Card Access HPC10 Users Manual

InHome™

Heavy-Duty Power Controller

Model Number: HPC10A

Installation Guide / Wiring Diagram

The information contained in this document represents current information and views of Card Access, Inc. as of the date of
publication. Card Access cannot guarantee the accuracy of any information presented after the date of this document’s publication.

COPYRIGHT ©2008 Card Access, Inc. All rights reserved. Any previously copyrighted contents contained herein remain the
property of the respective creators.

Card Access, InHome, Wires Not Included, and The Wire Stops Here are trademarks of Card Access, Inc.
Control4 is a registered trademark and 4Sight is a trademark of Control4 Inc.
ZigBee is a trademark of the ZigBee Alliance.
GE is a trademark of General Electric Company.
CEDIA is a trademark of the Custom Ele ctronic Design & Installation Asso ciation.
Other marks may be the property of their respective owners.

__________________________________________________________________________ _______________________________________________
Card Access
Card Access, Inc.

™

InHome™ Heavy-Duty Power Controller Installation Guide / Wiring Diagram Page 1 of 12

Card Access

InHome

Enable Automation Events for High-Voltage Systems in the Control4® Automated Home

Introduction

The Card Access™ InHome™ Heavy-Duty Power Controller (HPC10A) is a wirelessly controlled power controller
specifically designed for use with the Control4® home automation system and is Control4 Certified. This gives the
Control4-automated homeowners the ability to turn high-voltage items on or off based on the time of day, and even
operate them from a remote location with Control4’s 4Sight

The InHome Heavy-Duty Power Controller can also be operated independent of the home automation system by ‘hard­wiring’ in switches and controls in Stand-Alone configuration.

The device consists of two high voltage 100-240VAC 30 Amp relays that can be independently configured to control the
following types of loads:

• motors

• resistive loads

• ballast type loads

in residential or commercial applications. The control and configuration of these relays can occur through the Control4
Composer application (Control4 Operating Mode), or directly on the device, (Stand-Alone Operating Mode).

Control4 Operating Mode:

To operate in Control4 mode the device must be identified into the project. This is done by tapping of the ID button (the
method common to other devices in Control4 projects.)

Once the device is identified, its four contact inputs and two independently controlled high-voltage relay s are available to
the project for configuration and control.

Device control is accomplished through one of three methods:

• Through an IEEE 802.15.4 ZigBee-based wireless radio signal

• Through the four local switch inputs

• Through a combination of both methods

Using both methods provides for failsafe independent operation.
The InHome Heavy-Duty Power Controller’s Control4 driver supports complete device configuration and operation through

user selectable options. The device utilizes Control4’s proxies for control of blind motors, lifts, screens, gate motors,
fountain and pool pump motors, lighting loads, and appliance loads, etc.

The device also includes several easy-to-use diagnostic modes to help installers set the device up for proper operation.

Stand-Alone Operating Mode:

In Stand-Alone Operating Mode, the device uses the four dry contact closure inputs to control the two high-voltage power
relays in a one (1), two (2), or 3 button control configuration. This allows for a wide variation of configurations and
homeowner operation.

The InHome Heavy-Duty Power Controller’s onboard switches enable ease of setup, easy di agnostic test, and easy
troubleshooting for installers. LEDs indicate relay status and radio functionality. A relay disable switch is pr ovided to
allow functional test by the installer without sending power to connected high-power devices, allowin g ea sy testing of the
system.

The InHome Heavy-Duty Power Controller is powered by one of two methods:

__________________________________________________________________________ _______________________________________________
Card Access
Card Access, Inc.

™

InHome™ Heavy-Duty Power Controller Installation Guide / Wiring Diagram Page 2 of 12

™

Heavy-Duty Power Controller Installation Guide

™

service.

1. Connecting a 100-240VAC line power to the High Voltage terminals of the device

2. Connecting a 12VDC power supply to the power inputs of the Low Voltage terminal connector

No power jumpers or setting are required just connect one or the other (line power or external DC power supply in).
The device is designed to be permanently mounted in a fixed location. Power cables can be connected to the device

using conduit or by connecting flexible power lines to the device with feed through cable clamps.
Figure 1 below shows you where the InHome Heavy-Duty Power Controller is placed in a typical installation.

GRAPHIC TBD – show fixed mounting by conduit and by cable clamp

Figure 1 – InHome Heavy-Duty Power Controller in a Typical Installation

Specifications

Specifications for the InHome Heavy-Duty Power Controller are as follows:

HPC10A Specifications
Dimensions 4.6” x 10.5” x 2.1”
Weight 3.5 Lbs
Maximum Ambient

75 C
Operational Temperature
Power Input 100-240VAC at 50/60Hz, 0.1 Amps

Or

12VDC, 200mAmps
Relay Contact Ratings (per
relay)

Voltage Load Type Contact

Rating

240VAC General

30 Amps

Purpose
240VAC UL Resistive 25 Amps
120VAC Motor 1 HP
240VAC Motor 2 HP
277VAC Ballast 10 Amps

HV wiring 8 – 14 Gauge wiring depending on Load*

* An accessible disconnect device shall be installed into
the fixed wiring. Device must be wired by an authorized
electrician in accordance with the National Electrical
Code, ANSI/NFPA 70-1987. In the European community,
the unit must be wired by an authorized electrician in
accordance with all applicable European codes

Operational Environment Device shall be mounted in a dry moisture protected

location in accordance with National Electrical Code

__________________________________________________________________________ _______________________________________________
Card Access
Card Access, Inc.

™

InHome™ Heavy-Duty Power Controller Installation Guide / Wiring Diagram Page 3 of 12

!!! WARNING !!!: <warning verbiage here>

Control4 Compatibility

NOTE: <note verbiage here>

Site Requirements and Wiring Options

<This Section TBD – be sure that the device is placed in a safe moisture free location as specified in accordance with all
local and national electrical codes. Ensure that appropriate accessible disconnect devices (circuit brea ker) are installed
into the fixed wiring of the device. Ensure that the devices cover is securely replaced after device setup and
configuration.>

Low-Voltage Wiring Diagram Option

High-Voltage Wiring Diagram Options
Option 1: Used where a single external breaker to the device is used and the load is powered from this power source.
