SPECIFICATIONS
Printed in U.S.A. E40 0110
Carter-Hoffmann is a trademark
of Carter-Hoffmann, LLC
MDPM2 & MDPM4
PIE MERCHANDISERS
(For cooked & boxed individual pies)
CONSTRUCTION...Completely welded
stainless steel cabinet construction.
CABINET MATERIAL...All stainless steel
construction; 20 gauge polished exterior
and 24 gauge interior.
PIE CADDY... Stainless steel removable
pie caddy holds individually boxed pies.
MDPM2 has 2 columns and MDPM4 has
4 columns. Precision engineered hole
pattern in walls facilitates even circulation
of warm air throughout cabinet.
Removable for easy cabinet cleaning.
INSULATION...High density fiberglass,
full 1” thick continuous wrap-around type
in top, bottom and sides.
DOOR...Double panel stainless steel; 20
gauge polished exterior and 24 gauge
interior; gasketless design. With heavyduty hinge, built-in finger grab and
magnetic catch. Illuminated panel for
point of purchase graphic panel. Holes at
base indicate low product level.
CONTROLS... On/off switch with power
indicating light. Programmable controller
with low temperature alarm. Factory preset temperature of 165OF (74OC).
HEATING SYSTEM... Forced air heating
system. Incoloy-sheathed heating
element, fan motor, solid state
temperature controller.
ELECTRICAL CHARACTERISTICS...
Standard: 120 volts, 60 cycle, single
phase, 500 watts, 4.2 amps. Ten foot
power ford with 15 amp plug.
Options:
1) 200-208 volts, 413/446 watts, 50-60
cycle, single phase, 2.1 - 2.2 amps.*
2) 220-240 volts, 500/595 watts, 50-60
cycle, single phase, 2.3-2.5 amps.*
*International versions (specify plug type
by destination country).
PERFORMANCE...Preheat to 165OF
(74OC) in 10 minutes.
ACCESSORIES/OPTIONS...
Contact factory for other options on
volume orders
Specifications subject to change through product improvement & innovation.
CARTER-HOFFMANN
1551 McCormick Ave., Mundelein, IL 60060
(847) 362-5500 • (800) 323-9793 • Fax (847) 367-8981
www.carter-hoffmann.com
Model Pie Capacity Inside Working Overall Dimensions Shipping
Number Height Height Depth Width Weight
baked* fried in mm in mm in mm in mm lbs kgs
MDPM2 28 24 17
1
/
2
445 26
3
/
8
670 10 254 9
1
/
2
241 40 18
MDPM4 42 36 17
1
/
2
445 26
3
/
8
670 10 254 12
3
/
16
310 45 20
*Capacity shown for pie box dimensions of 3”wide x 6” deep x 1 1/4” high (76mmx152mmx32mm). Actual capacity may vary, depending on box
dimensions.
FOOD SERVICE EQUIPMENT
HEATED CABINETS
CARTER-HOFFMANN
MDPM4
Front View
MDPM4
Side View
MDPM4
Top View
MDPM2
Front View
MDPM2
Side View
MDPM2
Top View
Carter-Hoffmann CAD Dwg Scale: 1/2” = 1’
MDPM2 & MDPM4
PIE MERCHANDISERS
(For cooked & boxed individual pies)
Since 1947, Foodservice Equipment That Delivers!
FEATURES & BENEFITS
1551 McCormick Avenue, Mundelein, Illinois 60060
Tel. (847)362-5500
.
(800)323-9793
.
Fax (847)367-8981
www.carter-hoffmann.com
SMART CONSTRUCTION... Double-wall insulated construction with all electrical
components located at the top of the cabinet. Components are protected and easily
serviced through the top of the cabinet. Viewing holes at base of door indicate when pie
level is low.
PROGRAMMABLE CONTROLLER...
Electronic controller with digital display and
low temperature alarm
PIE CADDY... Removable for easy cleaning.
Reserve pie capacity above wire helps to
ensure constant supply of pies. When reserve
pies are moved below to the serving zone, it’s
time to make more. Two columns in MDPM2
and 3 columns in MDPM4
ACTIVE HEAT CIRCULATION... Circulated
heat reduces hot and cold spots in cabinet.
Precision-engineered holes in pie caddy
direct air flow evely and efficently.
GRAPHIC PANEL... Lighted POP display
serves to attract attention to cabinet and
merchandise pies. Graphic can be changed
as needed.
MDPM2
