Caple CM107 User Manual

Operating instructions

Compact Oven

CM 107

TABLE OF CONTENTS

1/NOTICES TO THE USER

• Safety recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

• Operating principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• Protecting the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2/INSTALLING YOUR APPLIANCE

• Before hook-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

• Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

• Building in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3/DESCRIPTION OF YOUR APPLIANCE

• The Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

• Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

• Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

• Selectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

• Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4/USING YOUR APPLIANCE

• Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

• Setting and adjusting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

• Stopping the turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

• Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

• Using the power levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

• Microwave function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

• Express Microwave Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

• Reheating on two levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

• Keep warm function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

• Automatic cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

• Guide to automatic functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

• Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

• Speed Defrost function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

• Defrosting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

• Grill function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

• Grill function cooking guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

• Microwave + Grill function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• Microwave + Grill function cooking guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• Fan heat function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

• Fan heat cooking guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

• Fan heat + Microwave function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

• Microwave + Fan heat cooking guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

• Memory programmes M1 / M2 / M3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

• Child Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

5/CARING FOR AND CLEANING YOUR APPLIANCE . . . . . . . . . . . . . . . . . . . . . . . 27

6/TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

7/FUNCTIONAL APTITUDE TESTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

EN 1/NOTICES TO THE USER

Important:

Keep this user guide with your appliance. If the appliance is ever sold or transferred to another person, ensure that the new owner receives the user guide. Please become familiar with these recommendations before installing and using your appliance. They were written for your safety and the safety of others.

Your appliance is designed for standard household use for cooking, reheating and defrosting foods. The manufacturer declines any responsibility in the case of inappropriate use.

The appliance is not intended to be used by

persons (including children) with reduced physical, sensory or mental abilities, or persons lacking experience or awareness, unless using it with the help of a person responsible for their safety, or under supervision and with prior instruction in its use.

Ensure that the cookware is suitable for use

in a microwave oven.

To avoid damaging your appliance, never

operate it while empty or without the turntable.

Do not interfere with the openings on the lock

on the front of the appliance; this could cause damage to your appliance that would require a service call.

The seal and frame of the door must be

regularly examined to ensure that they have not deteriorated. If these areas are damaged, discontinue use of the appliance and have a specialised technician check it.

While heating food items in plastic or paper

containers, monitor the microwave’s contents for there is a risk of spontaneous combustion.

For the microwave and microwave + fan

heating functions, the use of metallic cookware, forks, spoons, knives or metal

staples or fasteners for frozen foods is not recommended.

The contents of baby bottles and baby food jars should be shaken or stirred and their temperature checked before consumption to avoid burns. Never heat a baby bottle with the nipple on (risk of explosion).

Make sure children do not play with the appliance. Do not allow children to use the

microwave oven without supervision, unless appropriate instructions have been given so that the child can use the oven safely and understands the dangers of incorrect operation.

Always use oven mitts to remove dishes from the oven. Some dishes absorb the heat of foods and, therefore, are very hot.

Liquids and other foods should not be heated in sealed containers because they may explode.

It is recommended that you avoid heating eggs in their shells and whole hard-boiled eggs in the microwave oven because they run the risk of explosion, even after cooking is complete.

Heating beverages in the microwave oven can cause sudden and/or delayed splattering of boiling liquid, so precautions must be taken when handling their containers. In the case of small quantities (a sausage, a croissant, etc.) place a glass of water next to the food.

Excessive cooking times may dry out foods and carbonise them. To avoid such incidents, never use the same times recommended for cooking in a traditional oven.

If smoke appears, stop or unplug the oven and leave the door closed to smother any flames that may appear.

•SAFETY RECOMMENDATIONS

1/NOTICES TO THE USER

The microwaves used for cooking are electromagnetic waves. They are commonly found in our environment in the form of radio-electric waves, light or infrared rays.

Their frequency is in the 2450 MHz range.

Their behaviour:

• They are reflected by metals.

• They travel through all other materials.

• They are absorbed by water, fat and

sugar molecules.

When food is exposed to microwaves, its molecules begin moving rapidly, which causes heating.

The penetration depth of waves into the food is approximately 2.5 cm; if the food is thicker, the core of the food will be cooked by conduction, as in traditional cooking. It is valuable to note that the microwaves trigger within the food a simple thermal phenomenon and that they are not harmful to one’s health.

This appliance’s packing materials are recyclable. Recycle them and play a role in protecting the environment by disposing of them in municipal containers provided for this purpose.

Your appliance also contains various recyclable materials. Thus it is stamped with this logo to indicate to you that used appliances should be mixed with

other waste. The recycling of appliances organised by your manufacturer will take place under the best conditions, in compliance with European directive 2002/96/CE concerning electrical and electronic equipment waste. Consult your city hall or your retailer to find the drop-off points for used appliances that is nearest to your home. We thank you for your help in protecting the environment.

Fig.01

•OPERATING PRINCIPLE •PROTECTING THE ENVIRONMENT

EN 2/INSTALLING YOUR APPLIANCE

Warning:

Ensure that your appliance has not suffered any damage during transport (deformed seal or door, etc...). If you see any kind of damage, before doing anything else, contact your retailer.

In order to easily locate the reference information for your appliance, we recommend that you note these data on the “After-Sales Service Department and Customer Relations” page.

Ensure that:

- The electrical installation has sufficient

voltage.

- The electrical wires are in good condition.

- The diameter of the wires complies with the

installation requirements.

- Your electrical installation is equipped with

16-ampere thermal-sensitive protection.

In case of doubt, consult your electricianinstaller.

The electrical connections are made before the appliance is installed in its housing.

Electrical safety must be provided by a correct build-in. During installation and maintenance operations, the appliance must be unplugged from the electrical grid; fuses must be cut off or removed.

The oven must be connected with a power cable (standardized) with three 1.5 mm

conductors (1 ph + 1 N + ground) that must be connected to a monophase 220-240 V network via a CEI 60083 standardised receptacle (1 ph + 1 N + ground lead) or in accordance with installation rules. The safety wire (green-yellow) is connected to the appliance’s terminal and must be connected to the ground lead of the electrical set-up.

In the case of connections with an electric receptacle, it must remain accessible after installation of the appliance. The oven’s neutral conductor (blue wire) must be connected to the network’s neutral conductor.

In your electrical installation, allow for a useraccessible device that must be able to separate the appliance from the main power supply and whose contact opening is at least 3 mm above all the terminals.

If the power cable is damaged, it should be replaced by the manufacturer, its after-sales service department or by a qualified person to avoid danger.

Warning:

We cannot be held responsible for any accident resulting from an inexistent, defective or incorrect ground lead.

If the oven malfunctions in any way, unplug the appliance or remove the relevant fuse at the oven’s connection lead-in.

•BEFORE HOOK-UP

•ELECTRICAL CONNECTION

2/INSTALLING YOUR APPLIANCE

The oven can be installed under a worktop or in a column of cabinetry (open* or closed) having the appropriate dimensions for

built-in installation

(Fig.02).

Do not use your appliance immediately (wait approximately 1 to 2 hours) after having moved it from a cold location to a hot location because the condensation may cause a malfunction.

•BUILDING IN

Fig.02

550 int.

600 ext.

450 int.

456

592

547

450 int.

EN 3/DESCRIPTION OF YOUR APPLIANCE

Fig.03

•

Turntable:

Enables even cooking of foods with no handling. It rotates indiscriminately in both directions. If it is not rotating, ensure that all the components are properly positioned. Do not attempt to rotate it manually; you risk damaging the drive system. It can be used as a cooking dish. To remove it, take hold of it using the access zones defined in the cavity.

•

The driver:

causes the glass turntable to

rotate

(Fig.04)

•

The base rollers:

The wheels must be

placed in the right direction

(Fig.04)

. In the event of poor rotation, ensure that there are no foreign matter under the wheels.

Control panel

Cavity

Turntable

Door handle

•THE APPLIANCE

Fig.04

•

Grid (Fig.05):

Allows you to toast, brown or grill. The grid should not under any circumstances be used with other metal cookware on the microwave, grill + microwave or fan heat + microwave settings. However, you can reheat food in an aluminium tray if you insulate it from the grid using a plate.

•

Side racks (Fig.06):

2 two shelf supports with hooks allow you to use the grid at three heights.

The three insertion heights are available based on the type of cooking and food

(Fig.07/08).

For the

Grill or Grill + Microwave functions,

use the grid at insertion level 1 for thick foods such as roasts and at insertion level 3 for thinner foods such as chops or sausages.

For the

fan heat or microwave + fan heat

function,

insert the grid at level 1 or 2

depending on the dish.

3/DESCRIPTION OF YOUR APPLIANCE

Fig.06

Fig.07

➀

➁

➂

Fig.08

Fig.05

•ACCESSORIES

The automatic programme selector allows you to choose the

automatic function and the category of food.

The START/STOP touch control allows you to start a programme, and

suspend or stop a programme underway.

The “ - / + ” touch controls allow you to set the time, duration of

programmes, weight of the food, memorised programmes and the temperature for fan heat cooking programmes.

Pushing both touch controls simultaneously stops the rotation of the turntable to allow for the use of dishes that require all the space available in the oven.

The MEMO touch control lets you programme and initiate the memory

function. Pressing for five seconds allows you to access the CLOCK function to set the time.

The FUNCTION selector lets you choose the programme type.

•CONTROL PANEL

3/DESCRIPTION OF YOUR APPLIANCE

Fig.09
