Cary Audio Design
DVD6dvdplayer
RS-232 Protocol and Control Details
Com Port Setup:
Use standard communications settings. The default that most devices use/accept is:
Baud Rate - 9600
Data Bits - 8
Parity - None
Stop Bits - 1
Com Port Pin Configuration:
Use standard pin configuration. A configuration that allows direct connection to a PC via
9-pin straight through serial cable is best. Use of only 3 pins(Transmit, Receive, Ground)is best.
9 pin female D connector
Pin2=Transmit
Pin 3 = Receive
Pin 5 = Ground
RS-232 interface :
Commands are to be sent to the unit via RS-232 using the following format:
<Command> = <Command ID><Argument>
<Command ID> = <Byte>
<Argument> = 0x0d
<Byte> = 0x30,0x30
Status Byte:
Upon receiving the command and done, a single status byte will be transmitted
The format for the status byte is :
<Status Byte> = <Command>
<Command> = 0x31,0x30,0x30
RS232-Interface Usage Details:
The RS-232 interface has a first-in-first-out (FIFO) buffer which will allow each commands to be
received in direct succession. Commands are executed in the order in which they are received with
approximately a 1/2 second delay between each command. If a longer string of commands is
necessary, a minimum of 1/2 second delay should be added before sending additional commands.
Example for sending a long string of commands:
[Command 1]
<Delay 1/2 second>
[Command 2]
<Delay 1/2 second>
[Command 3]
<Delay 1/2 second>
If receiving the errors data, a single status byte will be transmitted. The status byte is:
Rs232 = <ERR>
ASCII = <0x45,0x58,0x58>
Upon
Recei ving the Command and done a Single Status byte will be transmitted
Command description
POWER ON
POWER OFF
TRAY OPEN/CLOSE
PLAY
PREVIOUS
PA U SE
STOP
NEXT
REVERSE
FORWARD
NUMBER KEY PAD 1
NUMBER KEY PAD 2
NUMBER KEY PAD 3
NUMBER KEY PAD 4
NUMBER KEY PAD 5
NUMBER KEY PAD 6
NUMBER KEY PAD 7
NUMBER KEY PAD 8
NUMBER KEY PAD 9
NUMBER KEY PAD 0
NUMBER KEY PAD +10
GOTO
REPEA T ALL
REPEAT A-B
POWER ON/OFF
MUTE
VOLUME -
VOLUME +
DVD ANGLE
DVD SUB-T ITLE
DVD AUDIO
DVD MENU
DVD ON SCREEN DISPLA Y
DVD TITLE
SETUP MENU
NAVIGATION UP
NAVIGATION DOWN
NAVIGATION LEFT
NAVIGATION RIGHT
NAVIGATION ENTER
ZOOM -
ZOOM +
Rs232
Command
00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
18
2A
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
ASCII
Command
0x30,0x30,0x0d
0x30,0x31,0x0d
0x30,0x32,0x0d
0x30,0x33,0x0d
0x30,0x34,0x0d
0x30,0x35,0x0d
0x30,0x36,0x0d
0x30,0x37,0x0d
0x30,0x38,0x0d
0x30,0x39,0x0d
0x30,0x41,0x0d
0x30,0x42,0x0d
0x30,0x43,0x0d
0x30,0x44,0x0d
0x30,0x45,0x0d
0x30,0x46,0x0d
0x31,0x30,0x0d
0x31,0x31,0x0d
0x31,0x32,0x0d
0x31,0x33,0x0d
0x31,0x34,0x0d
0x31,0x35,0x0d
0x31,0x36,0x0d
0x31,0x38,0x0d
0x32,0x41,0x0d
0x31,0x39,0x0d
0x31,0x41,0x0d
0x31,0x42,0x0d
0x31,0x43,0x0d
0x31,0x44,0x0d
0x31,0x45,0x0d
0x31,0x46,0x0d
0x32,0x30,0x0d
0x32,0x31,0x0d
0x32,0x32,0x0d
0x32,0x33,0x0d
0x32,0x34,0x0d
0x32,0x35,0x0d
0x32,0x36,0x0d
0x32,0x37,0x0d
0x32,0x38,0x0d
0x32,0x39,0x0d
Status
Command Description
Take unit out of standb
Putunitinstandby
Tr ay op en
Tr ay cl os e
Play
Previous
Pause
Stop
Next
Reverse
Fo r ward
Number Keypad 1
Number Keypad 2
Number Keypad 3
Number Keypad 4
Number Keypad 5
Number Keypad 6
Number Keypad 7
Number Keypad 8
Number Keypad 9
Number Keypad 0
Number Keypad +10
Goto
Re peat Al l
RepeatA-B
Power on/off
Mute
Volume -
Volume +
DVD Angle
DVD Sub-title
DVD Audio
DVD Menu
DVD on screen disply
DVD Title
Setup Menu
Navig ation up
Navig ation Down
Navig ation Left
Navig ation Right
Navig ation Enter
Zoom -
Zoom +
y
Rs232
Command
100
101
102a
102b
103
104
105
106
107
108
109
10A
10B
10C
10D
10E
10F
110
111
112
113
114
115
116
118
12A
119
11A
11B
11C
11D
11E
11F
120
121
122
123
124
125
126
127
128
129
0x31,0x30,0x30
0x31,0x30,0x31
0x31,0x30,0x32,0x41
0x31,0x30,0x32,0x42
0x31,0x30,0x33
0x31,0x30,0x34
0x31,0x30,0x35
0x31,0x30,0x36
0x31,0x30,0x37
0x31,0x30,0x38
0x31,0x30,0x39
0x31,0x30,0x41
0x31,0x30,0x42
0x31,0x30,0x43
0x31,0x30,0x44
0x31,0x30,0x45
0x31,0x30,0x46
0x31,0x31,0x30
0x31,0x31,0x31
0x31,0x31,0x32
0x31,0x31,0x33
0x31,0x31,0x34
0x31,0x31,0x35
0x31,0x31,0x36
0x31,0x31,0x38
0x31,0x32,0x41
0x31,0x31,0x39
0x31,0x31,0x41
0x31,0x31,0x42
0x31,0x31,0x43
0x31,0x31,0x44
0x31,0x31,0x45
0x31,0x31,0x46
0x31,0x32,0x30
0x31,0x32,0x31
0x31,0x32,0x32
0x31,0x32,0x33
0x31,0x32,0x34
0x31,0x32,0x35
0x31,0x32,0x36
0x31,0x32,0x37
0x31,0x32,0x38
0x31,0x32,0x39
ASCII
Command
