Contents:
XM-HD Series Binoculars
2-3
Count on Carson
... to bring you and your customers truly innovative,
high-quality optics at extraordinary value. We’ve become a leading supplier in
consumer optics for people of all ages and interests.
Whether you’re a hunter, birder, sports fan, or concert goer, Carson has the
perfect optical product to enhance your viewing experience. Our new state-
of-the-art design center enables us to offer innovative products and attractive
packaging at a reasonable cost. Carson’s dedicated sales team provides the
personalized support necessary to meet your every need.
XM Series Binoculars
YK Series Binoculars
Full Size / Zoom Binoculars
Compact Binoculars
Monoculars & Scopes
Pocket Microscopes
Telescopes
Cleaning Accessories
Tripods / Accessories
Outdoor Magnifiers / Kids
Custom Packaging / Terminology
4-5
6-7
8-9
10-11
12-13
14-15
16
17
18-19
20-21
22-23
No-Fault, No-Hassle Warranty* At Carson, we manufacture only
the highest quality binoculars. We’re so condent in our products that
we back them with America’s best binocular warranty! See our website
for details. In the event that your binoculars get damaged, regardless
of cause, Carson will repair or replace them for a total cost of $12, which
includes all return shipping and handling fees, NO HIDDEN CHARGES!
If your binoculars are found to have manufacturing defects in materials or workmanship, Carson will repair or replace your binoculars and
return them FREE-OF-CHARGE. Please Call for details.
*Battery operated items are protected by our Standard One-Year Limited Warranty.
Carson Optical
35 Gilpin Avenue
Hauppauge, New York 11788-4723
Phone 631-963-5000 | Fax 631-427-6749
For information, call toll-free: 1-800-967-8427
info@carsonoptical.com
sales@carsonoptical.com
www.carsonoptical.com
High Definition
Binocular Series
Features an
astonishing 84.7%
light transmission that
outperforms most of
our competitor’s more
expensive models.
See test results at www.carsonoptical.com
ULTRA BRIGHT IMAGE
NEW!
XM-050HD
10 x 50mm
High Definition
Fully Multi-Coated | O-Ring Sealed | Phase Coated | Waterproof | Fog Proof
Model XM-842HD XM-042HD XM-050HD XM-832HD
Magnification 8 x 42mm 10 x 42mm 10 x 50mm 8 x 32mm
Prism BAK-4 BAK-4 BAK-4 BAK-4
Lens Coating FMC FMC FMC FMC
Field of View 330 ft 314 ft 262 ft 420 ft
Eye Relief 22mm 17mm 19mm 15.5mm
Close Focus 13.1 ft 16 ft 19 ft 9.8 ft
Weight 24.3 oz. 24.3 oz. 34 oz. 20.6 oz.
XM-042HD
10 x 42mm
XM-842HD
8 x 42mm
HD OPTICAL
COATING TO
ENHANCE
BRIGHTNESS
NEW!
XM-832HD
8 x 32mm
High Definition
3
XM-842
8 x 42mm
ULTRA BRIGHT
Fully Multi-Coated | O-Ring Sealed Phase Coated | Waterproof | Fog Proof
Model XM-825 XM-025 XM-832 XM-842
Magnification 8 x 25mm 10 x 25mm 8 x 32mm 8 x 42mm
Prism BAK-4 BAK-4 BAK-4 BAK-4
Lens Coating FMC FMC FMC FMC
Field of View 272 ft 262 ft 420 ft 330 ft
Eye Relief 18.5mm 17mm 15.5mm 22mm
Close Focus 6.6 ft 6.6 ft 9.8 ft 13.1 ft
Weight 12.2 oz. 12.4 oz. 20.6 oz. 24.3 oz.
4
Lens Coating Legend
C = Coated
FC = Fully-Coated
MC = Multi-Coated
FMC = Fully Multi-Coated
XM-832
8 x 32mm
XM-025
10 x 25mm
XM-825
8 x 25mm
5
YK-828
8 x 28mm
YK-028
10 x 28mm
YK-832
8 x 32mm
6
YK-042
10 x 42mm
YK-600
12 x 50mm
Model YK-828 YK-028 YK-832 YK-842 YK-042 YK-600
Magnification 8 x 28mm 10 x 28mm 8 x 32mm 8 x 42mm 10 x 42mm 12 x 50mm
Prism BAK-4 BAK-4 BAK-4 BAK-4 BAK-4 BAK-4
Lens Coating FMC FMC FMC FMC FMC FMC
Field of View 327 ft 272 ft 330 ft 368 ft 284 ft 252 ft
Eye Relief 17.9mm 14mm 23mm 19mm 17mm 19.5mm
Close Focus 9.8 ft 9.8 ft 16 ft 16 ft 16 ft 16 ft
Weight 16.2 oz. 16.2 oz. 23.5 oz. 31.0 oz. 31.0 oz. 41.0 oz.
YK-842
8 x 42mm
7
6
NEW!
NEW!
JK-SeriesTM
JK-042 | 10 x 42mm
JK-SeriesTM
JK-842 | 8 x 42mm
EXTREME
CLOSE FOCUS
5-6 FEET
GREAT FOR
BIRD WATCHING
Model JK-842 JK-042
Magnification 8 x 42mm 10 x 42mm
Prism BAK-4 BAK-4
Lens Coating FMC FMC
Field of View 320 ft 306 ft
Eye Relief 22mm 16mm
Close Focus 5 ft 6 ft
Weight 21.5 oz. 22 oz.
8
7
8
SuperZoomTM
Z-80S | 20-80 x 25mm
Model AZ-725 CZ-021 MZ-517 Z-80S
Magnification 7-28 x 25mm 10-30 x 21mm 5-15 x 17mm 20-80 x 25mm
Prism BK-7 BK-7 BAK-4 BAK-4
Lens Coating FC MC FC FMC
Field of View 261/105 ft 173/84 ft 315/183 ft 98/42 ft
Eye Relief 10-8mm 12-7.5mm 13-10mm 5.6mm
Close Focus 16 ft 7.55 ft 10 ft 13 ft
Weight 11.0 oz. 9.3 oz. 7.0 oz. 12.5 oz.
AutoZoomTM
AZ-725 | 7-28 x 25mm
PUSH
BUTTON
ELECTRONIC
ZOOM
GreyhawkTM
NEW
CZ-021 | 10-30 x 21mm
MiniZoomTM
MZ-517 | 5-15 x 17mm
9
ViewPointTM
VP-830 | 8 x 30mm
TrekTM
TK-821 | 8 x 21mm
CheckeredFlagTM
CF-025 | 10 x 25mm
Available in:
Fire Engine Red Lemon Yellow Royal Blue
Also Available
in black with blue trim
VP-030 | 10 x 30mm
MicroTM
VM-616 | 6 x 16mm
TrackerTM
TZ-821 | 8 x 21mm
OutdoorPakTM
TZ-401
Pack Includes:
TZ-821 Binocular
Compass
Flashlight
Multi-Tool
10
Model CF-025 TK-821 TZ-821 VM-616 VP-830 VP-030
Magnification 10 x 25mm 8 x 21mm 8 x 21mm 6 x 16mm 8 x 30mm 10 x 30mm
Prism BK-7 BK-7 BK-7 BK-7 BK-7 BK-7
Field of View 290 ft 365 ft 379 ft 472 ft 342 ft 273 ft
Weight 7.4oz. 7.0 oz. 6.8 oz. 5.5 oz. 16.2 oz. 17.0 oz.
BUILT-IN
DIGITAL COMPASS
TrailFinderTM
TF-025 | 10 x 25mm
Model JD-718 JD-822 JD-025 MO-026 NS-025 TF-025
Magnification 7 x 18mm 8 x 22mm 10 x 25mm 10 x 26mm 10 x 25mm 10 x 25mm
Prism BK-7 BK-7 BK-7 BAK-4 BAK-4 BK-7
Field of View 489 ft 393 ft 342 ft 273 ft 275 ft 343 ft
Weight 4.5 oz. 6.0 oz. 9.9 oz. 9.0 oz. 30.0 oz. 12.0 oz.
MiniScoutTM
JD-718 | 7 x 18mm
ScoutTM
JD-822 | 8 x 22mm
ScoutPlusTM
JD-025 | 10 x 25mm
SHOCK FREE!
NoShockTM
NS-025 | 10 x 25mm
FalconTM
MO-026 | 10 x 26mm
11
NEW!
CloseUp
CF-718
7-18mm
Close-Focusing
Monocular
TM
EXTREME CLOSE FOCUS
FOCUS AS CLOSE AS 10 INCHES
FROM YOUR SUBJECT
HawkEyeTM
GolfScope
GS-718 7 x 18mm
NaviScopeTM
NS-630
6 x 30mm
Built-In Digital Compass
Model CF-718 GS-718 NS-630
Magnification 7 x 18mm 7 x 18mm 6 x 30mm
Prism K-9 BK-7 BAK-4
Field of View 472 ft 378 ft 579 ft
Weight 1.8 oz. 2.0 oz. 6.4 oz.
12
BanditTM
BA-825
8 x 25mm
ONE TOUCH
FOCUS LEVER
MonoZoom
ZM-825
8-16 x 25mm
Zoom Monocular
Model BA-825 XV-732 SS-550 ZM-825
Magnification 8 x 25mm 7 x 32mm 15-40 x 50mm 8- 16 x 25mm
Prism BK-7 BAK-4 BK-7 K-9
Field of View 393 ft 381 ft 141/72 ft 241/157 ft
Weight 3.2 oz. 7.5 oz. 23.5 oz 4.0 oz.
TM
X-View
XV-732
7 x 32mm Close-Focusing
Monocular
TM
BackCountryTM
SS-550 | 15-40 x 50mm
Dual Angle Spotting Scope
straight
observation
or twist to view
0
at 45
EXPANDABLE
13
Vista
MM-640 | 26x - 130x
NEW!
zPix
Zoom Digital Microscope
Also Available
zPix 200TM
MM-740 | Cobalt | 1.3 Megapixel
26x - 130x Zoom Digital Microscope
Integrated Camera and Video Capture!
Zoom Digital Microscope
Specimen Base
Forceps
Eyedropper
USB cable
3 Blank Slides
1 Prepared Specimen Slide
CD Rom Software
640 x 480 Resolution
14
Please note that any pictoral representations shown on this page do not in any way constitute a representation by the manufacturer that such objects can be seen with these products.
NEW!
zPix | Microscope
Accessory KitTM
MM-01
Kit Includes:
3 prepared slides including
Honeybee mouth
Fruit fly
Grasshopper leg
7 blank slides
10 slide covers
1 tweezer
1 storage case
Mac OS 10.4 or later
NEW!
X ScopeTM
CP-11
8x / 9x / 30x Pocket Scope
30x Microscope,
8x Telescope,
9x Fold-out Magnifier,
Directional Compass,
LED Flashlight,
Signal Whistle,
Digital Clock
NEW! NEW!
MicroBriteTM
MM-24
20-40x Power LED Microscope
MicroMax LEDTM
MM-200
60-100x Power LED Microscope
NEW!
MicroMaxTM
MM-100
60-100x Power Microscope
Model CP-11 MM-24 MM-100 MM-200 MV-820
Magnification 8x, 9x, 30x Power 20-40x Power 60-100x Power 60-100x Power 5x, 8x, 40x Power
Weight 3.4 oz. 2.7 oz. 1.28 oz. 1.12 oz. 3.4 oz.
MicroView
MV-820
5x, 8x, 40x
8x20mm Monocular,
5x stand Magnifier,
Precision 40x Portable
Microscope.
TM
15
TM
Sky
SV-350
14-116.6 x 70mm
Includes:
K-6, K-25 Eyepieces
2 x Barlow Lens
8 x 21mm Finder
TM
Aim
MTEL-50
20-80 x 50mm
Includes:
K-9, K-17.5 Eyepieces
2 x Barlow Lens
16
SkySeeker
JC-1000
40-100 x 60mm
Includes:
H-8, H-20 Eyepieces
5 x 24mm Finder
TM
Model MTEL-50 SV-350 JC-1000
Product 20-80x 50mm 14-116.6 x 70mm 40-100x 60mm
Description 2 Eyepieces, 2x Barlow Lens, Tripod 2 Eyepieces, 2x Barlow Lens, Tripod 2 Eyepieces, 5x Finder Scope, Aluminum Tripod
Weight 1.8 lbs 6.8 lbs 7.0 lbs
Please note that any pictoral representations shown on this page do not in any way constitute a representation by the manufacturer that such objects can be seen with these products.
Please note that any pictoral representations shown on this page do not in any way constitute a representation by the manufacturer that such objects can be seen with these products.
Small Lenses
LensPen MiniPro
LP-50
Cleaning System
for Small Lenses
TM
Standard Lenses
LensPen
LP-99
Cleaning System
for Standard Lenses
TM
LensPen
LP-80
Camouflage
Digital & SLR Sensors
NEW!
SensorKlear
LP-60
Cleaning System
for Digital Camera Sensors and SLR Sensors
TM
TM
LCD Screens
LapTop Pro
VM-50
Cleaning System for Lap-Top
Computer Screens & Keyboards
TM
Computer Screens
VidiMax
VM-99
Cleaning System
for Computer Screens
TM
17
The Rock Professional
TP-400 3-Way Panhead Tripod
65 " max ht. / 26" min ht. 61" / 25" 54" / 21" 18.5" / 11"
Binocular Not Included
TM
The Rock Deluxe
TP-300 3-Way Panhead Tripod
TM
The Rock Original
TP-200 3-Way Panhead Tripod
TM
The Rock Junior
TP-100 3-Way Panhead Tripod
TM
18
Level Quick
Release
Geared
Elevator
Hook /
Handle
NEW!
Tripod Adapter
TA-1 | Binocular Tripod Mount
BinoArmor
BA-03
Easy-Access
Protective Binocular
Wrap
TM
StarMapTM Light
SL-1 | Red LED Flashlight
RETRACTS
WITH EASE!
NEW!
Stuff-It
SN-50 | Retractable
Microfiber Lens Cloth
with Neoprene Pouch
Also Available
SN-50H
TM
HandiPod
TA-2 | Compact Folding Tripod
TM
19
16
Model Description
OD-65 2 x Power Flexible, LED Lighted Magnifier w/4 x Spot Lens and Clamp-on Base
OD-10 1.5 x Power (+2.25 Diopters) Clip-On, Flip-Up Magnifying Lenses for Eyeglasses
OD-12 1.75 x Power (+3.00 Diopters) Clip-On, Flip-Up Magnifying Lenses for Eyeglasses
OD-14 2 x Power (+4.00 Diopters) Clip-On, Flip-Up Magnifying Lenses for Eyeglasses
OD-75 1.5 x Power Clip-On, Magnifying Lenses for Hats, with Batteries and Built-In Case
OD-55 4 x Power Magnifier with Attached Precision Tweezers
OD-36 2.5 x Power Hand Magnifier with 5 x Power Spot Lens
OD-25 5 x Power Lighted, Retractable Pop-Out Magnifier
OD-99 4x Power Magnifier with Attached Precision Tweezers, Hook Cleaner and Line Cutter
VM-10 1.75 x Power (+3.00 Diopters) Clip-On, Flip-Up Magnifying Glasses w/ Carry Pouch
VM-12 2 x Power (+4.00 Diopters) Clip-On, Flip-Up Magnifying Glasses w/ Carry Pouch
VM-14 2.25 x Power (+5.00 Diopters) Clip-On, Flip-Up Magnifying Glasses w/ Carry Pouch
TyMateTM
OD-75
NEW!
MagniFlyTM
OD-65
Use with Batteries or with
Included 4.5V DC Adaptor
VisorMagTM
VM-10 | VM-12 | VM-14
NEW!
Clip & FlipTM
OD-10 | OD-12 | OD-14
Fish 'n GripTM
OD-99
20
MagniGripTM
OD-55
LumiClickTM
OD-25
MagniViewTM
OD-36
WildCat
HU-521
TM
FOCUS-FREE
BUILT-IN COMPASS
Hawk
HU-530
TM
Model Description
HU-55 5 x Power Stand Magnifier
HU-10 One-Hand Bug Catcher with 5 x Power Magnifier
HU-521 5 x 21mm Fixed Focus Binocular with Built-In Compass
AdventurePak
HU-401
Includes:
5 x 30mm Binocular
Lensatic Compass
Flashlight
Whistle/Thermometer
TM
BugView
HU-10
BugLoupeTM
HU-55
TM
BigEye
HU-20
OVERSIZED
5 INCH LENS
TM
HU-530 5 x 30mm Ultra Lightweight Kid's Binoculars
HU-20 2.5 x Power (5-inch) Acrylic Hand Magnifier
HU-401 5 x 30mm Binocular, Lensatic Compass, Flashlight, Whistle/Thermometer
21
Custom imprints and innovative "high-tech" packaging are available
for many of our binoculars, magnifiers and accessories. Great for private
store brands, customer thank-you gifts, or employee incentive rewards.
Call for details. (Minimum purchase may apply.)
22
TERMINOLOGY
Coated Optics
Coatings on lens surfaces reduce light loss and glare due to reflection, resulting in a
brighter, higher-contrast image with reduced eyestrain. Lenses are coated with a microscopic film of magnesium flouride. More coating leads to better light transmission.
Types of Coating
A single layer on at least one lens.
A single layer on all air-to-glass surfaces.
Multiple layers on at least one lens and all surfaces are
coated at least once.
Fully Multi-Coated:
Multiple layers on all air-to-glass surfaces.
Coated:
Fully-Coated:
Multi-Coated:
Magnification (Power)
Binoculars and scopes are often referred to by two numbers separated by an
"X". For example: 12 x 50mm. The first number is the power or magnification of
the lens. With a 12 x 50mm power binocular, the object being viewed appears to
be 12 times closer than you would see it with the unaided eye.
Objective Lens Size
The second number in the formula: (12 x 50mm) is the diameter of the objective
or front lens in millimeters. The larger the objective lens, the more light enters
the binocular, and the brighter the image.
Prism Glass
Most optical prisms are made from borosilicate (BK-7) glass or barium crown
(BAK-4) glass. BAK-4 is higher quality glass yielding brighter images and high
edge-sharpness.
50mm 80mm
Exit Pupil
The exit pupil refers to the size of the column of light that exits an
eyepiece. The larger the exit pupil, the brighter the image.
To determine the size, divide the objective lens diameter by the
magnification. (A 12 x 36mm model has an exit pupil, or usable
light, of 3mm.)
Eye Relief
The distance an eyepiece can be held away from the the eye and still present the full field
of view. Extended or long eye relief reduces eyestrain and is ideal for eyeglass wearers.
Field of View
Field-of-view is the side-to-side measurement of the circular viewing field or subject area.
It is defined by the width in feet or meters of the area visible at 1,000 yards or meters.
A wide field-of-view is better for following fast-moving action or scanning for wildlife.
Generally, the higher the magnification, the narrower the field-of-view.
XM-050 10 x 50mm BAK-4 262 ft at 1,000 yds
34.0 oz.
Prism Systems
The prism system turns what would be an upside-down image right-side up.
Porro Roof
Roof Prism System – The prisms overlap closely, allowing the objective lens-
es to line up directly with the eyepiece. The result is a slim, streamlined shape
in which the lenses and prisms that magnify and correct the image, are in a
straight line.
Porro Prism System – The objective or front lens is offset from the eye
-piece. Porro prisms provide greater depth perception and generally offer a
wider field-of-view.
Waterproof / Fog Proof
Some binoculars and scopes are sealed with o-rings and are nitrogen purged
for waterproof and fog proof protection. These models are able to withstand
complete immersion and remain dry inside.
23
Carson Optical
35 Gilpin Avenue
Hauppauge, New York 11788-4723
Phone 631-963-5000 | Fax 631-427-6749
For information, call toll-free: 1-800-967-8427
info@carsonoptical.com
sales@carsonoptical.com
www.carsonoptical.com
Loading...
