Carrier 24ABA4, Base 24ABA418, Base 24ABA424, Base 24ABA430, Base 24ABA436 Product Data

24ABA4
BasetSeries 14 Air Conditioner
with Puronr Refrigerant

Product Data

the environmentally sound refrigerant

Carrier’s Air Conditioners with Puronr refrigerant provide a
collection of features u nm atched by any other family o f
equipment. The 24ABA has been designed utilizing Carrier’s
Puron refrigerant. The environmentally sound refrigerant allows
you to make a responsible decision in the protection of the earth’s
ozone layer. Carrier’s air conditioning system with Puron
refrigerant meets the Energy Star r guidelines for energy
efficiency.

A04030

INDUSTRY LEADING
FEATURES / BENEFITS

Efficiency

14 SEER/11 EER

S
S

Microtube Technologyt refrigeration system

S

Indoor air quality accessories available

Sound

Sound level as low as 76 dBA

S

Comfort

System supports Thermidistatt or standard thermostat

S

controls

Reliability

S

Puronr refrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime servce cost.

S

Front--seating service valves

S

Scroll compressor

S

Internal pressure relief valve

S

Internal thermal overload

S

Filter drier

S

Balanced refrigeration system for maximum reliability

Durability

WeatherArmort protection package:

S

Solid, Durable sheet metal construction

S

Dense wire coil guard

S

Baked--on, complete coverage, powder paint

Applications

Long--line -- up to 250 feet total equivalent length, up

S

to 200 feet condenser above evaporator, or up to 80 ft.
evaporator above condenser (See Longline Guide for
more information.)

S

Low ambient (down to --20_F) with accessory kit

Warranty

5 year limited compressor warranty

S
S

5 year limited parts warranty

MODEL NUMBER NOMENCLATURE

12 3 4 5 6 78 9 10 11 12 13

N N A A A/N N N N A/N A/N A/N N N

24 A B A 4 36 A 0 0 3 0

Product

Series

24=AC A=RES AC B=Base A=Puron 4=14 SEER A=Standard

Product

Famil y

the environmentally sound refrigerant

Tier

Major

Series

SEER

T

O

D

E

A

I

R

F

I

I

T

R

E

C

R

A

I

R

E

C

R

O

Y

U

R

A

T

T

I

C

N

A

U

F

U

N

A

M

E

T

Q

N

U

E

I

P

M

A

R

I

S

D

T

A

R

N

A

D

Cooling

Capacity

A

S

C

O

M

P

L

N

D

Y

I

T

I

N

I

O

G

N

I

N

W

G

I

T

H

0

1

2

Variations Open Open Voltage Series

0=Not

Defined

ISO 9001:2000

REGISTERED

0=Not

Defined

3=208/230--- 1

24ABA4

STANDARD FEATURES

Feature 18 24 30 36 42 48 60

Puron Refrigerant X X X X X X X

14 SEER X X X X X X X

Scroll Compressor X X X X X X X

DenseWireCoilGuard X X X X X X X

FieldInstalledFilterDrier X X X X X X X

Front Seating Service Valves X X X X X X X

Internal Pressure Relief Valve X X X X X X X

Internal Thermal Overload X X X X X X X

Long Line capability X X X X X X X

Low Ambient capability with Kit X X X X X X X

0=

Original

Series

2

PHYSICAL DATA

UNIT SIZE SERIES 18 --- 30 24 --- 30 30 --- 30 36 --- 30 42 --- 30 48 --- 30 60 ---30
Operating Weight (lb) 171 185 188 191 237 239 295
Shipping Weight (lb) 199 214 217 225 272 272 330
Compressor Type Scroll
REFRIGERANT Puron® (R--- 410A)

Control TXV (Puron® Hard Shutoff)
Charge (lb) 5.7 7.25 7.1 7.25 10.9 11 13.9

COND FAN Propeller Type, Direct Drive

Air Discharge Vertical
Air Qty (CFM) 2235 2615 3170 3800 3800 3800 4050
Motor HP 1/12 1/10 1/5 1/5 1/5 1/5 1/5
Motor RPM 800 1100 1100 800 800 800 800

COND COIL

Face Area (Sq ft) 19.40 23.71 23.71 22.63 30.18 20.12 30.18
Fins per In. 25 25 25 25 25 20 20
Rows 1 1 1 1 1 2 2
Circuits 3 4 4 5 7 7 7

VALVECONNECT.(In.ID)

Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8 3/8 3/8 3/8 3/8 3/8 3/8

REFRIGERANT TUBES* (In. OD)

Vapor (0 --- 50 Ft Tube Length) 5/8 3/4 7/8 1 --- 1 / 8
Vapor(MaxDiameterfor

long--- Line applications
Liquid (0--- 50 Ft Tube Length) 3/8”
Liquid (For Long ---Line

applications)

* For tubing sets between 80 and 200 ft. horizontal or 20 ft. vertical differential, consult the Longline Guideline.

Note: See unit Installation Instruction for proper installation.

3/4 7/8 1 --- 1 / 8 1 --- 1 / 8

3/8”

VAPOR LINE SIZING AND COOLING CAPACITY LOSS
PURON 1--STAGE AIR CONDITIONER APPLICATIONS

LONG LINE APPLICATION: An application is considered
”Long line” when the total equivalent tubing length exceeds 80 ft
or when there is more than 20 Ft vertical separation between
indoor and outdoor units. These applications require additional
accessories and system modifications for reliable system
operation. The maximum allowable total equivalent length is
250Ft. The maximum vertical separation is 200 Ft when outdoor

Unit Nominal Size

(Btuh)

18000

1StagePuronAC

24000

1StagePuronAC

30000

1StagePuronAC

36000

1StagePuronAC

42000

1StagePuronAC

48000

1StagePuronAC

60000

1StagePuronAC

Standard Length = 80 Ft or less total equivalvent length
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines

Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See Long Line Application
Guidelines

Acceptable

Vapor Line

Diameters

(In. OD)

1/2 1 2 4 4 5 6 7 8 10 11 12
5/8 0 1 1 1 2 2 2 3 3 3 4
5/8 1 1 2 2 3 3 4 4 5 6 6

3/4 0 1 1 1 1 1 1 2 2 2 2
7/8 0 0 0 0 1 1 1 1 1 1 1
5/8 1 2 3 3 4 5 6 7 8 9 9
3/4 0 1 1 1 1 2 2 3 3 3 4
7/8 0 0 1 1 1 1 1 1 1 2 2
5/8 1 3 4 4 5 7 8 9 11 12 13
3/4 1 1 2 2 2 3 3 3 4 4 5
7/8 0 1 1 1 1 1 2 2 2 2 3
3/4 1 1 2 2 3 3 4 5 5 6 7
7/8 0 1 1 1 1 2 2 2 3 3 3

11/8 0 0 0 0 0 1 1 1 1 1 1

3/4 1 2 3 3 3 4 5 6 7 8 8
7/8 0 1 1 1 2 2 3 3 3 4 4

11/8 0 0 0 0 1 1 1 1 1 1 1

3/4 1 3 4 4 5 6 8 9 10 11 13
7/8 1 1 2 2 3 3 4 4 5 6 6

11/8 0 0 1 1 1 1 1 1 1 2 2

Standard Application Long Line Application Requires Accessories

25 50 80 80+ 100 125 150 175 200 225 250

unit is above indoor unit, and 50 Ft when the outdoor unit is
below the indoor unit. Refer to Accessory Usage Guideline below
for required accessories. See Long-- Line Application Guideline
for required piping and system modifications. Also, refer to the
table below for the acceptable vapor tube diameters based on the
total length to minimize the cooling capacity loss.

Cooling Capacity Loss (%)

Total Equivalent Line Length (ft)

24ABA4

3

ACCESSORY THERMOSTATS

THERMOSTAT / SUBBASE PKG. DESCRIPTION

TSTATCCPRH01--- B Thermidistat Control --- Programmable / Non--- Programmable Thermostat with Humidity control

TSTATCCPAC01---B Th e r mo s t at --- A u to C h a n g e o v e r, 7 --- D ay P r o g r a m m a b l e, _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l

TSTATCCNAC01--- C T h e r m os t a t --- A u t o C h a n g e o v e r, N o n --- P r o g r a m m a b le , _F/_C , 1 --- S t a g e H e a t, 1 --- S ta g e C oo l

TSTATCCBAC01--- B Builder’s Thermostat --- Manual Changeover, Non---Programmable, _F/_C , 1 --- S t a ge H e a t , 1 --- S t a g e C o ol

TSTATCCSEN01--- B Outdoor Air Temperature Sensor

TSTATXXBBP01 Backplate for Builder’s Thermostat

TSTATXXNBP01 Backplate for Non --- Programmable Thermostat

TSTATXXPBP01 Backplate for Programmable Thermostat

TSTATXXCNV10 Thermostat Conversion Kit (4 to 5 wires) --- 10 Pack

ACCESSORIES

KIT NUMBER DESCRIPTION 18 --- 30 24- -- 30 30--- 30 36- -- 30 42-- -30 48 --- 30 60 --- 30

KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X

KAATD0101TDR TIME DELAY RELAY X X X X X X X

KAAWS0101AAA WINTER START X X X X X X X

KSALA0301410 LOW AMBIENT PSW X X X X X X X

24ABA4

KSALA0601AAA MOTORMASTER 230V X X X X X X X

HC32GE234 MOTOR FAN BALL BEARING X

HC34GE239 MOTOR FAN BALL BEARING X X

HC40GE226 MOTOR FAN BALL BEARING X X

HC38GE219 MOTOR FAN BALL BEARING X

HC40GE228 MOTOR FAN BALL BEARING X

KSAHS1701AAA HARD START (CAP / RELAY) X X X X X X X

KSACY0101AAA CYCLE PROTECTOR X X X X X X X

KSASF0101AAA SUPPORT FEET X X X X X X X

KAACS0201PTC START ASSIST PTC X X X X X X X

KAACH1201AAA CRANKCASE HTR X X X

KAACH1401AAA CRANKCASE HTR X X X X

KSATX0201PUR TXV PURON HSO X X X

KSATX0301PUR TXV PURON HSO X X

KSATX0401PUR TXV PURON HSO X

KSATX0501PUR TXV PURON HSO X

KSASH0601COP SOUND HOOD X X X X X X

KSASH2101COP SOUND HOOD X

KAALP0301PUR LOW PRESSURE SWITCH X X X X X X X

KAAHI0401PUR HIGH PRESSURE SWITCH X X X X X X X

x = Accessory

ACCESSORY USAGE GUIDELINE

REQUIRED FOR

LONG LINE

APPLICATIONS*

(Over 80 Ft.)

ACCESSORY

REQUIRED FOR LOW---AMBIENT

COOLING APPLICATIONS

(Below 55° F)

Crankcase Heater Yes Yes No

Evaporator Freeze Thermostat Yes No No

Accumulator No No No

Compressor Start Assist Capacitor and Relay Ye s Yes No

Motor Master®Control or Low---ambient

Pressure Switch

Yes No No

Support Feet Recommended No Recommended

Liquid Line Solenoid Valve No

S e e L o n g --- L in e A p -

plication Guideline

Ball Bearing Fan Motor Yes { No No

* For tubing line sets between 80 and 200 ft. and/or 20 ft. vertical differntial, refer to Residential Split---System Longline Application Guideline.
{ Required for Low ---Ambient Controller (full modulation feature) an d MotorMasterr Control only.

REQUIRED FOR

SEA COAST
APPLICATIONS
(Within 2 miles)

No

4

Accessory Description and Usage (Listed Alphabetically)

1. Ball--Bearing Fan Motor

A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.

Usage Guideline:

Required on all units when MotorMasterr —

2. Compressor Start Assist -- Capacitor and Relay

Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.

Usage Guideline:

Required for reciprocating compressors in the
following applications:

Long line
Low ambient cooling

Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil

Required for single--phase scroll compressors in the
following applications:

Long line

Low ambient cooling

Suggested for all compressors in areas with a history of
low voltage problems.

3. Compressor Start Assist — PTC Type

Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.

Usage Guideline:

Suggested in installations with marginal power supply.

4. Crankcase Heater

An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.

Usage Guideline:

Required in low ambient cooling applications.

Required in long line applications.

5. Cycle Protector

The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5 -- minute delay
after power to the compressor has been interrupted for any
reason, including power outage, protector control trip, thermostat
jiggling, or normal cycling.

Suggested in all commercial applications.

6. Evaporator Freeze Thermostat

An SPST temperature-- actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.

Usage Guideline:

Required when low ambient kit has been added.

7. Low--Ambient Pressure Switch Kit

A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low-- ambient temperatures down to 0_F
when properly installed.

Usage Guideline:

A Low-- Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling
operation is used at outdoor temperatures below 55_F
(12.8_C).

8. MotorMasterr Low--Ambient Controller

A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F ±10_F (37.8_C ±

-- 1 2 _C).

Usage Guideline:

A MotorMasterr Low Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).

Suggested for all commercial applications.

9. Outdoor Air Temperature Sensor

Designed for use with Carrier Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also is required to enable
special thermostat features such as auxiliary heat lock out.

Usage Guideline:

Suggested for all Carrier thermostats listed in this
publication.

10. Sound Hood

Wraparound sound reducing cover for the compressor. Reduces
the sound level up to 2 dBA.

Usage Guideline:

Suggested when unit is installed closer than 15 ft to
quiet areas, bedrooms, etc.

Suggested when unit is installed between two houses less
than 10 ft apart.

11. Support Feet

Four stick--on plastic feet that raise the unit 4 in. above the
mounting pad. This allows sand, dirt, and other debris to be
flushed from the unit base, minimizing corrosion.

Usage Guideline:
Suggested in the following applications:

Coastal installations.
Windy areas or where debris is normally circulating.

Rooftop installations.
For improved sound ratings.

12. Thermostatic Expansion Valve (TXV)

A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.

Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.

NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.

Usage Guideline:

Required to achieve ARI ratings in certain equipment
combinations. Refer to combination ratings.

Hard shut off TXV or LLS required in air conditioner
long line applications.

Required for use on all zoning systems.

24ABA4

5

Accessory Description and Usage (Listed Alphabetically) -- Continued

13. Time--Delay Relay

An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.

NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.

Usage Guideline:

14. Winter Start Control

This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.

For improved efficiency ratings for certain
combinations of indoor and outdoor units. Refer to
ARI Unitary Directory.

ELECTRICAL DATA

OPER

UNIT SIZE V/PH

18
24 58.3 13.5 0.7 17.6 14 14 45 43 25
30 73.0 14.1 1.1 18.7 14 14 42 40 30
36 79.0 16.7 1.2 22.0 12 12 57 54 35
42 112.0 17.9 1.2 23.6 10 10 85 81 40
48 117.0 21.8 1.2 28.4 10 10 70 67 40
60 134.0 26.4 1.2 34.2 8 8 91 86 50

* Permissibl e limits of the voltage r ange at which the unit will operate satisfactorily

24ABA4

{ If wire is applied at ambient greater than 30˚ C(86˚ F), consult table 310---16 of the NEC (ANSI/NFPA 70). The ampacity of non ---metallic---sheathed cable

(NM), trade name ROMEX, shall be that of 60˚ C (140˚ F) conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If other than uncoated (no---plated), 60
or 75˚ C (140 or 167˚ C) insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables
of the NEC (ANSI/NFPA 70).

} Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
** Time---Delay fuse.

FLA --- F u l l L oad A m p s
LRA --- L o c k e d Ro t o r A m p s
MCA --- Minimum Circuit Amps
RLA --- RatedLoadAmps
NOTE: Control circuit is 24 --- V on all units and requires external power source. Copper wire must be used from service disconnect to unit.

All motors/compressors contain internal overload protection.

208/230/1 253 197

VOLTS*

MAX MIN LRA RLA FLA

COMPR FAN

48.0 9.0 0.5 11.7 14 14 67 64 15

MCA

MIN WIRE

SIZE{

60° C

MIN WIRE

SIZE{

75° C

MAX

LENGTH

(FT)}
60° C

MAX

LENGTH

(FT)}
75° C

MAX FUSE**

or CKT BRK

AMPS

A--WEIGHTED SOUND POWER (DBA)

UNIT SIZE

18 76 56.0 60.0 65.0 72.0 65.0 60.5 53.5
24 76 52.5 62.5 66.0 69.5 66.5 62.0 57.0
30 76 53.5 64.5 69.0 70.0 68.5 66.0 59.5
36 76 52.0 60.0 65.5 69.5 64.0 63.0 56.0
42 77 50.5 58.5 63.0 72.0 66.0 62.5 57.5
48 78 58.0 64.5 66.5 69.0 65.0 63.5 59.0
60 78 53.5 67.0 65.5 67.5 65.5 63.0 60.0

STANDARD

RATING

125 250 500 1000 2000 4000 8000

TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)

A--WEIGHTED SOUND POWER (DBA) WITH ACCESSORY SOUND HOOD

UNIT SIZE

18 74 56.0 60.0 65.0 69.0 63.0 60.0 52.5
24 74 52.0 62.0 66.5 68.5 66.0 61.0 56.5
30 75 53.5 64.5 69.0 69.5 68.0 65.5 59.0
36 75 52.0 62.0 65.5 67.5 63.0 61.0 53.5
42 75 51.0 60.0 62.5 68.5 64.0 61.0 55.0
48 75 59.5 63.5 66.5 67.5 64.0 62.0 55.5
60 75 54.0 63.5 65.0 66.0 63.5 61.0 57.0

STANDARD

RATING

125 250 500 1000 2000 4000 8000

TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)

CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)

UNIT SIZE ---SERIES REQUIRED SUBCOOLING (_F)

18--- 30 10

24--- 30 11

30--- 30 8

36--- 30 10

42--- 30 12

48--- 30 9

60--- 30 9

6

24ABA4

1. Allow 30” clearance to service side of unit, 48” above unit, 6” on one side, 12”

on remaining side, and 24” between units for proper airflow.

2. Minimum outdoor operating ambient in cooling mode is 55 _F, max. 125_ F.

3. Series d esignation is the 13th position of the unit model number.

(Professional Engineer), if required.

4. Center o f gravity

5. For hurricane tie downs, contact distributor for details and PE Certification

A B C D E F G H J K L M N P

X=YES

0=NO

ELECTRI CAL

CHARACTERISTICS

UNIT SERIES

24ABA418 0 X 0 0 0 31 3/16” 35 3/4” 33/4” 5/8” 6 9/16” 24 11/16” 91/8” 5/16” 3” 2 13/16” 1/2” 16 1/4” 16” 16 5/8”

24ABA424 0 X 0 0 0 31 3/16” 42 1/2” 33/4” 5/8” 6 9/16” 24 11/16” 91/8” 5/16” 3” 2 13/16” 1/2” 16” 16” 19”

24ABA430 0 X 0 0 0 31 3/16” 42 1/2” 33/4” 3/4” 6 9/16” 24 11/16” 91/8” 5/16” 3” 2 13/16” 1/2” 14 7/8” 15 1/4” 19 3/8”

24ABA436 0 X 0 0 0 35” 35 3/4” 33/4” 3/4” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 13/16” 1/2” 18 1/4” 18 1/2” 17 1/2”

24ABA442 0 X 0 0 0 35” 45 5/16” 37/8” 7/8” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 15/16” 5/8” 18 3/4” 17” 20 7/8”

24ABA448 0 X 0 0 0 35” 32 5/16” 37/8” 7/8” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 15/16” 5/8” 17 3/4” 18 3/4” 15 1/2”

DIMENSIONS

24ABA460 0 X 0 0 0 35” 45 15/16” 37/8” 7/8” 6 9/16” 28 7/16” 91/8” 5/16” 3” 2 15/16” 5/8” 17 7/8” 18 5/8” 20 1/4”

4 6 0 --- 3 --- 6 0

208/230--- 3 ---60

2 3 0 --- 1 --- 6 0

2 0 8 --- 2 3 0 --- 1 --- 6 0

PAD DIMENSIONS

MINIMUM MOUNTING

— 26” X 26”

18, 24, 30, 31 1/2” X 31 1/2”

UNIT SIZE

36, 42, 48, 60 35” X 35”

7

COMBINATION RATINGS

Unit Size

--- S e r i e s

Indoor Model To t a l C a p . B T UH

*CAP**2414A** 18,000 TXV 14.00 11.5

CAP**1814A** 17,600 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12
CAP**1814A** 17,800 TXV 13.50 11.20

CAP**2414A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070--- 12

CAP**2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16
CAP**2417A** 17,900 TDR&TXV 15.00 13.00 58MVB060 ---14
CAP**2417A** 18,000 TXV 14.00 11.50

CNPF*2418A** 18,000 TXV 13.50 11.20

CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070 ---12
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090 ---16
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB040---14
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB060---14
CNPH*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB080---14
CNPH*2417A** 18,000 TXV 13.50 11.20

Factory Supplied

Enhancement

Standard

Rating

SEER

TDR†

EER Furnace Model

24ABA4

18---30

24---30

CNPV*1814A** 17,600 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12
CNPV*1814A** 17,800 TXV 13.50 11.20

CNPV*2414A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070--- 12
CNPV*2414A** 18,000 TXV 14.00 11.50

CNPV*2417A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16
CNPV*2417A** 17,900 TDR&TXV 15.00 13.00 58MVB060---14
CNPV*2417A** 18,000 TXV 13.50 11.20

CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)070--- 12
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58MVB040 ---14
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58MVB060 ---14
CSPH*2412A** 17,900 TDR&TXV 15.00 13.00 58MVB080 ---14
CSPH*2412A** 18,000 TXV 14.00 11.50

FF1ENP018 17,800 TDR&TXV 13.50 11.20
FF1ENP024 18,000 TDR&TXV 13.50 11.20
FV4BNF002 18,200 TDR&TXV 15.00 13.20
FX4CNF018 18,000 TDR&TXV 15.00 13.00
FX4CNF024 18,300 TDR&TXV 15.00 13.00
FY4ANF018 17,800 TDR&TXV 13.50 11.20

FY4ANF024 17,900 TDR&TXV 13.50 11.20
CAP**2414A** 23,600 TXV 14.00 11.50
CAP**2414A** 23,200 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12

CAP**2417A** 23,600 TXV 14.00 11.50
CAP**2417A** 23,400 TDR&TXV 15.00 12.50 58MVB060 ---14

*CAP**3014A** 24,000 TXV 14.00 11.5

CAP**3014A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)070--- 12

CAP**3017A** 24,000 TXV 14.00 11.50
CAP**3017A** 24,400 TDR&TXV 15.00 13.00 58MVB060 ---14
CAP**3017A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16

CNPV*2414A** 23,600 TXV 14.00 11.50
CNPV*2414A** 23,200 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12

CNPV*2417A** 23,600 TXV 14.00 11.50
CNPV*2417A** 23,400 TDR&TXV 15.00 12.50 58MVB060---14
CNPV*2417A** 23,600 TDR&TXV 15.00 12.50 58CV(A,X)090--- 16

CNPV*3014A** 24,000 TXV 14.00 11.50
CNPV*3014A** 24,400 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12

CNPV*3017A** 24,000 TXV 14.00 11.50
CNPV*3017A** 24,400 TDR&TXV 15.00 13.00 58MVB060---14
CNPV*3017A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16

See notes on pg. 13

8

COMBINATION RATINGS -- CONTINUED

U n i t S i z e ---

Series

24---30

Indoor Model To t a l C a p . B T UH

CNPH*2417A** 23,600 TXV 14.00 11.50
CNPH*2417A** 23,400 TDR&TXV 15.00 12.50 58MVB040---14
CNPH*2417A** 23,400 TDR&TXV 15.00 12.50 58CV(A,X)070 ---12

CNPH*3017A** 24,000 TXV 14.00 11.50
CNPH*3017A** 24,400 TDR&TXV 15.00 13.00 58MVB040---14
CNPH*3017A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)070 ---12

CNPF*2418A** 23,600 TXV 14.00 11.50

CSPH*2412A** 23,600 TXV 14.00 11.50
CSPH*2412A** 23,200 TDR&TXV 15.00 12.50 58MVB040 ---14
CSPH*2412A** 23,200 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12
CSPH*2412A** 23,200 TDR&TXV 15.00 13.00 58CV(A,X)110--- 20
CSPH*2412A** 23,200 TDR&TXV 15.00 13.00 58CV(A,X)135--- 22
CSPH*2412A** 23,200 TDR&TXV 15.00 13.00 58CV(A,X)155--- 22

CSPH*3012A** 24,000 TXV 14.00 11.50
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB040 ---14
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB060 ---14
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB080 ---14
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB080 ---20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB100 ---20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58MVB120 ---20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)070--- 12
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)110--- 20
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)135--- 22
CSPH*3012A** 24,400 TDR&TXV 15.00 13.00 58CV(A,X)155--- 22

Factory Supplied

Enhancement

Standard

Rating

SEER

TDR†

EER Furnace Model

24ABA4

30---30

FY4ANF024 23,400 TDR&TXV 13.50 11.20

FY4ANF030 23,600 TDR&TXV 14.00 11.50

FX4CNF024 23,800 TDR&TXV 15.00 12.50

FX4CNF030 24,000 TDR&TXV 15.00 13.00

FF1ENP024 23,400 TDR&TXV 13.50 11.20

FF1ENP030 23,400 TDR&TXV 13.50 11.20

FV4BNF002 23,800 TDR&TXV 15.00 13.00

FV4BNF003 23,800 TDR&TXV 15.00 13.20

*CAP**3014A** 29,000 TXV 14.00 12

CAP**3014A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12

CAP**3017A** 29,000 TXV 14.00 11.50
CAP**3017A** 28,800 TDR&TXV 15.00 12.50 58MVB060 --- 14
CAP**3017A** 28,800 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16

CAP**3614A** 28,200 TXV 14.00 11.50
CAP**3614A** 27,800 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12

CAP**3617A** 29,200 TXV 14.00 11.50
CAP**3617A** 28,800 TDR&TXV 15.00 13.00 58MVB060 --- 14
CAP**3617A** 29,000 TDR&TXV 15.00 13.00 58CV(A,X)090--- 16

CAP**3621A** 29,200 TXV 14.00 11.50
CAP**3621A** 29,000 TDR&TXV 15.00 12.50 58MVB080 --- 14
CAP**3621A** 29,000 TDR&TXV 15.00 13.00 58CV(A,X)110--- 20

CNPV*3014A** 29,000 TXV 14.00 11.50
CNPV*3014A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12

CNPV*3017A** 29,000 TXV 14.00 11.50
CNPV*3017A** 28,800 TDR&TXV 15.00 12.50 58MVB060---14
CNPV*3017A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)090--- 16

CNPV*3617A** 29,200 TXV 14.00 11.50
CNPV*3617A** 28,800 TDR&TXV 15.00 12.50 58MVB060---14
CNPV*3617A** 29,000 TDR&TXV 15.00 12.50 58CV(A,X)090--- 16

CNPV*3621A** 29,200 TXV 14.00 11.50
CNPV*3621A** 29,000 TDR&TXV 15.00 12.50 58MVB080---14
CNPV*3621A** 29,000 TDR&TXV 15.00 12.50 58CV(A,X)110--- 20

See notes on pg. 13

9

COMBINATION RATINGS -- CONTINUED

U n i t S i z e ---

24ABA4

Series

30---30

Indoor Model To t a l C a p . B T UH

CNPH*3017A** 29,000 TXV 14.00 11.50
CNPH*3017A** 28,800 TDR&TXV 15.00 12.50 58MVB040---14
CNPH*3017A** 28,800 TDR&TXV 15.00 12.50 58MVB120---20
CNPH*3017A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070---12

CNPH*3617A** 29,200 TXV 14.00 11.50
CNPH*3617A** 28,800 TDR&TXV 15.00 12.50 58MVB040---14
CNPH*3617A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070---12

CNPF*3618A** 29,200 TXV 14.00 11.50

CSPH*3012A** 29,000 TXV 14.00 11.50
CSPH*3012A** 28,800 TDR&TXV 15.00 12.50 58MVB040---14
CSPH*3012A** 28,800 TDR&TXV 15.00 12.50 58CV(A,X)070--- 12
CSPH*3612A** 29,200 TXV 14.00 11.50
CSPH*3612A** 28,800 TDR&TXV 15.00 13.00 58MVB040---14
CSPH*3612A** 28,800 TDR&TXV 15.00 13.00 58CV(A,X)070--- 12

FY4ANF030 28,800 TDR&TXV 14.00 11.50

FY4ANF036 29,000 TDR&TXV 14.00 11.50

FX4CNF030 29,200 TDR&TXV 15.00 12.50

FX4CN(B,F)036 29,600 TDR&TXV 15.00 12.50

FF1ENP030 28,600 TDR&TXV 14.00 11.50

FF1ENP036 29,200 TDR&TXV 14.00 11.50

FV4BNF002 29,000 TDR&TXV 15.00 12.50

FV4BNF003 29,200 TDR&TXV 15.00 13.00

FV4BNF005 30,000 TDR&TXV 15.00 13.20
CAP**3614A** 35,000 TXV 14.00 11.50
CAP**3614A** 35,000 TDR&TXV 14.50 11.70 58CV(A,X)070--- 12

Factory Supplied

Enhancement

Standard

Rating

SEER

TDR†

EER Furnace Model

36---30

CAP**3617A** 35,400 TXV 14.00 11.50
CAP**3617A** 35,000 TDR&TXV 15.00 12.00 58MVB060 ---14
CAP**3617A** 35,000 TDR&TXV 15.00 12.00 58CV(A,X)090--- 16

CAP**3621A** 35,400 TXV 14.00 11.50
CAP**3621A** 35,000 TDR&TXV 14.50 11.70 58MVB080 ---14
CAP**3621A** 35,000 TDR&TXV 15.00 12.00 58MVB080 ---20
CAP**3621A** 35,200 TDR&TXV 15.00 12.00 58MVB100 ---20
CAP**3621A** 35,200 TDR&TXV 15.00 12.00 58CV(A,X)110--- 20

*CAP**4221A** 35,800 TXV 14.00 11.5

CAP**4221A** 35,200 TDR&TXV 14.50 11.70 58MVB080 ---14
CAP**4221A** 35,400 TDR&TXV 15.00 12.00 58MVB080 ---20
CAP**4221A** 35,400 TDR&TXV 15.00 12.00 58MVB100 ---20
CAP**4221A** 35,400 TDR&TXV 15.00 12.00 58CV(A,X)110--- 20

CAP**4224A** 35,800 TXV 14.00 11.50
CAP**4224A** 35,200 TDR&TXV 15.00 12.00 58MVB040 ---14
CAP**4224A** 35,400 TDR&TXV 15.00 12.00 58MVB120 ---20
CAP**4224A** 35,400 TDR&TXV 15.00 12.00 58CV(A,X)135--- 22

CNPV*3617A** 35,400 TXV 14.00 11.50
CNPV*3617A** 35,000 TDR&TXV 14.50 11.70 58MVB060---14
CNPV*3617A** 35,000 TDR&TXV 15.00 12.00 58CV(A,X)090--- 16

CNPV*3621A** 35,400 TXV 14.00 11.50
CNPV*3621A** 34,800 TDR&TXV 14.50 11.70 58MVB080---14
CNPV*3621A** 35,000 TDR&TXV 15.00 12.00 58CV(A,X)110--- 20

CNPV*4221A** 35,800 TXV 14.00 11.50
CNPV*4221A** 35,400 TDR&TXV 15.00 12.00 58MVB080---14
CNPV*4221A** 35,600 TDR&TXV 15.00 13.00 58CV(A,X)110--- 20

CNPH*3617A** 35,400 TXV 14.00 11.50
CNPH*3617A** 34,800 TDR&TXV 14.50 11.70 58MVB040---14
CNPH*3617A** 35,000 TDR&TXV 14.50 11.70 58CV(A,X)070 ---12

CNPH*4221A** 35,800 TXV 14.00 11.50
CNPH*4221A** 35,400 TDR&TXV 15.00 12.00 58MVB040---14
CNPH*4221A** 35,400 TDR&TXV 15.00 12.00 58CV(A,X)070 ---12

See notes on pg. 13

CNPH*4221A** 35,600 TDR&TXV 15.00 13.00 58CV(A,X)135 ---22

10

COMBINATION RATINGS -- CONTINUED

U n i t S i z e ---

Series

36---30

Indoor Model To t a l C a p . B T UH

CNPH*4221A** 35,600 TDR&TXV 15.00 13.00 58CV(A,X)155 ---22

CNPF*3618A** 35,400 TXV 14.00 11.50

CSPH*3612A** 36,200 TXV 14.00 11.50
CSPH*3612A** 35,600 TDR&TXV 15.00 12.00 58MVB040 ---14
CSPH*3612A** 35,800 TDR&TXV 15.00 12.00 58CV(A,X)070--- 12

CSPH*4212A** 36,600 TXV 14.00 11.50
CSPH*4212A** 35,800 TDR&TXV 15.00 12.00 58MVB040 ---14
CSPH*4212A** 36,000 TDR&TXV 15.00 12.00 58MVB120 ---20
CSPH*4212A** 36,000 TDR&TXV 15.00 12.00 58CV(A,X)070--- 12

FY4ANF036 34,800 TDR&TXV 14.00 11.50

FY4ANF042 36,000 TDR&TXV 14.00 11.50

FX4CN(B,F)036 36,000 TDR&TXV 15.00 12.00
FX4CN(B,F)042 36,600 TDR&TXV 15.00 12.00

FF1ENP036 35,000 TDR&TXV 14.00 11.50

FV4BNF002 35,200 TDR&TXV 15.00 12.00

FV4BNF003 35,400 TDR&TXV 15.00 12.00

FV4BNF005 36,600 TDR&TXV 15.00 13.00
CAP**4221A** 39,500 TXV 14.00 11.20
CAP**4221A** 39,000 TDR&TXV 14.20 11.50 58MVB080 ---14
CAP**4221A** 40,000 TDR&TXV 14.20 11.50 58MVB080 ---20
CAP**4221A** 40,000 TDR&TXV 14.20 11.50 58MVB100 ---20
CAP**4221A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)110--- 20

Factory Supplied

Enhancement

Standard

Rating

SEER

TDR†

EER Furnace Model

24ABA4

42---30

CAP**4224A** 39,500 TXV 14.00 11.50
CAP**4224A** 39,500 TDR&TXV 14.50 12.00 58MVB040 ---14
CAP**4224A** 40,000 TDR&TXV 14.50 12.00 58MVB120 ---20
CAP**4224A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22

CAP**4817A** 41,000 TXV 14.00 11.50
CAP**4817A** 40,000 TDR&TXV 15.00 12.50 58MVB060 ---14
CAP**4817A** 41,000 TDR&TXV 14.50 12.00 58CV(A,X)090--- 16

*CAP**4821A** 40,500 TXV 14.00 11.5

CAP**4821A** 40,000 TDR&TXV 15.00 13.20 58MVB080 ---14
CAP**4821A** 40,000 TDR&TXV 15.00 13.20 58CV(A,X)110--- 20

CAP**4824A** 40,500 TXV 14.00 12.00
CAP**4824A** 39,500 TDR&TXV 15.00 13.20 58MVB040 ---14
CAP**4824A** 41,000 TDR&TXV 15.00 13.20 58CV(A,X)135--- 22

CNPV*4221A** 40,000 TXV 14.00 11.50
CNPV*4221A** 39,500 TDR&TXV 14.50 12.00 58MVB080---14
CNPV*4221A** 40,500 TDR&TXV 15.00 12.50 58CV(A,X)110--- 20

CNPV*4821A** 40,500 TXV 14.00 11.50
CNPV*4821A** 40,000 TDR&TXV 14.50 12.00 58MVB080---14
CNPV*4821A** 41,000 TDR&TXV 14.50 12.00 58CV(A,X)110--- 20

CNPV*4824A** 40,500 TXV 14.00 12.00
CNPV*4824A** 40,000 TDR&TXV 14.50 12.00 58MVB040---14
CNPV*4824A** 41,000 TDR&TXV 15.00 12.50 58CV(A,X)135--- 22

CNPH*4221A** 40,000 TXV 14.00 12.50
CNPH*4221A** 40,000 TDR&TXV 14.50 12.00 58MVB040---14
CNPH*4221A** 39,500 TDR&TXV 15.00 13.20 58CV(A,X)070 ---12

CNPH*4821A** 40,500 TXV 14.00 11.50
CNPH*4821A** 40,000 TDR&TXV 14.50 12.00 58MVB040---14
CNPH*4821A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)070 ---12

CNPF*4818A** 40,000 TXV 14.00 11.95

CSPH*4212A** 40,500 TXV 14.00 11.50
CSPH*4212A** 40,000 TDR&TXV 14.50 12.00 58MVB040 ---14
CSPH*4212A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)070--- 12

See notes on pg. 13

CSPH*4812A** 41,000 TXV 14.00 12.05

11

COMBINATION RATINGS -- CONTINUED

U n i t S i z e ---

24ABA4

Series

42---30

Indoor Model To t a l C a p . B T UH

CSPH*4812A** 40,000 TDR&TXV 15.00 13.20 58MVB040 ---14
CSPH*4812A** 40,000 TDR&TXV 14.50 12.00 58CV(A,X)070--- 12

FY4ANF042 40,000 TDR&TXV 13.50 11.20

FY4ANF048 41,000 TDR&TXV 14.00 11.50

FX4CN(B,F)042 40,500 TDR&TXV 14.50 12.00
FX4CN(B,F)048 40,500 TDR&TXV 15.00 12.50

FV4BNF003 39,500 TDR&TXV 15.00 12.50

FV4BNF005 41,000 TDR&TXV 15.00 13.00

FV4BNB006 41,500 TDR&TXV 15.00 13.00
CAP**4817A** 46,500 TXV 13.50 11.20
CAP**4817A** 46,000 TDR&TXV 14.20 11.50 58CV(A,X)090--- 16

CAP**4821A** 47,500 TXV 13.50 11.20
CAP**4821A** 46,500 TDR&TXV 14.20 11.50 58MVB080 ---20
CAP**4821A** 46,500 TDR&TXV 14.20 11.50 58MVB100 ---20
CAP**4821A** 46,500 TDR&TXV 14.20 11.50 58CV(A,X)110--- 20

CAP**4824A** 47,500 TXV 13.50 11.20
CAP**4824A** 46,500 TDR&TXV 14.20 11.50 58MVB120 ---20
CAP**4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22
CAP**4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)155--- 22

CAP**6021A** 47,000 TXV 14.00 11.50
CAP**6021A** 46,500 TDR&TXV 14.20 11.50 58MVB080 ---20
CAP**6021A** 46,500 TDR&TXV 14.50 12.00 58MVB100 ---20
CAP**6021A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)110--- 20

Factory Supplied

Enhancement

Standard

Rating

SEER

TDR†

EER Furnace Model

48---30

*CAP**6024A** 48,000 TXV 14.00 11.5

CAP**6024A** 47,500 TDR&TXV 14.50 11.20 58MVB120 ---20
CAP**6024A** 48,000 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22
CAP**6024A** 48,000 TDR&TXV 15.00 12.50 58CV(A,X)155--- 22

CNPF*4818A** 46,500 TXV 13.50 11.20

CNPH*4821A** 47,500 TXV 13.50 11.20
CNPH*4821A** 46,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPH*4821A** 46,500 TDR&TXV 14.20 11.50 58CV(A,X)090 ---16

CNPH*6024A** 48,000 TXV 14.00 11.50
CNPH*6024A** 47,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPH*6024A** 47,500 TDR&TXV 14.50 12.00 58CV(A,X)090 ---16

CNPV*4821A** 47,500 TXV 13.50 11.20
CNPV*4821A** 46,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPV*4821A** 46,500 TDR&TXV 14.20 11.50 58MVB100---20
CNPV*4821A** 46,500 TDR&TXV 14.20 11.50 58CV(A,X)110--- 20

CNPV*4824A** 47,500 TXV 13.50 11.20
CNPV*4824A** 46,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPV*4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22
CNPV*4824A** 47,000 TDR&TXV 14.50 12.00 58CV(A,X)155--- 22

CNPV*6024A** 48,000 TXV 14.00 11.50
CNPV*6024A** 47,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPV*6024A** 48,000 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22
CNPV*6024A** 48,000 TDR&TXV 15.00 12.50 58CV(A,X)155--- 22

CSPH*4812A** 47,000 TXV 13.50 11.20
CSPH*4812A** 47,000 TDR&TXV 14.20 11.50 58MVB080 ---20
CSPH*4812A** 47,000 TDR&TXV 14.20 11.50 58CV(A,X)090--- 16

CSPH*6012A** 47,500 TXV 14.00 11.50
CSPH*6012A** 47,500 TDR&TXV 14.20 11.50 58MVB080 ---20
CSPH*6012A** 48,000 TDR&TXV 14.50 12.00 58CV(A,X)090--- 16

FV4BNB006 48,500 TDR&TXV 15.00 12.50

FV4BNF005 48,000 TDR&TXV 15.00 12.50

FX4CN(B,F)048 48,500 TDR&TXV 14.50 12.00
FX4CN(B,F)060 49,500 TDR&TXV 14.70 12.50

FY4ANB060 48,500 TDR&TXV 14.00 11.50

See notes on pg. 13

FY4ANF048 47,500 TDR&TXV 13.50 11.20

12

COMBINATION RATINGS -- CONTINUED

U n i t S i z e ---

Series

60---30

Indoor Model To t a l C a p . B T UH

CAP**6021A** 58,000 TXV 14.00 11.50
CAP**6021A** 55,000 TDR&TXV 14.20 11.50 58MVB080 ---20

*CAP**6024A** 59,000 TXV 14.00 11.5

CAP**6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22
CAP**6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155--- 22

CNPV*6024A** 58,500 TXV 14.00 11.50
CNPV*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPV*6024A** 57,500 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22
CNPV*6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155--- 22

CNPH*6024A** 58,500 TXV 14.00 11.50
CNPH*6024A** 55,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPH*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB100---20
CNPH*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPH*6024A** 57,500 TDR&TXV 14.20 11.50 58CV(A,X)110 ---20
CNPH*6024A** 57,500 TDR&TXV 14.50 12.00 58CV(A,X)135 ---22
CNPH*6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155 ---22

Factory Supplied

Enhancement

Standard

Rating

SEER

TDR†

EER Furnace Model

CSPH*6012A** 59,000 TXV 14.00 11.50
CSPH*6012A** 56,000 TDR&TXV 14.20 11.50 58MVB080 ---20
CSPH*6012A** 56,000 TDR&TXV 14.50 12.00 58MVB100 ---20
CSPH*6012A** 56,000 TDR&TXV 14.50 12.00 58MVB120 ---20
CSPH*6012A** 58,000 TDR&TXV 14.20 11.50 58CV(A,X)110--- 20
CSPH*6012A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)135--- 22
CSPH*6012A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155--- 22

FY4ANB060 59,000 TDR&TXV 13.50 11.20

FX4CN(B,F)060 59,500 TDR&TXV 14.00 11.50

* Tested combination
{ In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use

either the accessory Time ---Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Carrier fu rnaces are equipped with TDR.

EER — Energy Efficiency Ratio
SEER — Seasonal Energy Efficiency Ratio
TDR — T i m e --- D e l a y R el a y
TXV — Thermostatic Expansion Valve
NOTES:

1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.

2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other
combinations are determined under DOE computer simulation procedures.

3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.

4. Do not apply with capillary tube coils as performance and reliability are significantly affected.

FV4BNB006 59,000 TDR&TXV 14.50 12.00

24ABA424ABA4

13

DETAILED COOLING CAPACITIES

EVAPORATOR

CFM EWB

525

600

675

24ABA4

See notes on pg. 20

AIR

72 21.57 11.21 1.17 20.52 10.80 1.32 19.45 10.39 1.49 18.33 9.97 1.67 17.18 9.55 1.88 15.93 9.09 2.11
67 19.60 13.63 1.18 18.65 13.23 1.33 17.67 12.81 1.50 16.65 12.40 1.69 15.60 11.96 1.90 14.46 11.51 2.13
62 17.82 16.04 1.19 16.96 15.63 1.34 16.08 15.22 1.51 15.18 14.79 1.70 14.29 14.29 1.91 13.44 13.44 2.13
57 17.16 17.16 1.20 16.49 16.49 1.35 15.79 15.79 1.51 15.06 15.06 1.70 14.29 14.29 1.91 13.44 13.44 2.13
72 22.01 11.78 1.19 20.92 11.37 1.34 19.79 10.95 1.51 18.62 10.52 1.70 17.42 10.09 1.91 16.12 9.62 2.14
67 20.03 14.54 1.21 19.03 14.13 1.36 18.00 13.71 1.53 16.94 13.28 1.71 15.84 12.84 1.92 14.66 12.37 2.15
62 18.27 17.29 1.22 17.38 16.86 1.37 16.50 16.41 1.54 15.70 15.70 1.72 14.86 14.86 1.93 13.95 13.95 2.16
57 17.96 17.96 1.22 17.23 17.23 1.37 16.48 16.48 1.54 15.70 15.70 1.72 14.87 14.87 1.93 13.95 13.95 2.16
72 22.34 12.32 1.22 21.20 11.90 1.37 20.03 11.47 1.54 18.83 11.04 1.72 17.58 10.60 1.93 16.24 10.13 2.16
67 20.35 15.42 1.23 19.31 15.00 1.38 18.25 14.57 1.55 17.15 14.13 1.74 16.02 13.68 1.95 14.80 13.21 2.18
62 18.68 18.46 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18
57 18.63 18.63 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18

Indoor Model

*CAP**2414A** 1.00 1.00

CAP**1814A** 0.99 1.02
CAP**2417A** 1.00 1.00
CNPF*2418A** 1.00 1.03

CNPH*2417A** 1.00 1.03

CNPV*1814A** 0.99 1.02
CNPV*2414A** 1.00 1.00
CNPV*2417A** 1.00 1.03

CSPH*2412A** 1.00 1.00

CAP**1814A** 0.98 0.90 58CV(A,X)070---12
CAP**2414A** 0.99 0.88 58CV(A,X)070---12

CNPH*2417A** 0.99 0.88 58CV(A,X)070--- 12

CNPV*1814A** 0.98 0.90 58CV(A,X)070 ---12
CNPV*2414A** 0.99 0.88 58CV(A,X)070 ---12

CSPH*2412A** 0.99 0.88 58CV(A,X)070---12

CAP**2417A** 0.99 0.88 58CV(A,X)090---16

CNPH*2417A** 0.99 0.88 58CV(A,X)090--- 16

CNPV*2417A** 0.99 0.88 58CV(A,X)090 ---16
CSPH*2412A** 0.99 0.88 58CV(A,X)090---16
CNPH*2417A** 0.99 0.88 58MVB040---14
CSPH*2412A** 0.99 0.88 58MVB040 ---14

CAP**2417A** 0.99 0.88 58MVB060 ---14
CNPH*2417A** 0.99 0.88 58MVB060---14

CNPV*2417A** 0.99 0.88 58MVB060 --- 14
CSPH*2412A** 0.99 0.88 58MVB060 ---14
CNPH*2417A** 0.99 0.88 58MVB080---14
CSPH*2412A** 0.99 0.88 58MVB080 ---14

75 85 95 105 115 125

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

24ABA418A30 Outdoor Section With CAP**2414A** Indoor Section

Sens

‡

System

Multipliers for determining the performance with other indoor sections.

Cooling

FF1ENP018 0.99 1.02
FF1ENP024 1.00 1.03
FV4BNF002 1.01 0.88
FX4CNF018 1.00 0.88
FX4CNF024 1.02 0.90
FY4ANF018 0.99 1.02
FY4ANF024 0.99 1.02

CONDENSER ENTERING AIR TEMPERATURES deg F

To t a l

KW**

Capacity

MBtuh†

To t a l

Capacity Power Furnace Model

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

14

DETAILED COOLING CAPACITIES

EVAPORATOR

AIR

CFM EWB

72 28.59 14.92 1.54 27.34 14.44 1.73 26.02 13.94 1.95 24.62 13.41 2.19 23.11 12.85 2.45 21.45 12.25 2.74
67 25.94 18.18 1.55 24.78 17.69 1.74 23.56 17.18 1.96 22.27 16.64 2.19 20.88 16.08 2.46 19.35 15.46 2.75

700

62 23.61 21.43 1.55 22.55 20.93 1.75 21.45 20.41 1.96 20.30 19.86 2.20 19.15 19.15 2.46 18.01 18.01 2.75
57 22.84 22.84 1.56 22.01 22.01 1.75 21.12 21.12 1.96 20.18 20.18 2.20 19.15 19.15 2.46 18.01 18.01 2.75
72 29.18 15.68 1.58 27.87 15.19 1.77 26.49 14.68 1.98 25.03 14.15 2.22 23.46 13.58 2.48 21.74 12.96 2.77
67 26.48 19.38 1.58 25.27 18.88 1.78 24.00 18.36 1.99 22.66 17.82 2.23 21.22 17.24 2.49 19.64 16.61 2.78

800

62 24.19 23.07 1.59 23.12 22.54 1.78 22.00 22.00 2.00 21.01 21.01 2.23 19.91 19.91 2.50 18.69 18.69 2.78
57 23.86 23.86 1.59 22.97 22.97 1.78 22.02 22.02 2.00 21.01 21.01 2.23 19.91 19.91 2.50 18.69 18.69 2.78
72 29.62 16.40 1.61 28.26 15.90 1.80 26.84 15.38 2.02 25.33 14.84 2.26 23.71 14.26 2.52 21.93 13.64 2.81
67 26.89 20.53 1.62 25.64 20.02 1.81 24.33 19.50 2.03 22.95 18.94 2.27 21.46 18.35 2.53 19.85 17.71 2.82

900

62 24.74 24.57 1.62 23.77 23.77 1.82 22.77 22.77 2.03 21.70 21.70 2.27 20.54 20.54 2.53 19.25 19.25 2.82
57 24.71 24.71 1.62 23.77 23.77 1.82 22.77 22.77 2.03 21.70 21.70 2.27 20.54 20.54 2.53 19.25 19.25 2.82

See notes on pg. 20

75 85 95 105 115 125

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

Sens

To t a l

24ABA424A30 Outdoor Section With CAP**3014A** Indoor Section

Multipliers for determining the performance with other indoor sections.

Cooling

Indoor Model

*CAP**3014A** 1.00 1.00

CAP**2414A** 0.98 0.98
CAP**2417A** 0.98 0.98
CAP**3017A** 1.00 1.00

CNPF*2418A** 0.98 0.98
CNPH*2417A** 0.98 0.98
CNPH*3017A** 1.00 1.00

CNPV*2414A** 0.98 0.98

CNPV*2417A** 0.98 0.98

CNPV*3014A** 1.00 1.00

CNPV*3017A** 1.00 1.00
CSPH*2412A** 0.98 0.98
CSPH*3012A** 1.00 1.00

FF1ENP024 0.98 1.00
FF1ENP030 0.98 1.00
FV4BNF002 0.99 0.88
FV4BNF003 0.99 0.86
FX4CNF024 0.99 0.91
FX4CNF030 1.00 0.88
FY4ANF024 0.98 1.00

FY4ANF030 0.98 0.98
CAP**2414A** 0.97 0.89 58CV(A,X)070---12
CAP**3014A** 1.02 0.90 58CV(A,X)070---12

CNPH*2417A** 0.98 0.90 58CV(A,X)070 ---12
CNPH*3017A** 1.02 0.90 58CV(A,X)070 ---12

CNPV*2414A** 0.97 0.89 58CV(A,X)070--- 12
CNPV*3014A** 1.02 0.94 58CV(A,X)070--- 12

CSPH*2412A** 0.97 0.89 58CV(A,X)070--- 12
CSPH*3012A** 1.02 0.90 58CV(A,X)070--- 12

CAP**3017A** 1.02 0.90 58CV(A,X)090---16
CNPV*2417A** 0.98 0.90 58CV(A,X)090--- 16
CNPV*3017A** 1.02 0.90 58CV(A,X)090--- 16

CSPH*3012A** 1.02 0.90 58CV(A,X)090--- 16
CSPH*2412A** 0.97 0.86 58CV(A,X)110--- 20
CSPH*3012A** 1.02 0.90 58CV(A,X)110--- 20
CSPH*2412A** 0.97 0.86 58CV(A,X)135--- 22
CSPH*3012A** 1.02 0.90 58CV(A,X)135--- 22
CSPH*2412A** 0.97 0.86 58CV(A,X)155--- 22
CSPH*3012A** 1.02 0.90 58CV(A,X)155--- 22
CNPH*2417A** 0.98 0.90 58MVB040 ---14
CNPH*3017A** 1.02 0.90 58MVB040 ---14
CSPH*2412A** 0.97 0.89 58MVB040---14
CSPH*3012A** 1.02 0.90 58MVB040---14

CAP**2417A** 0.98 0.90 58MVB060---14
CAP**3017A** 1.02 0.90 58MVB060---14
CNPV*2417A** 0.98 0.90 58MVB060---14
CNPV*3017A** 1.02 0.90 58MVB060---14

CSPH*3012A** 1.02 0.90 58MVB060---14
CSPH*3012A** 1.02 0.90 58MVB080---14
CSPH*3012A** 1.02 0.90 58MVB080---20
CSPH*3012A** 1.02 0.90 58MVB100---20
CSPH*3012A** 1.02 0.90 58MVB120---20

CONDENSER ENTERING AIR TEMPERATURES deg F

Capacity

MBtuh†

To t a l

Capacity Power Furnace Model

‡

To t a l

System

KW**

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

24ABA4

15

DETAILED COOLING CAPACITIES

EVAPORATOR

AIR

CFM EWB

72 34.45 18.04 1.98 32.96 17.47 2.19 31.38 16.87 2.43 29.70 16.24 2.69 27.90 15.57 2.98 25.90 14.84 3.29
67 31.35 22.06 1.98 29.98 21.48 2.19 28.53 20.87 2.43 26.98 20.23 2.69 25.32 19.56 2.97 23.50 18.82 3.29

875

62 28.63 26.08 1.98 27.39 25.49 2.19 26.10 24.87 2.43 24.74 24.19 2.69 23.36 23.36 2.97 21.98 21.98 3.29
57 27.79 27.79 1.98 26.80 26.80 2.19 25.74 25.74 2.43 24.61 24.61 2.69 23.37 23.37 2.97 21.98 21.98 3.29
72 35.09 18.92 2.02 33.53 18.33 2.24 31.88 17.72 2.47 30.14 17.08 2.73 28.26 16.40 3.02 26.19 15.66 3.34

1000

1125

67 31.95 23.46 2.02 30.51 22.87 2.24 29.00 22.25 2.47 27.40 21.61 2.73 25.69 20.92 3.02 23.80 20.17 3.33
62 29.30 27.99 2.02 28.05 27.36 2.23 26.73 26.73 2.47 25.55 25.55 2.73 24.22 24.22 3.02 22.74 22.74 3.33
57 28.96 28.96 2.02 27.89 27.89 2.23 26.76 26.76 2.47 25.55 25.55 2.73 24.22 24.22 3.02 22.75 22.75 3.33
72 35.55 19.73 2.07 33.94 19.14 2.28 32.23 18.52 2.52 30.44 17.87 2.78 28.51 17.18 3.07 26.38 16.43 3.38
67 32.39 24.79 2.07 30.91 24.19 2.28 29.36 23.57 2.52 27.71 22.91 2.78 25.95 22.21 3.07 24.03 21.43 3.38
62 29.94 29.71 2.07 28.80 28.80 2.28 27.60 27.60 2.52 26.31 26.31 2.78 24.91 24.91 3.07 23.36 23.36 3.38
57 29.92 29.92 2.07 28.80 28.80 2.28 27.60 27.60 2.52 26.31 26.31 2.78 24.91 24.91 3.06 23.36 23.36 3.38

Capacity

MBtuh†

To t a l

75 85 95 105 115 125

To t a l

System

Sens

KW**

‡

Capacity

MBtuh†

Sens

To t a l

24ABA430A30 Outdoor Section With CAP**3014A** Indoor Section

Multipliers for determining the performance with other indoor sections.

CONDENSER ENTERING AIR TEMPERATURES deg F

Capacity

MBtuh†

To t a l

‡

To t a l

System

KW**

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

24ABA4

See notes on pg. 20

Cooling

Indoor Model

*CAP**3014A** 1.00 1.00

CAP**3017A** 1.00 1.04
CAP**3614A** 0.97 1.01
CAP**3617A** 1.01 1.05

CAP**3621A** 1.01 1.05
CNPF*3618A** 1.01 1.05
CNPH*3017A** 1.00 1.04
CNPH*3617A** 1.01 1.05
CNPV*3014A** 1.00 1.04
CNPV*3017A** 1.00 1.04
CNPV*3617A** 1.01 1.05
CNPV*3621A** 1.01 1.05
CSPH*3012A** 1.00 1.04
CSPH*3612A** 1.01 1.05

FF1ENP030 0.99 1.03
FF1ENP036 1.01 1.05
FV4BNF002 1.00 0.96
FV4BNF003 1.01 0.93
FV4BNF005 1.03 0.94

FX4CN(B,F)036 1.02 0.98

FX4CNF030 1.01 0.97
FY4ANF030 0.99 1.04

FY4ANF036 1.00 1.04
CAP**3014A** 0.99 0.95 58CV(A,X)070 ---12
CAP**3614A** 0.96 0.92 58CV(A,X)070 ---12

CNPH*3017A** 0.99 0.95 58CV(A,X)070---12
CNPH*3617A** 0.99 0.95 58CV(A,X)070---12
CNPV*3014A** 0.99 0.95 58CV(A,X)070 ---12
CSPH*3012A** 0.99 0.95 58CV(A,X)070 ---12
CSPH*3612A** 0.99 0.92 58CV(A,X)070 ---12

CAP**3017A** 0.99 0.92 58CV(A,X)090 ---16
CAP**3617A** 1.00 0.92 58CV(A,X)090 ---16

CNPV*3017A** 0.99 0.95 58CV(A,X)090 ---16
CNPV*3617A** 1.00 0.96 58CV(A,X)090 ---16

CAP**3621A** 1.00 0.92 58CV(A,X)110 ---20

CNPV*3621A** 1.00 0.96 58CV(A,X)110 ---20
CNPH*3017A** 0.99 0.95 58MVB040---14
CNPH*3617A** 0.99 0.95 58MVB040---14
CSPH*3012A** 0.99 0.95 58MVB040 ---14
CSPH*3612A** 0.99 0.92 58MVB040 ---14

CAP**3017A** 0.99 0.95 58MVB060 ---14
CAP**3617A** 0.99 0.92 58MVB060 ---14

CNPV*3017A** 0.99 0.95 58MVB060 ---14
CNPV*3617A** 0.99 0.95 58MVB060 ---14

CAP**3621A** 1.00 0.96 58MVB080 ---14

CNPV*3621A** 1.00 0.96 58MVB080 ---14
CNPH*3017A** 0.99 0.95 58MVB120---20

Capacity Power Furnace Model

16

DETAILED COOLING CAPACITIES

EVAPORATOR

AIR

CFM EWB

72 42.83 22.38 2.35 40.92 21.65 2.63 38.92 20.89 2.94 36.78 20.09 3.29 34.47 19.23 3.68 31.94 18.31 4.12

1050

1200

1350

See notes on pg. 20

67 38.83 27.27 2.35 37.06 26.52 2.63 35.20 25.74 2.94 33.22 24.93 3.29 31.08 24.06 3.68 28.75 23.12 4.12
62 35.34 32.16 2.35 33.74 31.40 2.63 32.07 30.59 2.94 30.32 29.72 3.29 28.58 28.58 3.68 26.83 26.83 4.12
57 34.26 34.26 2.35 32.98 32.98 2.63 31.63 31.63 2.94 30.17 30.17 3.29 28.58 28.58 3.68 26.83 26.83 4.12
72 43.66 23.46 2.40 41.67 22.71 2.68 39.58 21.94 2.99 37.36 21.12 3.34 34.96 20.26 3.73 32.33 19.32 4.17
67 39.58 28.97 2.40 37.74 28.21 2.68 35.80 27.42 2.99 33.75 26.59 3.34 31.55 25.71 3.73 29.14 24.76 4.17
62 36.18 34.48 2.40 34.56 33.67 2.68 32.87 32.87 2.99 31.35 31.35 3.34 29.67 29.67 3.73 27.80 27.80 4.17
57 35.72 35.72 2.40 34.36 34.36 2.68 32.91 32.91 2.99 31.36 31.36 3.34 29.67 29.67 3.73 27.80 27.80 4.17
72 44.27 24.46 2.45 42.22 23.70 2.73 40.06 22.91 3.05 37.77 22.09 3.40 35.31 21.21 3.79 32.61 20.26 4.22
67 40.14 30.57 2.45 38.24 29.80 2.73 36.25 29.01 3.04 34.15 28.17 3.39 31.89 27.28 3.78 29.44 26.29 4.22
62 36.97 36.59 2.45 35.49 35.49 2.73 33.97 33.97 3.04 32.33 32.33 3.39 30.56 30.56 3.78 28.59 28.59 4.22
57 36.94 36.94 2.45 35.50 35.50 2.73 33.97 33.97 3.04 32.34 32.34 3.39 30.56 30.56 3.78 28.60 28.60 4.22

75 85 95 105 115 125

Capacity

MBtuh†

To t a l Sens‡ To t al Sens‡ To tal Sens‡ To t a l Sens‡ To t a l Sens‡ To t a l Sens‡

To t a l
Sys-

tem

KW**

Capacity

MBtuh†

24ABA436A30 Outdoor Section With CAP**4221A** Indoor Section

Multipliers for determining the performance with other indoor sections.

Cooling

Indoor Model

*CAP**4221A** 1.00 1.00

CAP**3614A** 0.98 0.98
CAP**3617A** 0.99 0.99
CAP**3621A** 0.99 0.99
CAP**4224A** 1.00 1.00

CNPF*3618A** 0.99 0.99
CNPH*3617A** 0.99 0.99
CNPH*4221A** 1.00 1.00
CNPV*3617A** 0.99 0.99
CNPV*3621A** 0.99 0.99
CNPV*4221A** 1.00 1.00
CSPH*3612A** 1.01 1.01
CSPH*4212A** 1.02 1.02

FF1ENP036 0.98 0.98
FV4BNB006 1.03 0.90
FV4BNF002 0.98 0.94
FV4BNF003 0.99 0.95

FV4BNF005 1.02 0.90
FX4CN(B,F)036 1.01 0.96
FX4CN(B,F)042 1.02 0.98

FY4ANF036 0.97 0.97

FY4ANF042 1.01 1.01

CAP**3614A** 0.98 0.96 58CV(A,X)070 ---12
CNPH*3617A** 0.98 0.96 58CV(A,X)070 ---12
CNPH*4221A** 0.99 0.95 58CV(A,X)070 ---12
CSPH*3612A** 1.00 0.96 58CV(A,X)070--- 12
CSPH*4212A** 1.01 0.96 58CV(A,X)070--- 12

CAP**3617A** 0.98 0.94 58CV(A,X)090 ---16
CNPV*3617A** 0.98 0.94 58CV(A,X)090--- 16

CAP**3621A** 0.98 0.94 58CV(A,X)110 ---20

CAP**4221A** 0.99 0.95 58CV(A,X)110 ---20
CNPV*3621A** 0.98 0.94 58CV(A,X)110--- 20
CNPV*4221A** 0.99 0.88 58CV(A,X)110--- 20

CAP**4224A** 0.99 0.95 58CV(A,X)135 ---22
CNPH*4221A** 0.99 0.88 58CV(A,X)135 ---22
CNPH*4221A** 0.99 0.88 58CV(A,X)155 ---22

CAP**4224A** 0.98 0.94 58MVB040---14
CNPH*3617A** 0.97 0.96 58MVB040---14
CNPH*4221A** 0.99 0.95 58MVB040---14
CSPH*3612A** 0.99 0.95 58MVB040---14
CSPH*4212A** 1.00 0.96 58MVB040---14

CAP**3617A** 0.98 0.94 58MVB060---14
CNPV*3617A** 0.98 0.96 58MVB060---14

CAP**3621A** 0.98 0.96 58MVB080---14

CAP**4221A** 0.98 0.97 58MVB080---14
CNPV*3621A** 0.97 0.96 58MVB080---14
CNPV*4221A** 0.99 0.95 58MVB080---14

CAP**3621A** 0.98 0.94 58MVB080---20

CAP**4221A** 0.99 0.95 58MVB080---20

CAP**3621A** 0.98 0.94 58MVB100---20

CAP**4221A** 0.99 0.95 58MVB100---20

CAP**4224A** 0.99 0.95 58MVB120---20
CSPH*4212A** 1.01 0.96 58MVB120---20

CONDENSER ENTERING AIR TEMPERATURES deg F

To t a l
Sys-

KW**

Capacity

tem

MBtuh†

Capacity Power Furnace Model

To t a l
Sys-

tem

KW**

Capacity

MBtuh†

To t a l

Sys-

tem

KW**

Capacity

MBtuh†

To t a l
Sys-

tem

KW**

Capacity

MBtuh†

To t a l
Sys-

tem

KW**

24ABA4

17

DETAILED COOLING CAPACITIES

EVAPORATOR

AIR

CFM EWB

72 48.69 25.68 2.57 46.44 24.82 2.93 44.08 23.93 3.33 41.59 23.01 3.79 38.92 22.03 4.34 36.24 21.06 4.88

1225

1400

1575

67 44.08 31.40 2.60 42.00 30.53 2.95 39.82 29.63 3.35 37.54 28.70 3.81 35.09 27.71 4.39 32.52 26.69 4.98
62 40.13 37.15 2.61 38.27 36.26 2.96 36.35 35.33 3.35 34.37 34.37 3.81 32.57 32.57 4.40 30.57 30.57 5.00
57 39.17 39.17 2.61 37.67 37.67 2.96 36.09 36.09 3.35 34.41 34.41 3.81 32.57 32.57 4.40 30.57 30.57 5.00
72 49.63 26.97 2.62 47.28 26.10 2.98 44.82 25.19 3.38 42.24 24.26 3.84 39.47 23.26 4.38 36.72 22.29 4.90
67 44.93 33.44 2.65 42.75 32.56 3.00 40.50 31.65 3.40 38.13 30.70 3.86 35.60 29.69 4.43 32.98 28.65 5.02
62 41.12 39.90 2.66 39.26 38.92 3.01 37.52 37.52 3.41 35.73 35.73 3.87 33.77 33.77 4.46 31.68 31.68 5.04
57 40.82 40.82 2.66 39.21 39.21 3.01 37.52 37.52 3.41 35.73 35.73 3.87 33.77 33.77 4.46 31.68 31.68 5.04
72 50.34 28.18 2.68 47.90 27.30 3.03 45.37 26.38 3.43 42.70 25.43 3.88 39.87 24.43 4.42 37.06 23.45 4.91
67 45.57 35.39 2.70 43.33 34.49 3.05 41.01 33.57 3.46 38.58 32.60 3.92 35.99 31.57 4.48 33.34 30.50 5.07
62 42.20 42.20 2.71 40.50 40.50 3.06 38.71 38.71 3.46 36.82 36.82 3.92 34.75 34.75 4.50 32.59 32.59 5.08
57 42.20 42.20 2.71 40.50 40.50 3.06 38.72 38.72 3.46 36.82 36.82 3.92 34.76 34.76 4.50 32.59 32.59 5.08

Capacity

MBtuh†

To t a l

75 85 95 105 115 125

To t a l

System

Sens

KW**

‡

Capacity

MBtuh†

Sens

To t a l

24ABA442A30 Outdoor Section With CAP**4821A** Indoor Section

Multipliers for determining the performance with other indoor sections.

CONDENSER ENTERING AIR TEMPERATURES deg F

Capacity

MBtuh†

To t a l

‡

To t a l

System

KW**

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

Capacity

MBtuh†

To t a l

Sens

‡

To t a l

System

KW**

24ABA4

See notes on pg. 20

Cooling

Indoor Model

*CAP**4821A** 1.00 1.00

CAP**4221A** 0.98 1.00
CAP**4224A** 0.98 0.98
CAP**4817A** 1.01 1.01
CAP**4824A** 1.00 0.96

CNPF*4818A** 0.99 0.95
CNPH*4221A** 0.99 0.91
CNPH*4821A** 1.00 1.00

CNPV*4221A** 0.99 0.99

CNPV*4821A** 1.00 1.00

CNPV*4824A** 1.00 0.96
CSPH*4212A** 1.00 1.00
CSPH*4812A** 1.01 0.97

FV4BNB006 1.02 0.91
FV4BNF003 0.98 0.90

FV4BNF005 1.01 0.90
FX4CN(B,F)042 1.00 0.96
FX4CN(B,F)048 1.00 0.92

FY4ANF042 0.99 1.01

FY4ANF048 1.01 1.01

CNPH*4221A** 0.98 0.85 58CV(A,X)070---12
CNPH*4821A** 0.99 0.95 58CV(A,X)070---12
CSPH*4212A** 0.99 0.95 58CV(A,X)070 ---12
CSPH*4812A** 0.99 0.95 58CV(A,X)070 ---12

CAP**4817A** 1.01 0.97 58CV(A,X)090---16
CAP**4221A** 0.99 0.95 58CV(A,X)110---20
CAP**4821A** 0.99 0.86 58CV(A,X)110---20
CNPV*4221A** 1.00 0.92 58CV(A,X)110---20
CNPV*4821A** 1.01 0.97 58CV(A,X)110---20
CAP**4224A** 0.99 0.95 58CV(A,X)135---22
CAP**4824A** 1.01 0.88 58CV(A,X)135---22
CNPV*4824A** 1.01 0.93 58CV(A,X)135---22
CAP**4224A** 0.98 0.93 58MVB040---14
CAP**4824A** 0.98 0.85 58MVB040---14

CNPH*4221A** 0.99 0.95 58MVB040---14
CNPH*4821A** 0.99 0.95 58MVB040---14

CNPV*4824A** 0.99 0.95 58MVB040---14

CSPH*4212A** 0.99 0.95 58MVB040--- 14
CSPH*4812A** 0.99 0.86 58MVB040--- 14

CAP**4817A** 0.99 0.91 58MVB060---14
CAP**4221A** 0.96 0.96 58MVB080---14
CAP**4821A** 0.99 0.86 58MVB080---14
CNPV*4221A** 0.98 0.93 58MVB080---14
CNPV*4821A** 0.99 0.95 58MVB080---14
CAP**4221A** 0.99 0.99 58MVB080---20
CAP**4221A** 0.99 0.99 58MVB100---20
CAP**4224A** 0.99 0.95 58MVB120---20

Capacity Power Furnace Model

18

DETAILED COOLING CAPACITIES

EVAPORATOR

AIR

CFM EWB

72 60.16 31.56 3.28 57.50 30.54 3.65 54.64 29.46 4.05 51.60 28.32 4.50 48.30 27.10 4.99 44.61 25.76 5.51
67 55.07 38.75 3.27 52.61 37.72 3.64 50.00 36.62 4.05 47.20 35.47 4.49 44.18 34.24 4.98 40.83 32.90 5.51

1400

62 50.45 45.90 3.27 48.23 44.83 3.64 45.88 43.71 4.04 43.41 42.48 4.49 40.91 40.91 4.98 38.37 38.37 5.51
57 48.92 48.92 3.27 47.14 47.14 3.63 45.23 45.23 4.04 43.17 43.17 4.49 40.91 40.91 4.98 38.37 38.37 5.51
72 61.17 33.06 3.37 58.39 32.02 3.73 55.41 30.92 4.14 52.25 29.77 4.58 48.82 28.53 5.07 45.00 27.17 5.59
67 56.03 41.17 3.36 53.46 40.12 3.72 50.73 39.00 4.13 47.83 37.84 4.57 44.70 36.59 5.06 41.24 35.22 5.59

1600

62 51.54 49.21 3.35 49.27 48.08 3.72 46.90 46.90 4.12 44.73 44.73 4.57 42.31 42.31 5.06 39.58 39.58 5.59
57 50.90 50.90 3.35 48.99 48.99 3.72 46.94 46.94 4.12 44.73 44.73 4.57 42.31 42.31 5.06 39.58 39.58 5.59
72 61.90 34.47 3.45 59.02 33.42 3.81 55.95 32.30 4.22 52.69 31.14 4.66 49.16 29.88 5.15 45.24 28.51 5.67
67 56.72 43.47 3.44 54.07 42.40 3.80 51.26 41.28 4.21 48.28 40.10 4.66 45.07 38.82 5.14 41.52 37.41 5.67

1800

62 52.54 52.16 3.43 50.46 50.46 3.80 48.29 48.29 4.20 45.95 45.95 4.65 43.40 43.40 5.14 40.51 40.51 5.67
57 52.49 52.49 3.43 50.46 50.46 3.80 48.29 48.29 4.20 45.96 45.96 4.65 43.40 43.40 5.14 40.52 40.52 5.67

75 85 95 105 115 125

Capacity

MBtuh†

To t a l Sens‡ Tota l Sens‡ Tot a l Sens‡ Tot a l Sens‡ To t a l Sens‡ Tot a l Sens‡

To t a l
Sys-

tem

KW**

Capacity

MBtuh†

24ABA448A30 Outdoor Section With CAP**6024A** Indoor Section

Multipliers for determining the performance with other indoor sections.

CONDENSER ENTERING AIR TEMPERATURES deg F

To t a l

KW**

Sys­tem

Capacity

MBtuh†

To t a l
Sys-

tem

KW**

Capacity

MBtuh†

To t a l
Sys-

tem

KW**

Capacity

MBtuh†

To t a l

Sys­tem

KW**

Capacity

MBtuh†

To t a l
Sys-

tem

KW**

Indoor Model

*CAP**6024A** 1.00 1.00

CAP**4817A** 0.97 0.99
CAP**4821A** 0.99 1.02
CAP**4824A** 0.99 1.02
CAP**6021A** 0.98 0.98

CNPF*4818A** 0.97 0.99
CNPH*4821A** 0.99 1.02
CNPH*6024A** 1.00 1.00

CNPV*4821A** 0.99 1.02

CNPV*4824A** 0.99 1.02

CNPV*6024A** 1.00 1.00
CSPH*4812A** 0.98 1.01
CSPH*6012A** 0.99 0.99

FV4BNB006 1.01 0.93
FV4BNF005 1.00 0.92
FX4BNB060 1.01 1.04

FX4BNF048 1.00 1.03
FX4CN(B,F)048 1.01 0.97
FX4CN(B,F)060 1.03 0.95

FY4ANB060 1.01 1.01

FY4ANF048 0.99 1.02
CAP**4817A** 0.96 0.96 58CV(A,X)090--- 16

CNPH*4821A** 0.97 0.97 58CV(A,X)090 ---16
CNPH*6024A** 0.99 0.95 58CV(A,X)090 ---16
CSPH*4812A** 0.98 0.98 58CV(A,X)090--- 16
CSPH*6012A** 1.00 0.96 58CV(A,X)090--- 16

CAP**4821A** 0.97 0.97 58CV(A,X)110--- 20
CAP**6021A** 0.98 0.94 58CV(A,X)110--- 20
CNPV*4821A** 0.97 0.97 58CV(A,X)110---20
CAP**4824A** 0.98 0.94 58CV(A,X)135--- 22
CAP**6024A** 1.00 0.96 58CV(A,X)135--- 22
CNPV*4824A** 0.98 0.94 58CV(A,X)135---22
CNPV*6024A** 1.00 0.96 58CV(A,X)135---22
CAP**4824A** 0.98 0.94 58CV(A,X)155--- 22
CAP**6024A** 1.00 0.92 58CV(A,X)155--- 22
CNPV*4824A** 0.98 0.94 58CV(A,X)155---22
CNPV*6024A** 1.00 0.92 58CV(A,X)155---22
CAP**4821A** 0.97 0.97 58MVB080---20
CAP**6021A** 0.97 0.97 58MVB080---20

CNPH*4821A** 0.97 0.97 58MVB080 ---20
CNPH*6024A** 0.99 0.99 58MVB080 ---20

CNPV*4821A** 0.97 0.97 58MVB080---20

CSPH*4812A** 0.98 0.98 58MVB080---20
CSPH*6012A** 0.99 0.99 58MVB080---20

CAP**4821A** 0.97 0.97 58MVB100---20
CAP**6021A** 0.97 0.93 58MVB100---20
CNPV*4821A** 0.97 0.97 58MVB100---20
CAP**4824A** 0.97 0.97 58MVB120---20
CAP**6024A** 0.99 1.02 58MVB120---20
CNPV*4824A** 0.97 0.93 58MVB120---20
CNPV*6024A** 0.99 0.95 58MVB120---20

See notes on pg. 20

Cooling

Capacity Power Furnace Model

24ABA4

19

DETAILED COOLING CAPACITIES

EVAPORATOR

AIR

CFM EWB

72 70.52 37.08 3.97 67.20 35.81 4.38 63.70 34.48 4.83 59.99 33.10 5.32 55.97 31.62 5.86 51.51 30.01 6.45
67 64.33 45.47 3.92 61.31 44.20 4.33 58.13 42.87 4.78 54.75 41.49 5.27 51.12 40.02 5.82 47.11 38.42 6.40

1750

62 58.81 53.84 3.87 56.12 52.55 4.28 53.31 51.19 4.73 50.40 49.71 5.23 47.55 47.55 5.78 44.50 44.50 6.38
57 57.17 57.17 3.86 55.01 55.01 4.27 52.72 52.72 4.73 50.25 50.25 5.23 47.55 47.55 5.78 44.50 44.50 6.38
72 71.76 38.86 4.07 68.29 37.57 4.48 64.63 36.22 4.93 60.76 34.81 5.43 56.59 33.31 5.96 51.97 31.67 6.55
67 65.49 48.34 4.02 62.33 47.04 4.43 59.00 45.69 4.88 55.50 44.28 5.37 51.73 42.78 5.92 47.58 41.13 6.50

2000

62 60.13 57.72 3.98 57.39 56.32 4.38 54.66 54.66 4.84 52.02 52.02 5.34 49.12 49.12 5.89 45.84 45.84 6.48
57 59.48 59.48 3.97 57.15 57.15 4.38 54.68 54.68 4.84 52.03 52.03 5.34 49.12 49.12 5.89 45.85 45.85 6.48
72 72.67 40.54 4.17 69.08 39.23 4.58 65.29 37.86 5.03 61.30 36.43 5.52 57.00 34.90 6.06 52.25 33.24 6.64
67 66.34 51.06 4.12 63.07 49.75 4.53 59.64 48.38 4.98 56.04 46.94 5.47 52.17 45.40 6.01 47.92 43.68 6.60

2250

62 61.32 61.32 4.08 58.90 58.90 4.49 56.27 56.27 4.95 53.45 53.45 5.45 50.38 50.38 6.00 46.91 46.91 6.59
57 61.37 61.37 4.08 58.90 58.90 4.49 56.27 56.27 4.95 53.46 53.46 5.45 50.38 50.38 6.00 46.92 46.92 6.59

75 85 95 105 115 125

Capacity

MBtuh†

To t a l Sens‡ To t a l Sens‡ To tal Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

To t a l

System

KW**

Capacity

MBtuh†

24ABA460A30 Outdoor Section With CAP**6024A** Indoor Section

Multipliers for determining the performance with other indoor sections.

CONDENSER ENTERING AIR TEMPERATURES deg F

To t a l

System

KW**

Capacity

MBtuh†

To t a l

System

KW**

Capacity

MBtuh†

To t a l

System

KW**

Capacity

MBtuh†

To t a l

System

KW**

Capacity

MBtuh†

To t a l

System

KW**

24ABA4

Cooling

Indoor Model

*CAP**6024A** 1.00 1.00

CAP**6021A** 0.98 0.98
CNPH*6024A** 0.99 0.99
CNPV*6024A** 0.99 0.99
CSPH*6012A** 1.00 1.00

FV4BNB006 1.00 0.96

FX4CN(B,F)060 1.01 1.01

FY4ANB060 1.00 1.03
CNPH*6024A** 0.97 0.97 58CV(A,X)110 ---20
CSPH*6012A** 0.98 0.98 58CV(A,X)110 ---20
CAP**6024A** 0.98 0.94 58CV(A,X)135 ---22
CNPH*6024A** 0.97 0.93 58CV(A,X)135 ---22
CNPV*6024A** 0.97 0.93 58CV(A,X)135 ---22
CSPH*6012A** 0.98 0.94 58CV(A,X)135 ---22
CAP**6024A** 0.98 0.94 58CV(A,X)155 ---22
CNPH*6024A** 0.98 0.94 58CV(A,X)155 ---22
CNPV*6024A** 0.98 0.94 58CV(A,X)155 ---22
CSPH*6012A** 0.98 0.94 58CV(A,X)155 ---22
CAP**6021A** 0.93 0.93 58MVB080--- 20
CNPH*6024A** 0.94 0.94 58MVB080---20
CSPH*6012A** 0.95 0.95 58MVB080---20
CNPH*6024A** 0.94 0.90 58MVB100---20
CSPH*6012A** 0.95 0.91 58MVB100---20
CNPH*6024A** 0.94 0.90 58MVB120---20
CNPV*6024A** 0.94 0.90 58MVB120--- 20
CSPH*6012A** 0.95 0.91 58MVB120---20

Capacity Power Furnace Model

NOTE: When the required data fall between the published data, interpolation may be performed. Extrapolation is not an acceptable

practice.

* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240--94. If additional

tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.

{ Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
} Sensible capacities shown are based on 80_F (27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C),

deduct 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80_F(27_C),oradd835Btuh(245kW)
per 1000 CFM (480 L/S) of indoor coil air per degree above 80_F(27_C).

When the required data fall between the published data, interpolation may be performed.

** Total system kW is total of indoor and outdoor unit kilowatts.

20

GUIDE SPECIFICATIONS
GENERAL

System Description

Outdoor--mounted, air--cooled, split--system air conditioner
unit suitable for ground or rooftop installation. Unit consists
of a hermetic compressor, an air--cooled coil, propeller-- type
condenser fan, and a control box. Unit will discharge supply
air upward as shown on contract drawings. Unit will be used
in a refrigeration circuit to match up to a packaged fan coil
or coil unit.

Quality Assurance

— Unit will be rated in accordance with the latest edition

of ARI Standard 210.

— Unit will be certified for capacity and efficiency, and

listed in the latest ARI directory.

— Unit construction will comply with latest edition of

ANSI/ ASHRAE and with NEC.

— Unit will be constructed in accordance with UL

standards and will carry the UL label of approval.
Unit will have c--UL approval.

— Unit cabinet will be capable of withstanding Federal

Tes t
Method Standard No. 141 (Method 6061) 500--hr salt
spray test.

— Air --cooled condenser coils will be leak tested at 150

psig and pressure tested at 450 psig.

— Unit constructed in ISO9001 approved facility.

Delivery, Storage, and Handling

— Unit will be shipped as single package only and is

stored and handled per unit manufacturer’s
recommendations.

Warranty (for inclusion by specifying engineer)

— U.S. and Canada only.

PRODUCTS

Equipment

— Factory assembled, single piece, air--cooled air

conditioner unit. Contained within the unit enclosure
is all factory wiring, piping, controls, compressor,
refrigerant charge Puronr (R--410A), and special
features required prior to field start--up.

Unit Cabine

s

Fan

t

— Unit cabinet will be constructed of galvanized steel,

bonderized, and coated with a powder coat paint.

— Condenser fan will be direct--drive propeller type,

discharging air upward.

AIR--COOLED, SPLIT--SYSTEM AIR CONDITIONER

1--1/2 TO 5 NOMINAL TONS

— Condenser fan motors will be totally enclosed,

1--phase type with class B insulation and permanently
lubricated bearings. Shafts will be corrosion resistant.

— Fan blades will be statically and dynamically

balanced.

— Condenser fan openings will be equipped with coated

steel wire safety guards.

Compresso

Condenser Coi

Refrigeration Component

Operating Characteristics

Electrical Requirements

Special Features

r
— Compressor will be hermetically sealed.
— Compressor will be mounted on rubber vibration

isolators.

l
— Condenser coil will be air cooled.
— Coil will be constructed of aluminum fins

mechanically bonded to copper tubes which are then
cleaned, dehydrated, and sealed.

s

— Refrigeration circuit components will include

liquid--line shutoff valve with sweat connections,
vapor--line shutoff valve with sweat connections,
system charge of Puronr (R--410A) refrigerant, and
compressor oil.

— Unit will be equipped with filter drier for Puron

refrigerant.

— The capacity of the unit will meet or exceed _____

Btuh at a suction temperature of _____ _F. The power
consumption at full load will not exceed _____ kW.

— Combinationoftheunitandtheevaporatororfancoil

unit will have a total net cooling capacity of _____
Btuh or greater at conditions of _____ CFM entering
air temperature at the evaporator at _____ _Fwetbulb
and _____ _F dry bulb, and air entering the unit at
_____ _F.

— The system will have a SEER of _____ Btuh/watt or

greater at DOE conditions.

— Nominal unit electrical characteristics will be _____ v,

single phase, 60 hz. T he unit will be capable of
satisfactory operation within voltage limits of _____ v

to _____ v.
— Unit electrical power will be single point connection.
— Control circuit will be 24v.

— Refer to section of this literature identifying

accessories and descriptions for specific features and

available enhancements.

24ABA4

24ABA4

21

24ABA4

Copyright 2005 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231

Printed in U.S.A. edition date: 12 / 05

Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.

22

Catalog No: 24ABA4 ---1PD

Replaces:New
