I N ST RUCT I ONS FO R
USE
W INE CEL LAR
Wi3 113 B uilt - in
Wi6 222 B uilt - in
For Spare Parts, Technical Advice
or Product Service call the
CAPLE HELPLINE on 0870 850 8734
2
Thank you for buying your new CAPLE Wine Cellar. To ensure that you get the best
results from your new purchase, we strongly suggest that you read this instruction
manual thoroughly before use. This manual contains installation advice, usage
instructions and other important facts about your CAPLE Wine Cellar. If treated with
care, your CAPLE Wine Cellar should give you many years of trouble-free use.
PARTS & FEATURES
1. HANDLE 2. SWITCH
3. DIGITAL CONTROL PANEL 4 DOOR
5. LARGE SHELVES (5) 6. SMALL BOTTOM SHELF
7. LEGS 8. CABINET
3
IMPORTANT WARNINGS AND ADVICE
• Unpack your wine cellar carefully and remove all of the protective packing from inside and
outside.
• Packing (plastic bags, polystyrene, nails, metal, etc.) must not be left within the reach of
children as they are a potential source of danger.
• After unpacking, make sure that the appliance is in perfect order. If you have any doubt,
do not use it and contact your retailer.
• Check that all the fittings are in the correct position on the inside of the cabinet.
• Release the mains lead which is fitted with a 13 amp UK type plug.
• Move your wine cellar to its final location.
• DO NOT MOVE YOUR CABINET WHILE LOADED WITH WINE as this could distort the
cabinet.
• Ensure that the specified ventilation instructions are adhered to.
• Do not try to modify the appliance's technical characteristics as this could be dangerous
• This appliance should only be used for the specific purpose for which it was designed, i.e.
storage of wine. It is not designed for food storage.
• Do not clean or maintain the appliance without disconnecting it first.
• To prevent damaging the door gasket, make sure that the door is fully
open when pulling shelves out.
• Ensure that you fully understand these instructions before operating this appliance.
• Caple are NOT responsible for: -
1. Damage caused by incorrect, mistaken or irrational use.
2. For any errors in this manual, or for any damage linked to or following the
provision, performance or use of any wine cellar.
• The information in this document is subject to modification without prior notice.
DISPOSAL OF OLD APPLIANCE
Discarded appliances are potentially dangerous to CHILDREN.
Before you throw away your old Wine Cellar:
• Remove the door. Leave the shelves in place so that children cannot easily climb
inside.
• Never allow children to operate, play with, or climb inside the appliance.
4
INSTALLATION INSTRUCTIONS
BEFORE TURNING THE WINE CELLAR ON ENSURE IT IS PERFECTLY LEVEL. This
should minimize any vibrations.
Your cabinet is equipped with 4 adjustable feet. However, we recommend that you tighten the
back feet to the maximum and then use the front feet to level the cabinet.
IMPORTAN T: WAIT 2 HOURS BEFORE TURNING THE WINE CELLAR ON FOR THE FIRST
TIME.
Safety Instructions
• The Wi3113&Wi6222 is provided with a fan to evacuate heat via the bottom vents.
• It must be installed well away from any heat source.
• It must not be placed in direct sun light.
• It must not be in a damp location (laundry, pantry, bathroom, etc)
• It must be perfectly level.
• It must have a correctly installed and reliable electricity supply correctly earthed.
• Use of a multi-socket or extension lead is not recommended..
• This wine cellar must be earthed to provide protection in the event of an electrical
short circuit.
• It is fitted with a power cord having an earth wire terminating in a 13amp plug.
• Consult a qualified electrician or service engineer if the earthing instructions are not
completely understood.
WARNING: INCORRECT EARTHING CAN RESULT IN THE RISK OF ELECTRIC SHOCK.
Door reversal
WE RECOMMEND THAT SOMEONE ASSISTS YOU DURING THIS PROCESS. TOOLS
REQUIRED: - PHILIPS SCREWDRIVER. (A BOTTOM LEFT HAND HINGE IS SUPPLIED
WITH WINE CELLAR.
① Bottom hinge (Right) ② Screws ③ Door axis
④ Door ⑤ Top hinge(Right) ⑥ Lock screws
⑦ Top hinge(Left) ⑧ Bottom(Left)
1. Remove 2 screws ②, then pull
door④ As per arrowhead direction, you
will remove the door. Please remove
bottom hinge②as well for the coming
assembly. (Fig.A & Fig.B)
5
2. To remove 3 screws⑥ of right upper
Hinge, then to remove right upper⑤ &
Right lower hinges①; (See fig.C)
3. To use the screws which you removed
From right side hinges to fix left upper
& lower hinges (See Fig.D & Fig.E)
4. To rotate door at 180 degrees,
then assemble the door as per the
reverse way of remove.
Install the bar handle
Remove the door gasket on the drilling holes side to install the handle. (see below
drawing)
Back
Front
6
Stainless Steel Plinth (Supplied separately)
When the wine cellar is installed in its final position, the stainless steel plinth should be
fitted. Remove the protective tape from the adhesive strips on the rear of the plinth and
then place firmly in position onto the bottom of the wine cellar cabinet.
THE FLOW OF AIR THROUGH THE GRILL MUST NOT BE OBSTRUCTED AT ANY
TIME. FAILURE TO ADHERE TO THIS WILL INVALIDATE THE GUARANTEE.
OPERATING INSTRUCTIONS
The wine cellar should be placed where the ambient temperature is between 0-35 deg
centigrade (32-95 degrees Fahrenheit). If the ambient temperature is above or below this
range, the performance of the unit may be affected. For example, placing your unit in
extreme cold or hot conditions may cause interior temperatures to fluctuate. The range of
5-18 ºC (40-65 degrees Fahrenheit) may not be reached.
Control Panel
• RUN
Indicator light illuminates to signify the cooling cycle is currently in operation.
• LIGHT SWITCH
To control the interior light, on/off.
• “UP” Button
To raise (warm) the temperature in 1 ºC stages.
• “DOWN” Button
To lower (cool) the temperature in 1 ºC stages.
Setting the Temperature Control
• You can set the temperature as you desire by pressing the UP or DOWN buttons. When
you press either of the two buttons for the first time, the LED readout will show the original
temperature set at previous time (the temperature preset at the factory is 12 ºC.
• The temperature that you desire to set will increase by 1ºC if you press the UP button
once, and will decrease 1ºC if you press the DOWN button once.
• The temperature selected will flash in the LED display for approximately 5 seconds, and
will then display the actual temperature (which will gradually reach the set temperature).
• To view the “set” temperature, press the UP or DOWN button, then the LED display will
“flash” for 5 seconds to show the “set” temperature.
LIGHT SWITCH
DOWN
UP RUN
7
Installation of Shelves
To fit or remove the shelf, tilt the shelf as per the diagram and simply pull out, or push the
shelf in until it sits on the support brackets securely.
NOTE:
• If the unit is unplugged, if power is lost, or turned-off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the wine cellar will not
start.
• When you use the wine cellar for the first time or restart the wine cellar after it has been
switched off for a long time, there could be a few degrees variance between the
temperature you select and the one indicated on the LED readout. This is normal and it
is due to the length of the activation time. Once the wine cellar has been running for a
few hours, the temperature display will re-gain accuracy.
8
CARE AND MAINTENANCE
Cleaning
• Turn off the power, unplug the appliance, and remove all items including shelves and
rack.
• Wash the inside surfaces with a warm water and baking soda solution. The solution
should be about two tablespoons of baking soda to one litre of water.
• Wash the shelves with a mild detergent solution.
• Wring excess water out of the sponge or cloth when cleaning the control panel, or any
electrical parts.
• Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and
wipe dry with a clean soft cloth.
Power Failure
• Most power failures are corrected within a few hours and should not affect the temperature
of your appliance if you minimise the number of times the door is opened. If the power is
going to be off for a longer period of time, you need to take action to protect the contents.
Vacation Time
• Short vacations: Leave the wine cellar operating during vacations of less than three
weeks.
• Long vacations: If the wine cellar will not be used for several months, remove all items
and disconnect. Clean and dry the interior thoroughly. To prevent odour and mould
growth, leave the door open slightly (blocking it open if necessary).
Moving Your Wine Cellar
• Remove all bottles.
• Securely tape down all shelves inside the cabinet.
• Turn the adjustable legs up to the base to avoid damage.
• Tape the door shut.
• Be sure the appliance stays secure and upright during transportation. Also protect
the outside of the wine cellar. (e.g. with a blanket).
Energy Saving Tips
• The wine cellar should be located in the coolest area of a room, away from heat
producing appliances, and out of the direct sunlight.
9
TROUBLE SHOOTING GUIDE
You can solve many common wine cellar problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling the
service engineer.
PROBLEM
POSSIBLE CAUSE
The wine cellar does not operate.
The appliance is not plugged in.
The appliance is turned off.
The circuit breaker has tripped or a fuse has
blown.
The wine cellar is not cold enough.
Check the temperature control setting.
The external environment may require a higher
setting.
The door has been opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The wine cellar turns on and off frequently.
The room temperature is hotter than normal.
A large amount of bottles have been added to the
wine cellar.
The door has been opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work.
The appliance is not plugged in. Not plugged in.
The circuit breaker has tripped or a fuse has
blown.
The bulb needs replacing.
The light button is “OFF”.
The wine cellar vibrates
Check to that the wine cellar is level.
The wine cellar seems to make too much noise.
The rattling noise may come from the flow of
refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The wine cellar is not level.
The door will not close properly.
The wine cellar is not level.
The door was reversed and not properly installed.
The gasket is dirty.
The shelves are out of position.
10
DEFROSTING/CONDENSATION
Your wine cellar is designed with an “Auto-cycle” defrost system. When the RUN cycle is OFF,
the refrigerated surface of the wine cellar (interior rear wall) defrosts automatically. The defrost
water is channeled into a drain pan which is located at the back of the wine cellar next to the
compressor from where it evaporates.
HUMIDITY MAINTENANCE SYSTEM
The wine cellar is equipped with a system for maintaining the correct level of humidity. If
humidity is too low, insert the small plastic reservoir on to the top shelf. Fill this reservoir 3/4 full
with water. Check the water level occasionally and refill as necessary.
RECOMMENDED TEMPERATURE SETTINGS
For keeping ALL TYPES OF WINES 12 oc to 14 oc
Champagne NV, Sparkling 6 oc
Champagne Vintage 10 oc
Dry White Semillon, Sauvignon Blanc 8 oc
Dry White Gewurstraminer, Riesling 10 oc
Dry White Chardonnay 10 oc
Vintage chardonnay 14 oc
Sweet White Sauternes Monbazillac, Late Harvest ice wine 10 oc
Sweet whites vintage Sauternes 14 oc
Beaujolais 13 oc
Red Pinot Noir 16 oc
Vintage Pinot noir red 20 oc
Red Cabernet, Merlot, French, Australian, New Zealand, Chilean,
Argentinean, Italian, Spanish, Californian 20 oc
Red Grenache, Syrah 16 oc
