INTRODUCTION
Your new security system has many sophisticated features. It has been customized
by your installer for your home or business. The master keypad, which is wired
irectly
to the control center, is your link to the system. The control center is
mounted out of sight in a metal box. The master keypad and any wireless keypads or
handheld transmitters are the only things you need to control the system.
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..*.....................
1
An alarm system is not a substitute for vigilance and preparedness. You should have
System
Maintenance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
plans of action in the event of fire, intrusion, or any other emergency.
System
Overview
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
Daily, routine operation of the system will require you only to simply arm and
disarm it by pressing the appropriate keys. However, because this alarm system is
Monitoring
Service
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
designed to tell you when it is experiencing anything abnormal (an alarm, a low
Light
Operation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . .
2
battery, or an electronics problem), you need to know how to respond in these situations. This manual will explain the system’s operation and tell you what to do if the
Manual
Alarms
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.
. 2
system gives you a visual or audible message.
User
Codes.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.
.2
Optional features in your system are indicated by boxes
0
which your installer
Arming
&
Disarming
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
will mark to show that you do or do not have a particular feature. Boxes that are not
checked may be ignored.
Entry/Exit
Delays
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
System
AdvisoryTones
(SAT’s)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before reading further in this manual, turn to the Master Keypad Reference Diagram
4
on pages 8-9 and take a few minutes to familiarize yourself with the positions of the
Burglary
Violation
Beeps
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
keys and displays. This diagram will also be helpful for future reference as you use
Display
Windows
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
your system. Your installer has filled in the System Information section (inside the
5
back cover of this manual) with other facts about your system.
Clearing
Alarm
Memory...........................................................................
5
Trouble
Messages...................................................................................
6
Fire
Trouble..
...........................................................................................
6
Testing..
...................................................................................................
6
2ndUser
Codes......................................................................................
6
Chime
Mode............................................................................................
7
Bypassing..
.............................................................................................
7
Resetting
Hardwiree
Smoke
Detectors......................................................
7
SYSTEM MAINTENANCE
Be sure to have your installer go over the system with you until you are familiar with
, its operation and the complete procedures for testing all system components. No
ectronic product can perform better than the care and maintenance it receives.
This
manual contains instructions on how you can test your alarm system. Individual test
and maintenance instructions are also provided with many of the accessory components that make up your system. Keep those instructions with this booklet.
The manufacturer of this equipment strongly urges that you and your installing
company enter into a periodic service and maintenance agreement so that capable
service technicians can help assure that your system is operating properly.
In
Case
ofan
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10
AC
Power
&
Backup
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10
Duress
Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
60
Fire Detection & Emergency Evacuation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Things You
Should
Know AboutRFDevices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12
Limitations of the System
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13
SYSTEM OVERVIEW
This security system can be set up in a variety of ways, using radio frequency (RF)
transmitters, hardwire zones, or a combination of the two. RF transmitters send a
radio signal to the control center. Hardwire zones are physically connected to the
control by wires. This system contains:
0
All RF transmitters
0
All
hardwire
zones
0
A combination of both
1
Cl MONITORING SERVICE
(CANCELLING ACCIDENTAL ALARMS)
You may have elected to subscribe to a monitoring service. If so, reports will be sent
via telephone lines in the event of alarms or system trouble. The service then alerts
the appropriate authorities. Refer to the System Information pages for a list of the
(
reports you have selected for transmitting to the service. Be aware that you need to
call and cancel any accidental alarm. It is very expensive to have emergency
vehicles respond to unintentional alarms. You may be charged a fee for this type of
response.
0
LIGHT OPERATION
Your system may be set up to turn on selected lights when an alarm occurs or when
you intentionally activate them using a portable transmitter. Your installer will
explain how lights are tied into your system. The facts concerning selected lights
and their operation are recorded in the System Information pages.
MANUAL ALARMS
In an em
ergency, you can trigger an alarm from the master keypad by pressing both
“Fire” symbol keys simultaneously for a fire alarm or both “Police” symbol keys
simultaneously to activate a police alarm. If your system is connected to a monitoring service, the service will dispatch the appropriate emergency vehicles.
USER CODES
User codes are four-digit sequences of keys activated by either hardwire or wireless
keypads. These codes allow you to arm, disarm and change some features on your
system. You have approximately ten seconds from the time you begin to finish
pressing the keys. If you make a mistake, simply press a digit that is not part of your
code. This will clear the error and let you start over. You may also wait for the ten
seconds to expire before beginning again. There are three types of user codes:
Master Code:
This is the permanent code programmed during
the installation of your system. It is recorded on the System Information pages. Memorize it and do not give it to anyone except
those you wish to have complete access to your alarm system.
2nd User Code: This is a temporary code you can assign to
allow others to use your system without them knowing the master
code. See “Assigning a 2nd User Code” for more information.
0
Duress Code: Few installations will require this type of
code. If you have decided on this option during installation, you
must be extremely careful and use it only when you are in direct
personal danger. See “Duress Codes” for a complete explanation.
2
ARMING & DISARMING THE SYSTEM
Some sensors in your system are always armed and will trigger an alarm whenever
they are tripped. They are pre-set by your installer and you cannot, in most cases,
irn
them off. These would include protection for fire, police, emergency, etc.
The burglary intrusion sensors in the system are routinely armed and disarmed
(turned on and off) during the day. Burglary protection consists of perimeter and
interior sensors. Perimeter sensors are usually located on windows and doors, and
you normally leave these sensors armed when you are home. Interior sensors, such
as motion detectors, protect the interior of your residence and are normally armed
only when you are away.
Burglary sensors will be set for either instant or delay triggering when your system is
armed. If an instant sensor is tripped, an immediate alarm will sound. Delay sensors
provide time for you to enter or exit the building without causing an alarm.
The burglary protection in your system can be armed to three different modes. The
STAY and AWAY lights on the master keypad indicate the mode.
AWAY: No one is in the protected area. All interior and perimeter
sensors are on. You will normally put the system in Away when
you leave the premises.
STAY: You are inside the premises and want to be alerted if
someone tries to enter. Perimeter sensors are on. Interior sensors
are off, allowing you to move about freely.
Cl
NIGHT:
You
have retired for the evening and want additional
protection in selected areas. All perimeter protection is fully
armed as in the other modes. Certain interior sensors (selected by
you and your installer) are also on. For example, you may choose
to have downstairs interior sensors on while upstairs sensors
remain off.
Your installer will indicate the arming method you have chosen below:
0
Single-Digit Arming
(must disarm first to change modes)
Arm to AWAY: Press
‘AWAY’ key
*
Arm to STAY: Press
‘STAY’ key
0
Arm to NIGHT:
System is already armed to STAY:
Press ‘STAY’ key
I
Cl
Coded Arming
Arm to AWAY:
Press ‘AWAY’ key, then enter user code
Arm to STAY:
Press
‘STAY’ key, then enter user code
0
Arm to NIGHT:
System is already armed to STAY:
Press ‘STAY ‘ key, then enter user code
1
3
