Specifications subject to change through product improvement & innovation.
SPECIFICATIONS
Printed in U.S.A. SSIT 0114
Carter-Hoffmann is a trademark
of Carter-Hoffmann LLC.
STARTER STATIONS &
INDUCTION TABLES
For Healthcare Facilities
CONSTRUCTION...Completely
welded straight line modular
construction. All horizontal supports
are welded and polished to vertical
uprights to form one-piece rigid cart.
Extra welds on bottom supports for
maximum support and added
durability. Design allows for
cantilever or straddle use over
conveyor line.
CABINET MATERIAL...All stainless
steel construction; Framework and
supports constructed of 1” x 18
gauge seamless, polished stainless
steel tubing.
CASTERS...Stem mounted 5”
diameter red Performa casters. All
full ball bearing swivel. Two fitted
with brakes
STORAGE...Accommodate 14.75” x
8.25” x 7” plastic storage bins with
dividers (included)
OPTIONS AND ACCESSORIES...
Plastic bin
Plastic bin divider
Model Capacity Overall Dimensions Caster Shipping
Number of Height Depth Width Diameter Weight
Storage Bins in mm in mm in mm in mm lbs kg
SS36 8 67
3
/
8
1711 31 787 37
1
/
2
953 5 127 115 52
SS48 10 67
3
/
8
1711 31 787 49
1
/
2
1257 5 127 125 57
SS60 14 67
3
/
8
1711 31 787 61
1
/
2
1562 5 127 135 61
SS72 16 67
3
/
8
1711 31 787 73
1
/
2
1867 5 127 145 66
FOOD SERVICE EQUIPMENT
STARTERS & INDUCTION TABLES
CARTER-HOFFMANN
CARTER-HOFFMANN
1551 McCormick Ave., Mundelein, IL 60060
(847) 362-5500 • (800) 323-9793 • Fax (847) 367-8981
www.carter-hoffmann.com
SS60
Starter Station
IT3024
Induction Table
IT3024M
Induction Table
STARTER STATIONS
INDUCTION TABLES
Model Type Overall Dimensions Caster Shipping
Number Height Depth Width Diameter Weight
in mm in mm in mm in mm lbs kg
IT3024 Stationary 30
3
/
8
771 24 588 30 762 - - 71 32
IT3024M Mobile 30
3
/
8
771 24
7
/
8
632 30
7
/
8
784 5 127 68 31
CONSTRUCTION...All welded
stainless steel construction with
marine edge top and under-shelf.
Stainless steel 18 gauge 1.5” tubular
vertical and 1” horizontal supports.
MATERIAL...Sturdy stainless steel
platform to hold charging station and
shelf below for additional storage.
CASTERS/LEGS...IT3024: stem
mounted 5” diameter red Performa
casters. All full ball bearing swivel.
Two fitted with brakes. IT3024M:
adjustable stainless steel bullet feet.
