Caple CGi900SS Instruction Manual

INSTALLATION AND OPERATING

INSTRUCTION BOOKLET

Chimney Extractors

CGI900SS

IMPORTANT: You must read this instruction Book before

installing or using this appliance and retain it for future use.

Caple Products

Telephone [phone]

Facsimile 0117 982 6878

1

YOUR APPLIANCE

Thank you for buying your new Cape Chimney Extractor.
To ensure that you get the best results from your new Chimney Extractor, we strongly suggest

that you read this instruction manual thoroughly before use.
This manual contains installation advice, usage instructions and a cleaning guide, as well as other

important facts about your Caple Chimney Extractor.
If treated with care, your Caple Chimney Extractor should give you years of trouble-free use.
To register ownership, please ensure you complete and return the guarantee card supplied with the

appliance.

CGI900SS

These cooker hoods are designed to extract unpleasant odours from the kitchen; they are not intended to
extract steam.

Note: CE Marking certifies that this appliance complies with the requirements laid down in EEC directive 89:336.
(Electromagnetic compatibility) and subsequent modifications and Low Voltage directive 72/23/E.

2

IMPORTANT SAFETY INFORMATION

These warnings are provided in the interests of your safety. Ensure that you understand them all
before installing or using this appliance. Your safety is of paramount importance. If you are unsure
about any of the meanings of these warnings contact the Customer Care Department.

Installation

 Installation work must be undertaken by a qualified electr ician or a competent person.
 Electrical connection must b e by a quali fied elec trician.
 This hood must be installed in accordance with the installation instructions and all measurements must be adhered

to.

 If the cooker hood is installed for use above a gas appliance then the provision for ventil ation must be in accordance

with the Gas Safety Codes of Practice BS.6172, BS.5440 and BS.6891 (Natural Gas) and BS.5482 (LP Gas) 1994 , the
Gas Safety (Installation & Use) Regulations, the Building Regulations issued by the Department of the Environment ,
the Bu i ld i n g st andard s (Sco tland) (Consolid ated) Regulati ons i ssued by the S cotti sh Dev elopmen t Depar tment .

 The fan motor of this cooker hood incorporates a cut out device which will operate if the motor becomes

overheated. If the cut-out device is activated, switch off the fan motor and allow the cooker hood to cool. The
cut-out device will reset itself when the fan motor has cooled significantly.

 It is dangerous to alter the specifications or modify this product in any way.
 When installed between adjoining wall cabinets the wall cabinets must not overhang the hob.
 If the room where the hood is to be used contains a fuel burning appliance such as a central heating boiler then its

flue must be of the room sealed or balanced flue type.

 If other types of flue or appliances are fitted ensur e that th ere is an adequ ate supply of air to the room .
 The ducting system for this a pplia nce m ust not be co nnecte d to an y ex istin g vent ilatio n syst em whic h is bei ng

used for any other purpose.

 This extractor is supplied with flexible ducting that extends to 2 metres.
 If site conditions make it necessary to extend the length, the size of the addi tional ducting must not be of a le sser

cross sectional area and the ducting outlet must provide minimal flow resistance. Failure to follow this instruction
will increase the noise level and overload the motor. THE GUARANTEE WILL ALSO BE INVALIDATED.

Child Safety
 This appliance is designed to be operated by adults. Children should not be allowed to tamper with the controls or

play with the appliance.

During Use

 This product is for domestic use only.
 Never leave frying pans unattended during u se as over-heated fats and oi ls might catch fi re.
 Never do flambé cooking under this cooker hood.
 Do not leave naked flames under the hood.

Maintenance and Service

 This appliance can be a hazard if the metal filters are not washed regularly.
 If charcoal filters are fitted the type and frequency of cooking will determine when the charcoal filter will require

changing. In any case, these must be replaced every three/four months.

 Under no circumstances should you attemp t to r epai r the appliance yourself. Repairs carried out by inexperienced

persons may cause injury or more serious malfunction . Refer to your Caple S e r v ic e C e n t re .

3
