Pocket PC

• Power, to maximize battery life

• Today, to customize the information that is displayed on the Today screen

• Brightness, to adjust the brightness of the front light.

• Program Button Control, to disable the front light so it does not light when you press the

Program button.

menu and to enable a pop-up menu from the

Adding or Removing Programs

Programs added to your device at the factory are stored in ROM (read-only memory). You cannot remove this software, and you’ll never accidentally lose ROM contents. ROM programs can be updated using special installation programs with a *.xip extension. All other programs and data files added to your device after factory installation are stored in RAM (random access memory).

You can install any program created for your device, as long as your device has enough memory. The most popular place to find software for your device is on the Pocket PC Web site (http://www.microsoft.com/mobile/pocketpc).

To add programs using ActiveSync

Yo u ’ll need to install the appropriate software for your Pocket PC on your desktop computer before installing it on your Pocket PC.

1. Determine your Pocket PC and processor type so that you know which version of the software

to install. Tap make a note of the information in Processor.

2. Download the program to your desktop computer (or insert the CD or disk that contains the

program into your desktop computer). You may see a single *.xip, *.exe, or *.zip file, a Setup.exe file, or several versions of files for different Pocket PC types and processors. Be sure to select the program designed for the Pocket PC and your Pocket PC processor type.

3. Read any installation instructions, Read Me files, or documentation that comes with the

program. Many programs provide special installation instructions.

4. Connect your Pocket PC and desktop computer.

5. Double-click the *.exe file.

• If the file is an installer, the installation wizard will begin. Follow the directions on the screen. Once the software has been installed on your desktop computer, the installer will automatically transfer the software to your Pocket PC.

• If the file is not an installer, you will see an error message stating that the program is valid but it is designed for a different type of computer. You will need to move this file to your Pocket PC. If you cannot find any installation instructions for the program in the Read Me file or documentation, use ActiveSync Explore to copy the program file to the Program Files folder on your Pocket PC. For more information on copying files using ActiveSync, see ActiveSync Help.

Once installation is complete, tap

and then Settings. On the System tab, tap About. Tap the Version tab, and

, Programs, and then the program icon to switch to it.

To add a program directly from the Internet

1. Determine your Pocket PC and processor type so that you know which version of the software

to install. Tap note of the information in Processor.

2. Download the program to your device straight from the Internet using Pocket Internet

Explorer. You may see a single *.xip, *.exe or *.zip file, a Setup.exe file, or several versions of files for different device types and processors. Be sure to select the program designed for the Pocket PC and your device processor type.
