Carrier Access Access Navigator User Manual

Access Navigator

USER MANUAL

Part Number: 770-0079-AP
Product Release: 1.8
August 2003

Copyright© 2003 Carrier Access Corporation. All rights reserved.
The information presented in this manual is subject to change without notice and does not represent a

commitment on the part of Carrier Access Corporation. The hardware and software described herein are
furnished under license(s) or non-disclosure agreement(s). The hardware, software, and manual may be
used or copied only in accordance with the terms of such agreement(s), including, but not limited to, the
software license cont ained her ein. It is aga inst the law to reproduc e, transmit , transcr ibe, store i n a retri eval
system, or translate into any medium - electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise - any part of this manual or software supplied with the Access Navigator for any purpose other
than the purchaser's personal use without the express written permission of Carrier Access Corporation.

Access Navigator, Access Bank, Adit, and the Carrier Access logo are registered trademarks of Carrier
Access Corporation. Val et and NetworkValet ar e trademarks of Carri er Access Corporation. All other brand
or product names are trademarks or registration trademarks of thei r re spective companies or organiz at ions.

Contact Information:
Carrier Access Corporation

5395 Pearl Parkway
Boulder, CO 80301-2490
Corporate Phone: [phone]
Fax: [phone]

www.carrieraccess.com

Customer Support Direct: [phone]
E-mail: [e-mail]

In this Preface

n Compliance ... iv
n Notices ... iv
n Electrostatic Discharge (ESD) Precautions ... v

PREFACE

Preface

n Carrier Access Software License Agreement ... vi
n Warranty ... ix

Preface

Compliance

USA

l UL 1950, 3rd Edition
l FCC Part 15, Class A
l FCC Part 68
l NEBS Level 3 for Type 2 and 4 equipment

GR-1089-CORE
GR-63-CORE

CANADA

l CSA C22.2 No. 950.95
l ICES-003, Class A
l CS-03

See Chapters 2, 3, and 4 for detailed compliance requirements on each product.

Notices

This manua l contains im portant infor mation and warnings that must be follow ed to ensure safe
operation of the equipment.

DANGER! A DANGER NOTICE INDICATES THE PRESENCE OF A HAZARD THAT CAN OR WILL

CAUSE DEATH OR SEVERE PERSONAL INJURY IF THE HAZARD IS NOT AVOIDED.

CAUTION! A CAUTION NOTICE INDICATES THE POSSIBILITY OF INTERRUPTING NETWORK

SERVICE IF THE HAZARD IS NOT AVOIDED.

WARNING! A WARNING NOTICE INDICATES THE POSSIBILITY OF EQUIPMENT DAMAGE IF

THE HAZARD IS NOT AVOIDED.

NOTE: A Note indicates informat ion to hel p you un derstand how t o perform a procedure

or how the system work. Notes should be read before performing the required action.

1iv August 2003 Access Navigator - Release 1.8

Electrostatic Discharge (ESD) Precautions

ESD can damage processors, circuit boards, and other electronic components. Always observe the
following precautions before installing a system component.

1. Do not remove a component from its protective packaging until ready to install it.

2. Wear a wrist grounding strap and attach it to a metal part of the system unit before handling
components. If a wrist strap i s not available, maintai n con tac t wi th the system unit throughout
any procedure requiring ESD protection.

3. For more information, see Static-Sensitive Equipment Handling Procedures on page 3.

WARNING! INTEGRATED CIRCUITS (ICS) ARE EXTREMELY SUSCEPTIBLE TO ELECTRO-

STATIC DISCHARGE. UNLESS YOU ARE A QUALIFIED SERVICE TECHNICIAN WHO USES TOOLS AND
TECHNIQUES THAT CONFORM TO ACCEPTED INDUSTRY PRACTICES, DO NOT HANDLE ICS.

Preface

The ESD warning label appea rs on packages a nd storage bags that contain stat ic-sensitiv e products and
components.

Access Navigator - Release 1.8 August 2003 1v

Preface

Carrier Access Software Licens e Agreement

PLEASE CAREFULLY READ THE FOLLOWING TERMS AND CONDITIONS CONTAINED IN
THIS LICENSE (THE "LICENSE") BEFORE OPENING THE SOFTWARE PACKAGE; OPENING
THIS PACKAGE INDICATES THAT YOU HAVE ACCEPTED THESE TERMS AND
CONDITIONS AND AGREE TO BE BOUND BY THEM.

CARRIER ACCESS CORPORATION provides this Software and licenses its use to you, the
LICENSEE, pursuant to the fo llowing terms. "LICENSEE" m eans the entity that h as accepted the terms
and conditions of this Lice nse by openi ng th is packa ge, refere nce s to "LICENSOR" mean "CARRIER
ACCESS CORPORATION" and references to the "Software" mean all of the contents of the files,
disks, CD-ROMs or other media with which this License is provided. LICEN SEE assumes
responsibility for the selection of the Software to achieve LICENSEE's intended results. Further,
LICENSEE is responsible for the installation, use, and results obtained from the Software.

License

LICENSEE desires to license from LICENSOR and LICENSOR desires to license to LICENSEE
the Software that is an in tegral e lement of the communi cation an d equipment package markete d by
LICENSOR.

LICENSEE has the limited non-excl usive right to use the accessed Sof tware only on the number of
units agreed to in th e purchase order under which the Soft ware was purchased. LICENSEE may not
transfer the Software from one unit to an other even t hough the Software is used on only one unit at
a time. LICENSEE may not provide copies of the Software to any third party. LICENSEE may
make one copy of the Software solely for backup purposes. LICENSEE may not modify the
Software.

LICENSEE agrees that it will not attempt to alter, disassemble, decrypt or reverse engineer the
Software. LICENSEE will not make, or have made, or permit to be made, any copies of the
Software or portions thereof, except as necessary for its use with the number of units previously
agreed upon in the purc hase order under which the Sof tware was purchased. LICENSEE agrees that
any such copies of the Software shall contain the same proprietary notices that appear on or in the
Software.

Title and Risk

Title to the Software, including the ownership of all copyrights, mask work rights, patents,
trademarks, trade secrets, and all other intellectual property rights subsisting in the Software,
documentation, enhancements, adaptations, and to any modifications thereto shall at all times
remain with LICENSOR.

LICENSEE shall make no claim of any ownership, interest in the intellectual property rights,
including without limitation copyright and patents, in the Software, enhancements, and any
adaptations, developments, or modifications thereof.

LICENSEE acknowledges that th e laws and regulat ions of the Uni ted States restrict th e export and
re-export of commodities and technical data of United States origin, including the Software.

1vi August 2003 Access Navigator - Release 1.8

LICENSEE agrees that it will not export or re-export the Software in any form without the
appropriate United State s and for ei gn gove rnmen t li censes. LICENSEE agrees that its obligations
pursuant to this Section shall survive and continue after any termination or expiration of rights
under this License.

Copyright

The Software is copyr ight ed by LICENSOR and, except as permitted by this License , LI CENSEE
may not duplicate the Software or disclose it to any other party.

Term

This License is effective until terminated. LICENSEE may terminate it voluntarily at any time.
Voluntary termination by LICENSEE must be accompanied by complete destruction of the
Software and all copies thereof. LICENSOR or LICENSOR's Licensors of the Software may
terminate this License without notice upon LICENSEE 's failure to abide by this License.

Warranty

For a period of ninety (90) days after the initial delivery of the Software to LICENSEE (the
"Software Warranty Period"), LICENSOR warrants that the Software, when used as permitted
under this License will op erate substan tial ly as des cribe d in the Sof tware pub lishe d speci ficatio ns.
LICENSOR will, at its own expense and as its sole obligation and LICENSEE's exclusive remedy
for any breach of this warranty, use commercially reasonable efforts to correct any reproducible
error in the Software reported to LICENSOR by LICENSEE in writing during the Software
Warranty Period, or to replace the defective Software. If LICENSOR determines that it is unable to
correct the error or replace the Sof tware, LICENSOR will refund to LICENSEE all license f ees paid
for the Software, in which case this License and LICENSEE's right to use the Softw are will be
terminated. Any such error correction or replacement provided to LICENSEE will not extend the
original Software Warranty Period

Preface

Disclaimer

ALL WARRANTIES OTHER THAN THOSE STATED IN THIS LICENSE, EITHER
EXPRESSED OR IMPLIED, ARE DISCLAIMED AS TO THE SOFTWARE AND ITS
QUALITY, PERFORMANCE, OR FITNESS FOR ANY PARTICULAR PURPOSE. LICENSEE
BEARS THE ENTIRE RISK RELATING TO THE QUALITY OF THE SOFTWARE AND IF
THE SOFTWARE PROVES TO HAVE ANY DEFECTS, LICENSEE ASSUMES THE COST OF
ANY NECESSARY SERVICING OR REPAIRS.

LICENSOR MAKES NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE TITLE, AND NON-INFRINGEMENT OF THIRD PARTY RIGHTS.

Limitation of Liability

IN NO EVENT SHALL LICENSOR BE RESPONSIBLE FOR ANY INDIRECT, EXEMPLARY,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING WITHOUT
LIMITATION ANY LOST DATA, LOST PROFITS, AND COSTS OF PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES, ARISING FROM OR RELATING TO THESE
LICENSE TERMS, HOWEVER CAUSED AND UNDER ANY THEORY OF LIABILITY

Access Navigator - Release 1.8 August 2003 1vii

Preface

(INCLUDING NEGLIGENCE, CONTRACT AND TORT), EVEN IF LICENSOR HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

THE AGGREGATE LIABILITY OF LICENSOR TO LICENSEE IN RESPECT OF ANY AND
ALL CAUSES OF ACTION AT ANY TIME OR TIMES ARISING OUT OF THIS LICENSE,
INCLUDING WITHOUT LIMITATION ANY BREACH OF WARRANTY, SHALL NOT
EXCEED AN AMOUNT EQUAL TO THE SOFTWARE LICENSE OR PURCHASE FEE PAID
PRIOR TO THE TIME WHEN SUCH CAUSE OF ACTION ARISES, REDUCED BY TWENTY
PERCENT (20%) FOR EACH SUBSEQUENT YEAR, WHICH SHALL HAVE EXPIRED
PRIOR TO THAT TIME.

Jurisdiction and Venue

This License shall be cons trued and interpret ed accordi ng to the la ws of the st ate of Colo rado. Any
action or proceeding arising from or relating to these License Terms shall be brought solely in the
state and federal courts of Colorado, and each Party irrevocably submits to the jurisdiction and
venue of any such court in any such action or proceeding.

1viii August 2003 Access Navigator - Release 1.8

Warranty

Carrier Access Corporation conditionally warrants to BUYER that PRODUCTS are free from
substantial defect in material and workmanship under normal use given proper installation and
maintenance for the period of five years from the date of shipment by Carrier Access Corporation.

BUYER will promptly notify Carrier Access Corporation of any defect in the PRODUCT. Carrier
Access Corporation or its agent will have the right to inspect the PRODUCT or workmanship on
BUYER’S or BUYER’S customer premises. Carrier Access Corporation has the option to: (a) repair,
replace or service at its factory or on the premises the PRODUCT or workmanship found to be
defective; or (b) credit BUYER for the
depreciation policy. Refurbished material may be used to repair or replace the PRODUCT.
PRODUCTS returned to Carrier Access Corporation for repair, replacement, or credit will be shipped
prepaid to BUYER.

Limitations of Warranty & Limitation of Remedies

Correction of defects by repair, replacement, service or credit will be at Carrier Access Corporation’s
option and constitute fulfillment of all obligations to buyer for breach of warranty.

Carrier Access Corporation assumes no warranty liability with respect to defects in the PRODUCT
caused by: (a) modificat ion, repair, i nstallation, ope ration or maint enance of the PRODUCT by anyo ne
other than Carrier Access Cor poration or its agent, ex cept as describe d in Carri er Acces s Corporat ion’s
documentation; or (b) the negligent or other improper use of the PRODUCT; or (c) handling or
transportation after title of the PRODUCT passes to BUYER.

Other manufacturer’s equipment purchased by Carr ier Access Corporation and resold to BUYER will
be limited to that manufacture’s war ranty. Carrier Acc ess Corporation ass umes no warranty l iability for
other manufacturer’s equipment furnished by BUYER.

Preface

PRODUCT in accordance with Carrier Access Corporation’s

Buyer understands and agr ees as f ollows: the warr antie s in this agreemen t repla ce all ot her warr anti es,
expressed or implied, and all other obligations or liabilities of Carrier Access Corporation, including
any warranties of merchantability and fitness for a particular purpose. All other warranties are
disclaimed and excluded by Carrier Access Corporation.

The remedies contained in t hi s agr eeme n t wi ll be th e sol e and excl usive remedies whether in contract,
tort or otherwise, and Carrier Access Corporation will not be liable for injuries or damages to persons
or property resulti ng from any case whatso ever, with the exc eption of injuries or damages caused b y the
gross negligence of Carrier Access Corporation. These limitations apply to all services, software, and
products during and a fter t he warrant y period. In no even t will Car rier Acc ess Corporat ion be liable for
any special, incidental, or consequential damages or commercial losses even if Carrier Access
Corporation has been advised thereof.

No agent, distributor, or representative is autho rized to make any warrantie s on behalf of Carrier Access
Corporation or to assume for Carrier Access Corporation any other liability in connection with any of
Carrier Access Corporation’s PRODUCTS, Software, or Services.

Access Navigator - Release 1.8 August 2003 1ix

Preface

Warranty Product Returns

Before returning any equ ipment to Carrier Access, first contac t the distribut or or dealer fro m which you
purchased the product.

A Return Material Authorization (RMA) number is required for all equipment returned to Carrier
Access. Call Carrie r Access Customer S upport at [phone] or [phone] f or RMA number,
repair/warranty information and shipping instructions. Be prepared to provide the following
information:

l Carrier Access serial number(s) from the system chassis or circuit card(s)
l Name of distributor or dealer from which you purchased the product
l Description of defect

Ensure that returned items are packaged pr operly:

l Follow Electrostatic Discharge (ESD) Precautions on page v
l Enclose circuit cards in anti-static wrappers
l Cushion items to prevent damage during shipment
l If replacing parts, use same packaging to return old parts
l Ensure that shipping address is correct and clearly visible on outside of shipping container
l If returning equipment to Carrier Access Corporation, ensure that RMA number is clearly

visible on outside of shipping container

1x August 2003 Access Navigator - Release 1.8

TABLE OF CONTENTS

Preface

Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Electrostatic Discharge (ESD) Precautions . . . . . . . . . . . . . . . . . . . . . . . . . .v

Carrier Access Software License Agreement . . . . . . . . . . . . . . . . . . . . . . . vi

License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Title and Risk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v i

Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Term . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Limitation of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Jurisdiction and Venue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Limitations of Warranty & Limitation of Remedies . . . . . . . . . . . . . . ix

Warranty Product Returns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x

Table of Contents

TABLE OF CONTENTS

1 Introduction

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Features and Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Access Navigator Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

System Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Carrier Access Support Products. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Access Banks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Adit 600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Command Line Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Valet and NetworkValet EMS Software. . . . . . . . . . . . . . . . . . . . . . . 1-8

2 Access Navigator / DCS Service Manager

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

System Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Features and Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Table of Contents

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

DCS Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

DS1 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

System Clocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Signaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Protocols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Compliance Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

FCC Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Telcordia (Bellcore) Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

UL Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

CSA Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

3 Access Navigator / GR-303 + Data Host

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

System Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

GR-303 Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

DCS Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Management Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

IP DS0 Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

FDL Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11

GR-303 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11

Crossconnects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11

DS1 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11

System Clocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11

GR-303 Signaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

DCS Signaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Protocols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13

1xii August 2003 Access Navigator - Release 1.8

Table of Contents

Environmental. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13

Physical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13

Compliance Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14

FCC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14

Telcordia (Bellcore) Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

UL Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

CSA Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

Ordering Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

4 Access Navigator / GR-303 Host with P-Phone

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

System Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Features and Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

GR-303 Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

P-Phone Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

DCS Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Management Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

IP DS0 Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

FDL Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

GR-303 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Crossconnects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

DS1 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

System Clocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

GR-303 Signaling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

DCS Signaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

Management Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

Environmental. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

Physical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

Compliance Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15

FCC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-15

Telcordia (Bellcore) Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

UL Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

CSA Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

Ordering Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

Access Navigator - Release 1.8 August 2003 1xiii

Table of Contents

5 Physical Installation

Compliance and Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Tools and Materials. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Unpacking and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Horizontal 19-Inch Rack Mount. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Attach Mounting Brackets to Access Navigator . . . . . . . . . . . . . . . . 5-5

Attach Access Navigator to Equipment Rack . . . . . . . . . . . . . . . . . . 5-5

Horizontal 23-Inch Rack Mount. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Attach Mounting Brackets to Access Navigator . . . . . . . . . . . . . . . . 5-8

Attach Access Navigator to Equipment Rack . . . . . . . . . . . . . . . . . . 5-9

Vertical Rack Mount Using Crossbars . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11

Install Crossbars. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12

Attach Mounting Brackets to Access Navigator . . . . . . . . . . . . . . . 5-12

Attach Access Navigator to Crossbars. . . . . . . . . . . . . . . . . . . . . . . 5-12

Vertical Wall Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16

Ensure Adequate Clearance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16

Prepare Plywood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16

Attach Mounting Brackets to Access Navigator . . . . . . . . . . . . . . . 5-16

Attach Access Navigator to Plywood . . . . . . . . . . . . . . . . . . . . . . . 5-17

6 Electrical Installation

Compliance and Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

Static-Sensitive Equipment Handling Procedures. . . . . . . . . . . . . . . . . . . 6-3

Tools and Materials Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Chassis Ground Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Run Ground Wire to Access Navigator. . . . . . . . . . . . . . . . . . . . . . . 6-6

Connect Ground Wire to Ground Lug . . . . . . . . . . . . . . . . . . . . . . . . 6-6

Attach Ground Lug to Access Navigator. . . . . . . . . . . . . . . . . . . . . . 6-7

1xiv August 2003 Access Navigator - Release 1.8

Table of Contents

DSX-1 Cable Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8

Installation Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

Prepare DSX-1 Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

Connect DSX-1 Cables to Access Navigator . . . . . . . . . . . . . . . . . .6-11

Connect DSX-1 Cables to Interface or Patch Panel . . . . . . . . . . . . . 6-14

RS-232 Management Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17

Installation Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17

Information, Tools, and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17

Connect Shielded RS-232 Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19

Attach Ferrite Bead RF Suppressor . . . . . . . . . . . . . . . . . . . . . . . . . 6-20

Preconfigure Optional Modem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21

Ethernet Management Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22

Installation Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22

Information and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22

Make Ethernet Cable (Optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22

Connect Ethernet Cable to Access Navigator. . . . . . . . . . . . . . . . . . 6-24

Connect Ethernet Cable to Ethernet Hub . . . . . . . . . . . . . . . . . . . . . 6-24

External Timing Source (BITS) Connection . . . . . . . . . . . . . . . . . . . . . . 6-25

Installation Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25

Make BITS Cable (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26

Connect BITS Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26

Alarm Output Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27

Installation Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27

Wire Alarm Output Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28

Plug Output Alarm Connector into Access Navigator . . . . . . . . . . . 6-30

Alarm Input Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-31

Installation Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-31

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-31

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-31

Wire Alarm Input Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32

Plug Alarm Input Connector into Access Navigator . . . . . . . . . . . .6-34

DC Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-35

Installation Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-35

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-35

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-35

Wire Power Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36

Verify Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-37

Connect Power Plugs to Access Navigator. . . . . . . . . . . . . . . . . . . . 6-37

Access Navigator - Release 1.8 August 2003 1xv

Table of Contents

Dress Cables and Wires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38

Dress Cables and Wires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38

Acceptance Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-39

Verification Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-39

Apply Power and Verify Operation. . . . . . . . . . . . . . . . . . . . . . . . . 6-40

Verify Chassis Ground Connection. . . . . . . . . . . . . . . . . . . . . . . . . 6-41

Verify DSX-1 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-41

Verify RS-232 Management Connection. . . . . . . . . . . . . . . . . . . . . 6-42

Verify Ethernet Cable Connection. . . . . . . . . . . . . . . . . . . . . . . . . . 6-43

Verify Ethernet Management Connection . . . . . . . . . . . . . . . . . . . . 6-43

Verify BITS Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-44

Verify Alarm Output Connections. . . . . . . . . . . . . . . . . . . . . . . . . . 6-45

Verify Alarm Input Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-47

Exit Management Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-48

Install Redundant Controller Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-49

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-49

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-49

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-50

Verify Software Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-50

Remove Front Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-51

Install Controller Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-52

Verify Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-53

Install Additional Quad T1 Framer Cards. . . . . . . . . . . . . . . . . . . . . . . . 6-55

Installation Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-55

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-55

Tools and Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-55

Remove Front Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-56

Install Quad T1 Framer Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-57

Verify Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-59

Replace Front Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-61

Configure Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-61

Setup Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-61

Start RS-232 Management Session . . . . . . . . . . . . . . . . . . . . . . . . . 6-62

Set Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-63

Set Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-63

Set System ID or CLLI code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-64

Set IP Address and Subnet Mask. . . . . . . . . . . . . . . . . . . . . . . . . . . 6-64

Set Gateway Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-65

Exit Management Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-65

1xvi August 2003 Access Navigator - Release 1.8

Table of Contents

7 Start Management Session

Management Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2

Command Line Interface Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3

RS-232 Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4

RS-232 Management Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . 7-4

Procedure Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4

Obtain Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5

Connect RS-232 Cable to Access Navigator . . . . . . . . . . . . . . . . . . . 7-5

Set Up Terminal Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5

Start RS-232 Management Session. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6

Perform Management Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7

Exit RS-232 Management Session . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7

Telnet Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8

Telnet Management Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8

Procedure Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8

Obtain Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9

Start Telnet Program and Connect to Access Navigator . . . . . . . . . . 7-9

Start Telnet Management Session. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9

Perform Management Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10

Exit Telnet Management Session When Finished . . . . . . . . . . . . . . 7-10

NetworkValet EMS and Valet Management . . . . . . . . . . . . . . . . . . . . . . 7-11

8 Provision Access Navigator

Basic Provisioning Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

Basic Provisioning Quick Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

Obtain Provisioning Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

Verify System Equipment Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

Set System ID or CLLI Code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

Set Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6

Set Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6

Set Ethernet Properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Set User and Password Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Set SNMP Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

9 Provision DCS Service

DCS Provisioning Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

Provisioning ISDN BRI Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

Provisioning TR-08 Service with DCS. . . . . . . . . . . . . . . . . . . . . . . . 9-3

DCS Provisioning Quick Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-6

Obtain Provisioning Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7

Verify System Equipment Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 9-7

Verify Service Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

Set Unused Circuits Out of Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10

Set System Clock Source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11

Provision “Groom” DS1 Circuits to Network . . . . . . . . . . . . . . . . . . . . . 9-12

Access Navigator - Release 1.8 August 2003 1xvii

Table of Contents

10 Provision GR-303 Service

Test Groom DS1 Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-14

Provision “Drop” DS1 Circuits to Subscribers. . . . . . . . . . . . . . . . . . . . 9-14

Provision and Connect ISDN PRI Channels. . . . . . . . . . . . . . . . . . . . . . 9-16

Provision and Connect ISDN BRI 3DS0 Channels . . . . . . . . . . . . . . . . 9-16

Provision and Connect DS0s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17

Turn Up Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-19

Test DS1 and DS0 Circuits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-19

GR-303 Provisioning Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2

Provisioning ISDN BRI Service . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4

Provisioning P-Phone Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4

Provisioning TR-08 Service with GR-303 Translation . . . . . . . . . . 10-5

GR-303 Provisioning Quick Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-9

Obtain Provisioning Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-10

Verify System Equipment Configuration . . . . . . . . . . . . . . . . . . . . . . . 10-10

Verify Service Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11

Set Unused Circuits Out of Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-13

Set System Switch Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14

Set System Clock Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14

Provision “Switch” DS1s to Interface Group . . . . . . . . . . . . . . . . . . . . 10-15

Assign Primary and Secondary EOC . . . . . . . . . . . . . . . . . . . . . . . . . . 10-18

Assign Primary and Secondary TMC . . . . . . . . . . . . . . . . . . . . . . . . . . 10-19

Test DS1 Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-20

Provision “Drop” DS1 Circuits to Subscriber. . . . . . . . . . . . . . . . . . . . 10-21

Provision ISDN BRI 4:1 TDM Service to Subscribers. . . . . . . . . . . . . 10-25

Provision DS0s to Subscribers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-30

Assign Call Reference Values (CRVs). . . . . . . . . . . . . . . . . . . . . . . . . 10-32

Turn Up Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-34

Test Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-34

11 Provision Remote Access Bank II

Remote Access Bank II Provisioning Overview. . . . . . . . . . . . . . . . . . . 11-2

Pre-Provisioning and Testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3

Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3

Analog Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4

Crossconnect Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4

FX Analog Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-6

Fractional Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-7

Remote Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-8

Remote Access Bank II Provisioning Quick Guide . . . . . . . . . . . . . . . . 11-9

Remote Access Bank II Maintenance Quick Guide . . . . . . . . . . . . . . . 11-10

Obtain Provisioning Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-11

Verify System Equipment Configuration . . . . . . . . . . . . . . . . . . . . . . . 11-11

Temporarily Disable Configuration Downloading . . . . . . . . . . . . . . . . 11-14

1xviii August 2003 Access Navigator - Release 1.8

Table of Contents

Provision Drop DS1 to Remote Access Bank II . . . . . . . . . . . . . . . . . . 11-15

Test DS1 Circuits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-17

Provision DS0s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-17

Provision DS0 Crossconnects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-19

Create Fractional Interfaces (if required). . . . . . . . . . . . . . . . . . . . . . . .11-21

Configure Remote RS-232 Interface (if used). . . . . . . . . . . . . . . . . . . . 11-22

Configure Remote T1 Drop Interface (if used) . . . . . . . . . . . . . . . . . . . 11-24

Configure Remote V.35 Interface (if used) . . . . . . . . . . . . . . . . . . . . . . 11-26

Connect Fractional Interface to Remote Interface. . . . . . . . . . . . . . . . . 11-28

Download Configuration to Remote Access Bank II. . . . . . . . . . . . . . . 11-28

Verify Downloaded Settings (optional). . . . . . . . . . . . . . . . . . . . . . . . .11-29

Turn Up Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-29

Test Remote Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-30

12 Provision Remote Adit 600 via FDL

Remote Adit 600 FDL Provisioning Overview. . . . . . . . . . . . . . . . . . . .12-2

FDL Management Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . .12-3

Remote Adit 600 FDL Provisioning Quick Guide. . . . . . . . . . . . . . . . . . 12-4

Obtain Provisioning Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-6

Verify Equipment Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-6

Provision Drop DS1s to Remote Adit 600. . . . . . . . . . . . . . . . . . . . . . . 12-10

Provision Drop DS0s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13

Provision DS0 Crossconnects (if required) . . . . . . . . . . . . . . . . . . . . . . 12-15

Provision Remote Adit 600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-17

Test DS1 and DS0 Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-17

13 Provision Remote Adit 600 via IP DS0

Remote IP DS0 Provisioning Overview . . . . . . . . . . . . . . . . . . . . . . . . . 13-2

IP DS0 Management Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 13-3

Remote IP DS0 Provisioning Quick Guide . . . . . . . . . . . . . . . . . . . . . . .13-4

Router Provisioning Quick Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-5

Remote Adit IP DS0 Provisioning Quick Guide. . . . . . . . . . . . . . . . . . . 13-7

Obtain Provisioning Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-8

Verify Equipment Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-8

Provision Groom DS1s to Adit Router . . . . . . . . . . . . . . . . . . . . . . . . . 13-12

Provision Drop DS1s to Remote Adit . . . . . . . . . . . . . . . . . . . . . . . . . . 13-15

Provision Groom DS0s to Adit Router . . . . . . . . . . . . . . . . . . . . . . . . . 13-18

Provision Drop DS0s to Remote Adit . . . . . . . . . . . . . . . . . . . . . . . . . . 13-19

Provision DS0 Crossconnects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-21

Provision Remote Adit 600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-23

Test DS1 and DS0 Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-23

Access Navigator - Release 1.8 August 2003 1xix

Table of Contents

14 Alarm Clearing

15 Diagnostics & Troubleshooting

Identify Alarm Clearing Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-2

Clear Alarms – FDL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-3

Clear Alarms – EOC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-8

Clear Alarms – SNMP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-14

Clear Alarms – Status Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15

Power Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-16

Active/Standby Controller Status LEDs . . . . . . . . . . . . . . . . . . . . 14-17

Critical Alarm Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-18

Major Alarm Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-18

Minor Alarm Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-19

Alarm Cutoff (ACO) Status LED . . . . . . . . . . . . . . . . . . . . . . . . . 14-19

DS1 Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-20

Ethernet Link Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-21

Alarms and Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-2

Operations Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-2

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-2

Alarm Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-3

Alarm Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-3

Alarm and Status Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-3

Facility Alarm System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-4

Alarm Cutoff (ACO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-4

Alarm Signaling – Red, Yellow (RAI), Blue (AIS). . . . . . . . . . . . . 15-4

DS1 Failures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-5

Event Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-5

Configuration Change Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-6

BERT Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-7

TMC Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-7

Alarm and Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-8

Indicator Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-8

Indicator Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-10

Status and Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-11

Status Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-11

Status DS0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-12

Status DS1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-13

Status DS1 All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-14

Status DS1 Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16

Status DS1 Performance History. . . . . . . . . . . . . . . . . . . . . . . . . . 15-17

Clear DS1 Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-18

Status Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-19

Status IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-20

Status Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-21

1xx August 2003 Access Navigator - Release 1.8

Table of Contents

GR-303 Status and Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-22

Status CRV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-22

Status ISDN CRV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-23

Status EOC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-25

Status TMC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-25

Status TMC History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-27

Clear Blocked Call Count. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-28

Clear Peak Call Count. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-28

Clear Permanent Call Count. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-28

Set CRV Idle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-28

Near-End Loopbacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-29

DS1 Loopdetect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-29

DS1 FDL Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-29

DS1 Line Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-30

DS1 Payload Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-30

Far-End Loopbacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-31

DS1 CSU Loopup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-31

DS1 Line Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-32

DS1 Network Loopup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-33

DS1 NIU Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-34

DS1 Payload Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-35

Access Bank II Loopbacks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-36

Read Remote Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-36

Send Remote Loopdown. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-36

Send Remote RS232 Line Loopup. . . . . . . . . . . . . . . . . . . . . . . . . 15-37

Send Remote RS232 TSI Equipment Loopup . . . . . . . . . . . . . . . . 15-37

Send Remote RS232 TSI Network Loopup . . . . . . . . . . . . . . . . . . 15-38

Send Remote SDSL Payload Loopup. . . . . . . . . . . . . . . . . . . . . . . 15-38

Send Remote T1 Payload Loopup . . . . . . . . . . . . . . . . . . . . . . . . . 15-39

Send Remote T1 TSI Loopup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-39

Send Remote T1 Drop Line Loopup. . . . . . . . . . . . . . . . . . . . . . . .15-40

Send Remote T1 Drop Payload Loopup. . . . . . . . . . . . . . . . . . . . . 15-40

Send Remote T1 Drop Payload Loopup. . . . . . . . . . . . . . . . . . . . . 15-41

Send Remote V35 Line Loopup. . . . . . . . . . . . . . . . . . . . . . . . . . . 15-41

Send Remote V35 TSI Equipment Loopup . . . . . . . . . . . . . . . . . . 15-42

Send Remote V35 TSI Network Loopup . . . . . . . . . . . . . . . . . . . . 15-42

Bit Patterns and Error Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-43

Send DS1 (Pattern) Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-43

Send DS1 Line Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-44

Send DS1 Payload Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-45

Send DS1 Line Pattern with BER Test . . . . . . . . . . . . . . . . . . . . . . 15-46

Send DS1 Payload Pattern with BER Test. . . . . . . . . . . . . . . . . . . 15-49

Other Maintenance Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-52

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-54

Access Navigator - Release 1.8 August 2003 1xxi

Table of Contents

16 Maintenance Procedures

17 Update Controller Card Software

Compliance and Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 16-2

Repair and Return Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-2

Replace Controller Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-3

Procedure Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-3

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-3

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-4

Tools and Materials Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-4

Verify Equipment Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-5

Determine Which Replacement Procedure to Use. . . . . . . . . . . . . . 16-5

Replace Protected Controller Card . . . . . . . . . . . . . . . . . . . . . . . . . 16-6

Replace Unprotected Controller Card . . . . . . . . . . . . . . . . . . . . . . 16-13

Replace Quad T1 Framer Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-19

Install SIMM on Controller Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-28

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-2

Download Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-2

Update Software via TFTP (Two Controllers) . . . . . . . . . . . . . . . . . . . . 17-3

Procedure Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-3

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-3

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-4

Information and Materials Required . . . . . . . . . . . . . . . . . . . . . . . . 17-5

Install Optional TFTP Server Software . . . . . . . . . . . . . . . . . . . . . . 17-5

Verify Equipment Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-6

Verify IP Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-7

Upload Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-7

Download Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-8

Download Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-10

Update Software via Xmodem (Two Controllers) . . . . . . . . . . . . . . . . 17-11

Procedure Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-11

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-11

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-12

Information and Materials Required . . . . . . . . . . . . . . . . . . . . . . . 17-13

Verify Equipment Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-13

Download Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-14

Update Software via Xmodem (One Controller) . . . . . . . . . . . . . . . . . 17-17

Procedure Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-17

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-17

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-18

Information and Materials Required . . . . . . . . . . . . . . . . . . . . . . . 17-19

Verify Equipment Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-19

Download Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-20

1xxii August 2003 Access Navigator - Release 1.8

Table of Contents

18 CLI Language Reference

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-2

CLI Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-3

CLI over RS-232. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-3

CLI over Telnet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-4

Using CLI Command Scripts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-5

CLI Conventions and Shortcuts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-6

Command Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-6

Commands, Confirmations, and Error Messages . . . . . . . . . . . . . . .18-6

Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-7

Command Syntax Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-8

Entering DS1 and DS0 Numbers and Ranges . . . . . . . . . . . . . . . . . 18-9

Command Shortcuts (Tabbing). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-9

Keyboard Shortcuts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-9

Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-10

Help System Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-10

Displaying Basic Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-10

Context Sensitive Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-11

Printing the Help File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-13

Users and Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-14

Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-14

Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-14

Managing Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-15

Logging In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-18

Startup Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-18

Login with No User Name Required . . . . . . . . . . . . . . . . . . . . . . . 18-18

Login with User Name Required . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

Login with No Password Required. . . . . . . . . . . . . . . . . . . . . . . . . 18-19

Login with Password Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

Logout (Exit). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-20

Autoexit (CLI Session Timeout). . . . . . . . . . . . . . . . . . . . . . . . . . . 18-20

CLI Command List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-21

ACO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-23

Add Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-23

Add User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-25

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-25

Clear BERT Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-27

Clear Blocked Call Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-27

Clear Config Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-27

Clear DS1 Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-27

Clear Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-28

Clear Peak Call Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-28

Clear Permanent Call Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-28

Clear Remote Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-28

Clear TMC Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-28

Access Navigator - Release 1.8 August 2003 1xxiii

Table of Contents

Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-29

Connect Remote Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-31

Delete Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-32

Delete User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-33

Disconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-33

Disconnect Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-34

Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-34

Exit Remote Session (Ctrl+C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-34

Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-35

Load TFTP Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-37

Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-38

Log BERT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-40

Log Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-41

Log TMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-43

Logon Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-44

Ping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-45

Read Remote Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-45

Read Remote Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-48

Read Remote Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-50

Read Remote Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-51

Read Remote RS232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-51

Read Remote Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-52

Read Remote T1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-54

Read Remote T1drop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-55

Read Remote V35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-56

Reset All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-57

Reset DS1 Framer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-57

Reset Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-58

Reset Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-58

Restore Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-59

Send DS1 CSU Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-62

Send DS1 Line Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-63

Send DS1 Line <pattern> . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-65

Send DS1 Line <pattern> Test . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-67

Send DS1 Network Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-70

Send DS1 NIU Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-71

Send DS1 Payload Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-73

Send DS1 Payload <pattern> . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-75

Send DS1 Payload <pattern> Test . . . . . . . . . . . . . . . . . . . . . . . . 18-77

Send DS1 Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-80

Send Remote Loopdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-80

Send Remote RS232 Line Loopup . . . . . . . . . . . . . . . . . . . . . . . . 18-81

Send Remote RS232 TSI Loopup . . . . . . . . . . . . . . . . . . . . . . . . . 18-82

1xxiv August 2003 Access Navigator - Release 1.8

Table of Contents

Send Remote SDSL Payload Loopup . . . . . . . . . . . . . . . . . . . . . . 18-84

Send Remote T1 Payload Loopup . . . . . . . . . . . . . . . . . . . . . . . . . 18-85

Send Remote T1 TSI Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-86

Send Remote T1Drop Line Loopup . . . . . . . . . . . . . . . . . . . . . . . .18-87

Send Remote T1Drop Payload Loopup . . . . . . . . . . . . . . . . . . . . . 18-88

Send Remote T1Drop TSI Loopup . . . . . . . . . . . . . . . . . . . . . . . . 18-89

Send Remote V35 Line Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . 18-90

Send Remote V35 TSI Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-92

Send Switch Provision Request . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-93

Set Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-94

Set Autoexit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-94

Set Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-95

Set CRV Idle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-96

Set Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-96

Set DS0 CRV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-96

Set DS0 ISDN BRI CRV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-100

Set DS0 P-Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-101

Set DS0 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-102

Set DS0 Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-103

Set DS0 Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-104

Set DS1 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-105

Set DS1 FDL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-105

Set DS1 Framing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-107

Set DS1 ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-108

Set DS1 LBO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-108

Set DS1 Line Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-108

Set DS1 Linecode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-109

Set DS1 Loopdetect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-110

Set DS1 Payload Loopup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-111

Set DS1 Remote Device Mgmt . . . . . . . . . . . . . . . . . . . . . . . . . . 18-112

Set DS1 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-113

Set DS1 TermID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-113

Set DS1 Threshold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-114

Set DS1 Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-115

Set EOC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-115

Set Ethernet IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-116

Set ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-117

Set IP Gateway Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-117

Set Remote Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-118

Set Remote ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-119

Set Remote RS232 Baud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-119

Set Remote RS232 Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-120

Set Remote RS232 Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-120

Access Navigator - Release 1.8 August 2003 1xxv

Table of Contents

Set Remote T1Drop Framing . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-121

Set Remote T1Drop LBO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-122

Set Remote T1Drop Linecode . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-122

Set Remote T1Drop PRM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-123

Set Remote V35 ClockInv . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-123

Set Remote V35 CTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-124

Set Remote V35 Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-124

Set Remote V35 DSU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-125

Set Remote V35 RxClock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-125

Set Remote V35 Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-125

Set Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-126

Set SNMP Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-127

Set SNMP GetCom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-127

Set SNMP Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-128

Set SNMP Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-128

Set SNMP NMS Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-129

Set SNMP SetCom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-129

Set SNMP TrapCom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-130

Set Switch Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-130

Set Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-131

Set TMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-131

Set User Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-132

Set User Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-133

Show Autoexit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-134

Show Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-134

Show Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-134

Show CRV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-136

Show Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-138

Show DS0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-138

Show DS1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-139

Show DS1 All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-142

Show EOC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-144

Show Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-144

Show ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-145

Show Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-145

Show IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-147

Show ISDN CRV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-147

Show Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-149

Show Remote Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-150

Show SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-152

Show Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-153

Show Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-153

Show TMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-153

1xxvi August 2003 Access Navigator - Release 1.8

Table of Contents

Show Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-154

Status Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-155

Status CRV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-156

Status DS0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-157

Status DS1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-158

Status DS1 All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-160

Status DS1 Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-161

Status DS1 Performance History . . . . . . . . . . . . . . . . . . . . . . . . . 18-164

Status EOC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-166

Status Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-167

Status IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-169

Status ISDN CRV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-170

Status Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-171

Status TMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-172

Status TMC History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-174

Switch Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-175

Upload TFTP Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-175

WhoAmI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-176

A EOC Interface

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-2

Managed Object Class Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-4

Analog Line Termination Objects . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5

Alarm Count List Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5

DS0 Channel Termination Objects. . . . . . . . . . . . . . . . . . . . . . . . . . .A-6

DS1 Framed Path Termination Objects . . . . . . . . . . . . . . . . . . . . . . .A-6

DS1 Line Termination Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-7

EBS Line Termination Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-7

ISDN Line Termination Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-8

ISDN Framed Path Termination Objects . . . . . . . . . . . . . . . . . . . . . .A-8

Quarter DS0 Channel Termination. . . . . . . . . . . . . . . . . . . . . . . . . .A-10

Crossconnection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-10

Equipment Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-11

IDLC Call Processing Profile Objects . . . . . . . . . . . . . . . . . . . . . . .A-11

IDLC Data Link Profile Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . .A-12

IDLC Data Link Termination Objects . . . . . . . . . . . . . . . . . . . . . . .A-13

IDLC Terminal Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-14

Memory Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-14

Network Element Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-15

Protection Group Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-15

Protection Group Unit Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-16

Actions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-17

Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-18

Access Navigator - Release 1.8 August 2003 1xxvii

Table of Contents

B FDL Interface

C SNMP Interface

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2

Remote Provisioning Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Access Navigator Remote Provisioning Requirements. . . . . . . . . . . B-3

Access Bank II Remote Provisioning Requirements. . . . . . . . . . . . . B-3

Adit 600 TDM Remote Provisioning Requirements . . . . . . . . . . . . . B-3

Remote Provisioning Capabilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4

Access Bank II Capabilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2

Carrier Access Enterprise MIB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

SNMP Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4

MIB Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4

MIB Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5

Managing Networks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6

SNMP Protocols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7

SNMP Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8

SNMP Trap Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9

Glossary

Abbreviations/Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Glossary-1

Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Glossary-4

Index

1xxviii August 2003 Access Navigator - Release 1.8

CHAPTER

In this Chapter

n Overview ... 1-2
n Features and Benefits ... 1-3
n Access Navigator Configurations ... 1-3

Introduction

n System Architecture ... 1-4
n Carrier Access Support Products ... 1-5
n Management ... 1-6

Introduction

Overview

Overview

The Access Navigator® Multiservice Digital Access (MDA) system combines the functionality of a
miniature 1/0 digital crossconnect switch (DCS) with the call processing and concentration capabilities of
a GR-303 digital loop car rier (DLC) system. Providin g up to 32 DS1 ports (768 DS0s) in one small package,
the Access Navigator fits easily into small collocation spaces and phone closets. Software configuration
options include:

l DCS Service Manage r
l GR-303 with Data Host
l GR-303 Host with P-Phone

The Access Navigator is a complete solution for managing 4 to 32 T1 access connections. In conjunction
with Carrier Access’ remotely mana ged Adit® 600 and Access Bank® families of T1 voice and dat a access
products, the Access Navigat or provides an end-to-e nd managed solution for deployi ng T1-based multi-line
voice and data services to businesses, with up to 24 voice lines and data rates up to 1.536 Mbps.

Figure 1-1. Access Navigator

1-2 August 2003 Access Navigator - Release 1.8

Introduction

Features and Benefits

Features and Benefits

The Access Navigator provides the ability to concentrate and groom a mix of voice and data information.
The 1/0 crossconnect functionality of the DCS allows data channels from a variety of locations to be
crossconnected an d packed into dedicated T1s . The time slo t interchan ge (TSI) func tionality of the GR-303
system dynamically assigns voice traffic to the local digital switch. These two functions significantly reduce
the number of switch ports and T1s required to backhaul both voice and data traffic.

DCS, GR-303, and P-Phone benefits include:

l Voice and data concentration
l Voice and data grooming
l GR-303 line concentration of 4:1 TDM ISDN BRI services
l GR-303 line concentration of Nortel P-Phone (EBS) services from CA’s Adit® terminals
l Installation at central office or customer premises
l Remote Acce ss Navigator manag ement via Ethernet IP, Telnet, SNMP, Valet™ a nd NetworkValet™

EMS software

l Remote management of CA’s Adit 600 and Access Bank® II terminals via T1 Facility Data Link
l Remote management of CA’s Adit 600 terminals using IP commands via T1 DS0 channel

Access Navigator Configurations

With up to 32 DS1 interfaces, the Access Navigator has the capacity and flexibility to deploy a variety of
voice and data services. Configurations include:

l Access Naviga tor / DCS Service Manager – crossco nnects and grooms DS0s car rying voi ce and dat a

for most efficient use of DS1s (se e Access Navigator / DCS Service Manager on page 2-1).

l Access Navigator / GR-303 + Data Host – dynamically crossconnects and concentrates DS0 voice

lines for most e fficien t swit ch usage, i n additi on to providing all DCS feature s (see Access Navigator
/ GR-303 + Data Host on page 3-1).

l Access Na vigator / GR-303 Host with P-Phone – dynamically crosscon nects an d concent rates No rtel

EBS (P-Phone) services from CA’s Adi t 600 terminal s for most eff icient switc h usage, in addi tion to
providing all GR-303 and DCS features (see Access Navigator / GR-303 Host with P-Phone on

page 4-1).

Access Navigator - Release 1.8 August 2003 1-3

Introduction

System Architecture

System Architecture

The Access Navigator i s a di st ributed system in which the Access Navi gat or is the host terminal located at
a co-location or customer premise. CA’s Access Bank® and Adit® 600 products operate as remotely
managed s ervice units at the customer premis es.

Voice Switc h

(GR-303)

Public Network

DCS Voi c e

and Data

Internet, Data,

Private and

Special Services

Data Network

Voice

Remote

Management

Switch

DS1s

Groom

DS1s

Access

Navigator

RS-232Ethernet

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal

Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor
Output

Voice

Monitor

T1

-48Vdc
Return
Ground

Tip & Ring

Access Bank I

ACCESS BANK II

and

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc
Return
Ground

Tip & Ring

V . 35, T1

Voice

Data

Access Bank II

Voice

and

Data

24

PBX

Lines

Voice
Lines

or DSL

Router

P-Phone

FXS/FXO

PBX

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

P-Phones

(EBS)

Key System

Fax

ADIT 600

VoIP
T1 Drop

PBX

Stations

Adit 600

10/100BaseT

RS232

Modem

DDS
ISDN BRI

Switch Center

Co-location

T1 Drop
V.35

Customer Premises

Router

Ethernet

Figure 1-2. Access Navigator Sy stem Architecture

1-4 August 2003 Access Navigator - Release 1.8

Introduction

Carrier Access Support Products

Carrier Access Support Products

Access Banks

Access Bank® family of T1 CSU products (see Figure 1-2) includes:

l Access Bank I – up to 24 voice channels
l Access Bank II – up to 24 voice channels plus T1 and V.35 da ta interfaces
l Access Bank II / SNMP – up to 24 voice channels plus T1 and V.35 data, and Ethernet SNMP
l Access Bank II / SDSL – up to 24 voice channels plus SDSL and V.35 data interfaces

Adit 600

Adit® 600 family of Customer Service Terminals (see Figure 1-2) includes:

l Adit 600 TDM – 6 service card slots support up to 18 T1s per unit, up to 48 voice channels, or

any combination of voice and data services

Access Navigator - Release 1.8 August 2003 1-5

Introduction

Management

Management

The Access Navigator includes RS-232 and Ethern et port s for local and remot e management , provis ioning,
and testing (see Figure 1-3). Flow-thro ugh provisioni ng enables the Acc ess Navigator to pr e-provision , test
and manage remote Access Bank II units to provide the required voice and data services. The Access
Navigator also provides host support for provisioning and managing Adit 600 terminals.

Remote

Management

Network

Operations

Center

IP, SNMP,
Tel net CLI

RS-232 CLI

Local

Management

Computer or

Craft Terminal

Figure 1-3. Access Navigator Management

Hub or

Network

Modem or

Direct

IP, SNMP,

T elnet CLI

RS-232 CLI

Ethernet

RS-232

Access

Navigator

Command Line Interface

The command line interface is a simple user interface that controls configuration and maintenance
operations. There are two ways to use the command line interface:

l A VT-100 terminal (or a PC running terminal emulation software such as Hyper Terminal)

connected to the 9- pin (DB9) RS-232 port. The port runs at 960 0 baud, 8 data bits, 1 stop bit, no
parity, and no flow control.

l A Telnet connection using the 10Base-T Ethernet port. To use Telnet, the user must first assign

an IP address to the Access Navigator using the RS-232 interface.

1-6 August 2003 Access Navigator - Release 1.8

Introduction

SNMP

SNMP

The Access Navigator SNMP Agent is based on the SNMPv1 standard. It i mplements the following two
industry standard s p ec if ic at ions for the TCP/IP and DS1 interfaces, plus an Enterprise MIB developed
for managing CA’s Access Bank II products:

l RFC 1213 – Management Information Base for Network Management of TCP/ IP-based internets:

MIB-II

l RFC 1406 – Definitions of Managed Objects for the DS1 and E1 Interface Types

The Access Navigator supports:

l All mandatory objects defined in RFC 1213 for the TCP/IP network interface.
l The DS1 mandatory objects in RFC 1406 Near End Configuration Group, including t he Near End

Current, Interval, and Total objects. The Far End Object Group is optional and is not currently
supported.

The CA Enterprise MIB provides management support for Access Navigator features not included in
the standard MIB (RFC 1213). It also enables remote management of CA products connected via the
T1 facility data link (FDL) to the Access Navigator (Figure 1-1). The CA Enterprise MIB supports:

l Access Navigator system configuration settings including SNMP
l Access Navigator interface management
l DS1 management features not supported by the standard MIB
l DS0 management
l Remote device management
l Remote crossconnect management
l Remote in terface settin gs
l Remote DS1 settings
l Remote DS0 settings
l Remote cards and slots

The network manager can use any SNMP-compatible network management system such as
SunConnect’s SunNet Manager, HP OpenView, or Castle Rock’s SNMPc to monitor and control the
Access Navigator

The user connects to the SNMP agent through the 10Base-T Ethernet port. Before using the Ethernet
port, the user must set the IP, mask, gateway, and NMS addresses using the RS-232 command line
interface. See Provision Access Navigator on page 8-1 for instructions on how to configure these
addresses.

Access Navigator - Release 1.8 August 2003 1-7

Introduction

Valet and NetworkValet EMS Software

Valet and NetworkValet EMS Software

Valet™ and NetworkValet™ EMS are enhanced element management systems with simple graphical
user interfaces. Valet is ideal for technicians deploying Access Navigators in carrier networks, while
the full-featured Ne tworkValet EMS with alarms a nd performan ce monitori ng is inte nded for Networ k
Operations Centers (NOCs).

Valet and NetworkValet provide easy management of Carrier Access products including the Access
Navigator and Adit 600. Val et and NetworkValet are cross-platf orm Java applicat ions that run on eit her
Microsoft Windows and Solaris based computer systems. Java Runtime Engine (JRE) software for
Windows or Solaris is included with the Valet and NetworkValet installation programs.

Valet and NetworkValet sen d commands over the ca rrier’s IP network to communica te with the SNMP
agent in the Access Navigator. The Access Navigator includes a standard 10Base-T Ethernet port for
connection to the hub or network interface, or laptop computer. The Access Navigator must have
FLASH software version 1.7 or higher to support IP DS0 management of remote Adit 600 terminals.

1-8 August 2003 Access Navigator - Release 1.8

CHAPTER

Access Navigator / DCS Service Manager

In this Chapter

n Overview ... 2-2
n System Architecture ... 2-3
n Features and Benefits ... 2-4
n Configuration ... 2-6
n Applications ... 2-7
n Interfaces ... 2-7
n Specifications ... 2-7
n Compliance Requirements ... 2-10
n Ordering Information ... 2-12

Access Navigator / DCS Service Manager

Overview

Overview

The Access Navigator® / DCS Service Manager is a complete service solution for managing 4 to 32 T1
access connections. The power of a remotely managed, 32-port, Digital Crossconnect System (DCS) is
contained in only 1½ rack units. Integrated testing and optional common equipment redundancy ensure
carrier-class service a vailability.

The Access Navigator / DCS Service Manager provides the functionality of a miniature 1/0 digital
crossconnect switch (DCS). Providing up to 32 DS1 ports (768 DS0s) in one small package, the Access
Navigator fits easily into small collocation spaces and phone closets.

The Access Navigator is a complete solution for managing 4 to 32 T1 access connections. In conjunction
with Carrier Access’ remotely mana ged Adit® 600 and Access Bank® families of T1 voice and dat a access
products, the Access Navigat or provides an end-to-e nd managed solution for deployi ng T1-based multi-line
voice and data services to businesses, with up to 24 voice lines and data rates up to 1.536 Mbps.

.

Figure 2-1. Access Navigator / DCS Service Manager

2-2 August 2003 Access Navigator - Release 1.8

Access Navigator / DCS Service Manager

System Architecture

System Architecture

24

PBX

PBX

Router

PBX

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

Voice Switch

Voice

Public Network

DCS Voi c e

and Data

Internet, Data,

Private and

Spec ial Services

Data Netwo rk

Remote

Management

Ethernet

Telnet &

SNMP

Groom

T1s

Access

Navigator

RS-232

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal
Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor
Output

Voice

Monitor

T1

-48Vdc
Return
Ground

Tip & Ring

Access Bank I

ACCESS BANK II

and

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc
Return
Ground

Tip & Ring

V.35, T1

Voice

Data

Access Bank II

Voice

and

Data

Lines

Voice
Lines

or DSL

FXS/FXO
VoIP

T1 Drop

ADIT 600

10/100BaseT

Adit 600

RS232

Modem

DDS
ISDN BRI

Switch Cen ter

Co-location

T1 Drop
V.35

Customer Premises

Router

Ethernet

Figure 2-2. Access Navigator / DCS Service Manager Architecture

Access Navigator - Release 1.8 August 2003 2-3

Access Navigator / DCS Service Manager

Features and Benefits

Features and Benefits

Functions

The Access Navigator / DCS Service Manager is a transport element that combines the functions of a
32-port T1 digital crossconnect system, T1 channel/data service unit (CSU), T1 diagnostic test
equipment, and Access Ban k® II host controlle r int o a modular chassis 1½ rack units high ( see Figure
2-2). Ethernet SNMP, optiona l redundancy, and modular T1 expansion provide carrier-class service
protection and management at either carrier or customer located T1 service access points.

Services

The Access Navigator provides all the grooming and filling functions of a 1/0 digital crossconnect
system to maximize T1 u sag e. W i th carrier/customer demarcation testin g, c arr i ers are able to decrease
maintenance costs and labor, while increasing service availability. Fractional voice and data services
from multiple customers and applications are combined by the Access Navigator to save recurring
backhaul transmission costs, and capital costs on switch or router ports.

Facilities

With both NEBS and customer premise certifications, the Access Navigator can be located in carrier
racks or on customer walls. Spa ce, power, and install ation labor are dramatic ally reduced in compari son
to old generation di git al cr oss con nect and CSU or NIU shelves. Additional Quad T1 Framer cards can
be installed while the Acces s Navigator is in service to provide from 4 to 32 DS1/CSU conne ction ports.
TFTP and Xmodem utilities permit software updates to redundant systems without affecting service.

Management

Access Navigators pr ovi de management access vi a Ethernet SNMP, Telnet CLI, and RS-232 CLI (see
Figure 2-3). Valet™ and NetworkVale t™ EMS software pr ovides a gra phical user interf ace (GUI) for
SNMP management. Flow-t hrough provis ionin g of the remote Access Bank II and t esti ng cont rol o ver
T1 connections re duce truck rolls a nd monitors voice a nd data service availability at c ustomer locations .

2-4 August 2003 Access Navigator - Release 1.8

Access Navigator / DCS Service Manager

Management

Network

Operations

Center

CLI/Telnet

Access

Navigator

Element

Manager

SNMP

TCP/IP

Network

Voice

Switch

Data

Switch

On-Net

Location

Access

Navigator

Local

Management

CLI/RS-232

Customer

Wiring Closet

ACCESS BANK II

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232

FDL

T1

Adit 600

Data

-48Vdc
Return
Ground

Tip & Ring

Access

Bank II

ADIT 600

Voice
Lines

PBX

V.35, T1

or DSL

Router

FXS/FXO

VoIP

PBX

T1 Drop

10/100BaseT

RS232

Modem

DDS
ISDN BRI
T1 Drop
V.35

Router

Customer

Premises

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

Ethernet

Figure 2-3. Access Navigator Management A rchi t ect ure

Access Navigator - Release 1.8 August 2003 2-5

Access Navigator / DCS Service Manager

Configuration

Configuration

l Hardware configuration: Modular construction with plug-in cards includes built-in circuit and

network testing and fuse-less protection (see Figure 2-4).

l Software confi gurat ion: Ope rating s yst em is stor ed in upgrade able f lash memory. Configu ratio n and

provisioning data are stored in nonvolatile RAM, protected from power interruptions.

Technology Advantages

• Low Cost

• Small Size

• Low Power

• Surge Protection

• Test Integration

• Fault Isolation

• No Fans

Quad T1 Framer Card Features

• Four T1 circuits per card

• Up to 8 cards (32 T1s)

•1/0 cross-connections

•Groom and fill T1s

• Fuseless high-voltage
protection

•Built-in T1 CSU

• Hot swappable

Front

Controller

Card

Controller

Card

Controller Card Features

•Power and control
circuit redundancy

•Ethernet Telnet and SNMP
remote management

•Built-in circuit and network
testing

Lightning

Hazards

Power Line

Hazards

Rear

RS232

Management

Figure 2-4. Access Navigator Hardware Configuration

Ethernet

Management

Redundant

Power Input

T1 Interface

Cables

2-6 August 2003 Access Navigator - Release 1.8

Access Navigator / DCS Service Manager

Applications

Applications

l T1 Service POP-In-A-Box: Customer-located T1 access management for carriers
l End-Office T1 Grooming: T1 access consolidation, provisioning, protection, and service

management

l DCS Host Control o f Access Bank II: Flow-t hrough remote management a nd bandwidth grooming o f

Access Bank IIs

l PCS and Cellular Site T1 Bandwidth Management: Drop, groom, and test multiple T1 connections

between cell sites and hubs

Interfaces

l DS1 Interfa ce: Two Champ® 64-pin connector s with 32 DS1 circuits, one for recei ve (input) and one

for transmit (output)

l RJ45C Interface: Timing input connector for external clock source (such as BITS)
l RS-232 Interface: DB9 (DE9) female connector for CLI management by craft terminal or computer

with terminal emulation software

l Ethernet Interface: 10Base-T connector for SNMP and Telnet CLI management

Specifications

DCS Operation

l Up to 32 T1s per system
l DCS 1/0 interface supports crossconnects at DS0 level
l Crossconnects up to 24 contiguous DS0s between T1s with one command
l Redundancy, 1:1 controller & power conversion

DS1 Interface

l Four T1s per line card, hot swappable
l Line rate: 1.544 Mb/s ± 32ppm
l Line code: B8ZS or AMI
l Framing: D4 (SF) or ESF
l DS1 receive sensitivity: –28dB to +1.5dB
l Line build-outs:

DSX-1 (0 to 660 ft. in 5 steps)
CSU (0 dB, –7.5 dB, –15 dB, –22.5dB)

Access Navigator - Release 1.8 August 2003 2-7

Access Navigator / DCS Service Manager

System Clocking

ANSI T1.403, Section 6 & 7 (jitter, pulse mask transmission, receive sensitivity, framing

l

formats)

l Built-in CSU with loopback and BERT for testing the T1s

System Clocking

l Primary and secondary sources from: DS1s, external clock source (suc h as BITS) or internal

clock (minimum Stratum 4)

l Automatic clock switching and holdover

Signaling

l Robbed-bit and clear channel connections at DS0 level
l FXS/FXO loop start and ground st art robbed bit signaling
l E&M robbed bit signaling

Management Interfaces

l Command line interface (CLI) for provisioning and maintenance
l RS-232 interface for local CLI
l Ethernet Telnet support for remote CLI
l Ethernet SNMP uses Telcordia® standard MIB for DS1 interfaces (RFC-1406)
l TFTP and Xmodem support for flash memory software upgrades

Protocols

l Command Line Interface (CLI)
l Simple Network Management Protocol (SNMP)
l Telnet /TFTP

Alarms

l Critical, Major, and Minor alarm levels
l DS1 alarms for LOS, LOF, AIS, and RAI
l Front panel LED indicators
l Output signal: relay contact closure and LED indi cation

Maximum relay contact rating: 110V AC or DC @ 1A

l Alarm inputs from dry contact closures

Maximum input rating: 60V DC

2-8 August 2003 Access Navigator - Release 1.8

Access Navigator / DCS Service Manager

Compliance

Compliance

USA

l UL 1950, 3rd Edition
l FCC Part 15, Clas s A
l FCC Part 68
l NEBS Level 3 for Type 2 and 4 equipment

GR-1089-CORE
GR-63-CORE

CANADA

l CSA C22.2 No. 950.95
l ICES-003, Class A
l CS-03

Power

l Input power: –42 to –60 VDC @ 1.5A
l Dual feed DC power input terminals
l Power dissipation: 65 watts (225 Btu/hr.), fully equipped
l Solid-state (fuse-less) over-voltage and over-current protection

Environmental

l Operating temperature: –5°C to +45°C (23°F to 113°F), up to +55°C short term (NEBS)
l Solid-state over-temperature protection
l Relative humidity: 0 to 95%, non-condensing
l No fans; Passive therma l management

Physical

l Dimensions: 17" x 13.5" x 2.63"
l Weight: 10 lbs. (4.54 kg)
l Mounts in 19 and 23 inch racks
l Optional wall mount brackets

Access Navigator - Release 1.8 August 2003 2-9

Access Navigator / DCS Service Manager

Compliance Requirements

Compliance Requirements

FCC Requirements

This equipment complies with Pa rt 15 and Part 68 of the F ederal Communicat ions Commission (FCC)
Rules.

Part 15, Class A

This equipment has bee n t es te d a nd found to comply with the limits for a Cla ss A digital device in
accordance with Part 15 of the FCC Rules. These limits provide reasonable protection against
harmful interference when equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions in this manual may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which ca se the user will be required to correct the interference at the user’s own
expense.

The following cables, when conne cted to this equipment , must be shielded to maint ain FCC Part 15
compliance:

l Both DSX-1 cables
l RS-232 cable

Part 68

This equipment complies with Part 68 of the Federal Communications Commission rules. The
silkscreen on the top cover of this equipment includes the FCC registration number.

You must supply the following information to the telephone company, if they request it.

l FCC Registration Number: 2Z6USA-33482-DD-N
l Service Center in the USA:

Carrier Access Corporation
5395 Pearl Parkway
Boulder CO 80301-2490
Phone [phone]

If this equipment has been found to cause harm to the telephone network, the telephone company
will notify you in advance. If advance n otice prove s impractica l, the tel ephone company wi ll notify
the customer as soon as possible. Also, you will be advised of your ri ght to file a complaint with the
FCC if you believe such action is necessary.

If the trouble is causing harm to the telephone network, the telephone company may request that
you remove the equipment fr om the network until the problem is resolved.

The telephone company may make changes in it’s facilities, equipment, operations or procedures
that could affect the operation of your equipment. If this happens, the telephone company will

2-10 August 2003 Access Navigator - Release 1.8

Access Navigator / DCS Service Manager

Telcordia (Bellcore) Requirements

provide advance n otice i n order f or you t o make nece ssary modi ficati ons to mai ntain uni nterrup ted
service.

If you need to make repairs or modifications to the equipment, please first contact Carrier Access
Corporation for repair, modification, and warranty information. Customer repairs and
modifications are limited to the replacement of circuit boards; any other repairs or modifications
will void your warranty.

Facility Interface Codes (FIC)

FIC CODES DESCRIPTION

04DU9-BN 1.544 Mbps Superframe Format (SF) without Line Power
04DU9-DN 1.544 Mbps Superframe (SF) and B8ZS without Line Power
04DU9-1KN 1.544 Mbps ANSI, ESF without Line Power
04DU9-1SN 1.544 Mbps ANSI, ESF, and B8ZS without Line Power

Service Order Codes (SOC)

SOC CODES DESCRIPTION

6.0F Combinations of equipment provide full protection to digital
services. Billing protection and encoded analog protection are
provided either by including auxiliary equipment within the
registration envelope or by use of a separately registered device.

Telcordia (Bellcore) Requirements

This equipment conforms with Telcordia® standard GR-1089-CORE, New Equipment Building
System (NEBS), requirements for intra-building (inside plant) Type 2 and Type 4.

To maintain compli ance wi th t he GR-10 89-CORE re quire ments to prevent EMI /EMC radio freque ncy
interference with other equipment, the DSX-1 and RS-232 cables mus t be shielded and ha ve ferrite bead
RFI suppressors.

UL Requirements

This equipment conforms with Underwriters Laboratory standard UL 1950 (supersedes UL 1459). To
maintain this compliance, all access covers must be replaced after servicing the equipment to prevent
fires from spreading to nearby equipment.

Access Navigator - Release 1.8 August 2003 2-11

Access Navigator / DCS Service Manager

CSA Requirements

CSA Requirements

This telecommunication network equipment conforms with Canadian Standards Association (CSA)
standard C22.2 No. 950.95. To maintain this compliance, all access covers must be replaced after
servicing the equipment to prevent fires from spreading to nearby equipment.

Ordering Infor m ation

Part Numb er Item Description

930-0202 AN/DCS/R/32 Access Navigator DCS Service Manager,

930-0200 AN-Case Access Navigator redundant NEBS chassis and

740-0016 AN-DCS Controller

Card

740-0018 Quad T1 Framer Card Access Navigator Quad T1 Framer card

32 T1 Redundant Package:
2 AN-DCS Controller Cards
8 AN-Quad T1 Framer Cards

backplane. Chassis holds two Controller cards
and eight Quad T1 Framer cards (32 T1 circuits).
Order cards separately.

Access Navigator Controller card with Digital
Crossconnect System (DCS) software.

terminates 4 T1 interfaces from switch, customer
site, or data network.

005-0025 DSX-1 Cable 64-pin DSX-1 cable, 10 feet long, male/male.

Two cables must be ordered per Access
Navigator, one TX, one RX. May be used for

DS1 and DSX-1 transmission levels.
005-0030 DSX-1 Cable 64-pin DSX-1 cable, 25 feet long (see 005-0025).
710-0153 19”/23” Universal

Mounting Brackets

710-0003 19” Vertical Mount

Crossbars

710-0004 23” Vertical Mount

Crossbars

770-0079 AN-Manual Access Navigator User Manual is included with

Universal mounting brackets and screws for 19

and 23 inch equipment racks. This bracket set is

included with all Access Navigator unit

purchases.

Two heavy-duty 19 inch horizontal crossbars

mount in equipment rack and enable vertical

installation of up to 6 Acce ss Navigat or and Wide

Bank 28 products.

Two heavy-duty 23 inch horizontal crossbars

mount in equipment rack and enable vertical

installation of up to 6 Acce ss Navigat or and Wide

Bank 28 products.

all Access Navigator unit purchases.

2-12 August 2003 Access Navigator - Release 1.8

CHAPTER

Access Navigator / GR-303 + Data Host

In this Chapter

n Overview ... 3-2
n System Architecture ... 3-3
n Features and Benefits ... 3-4
n GR-303 Services ... 3-4
n DCS Services ... 3-6
n Management Architecture ... 3-7
n Configuration ... 3-9
n Applications ... 3-10
n Interfaces ... 3-10
n Specifications ... 3-11
n Compliance Requirements ... 3-14
n Ordering Information ... 3-16

Access Navigator / GR-303 + Data Host

Overview

Overview

The Access Navigator® / GR- 303 + Dat a Host of fers a highl y inte grate d solut ion for combini ng multi -line
local voice and dat a services on customer T1 acc ess lines. Using the Tel cordia® standard GR-303 s witching
protocol, up to 672 customer telephone channels can be assigned on a call-by-call basis to Class 5 local
digital switch T1 connect ions. In addition to the con centration and management of CLASS® voice services,
the Access Navigator grooms, and optionally concentrates, fractional T1 data connections from customer
locations

.

Figure 3-1 Access Navigator / GR-303 + Data Host

3-2 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 + Data Host

System Architecture

System Architecture

GR-303

Voice

Switch with

GR-303

DCS Voice

and Data

Internet, Data,

Private and

Special Services

Remote

Management

Switch

DS1s

Groom

DS1s

Access

Navigator

RS-232Ethernet

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal
Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor
Output

Voice

Monitor

T1

-48Vdc

Return

Ground

Tip & Ring

Access Bank I

ACCESS BANK II

and

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc

Return

Ground

Tip & Ring

V.35, T1

Voice

Data

Access Bank II

Voice

and

Data

24

PBX

Lines

Voice
Lines

or DSL

Router

FXS/FXO
VoIP

T1 Drop

PBX

PBX

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

ADIT 600

10/100BaseT

Adit 600

RS232

Modem

DDS
ISDN BRI

Switch Center

Co-location

T1 Drop
V.35

Customer Premises

Router

Ethernet

Figure 3-2. Access Navigator / GR-303 + Data Host Architecture

Access Navigator - Release 1.8 August 2003 3-3

Access Navigator / GR-303 + Data Host

Features and Benefits

Features and Benefits

The Access Navigator / GR-303 + Data Host is a transp ort element that combines the functi ons of a GR-303
digital terminal, 32-port T1 digital crossco nnect sys tem, T1 channe l/data service unit (CSU), T1 diagnost ic
test equipment, and Access Bank® II host controller into a modular chassis 1½ rack units high. Ethernet
SNMP, optional redundancy, and modular T1 expansion provide carrier-class service protection and
management at either carrier or customer located T1 service access points.

Access Navigator / GR-303 + Data Host offers an integration of:

l 32 T1 port GR-303 remote digital terminal
l GR-303 to TR-08 translation for CA’s Access Bank® I/TR-08
l GR-303 Direct Inward Dial (DID) support when used with Lucent 5ESS switches
l Digital crossconnect system
l T1 CSUs and demarcation testing
l Ethernet Telnet and SNMP management
l Optional Controller redundancy
l Modular Quad T1 expansion
l NEBS Certified

GR-303 Services

The Access Navigator / GR-303 + Data Host provides T1 local voice and data se rvices to multiple customers
(see Figure 3-3). Using GR-303 switching protocol for call concentration, the Access Navigator reduces
recurring backhaul transmission costs and switch port costs by up to a factor of 4.

By using CA's Access Bank® II and Adit 600 products at the customer premise, an end-to-end distributed
voice and data digita l loop carrier and remote management system is provided. Standard T1 connections
from customer PBXs and key systems may be concentrated or bypassed from the GR-303 groups.

The power of a 32 T1 port voice and data switch/concentrator and remote service management system is
contained in only 1½ rack units of space. Integrated testing and optional common equipment redundancy
assure carrier-class service availability.

3-4 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 + Data Host

GR-303 Services

CA's Access Navigator / GR-303 + Data Host, together with the Access Bank II and Adit 600, bring cost­effective concentration and remote management to competitive local carriers with a new level of
serviceability and space efficiency.

24

PBX

PBX

Router

PBX

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

Switch

GR-303

Voice &

ISDN BRI

Data

GR-303

Interface

Group

Remote

Management

Ethernet

Telnet &

SNMP

Switch

DS1s

Access

Navigator

RS-232

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal
Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor
Output

Voice

Monitor

T1

-48Vdc
Return
Ground

Tip & Ring

Access Bank I

ACCESS BANK I I

and

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc
Return
Ground

Tip & Ring

V .35, T1

Voice

Data

Access Bank II

Voice

and

Data

Lines

Voice

Lines

or DSL

FXS/FXO

VoIP
T1 Drop

ADIT 600

10/100BaseT

Adit 600

RS232

Modem

DDS
ISDN BRI

Integrated Digital

T erminal (IDT)

Remote Digital
Terminal (RDT)

T1 Drop
V.35

Customer Premises

Router

Ethernet

Figure 3-3. Access Navigator GR-303 + Data Host Architecture

Access Navigator - Release 1.8 August 2003 3-5

Access Navigator / GR-303 + Data Host

DCS Services

DCS Services

The Access Navigator provides all the grooming and filling functions of a 1/0 digital crossconnect system
(DCS) to maximize T1 usage. With carrier/customer demarcation testing, carriers are able to decrease
maintenance costs an d la bor , while increasing service availability. Fract ional voice and data services from
multiple customers and applications are combined by the Access Navigator to save recurring backhaul
transmission costs, and capital costs on switch or router ports.

24

PBX

PBX

Router

PBX

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

Voice Switch

Voice

Public Network

DCS Voi c e

and Data

Internet, Data,

Private and

Spec i al Services

Data Netwo rk

Remote

Management

Ethernet
Telnet &

SNMP

Groom

T1s

Access

Navigator

RS-232

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal
Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor

Output

Voice

Monitor

T1

-48Vdc
Return
Ground

Tip & Ring

Access Bank I

ACCESS BANK II

and

T1
Span 1

T1
Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc
Return
Ground

Tip & Ring

V.35, T1

Voice

Data

Access Bank II

Voice

and

Data

Lines

Voice
Lines

or DSL

FXS/FXO
VoIP

T1 Drop

ADIT 600

10/100BaseT

Adit 600

RS232

Modem

DDS
ISDN BRI

Switch Cen ter

Co-location

T1 Drop
V.35

Customer Premises

Router

Ethernet

Figure 3-4. Access Navigator Data Host Architecture

3-6 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 + Data Host

Management Architecture

Management Architecture

Access Navigators pr ovide manag ement acce ss via Et hernet SNMP, Teln et CLI, and RS- 232 CLI. Valet™
and NetworkValet™ EMS software provides a graphical user interface (GUI) for SNMP management.
Flow-through provisioning of the remote Access Bank II and testing control over T1 connections reduce
truck rolls and monitors voice and data service availability at customer locations.

IP DS0 Management

The Access Navigator can use IP management commands and dedicated DS0s to manage up to 24
remote Adit 600 terminals. IP DS0 management uses a colocated Adit 600 terminal with an IP Router
card to redirect IP messag es between the Access Navigat or’s IP port and t he 24 DS0s on a groom DS1.
The Access Navigator then cross-connects the groom DS0s to a dedicated drop DS0 going to each
remote Adit 600. Customers wishing to conserve IP addresses can use an Ethernet hub or router
providing port addresses translation (NAT) to isolate the IP DS0 management network.

Network

Operations

Center

IP = X.X.X.1

Management

Console

Figure 3-5. Access Navigator IP DS0 Management Architecture

On-Net

Location

Ethernet

Hub

Navigator

POWER

ACO

CRIT

MAJOR

(PUSH)

ACO

MINOR

CONTROLL ER A

ACTIVE

123456789101112131415161718192021222324252627

DS1 STATUS

Static DS0 Management

Connnections between
Groom and Drop DS1s

Adit 600

(colocated) (remote)

IP

Router

Access

POWER

ACO

ACCESS

CRIT

MAJOR

(PUSH)

ACO

NAVIGATOR

ACTIVE

293031

MINOR

CARRIER ACCESS

CONTROLLER B

CORPORATION

DS1 25

Adit 600

DS0 1

Groom
DS1

Drop DS1s

32

28

l
l
l

Customer

Premises

Adit 600

DS1 1
DS0 24

IPDS0 = X.X.X.1

Up to 24

Remote Adits

Adit 600

(remote)

DS1 24
DS0 24

IPDS0 = X.X.X.24

Adit 6 00

l
l
l

Adit 6 00

Access Navigator - Release 1.8 August 2003 3-7

Access Navigator / GR-303 + Data Host

FDL Management

FDL Management

When T1 Type I lines are available, the Access Navigator can use the ESF Faciltiy Data Link channel
to manage re mote Access B ank II and Adit 600 terminals.

Network

Operations

Center

CLI/Telnet

Access

Navigator

Element

Manager

SNMP

TCP/IP

Network

Voice

Switch

Data

Switch

On-Net

Location

Access

Navigator

Local

Management

CLI/RS-232

Customer

Wiring Closet

ACCESS BANK II

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232

FDL

T1

Adit 600

Data

-48Vdc
Return
Ground

Tip & Ring

Access

Bank II

ADIT 600

Voice
Lines

PBX

V.35, T1

or DSL

Router

FXS/FXO
VoIP

PBX

T1 Drop

10/100BaseT

RS232

Modem

DDS
ISDN BRI
T1 Drop
V.35

Router

Customer

Premises

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

Ethernet

Figure 3-6. Access Navigator FDL Management Architecture

3-8 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 + Data Host

Configuration

Configuration

The Access Navigator / GR-303 + Data Host combines call processing and concentration capabilities of a
GR-303 digital loop carrier (DLC) system with the functionality of a miniature 1/0 digital crossconnect
switch (DCS). Providing up to 32 DS1 ports (768 DS0s) in one small package, the Access Navigator fits
easily into small collocation spaces and phone closets.

l Hardware configuration: Modular construction with plug-in cards includes built-in circuit and

network testing and fuse-less protection (see Figure 3-7)

l Software confi gurat ion: Ope rating s yst em is stor ed in upgrade able f lash memory. Configu ratio n and

provisioning data are stored in nonvolatile RAM, protected from power interruptions.

Technology Advantages

• Low Cost

• Small Size

• Low Power

• Surge Protection

• Test Integratino

• Fault Isolation

• No Fans

Quad T1 Framer Card Features

• Four T1 circuits per card

• Up to 8 cards (32 T1s)

•1/0 cross-connections

•Groom and fill T1s

• Fuseless high-voltage
protection

•Built-in T1 CSU

• Hot swappable

Front

Controller

Card

Controller

Card

Controller Card Features

•Power and control
circuit redundancy

•GR-303 call support

•Ethernet Telnet and SNMP
remote management

•Built-in circuit and network
testing

Lightning

Hazards

Power Line

Hazards

Rear

RS232

Management

Figure 3-7. Access Navigator Hardware Configuration

Access Navigator - Release 1.8 August 2003 3-9

Ethernet

Management

Redundant

Power Input

T1 Interface

Cables

Access Navigator / GR-303 + Data Host

Applications

Applications

l T1 Service POP-In-A-Box: Customer-located T1 access management for carriers
l Call Conc ent ra ti on: Var ia bl e concentration of voice calls for more efficient use of backhaul T1s and

switch resources

l End-Office T1 Grooming: T1 access consolidation, provisioning, protection, and service

management

l Host Control of Access Bank II: Flow-through remote management and bandwidth grooming of

Access Bank IIs

Interfaces

l DS1 Interfa ce: Two Champ® 64-pin connector s with 32 DS1 circuits, one for recei ve (input) and one

for transmit (output)

l RJ45C Interface: Timing input connector for external clock source (such as BITS)
l RS-232 Interface: DB9 (DE9) connector for CLI management by craft terminal or computer with

terminal emulation software

l Ethernet Interface: 10Base-T connector for SNMP and Telnet CLI management

3-10 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 + Data Host

Specifications

Specifications

GR-303 Operation

l Up to 32 T1s per system
l Primary and redundant protection for EOC and TMC
l GR-303 to TR-08 translation for CA’s Access Bank I/TR-08
l GR-303 Direct Inward Dial (DID) support for Lucent 5ESS switches
l GR-303 line concentration of 4:1 TDM ISDN BRI services
l Alarm and maintenance support for DS1 terminations
l Compatible with Lucent, Nortel, and Siemens switches
l Configurable concentration ratios
l Programmable call reference values (CRVs)
l Redundancy, 1:1 controller & power conversion

Crossconnects

l DCS 1/0 interface supports crossconnects at DS0 level
l Crossconnects up to 24 contiguous DS0s between T1s with one command

DS1 Interface

l Four T1s per line card, hot swappable
l Line rate: 1.544 Mb/s ± 32ppm
l Line code: B8ZS or AMI
l Framing: D4 (SF) or ESF
l DS1 receive sensitivity: –28dB to +1.5dB
l Line build-outs:

DSX-1 (0 to 660 ft. in 5 steps)
CSU (0 dB, –7.5 dB, –15 dB, –22.5dB)

l ANSI T1.403, Section 6 & 7 (jitter, pulse mask transmission, receive sensitivity, framing

formats)

l Built-in CSU with loopback and BERT for testing the T1s

System Clocking

l Primary and secondary sources from: DS1s, external clock source (such as BITS) or internal

clock (minimum Stratum 4)

l Automatic clock switching and holdover

Access Navigator - Release 1.8 August 2003 3-11

Access Navigator / GR-303 + Data Host

GR-303 Signaling

GR-303 Signaling

l GR-303 ABCD robbed-bit signal codes
l GR-303 Direct Inward Dial (DID) signaling for Lucent switches
l GR-303 4:1 TDM mode support for ISDN BRI
l FXS loop start and ground start

DCS Signaling

l Robbed-bit and clear channel connections at DS0 level
l FXS/FXO loop start and ground start
l E&M robbed bit signaling

Management Interfaces

l Command line interface (CLI) for provisioning and maintenance
l RS-232 interface for local CLI
l Ethernet Telnet support for remote CLI
l Ethernet SNMP uses Telcordia® standard MIB for DS1 interfaces (RFC-1406)
l TFTP and Xmodem support for flash memory software upgrades

Protocols

l Command Line Interface (CLI)
l Simple Network Management Protocol (SNMP)
l Telcordia® GR-303
l Telnet
l TFTP and Xmodem support for flash memory software upgrades

Alarms

l Critical, Major, and Minor alarm levels
l DS1 alarms for LOS, LOF, AIS, and RAI
l Front panel LED indicators
l Output signal: relay contact closure and LED indi cation

Maximum relay contact rating: 110V AC or DC @ 1A

l Alarm inputs from dry contact closures

Maximum input rating: 60V DC

3-12 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 + Data Host

Compliance

Compliance

USA

l UL 1950, 3rd Edition
l FCC Part 15, Clas s A
l FCC Part 68
l NEBS Level 3 for Type 2 and 4 equipment

GR-1089-CORE
GR-63-CORE

CANADA

l CSA C22.2 No. 950.95
l ICES-003, Class A
l CS-03

Power

l Input power: –42 to –60 VDC @ 1.5A
l Dual feed DC power input terminals
l Power dissipation: 65 watts (225 Btu/hr.), fully equipped
l Solid-state (fuse-less) over-voltage and over-current protection

Environmental

l Operating temperature: –5°C to +45°C (23°F to 113°F), up to +55°C short term (NEBS)
l Solid-state over-temperature protection
l Relative humidity: 0 to 95%, non-condensing
l No fans; Passive therma l management

Physical

l Dimensions: 17" x 13.5" x 2.63"
l Weight: 10 lbs. (4.54 kg)
l Mounts in 19 and 23 inch racks
l Optional wall mount brackets

Access Navigator - Release 1.8 August 2003 3-13

Access Navigator / GR-303 + Data Host

Compliance Requirements

Compliance Requirements

FCC Requirements

This equipment complies with Pa rt 15 and Part 68 of the F ederal Communicat ions Commission (FCC)
Rules.

Part 15, Class A

This equipment has bee n t es te d a nd found to comply with the limits for a Cla ss A digital device in
accordance with Part 15 of the FCC Rules. These limits provide reasonable protection against
harmful interference when equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions in this manual may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which ca se the user will be required to correct the interference at the user’s own
expense.

The following cables, when conne cted to this equipment , must be shielded to maint ain FCC Part 15
compliance:

l Both DSX-1 cables
l RS-232 cable

Part 68

This equipment complies with Part 68 of the Federal Communications Commission rules. The
silkscreen on the top cover of this equipment includes the FCC registration number.

You must supply the following information to the telephone company, if they request it.

l FCC Registration Number: 2Z6USA-33482-DD-N
l Service Center in the USA:

Carrier Access Corporation
5395 Pearl Parkway
Boulder CO 80301-2490
Phone [phone]

If this equipment has been found to cause harm to the telephone network, the telephone company
will notify you in advance. If advance n otice prove s impractica l, the tel ephone company wi ll notify
the customer as soon as possible. Also, you will be advised of your ri ght to file a complaint with the
FCC if you believe such action is necessary.

If the trouble is causing harm to the telephone network, the telephone company may request that
you remove the equipment fr om the network until the problem is resolved.

The telephone company may make changes in its facilities, equipment, operations or procedures
that could affect the operation of your equipment. If this happens, the telephone company will

3-14 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 + Data Host

Telcordia (Bellcore) Requirements

provide advance n otice i n order f or you t o make nece ssary modi ficati ons to mai ntain uni nterrup ted
service.

If you need to make repairs or modifications to the equipment, please first contact Carrier Access
Corporation for repair, modification, and warranty information. Customer repairs and
modifications are limited to the replacement of circuit boards; any other repairs or modifications
will void your warranty.

Facility Interface Codes (FIC)

FIC CODES DESCRIPTION

04DU9-BN 1.544 Mbps Superframe Format (SF) without Line Power
04DU9-DN 1.544 Mbps Superframe (SF) and B8ZS without Line Power
04DU9-1KN 1.544 Mbps ANSI, ESF without Line Power
04DU9-1SN 1.544 Mbps ANSI, ESF, and B8ZS without Line Power

Service Order Codes (SOC)

SOC CODES DESCRIPTION

6.0F Combinations of equipment provide full protection to digital
services. Billing protection and encoded analog protection are
provided either by including auxiliary equipment within the
registration envelope or by use of a separately registered device.

Telcordia (Bellcore) Requirements

This equipment conforms with Telcordia® standard GR-1089-CORE, New Equipment Building
System (NEBS), requirements for intra-building (inside plant) Type 2 and Type 4.

To maintain compli ance wi th t he GR-10 89-CORE re quire ments to prevent EMI /EMC radio freque ncy
interference with other equipment, the DSX-1 and RS-232 cables mus t be shielded and ha ve ferrite bead
RFI suppressors.

UL Requirements

This equipment conforms with Underwriters Laboratory standard UL 1950 (supersedes UL 1459). To
maintain this compliance, all access covers must be replaced after servicing the equipment to prevent
fires from spreading to nearby equipment.

Access Navigator - Release 1.8 August 2003 3-15

Access Navigator / GR-303 + Data Host

CSA Requirements

CSA Requirements

This telecommunication network equipment conforms with Canadian Standards Association (CSA)
standard C22.2 No. 950.95. To maintain this compliance, all access covers must be replaced after
servicing the equipment to prevent fires from spreading to nearby equipment.

Ordering Infor m ation

Part Numb er Item Description

930-0201 AN/GR-303/R/32 Access Navigator GR-303 + Data Host,

930-0200 AN-Case Access Navigator redundant NEBS chassis and

740-0017 AN-GR-303

Controller Card

740-0018 Quad T1 Framer Card Access Navigator Quad T1 Framer card

32 T1 Redundant Package:
2 AN-GR-303 Controller Cards
8 AN-Quad T1 Framer Cards

backplane. Chassis holds two Controller cards
and eight Quad T1 Framer cards (32 T1 circuits).
Order cards separately.

Access Navigator Controller card with GR-303
and DCS software.

terminates 4 T1 interfaces from switch, customer
site, or data network.

005-0025 DSX-1 Cable 64-pin DSX-1 cable, 10 feet long, male/male.

Two cables must be ordered per Access
Navigator, one TX, one RX. May be used for

DS1 and DSX-1 transmission levels.
005-0030 DSX-1 Cable 64-pin DSX-1 cable, 25 feet long (see 005-0025).
710-0153 19”/23” Universal

Mounting Brackets

710-0003 19” Vertical Mount

Crossbars

710-0004 23” Vertical Mount

Crossbars

770-0079 AN-Manual Access Navigator User Manual is included with

Universal mounting brackets and screws for 19

and 23 inch equipment racks. This bracket set is

included with all Access Navigator unit

purchases.

Two heavy-duty 19 inch horizontal crossbars

mount in equipment rack and enable vertical

installation of up to 6 Acce ss Navigat or and Wide

Bank 28 products.

Two heavy-duty 23 inch horizontal crossbars

mount in equipment rack and enable vertical

installation of up to 6 Acce ss Navigat or and Wide

Bank 28 products.

all Access Navigator unit purchases.

3-16 August 2003 Access Navigator - Release 1.8

CHAPTER

Access Navigator / GR-303 Host with

P-Phone

In this Chapter

n Overview ... 4-2
n System Architecture ... 4-3
n Features and Benefits ... 4-4
n GR-303 Services ... 4-4
n P-Phone Services ... 4-6
n DCS Services ... 4-7
n Management Architecture ... 4-8
n Configuration ... 4-10
n Applications ... 4-11
n Interfaces ... 4-11
n Specifications ... 4-12
n Compliance Requirements ... 4-15
n Ordering Information ... 4-17

Access Navigator / GR-303 Host with P-Phone

Overview

Overview

The Access Navigator® / GR-303 Host with P-Phone offers a highly integrated solution for combining
multi-line local voice and data serv ices on customer T1 acce ss lines. Using the Telcordia® stand ard GR-303
switching protoco l, up to 672 c ustomer telephone channels can be assigned on a cal l- by- ca ll basis to Class
5 local digital s witch T1 connection s. When connected to a Nortel DMS switch pr oviding Nortel Prop rietary
Phone (P-Phone) Centrex service, the Access Navigator can support up to 384 P-Phone channels from up
to 14 remote Adit 600s. In addition to the concentration and management of CLASS® voice services, the
Access Navigator grooms, and optionally concentrates, fractional T1 data connections from customer
locations.

.

Figure 4-1 Access Navigator / GR-303 Host with P-Phone

4-2 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 Host with P-Phone

System Architecture

System Architecture

Voice Switc h

(GR-303)

Public Network

DCS Voi c e

and Data

Internet, Data,

Private and

Special Services

Data Network

Voice

Remote

Management

Switch

DS1s

Groom

DS1s

Access

Navigator

RS-232Ethernet

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal

Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor
Output

Voice

Monitor

T1

-48Vdc
Return
Ground

Tip & Ring

Access Bank I

ACCESS BANK II

and

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc
Return
Ground

Tip & Ring

V . 35, T1

Voice

Data

Access Bank II

Voice

and

Data

24

PBX

Lines

Voice
Lines

or DSL

Router

P-Phone

FXS/FXO

PBX

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

P-Phones

(EBS)

Key System

Fax

ADIT 600

VoIP
T1 Drop

PBX

Stations

Adit 600

10/100BaseT

RS232

Modem

DDS
ISDN BRI

Switch Center

Co-location

T1 Drop
V.35

Customer Premises

Router

Ethernet

Figure 4-2. Access Navigator / GR-303 with P-Phone Architecture

Access Navigator - Release 1.8 August 2003 4-3

Access Navigator / GR-303 Host with P-Phone

Features and Benefits

Features and Benefits

The Access Navigator / GR-303 with P-Phone is a transport element that combines the functions of a
GR-303 digital terminal, 32-port T1 digital crossconnect system, T1 channel/data service unit (CSU), T1
diagnostic test equip me nt, and Access Bank® II host contro ller into a modular chassis 1½ rac k unit s hi gh.
Ethernet SNMP, optional redundancy, and modular T1 expansion provide carrier-class service protection
and management at either carrier or customer located T1 service access points.

Access Navigator / GR-303 Host with P-Phone offers an integration of:

l 32 T1 port GR-303 remote digital terminal
l GR-303 to TR-08 translation for CA’s Access Bank® I/TR-08
l GR-303 Direct Inward Dial (DID) support when used with Lucent 5ESS switches
l P-Phone (EBS) support with GR-303 voice concent rati on when used wi th Nortel DMS swit ches and

remote Adit 600 terminals equipped with P-Phone service cards

l Digital crossconnect system
l T1 CSUs and demarcation testing
l Ethernet Telnet and SNMP management
l Optional Controller redundancy
l Modular Quad T1 expansion
l NEBS Certified

GR-303 Services

The Access Navigator / GR-303 Host with P-Phone pr ovides T1 local voic e, P-Phone, an d data serv ic es to
multiple customers (Figure 4-3). Using GR-303 switching protocol for call concentration, the Access
Navigator reduces recurring backhaul transmission costs and switch port costs by up to a factor of 4.

By using CA's Access Bank® II and Adit 600 products at the customer premise, an end-to-end distributed
voice and data digita l loop carrier and remote management system is provided. Standard T1 connections
from customer PBXs and key systems may be concentrated or bypassed from the GR-303 groups.

The power of a 32 T1 port voice and data switch/concentrator and remote service management system is
contained in only 1½ rack units of space. Integrated testing and optional common equipment redundancy
assure carrier-class service availability.

CA's Access Navigator / GR-303 Host with P-Ph one, together with the Access Bank II and Adi t 600, bring
cost-effective concentration and remote management to competitive local carriers with a new level of
serviceability and space efficiency.

4-4 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 Host with P-Phone

GR-303 Services

24

PBX

PBX

Router

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

P-Phones

(EBS)

Key System

Fax

Switch

GR-303

Voice &

ISDN BRI

Data

GR-303

Interface

Group

Remote

Management

Ethernet

Telnet &

SNMP

Switch

DS1s

Access

Navigator

RS-232

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal
Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor
Output

Voice

Monitor

T1

-48Vdc
Return
Ground

Tip & Ring

Access Bank I

ACCESS BANK I I

and

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc
Return
Ground

Tip & Ring

V .35, T1

Voice

Data

Access Bank II

Voice

P-Phone

and

Data

FXS/FXO

Lines

Voice

Lines

or DSL

Integrated Digital

T erminal (IDT)

Figure 4-3. Access Navigator / GR-303 Host with P-Phone Architecture

Remote Digital
Terminal (RDT)

VoIP

ADIT 600

T1 Drop

Adit 600

10/100BaseT

RS232

DDS
ISDN BRI
T1 Drop
V.35

Customer Premises

PBX

Modem

Router

Stations

Ethernet

Access Navigator - Release 1.8 August 2003 4-5

Access Navigator / GR-303 Host with P-Phone

P-Phone Services

P-Phone Services

The Access Navigator / GR-303 Host with P-Phone includes Nortel Proprietary Phone (P-Phone) Centrex
service support using remote Adit 600 terminals with P-Phone service cards. The cards convert the
customer’s analog P-Phone si gnals to mor e efficie nt digit al loo p carrie rs. These d igital signals t hat are then
transmitted over DS0s on the Access Navigator’s drop DS1.

Command and signaling information for all P-Phones is carried by message packets sent over the IP DS0
management channel between the Access Navigator and remote Adit 600, then over the GR-303 EOC
channel between the Access Navigator and the Nortel DMS switch. The Access Navigator can support up
to 384 P-Phone channels origi nating from up to 14 remote Adit 60 0s. For a detailed descripti on of supported
P-Phone features, see the Adit 600 User Manual.

Figure 4-4 P-Phone Service Support Using Adit 600 Terminals

4-6 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 Host with P-Phone

DCS Services

DCS Services

The Access Navigator provides all the grooming and filling functions of a 1/0 digital crossconnect system
(DCS) to maximize T1 usage. With carrier/customer demarcation testing, carriers are able to decrease
maintenance costs and labor, while increasing service availabil it y. Fr act i onal voi ce and data services from
multiple customers and applications are combined by the Access Navigator to save recurring backhaul
transmission costs, and capital costs on switch or router ports.

24

PBX

PBX

Router

PBX

Stations

Key System

Fax

Modem

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

Voice Switch

Voice

Public Network

DCS Voi c e

and Data

Internet, Data,

Private and

Spec ial Services

Data Netwo rk

Remote

Management

Ethernet

Telnet &

SNMP

Groom

T1s

Access

Navigator

RS-232

Drop

DS1s

ACCESS BANK I

Self
Test

Normal

Normal
Network
Loopback

Normal

Remote

Normal
Alarm
Cut-Off

Test

Status

T1

Framing

Input
Monitor
Output

Voice

Monitor

T1

-48Vdc
Return
Ground

Tip & Ring

Access Bank I

ACCESS BANK II

and

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232
Data

-48Vdc
Return
Ground

Tip & Ring

V.35, T1

Voice

Data

Access Bank II

Voice

and

Data

Lines

Voice
Lines

or DSL

FXS/FXO
VoIP

T1 Drop

ADIT 600

10/100BaseT

Adit 600

RS232

Modem

DDS
ISDN BRI

Switch Cen ter

Co-location

T1 Drop
V.35

Customer Premises

Router

Ethernet

Figure 4-5. Access Navigator Data Host Architecture

Access Navigator - Release 1.8 August 2003 4-7

Access Navigator / GR-303 Host with P-Phone

Management Architecture

Management Architecture

Access Navigators pr ovide manag ement acce ss via Et hernet SNMP, Teln et CLI, and RS- 232 CLI. Valet™
and NetworkValet™ EMS software provides a graphical user interface (GUI) for SNMP management.
Flow-through provisioning of the remote Access Bank II and testing control over T1 connections reduce
truck rolls and monitors voice and data service availability at customer locations.

IP DS0 Management

The Access Navigator can use IP management commands and dedicated DS0s to manage up to 24
remote Adit 600 terminals. (Up to 14 of the remote Adit 600s may have P-Phone cards.) IP DS0
management uses a coloc ated Adit 600 termin al with an IP Router c ard to redirect IP mes sages between
the Access Navigator’s IP port and the 24 DS0s on a groom DS1. The Access Navigator then cross­connects the groom DS0s to a dedicated dr op DS0 goi ng to each remote Adit 600. Customers wishing
to conserve IP addre sse s ca n use an Ethernet hub or router providing port addresses translation (NAT)
to isolate the IP DS0 management network.

Network

Operations

Center

IP = X.X.X.1

Management

Console

Figure 4-6. Access Navigator IP DS0 Management Architecture

On-Net

Location

Ethernet

Hub

Navigator

POWER

ACO

CRIT

MAJOR

(PUSH)

ACO

MINOR

CONTROLL ER A

ACTIVE

123456789101112131415161718192021222324252627

DS1 STATUS

Static DS0 Management

Connnections between
Groom and Drop DS1s

Adit 600

(colocated) (remote)

IP

Router

Access

POWER

ACO

ACCESS

CRIT

MAJOR

(PUSH)

NAVIGATOR

ACO

ACTIVE

293031

MINOR

CARRIER ACCESS

CONTROLLER B

CORPORATION

DS1 25

Adit 600

DS0 1

Groom
DS1

Drop DS1s

32

28

l
l
l

Customer

Premises

Adit 600

DS1 1
DS0 24

IPDS0 = X.X.X.1

Up to 24

Remote Adits

Adit 600

(remote)

DS1 24
DS0 24

IPDS0 = X.X.X.24

Adit 6 00

l
l
l

Adit 6 00

4-8 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 Host with P-Phone

FDL Management

FDL Management

When T1 Type I lines are available, the Access Naviga tor can use th e ESF Faciltiy Data Link to manage
remote Access Bank II a nd Adit 600 terminals . (FDL can no t be used to manage re mote Adit 6 00s with
P-Phone cards.)

Network

Operations

Center

CLI/Telnet

Access

Navigator

Element

Manager

SNMP

TCP/IP

Network

Voice

Switch

Data

Switch

On-Net

Location

Access

Navigator

Local

Management

CLI/RS-232

Customer

Wiring Closet

ACCESS BANK II

T1

Span 1

T1

Span 2

T1 Test 1

T1 Test 2

V.35
DCE

V.35
Status

RS232

FDL

T1

Adit 600

Data

-48Vdc
Return
Ground

Tip & Ring

Access

Bank II

ADIT 600

Voice
Lines

PBX

V.35, T1

or DSL

Router

FXS/FXO

VoIP

PBX

T1 Drop

10/100BaseT

RS232

Modem

DDS
ISDN BRI
T1 Drop
V.35

Router

Customer

Premises

Stations

Key System

Fax

Ethernet

Key System

Fax
Stations

Ethernet

Figure 4-7. Access Navigator FDL Management Architecture

Access Navigator - Release 1.8 August 2003 4-9

Access Navigator / GR-303 Host with P-Phone

Configuration

Configuration

The Access Navigator / GR-303 Host wit h P-Phone combines call processi ng and concentration capabi lities
of a GR-303 digital l oop carrier (DLC) system with the functiona lity of a min iature 1/0 digital cr ossconnect
switch (DCS). Providing up to 32 DS1 ports (768 DS0s) in one small package, the Access Navigator fits
easily into small collocation spaces and phone closets.

l Hardware configuration: Modular construction with plug-in cards includes built-in circuit and

network testing and fuse-less protection (see Figure 4)

l Software confi gurat ion: Ope rating s yst em is stor ed in upgrade able f lash memory. Configu ratio n and

provisioning data are stored in nonvolatile RAM, protected from power interruptions.

Technology Advantages

• Low Cost

• Small Size

• Low Po wer

• Surge Protection

• Test Integratino

• Fault Isolation

• No Fans

Quad T1 Framer Card Features

• Four T1 circuits per card

• Up to 8 cards (32 T1s)

•1/0 cross-connections

•Groom and fill T1s

• Fuseless hi gh- voltage
protection

•Built-in T1 CSU

• Hot swappable

Front

Controller

Card

Controller

Card

Controller Card Features

•Power and control
circuit redundancy

•GR-303 call support

•Ethernet Telnet and SNMP
remote management

•Built-in circuit and network
testing

Lightning

Hazards

Power Line

Hazards

Rear

RS232

Management

Figure 4-8. Access Navigator Hardware Configuration

4-10 August 2003 Access Navigator - Release 1.8

Ethernet

Management

Redundant

Power Input

T1 Interface

Cables

Access Navigator / GR-303 Host with P-Phone

Applications

Applications

l T1 Service POP-In-A-Box: Customer-located T1 access management for carriers
l Call Concentration: Variable concentration of voice and P-Phone calls for more efficient use of

backhaul T1s and switch resources

l End-Office T1 Grooming: T1 access consolidation, provisioning, protection, and service

management

l Host Control of Access Bank II: Flow-through remote management and bandwidth grooming of

Access Bank IIs

Interfaces

l DS1 Interfa ce: Two Champ® 64-pin connector s with 32 DS1 circuits, one for recei ve (input) and one

for transmit (output)

l RJ45C Interface: Timing input connector for external clock source (such as BITS)
l RS-232 Interface: DB9 (DE9) connector for CLI management by craft terminal or computer with

terminal emulation sof tware

l Ethernet Interface: 10Base-T connector for SNMP and Telnet CLI management

Access Navigator - Release 1.8 August 2003 4-11

Access Navigator / GR-303 Host with P-Phone

Specifications

Specifications

GR-303 Operation

l Up to 32 T1s per system
l Primary and redundant protection for EOC and TMC
l GR-303 to TR-08 translation for CA’s Access Bank I/TR-08
l GR-303 Direct Inward Dial (DID) support for Lucent 5ESS switches
l GR-303 line concentration of 4:1 TDM ISDN BRI services
l GR-303 line concentration of Nortel P-Phone (EBS) services from CA’s Adit 600 terminals

(up to 384 P-Phone channels from up to 14 remote Adit 600 terminals)

l Alarm and maintenance support for DS1 terminations
l Compatible with Lucent, Nortel, and Siemens switches
l Configurable concentration ratios
l Programmable call reference values (CRVs)
l Redundancy, 1:1 controller & power conversion

Crossconnects

l DCS 1/0 interface supports crossconnects at DS0 level
l Crossconnects up to 24 contiguous DS0s between T1s with one command

DS1 Interface

l Four T1s per line card, hot swappable
l Line rate: 1.544 Mb/s ± 32ppm
l Line code: B8ZS or AMI
l Framing: D4 (SF) or ESF
l DS1 receive sensitivity: –28dB to +1.5dB
l Line build-outs:

DSX-1 (0 to 660 ft. in 5 steps)
CSU (0 dB, –7.5 dB, –15 dB, –22.5dB)

l ANSI T1.403, Section 6 & 7 (jitter, pulse mask transmission, receive sensitivity, framing

formats)

l Built-in CSU with loopback and BERT for testing the T1s

System Clocking

l Primary and secondary sources from: DS1s, external clock source (suc h as BITS) or internal

clock (minimum Stratum 4)

l Automatic clock switching and holdover

4-12 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 Host with P-Phone

GR-303 Signaling

GR-303 Signaling

l GR-303 ABCD robbed-bit signal codes
l GR-303 Direct Inward Dial (DID) signaling for Lucent switches
l GR-303 4:1 TDM mode support for ISDN BRI
l GR-303 P-Phone (EBS) signaling for Nortel switches
l FXS loop start and ground start

DCS Signaling

l Robbed-bit and clear channel connections at DS0 level
l FXS/FXO loop start and ground start
l E&M robbed bit signaling

Management Interfaces

l Command line interface (CLI) for provisioning and maintenance
l RS-232 interface for local CLI
l Ethernet Telnet support for remote CLI
l Ethernet SNMP uses Telcordia® standard MIB for DS1 interfaces (RFC-1406)
l TFTP and Xmodem support for flash memory software upgrades

Protocols

l Command Line Interface (CLI)
l Simple Network Management Protocol (SNMP)
l Telcordia® GR-303
l Nortel NIS V202-1, Issue 01 (P-Phone)
l Telnet
l TFTP and Xmodem support for flash memory software upgrades

Alarms

l Critical, Major, and Minor alarm levels
l DS1 alarms for LOS, LOF, AIS, and RAI
l Front panel LED indicators
l Output signal: relay contact closure and LED indication

Maximum relay contact rating: 110V AC or DC @ 1A

l Alarm inputs from dry contact closures

Maximum input rating: 60V DC

Access Navigator - Release 1.8 August 2003 4-13

Access Navigator / GR-303 Host with P-Phone

Compliance

Compliance

USA

l UL 1950, 3rd Edition
l FCC Part 15, Clas s A
l FCC Part 68
l NEBS Level 3 for Type 2 and 4 equipment

GR-1089-CORE
GR-63-CORE

CANADA

l CSA C22.2 No. 950.95
l ICES-003, Class A
l CS-03

Standards

l AT&T 62411 (Stratum 4 enhanced T1 CPE)
l ANSI T1.403 and T1.107a

Power

l Input power: –42 to –60 VDC @ 1.5A
l Dual feed DC power input terminals
l Power dissipation: 65 watts (225 Btu/hr.), fully equipped
l Solid-state (fuse-less) over-voltage and over-current protection

Environmental

l Operating temperature: –5°C to +45°C (23°F to 113°F), up to +55°C short term (NEBS)
l Solid-state over-temperature protection
l Relative humidity: 0 to 95%, non-condensing
l No fans; Passive therma l management

Physical

l Dimensions: 17" x 13.5" x 2.63"
l Weight: 10 lbs. (4.54 kg)
l Mounts in 19 and 23 inch racks
l Optional wall mount brackets

4-14 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 Host with P-Phone

Compliance Requirements

Compliance Requirements

FCC Requirements

This equipment complies with Pa rt 15 and Par t 68 of the F ederal Communi cati ons Commiss ion (FCC)
Rules.

Part 15, Class A

This equipment has bee n t es te d and found to comply with the limits for a Class A digital device in
accordance with Part 15 of the FCC Rules. These limits provide reasonable protection against
harmful interference when equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions in this manual may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which ca se the user will be required to correct the interference at the user’s own
expense.

The following cables, when conne cted to this equipment , must be shielded to maint ain FCC Part 15
compliance:

l Both DSX-1 cables
l RS-232 cable

Part 68

This equipment complies with Part 68 of the Federal Communications Commission rules. The
silkscreen on the top cover of this equipment includes the FCC registration number.

You must supply the following information to the telephone company, if they request it.

l FCC Registration Number: 2Z6USA-33482-DD-N
l Service Center in the USA:

Carrier Access Corporation
5395 Pearl Parkway
Boulder CO 80301-2490
Phone [phone]

If this equipment has been found to cause harm to the telephone network, the telephone company
will notify you in advance. If advance n otice prove s impractica l, the tel ephone company wi ll notify
the customer as soon as possib le. Also, you will be advised of your ri ght to file a complaint with the
FCC if you believe such action is necessary.

If the trouble is causing harm to the telephone network, the telephone company may request that
you remove the equipment from the network until the problem is resolved.

The telephone company may make changes in its facilities, equipment, operations or procedures
that could affect the operation of your equipment. If this happens, the telephone company will

Access Navigator - Release 1.8 August 2003 4-15

Access Navigator / GR-303 Host with P-Phone

Telcordia (Bellcore) Requirements

provide advance n otice i n order f or you t o make nece ssary modi ficati ons to mai ntain uni nterrup ted
service.

If you need to make repairs or modifications to the equipment, please first contact Carrier Access
Corporation for repair, modification, and warranty information. Customer repairs and
modifications are limited to the replacement of circuit boards; any other repairs or modifications
will void your warranty.

Facility Interface Codes (FIC)

FIC CODES DESCRIPTION

04DU9-BN 1.544 Mbps Superframe Format (SF) without Line Power
04DU9-DN 1.544 Mbps Superframe (SF) and B8ZS without Line Power
04DU9-1KN 1.544 Mbps ANSI, ESF without Line Power
04DU9-1SN 1.544 Mbps ANSI, ESF, and B8ZS without Line Power

Service Order Codes (SOC)

SOC CODES DESCRIPTION

6.0F Combinations of equipment provide full protection to digital
services. Billing protection and encoded analog protection are
provided either by including auxiliary equipment within the
registration envelope or by use of a separately registered device.

Telcordia (Bellcore) Requirements

This equipment conforms with Telcordia® standard GR-1089-CORE, New Equipment Building
System (NEBS), requirements for intra-building (inside plant) Type 2 and Type 4.

To maintain compli ance wi th t he GR-10 89-CORE requi rements to pre vent E MI/EMC radi o fr equency
interference with other equipment, the DSX-1 and RS-232 cables mus t be shielded and ha ve ferrite bead
RFI suppressors.

UL Requirements

This equipment conforms with Underwriters Laboratory standard UL 1950 (s upersedes UL 1459). To
maintain this compliance, all access covers must be replaced after servicing the equipment to prevent
fires from spreading to nearby equipment.

4-16 August 2003 Access Navigator - Release 1.8

Access Navigator / GR-303 Host with P-Phone

CSA Requirements

CSA Requirements

This telecommunication network equipment conforms with Canadian Standards Association (CSA)
standard C22.2 No. 950.95. To maintain this compliance, all access covers must be replaced after
servicing the equipment to prevent fires from spreading to nearby equipment.

Ordering Infor m ation

Part Numb er Item Description

930-1026 AN/GR-303 P-Phone Access Navigator GR-303 Host with P-Phone,

32 T1 Redundant Package:
2 AN-GR-303 Controller Cards
8 AN-Quad T1 Framer Cards

930-0200 AN-Case Access Navigator redundant NEBS chassis and

backplane. Chassis holds two Controller cards
and eight Quad T1 Framer cards (32 T1 circuits).
Order cards separately.

740-0216 AN-GR-303 P-Phone

Controller Card

740-0018 Quad T1 Framer Card Access Navigator Quad T1 Framer card

Access Navigator Controller card with GR-303,
P-Phone, and DCS software.

terminates 4 T1 interfaces from switch, customer
site, or data network.

005-0025 DSX-1 Cable 64-pin DSX-1 cable, 10 feet long, male/male.

Two cables must be ordered per Access
Navigator, one TX, one RX. May be used for

DS1 and DSX-1 transmission levels.
005-0030 DSX-1 Cable 64-pin DSX-1 cable, 25 feet long (see 005-0025).
710-0153 19”/23” Universal

Mounting Brackets

710-0003 19” Vertical Mount

Crossbars

710-0004 23” Vertical Mount

Crossbars

770-0079 AN-Manual Access Navigator User Manual is included with

Universal mounting brackets and screws for 19

and 23 inch equipment racks. This bracket set is

included with all Access Navigator unit

purchases.

Two heavy-duty 19 inch horizontal crossbars

mount in equipment rack and enable vertical

installation of u p to 6 Access Navi gator an d Wide

Bank 28 products.

Two heavy-duty 23 inch horizontal crossbars

mount in equipment rack and enable vertical

installation of u p to 6 Access Navi gator an d Wide

Bank 28 products.

all Access Navigator unit purchases.

Access Navigator - Release 1.8 August 2003 4-17

Access Navigator / GR-303 Host with P-Phone

Ordering Information

4-18 August 2003 Access Navigator - Release 1.8

CHAPTER

Physical Installation

In this Chapter

n Compliance and Safety Requirements ... 5-2
n Tools and Materials ... 5-3
n Unpacking and Inspection ... 5-3
n Horizontal 19-Inch Rack Mount ... 5-4
n Horizontal 23-Inch Rack Mount ... 5-7
n Vertical Rack Mount Using Crossbars ... 5-11
n Vertical Wall Mount ... 5-15

Physical Installation

Compliance and Safety Requirements

Compliance and Safety Requirements

DANGER! FIRE HAZARD. STANDARDS UL 1950 AND C22.2 NO. 950.95 REQUIRE

THAT ALL ACCESS COVERS BE REPLACED TO PREVENT FIRES FROM SPREADING TO
NEARBY EQUIPMENT.

CAUTION! NEBS 1089 EMI/EMC AND FCC REQUIREMENT PART 15 COMPLI-

ANCE REQUIRES CHASSIS GROUNDING, SHIELDED DSX-1 AND RS-232 CABLES WITH
FERRITE RF SUPPRESSOR BEADS, AND SHIELDED ETHERNET AND BITS CLOCK
CABLES TO PREVENT RADIO FREQUENCY INTERFERENCE WITH OTHER EQUIPMENT.

WARNING! NEBS REQUIREMENT. DO NOT CONNECT THIS EQUIPMENT DIRECTLY

TO METALLIC TIP-AND-RING OUTSIDE PLANT CONDUCTORS. THIS EQUIPMENT CAN ONLY
BE USED FOR INTRA-BUILDING (INSIDE PLANT) INSTALLATION IN A CENTRAL OFFICE OR
CUSTOMER PREMISES.

WARNING! THE ACCESS NAVIGATOR CONTAINS CIRCUIT CARDS AND COMPO-

NENTS THAT ARE SUBJECT TO DAMAGE BY ELECTROSTATIC DISCHARGE (ESD).

A

LWAYS FOLLOW THE STATIC-SENSITIVE EQUIPMENT HANDLING PROCEDURES ON

page 6-3 WHEN OPENING EQUIPMENT COVERS AND HANDLING PLUG-IN CIRCUIT CARDS.

5-2 August 2003 Access Navigator - Release 1.8

Physical Installation

Tools and Materials

Tools and Materials

Physical installation requires the following tools and materials.

• Screwdrivers, Phillips #2 and #3

• Screwdr ivers, slotted

• Screws (4 ea.), 12-24 × 1/2 inch (for 23 inch rack only)

• Screws (8 ea.), #8 × 3/4 inch panhead (for wall mount only)

• Universal rack mounting kit, PN 710-0153 (one additional kit required for wall mount only)

• Plywood and fasteners (for wall mount only, see Vertical Wall Mount on page 5-15)

NOTE: ABAM shielded cable is recommended for extending DSX-1 connections.

Unpacking and Ins pection

1. Inspect containers for damage during shipment. Report any damage to the freight carrier for
possible insurance claims.

NOTE: Check packing list (taped to outside of container) before openi ng container.

Packing list should agree with label on outs ide of Access Navigator shipping container.
Packing lists show only top level part numbers.

2. Compare packing list with office records. Report any discrepancies to the office.

3. Open shipping containers. Be careful not to damage contents.

WARNING! DO NOT OPEN EQUIPMENT COVERS OR ANTI-STATIC PLASTIC BAGS

UNTIL READY FOR INSTALLATION. ALWAYS FOLLOW THE STATIC-SENSITIVE EQUIPMENT

HANDLING PROCEDURES ON page 6-3 WHEN OPENING EQUIPMENT COVERS AND

HANDLING PLUG-IN CIRCUIT CARDS.

4. Inspect contents of shipping containers for any damage that may have occurred during shipment.
Report any damage to the freight carrier for possible insurance claims.

5. If equipment must be returned to for any reason, carefully repack equipment in original shipping
container with ori ginal pac king mate rials if pos sible . See Warranty a nd Warrant y Product Ret urns
in the Preface of this manual.

6. If equipment is to be installed later, replace equipment in original shipping containers and store
temporarily in a safe place until ready to install equipment.

Access Navigator - Release 1.8 August 2003 5-3

Physical Installation

Horizontal 19-Inch Rack Mount

Horizontal 19-Inch Rack Mount

Installation Summary

n Precautions ... 5-4
n Tools and Materials ... 5-4
n Attach Mounting Brackets to Access Navigator ... 5-5
n Attach Access Navigator to Equipment Rack ... 5-5

Precautions

CAUTION! ACCESS NAVIGATOR REQUIRES AT LEAST 4.37 INCHES (2.5 RACK

UNITS) OF FREE AIR SPACE ABOVE AND BELOW CHASSIS FOR AIR CIRCULATION.

I

NSUFFICIENT SPACING MAY CAUSE SERVICE INTERRUPTIONS, RESULTING FROM

EQUIPMENT OVERHEATING AND SHUTTING DOWN.

Tools and Materials

Obtain the fo llowing tools and material s:

• Screwdrivers, Phillips #2 and #3

• Screwdr ivers, slotted

• Universal rack mounting bracket kit, PN 710-0153, included with Access Navigator

• Rack mounting screws (4 ea.), as appropriate for equipment rack

NOTE: Rack mounting brackets come with hardware for install ation in both 19-inch and

23-inch equipment racks. Some hardware is not required for 19-inch rack installation.

5-4 August 2003 Access Navigator - Release 1.8

Physical Installation

Attach Mounting Brackets to Access Navigator

Attach Mounting Brackets to Access Navigator

1. Open bag containing universal rack mounting kit and select the following items (see Figure 5-1):

• Mounting bracket (2 ea.), PN 0040303 (stamped on part)

Mounting

Brackets

Figure 5-1. Mounting Brackets

2. Position mounting brac ket s for required flush mount or 5-inch forward offset with respect to front
rails of equipment rack (see A in Figure 5-2 on page 5-6).

3. Remove mounting screws (6-32 × 3/8 inch, 82º undercu t, Phillips) fr om sides of Access Navigator
where brac kets will be attached.

4. Attach mounting bracket s to sides of Access Navi gator using mounting scre ws removed in previous
step (see B in Figure 5-2).

Attach Access Navigator to Equipment Rack

CAUTION! ACCESS NAVIGATOR REQUIRES AT LEAST 4.37 INCHES (2.5 RACK

UNITS) OF FREE AIR SPACE ABOVE AND BELOW CHASSIS FOR AIR CIRCULATION.

I

NSUFFICIENT SPACING MAY CAUSE SERVICE INTERRUPTIONS, RESULTING FROM

EQUIPMENT OVERHEATING AND SHUTTING DOWN.

1. Position Access Navigator in equipment rack slot (refer to office records). Ensure that there is at
least 4.37 inches (2.5 rack units) of free air space above and below chassis for cooling (see Figure
5-3 on page 5-6).

2. Secure mounting brackets to equipment rack using appropriate mounting screws (see C in Figure
5-2). Brackets accommodate 1.75 and 2.00 inch hole spacing.

Access Navigator - Release 1.8 August 2003 5-5

Physical Installation

Attach Access Navigator to Equipment Rack

Mounting

Bracket

Mounting

Bracket

Mount bracket here

for flush mount.

Mount bracket here for

5 inch forward offset.

C

Fasten brackets to

equipment rack

with appropriate

mounting screws

(two per side).

A

Fasten brackets to

B

Access Navigator

with 6-32 x 3/8"

underc ut s crews

(four per side).

Figure 5-2. Installation in 19-inch Equipment Rack

4.37 inches
(minimum)

Figure 5-3. Spacing Require ments

5-6 August 2003 Access Navigator - Release 1.8

7.00 inches
(minimum)

Physical Installation

Horizontal 23-Inch Rack Mount

Horizontal 23-Inch Rack Mount

Installation Summary

n Precautions ... 5-7
n Tools and Materials ... 5-7
n Attach Mounting Brackets to Access Navigator ... 5-8
n Attach Access Navigator to Equipment Rack ... 5-9

Precautions

CAUTION! ACCESS NAVIGATOR REQUIRES AT LEAST 4.37 INCHES (2.5 RACK

UNITS) OF FREE AIR SPACE ABOVE AND BELOW CHASSIS FOR AIR CIRCULATION.

I

NSUFFICIENT SPACING MAY CAUSE SERVICE INTERRUPTIONS, RESULTING FROM

EQUIPMENT OVERHEATING AND SHUTTING DOWN.

Tools and Materials

Obtain the fo llowing tools and material s:

• Phillips screw drivers, #2 and #3

• Universal rack mounting bracket kit, PN 710-0153, included with Access Navigator

• Rack mounting screws (4 ea.), as appropriate for equipment rack

NOTE: Rack mounting brackets come with hardware for in stallation in both 19-inch and

23-inch equipment racks. Some hardware is not required for 19-inch rack installation.

Access Navigator - Release 1.8 August 2003 5-7

Physical Installation

Attach Mounting Brackets to Access Navigator

Attach Mounting Brackets to Access Navigator

1. Open bag containing universal r ack mounti ng kit. It should co ntain th e followi ng items ( see Figure
5-4):

• Mounting bracket (2 ea.), PN 0040303 (stamped on part)

• Bracket extender (2 ea.), PN 0040310 (stamped on part)

• Mounting screw (4 ea.), 12-24 × 5/8 inch

Bracket

Extender

Mounting

Bracket

Mounting

Bracket

Fasten brackets to extensions
with four 12-24 x 5/ 8" machine

screws (two pe r bracket)

Figure 5-4. Assemble Mounting Brackets

2. Assemble mounting brackets for 23-inch racks (see Figure 5-4).

• Attach each mounting bracket to a bracket extender with two 12-24 × 5/8 inch screws.

3. Position mounting brac ket s for required flush mount or 5-inch forward offset with respect to front
rails of equipment rack (see A in Figure 5-5).

4. Remove four mounting screws (6-32 × 3/8 inch, 82º undercut, Phillips) from each side of Access
Navigator where brackets will be attached.

5. Attach mounting bracke ts t o each side of Access Navigat or us ing t he mounti ng scr ews re moved in
previous step (see B in Figure 5-5).

Bracket

Extender

5-8 August 2003 Access Navigator - Release 1.8

Physical Installation

Attach Access Navigator to Equipment Rack

Attach Access Navigator to Equipment Rack

CAUTION! ACCESS NAVIGATOR REQUIRES AT LEAST 4.37 INCHES (2.5 RACK

UNITS) OF FREE AIR SPACE ABOVE AND BELOW CHASSIS FOR AIR CIRCULATION.

NSUFFICIENT SPACING MAY CAUSE SERVICE INTERRUPTIONS, RESULTING FROM

I

EQUIPMENT OVERHEATING AND SHUTTING DOWN.

Mount brackets here

for flush mount.

Mount brackets here for

5 inch forward offset.

A

Fasten brackets to

B

Access Navigator

with 6-32 x 3/8"

undercut screws

(four per side)

Fasten brackets to

equipment rack

with appropriate

mounting screws

(two per side).

Figure 5-5. Installation in 23-inch Equipment Rack

Access Navigator - Release 1.8 August 2003 5-9

C

Physical Installation

Attach Access Navigator to Equipment Rack

1. Access Navigator requires at least 4.37 inches (2.5 rack units) of free air space above and below
chassis for air circulation. Insufficient spacing may cause service interruptions, resulting from
equipment overheating and shutting down.

2. Position Access Navigator in equipment rack slot (refer to office records). Ensure that there is at
least 4.37 inches (2.5 rack units) of free air space above and below chassis for cooling (see Figure
5-6 on page 5-10).

3. Secure mounting brackets to equipment rack using appropriate mounting screws (see C in Figure
5-5). Brackets accommodate 1.75 and 2.00 inch hole spacing.

4.37 inches
(minimum)

Figure 5-6. Spacing Require ments

7.00 inches
(minimum)

5-10 August 2003 Access Navigator - Release 1.8

Physical Installation

Vertical Rack Mount Using Crossbars

Vertical Rack Mount Using Crossbars

Installation Summary

n Precautions ... 5-11
n Tools and Materials ... 5-11
n Install Crossbars ... 5-12
n Attach Mounting Brackets to Access Navigator ... 5-12
n Attach Access Navigator to Crossbars ... 5-12

Precautions

CAUTION! NEBS THERMAL RESTRICTION – DO NOT INSTALL MORE THAN THREE

ROWS OF ACCESS NAVIGATORS PER EQUIPMENT RACK.

CAUTION! ACCESS NAVIGATOR REQUIRES AT LEAST 0.75 INCH OF FREE AIR

SPACE ON LEFT AND RIGHT SIDE OF CHASSIS FOR AIR CIRCULATION. INSUFFICIENT
SPACING MAY CAUSE SERVICE INTERRUPTIONS, RESULTING FROM EQUIPMENT
OVERHEATING AND SHUTTING DOWN. IF INSTALLING MORE THAN ONE ROW OF UNITS,
ENSURE THAT UNITS ARE MOUNTED DIRECTLY ABOVE OR BELOW UNITS IN OTHER ROWS
TO MAINTAIN UNOBSTRUCTED VERTICAL AIR CIRCULATION.

Tools and Materials

Obtain the fo llowing tools and material s:

• Phillips screw drivers, #2 and #3

• Vertical Mount Crossbars (2 per kit), PN 710-0003 for 19-inch racks
or PN 710-0004 for 23-inch racks.

• Universal rack mounting kit, PN 710-0153, included with Access Navigator

• Rack mounting screws (4 ea.), as appropriate for equipment rack

NOTE: Crossbars are sold in pairs. Two 19-inch crossbars mount in 19-inch equipment

rack and hold up to five Access Navigator or Wide Bank 28 units. Two 23-inch crossbars
mount in 23-inch equipment rack and hold up to six units. One additional crossbar is
needed for each additional row of units.

Access Navigator - Release 1.8 August 2003 5-11

Physical Installation

Install Crossba rs

Install Crossbars

1. Position Vertical Mount Crossbars (refer to off ice records) so that inside mount ing holes are 18.375
inches apart (see A in Figure 5-7 on page 5-13).

2. Attach crossbars to equipment rack with appropriate mounting screws (see B in Figure 5-7).

Attach Mounting Brackets to Access Navigator

NOTE: Universal rack mounting bracket kit includes hardware that is not required for

installation using crossbars.

1. Open bag containin g the universal rack mounting kit and select the following ite ms (see A in Fig ure
5-8 on page 5-14):

• Mounting brackets (2 ea.), PN 0040303 (stamped on part)

• Mounting screws (4 ea.), 12-24 × 5/8inch, for at taching brackets to crossbars

2. Position mounting brac ket s for required flush mount or 5-inch forward offset with respect to front
rails of equipment rack (see B in Figure 5-8).

3. Remove four mounting screws (6-32 × 3/8 inch, 82º undercut, Phillips) from each side of Access
Navigator where brackets will be attached.

4. Attach mounting bracke ts t o each side of Access Navigat or us ing t he mounti ng scr ews re moved in
previous step (see C in Figure 5-8).

Attach Access Navigator to Crossbars

CAUTION! ACCESS NAVIGATOR REQUIRES AT LEAST 0.75 INCH OF FREE AIR

SPACE ON LEFT AND RIGHT SIDE OF CHASSIS FOR AIR CIRCULATION. INSUFFICIENT
SPACING MAY CAUSE SERVICE INTERRUPTIONS, RESULTING FROM EQUIPMENT
OVERHEATING AND SHUTTING DOWN. IF INSTALLING MORE THAN ONE ROW OF UNITS,
ENSURE THAT UNITS ARE MOUNTED DIRECTLY ABOVE OR BELOW UNITS IN OTHER ROWS
TO MAINTAIN UNOBSTRUCTED VERTICAL AIR CIRCULATION.

1. Position Access Navigator vertically in crossbar slot (refer to office records) with 1.75 inch
minimum bracket spacing (3 holes) between other brackets in row (see Figure 5-9 on page 5-14).

2. Secure mounting bracket s to c rossba r usin g 12-24 × 5/ 8in ch mounting s crews ( see D i n Figur e 5-8
on page 5-14).

5-12 August 2003 Access Navigator - Release 1.8

Physical Installation

Attach Access Navigator to Crossbars

1.75

B

Fasten Crossbars
to equipment rack

with appropriate

mounting screws

(two per side).

Figure 5-7. Crossbar Installation

Slotted hole

Key hole

A

Position inside

mounting holes

18.375 (18 3/8)
inches apart.

Access Navigator - Release 1.8 August 2003 5-13

Physical Installation

Attach Access Navigator to Crossbars

Mounting

Brackets

A

Fasten brackets to

crossbar with
12-24 x 5/8 inch
machine screws

(two per side).

Figure 5-8. Bracket Installation

Mount bracket here

for flush mount.

D

B

Mount bracket here for

5 inch forward offset.

Fasten brack e ts to

C

Access Navigator

with 6-32 x 3/8"

underc ut s c rews

(four per side).

19-inch Equipment Rack

(5 units per row maximum)

ABCDE ABCDEF

1.75 inch

Bracket spacing

Figure 5-9. Spacing Require ments

23-inch Equipment Rack

(6 units per row ma ximum)

0.75 inch

Minimum air space

1.75

17.25

5-14 August 2003 Access Navigator - Release 1.8

Physical Installation

Vertical Wall Mount

Vertical Wall Mount

NOTE: The following procedure assumes that the Access Navigator and oth e r compo-

nents will be mounted on a plywood sheet before attaching plywood to wall. Pre-mount ing
equipment at the carrier facility will speed up installation at the customer site .

Installation Summary

n Precautions ... 5-15
n Tools and Materials ... 5-16
n Ensure Adequate Clearance ... 5-16
n Prepare Plywood ... 5-16
n Attach Mounting Brackets to Access Navigator ... 5-16
n Attach Mounting Brackets to Access Navigator ... 5-16
n Attach Access Navigator to Plywood ... 5-17

Precautions

CAUTION! WALL MOUNTING IS APPROVED ONLY FOR CUSTOMER PREMISES.

CAUTION! ACCESS NAVIGATOR REQUIRES FREE AIR SPACE ON TOP, BOTTOM, AND

ENDS OF CHASSIS FOR AIR CIRCULATION. INSUFFICIENT VENTILATION MAY CAUSE
SERVICE INTERRUPTIONS, RESULTING FROM EQUIPMENT OVERHEATING AND SHUTTING
DOWN. DO NOT ALLOW CABLES AND OTHER COMPONENTS TO OBSTRUCT AIR
CIRCULATION. THE ACCESS NAVIGATOR INCLUDES TIE POINTS FOR ATTACHING WIRE
TIES TO SECURE CABLES TO REAR PANEL WITHOUT OBSTRUCTING AIR FLOW (SEE

FIGURE 5-11).

WARNING! IF ACCESS NAVIGATOR IS MOUNTED ON PLYWOOD, DO NOT USE A

HAMMER TO ATTACH PLYWOOD TO WALL BECAUSE THE IMPACT SHOCK MAY DAMAGE
THE ACCESS NAVIGATOR AND OTHER COMPONENTS MOUNTED ON THE PLYWOOD. A
POWER DRILL AND SCREWDRIVER IS RECOMMENDED TO AVOID DAMAGE.

Access Navigator - Release 1.8 August 2003 5-15

Physical Installation

Tools and Materials

Tools and Materials

Obtain the fo llowing tools and material s:

• Phillips screw drivers, #2 and #3

• Screws ( 8 ea.), #8 × 3/4 inch panhead

• Universal mounting kits (2 ea.), PN 710-0153.
(Access Navigator includ es one kit . )

• Plywood, 3/4 inch thick, 10 × 21 inches minimum size

Ensure Adequate Clearance

Ensure there is adequate clearance around Access Navigator to access cards and connectors, and
sufficient space for proper ventilation (see Figure 5-10 on page 5-18).

Prepare Plywood

1. Ensure that plywood is large enough to hold the Access Navi gator (see Figur e 5-11 on pag e 5-19 ).
Plywood should extend at least 1 inch beyond brackets.

2. Mark mounting hole locations on plywood to ensure that brackets will mount squarely against
plywood (see Figure 5-12 on page 5-20).

Attach Mounting Brackets to Access Navigator

NOTE: Universal mounting kit includes hardware that is not required for wall mount

installation.

1. Open bags containing the universal mounting kits and select the following items (see A in Figure
5-13 on page 5-21):

• Mounting brackets (4 ea.), PN 0040303 (stamped on part)

2. Position mounting brackets for wall mounting (s ee B in Figure 5-13).

3. Remove two mounting screws (6-32 × 3/8 inch, 82º undercut, Phillips) from Access Navigator
where each bracket will be attached (see C in Figure 5-13).

4. Attach mounting bracke ts t o each side of Access Navigat or us ing t he mounti ng scr ews re moved in
previous step (see C in Figur e 5-13). Sl ide brac kets down i n screw slots to ensure maximum space
beneath Access Navigator for ventilation.

5-16 August 2003 Access Navigator - Release 1.8

Physical Installation

Attach Access Navigator to Plywood

Attach Access Navigator to Plywood

1. Position Access Navigat or with brackets atta ched over screw hole locati ons marked in plywood (see

Figure 5-12 on page 5-20).

2. Secure mounting brackets to plywood using eight #8 × 3/4 inch panhead screws (see D in Figure

5-13 on page 5-21).

WARNING! IF ACCESS NAVIGATOR IS MOUNTED ON PLYWOOD, DO NOT USE A

HAMMER TO ATTACH PLYWOOD TO WALL BECAUSE THE IMPACT SHOCK MAY DAMAGE
THE ACCESS NAVIGATOR AND OTHER COMPONENTS MOUNTED ON THE PLYWOOD. A
POWER DRILL AND SCREWDRIVER IS RECOMMENDED TO AVOID DAMAGE.

3. Attach plywood to wall using fasteners appropriate for heavy objects.

Access Navigator - Release 1.8 August 2003 5-17

Physical Installation

Attach Access Navigator to Plywood

Wall View

UP

2 in. Ventilation

Connector

Panel

Access

End View

Connector

Panel

Access

28.5 inches

Ventilation

2 in.

1.75 in.

1.5 in.

Control Panel and

Circuit Board

Access

10 inches6 inches

Ventilation

Control Panel and

Circuit Board

Access

21 inches

6 inches

Mounting brackets provide bott om clearance for ventilation

Figure 5-10. Access Clearance Requirements

5-18 August 2003 Access Navigator - Release 1.8
