Page 1
Installation Instructions
SAFETY CONSIDERATIONS
Centrifugal liquid chillers are designed to provide safe
and reliable service when operated within design specifications. When operating this equipment, use good judgment and safety precautions to avoid damage to equipment and property or injury to personnel.
Be sure you understand and follow the procedures and
safety precautions contained in the machine instructions, as well as those listed in this guide.
DO NOTVENTrefrigerant relief devices within a building. Outlet from
rupture disc or relief valve must be vented outdoors in accordance with
the latest edition of ANSI/ASHRAE 15 (American National Standards
Institute/American Society of Heating, Refrigeration and Air-Conditioning
Engineers) (Safety Code for Mechanical Refrigeration). The accumulation of refrigerant in an enclosed space can displace oxygen and cause
asphyxiation.
PROVIDE adequate ventilation in accordance with ANSI/
ASHRAE 15, especially for enclosed and low overhead spaces. Inhalation of high concentrations of vapor is harmful and may cause heart
irregularities, unconsciousness, or death. Intentional misuse can be fatal. Vapor is heavier than air and reduces the amount of oxygen available for breathing. Product causes eye and skin irritation. Decomposition products are hazardous.
DO NOT USE OXYGEN to purge lines or to pressurize a machine for
any purpose. Oxygen gas reacts violently with oil, grease, and other
common substances.
DO NOT USE air to leak test. Use only refrigerant or dry nitrogen.
NEVER EXCEED specified test pressures. VERIFY the allowable test
pressure by checking the instruction literature and the design pressures
on the equipment nameplate.
DO NOT VALVE OFF any safety device.
BE SURE that all pressure relief devices are properly installed and func-
tioning before operating any machine.
RISK OF INJURYOR DEA THby electrocution. High voltage is present
on motor leads even though the motor is not running when a solid state
or inside-delta mechanical starter is used. Open the power supply disconnect before touching motor leads or terminals.
DO NOT WELD OR FLAMECUT any refrigerant line or vessel until
all refrigerant (liquid and vapor) has been removed from chiller.Traces
of vapor should be displaced with dry air or nitrogen and the work area
should be well ventilated. Refrigerant in contact with an open flame
produces toxic gases.
DO NOT USE eyebolts or eyebolt holes to rig machine sections or the
entire assembly.
DO NOT work on high-voltage equipment unless you are a qualified
electrician.
DO NOT WORK ON electrical components, including control
panels, switches, starters, or oil heater until you are sureALL POWER
IS OFF and no residual voltage can leak from capacitors or solid-state
components.
LOCK OPENAND TAG electrical circuits during servicing. IF WORK
IS INTERRUPTED, confirm that all circuits are deenergized before
resuming work.
AVOID SPILLING liquid refrigerant on skin or getting it into the eyes.
USE SAFETY GOGGLES. Wash any spills from the skin with soap
and water.If liquid refrigerant enters the eyes, IMMEDIATELYFLUSH
EYES with water and consult a physician.
NEVER APPLY an open flame or live steam to a refrigerant cylinder.
Dangerous over pressure can result. When it is necessary to heat refrigerant, use only warm (110 F [43 C]) water.
DO NOT REUSE disposable (nonreturnable) cylinders or attempt to
refill them. It is DANGEROUS AND ILLEGAL. When cylinder is emptied, evacuate remaining gas pressure, loosen the collar, and unscrew
and discard the valve stem. DO NOT INCINERATE.
CHECK THE REFRIGERANT TYPE before adding refrigerant to the
machine. The introduction of the wrong refrigerant can cause
machine damage or malfunction.
Operation of this equipment with refrigerants other than those cited
herein should comply with ANSI/ASHRAE15 (latest edition). Contact
Carrier for further information on use of this machine with other
refrigerants.
DO NOT ATTEMPT TO REMOVE fittings, covers, etc., while
machine is under pressure or while machine is running. Be sure pressure is at 0 psig (0 kPa) before breaking any refrigerant connection.
CAREFULLY INSPECT all relief valves, rupture discs, and other
relief devices AT LEAST ONCE A YEAR. If machine operates
in a corrosive atmosphere, inspect the devices at more frequent
intervals.
DO NOT ATTEMPT TO REPAIR OR RECONDITION any
relief valve when corrosion or build-up of foreign material (rust, dirt,
scale, etc.) is found within the valve body or mechanism. Replace the
valve.
DO NOT install relief devices in series or backwards.
USE CARE when working near or in line with a compressed spring.
Sudden release of the spring can cause it and objects in its path to act
as projectiles.
DO NOT STEP on refrigerant lines. Broken lines can whip about and
release refrigerant, causing personal injury.
DO NOT climb over a machine. Use platform, catwalk, or staging. Follow safe practices when using ladders.
USE MECHANICAL EQUIPMENT (crane, hoist, etc.) to lift or move
inspection covers or other heavy components. Even if components are
light, use mechanical equipment when there is a risk of slipping or
losing your balance.
BE AWARE that certain automatic start arrangements CAN ENGAGE
THE STARTER,TOWERFAN,OR PUMPS. Open the disconnect ahead
of the starter, tower fan, and pumps. Shut off the machine or pump
before servicing equipment.
USE only repaired or replacement parts that meet the code requirements of the original equipment.
DO NOT VENT OR DRAIN waterboxes containing industrial brines,
liquid, gases, or semisolids without the permission of your process control group.
DO NOT LOOSEN waterbox cover bolts until the waterbox has been
completely drained.
DOUBLE-CHECK that coupling nut wrenches, dial indicators, or other
items have been removed before rotating any shafts.
DO NOT LOOSEN a packing gland nut before checking that the nut
has a positive thread engagement.
PERIODICALLY INSPECT all valves, fittings, and piping for corrosion, rust, leaks, or damage.
PROVIDE A DRAIN connection in the vent line near each pressure
relief device to prevent a build-up of condensate or rain water.
19XR
50/60 Hz
Hermetic Centrifugal Liquid Chillers
with HFC-134a
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 2
Tab 5a
PC 211 Catalog No. 531-940 Printed in U.S.A. Form 19XR-2SI Pg 1 10-97 Replaces: 19XR-1SI
Page 2
CONTENTS
Page
SAFETY CONSIDERATIONS ..................1
INTRODUCTION .............................2
General .....................................2
Job Data ....................................2
INSTALLATION .............................2-35
Receiving the Machine .......................2
• INSPECT SHIPMENT
• IDENTIFY MACHINE
• PROVIDE MACHINE PROTECTION
Rigging the Machine .........................2
• RIG MACHINE ASSEMBLY
• RIG MACHINE COMPONENTS
Install Machine Supports ....................17
• INSTALL STANDARD ISOLATION
• INSTALL ACCESSORY ISOLATION
• INSTALL SPRING ISOLATION
Connect Piping .............................19
• INSTALL WATER PIPING TO HEAT
EXCHANGERS
• INSTALL VENT PIPING TO
RELIEF VALVES
Make Electrical Connections ................28
• CONNECT CONTROL INPUTS
• CONNECT CONTROL OUTPUTS
• CONNECT STARTER
• CARRIER COMFORT NETWORK INTERFACE
Install Field Insulation ......................35
INSTALLATION START-UP REQUEST
CHECKLIST ........................CL-1, CL-2
INTRODUCTION
General—
The 19XR machine is factory assembled, wired,
and leak tested. Installation (not by Carrier) consists
primarily of establishing water and electrical services to
the machine. The rigging, installation, field wiring, field piping, and insulation of waterbox covers are the responsibility
of the contractor and/or customer.Carrier has no installation
responsibilities for the equipment.
Job Data
Necessary information consists of:
• job contract or specifications
• machine location prints
• rigging information
• piping prints and details
• field wiring drawings
• starter manufacturer’s installation details
• Carrier certified print
INSTALLATION
Receiving the Machine
INSPECT SHIPMENT
Do not open any valves or loosen any connections. The
standard 19XR machine is shipped with a full refrigerant charge. Some machines may be shipped with a nitrogen holding charge as an option.
1. Inspect for shipping damage while machine is still on shipping conveyance. If machine appears to be damaged or
has been torn loose from its anchorage, have it examined
by transportation inspectors before removal. Forward claim
papers directly to transportation company. Manufacturer
is not responsible for any damage incurred in transit.
2. Check all items against shipping list. Immediately notify
the nearest Carrier representative if any item is missing.
3. To prevent loss or damage, leave all parts in original packages until beginning installation. All openings are closed
with covers or plugs to prevent dirt and debris from entering machine components during shipping. A full operating oil charge is placed in the oil sump before
shipment.
IDENTIFY MACHINE — The machine model number,
serial number, and heat exchanger sizes are stamped on
machine identification nameplate (Fig. 1 and 2). Check this
information against shipping papers and job data.
PROVIDE MACHINE PROTECTION — Protect machine
and starter from construction dirt and moisture. Keep protective shipping covers in place until machine is ready for
installation.
If machine is exposed to freezing temperatures after water
circuits have been installed, open waterbox drains and remove all water from cooler and condenser. Leave drains open
until system is filled.
Rigging the Machine — The 19XR machine can be
rigged as an entire assembly. It also has flanged connections
that allow the compressor, cooler, and condenser sections to
be separated and rigged individually.
RIG MACHINE ASSEMBLY — See rigging instructions on
label attached to machine. Also refer to rigging guide
(Fig. 3 and 4), physical data in Fig. 5, and Tables 1-8B. Lift
machine only from the points indicated in rigging guide. Each
lifting cable or chain must be capable of supporting the entire weight of the machine.
Lifting machine from points other than those specified
may result in serious damage to the unit and personal
injury. Rigging equipment and procedures must be adequate for machine weight. See Fig. 3 and 4 for machine weights.
NOTE: These weights are broken down into component sections for use when installing the unit in
sections. For the complete machine weight, add all component sections and refrigerant charge together. See
Tables 4-8B for machine component weights.
IMPORTANT: Ensure that rigging cable is over the
guide bolt or cable hook on the motor end cover before lifting if cooler size is 10 through 67.
2
Page 3
Fig. 1 — Model Number Identification
3
Page 4
1—Oil Level Sight Glass
2—Diffuser Actuator (Hidden/19XR5 Only)
3—Discharge Isolation Valve
4—Condenser Pumpout Connection
5—Condenser Safety Relief Valves
6—Three-Way Condenser Relief Valve
7—Hot Gas Bypass Line
8—Condenser Waterbox Nozzles
9—Cooler Waterbox Nozzles
10 — Cooler Safety Relief Valves
11 — Cooler Pumpout Connection
12 — Machine Identification Nameplate
13 — Control Panel
14 — Refrigerant Charging Valve
15 — Guide VaneActuator
16 — Compressor/Transmission
17 — Oil Drain/Charging Valve
18 — Oil Pump
19 — Auxillary Power Panel
20 — Oil Filter Isolation Valve
21 — Oil Filter
22 — Motor
FRONT TOP VIEW
BOTTOM REAR VIEW
23 — Waterbox Vents
24 — Oil Reclaim Filter
25 — Float Chamber
26 — Unit Mounted Starter
27 — Refrigerant Filter/Drier Isolation Valves
28 — Sight Glass/Moisture Indicator
29 — Refrigerant Filter/Drier
30 — Cooler Liquid Line Isolation Valve
31 — Hot Gas Bypass Valve (Option)
32 — Hot Gas Bypass Isolation Valve (Option)
33 — Oil Reclaim Filter Isolation Valve
34 — Waterbox Vents
Fig.2—Typical 19XR Installation
4
Page 5
MACHINE RIGGING GUIDE
NOTES:
1. Each cable must be capable of supporting the entire weight of the
machine. See chart for maximum weights.
2. Chain lengths shown are typical for 158 lifting height. Some minor
adjustments may be required.
COMPRESSOR
FRAME SIZE*
COOLER
SIZE
MAXIMUM
WEIGHT (lb)
VESSEL
LENGTH
DIM. ‘‘A’’
CHAIN LENGTH
DIM. ‘‘E’’ DIM. ‘‘F’’
‘‘B’’ ‘‘C’’ ‘‘D’’
2
10-12 18,500 108 48-79 128-79 138-09 138-09
28-39 28-69
15-17 19,000 128 58-99 138-69 138-29 138-39
20-22 19,500 108 48-79 128-79 138-09 138-09 38-19 28-49
2or3
30-32 21,000 128 58-99 138-69 138-29 138-39
38-69 28-69
35-37 22,500 148 78-49 148-29 138-49 138-49
3
40-42 29,700 128 58-99 128-89 128-89 138-49
38-29 28-79
45-47 31,800 148 68-109 138-19 138-29 138-89
50-52 32,200 128 58-99 128-79 128-99 138-59
55-57 33,200 148 68-109 138-19 188-39 158-99
4
50-52 32,530 128 58-99 138-19 128-99 138-49
38-49 28-89
55-57 34,230 148 68-29 138-79 138-19 148-49
60-62 39,950 128 58-99 138-19 128-99 138-49
65-67 36,950 148 68-29 138-79 138-19 148-49
*The first digit of the 3-digit compressor code indicates the frame size of the compressor.
Fig. 3 — Machine Rigging Guide (Cooler Size 10 Through 67)
5
Page 6
COMPRESSOR
FRAME SIZE*
COOLER
SIZE
MAXIMUM
WEIGHT (lb)
VESSEL
LENGTH
DIM. ‘‘A’’ DIM. ‘‘B’’ DIM. ‘‘C’’
CHAIN LENGTH
‘‘D’’ ‘‘E’’ ‘‘F’’
4
70-72 40,410 148 68-69 38-49 38-59 118-69 128-59 128-99
75-77 44,210 168 78-59 38-59 38-59 128-09 138-39 138-69
5
70-72 45,600 148 68-29 38-69 38-79 118-69 128-59 128-99
75-77 49,400 168 68-119 38-69 38-69 128-09 138-39 138-69
80-82 54,900 148 68-29 38-69 38-79 118-69 128-59 128-99
85-87 58,300 168 68-119 38-69 38-69 128-09 138-39 138-69
*The first digit of the 3-digit compressor code indicates the frame size of the compressor.
MACHINE RIGGING GUIDE
NOTES:
1. Each chain must be capable of supporting the entire weight of the
machine. See chart for maximum weights.
2. Chain lengths shown are typical for 158 lifting height. Some minor
adjustments may be required.
3. Dimensions ‘‘A’’ and ‘‘B’’ define distance from machine center of
gravity to tube sheet outermost surfaces. Dimension ‘‘C’’ defines
distance from machine center of gravity to floor.
Fig. 4 — Machine Rigging Guide (Cooler Size 70 Through 87)
CG — Center of Gravity
6
Page 7
Table 1 — 19XR Dimensions (Nozzle-In-Head Waterbox)
HEAT EXCHANGER
SIZE
A (Length, with Nozzle-in-Head Waterbox)
B (Width) C (Height)
2-Pass* 1 or 3 Pass†
ft-in. mm ft-in. mm ft-in. mm ft-in. mm
10 to 12 11- 3
7
⁄
8
3451 11-103⁄
4
3626 4-113⁄
4
1518 6- 11⁄
4
1861
15 to 17 13- 7
3
⁄
8
4150 14- 21⁄
4
4324 4-113⁄
4
1518 6- 11⁄
4
1861
20 to 22 11- 5
1
⁄
8
3483 12- 01⁄
2
3670 5- 53⁄
4
1670 6- 31⁄
4
1911
30 to 32 13- 8
1
⁄
4
4172 14- 31⁄
4
4350 5- 53⁄
4
1670 6- 95⁄
8
2073
35 to 37 15- 4
3
⁄
4
4693 15-113⁄
4
4870 5- 53⁄
4
1670 6- 95⁄
8
2073
40 to 42 13-11 4242 14- 6
1
⁄
4
4426 6- 2 1880 7- 03⁄
4
2153
45 to 47 15- 7
1
⁄
2
4763 16- 23⁄
4
4947 6- 2 1880 7- 03⁄
4
2153
50 to 52 13-11
1
⁄
4
4248 14- 63⁄
4
4439 6- 61⁄
2
1994 7- 27⁄
8
2207
55 to 57 15- 7
3
⁄
4
4769 16- 31⁄
4
4959 6- 61⁄
2
1994 7- 27⁄
8
2207
60 to 62 13-11
3
⁄
4
4261 14- 71⁄
4
4451 6-101⁄
2
2096 7- 47⁄
8
2257
65 to 67 15- 8
1
⁄
4
4782 16- 33⁄
4
4972 6-101⁄
2
2096 7- 47⁄
8
2257
70 to 72 16- 4 4978 17- 0
1
⁄
2
5194 7-111⁄
2
2426 9- 91⁄
2
2985
75 to 77 18- 4 5588 19- 0
1
⁄
2
5804 7-111⁄
2
2426 9- 91⁄
2
2985
80 to 82 16- 4
3
⁄
4
4997 17- 11⁄
2
5220 8-103⁄
4
2711 9-111⁄
4
3029
85 to 87 18- 4
3
⁄
4
5607 19- 11⁄
2
5829 8-103⁄
4
2711 9-111⁄
4
3029
*Assumes both cooler and condenser nozzles on same end of chiller.
†1 or 3 pass length applies if either (or both) cooler or condenser isa1or3pass design.
NOTES:
1. Service access should be provided per American Society of Heating, Refrigeration, andAir Conditioning Engineers (ASHRAE) 15, latest edition,
National Fire Protection Association (NFPA) 70, and local safety code.
2. Allow at least 3 ft (915 mm) overhead clearance for service rigging.
3. Certified drawings available upon request.
C
B
A
MOTOR SERVICE
CLEARANCE
4'0"- (1219 mm)
3'0" (915 mm)
RECOMMENDED OVERHEAD
SERVICE CLEARANCE
2'-6
1
/8" MIN
(362 mm)
2' MIN
(610 mm)
SERVICE AREA
TUBE REMOVAL
SPACE FOR
EITHER END
10'-0" (3048 mm)
(SIZES 10-12, 20-22)
12'-3 1/2" (3747 mm)
(SIZES 15-17)
12'-3 1/2" (3747 mm)
(SIZES 30-32, 40-42,
50-52, 60-62)
14'-3" (4343 mm)
(SIZES 35-37, 45-47,
55-57, 65-67)
14'-0" (4267 mm)
(SIZES 70-72,
80-82)
16'-0" (4877 mm)
(SIZES 75-77,
85-87)
Fig. 5 — 19XR Dimensions (Refer to Tables 1 Through 3)
7
Page 8
Table 2 — 19XR Dimensions (Marine Waterbox)
HEAT EXCHANGER
SIZE
A (Length, Marine Waterbox —
not shown)
2-Pass* 1 or 3 Pass†
ft-in. mm ft-in. mm
10 to 12 NA NA NA NA
15 to 17 NA NA NA NA
20 to 22 12- 6
5
⁄
8
3826 14- 3 4343
30 to 32 14- 9 4496 16- 4
3
⁄
4
4997
35 to 37 16- 5
1
⁄
2
5017 18- 11⁄
4
5518
40 to 42 15- 0
1
⁄
4
4591 16- 83⁄
4
5099
45 to 47 16- 8
3
⁄
4
5099 18- 51⁄
4
5620
50 to 52 15- 0
1
⁄
4
4591 16- 83⁄
4
5099
55 to 57 16- 8
3
⁄
4
5099 18- 51⁄
4
5620
60 to 62 15- 0
3
⁄
4
4591 16- 91⁄
4
5111
65 to 67 16- 9
1
⁄
4
5112 18- 53⁄
4
5632
70 to 72 17- 8 5385 19-10
1
⁄
2
6058
75 to 77 19- 8 5994 21-10
1
⁄
2
6668
80 to 82 17- 8
1
⁄
2
5398 20- 1 6121
85 to 87 19- 8
1
⁄
2
6007 22- 1 6731
*Assumes both cooler and condenser nozzles on same end of chiller.
†1 or 3 pass length applies if cooler isa1or3pass design.
NOTES:
1. Service access should be provided per American Society of Heating, Refrigeration, andAir Conditioning Engineers (ASHRAE) 15, latest edition,
National Fire Protection Association (NFPA) 70, and local safety code.
2. Allow at least 3 ft (915 mm) overhead clearance for service rigging.
3. Certified drawings available upon request.
Table 3 — 19XR Nozzle Size
FRAME
SIZE
NOZZLE SIZE (in.)
(Nominal Pipe Size)
Cooler Condenser
1-Pass 2-Pass 3-Pass 1-Pass 2-Pass 3-Pass
1 866866
210 8 6 10 8 6
3 10 8 6 10 8 6
4 10 8 6 10 8 6
5 10 8 6 10 10 8
6 10 10 8 10 10 8
7 14 12 10 14 12 12
8 14 14 12 14 14 12
8
Page 9
Table 4 — 19XR Compressor Weights
MOTOR
CODE
ENGLISH SI
Total Compressor Weight*
(lb)
Total Compressor Weight*
(kg)
60 Hz 50 Hz 60 Hz 50 Hz
BD 3,755 3,755 1703 1703
BE 3,805 3,805 1726 1726
BF 3,870 3,870 1755 1755
BG 3,950 3,950 1792 1792
BH 3,950 3,950 1792 1792
CD 4,659 4,756 2134 2153
CE 4,685 4,771 2155 2165
CL 4,710 4,842 2137 2167
CM 4,737 4,868 2149 2209
CN 4,751 4,883 2156 2215
CP 4,806 4,898 2181 2212
CQ 4,874 4,898 2211 2212
DB 6,112 6,158 2772 2793
DC 6,138 6,224 2822 2823
DD 6,216 6,262 2819 2840
DE 6,224 6,351 2823 2881
DF 6,274 6,412 2846 2908
DG 6,364 6,466 2886 2933
DH 6,412 6,868 2908 3115
DJ 6,466 6,977 2933 3165
EH 8,025 11,135 3640 5051
EJ 11,085 11,265 5028 5110
EK 11,160 11,282 5062 5118
EL 11,181 11,435 5072 5187
EM 11,271 11,435 5113 5187
EN 11,335 11,635 5142 5278
EP 11,434 11,605 5186 5264
*Compressor weight is comprised of compressor, stator, rotor, end bell, suction elbow, and dis-
charge elbow.
NOTE: For medium voltage motors (over 600 v), add 490 lb (222 kg).
Table 5 — 19XR Component Weights
COMPONENT
FRAME 2
COMPRESSOR
FRAME 3
COMPRESSOR
FRAME 4
COMPRESSOR
FRAME 5
COMPRESSOR
lb kg lb kg lb kg lb kg
Suction Elbow 50 23 54 24 175 79 210 95
Discharge Elbow 60 27 46 21 157 71 140 63
Control Cabinet* 30 14 30 14 30 14 30 14
Optional Unit-Mounted Starter† 800 363 800 363 800 363 800 363
Optional Isolation Valves 115 52 115 52 115 52 115 52
*Included in total cooler weight.
†Weight of optional factory-mounted starter is not included and must be added to the heat
exchanger weight.
9
Page 10
Table 6 — 19XR Heat Exchanger Data
CODE
ENGLISH SI
Dry Rigging Weight
(lb)
Machine Charge
Dry Rigging Weight
(kg)
Machine Charge
Cooler
Only
Condenser
Only
Refrigerant
Weight
Water Volume
(gal)
Cooler
Only
Condenser
Only
Refrigerant
Weight
Water
Volume
Cooler Condenser Cooler Condenser Cooler Condenser Cooler Condenser
10 2,742 2,704 290 200 34 42 1244 1227 132 91 129 158
11 2,812 2,772 310 200 37 45 1276 1257 141 91 140 170
12 2,883 2,857 330 200 40 49 1308 1296 150 91 152 185
15 3,003 2,984 320 250 39 48 1362 1354 145 113 149 183
16 3,089 3,068 340 250 43 52 1401 1392 154 113 163 198
17 3,176 3,173 370 250 47 57 1441 1439 168 113 178 216
20 3,442 3,523 345 225 48 48 1561 1598 156 102 183 181
21 3,590 3,690 385 225 55 55 1628 1674 175 102 207 210
22 3,746 3,854 435 225 62 63 1699 1748 197 102 234 239
30 4,137 3,694 350 260 55 55 1877 1676 159 118 208 210
31 4,319 3,899 420 260 64 65 1959 1769 190 118 242 246
32 4,511 4,100 490 260 72 74 2046 1860 222 118 271 282
35 4,409 4,606 400 310 61 62 2000 2089 181 141 232 233
36 4,617 4,840 480 310 70 72 2094 2195 218 141 266 273
37 4,835 5,069 550 310 80 83 2193 2299 249 141 301 314
40 5,898 6,054 560 280 89 96 2675 2746 254 127 338 365
41 6,080 6,259 630 280 97 106 2757 2839 286 127 368 400
42 6,244 6,465 690 280 105 114 2832 2933 313 127 396 433
45 6,353 6,617 640 330 98 106 2881 3001 290 150 372 403
46 6,561 6,851 720 330 108 117 2976 3108 327 150 407 442
47 6,748 7,085 790 330 116 127 3060 3214 358 150 438 481
50 7,015 7,285 750 400 115 128 3181 3304 340 181 435 483
51 7,262 7,490 840 400 126 137 3293 3397 381 181 477 518
52 7,417 7,683 900 400 133 136 3364 3484 408 181 502 552
55 7,559 7,990 870 490 127 142 3428 3624 395 222 481 536
56 7,839 8,214 940 490 139 152 3555 3725 426 222 527 575
57 8,016 8,434 980 490 147 162 3635 3825 445 222 557 613
60 8,270 8,286 940 420 144 159 3751 3758 426 190 546 601
61 8,462 8,483 980 420 153 168 3838 3847 445 190 578 636
62 8,617 8,676 1020 420 160 177 3908 3935 463 190 604 669
65 8,943 9,204 1020 510 160 176 4056 4174 463 231 605 668
66 9,161 9,428 1060 510 169 187 4155 4276 481 231 641 707
67 9,338 9,648 1090 510 177 197 4235 4376 494 231 671 745
70 12,395 13,139 1220 780 224 209 5622 5960 553 354 848 791
71 12,821 13,568 1340 780 243 229 5816 6154 608 354 919 867
72 13,153 13,969 1440 780 257 248 5966 6336 653 354 974 937
75 13,293 14,211 1365 925 245 234 6030 6446 619 420 927 885
76 13,780 14,702 1505 925 266 257 6251 6669 683 420 1009 971
77 14,159 15,160 1625 925 283 278 6423 6877 737 420 1072 1052
80 16,156 15,746 1500 720 285 264 7328 7142 680 327 1080 1000
81 16,530 16,176 1620 720 302 284 7498 7337 735 327 1143 1075
82 16,919 16,606 1730 720 319 304 7674 7532 785 327 1208 1150
85 17,296 17,001 1690 860 313 295 7845 7712 767 390 1183 1118
86 17,723 17,492 1820 860 331 318 8039 7934 826 390 1254 1205
87 18,169 17,984 1940 860 351 341 8241 8158 880 390 1329 1291
*Rigging weights are for standard tubes of standard wall thickness (Turbo-B3 and Spikefin 2,
0.025-in. [0.635 mm] wall).
NOTES:
1. Cooler includes the control panel (LID), suction elbow, and
1
⁄2the distribution piping weight.
2. Condenser includes float valve and sump, discharge elbow, and
1
⁄2the distribution piping
weight.
3. For special tubes refer to the 19XR Computer Selection Program.
4. All weights for standard 2 pass NIH (nozzle-in-head) design.
10
Page 11
Table 7 — 19XR Additional Data for Marine Waterboxes*
HEAT EXCHANGER
FRAME, PASS
ENGLISH SI
Psig
Rigging Weight
(lb)
Water Volume
(gal)
kPa
Rigging Weight
(kg)
Water Volume
(L)
FRAME 2, 1 AND 2 PASS 150 730 84 1034 331 318
FRAME 2, 2 PASS 150 365 42 1034 166 159
FRAME 3, 1 AND 2 PASS 150 730 84 1034 331 317
FRAME 3, 2 PASS 150 365 42 1034 166 159
FRAME 4, 1 AND 3 PASS 150 1060 123 1034 481 465
FRAME 4, 2 PASS 150 530 61 1034 240 231
FRAME 5, 1 AND 3 PASS 150 1240 139 1034 562 526
FRAME 5, 2 PASS 150 620 69 1034 281 263
FRAME 6, 1 AND 3 PASS 150 1500 162 1034 680 612
FRAME 6, 2 PASS 150 750 81 1034 340 306
FRAME 7, 1 AND 3 PASS 150 2010 326 1034 912 1234
FRAME 7, 2 PASS 150 740 163 1034 336 617
FRAME 8, 1 AND 3 PASS 150 1855 406 1034 841 1537
FRAME 8, 2 PASS 150 585 203 1034 265 768
FRAME 2, 1 AND 3 PASS 300 860 84 2068 390 318
FRAME 2, 2 PASS 300 430 42 2068 195 159
FRAME 3, 1 AND 3 PASS 300 860 84 2068 390 317
FRAME 3, 2 PASS 300 430 42 2068 195 159
FRAME 4, 1 AND 3 PASS 300 1210 123 2068 549 465
FRAME 4, 2 PASS 300 600 61 2068 272 231
FRAME 5, 1 AND 3 PASS 300 1380 139 2068 626 526
FRAME 5, 2 PASS 300 690 69 2068 313 263
FRAME 6, 1 AND 3 PASS 300 1650 162 2068 748 612
FRAME 6, 2 PASS 300 825 81 2068 374 306
FRAME 7, 1 AND 3 PASS 300 3100 326 2068 1406 1234
FRAME 7, 2 PASS 300 2295 163 2068 1041 617
FRAME 8, 1 AND 3 PASS 300 2745 405 2068 1245 1533
FRAME 8, 2 PASS 300 1630 203 2068 739 768
*Add to heat exchanger data for total weights or volumes.
NOTES:
1. Weight adder shown is the same for cooler and condenser of equal frame size.
2. For the total weight of a vessel with a marine waterbox, add these values to the heat
exchanger weights (or volumes).
11
Page 12
Table 8A — 19XR Waterbox Cover Weights
ENGLISH (lb)
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 1 FRAME 2 FRAME 3
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 177 204 320 350 320 350
NIH, 2 Pass Cover, 150 psig 185 218 320 350 320 350
NIH, 3 Pass Cover, 150 psig 180 196 300 340 300 340
NIH/MWB End Cover, 150 psig 136 136 300 300 300 300
NIH, 1 Pass Cover, 300 psig 248 301 411 486 411 486
NIH, 2 Pass Cover, 300 psig 255 324 411 518 411 518
NIH, 3 Pass Cover, 300 psig 253 288 433 468 433 468
NIH/MWB End Cover, 300 psig 175 175 400 400 400 400
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 4 FRAME 5 FRAME 6
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 485 521 616 652 802 838
NIH, 2 Pass Cover, 150 psig 487 540 590 663 770 843
NIH, 3 Pass Cover, 150 psig 504 520 629 655 817 843
NIH/MWB End Cover, 150 psig 379 379 428 428 583 583
NIH, 1 Pass Cover, 300 psig 593 668 764 655 880 956
NIH, 2 Pass Cover, 300 psig 594 700 761 839 844 995
NIH, 3 Pass Cover, 300 psig 621 656 795 838 901 952
NIH/MWB End Cover, 300 psig 569 569 713 713 833 833
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 7 COOLER FRAME 7 CONDENSER
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 1392 1469 1205 1282
NIH, 2 Pass Cover, 150 psig 1345 1461 1163 1279
NIH, 3 Pass Cover, 150 psig 1434 1471 1222 1280
NIH/MWB End Cover, 150 psig 1022 1022 920 920
NIH, 1 Pass Cover, 300 psig 1985 2150 1690 1851
NIH, 2 Pass Cover, 300 psig 1934 2174 1628 1862
NIH, 3 Pass Cover, 300 psig 2009 2090 1714 1831
NIH/MWB End Cover, 300 psig 1567 1567 1923 1923
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 8 COOLER FRAME 8 CONDENSER
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 1831 1909 1682 1760
NIH, 2 Pass Cover, 150 psig 1739 1893 1589 1744
NIH, 3 Pass Cover, 150 psig 1851 1909 1702 1761
NIH/MWB End Cover, 150 psig 1480 1480 1228 1228
NIH, 1 Pass Cover, 300 psig 2690 2854 2394 2549
NIH, 2 Pass Cover, 300 psig 2595 2924 2269 2578
NIH, 3 Pass Cover, 300 psig 2698 2861 2417 2529
NIH/MWB End Cover, 300 psig 1440 1440 1767 1767
LEGEND
NIH — Nozzle-in-Head
MWB — Marine Waterbox
NOTE: Weight for NIH 2-Pass Cover, 150 psig is included in the heat exchanger weights shown in Table 6.
RIG MACHINE COMPONENTS — Refer to instructions
below,Fig. 6-9, and Carrier Certified Prints for machine component disassembly.
IMPORTANT: Only a qualified service technicianshould
perform this operation.
Do not attempt to disconnect flanges while the machine
is under pressure. Failure to relieve pressure can result
in personal injury or damage to the unit.
Before rigging the compressor, disconnect all wires entering the power panel.
12
Page 13
Table 8B — 19XR Waterbox Cover Weights
SI (kg)
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 1 FRAME 2 FRAME 3
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 80 93 145 159 145 159
NIH, 2 Pass Cover, 150 psig 84 99 145 159 145 159
NIH, 3 Pass Cover, 150 psig 82 89 136 154 140 154
NIH/MWB End Cover, 150 psig 62 62 136 136 136 136
NIH, 1 Pass Cover, 300 psig 112 137 186 220 186 220
NIH, 2 Pass Cover, 300 psig 116 147 186 235 186 235
NIH, 3 Pass Cover, 300 psig 115 131 196 212 196 212
NIH/MWB End Cover, 300 psig 79 79 181 181 181 181
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 4 FRAME 5 FRAME 6
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 220 236 279 296 364 380
NIH, 2 Pass Cover, 150 psig 221 245 268 301 349 382
NIH, 3 Pass Cover, 150 psig 229 236 285 297 371 381
NIH/MWB End Cover, 150 psig 172 172 194 194 265 265
NIH, 1 Pass Cover, 300 psig 269 303 347 381 399 434
NIH, 2 Pass Cover, 300 psig 269 318 345 398 383 451
NIH, 3 Pass Cover, 300 psig 282 298 361 380 409 432
NIH/MWB End Cover, 300 psig 258 258 323 323 378 378
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 7 COOLER FRAME 7 CONDENSER
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 631 666 547 582
NIH, 2 Pass Cover, 150 psig 610 663 528 580
NIH, 3 Pass Cover, 150 psig 650 667 554 581
NIH/MWB End Cover, 150 psig 464 464 417 417
NIH, 1 Pass Cover, 300 psig 900 975 767 840
NIH, 2 Pass Cover, 300 psig 877 986 738 845
NIH, 3 Pass Cover, 300 psig 911 948 777 831
NIH/MWB End Cover, 300 psig 711 711 872 872
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 8 COOLER FRAME 8 CONDENSER
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 831 866 763 798
NIH, 2 Pass Cover, 150 psig 789 859 721 791
NIH, 3 Pass Cover, 150 psig 840 866 772 799
NIH/MWB End Cover, 150 psig 671 671 557 557
NIH, 1 Pass Cover, 300 psig 1220 1295 1086 1156
NIH, 2 Pass Cover, 300 psig 1177 1326 1029 1169
NIH, 3 Pass Cover, 300 psig 1224 1298 1096 1147
NIH/MWB End Cover, 300 psig 653 653 802 802
LEGEND
NIH — Nozzle-in-Head
MWB — Marine Waterbox
NOTE: Weight for NIH 2-Pass Cover, 150 psig is included in the heat exchanger weights shown in Table 6.
NOTE: If the cooler and condenser vessels must be separated, the heat exchangers should be kept level by placing a
support plate under the tube sheets. The support plate will
also help to keep the vessels level and aligned when the vessels are bolted back together.
NOTE: Wiring must also be disconnected. Label each wire
before removal (see Carrier Certified Prints). In order to disconnect the starter from the machine, remove wiring for the
oil pump, oil heater, control wiring at the power panel, and
the main motor leads at the starter lugs.
Remove all transducer and sensor wires at the sensor. Clip
all wire ties necessary to pull heat exchangers apart.
To Separate Cooler and Condenser:
1. Place a support plate under each tube sheet to keep each
vessel level (Fig. 6, Item 6).
2. Cut the refrigerant motor cooling line at the location shown
(Fig. 6, Item 7).
13
Page 14
3. Disconnect the compressor discharge elbow at the compressor (Fig. 7, Item 3).
4. Cut the hot gas bypass line at the location shown (Fig. 6,
Item 1).
5. Unbolt the cooler liquid feed line at the location shown
(Fig. 6, Item 10).
6. Cover all openings.
7. Disconnect all wires and cables that cross from the cooler
side of the machine to the condenser side, including:
a. temperature sensor cable at the waterbox (Fig. 9,
Item 1)
b. condenser transducer cable at the transducer (Fig. 7,
Item 4)
c. motor power wires at the starter (Fig. 6, Item 4)
d. wires and cable housings at the power panel that cross
from the starter to the power panel (Fig. 7, Item 2).
8. Disconnect the rabbet-fit connectors on the tube sheets
(Fig. 6, Item 5).
9. Rig the vessels apart.
To Separate the Compressor from the Cooler:
1. Unbolt the compressor suction elbow at the cooler flange
(Fig. 6, Item 2).
2. Cut the refrigerantmotor cooling line at the location shown
(Fig. 6, Item 7).
3. Disconnect the motor refrigerant return line (Fig. 6,
Item 8).
4. Disconnect the following:
a. compressor oil sump temperature sensor cable
(Fig. 8, Item 4)
b. bearing temperature sensor cable (Fig. 8, Item 2).
c. motor temperature sensor cable (Fig. 8, Item 1)
d. wires and cable housings that cross from the power
panel to the starter and control panel (Fig. 7, Item 2)
e. discharge temperature sensor cable (Fig. 8, Item 6)
f. compressor oil sump pressure cable (Fig. 8, Item 3)
g. compressor oil discharge pressure cable (Fig. 8,
Item 5)
h. guide vane actuator cable (Fig. 7, Item 1).
i. diffuser actuator cable (Frame 5 compressor only —
not shown)
5. Disconnect the flared fitting for the oil reclaim line
(Fig. 6, Item 3).
6. Unbolt the compressor discharge elbow (Fig. 7, Item 3).
7. Cover all openings.
8. Disconnect motor power cables at the starter lugs
(Fig. 6, Item 4).
9. Unbolt the compressor mounting from the cooler
(Fig. 6, Item 9).
10. Rig the compressor.
1—Optional Hot Gas Bypass (Cut)
2—Compressor Suction Elbow (Unbolt)
3—Oil Reclaim Line (Unbolt)
4—Starter Connector (Unbolt)
5—Vessel Connectors (Unbolt)
6—Tube Sheet
7—Refrigerant Motor Cooling Line (Cut)
8—Motor Drain (Unbolt)
9—Compressor Mounting (Unbolt)
10 — Cooler Liquid Feed Line (Unbolt)
Fig. 6 — Cooler, Side View
14
Page 15
1—Guide Vane Actuator Cable
2—Power Panel to Starter Cables (Oil Pump Power,
Control Power, and Communication)
Fig. 7 — 19XR Chiller Top View
3—Compressor Discharge Elbow Joints
4—Condenser Transducer Cable
1—Motor Temperature Sensor Cable
2—Bearing Temperature Sensor Cable
Connection (Inside Box)
3—Compressor Oil Sump Pressure Cable
4—Compressor Oil Sump Temperature
Sensor Cable
5—Compressor Oil Discharge Pressure Cable
6—Discharge Temperature Sensor Cable
Fig. 8 — Compressor Detail
15
Page 16
1—Guide Vane Actuator
2—Diffuser Actuator
3—Water Temperature Sensor Cables
Fig. 9 — Chiller End View
16
Page 17
To Rig Compressor
NOTE: The motor end of the 19XR compressor is heavy
and will tip backwards unless these directions are followed:
1. Cut two 4 in. × 6 in. wooden beams to the same length
as the compressor.
2. Drill holes into the beams and bolt them to the base of
the compressor.
Additional Notes
1. Use silicon grease on new O-rings when refitting.
2. Use gasket sealant on new gaskets when refitting.
3. Cooler and condenser vessels may be rigged vertically.
Rigging should be fixed to all 4 corners of the tube sheet.
Install Machine Supports
INSTALL STANDARD ISOLATION — Figures 10 and 11
show the position of support plates and shear flex pads, which
together form the standard machine support system.
INSTALL ACCESSORY ISOLATION (if required) — Uneven floors or other considerations may dictate the use of
accessory soleplates (supplied by Carrier for field installation) and leveling pads. Refer to Fig. 10 and 12.
Level machine by using jacking screws in isolation sole-
plates. Use a level at least 24-in. (600 mm) long.
For adequate and long lasting machine support, proper grout
selection and placement is essential. Carrier recommends that
only pre-mixed, epoxy type, non-shrinking grout be used for
machine installation. Follow manufacturer’s instructions in
applying grout.
1. Check machine location prints for required grout
thickness.
2. Carefully wax jacking screws for easy removal from grout.
3. Grout must extend above the base of the soleplate and
there must be no voids in grout beneath the plates.
4. Allow grout to set and harden, per manufacturer’s in-
structions, before starting machine.
5. Remove jacking screws from leveling pads after grout has
hardened.
HEAT EXCHANGER
SIZE
DIMENSIONS (ft-in.)
AB
10-12 10- 7
1
⁄
4
4-111⁄
4
15-17 12-103⁄
4
4-111⁄
4
20-22 10- 71⁄
4
5- 51⁄
4
30-32 12-103⁄
4
5- 41⁄
4
35-37 14- 71⁄
4
5- 41⁄
4
40-42 12-103⁄
4
6- 0
45-57 14- 7
1
⁄
4
6- 0
50-52 12-10
3
⁄
4
6- 51⁄
2
55-57 14- 71⁄
4
6- 51⁄
2
60-62 12-103⁄
4
6- 91⁄
2
65-67 14- 71⁄
4
6- 91⁄
2
70-72 15- 17⁄
8
7-101⁄
2
75-77 17- 17⁄
8
7-101⁄
2
80-82 15- 17⁄
8
8- 93⁄
4
85-87 17- 17⁄
8
8- 93⁄
4
Fig. 10 — 19XR Machine Footprint
17
Page 18
INSTALL SPRING ISOLATION — Spring isolation may
be purchased as an accessory from Carrier for field installation. It may also be field supplied and installed. Spring isolators may be placed directly under machine support plates
or located under machine soleplates. See Fig. 13. Consult
job data for specific arrangement. Low profile spring isolation assemblies can be field supplied to keep the machine at
a convenient working height.
Obtain specific details on spring mounting and machine
weight distribution from job data. Also, check job data for
methods to support and isolate pipes that are attached to spring
isolated machines.
NOTES:
1. Dimensions in ( ) are in millimeters.
2. Isolation package includes 4 shear flex pads.
VIEW Y-Y
Fig. 11 — Standard Isolation
ACCESSORY SOLEPLATE DETAIL
LEGEND
HRS — Hot Rolled Steel
NOTES:
1. Dimensions in ( ) are in millimeters.
2. Accessory (Carrier supplied, field installed) soleplate package
includes 4 soleplates, 16 jacking screws and leveling pads.
3. Jacking screws to be removed after grout has set.
4. Thickness of grout will vary, depending on the amount necessary
to level chiller. Use only pre-mixed non-shrinking grout, Ceilcote
648CP 08-1
1
⁄29 (38.1) to 08-21⁄49 (57) thick.
VIEW X-X
Fig. 12 — Accessory Isolation
NOTE: The accessory spring isolators are supplied by Carrier for installation in the field.
Fig. 13 — 19XR Accessory Spring Isolation
(Shown with Accessory Soleplates)
18
Page 19
Connect Piping
INSTALL WATER PIPING TO HEAT EXCHANGERS —
Install piping using job data, piping drawings, and procedures outlined below. A typical piping installation is shown
in Fig. 14.
Factory-supplied insulation is not flammable but can be
damaged by welding sparks and open flame. Protect insulation with a wet canvas cover.
Remove chilled and condenser water sensors before
welding connecting piping to water nozzles. Refer to
Fig. 9. Replace sensors after welding is complete.
1. Offset pipe flanges to permit removal of waterbox cover
for maintenance and to provide clearance for pipe cleaning. No flanges are necessary with marine waterbox
option; however, water piping should not cross in front
of the waterbox or access will be blocked.
2. Provide openings in water piping for required pressure
gages and thermometers. For thorough mixing and temperature stabilization, wells in the leaving water pipe should
extend inside pipe at least 2 in. (50 mm).
3. Install air vents at all high points in piping to remove air
and prevent water hammer.
4. Install pipe hangers where needed. Make sure no weight
or stress is placed on waterbox nozzles or flanges.
5. Water flow direction must be as specified in Fig. 15-18.
NOTE: Entering wateris always the lower of the 2 nozzles.
Leaving water is always the upper nozzle for cooler or
condenser.
6. Water flow switches must be of vapor-tight construction
and must be installed on top of pipe in a horizontal run
and at least 5 pipe diameters from any bend.
7. Install waterbox vent and drain piping in accordance with
individual job data. All connections are3⁄4-in. FPT.
8. Install waterbox drain plugs in the unused waterbox drains
and vent openings.
9. Install optional pumpout system or pumpout system and
storage tank as shown in Fig. 19-22.
LEGEND
COM — Common
N.O. — Normally Open
*Do not tap connections after shutoff valve.
Fig. 14 — Typical Nozzle Piping
*
*
19
Page 20
NOZZLE-IN HEAD WATERBOXES
FRAMES 1, 2, AND 3
FRAMES 4, 5, AND 6
NOZZLE ARRANGEMENT CODES FOR ALL 19XR NOZZLE-IN-HEAD WATERBOXES
PASS
COOLER WATERBOXES
In Out
Arrangement
Code*
1
85 A
58 B
2
79 C
46 D
3
76 E
49 F
*Refer to certified drawings.
PASS
CONDENSER WATERBOXES
In Out
Arrangement
Code*
1
11 2 P
211 Q
2
10 12 R
13 S
3
10 3 T
112 U
Fig. 15 — Piping Flow Data (NIH, Frames 1 Through 6)
20
Page 21
NOZZLE-IN-HEAD WATERBOXES
FRAMES 7 AND 8
NOZZLE ARRANGEMENT CODES FOR ALL 19XR NOZZLE-IN-HEAD WATERBOXES
PASS
COOLER WATERBOXES
In Out
Arrangement
Code*
1
85 A
58 B
2
79 C
46 D
3
76 E
49 F
*Refer to certified drawings.
PASS
CONDENSER WATERBOXES
In Out
Arrangement
Code*
1
11 2 P
211 Q
2
10 12 R
13 S
3
10 3 T
112 U
Fig. 16 — Piping Flow Data (NIH, Frames 7 and 8)
21
Page 22
MARINE WATERBOXES
FRAMES 2 AND 3*
*There is no Frame 1 marine waterbox.
NOZZLE ARRANGEMENT CODES
PASS
COOLER WATERBOXES CONDENSER WATERBOXES
In Out
Arrangement
Code
In Out
Arrangement
Code
1
85 A — — —
58 B — — —
2
79 C 1012 R
46 D 1 3 S
3
76 E — — —
49 F — — —
Fig. 17 — Piping Flow Data (MWB, Frames 2 and 3)
22
Page 23
MARINE WATERBOXES (cont)
FRAMES 4, 5, AND 6
NOZZLE ARRANGEMENT CODES
PASS
COOLER WATERBOXES CONDENSER WATERBOXES
In Out
Arrangement
Code
In Out
Arrangement
Code
1
96 A — — —
69 B — — —
2
79 C 1012 R
46 D 1 3 S
3
76 E — — —
49 F — — —
FRAMES 7 AND 8
NOZZLE ARRANGEMENT CODES
PASS
COOLER WATERBOXES CONDENSER WATERBOXES
In Out
Arrangement
Code
In Out
Arrangement
Code
1
85 A — — —
58 B — — —
2
79 C 1012 R
46 D 1 3 S
3
76 E — — —
49 F — — —
Fig. 18 — Piping Flow Data (MWB, Frames 4 Through 8)
23
Page 24
Table 9 — 19XR Waterbox Nozzle Sizes
FRAME
SIZE
PRESSURE
psig (kPa)
PASS
NOMINAL PIPE SIZE (in.) ACTUAL PIPE ID (in.)
Cooler Condenser Cooler Condenser
1
150/300
(1034/2068)
1 8 8 7.981 7.981
2 6 6 6.065 6.065
3 6 6 6.065 6.065
2
150/300
(1034/2068)
1 10 10 10.020 10.020
2 8 8 7.981 7.981
3 6 6 6.065 6.065
3
150/300
(1034/2068)
1 10 10 10.020 10.020
2 8 8 7.981 7.981
3 6 6 6.065 6.065
4
150/300
(1034/2068)
1 10 10 10.020 10.020
2 8 8 7.981 7.981
3 6 6 6.065 6.065
5
150/300
(1034/2068)
1 10 10 10.020 10.020
2 8 10 7.981 10.020
3 6 8 6.065 7.981
6
150/300
(1034/2068)
1 10 10 10.020 10.020
2 10 10 10.020 10.020
3 8 8 7.981 7.981
7
150
(1034)
1 14 14 13.250 13.250
2 12 12 12.000 12.000
3 10 12 10.020 12.000
300
(2068)
1 14 14 12.500 12.500
2 12 12 11.376 11.750
3 10 12 9.750 11.750
8
150
(1034)
1 14 14 13.250 13.250
2 14 14 13.250 13.250
3 12 12 12.000 12.000
300
(2068)
1 14 14 12.500 12.500
2 14 14 12.500 12.500
3 12 12 11.376 11.376
24
Page 25
DIMENSIONS
ENGLISH (ft-in.)
TANK
SIZE
ABCDEFGHJKLMNPRST
0428 10- 5 9-10 4-9 2-4
3
⁄41-23⁄83-13⁄164-11 3-81⁄83- 8 2-97⁄163-2 0-31⁄24-83⁄41-77⁄81-75⁄163-73⁄45-01⁄
4
0452 14-111⁄414- 41⁄25-07⁄82-81⁄21-41⁄43-47⁄167- 21⁄44-0 3-117⁄83-15⁄163-57⁄80-33⁄87-11⁄21-83⁄41-79⁄163-8 5-01⁄
2
SI (mm)
TANK
SIZE
ABCDEFGHJKLMNPRST
0428 3175 2997 1448 730 365 945 1499 1121 1118 849 965 89 1442 505 491 1111 1530
0452 4553 4382 1546 826 413 1027 2191 1219 1216 948 1064 86 2172 528 497 1118 1537
NOTES:
1. Denotes center of gravity.
2. Dimensions in ( ) are in millimeters.
3. The weights and center of gravity values given are for an empty storage tank.
4. For additional information on the pumpout unit, see certified drawings.
5. The available conduit knockout sizes are:
QTY TRADE SIZE LOCATION
1
1
⁄29 top
1
3
⁄49 bottom
119 middle
11
1
⁄
4
9 middle
Fig. 19 — Optional Pumpout Unit and Storage Tank
25
Page 26
RATED DRY WEIGHT AND REFRIGERANT CAPACITY
ENGLISH (lb)
TANK
SIZE
TANK OD
(in.)
DRY
WEIGHT*
(lb)
MAXIMUM REFRIGERANT CAPACITY (lb)
ANSI/ASHRAE 15 UL 1963
0428 24.00 2380 1860 1716
0452 27.25 3460 3563 3286
SI (kg)
TANK
SIZE
TANK OD
(mm)
DRY
WEIGHT*
(kg)
MAXIMUM REFRIGERANT CAPACITY (kg)
ANSI/ASHRAE 15 UL 1963
0428 610 1080 844 778
0452 592 1569 1616 1491
LEGEND
ASHRAE — American Society of Heating, Refrigeration,
and Air Conditioning Engineers
OD — Outside Diameter
UL — Underwriters’ Laboratories
*The above dry weight includes the pumpout condensing unit weight of 210 lbs (95 kg).
Fig. 19 — Optional Pumpout Unit and Storage Tank (cont)
26
Page 27
Fig. 20 — Optional Pumpout System Piping Schematic with Storage Tank
Fig. 21 — Optional Pumpout System Piping Schematic without Storage Tank
27
Page 28
INSTALL VENT PIPING TO RELIEF VALVES — The
19XR chiller is factory equipped with relief devices on the
cooler and condenser shells. Refer to Fig. 23 and Table 10
for size and location of relief devices. Vent relief devices to
the outdoors in accordance with ANSI/ASHRAE 15 (latest
edition) Safety Code for Mechanical Refrigeration and all
other applicable codes.
Refrigerant discharged into confined spaces can displace oxygen and cause asphyxiation.
1. If relief devices are manifolded, the cross-sectional area
of the relief pipe must at least equal the sum of the areas
required for individual relief pipes.
2. Provide a pipe plug near outlet side of each relief device
for leak testing. Provide pipe fittings that allow vent piping to be disconnected periodically for inspection of valve
mechanism.
3. Piping to relief devices must not apply stress to the
device. Adequately support piping. A length of flexible
tubing or piping near the device is essential on springisolated machines.
4. Cover the outdoor vent with a rain cap and place a condensation drain at the low point in the vent piping to prevent water build-up on the atmospheric side of the relief
device.
Table 10 — Relief Device Locations
RELIEF VALVE
OUTLET SIZE
LOCATION
QUANTITY
Frame 5
Compressor With
Frame 7 or 8
Heat Exchanger
All
Others
1-in. NPT FEMALE
CONNECTOR
Cooler 4 2
1-in.NPT FEMALE
CONNECTOR
Condenser 4 2
1-in. NPT FEMALE
CONNECTOR
Optional
Storage Tank
22
NOTE: All valves relieve at 185 psi (1275 kPa).
Make Electrical Connections — Field wiring must
be installed in accordance with job wiring diagrams and all
applicable electrical codes.
Do not run 120-v wiring into the control cabinet. The
control cabinet should only be used for additional extralow voltage wiring (50 v maximum).
Wiring diagrams in this publication (Fig. 24-31) are for
reference only and are not intended for use during actual installation; follow job specific wiring diagrams.
Do not attempt to start compressor or oil pump (even
for a rotation check) or apply test voltage of any kind
while machine is under dehydration vacuum. Motor insulation breakdown and serious damage may result.
CONNECT CONTROL INPUTS — Connect the control input wiring from the chilled and condenser water flow switches
to the starter terminal strip. Wiring may also be specified for
a spare safety switch, and a remote start/stop contact can be
wired to the starter terminal strip. Additional spare sensors
and Carrier Comfort Network modules may be specified as
well. These are wired to the machine control panel as indicated in Fig. 24 and 25.
CONDENSER
WATER CONNECTIONS
OIL
RETURN LINE
CONNECTION
SERVICE
VALVES
REFRIGERANT
INLET VALVE
COMPRESSOR
MOUNTING
SPRINGS
Fig. 22 — Pumpout Unit
Fig. 23 — Relief Valve Locations
28
Page 29
Fig. 24 — Carrier Comfort Network Communication Bus Wiring
LEGEND
Factory Wiring
Field Wiring
*Field supplied terminal strip must be located in control panel.
Fig. 25 — COMM1 CCN Communication Wiring For Multiple Chillers (Typical)
29
Page 30
CONNECT CONTROL OUTPUTS — Connect auxiliary
equipment, chilled and condenser water pumps, and spare
alarms as required and indicated on job wiring drawings.
CONNECT STARTER— The 19XR is available with either
a unit-mounted, factory-installed starter or a free-standing,
field-installed starter (Fig. 28 and 29).
Unit Mounted, Factory-Installed Starter— Attach power leads
by connecting them from inside the starter cabinet to the line
side circuit breaker terminals. See Fig. 26 and 28. Machines
with electro-mechanical starters (wye-delta) will have a top
hat shipped with the machine if the RLA (rated load amps)
is greater than 935 amps. If the machine is equipped with a
solid-state starter, a top hat is provided if the RLA exceeds
740 amps. The top hat is shipped in the knocked-down position and must be assembled and installed on top of the starter
cabinet, over the line side circuit breaker. During assembly,
remove the access plate and use it as the cover piece of the
top hat. The top hat provides additional wire bending space
to attach line side power leads to the circuit breaker within
the starter.
IMPORTANT: Be sure to ground the power circuit in
accordance with the National Electrical Code (NEC),
applicable local codes, and job wiring diagrams. Also,
make sure correct phasing is observed for proper
rotation.
3
7
8
LEGEND
1—Disconnect
2—Unit Mounted Starter
3—Control Cabinet
4—Power Panel
5—Vents
6—Pressure Gages
7—Chilled Water Pump
8—Condenser Water Pump
9—Chilled Water Pump Starter
10 — Condensing Water Pump Starter
11 — Cooling Tower Fan Starter
IMPORTANT: Wiring and piping shown are for general pointof-connection only and are not intended to show details for a
specific installation. Certified field wiring and dimensional diagrams are available on request.
NOTES:
1. All wiring must comply with applicable codes.
2. Refer to Carrier System Design Manual for details regarding piping techniques.
3. Wiring not shown for optional devices such as:
• remote start-stop
• remote alarm
• optional safety device
• 4 to 20 mA resets
• optional remote sensors
Piping
Control Wiring
Power Wiring
Fig. 26 — 19XR with Optional Unit-Mounted Starter
30
Page 31
Free-Standing, Field-Installed Starter — Assemble and install compressor terminal box in desired orientation, and cut
necessary conduit openings in conduit support plates. See
Fig. 27 and 29. Attach power leads to compressor terminals
in accordance with job wiring drawings, observing caution
label in terminal box. Use only copper conductors. The motor must be grounded in accordance with NEC (National Electrical Code), applicable local codes, and job wiring diagrams.
Installer is responsible for any damage caused by improper
wiring between starter and compressor motor.
IMPORTANT: Do not insulate terminals until wiring
arrangement has been checked and approved by
Carrier start-up personnel.Also, make sure correct phasing is followed for proper motor rotation.
Insulate Motor Terminals and Lead Wire Ends — Insulate
compressor motor terminals, lead wire ends, and electrical
wires to prevent moisture condensation and electrical arcing. For low-voltage units (up to 600 v), obtain insulation
material from machine shipping package consisting of 3 rolls
of insulation putty and one roll of vinyl tape.
1. Insulate each terminal by wrapping with one layer of insulation putty.
2. Overwrap putty with 4 layers of vinyl tape.
High Voltage Units — High-voltage units require special terminal preparation. Follow local electrical codes for highvoltage installation. Vinyltape is not acceptable; ahigh voltage
terminal method must be used.
Connect Power Wires to Oil Pump Starter — See Fig. 30.
Connect power wires to oil pump starter mounted in machine power panel. Use separate fused disconnect or circuit
breaker as shown on job wiring diagrams and Fig. 30. Check
that power supply voltage agrees with oil pump voltage. Follow correct phasing for proper motor rotation.
Do not punch holes or drill into the top surface of the
power panel. Knockouts are provided in the bottom of
the power panel for wiring connections.
Piping
Control Wiring
Power Wiring
LEGEND
1—Disconnect
2—Free-Standing Compressor Motor Starter
3—Compressor Motor Terminal Box
4—Chiller Power Panel
5—Control Cabinet
6—Vents
7—Pressure Gages
8—Chilled Water Pump
9—Condenser Water Pump
10 — Chilled Water Pump Starter
11 — Condensing Water Pump Starter
12 — Cooling Tower Fan Starter
13 — Disconnect
14 — Oil Pump Disconnect (see Note 4)
IMPORTANT: Wiring and piping shown are for general pointof-connection only and are not intended to show details for a
specific installation. Certified field wiring and dimensional diagrams are available on request.
NOTES:
1. All wiring must comply with applicable codes.
2. Refer to Carrier System Design Manual for details regarding piping techniques.
3. Wiring not shown for optional devices such as:
• remote start-stop
• remote alarm
• optional safety device
• 4 to 20 mA resets
• optional remote sensors
4. Oil pump disconnect may be located within the enclosure of Item
2 — Free-Standing Compressor Motor Starter.
Fig. 27 — 19XR with Free-Standing Starter
31
Page 32
IMPORT ANT: Wiring shown is typical and not intended toshow
detail for a specific installation. Refer to certified field wiring
diagrams.
NOTES:
I. GENERAL
1.0 Starters shall be designed and manufactured in accordance with
Carrier Engineering Requirement Z-375.
1.1 All field-supplied conductors, devices, field-installation wiring, and termination of conductors and devices must be in compliance with all applicable codes and job specifications.
1.2 The routing of field-installed conduit and conductors and the location
of field-installed devices must not interfere with equipment access or
the reading, adjusting, or servicing of any component.
1.3 Equipment, installation, and all starting and control devices must comply with details in equipment submittal drawings and literature.
1.4 Contacts and switches are shown in the position they would assume
with the circuit deenergized and the chiller shut down.
1.5 WARNING
— Do not use aluminum conductors.
1.6 Installer is responsible for any damage caused by improper wiring between starter and machine.
II. POWER WIRING TO STARTER
2.0 Power conductor rating must meet minimum unit nameplate voltage
and compressor motor RLA.
When (3) conductors are used:
Minimum ampacity per conductor = 1.25 x compressor RLA
When (6) conductors are used:
Minimum ampacity per conductor = 0.721 x compressor RLA
2.1 Lug adapters may be required if installation conditions dictatethat conductorsbe sized beyond the minimumampacity required. Contact starter
supplier for lug information.
2.2 Compressor motor and controls must be grounded by using equipment grounding lugs provided inside starter enclosure.
III. CONTROL WIRING
3.0 Field supplied control conductors to be at least 18 AWG or larger.
3.1 Chilled water and condenser water flow switch contacts, optional remote start device contacts, and optional spare safety device contacts
must have 24 vdc rating. Max current is 60 mA; nominal current is
10 mA. Switches with gold plated bifurcated contacts are
recommended.
3.2 Remove jumper wire between 12A and 12B before connecting auxiliary safeties between these terminals.
3.3 Pilot relays can control cooler and condenser pump and tower fan motor contactor coil loads rated 10 amps at 115 vac up to 3 amps at
600 vac. Control wiring required for Carrier to start pumps and tower
fan motors mustbe providedto assuremachine protection. If primary pump
and tower fan motor are controlled by other means, also provide a parallel
means for control by Carrier. Do not use starter control transformer as the
power source for pilot relay loads.
3.4 Do not route control wiring carrying 30 v or less within a conduit which has
wires carrying 50 v or higher or alongside wires carrying 50 v or higher.
3.5 Voltage selector switch in machine power panel is factory set for 115 v
control power source. When 230 v control power source is used, set switch
to 230 v position.
3.6 Control wiring cables between starter and power panel must be shielded
with minimum rating of 600 v, 80 C. Ground shield at starter.
3.7 If optional oil pump circuit breaker is not supplied within the starter enclosure as shown, it must be located within sight of the machine with wiring
routed to suit.
IV. POWER WIRING BETWEEN STARTERAND COMPRESSOR MOTOR
4.0 Low voltage (600 v or less) compressor motors have (6)3⁄4in. terminal
studs (lead connectors not supplied by Carrier). Either 3 or 6 leads
must be runbetween compressormotor andstarter,depending ontype
of motor starter employed. If only 3 leads are required, jumper motor
terminals as follows: 1 to 6, 2 to 4, 3 to 5. Center to center distance
betweenterminals is2
15
⁄16inches.Compressor motorstarter must have
nameplate stamped as conforming with Carrier requirement Z-375.
4.1 When more than one conduit is used to run conductors from starter to
compressor motor terminal box, one conductor from each phase must
be in each conduit to prevent excessive heating. (e.g., conductors to
motor terminals 1,2&3inoneconduit, and those to 4,5&6in
another.)
4.2 Compressor motor power connections can be made through top, top
rear,or sides of compressor motor terminal box using holes cut by contractor to suit conduit. Flexible conduit should be used for the last few
feet to the terminal box for unit vibration isolation. Use of stress cones
or 12 conductors larger than 500 MCM may require an oversize (special) motor terminal box (not supplied by Carrier). Lead connections
between 3-phase motors and their starters must not be insulated until
Carrier personnel have checked compressor and oil pump rotations.
4.3 Compressor motor frame to be grounded in accordance with the NationalElectrical Code (NFPA-70)andapplicablecodes. Means forgrounding compressor motor is a pressure connector for No. 4 to 500 MCM
wire, supplied and located in the back lowerleft side corner of the compressor motor terminal box.
4.4 Do notallow motor terminals to support weight of wire cables.Use cable
supports and strain reliefs as required.
4.5 Use backup wrench when tightening lead connectors to motor terminal
studs. Torque to 45 lb-ft max.
Fig. 28 — 19XR Typical Field Wiring with Optional Unit-Mounted Starter
LEGEND
AWG — American Wire Gage
N.C. — Normally Closed
N.O. — Normally Open
PR — Pilot Relay
RLA — Rated Load Amps
ST — Shunt Trip
TB — Terminal Block
Required Power Wiring
Required Control Wiring
Options Wiring
32
Page 33
LEGEND
NOTES:
I. GENERAL
1.0 Starters shall be designed and manufactured in accordance with
Carrier Engineering Requirement Z-375.
1.1 All field-supplied conductors, devices, field-installation wiring, and termination of conductors and devices must be in compliance with all applicable codes and job specifications.
1.2 The routing of field-installed conduit and conductors and the location
of field-installed devices must not interfere with equipment access or
the reading, adjusting, or servicing of any component.
1.3 Equipment, installation, and all starting and control devices must comply with details in equipment submittal drawings and literature.
1.4 Contacts and switches are shown in the position they would assume
with the circuit deenergized and the chiller shut down.
1.5 WARNING
— Do not use aluminum conductors.
1.6 Installer is responsible for any damage caused by improper wiring between starter and machine.
II. POWER WIRING TO STARTER
2.0 Power conductor rating must meet minimum unit nameplate voltage
and compressor motor RLA.
When (3) conductors are used:
Minimum ampacity per conductor = 1.25 x compressor RLA
When (6) conductors are used:
Minimum ampacity per conductor = 0.721 x compressor RLA
2.1 Lug adapters may be required if installation conditions dictatethat conductorsbe sized beyond the minimumampacity required. Contact starter
supplier for lug information.
2.2 Compressor motor and controls must be grounded by using equipment grounding lugs provided inside starter enclosure.
III. CONTROL WIRING
3.0 Field supplied control conductors to be at least 18 AWG or larger.
3.1 Chilled water and condenser water flow switch contacts, optional remote start device contacts, and optional spare safety device contacts
must have 24 vdc rating. Max current is 60 mA; nominal current is
10 mA. Switches with gold plated bifurcated contacts are
recommended.
3.2 Remove jumper wire between 12A and 12B before connecting auxiliary safeties between these terminals.
3.3 Pilot relays can control cooler and condenser pump and tower fan motor contactor coil loads rated 10 amps at 115 vac up to 3 amps at
600 vac. Control wiring required for Carrier to start pumps and towerfan motors must be provided to assure machine protection. If primary
pump and tower fan motor are controlled by other means, also provide
a parallel means for control by Carrier. Do not use starter control trans-
former as the power source for pilot relay loads.
3.4 Do not route control wiring carrying 30 v or less within a conduit which
has wires carrying 50 v or higher or alongside wires carrying 50 v or
higher.
3.5 Voltage selector switch in machine power panel is factory set for
115v control power source. When 230 v control power source is used,
set switch to 230 v position.
3.6 Control wiringcables between starter and powerpanel mustbe shielded
with minimum rating of 600 v, 80 C. Ground shield at starter.
3.7 If optional oil pump circuit breaker is not supplied within the starter enclosure as shown, it must be located within sight of the machine with
wiring routed to suit.
3.8 For 19XR chillers with free-standing starts, voltage to terminals LL1
and LL2 comes from a control transformer in a starter built to Carrier
specifications. Do not connect an outside source of control power to
thecompressor motorstarter terminals (LL1 and LL2).Anoutside power
source will produce dangerous voltage at the line side of the starter,
because supplying voltage at the transformer secondary terminals produces input level voltage at the transformer primary terminals.
IV. POWER WIRING BETWEEN STARTERAND COMPRESSOR MOTOR
4.0 Low voltage (600 v or less) compressor motors have (6)3⁄4in. terminal
studs (lead connectors not supplied by Carrier). Either 3 or 6 leads
must be runbetween compressormotor andstarter,depending ontype
of motor starter employed. If only 3 leads are required, jumper motor
terminals as follows: 1 to 6, 2 to 4, 3 to 5. Center to center distance
betweenterminals is2
15
⁄16inches.Compressor motorstarter must have
nameplate stamped as conforming with Carrier requirement Z-375.
4.1 When more than one conduit is used to run conductors from starter to
compressor motor terminal box, one conductor from each phase must
be in each conduit to prevent excessive heating. (e.g., conductors to
motor terminals 1,2&3inoneconduit, and those to 4,5&6in
another.)
4.2 Compressor motor power connections can be made through top, top
rear,or sides of compressor motor terminal box using holes cut by contractor to suit conduit. Flexible conduit should be used for the last few
feet to the terminal box for unit vibration isolation. Use of stress cones
or 12 conductors larger than 500 MCM may require an oversize (special) motor terminal box (not supplied by Carrier). Lead connections
between 3-phase motors and their starters must not be insulated until
Carrier personnel have checked compressor and oil pump rotations.
4.3 Compressor motor frame to be grounded in accordance with the NationalElectrical Code (NFPA-70)andapplicablecodes. Means forgrounding compressor motor is a pressure connector for No. 4 to 500 MCM
wire, supplied and located in the back lowerleft side corner of the compressor motor terminal box.
4.4 Do notallow motor terminals to support weight of wire cables.Use cable
supports and strain reliefs as required.
4.5 Use backup wrench when tightening lead connectors to motor terminal
studs. Torque to 45 lb-ft max.
Fig. 29 — 19XR Typical Field Wiring with Free-Standing Starter
IMPORTANT: Wiring shown is typical and not intended to show detail
for a specific installation. Refer to certified field wiring diagrams.
AWG — American Wire Gage
N.C. — Normally Closed
N.O. — Normally Open
PR — Pilot Relay
RLA — Rated Load Amps
SMM — Starter Management
Module
TB — Terminal Block
Required Power Wiring
Required Control Wiring
Options Wiring
33
Page 34
Connect Power Wires to Oil Heater Contactor — Connect
control power wiring between the oil heater contactor terminals and terminals LL1 and LL2 on the field wiring strip
in the compressor motor starter. Refer to Fig. 31 and wiring
label on the machine power panel.
Voltage to terminals LL1 and LL2 comes from a control transformer in a starter built to Carrier specifications. Do not connect an outside source of control power
to the compressor motor starter (terminals LL1 and LL2).
An outside power source will produce dangerous voltage at the line side of the starter, because supplying voltage at the transfomer secondary terminals produces input level voltage at the transformer primary terminals.
Connect Wiringfrom Starter to Power Panel — Connect control wiring from main motor starter to the machine power
panel.All control wiring must use shielded cable. Also, connect the communications cable. Refer to the job wiring diagrams for cable type and cable number. Make sure the control circuit is grounded in accordance withapplicable electrical
codes and instructions on machine control wiring label.
CARRIER COMFORT NETWORK INTERFACE — The
Carrier Comfort Network (CCN) communication bus wiring
is supplied and installed by the electrical contractor. It consists of shielded, 3-conductor cable with drain wire.
The system elements are connected to the communication
bus in a daisy chain arrangement. The positive pin of each
system element communication connector must be wired to
the positive pins of the system element on either side of it.
The negative pins must be wired to the negative pins. The
signal ground pins must be wired to the signal ground pins.
See Fig. 24 for location of the CCN network connector
(COMM1) on the processor module.
NOTE: Conductors and drain wire must be 20 AWG
(American WireGage) minimum stranded, tinned copper. Individual conductors must be insulated with PVC, PVC/
nylon, vinyl, Teflon,or polyethylene.An aluminum/polyester
100% foil shield and an outer jacket of PVC, PVC/nylon,
chrome vinyl, or Teflon with a minimum operating temperature range of −4 F to 140 F (−20 C to 60 C) is required. See
table below for cables that meet the requirements.
MANUFACTURER CABLE NO.
Alpha 2413 or 5463
American A22503
Belden 8772
Columbia 02525
When connecting the CCN communication bus to a system element, a color code system for the entire network is
recommended to simplify installation and checkout. The following color code is recommended:
SIGNAL TYPE
CCN BUS CONDUCTOR
INSULATION COLOR
COMM1 PLUG
PIN NO.
+ Red 1
Ground White 2
− Black 3
If a cable with a differentcolor scheme is selected, a similar color code should be adopted for the entire network.
At each system element, the shields of its communication
bus cables must be tied together. If the communication bus
is entirely within one building, the resulting continuous shield
must be connected to ground at only one single point. See
Fig. 25. If the communication bus cable exits from one building and enters another, the shields must be connected to ground
at the lightening suppressor in each building where the cable
enters or exits the building (one point only).
To connect the 19XR chiller to the network, proceed as
follows (Fig. 24 and 25):
1. Cut power to the PIC control panel.
2. Remove the COMM1 plug from the processor module.
3. Cut a CCN wire and strip the ends of the RED, WHITE,
and BLACK conductors.
4. Using a wirenut, connect the drain wires together.
5. Insert and secure the RED wire to Terminal 1 of the
COMM1 plug.
6. Insert and secure the WHITE wire to Terminal 2 of the
COMM1 plug.
7. Insert and secure the BLACK wire to Terminal 3 of the
COMM1 plug.
8. Mount a terminal strip in a convenient location.
9. Connect the opposite ends of each conductor to separate
terminals on the terminal strip.
10. Cut another CCN wire and strip the ends of the
conductors.
11. Connect the RED wire to the matching location on the
terminal strip.
12. Connect the WHITE wire to the matching location on
the terminal strip.
13. Connect the BLACK wire to the matching location on
the terminal strip.
LEGEND
Factory Wiring
Field Wiring
Oil Pump Terminal
Power Panel Component Terminal
Fig. 30 — Oil Pump Wiring
LEGEND
Field Wiring
Power Panel Component Terminal
NOTE: The voltage selector switch in the machine power panel is
factoryset for 115v control power source. Whena 230 vcontrol power
source is used, set the voltage selector switch at 230 v.
Fig. 31 — Oil Heater and Control Power Wiring
34
Page 35
Install Field Insulation
Protect insulation from weld heat damage and weld
splatter. Cover with wet canvas cover during water
piping installation.
When installing insulation at the jobsite, insulate the fol-
lowing components:
• compressor motor
• cooler shell
• cooler tube sheets
• suction piping
• motor cooling drain
• oil reclaim piping
• oil cooler refrigerant side tubing
• refrigerant liquid line to cooler
NOTE: Insulation of the waterbox covers is applied only at
the jobsite by the contractor.When insulating the covers, make
sure there is access for removal of waterbox covers for servicing (Fig. 32).
Fig. 32 — 19XR Insulation Area
35
Page 36
Page 37
Page 38
Copyright 1997 Carrier Corporation
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 2
Tab 5a
PC 211 Catalog No. 531-940 Printed in U.S.A. Form 19XR-2SI Pg 38 10-97 Replaces: 19XR-1SI
Page 39
INSTALLATION START-UP REQUEST CHECKLIST
Machine Model Number: 19XR Serial Number:
To:
Attn:
Date
Project Name
Carrier Job Number
The following information provides the status of the chiller installation.
YES/NO
(N/A)
DATE TO BE
COMPLETED
1. The machine is level.
2. The machine components are installed and connected in
accordance with the installation instructions.
3. The isolation package and grouting (if necessary)
are installed.
4. The relief valves are piped to the atmosphere.
5. All piping is installed and supported. Direction of flow
is indicated in accordance with the installation instructions
and job prints.
a. Chilled water piping
b. Condenser water piping
c. Waterbox drain piping
d. Pumpout unit condenser piping (if installed)
e. Other
6. Gages are installed as called for on the job prints required
to establish design flow for the cooler and condenser.
a. Water pressure gages IN and OUT
b. Water temperature gages IN and OUT
7. The machine’s starter wiring is complete. The wiring is
installed per installation instructions and certified prints.
a. Power wiring to compressor motor. (Motor leads will
not be taped until the Carrier technician megger tests
the motor.)
b. Oil pump wiring
c. Oil heater/control wiring
d. Other
8. The motor starter has not been supplied by Carrier. It
has been installed according to the manufacturer’s
instructions.
9. The motor starter has not been supplied by Carrier and it
has been checked for proper operation.
COMMENTS:
CL-1
Page 40
TESTING YES/NO
DATE TO BE
COMPLETED
1. The cooling tower fan has been checked for blade pitch and
proper operation.
2. The chilled water and condenser water lines have been:
a. Filled
b. Tested
c. Flushed
d. Vented
e. Strainers cleaned
3. The chilled water and condenser water pumps have been
checked for proper rotation and flow.
4. The following cooling load will be available for start-up:
a. 25%
b. 50%
c. 75%
d. 100%
5. The refrigerant charge is at the machine.
6. Services such as electrical power and control air will be available at start-up.
7. The electrical and mechanical representatives will be available
to assist in commissioning the machine.
8. The customer’s operators will be available to receive instructions for proper operation of the chiller after start-up.
Concerns about the installation/request for additional assistance:
I am aware that the start-up time for a Carrier chiller can take between 2 and 6 days depending on the model of the machine and
the options and accessories used with it.
Your contact at the jobsite will be
Phone number
Beeper number
Fax number
In accordance with our contract, we hereby request the services of your technician to render start-up services per contract terms
for this job on (Date). I understand that the technician’stime will be charged as extra services due to correcting items
in this checklist that are incomplete.
Signature of Purchaser
Signature of Jobsite Supervisor
----------------------------------------------------------------------------------------
CUT ALONG DOTTED LINE CUT ALONG DOTTED LINE
Copyright 1997 Carrier Corporation
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 2
Tab 5a
PC 211 Catalog No. 531-940 Printed in U.S.A. Form 19XR-2SI Pg CL-2 10-97 Replaces: 19XR-1SI
Loading...
