50ZPA
Baset 13 SEER Single ---P ackaged Air Conditioner System
With R---22 Refrigerant Single and Three Phase
2 to 5 Nominal Tons (Sizes 024---060)
Owner’s Information Manual
A05194
Fig. 1 -- Unit 50ZPA
NOTE TO EQUIPMENT OWNER:
For your convenience, please record the model and serial numbers of your new equipment in the spaces
provided. This information, along with the installation data and dealer contact information, will be helpful
should your system require maintenance or service.
UNIT INFORMATION
Model # _____________________________________
Serial # ______________________________________
ACCESSORIES (List type and model #)
_____________________________________________
_____________________________________________
_____________________________________________
NOTE TO INSTALLER:
This manual must be left with the equipment owner.
INSTALLATION INFORMATION
Date Installed ________________________________
DEALERSHIP CONTACT INFORMATION
Company Name_______________________________
Address______________________________________
_____________________________________________
Phone Number _______________________________
Technician Name _____________________________
_____________________________________________
1
SAFETY CONSIDERATIONS
Installation and servicing of this equipment can be hazardous due to
mechanical and electrical components. Only trained and qualified
personnel should install, repair, or service this equipment.
Untrained personnel can perform basic maintenance functions such
as cleaning and replacing air filters. All other operations must be
performed by trained service personnel. When working on this
equipment, observe precautions in the literature, on tags, and on labels attached to or shipped with the unit and other safety precautions
that may apply.
Follow all safety codes. Installation must be in compliance with local and national building codes. Wear safety glasses, protective
clothing, and work gloves. Have fire extinguisher available. Read
these instructions thoroughly and follow all warnings or cautions
included in literature and attached to the unit.
Recognize safety information. This is the safety--alert symbol
Whenyou see this symbolon theunitandininstructions or manuals,
be alert to the potential for personal injury.
Understand thesesignalwords: DANGER, WARNING,and CAUTION. These words are u sed with the safety--alert symbol. DANGER identifies the most serious hazards which will result in severe
personal injury or death. WARNING signifies hazards which could
result in personalinjury or death. CAUTION is used to identify unsafe practices which may resultin minor personal injury or product
and propertydamage. NOTE isused to highlight suggestionswhich
will result in enhanced installation, reliability, or operation.
Note: Installer:This manual should be left with theequipment user.
!
ELECTRICAL SHOCK AND OPERATION HAZARD
Failure to follow this warning could result in personal injury,
death or property damage.
Do not use this unit if any part has been underwater.
Immediately call a qualified service technician to inspect the
unit and to replace any part of the control system which has
been underwater.
!
ELECTRICAL SHOCK AND CUT HAZARD
Failure to follow this warning could result in personal injury,
death or property damage.
When removing access panels or performing maintenance
functions inside your unit, be aware of sharp sheetmetal parts
and screws. Although special care is taken to reduce sharp
edges to a minimum, be extremely careful when handling
parts or reaching into the unit.
1. Turn on the electrical power supply to the unit.
2. Select temperature and set system switch to desired mode.
WARNING
WARNING
TO START UNIT:
TO SHUT OFF UNIT:
Note: If the unit is being shut down because of a malfunction, call
your dealer as soon as possible.
1. Set the temperature switch to OFF.
2. Turn off the electrical power supply to unit.
ROUTINE MAINTENANCE
All routine maintenance should be handled by skilled, experienced
personnel. Yourdealer can help you establish a standardprocedure.
For your safety, keep the unit area clear and free of combustible
materials, gasoline, and other flammable liquids and vapors.
To assure proper functioning of the unit,flow of condenser air must
not be obstructed from reaching the unit. Clearance from the top of
the unit is 48 in. (1219 mm). Clearance of at least 36 in. (914 mm)
is required on sides except the power entry side (42 in. [1067 mm]
clearance) and the duct side (12 in. [305 mm] minimum clearance).
Maintenance and Care for the Equipment Owner
!
!
Before proceeding with those things you might want to maintain
yourself, please carefully consider the following:
!
FIRE, EXPLOSION, ELECTRICAL SHOCK AND
CUT HAZARD
Failure to follow this warning could result in personal injury,
death or property damage.
1. TURN OFF ELECTRICAL POWER TO YOUR UNIT
BEFORE SERVICING OR PERFORMING
MAINTENANCE.
2. When removing access panels or performing maintenance
functions inside your unit, be aware of sharp sheet metal
parts and screws. Although special care is taken to reduce
sharp edges to a minimum, be extremely careful when
handling parts or reaching into the unit.
Air Filters
The air filter(s) should be checked every 3 or 4 weeks and changed
or cleaned whenever it becomes dirty. Dirty filters produce excessive stress on the blower motor and can cause the motor to overheat
and shut down.
This unit must have air filters in place before it can be operated.
These filters can be located in one of at least two places. In many
applications, the installer will provide return air filter grilles
mounted on the wall or ceiling of the conditioned structure. In the
instance of filter grilles, the filters can simply be removed from the
grille and replaced.
The other typical application is an accessory filter rack installed
inside the unit itself. The following information is given to assist
in changing filters used in these internal filter racks.
Table 1 indicates the correct indoor filter size for your unit.
Unit Size Filter Size
024--- 036 24x24x1 (610x610x25 mm)
042--- 060 30x30x1 (762x762x25 mm)
If you have difficulty locating your air filter(s) or have questions
concerning proper filter maintenance, contact your dealer for
instructions. When replacing filters, always use the same size and
type of filter that was supplied, originally, by the installer.
WARNING
Table 1—Indoor Air Filter Data
2
!
UNIT OPERATION HAZARD
Failure to follow this caution may result in property damage.
Never operate your unit without filters in place. An
accumulation of dust and lint on internal parts of your unit can
cause loss of efficiency.
Fans and Fan Motors
Periodically check the condition of fan wheels and housings and
fan--motor shaft bearings. No lubrication of condenser--or
evaporator--fan bearings or motors is required or recommended.
Indoor and Outdoor
Cleaning of the coils should only be done by qualified service personnel. Contact your dealer for the required annual maintenance.
Condensate
The drain pan and condensate drain line should be checked and
cleaned at the same time the cooling coils are checkedby yourdealer.
Compressor
All compressors are factoryshipped with a normalchargeof the correcttype of refrigeration grade oil in them and should rarely require
additional oil.
Condenser
Drain
Fan
!
PERSONAL INJURY AND UNIT DAMAGE HAZARD
Failure to follow this warning could result in personal injury,
death or property damage.
Do not insert sticks, screwdrivers, or any other object into
revolving fan blades.
The fan must be kept free of all obstructions to ensure proper cooling. Contact your dealer for any required service.
Electrical Controls and W
Electrical controls are difficultto checkwithout proper instrumentation. If there are any discrepancies in the operating cycle, contact
your local dealer and request service.
Refrigerant
Therefrigerant circuit isdifficultto check forleakswithout the proper equipment.If inadequate cooling is suspected, contactyour local
dealer for service.
Circuit
!
EXPLOSION AND ENVIRONMENTAL HAZARD
Failure to follow this warning could result in personal injury,
death or property damage.
System under pressure. Relieve pressure and recover all
refrigerant before system repair or final unit disposal. Use all
service ports and open all flow--control devices, including
solenoid valves.
CAUTION
Coils
WARNING
iring
WARNING
REGULAR DEALER MAINTENANCE
In addition to the type of routine maintenance you might be willing
to perform, your unit should be inspected regularly by a properly
trained service technician. An inspection (preferably each year, but
at least every other year) should include the following:
1. Inspection and, if required, cleaning of the indoor coil
condensate drain.
2. Inspection and, if required, cleaning of the evaporator drain
pan.
3. Inspection and cleaningof blowerwheelhousing and motor.
4. Inspection of all supply--air and return--air ducts for leaks,
obstructions, and insulation integrity. Any problems found
should be resolved at this time.
5. Inspectionof theunit base to ensure thatno cracks, gaps,etc.,
exist which may cause a hazardous condition.
6. Inspection of the unit casing for signs of deterioration.
7. Inspection of all electrical wiring and components to ensure
proper connection.
8. Inspection for leaksin the refrigerant circuit. Pressure-- check
to determine appropriate refrigerant charge.
9. Inspection of compressor oil level by service person to
ensureproper oil level is maintained in the compressor when
it is installed and running.
10. Operational check of the unit to determine working
conditions.Repair or adjustment shouldbe madeatthistime.
Your servicing dealer may offer an economical service contractthat
covers seasonal inspections. Ask for further details.
Completeservice instructions can be found in the unit Installation,
Start--up and Service Instructions.
Warranty Certificate
Your 50ZPA unithas a limitedwarranty. Be suretoreadthe warranty
carefully to determine the coverage for your unit.
Before you call for service...
...check for several easily --solved problems.
If insufficient heating or cooling is suspected:
( ) Check for sufficient airflow.
( ) Check the air filter for dirt.
( ) Check for blocked return--air or supply--air grilles. Be sure they
are open and unobstructed. If these checks do not reveal the cause,
call your servicing dealer.
If your unit is not operating at all, check the following list for
easy solutions:
( ) Check to be sure that your thermostattemperature selector is set
belowthe indoor temperatureduringthecooling season.Be sure the
SYSTEM switch or MODE control is in the COOL position and
not in the OFF position.
( ) If your unit still fails to operate, call your servicing dealer for
troubleshooting and repairs. Specify the model and serial numbers
of your unit. (Record them in this manual in the space provided.) If
the dealer knows exactly which unit you have, he may be able to
offer suggestions over the phone, or save valuable time through
knowledgeable preparation for the service call.
In Case of Trouble
If you perform the stepsabove and unit performance is still unsatisfactory, shut off the unit and call your dealer.
Unit Panels
Afterperforming any maintenanceor serviceon theunit,be sure all
panels are fastened securely in place to prevent rain from entering
unit cabinet and topreventdisruption of the correctunit airflow pattern.
Dealer’s Name
Telephone
Unit Model
Unit Serial Number
3
HEATING & COOLING
TO OBTAIN INFORMATION ON PARTS: Consult your installing dealer or classified section of your local telephone directory under the
“Heating Equipment” or “Air Conditioning Contractors & Systems” heading for dealer listing by brand name.
Have available the Model No., Series Letter, & Serial No. of your equipment to ensure correct replacement part.
Copyright 2008 Carrier Corporation Printed in the U.S.A. Edition Date: 02/08
Manufacturer reserves the right to change, at any time, specifications and design without notice and without obligation.
Catalog No: OM50ZPA--- 01
R e p l a c e s : OM 5 0 --- 4 0
4
Loading...
