Page 1
SECTION 1
www.carnes.com E-1
Fire, Smoke & Ceiling Radiation Dampers
CHOOSE CARNES FIRE DAMPERS
FOR ALL OF YOUR UL
DAMPER APPLICATIONS
UL 555 Listing 1-1/2 and 3 hours
ULC S112 Listing 1-1/2 and 3 hours
All Fire Damper models
meet or comply with all
major building codes,
including IBC/ICC
International Code.
Type A Fire Dampers
(EA and EH Series)
- Curtain Blade
- Crimped (3V) Blade
- Airfoil Blade
- Slimline
- True Round
- Static or Dynamic
Type B Fire Dampers
(EB and EK Series)
- Curtain Blade
- Slimline
- Static or Dynamic
Type C Fire Dampers
(EC and EJ Series)
- Curtain Blade
- Static or Dynamic
When Fire Safety Matters,
You Can Count On Carnes.
Page 2
Fire, Smoke & Ceiling Radiation Dampers
Fire Dampers
E-2 www.carnes.com
Carnes Fire Damper Selection Guide
Carnes Model Description of Damper
EAAA Type A curtain fire damper, for static systems, integral sleeve, curtain blade, 1.5 and 3 hr. ratings
EABA Type A curtain fire damper, for static systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EACA Type A slimline curtain fire damper, for static systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EADA Type A ultra slimline curtain fire damper, for static systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EAEA Type A curtain fire damper, for static systems, sidewall grille mount, sleeved, curtain blade, 1.5 and 3 hr. ratings
EAFA Type A curtain fire damper, for static systems, floor/ceiling mount, sleeved, curtain blade, 1.5 and 3 hr. ratings
EAGA
Type A curtain fire damper, for static systems, outside wall/partition mount, sleeved, curtain blade, 1.5 and 3 hr. ratings
EAHA Type A fire damper, for static systems, single crimped (3V) blade, sleeved, curtain blade, 1.5 hr. only rating
EAIA Type A fire damper, for static systems, multi blade crimped (3V) blade, no sleeve, 1.5 and 3 hr. ratings
EAJA Type A fire damper, for static systems, multi blade, airfoil blade, no sleeve, 1.5 and 3 hr. ratings
EAKA
Type A curtain fire damper, for static systems, medium pressure, caulked, 5” sleeve, curtain blade, 1.5 and 3 hr. rat
ings
EALA
Type A curtain fire damper, for static systems, high pressure, fully welded, 5” sleeve, curtain blade, 1.5 and 3 hr. rat
ings
EARA Type A fire damper, for static systems, true round, single blade, sleeved, 1.5 hr. only rating
EHAA Type A curtain fire damper, for dynamic systems, integral sleeve, curtain blade, 1.5 and 3 hr. ratings
EHBA Type A curtain fire damper, for dynamic systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EHCA Type A slimline curtain fire damper, for dynamic systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EHEA Type A curtain fire damper, for dynamic systems, sidewall grille mount, sleeved, curtain blade, 1.5 and 3 hr. ratings
EHFA Type A curtain fire damper, for dynamic systems, floor/ceiling mount, sleeved, curtain blade, 1.5 and 3 hr. ratings
EHGA
Type A curtain fire damper, for dynamic systems, outside wall/partition mount, sleeved, curtain blade, 1.5 and 3 hr.
ratings
EHIA Type A fire damper, for dynamic systems, multi blade crimped (3V) blade, no sleeve, 1.5 and 3 hr. ratings
EHJA Type A fire damper, for dynamic systems, multi blade, airfoil blade, no sleeve, 1.5 and 3 hr. ratings
EHRA Type A fire damper, for dynamic systems, true round, single blade, sleeved, 1.5 hr. only rating
t Type A:
Carnes Model Description of Damper
EBAA Type B curtain fire damper, for static systems, integral sleeve, curtain blade, 1.5 and 3 hr. ratings
EBBA Type B curtain fire damper, for static systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EBCA Type B slimline curtain fire damper, for static systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EKAA Type B curtain fire damper, for dynamic systems, integral sleeve, curtain blade, 1.5 and 3 hr. ratings
EKBA Type B curtain fire damper, for dynamic systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EKCA Type B slimline curtain fire damper, for dynamic systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
t Type B:
Carnes Model Description of Damper
ECAA Type C curtain fire damper, for static systems, integral sleeve, curtain blade, 1.5 and 3 hr. ratings
ECBA Type C curtain fire damper, for static systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
EJAA Type C curtain fire damper, for dynamic systems, integral sleeve, curtain blade, 1.5 and 3 hr. ratings
EJBA Type C curtain fire damper, for dynamic systems, no sleeve, curtain blade, 1.5 and 3 hr. ratings
t Type C:
Note: Many damper models are available with an optional sleeve. See individual model specifications for details.
Page 3
Fire Dampers
www.carnes.com E-3
Fire, Smoke & Ceiling Radiation Dampers
Selecting a Fire Damper
Fire dampers are used to prevent the transmission of flames through air ducts and in air transfer openings in
walls and partitions. Fire damper construction is available in Type A, Type B and Type C, as well as for use
in static systems or dynamic systems.
Type A, Type B and Type C Dampers:
Fire dampers are constructed to meet the UL555 test as to minimum construction gauge and edge seals and
are manufactured in three types (Type A, Type B and Type C).
The Type A fire damper is constructed with the damper framed the same size as the duct size and includes
the blade stack and edge seals within the air stream. The Type A fire damper has the highest air pressure
drop. Typical installation is in a low pressure (less than 3” w.c.) system.
The Type B fire damper has the blade stack out of the airstream, but the receiving channel is within the
airstream. Air pressure drop is substantially reduced. The Type B fire damper is generally used where the
duct height is 12” or less, or where air speed velocities are fast enough.
The Type C fire damper has a 100% free area through the damper for a minimal pressure drop, and can be
used in a low, medium or high pressure application.
Fire Dampers for Static Systems and Dynamic Systems
:
Fire dampers for use in static systems are used in duct systems or penetrations where there is little to no airflow when the damper closes. Fire dampers for use in dynamic systems are required if the HVAC system will
be operating with the fans on during a fire incident. Dynamic system dampers are expected to be able to
close against the air velocity and pressure produced by the system fan.
In most cases, static system dampers rely on gravity to pull the curtain/blade closed, and dynamic system
dampers utilize springs to pull the curtain closed. Both static and dynamic fire dampers carry an hourly fire
resistance rating (1-1/2 or 3 hours). Dynamic system dampers are also provided with an airflow rating,
indicating the maximum velocity and static pressure that the damper is designed for
1
.
1. Information provided per UL Marking and Application Guide: Dampers for Fire Barrier and Smoke Applications & Ceiling Dampers,
April 2003.
Page 4
Fire, Smoke & Ceiling Radiation Dampers
Fire Dampers
E-4 www.carnes.com
Fire Damper Model Breakdown
Design
Fuse
Model Number Series Width Height Finish Mtg. Link OPTIONS
1 2 3 4 5 6 7 8 9101112 13 14 15 161718
20 - Mill Finish
E
B A A 0 6 0 0 6 0 2 0
V
3
Misc.
3 - Micro Switch
Package
4 - Out of Wall
Const.
5 - Micro Switch
Pkg. & Out
of Wall
Const.
E - Fire
Damper
A - Type A Fire Damper
for Static Systems
B - Type B Fire Damper
for Static Systems
C - Type C Fire Damper
for Static Systems
H - Type A Fire Damper
for Dynamic Systems
K - Type B Fire Damper
for Dynamic Systems
J - Type C Fire Damper
for Dynamic Systems
A - Curtain Fire Damper
Integral Sleeve, Curtain Blade
B - Curtain Fire Damper
No Sleeve, Curtain Blade
C - Slimline Curtain Fire Damper
No Sleeve, Curtain Blade
D - Ultra Slimline Curtain Fire Damper
No Sleeve, Curtain Blade
E - Curtain Fire Damper, Sidewall Grille Mount
Sleeved, Curtain Blade
F - Curtain Fire Damper, Floor/Ceiling Grille Mount
Sleeved, Curtain Blade
G - Curtain Fire Damper, Outside Wall/Partition Mount
Sleeved, Curtain Blade
H - Curtain Fire Damper, Single Blade, Crimped (3V) Blade
Sleeved
I - Fire Damper, Multi Blade, Crimped (3V) Blade
No Sleeve
J - Fire Damper, Multi Blade, Airfoil Blade
No Sleeve
K - Curtain Fire Damper, Med. Pressure, Caulked
5” Sleeve, Curtain Blade
L - Curtain Fire Damper, High Pressure, Fully Welded
5” Sleeve, Curtain Blade
R - Fire Damper, True Round
Sleeved, Single Blade
Transition
7 - Round Low Profile
8 - Round
9 - Rectangular
0 - Oval
Mounting Angles
1 - Retaining Angles, 1 side
2 - Retaining Angles, 2 sides
06 - 6”
Fractional
Size
0 - 0”
1 - 1/8”
2 - 1/4”
3 - 3/8”
4 - 1/2”
5 - 5/8”
6 - 3/4”
7 - 7/8”
Fusible Link
1 - 1.5 Hr., 165 Deg.
2 - 3 Hr., 165 Deg.
3 - 1.5 Hr., 212 Deg.
4 - 3 Hr., 212 Deg.
5 - 1.5 Hr., Elec./Pneum. Link
6 - 3 Hr., Elec./Pneum. Link
Mounting
Direction
V - Vertical
H - Horizontal
06 - 6”
Fractional
Size
0 - 0”
1 - 1/8”
2 - 1/4”
3 - 3/8”
4 - 1/2”
5 - 5/8”
6 - 3/4”
7 - 7/8”
Actuators (Round and Multi Blade Models Only)
A - Hand Quadrant
B - Electric, 165 Deg.
C - Electric, 212 Deg.
D - Electric, 250 Deg.
E - Electric, 350 Deg.
F - Pneumatic, 165 Deg.
G - Pneumatic, 212 Deg.
H - Pneumatic, 250 Deg.
J - Pneumatic, 350 Deg.
