Page 1
Get Ultimate Carlton Chipper Performance with
SELF-PROPELLED/WALK-BEHIND
The Professionals Choice
TIER 3
STUMPCUTTER
SP5014SERIES
Page 2
• A variety of
powerful
engine options
are available to take
on the toughest jobs.
• SP5014 TRX is the perfect
machine when access is the
primary concern.
The SP5014 TRX has all the features
SP5014 TRX Track-Mounted
of the SP5014 with the addition of a
retractable track system. The track
drive system offers exceptional tractive
effort - allowing the SP5014 TRX to
easily climb chip piles and obstacles.
The tracks on the SP5014 TRX retract
from a wide 48 inches to a narrow
35 inches to fit through a standard
backyard gate. A hydraulic controlled
scrape blade is standard equipment on
the SP5014 TRX
• Tapered Bearings
on cutter wheel and
jack shaft provide long
service life and reduced
maintenance.
Optional wireless remote control
increases operator’s visibility and
reduces fatigue.
Tracks expand and contract
hydraulically from a wide 48 inch
stance to gate accessible narrow
35 inch width.
Over 60 years and 15,000
machines of experience!
Proprietary dual motor drive system
eliminates chains, axles, and axle
bearings while providing class leading
ground speed and climbing torque.
Feather touch hydraulic controls make
the SP5014 Series easy to operate and
provide optimum user control.
Page 3
SP4012Series
SELF-PROPELLED/WALK-BEHIND
The Professionals Choice
SP5014SERIES
STUMPCUTTER
SP5014 SP5014TRX
Engine Option 1 Vanguard Big Block 993 CC
Engine Option 1 Performance 35 Horsepower 52 ft-lbs.
Cutting Depth Below Ground 14"
Cutting Height Above Ground 34"
Cutter Head Swing 50"
Cutter Wheel Thickness 1 1/4"
Number of Teeth on Cutterwheel 36 Razor Teeth
Type of Cutter Teeth Hard Micro Structure Carbide
Jack Shaft Bearing Size 1 11/16"
Cutter Head Bearing Size 1 11/16"
Fuel Tank Capacity 10 Gallons
Hydraulic Tank Capacity 4 Gallons
Track Width NA 7"
Track Length NA 42"
Tire Size 5.7 x 8 NA
Ground Pressure 8.6 PSI 4 PSI
Machine Width - Wide Stance 48" with duals 48"
Machine Width - Narrow Stance 35" 35"
Machine Height 58" 56"
Machine Length 108" 95"
Machine Weight 1650 lbs. 2215 lbs.
*Due to commitment to constant improvement specifications are subject to change. Please consult
factory for latest specifications.
Carlton offers a full line of high quality professional
tree equipment including stump cutters from
13 horspower to 250 horsepower and chippers
from 6 inch to 20 inch capacity. Carlton has been
manufacturing stump cutting equipment for over
50 years and our commitment to quality can be
found in every piece of equipment we manufacture.
Plus, Carlton’s staff of highly trained and experienced
professionals stands behind every piece of Carlton
equipment and is ready with answers to your
questions. From parts and service to technical
support, Carlton is dedicated to providing our
customers with the best experience.
Check out the great lineup of other Carlton products.
900H Series
Walk-Behind
SP7015 Series
Self-Propelled
SP7015 TRX Series
Track-Mounted
121 John Dodd Road
Spartanburg, SC 29303
SP8018 TRX Series
Track-Mounted
www.stumpcutters.com
Hurricane RS Series
Track-Mounted
800-243-9335
