Carl Martin Echotone User Manual

The Carl Martin Echotone! 1200 milliseconds of vintage echo, foot-switchable Tap or Manual time settings,

insert loop and switchable trail function at bypass. Imagine switching from a Manual time setting to a Tap

time setting right at your feet, so you can play with your favourite slap-back echo on rhythm to a Tap (tempo)

set echo for that massive lead or solo! Combine this with flavouring your echo by installing a chorus, flange

or even distortion pedal in the insert loop, and the switchable trail function at bypass, and you have what our

test players are calling ‘the best echo they have ever heard’!

As with all the Danish built Carl Martin effects, the Echotone comes in our low-profile housing, coated in our

new stunning off-white colour, with the built-in 12v (+-) regulated power supply.

The ECHO switch is to activate or bypass the Echotone, with the LED on

the unit is activated.

Please note the Echotone is NOT true bypass, it features a high quality

buffered bypass, to ensure long cabling without loss.

The SELECT switch choose between the manual time setting and the TAP

TEMPO function.

With the LED above the TAP TEMPO switch ON the TAP TEMPO function

is activated, the manual time knob does not work.

With the LED above the TAP TEMPO switch OFF the MANUAL TIME

function is activated, the tap tempo does not work.

By this you can easily shift between two presets i.e. a slapback on the

MANUAL knob, and while using that on the A part of the song you can tap

in the song tempo while playing, and in the solo enter the select switch for

long delay time for the heroic lead, and after the solo enter the SELECT

switch to return to the slapback.

With the TAP TEMPO chosen on the select switch LED on, you can set

the delay time simply by tapping the desired or the song tempo on the

TEMPO switch with your foot, you shall tap minimum two times ore more

as the unit will always set the tempo after the last two tap's.

With the MANUAL time function chosen on the select switch (LED above

tempo switch off) you set the desired delay time on the chicken head

knob.

Counter Clock wise (-) longer delay time, Clock wise faster delay time.

On the ECHO knob you mix between dry and wet, Clock wise more echo.

On the FEEDBACK knob you choose the amount of echo's you want after

the original note.

With the TONE knob you adjust the voicing on the repeats from dark

position full counter clock wise to light full clock wise.

PLEASE NOTE the tone only effect the repeats not the overall guitar

sound.
